V3_2015
w: www.sealite.com
e: info@sealite.com
Sealite Pty Ltd
AUSTRALIA
t: +61 (0)3 5977 6128
Sealite USA, LLC
USA
t: +1 (603) 737 1311
Sealite United Kingdom Ltd
United Kingdom
t: +44 (0) 1502 588026
The Sealite Advantage
•Over424,000cd,white
•Over5NMvisibledaytime
range
•Over23NMvisiblenight-time
range
•Wideoperatingvoltage
range:universalDC10–30VDC
oruniversalAC110–240VAC
•PCorIRProgrammerfor
setup,diagnostic&testing
•Internalorexternalphotocell
options
•Usercongurableday/night
&twilightintensitysettings
•Advancedremotemonitoring
features
•Internaldata-loggingfor
longtermretentionofkey
operationalparameters&
alarmconditions
•Optionalsolarpowered
congurationsavailable
TheSealiteSL-RLSeriesisalongrange,highintensityrangelightdesignedtogive
vesselsclearnightand/ordaytimenavigation.Adaytimerangeofover5NManda
night-timerangeinexcessof23NMcanbeachieved.
LongRangeLEDOpticswithUltra-LowPower
Consumption
Providing over 424,000cd, the Sealite Range Light is highly
efcient and ideal for solar power systems.
RobustConstruction
The Sealite Range Light is extremely robust and of high-quality
construction. The unit is built from CNC machined marine grade
aluminium alloy, subject to 7-stage powder coating. The IP68
rated enclosure offers maximum resistance to weather.
AdvancedPCorIRProgramming
Sealite’s convenient PC Conguration Tool or IR programmer
allows a host of features to be user set including;
• Multipleintensitysettings
• 310ashsettingsincludingcustomcharacter
• Adjustableon/offluxlevels
• Lowbatterythreshold
• GPSsynchronisationoffset
• Alarmconditions
OptionalGPSSynchronisation
ForashsynchronisationoflanternsaGPSmodulemaybetted.
Multiplegeneralpurposeinputsandoutputsallowforhardwiresynchronisationandmain/standby
lantern congurations.
OptionalGSMMonitoring&Control
TheRangeLightmayalsobettedwithaGSMmoduleformonitoringandcontrol–enablingusers
to access real-time diagnostic data and change light settings via cell-phone. The system can also
beconguredtosendoutalarmSMStextmessagestodesignatedcellulartelephonenumbers.
Users can also have alarms and reports sent to designated email addresses.
OptionalType1orType3AIS
The SL-RL Series Range Light is available with a class-leading integrated, low-powered Type 1 or Type
3 AIS. When tted, the AIS is encapsulated within the body of the light to maintain the weatherproof
integrity.VHFandGPSantennastosupportAISaretteddirectlytothetopsurfaceofthelantern
-offeringsignicantadvantagesovercompetitor’sproductswithexternallywiredGPS&VHF
antennae and AIS systems.
HighIntensityLEDRangeLight
SL-RL Series
T/CT/C
Read Lux
Flash Code Intensity Battery Status
Test / Congure
1 2 3
4 5 6
7 8 9
R0L
FC I B
Lux D-N Lux N-D
IR Programmer
Optional
GPS Sync
GSM
AIS
Name
Type
Latitude
Longitude
Name
Type
Latitude
Longitude
Name
Type
Latitude
Longitude
Name
Type
Latitude
Longitude
Standard
PC
Configuration
Tool
RS232/422/485
Port
Hard-wire Sync
Horizontal adjustment and
heavy duty, cast aluminium base
Precision LED lenses
Powder coated,
marine grade
aluminium alloy to
resist the elements
Vertical adjustment
Wide operating
voltage range:
DC10–30VDCor
AC110–240VAC
Light sensor for
automatic night
activation
Protective hood
Precision
LED Optic
UV-stabilised
acrylic lens
Horizontal adjustment
200mm bolt pattern
for ease of installation
Available in
universal AC or
universal DC
w: www.sealite.com
e: info@sealite.com
Sealite Pty Ltd
AUSTRALIA
t: +61 (0)3 5977 6128
Sealite USA, LLC
USA
t: +1 (603) 737 1311
Sealite United Kingdom Ltd
United Kingdom
t: +44 (0) 1502 588026
V3_2015
HighIntensityLEDRangeLight
SL-RL Series
332.2
316.8
230.0
30°
PCD 200
16 X 15 Slots
6 Places
SPECIFICATIONS•*
SL-RL-04
LightCharacteristics
Light Source High efciency LEDs
Available Colours White as standard. Other colours available on request
MaximumLuminousIntensity(cd)† Refer to table
VisibleRange(NM) 3degverticle&3deghorizontal,white:
AT@0.74:23.4NMnight-time,5NMdaytime
AT@0.85:37.3NMnight-time,6.3NMdaytime
Horizontal Output (degrees) 3 as standard. Other options available
Vertical Divergence (degrees) 3 as standard. Other options available
Available Flash Characteristics Upto310including256IALArecommended,&1custom
Intensity Adjustments User adjustable
LED Life Expectancy (hours) >100,000
ElectricalCharacteristics
Power (W) VDCModel:upto28.8W VACModel:upto38W,50VA
Circuit Protection Polarity protected
Nominal Voltage VDCModel:10–30VDC VACModel:110–240VAC
PhysicalCharacteristics
BodyMaterial 7-stage powder-coated aluminium
LensMaterial UV-stabilised acrylic
Lens Design MultipleLEDoptic
Mounting 3&4hole200mmboltpattern
Height(mm/inches) 332/13
Width(mm/inches) 226/9
Depth(mm/inches) 317/12½
Mass(kg/lbs) 7.5/16.5
Product Life Expectancy Up to 12 years
EnvironmentalStandards
Shock MIL-STD-202GTestConditionH,Method213B30Gverticaland35G
horizontalshock
Vibration MIL-STD-202G,TestConditionB,Method204D5Ginallaxes
Ice Loading Ratedtowithstand22kg/m2
Wind Exposure Ratedtowithstand140knots
Hail Impact Ratedtowithstand25mmdiametericeballimpactat20m/s
Humidity 0–100%,condensing
Temperature Range -40 to 80°C
Certications
CE&Electrical FCCPart15Rules&ICES-003.
EN61000-6-1: 2007 (IEC61000-6-1:2005) Part 6-1 Immunity.
EN61000-6-3: 2007 (IEC61000-6-3: 2006) Electromagnetic compatibility
(EMC)-Part6-3Emission.
IEC61000-4-2: 2008 Ed 2 Part 4-2 Electrostatic discharge immunity test
Level 4.
IEC61000-4-3: 2010 Ed 3.2 Part 4-3. Radiated, radio-frequency,
electromagnetic eld immunity.
IEC61000-4-6:2008Ed3.,Electromagneticcompatibility(EMC)-Part
4-6 Immunity.
IALA Signal colours compliant to IALA E-200-1
AmbientlightlevelscomplianttoIALAGuidelineNo.1038
Quality Assurance ISO9001:2008
Waterproof IP68
IntellectualProperty
Trademarks SEALITE®isaregisteredtrademarkofSealitePtyLtd
Warranty* 3 years
OptionsAvailable •GPSSynchronisation
•AISType1orType3
•GSMMonitoring&ControlSystem(ExternalforAC,InternalforDC)
•RS232/422/485Port
•Hard-wireSynchronisation
•Varietyofsolar/batterycongurations
•Multipledivergencelens
•Birddeterrentspikes
• Specications subject to change or variation without notice
* Subject to standard terms and conditions
† Intensity setting subject to solar availability
OpticalPerformance
Maximumluminousintensity
(cd)
Divergence
(deg)
RED GREEN WHITE
3(V) x 3(H) 170,000 150,000 424,000
3(V) x 8(H) 60,000 53,000 140,000
