Manual
EV-290 Transmitter
Overview:
The Secure Wireless sample transmitter for AMAC has two tact switches on the printed
circuit board (PCB) that allow flexibility in operation and programming. When in
standard AMAC mode pressing anywhere on the top of the button will ensure that either
or both of the PCB tact switches will be depressed. If any tact switch is pressed, the unit
will send its transmission immediately.
Programming:
In programming you can choose to change the serial number OR change the operation of
the transmitter from supervised to supervised with polling.
To change the serial number:
1) Press and HOLD both buttons on the AMAC sample transmitter. You will need
to press both the upper right and upper left corners of the one button to make
sure that you are pressing both buttons simultaneously.*
2) Continue holding the buttons, The LED will turn OFF after it is done
transmitting (approximately 3 seconds) and will turn back ON after
approximately 5 additional seconds, RELEASE both buttons.
3) Use the left tact switch for a ‘0’ and the right for a ‘1’. Example; if the AMAC
code that you desire is 28 then you will enter the data as follows;
0 0 1 0 1 0 0 0
_ _ _ _ _ _ _ _
4) You will also need to add a 0001 for a regular AMAC remote or a 1110 for a
silent panic type key.
This encoding may be different from what you have done in the past but this is the right
format for Hex to Binary encoding.
5) Once all 12 digits have been entered the LED will flash rapidly.
* I have supplied a two button rubber insert for programming if you feel it is easier
during the programming sequences.
To change from Supervised to Supervised with Polling:
1) Press and HOLD both buttons on the AMAC sample transmitter. You will need
to press both the upper right and upper left corners of the one button to make
sure that you are pressing both buttons simultaneously.*
2) Continue holding the buttons, The LED will turn OFF after it is done
transmitting (approximately 3 seconds) and will turn back ON after
approximately 5 additional seconds, WAIT until the LED begins to flash
(approximately 5 seconds). The total hold time is approximately 13 seconds.
Once the LED is flashing, Release buttons.
3) Press Button # 1 (left) for Standard AMAC supervised unit. LED will confirm
choice with 1 flash OR Press button # 2 (right) for Supervised with polling,
LED will confirm choice with 2 flashes.
4) For testing purposes this unit will supervise itself every 10 seconds and will
send a supervisory heartbeat if programmed for supervised with polling.
* I have supplied a two button rubber insert for programming if you feel it is easier
during the programming sequences.
Battery Information:
Battery statistics are as follows:
4.8uA Standby Current
1.8uA Wake up time
.001uA Supervisory
.17uA 1 Button press per day
6.771uA Total battery draw
Battery is a CR2025 with 160mA power
Calculation is as follows:
(160,000/6.771)/8760= 2.6975 years on average
This is actual field usage since you do not activate the battery until it is ready for use.
Supervisory with Polling Transmission:
When the Polling is enabled, the heartbeat transmission is sent every 6 hours. It sends the
12.5 mS long data packet 5 times as a means to insure system integrity.
Default Programming:
The AMAC unit will be pre-programmed at the factory with a standard code and
defaulted as a standard supervised device without any polling transmissions.
Low Battery Trigger:
Currently we check for a low battery every 12 hours for 3 consecutive wake ups. That
means that when a low battery is detected we must see it on three consecutive occasions
before we will lock and transmit low battery. When the AMAC remote detects low
battery it will take a minimum of 36 hours before it will transmit.
FCC Compliance Statement:
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
