1-800-SCOTSMAN Fax: 847-913-9844 customer.relations@scotsman-ice.comwww.scotsman-ice.com

775 Corporate Woods Parkway, Vernon Hills, IL 60061

SSM Plus

Extends the life of your Scotsman machine and provides cleaner, more consistent ice.

Now with AquaArmor with AgION , a silver-based anti-microbial compound that reduces the

growth of bacteria, microorganisms, algae, mold and slime on ice machine surfaces, preventing

premature clogging.

Ultrafine half-micron filtration, combined with food-grade polyphosphate, assures that chlorine,

off-tastes, odors and particles stay out of your ice.

Filtration can reduce unscheduled water-related maintenance calls by as much as 40%.

Easy to install and maintain.

Water Filters

Water Filters

SSM Plus and Aqua Patrol Plus Water Filtration Systems

®

®

®

with

®

Certification

8

Features

®

AquaPatrol Plus

Leaves chlorine in water to keep machine cleaner longer.

Polyphosphate feed to inhibit scale build up.

Easy to install and maintain.

Tighter pore size now eliminates more undesirable compounds.

New smaller footprint gives operations more flexibility.

The SSM and AquaPatrol Plus filter and replacement cartridge have been tested and listed by

NSF only for the functions listed above. Check for compliance with state and local law and

regulations. Do not use where the water is micro-biologically unsafe, or with water of unknown

quality without adequate disinfection before or after the unit. Can be used on water that may

contain filterable cysts.

NSF International Standards

Standard No. 42: Aesthetic Effects

Chemical Unit

Chlorine reduction, class 1

Taste and odor reduction

Mechanical Filtration Unit

Particle reduction, class 1

99.9% reduction of particles

1/2 micron and larger sizes

®

Standard No. 53: Health Effects

Mechanical Filtration Unit

Turbidity reduction

Cyst reduction

Asbestos reduction

Warranty

• 5 years on manifold parts only

Warranty valid in North, South & Central America.

Contact factory for warranty in other regions.

Water Filters

Specifications

Model

Number

Dimensions Description Maximum Flow

W(gallons/minute)D H

SSM Plus

SSM1-P

SSM2-P

SSM3-P

5.6

16.6

21

4.75

5.5

5.5

30.5

29.26

29.26

1.67

3.34

5.01

Single System for Cubers up to 650 lb (295 kg) and flakers, nuggets and

nugget dispensers up to 1,200 lb (544 kg).

Double System for Cubers up to 650 lb (295 kg) and flakers, nuggets and

nugget dispensers up to 1,200 lb (544 kg).

Triple System for Cubers over 1,300 lb (544 kg)

AquaPatrol

Plus

AP1-P

AP2-P

AP3-P

5.6

16.6

21

4.75

5.5

5.5

21.5

19.26

19.26

2.1

4.2

6.3

Single System for Cubers up to 650 lb (295 kg) and flakers, nuggets and

nugget dispensers up to 1,200 lb (544 kg).

Double System for Cubers up to 650 lb (295 kg) and flakers, nuggets and

nugget dispensers up to 1,200 lb (544 kg).

Triple System for Cubers over 1,300 lb (544 kg)

Shipping Accessories

SC10 Replacement Filter (package of 40)

SC20 Replacement Filter (package of 20)

Replacement Cartridge for SSM Plus (package of 1)

Replacement Cartridge for SSM Plus (package of 6)

SC10RC40

SC20RC20

SSMRC1

SSMRC6

Replacement Cartridge for AquaPatrol Plus (package of 6)

Replacement Cartridge for AquaPatrol Plus (package of 1)

APRC6-P

APRC1-P

Model Number Description

Scotsman recommends all ice machines have water filtration.

1-800-SCOTSMAN Fax: 847-913-9844 customer.relations@scotsman-ice.comwww.scotsman-ice.com

775 Corporate Woods Parkway, Vernon Hills, IL 60061

Specifications and design are subject to change without notice.

Operating Requirements

Minimum

Air Temperatures

Water Temperatures

Water Pressures

50°F (10°C)

40°F (4.4°C)

20 PSIG (1.4 bar)

100°F (38°C)

100°F (38°C)

80 PSIG (5.5 bar)

Maximum

SIS-SS-SSMP 01-15© 2015 Scotsman Ice Systems.

Water Filters

SSM Plus and Aqua Patrol Plus Water Filtration Systems

®

D

D

D

D

D

W

W

WW

W

H

H

H

H

H

INLET

3/8” FNPT OUTLET

3/8” FNPT

OUTLET

3/4” FNPT

INLET

3/4” MNPT

INLET

3/4” MNPT

OUTLET

3/4” FNPT

INLET

3/4” FNPT

OUTLET

3/4” FNPT

INLET

3/4” FNPT

OUTLET

3/4” FNPT

SSM1-P &

AP1-P

SSM2-P &

AP2-P

SSM3-P &

AP3-P

SC20 -A

SC10 -A

SSM1-P:

SSM2-P:

SSM3-P:

AP1-P:

AP2-P:

AP3-P:

SC10-A:

SC20-A:

21” x 10” x 6”

21” x 10” x 10”

21” x 10” x 10”

21” x 10” x 10”

21” x 10” x 10”

21” x 10” x 10”

6” x 6” x 17”

6” x 6” x 17”

7/3

11/5

16/7

7/3

11/5

16/7

5/2

11/5

Model

Number

Dimensions Weight

(lb/kg)

®

®

®

Coarse

Pre-Filters

SC10-A

SC20-A

5.16

5.16

5.5

5.5

12.44

22.44

5

10

Single System for Cubers up to 650 lb (295 kg) and flakers, nuggets and

nugget dispensers up to 1,200 lb (544 kg).

Single System for Cubers up to 650 lb (295 kg) and flakers, nuggets and

nugget dispensers up to 1,200 lb (544 kg).
