Scientific Toys 5058-24GR R/C Vehicle User Manual
Scientific Toys Ltd R/C Vehicle
User Manual
Unscrew to open
the battery cover
Trigger
LED
2 x AA
batteries
Bottom Panel
of transmitter
DIAGRAM 3 DIAGRAM 4
DIAGRAM 1 DIAGRAM 2
DIAGRAM 6
DIAGRAM 7
Steering
alignment
lever
DIAGRAM 5
On
6 x AA
Batteries
On/Off
switch
Unscrew
to open
Battery
cover
1
3
1+B 1+A
3+B 3+A
2Stop
SIZE: 210MM X 297MM PN#65-6102-000-0100
BATTERY INSTALLATION
PERFORMANCE TIPS
1. Operate your vehicle in a safe place. Do not drive in the street. Avoid driving
through sand, mud, and water, which can impair the performance of your vehicle.
2. Do not leave your vehicle near sources of heat or under direct sunlight for long
periods of time.
3. Do not expose your transmitter or car to humidity for long periods of time as
dampness can damage interior mechanism.
4. Clean the toy vehicle regularly with a slightly damp cloth.
5. When the vehicle slows down or begins to move erratically, replace the batteries
with new ones.
6. Concrete walls, metal posts, wire fence, and other electrical appliances and
machineries can interfere with the transmission signal of your transmitter and
result in erratic performance of your car. In this case, change to a different location.
7. If another radio control vehicle or CB radio is operating at your same location,
they may interfere with the performance of your vehicle.
8. Alkaline batteries are highly recommended.
BATTERY CAUTIONS
1. For maximum performance, use alkaline batteries.
2. Do not mix old and new batteries.
3. Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries.
4. Do not recharge non-rechargeable battery.
5. Ensure batteries are inserted with the correct polarity.
6. Remove batteries when toy is not in use.
7. Remove exhausted batteries from toy and dispose of in accordance with the
makers recommendation.
8. Rechargeable batteries should only be charged under adult supervision.
9. Remove rechargeable batteries from toy before charging.
10. The supply terminals are not to be short-circuited.
Battery/Batteries should be installed by adult only. The toy is not intended for children
under 3 years old.
Keep packing for reference since it contains important information.
Exhausted batteries are to be removed from the toy.
WARNING:
NOT SUITABLE FOR CHILDREN UNDER THE AGE OF 36 MONTHS AS SMALL
PART(S) AND ENTANGLEMENT/ STRANGULATION HAZARDS.
PACKAGING MATERIALS ARE NOT TOYS.
PLEASE REMOVE ALL PACKAGING AND PACKING TAGS/WIRES BEFORE
GIVING THIS TOY TO YOUR CHILD. COLOUR, DESIGNS AND DECORATIONS
MAY VARY FROM THOSE SHOWN IN THE PHOTOGRAPHS.
HAIR ENTANGLEMENT MAY RESULT IF THE CHILD'S HEAD IS TOO CLOSE TO
THE MOTORISED UNIT OF THIS TOY.
ATTENTION PARENTS
It is recommended that this toy and all accessories be periodically examined for
potential hazards and that any potentially hazardous parts be repaired or replaced.
HOW TO INSTALL BATTERY IN VEHICLE
1. Turn over the vehicle and push the ON/OFF to "OFF" position. (See Diagram #1)
2. Open the battery cover. (See Diagram #1)
3. Follow the "arrow" sign and insert the battery pack into the battery compartment.
Make sure the (+) (–) polarity is correct. (See Diagram #2)
4. Replace the battery cover.
CAUTIONS
1. Non-rechargeable batteries are not to be recharged.
2. Rechargeable batteries are to be removed from the toy before being charged.
3. Rechargeable batteries are only to be charged under adult supervision.
4. Different types of batteries or new and used batteries are not to be mixed.
5. Only batteries of the same or equivalent type as recommended are to be used.
6. Batteries are to be inserted with the correct polarity.
7. Exhausted batteries are to be removed from the toy.
8. The supply terminals are not to be short-circuited.
WARNING: CHOKING HAZARD - SMALL PARTS, NOT FOR CHILDREN UNDER
3 YEARS.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If you cannot eliminate the interference, the FCC requires that you stop using your
equipment. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
© 2017 SCIENTIFIC TOYS LTD. 1108, TOWER B,
14 SCIENCE MUSEUM ROAD, TSIMSHATSUI, HONG KONG.
PRINTED IN CHINA
O.I. NO.6102
WARNING:
CHOKING HAZARD-
Small parts, Not for chidren under 3 years
HOW TO INSTALL BATTERY IN TRANSMITTER
1. Remove battery cover and install 2 x AA batteries by matching + and – poles as
indicated in the battery compartment. (See Diagram #3)
2. Replace the battery cover.
Note: Remove battery after you have finished using your vehicle.
HOW TO PLAY
PAIRING TRANSMITTER WITH VEHICLE
1. Turn ON the vehicle (See Diagram #5).
2. Install 2 x AA battery in the transmitter, the pairing LED light on the transmitter will
flash (See Diagram #3).
3. If pairing success, the pairing LED light will turn OFF
4. You must pairing the transmitter with the vehicle within 45 seconds, after 45 seconds
you must push the control on the transmitter to pair again.
5. You must repeat pairing again when the transmitter needs to replace new batteries.
Notes:
1. If pairing failed, reinstall the battery of transmitter, move closer and then try again.
2. If more then one vehicle are pairing at the same time, pair each vehicle one by one.
Vehicle has memory to store the paired data, no need to pair each time play until
replace the battery in transmitter
OPERATION
1. Operate the vehicle with the transmitter (See Diagram #6).
2. Turn OFF the vehicle after playing and remove all batteries from the transmitter
and the car.
3. To adjust steering alignment, adjust the "Steering Alignment Lever" on the
underside of the vehicle when the vehicle does not run straight forward
(See Diagram #7).
