Installation Guide

Installation Guide

V940B Network Dome Cameras

XX291-00-01

Vicon

Industries Inc. does not warrant that the functions contained in this

equipment will meet your requirements or that the operation will be entirely error

free or perform precisely as described in the documentation. This system has not

been designed to be used in life-critical situations and must not be used for this

purpose.

Document Number: 8009-8291-00-01

Product specifications subject to change without notice.

Issued: 10/17 Copyright © 2017 Vicon Industries Inc. All rights reserved.

Vicon Industries Inc.

Tel: 631-952-2288) Fax: 631-951-2288

Toll Free: 800-645-9116

24-Hour Technical Support: 800-34-VICON

(800-348-4266) UK: 44/(0) 1489-566300

www.vicon-security.com

Notice

Copyright Statement

This manual may not be reproduced in any form or by any means to create any

derivative such as translation, transformation, or adaptation without the prior

written permission of Vicon Industries.

Vicon Industries reserves the right to change this manual and the specifications

without prior notice. The most recent product specifications and user

documentation for all Vicon Industries products are available on our web site

www.vicon-security.com.

Trademarks

Vicon and its logo are registered trademarks of Vicon Industries.

All other trademarks that may appear belong to their respective proprietors.

FCC Warning

The V940B Series Bullet Cameras comply with the FCC rules.

Operation is subject to the following two conditions:

- This device will not cause harmful interference.

- This device must accept any interference received, including interference that

may cause undesired operations.

The V940B Series HD IR Smart IP Bullet Camera have been tested and found to

comply with the limits for a Class A digital device, pursuant to the FCC rules.

With these rules and regulations being obeyed to maintain the good working

condition of device, the operation is not supposed to be affected by the external

interruptions under certain circumstances. This device is electromagnetic, so all

the installation and application processing along the device has to follow strictly

to the manual or it may hamper telecommunications around. Meanwhile, there is

no guarantee that interference will not occur in a certain particular installation

situation.

Read this manual carefully before installation. This manual

should be saved for future use.

Important Safety Instructions and Warnings:

- Electronic devices must be kept away from water, fire or high magnetic

radiation.

- Clean with a dry cloth.

- Provide adequate ventilation.

- Unplug the power supply when the device is not to be used for an extended

period of time.

- Only use components and parts recommended by manufacturer.

- Position power source and related wires to assure to be kept away from ground

and entrance.

- Refer to qualified personnel for all service matters.

- Save product packaging to ensure availability of proper shipping containers

for future transportation.

Indicate that the uninsulated components within the product may carry a

voltage harmful to humans.

Indicate operations that should be conducted in strict compliance with

instructions and guidelines contained in this manual.

Warning: To avoid risk of fire and electric shock, keep the product away

from rain and moisture!

CONTENTS

Chapter I System Introduction ................................................................ 1

1.1 Product Description............................................................................... 1

1.2 Product Model ....................................................................................... 2

1.3 Product Features.................................................................................... 2

1.4 System Requirement ............................................................................. 4

1.5 Specifications ........................................................................................ 4

1.6 Notes ..................................................................................................... 8

Chapter II Installation .............................................................................. 9

2.1 Installation Precautions ......................................................................... 9

2.2 Dimensions ........................................................................................... 9

2.3 Installation of Camera ........................................................................... 9

Chapter III IE Browser Settings ............................................................ 13

3.1 Equipment Connection ........................................................................ 13

3.2 Software Installation ........................................................................... 13

Chapter IV Basic Function Operation ................................................... 16

4.1 Live View ............................................................................................ 16

4.2 System ................................................................................................ 20

4.2.1 System Information ..............................................................................20

4.2.2 Time Settings .......................................................................................20

4.2.3 Advanced Settings................................................................................22

4.3 Network Settings ................................................................................. 25

4.3.1 Network Settings..................................................................................26

4.3.2 FTP Settings .........................................................................................27

4.3.3 SMTP Settings .....................................................................................27

4.3.4 HTTPS Settings ...................................................................................28

4.3.5 802.1X Settings ....................................................................................28

4.3.6 QOS Settings .......................................................................................29

4.3.7 IGMP Settings......................................................................................29

4.3.8 SIP Settings ..........................................................................................30

4.3.9 DDNS Settings.....................................................................................31

4.3.10 UPnP Settings ....................................................................................32

4.3.11 NAS Settings......................................................................................33

4.3.12 RTSP ..................................................................................................34

4.3.13 IP Filter ..............................................................................................34

4.3.14 Monitor Connect ................................................................................36

4.4 Camera Settings .................................................................................. 37

4.4.1 Basic Settings ......................................................................................37

4.4.2 Exposure Settings ................................................................................38

4.4.3 Effect Settings ......................................................................................39

4.4.4 White Balance ......................................................................................41

4.4.5 Focus Settings ......................................................................................42

4.4.6 IR Set ...................................................................................................44

4.4.7 Reset ....................................................................................................44

4.5 Video and audio Settings ..................................................................... 45

4.5.1 Video Settings ......................................................................................45

4.5.2 OSD .....................................................................................................48

4.5.3 Motion Detection .................................................................................51

4.5.4 Privacy Mask .......................................................................................52

4.5.5 ROI ......................................................................................................53

4.5.6 Storage Path .........................................................................................54

4.5.7 Audio Settings ......................................................................................54

4.6 Video Contents Analysis Functions ..................................................... 55

4.6.1 Camera Tampering ...............................................................................55

4.6.2 Line Cross Detection............................................................................57

4.6.3 Intrusion Detection ..............................................................................59

4.7 Alarm Settings ..................................................................................... 60

4.8 Storage Management ........................................................................... 63

4.8.1 Record Settings ....................................................................................63

4.8.2 Replay ..................................................................................................64

4.9 User Settings ....................................................................................... 65

4.10 System Log ....................................................................................... 68

Appendix I Questions & Solutions ......................................................... 69

1

Chapter I System Introduction

1.1 Product Description

The V940B Series Bullet Camera adopts progressive scan CMOS sensor with an

internal HD motorized zoom lens. The camera has an internal Smart IR

technology that provides 98 ft/30m IR distance. The IR LEDs output power can

be adjusted automatically according to the brightness of the scene so that the IR

LEDs do not work at full capacity. The power consumption of the complete unit

is greatly lowered and the service life is lengthened.

V940B Series offers 2MP cameras and 4MP cameras; the 4MP cameras can

support up to 2592×1520@20fps video output. All cameras use H.265/H.264/M-

JPEG encoding, providing output with excellent definition and color

reproduction, more detailed and accurate information and the accuracy of smart

analysis that can, effectively, be guaranteed.

V940B Series cameras boast of smart functions, including camera tampering, to

detect if the camera/lens has been moved, blocked, low/high brightness or

defocused; intrusion detection, providing protection for key areas; and line cross

detection, providing border protection, which are important features for many

enterprises. These cameras can be widely used in sites that demand high

definition image quality in low lighting environments, such as ordinary buildings,

supermarkets, hotels, shops, parks, schools, factories, warehouses, underground

parking lots, etc.

The compact design makes it easy to install; the integral wall mount allows

adjustment of the angle of view.

2

1.2 Product Model

This manual is for the following models:

V942B-W312MIR HD Megapixel IR IP Bullet Camera, WDR,

Intelligence, 2.0Mpx, 1/3"CMOS, day/night,

H.265/H.264/M-JPEG, with audio alarm, 2.7~12mm

motorized zoom lens, 30m IR distance, IP67,

PoE/12VDC/24VAC

V944B-W312MIR HD Megapixel IR IP Bullet Camera, WDR,

Intelligence,4.0Mpx, 1/3"CMOS, day/night,

H.265/H.264/M-JPEG, with audio alarm, 2.7~12mm

motorized zoom lens, 30m IR distance, IP67,

PoE/12VDC/24VAC

V942B-W310MIR-XW HD Megapixel IR IP Bullet Camera, WDR,

Intelligence, 2.0Mpx, 1/2.8"CMOS, day/night,

H.265/H.264/M-JPEG, with audio alarm, 3~10.5mm

motorized zoom lens, 30m IR distance, IP67,

PoE/12VDC/24VAC

V942B-W310MIR-XS HD Megapixel IR IP Bullet Camera, WDR,

Intelligence, 2.0Mpx, 1/1.9"CMOS, day/night,

H.265/H.264/M-JPEG, with audio alarm, 3.6~10mm

motorized zoom lens, 30m IR distance, IP67,

PoE/12VDC/24VAC

1.3 Product Features

- Progressive scan CMOS sensor

- IR-Cut Removable (ICR) Filter for Day/Night switching

- 98 ft/30m IR distance

- Uses Smart-IR technology; auto-adjusts IR lamp power according to ambient

illumination

- Supports multi-frame integration WDR

3

- Smart functions, such as camera tampering, line cross, and intrusion detection

- Built-in motorized zoom lens, supporting assistant focusing

- H.265/ H.264/M-JPEG video encoding, three streams

- Maximum resolution of V944B-W312MIR supports 2592×1520@20fps,

2560×1440@25fps

- Bi-directional audio, G.711a/G.711u/AAC optional

- Supports corridor mode

- Local PC recording

- Supports TF card (also referred to as SD card) storage/NAS storage

- Supports alarm recording and event recording (including broken network)

- Supports alarm snapshot and event snapshot

- Supports multiple alarm trigger methods such as I/O input, motion detection,

smart detecting, SD card out, network link down, heart beat lost, etc.; supports

flexible alarm association settings like I/O output, emails, FTP picture

uploading, audio, TF card recording and alarm information push

- Up to eight ROI (Region of Interest) areas

- Supports motion detection, 4 areas configurable

- Supports privacy mask, 4 privacy areas configurable

- Supports live access and parameter setting via Web Server from multiple

users

- Compatible with Vicon Valerus VMS software

- Standard SDK provided for easy integration with other video surveillance

software

- ONVIF Profile S and Profile G compliant

- Supports PoE/12VDC/24VAC power supply

- IP67 rating

- With analog video output

4

1.4 System Requirement

Configuration of the computer to display image and control the camera:

CPU: Intel Pentium 4, 2.4 GHz or above

RAM: 512MB or greater

Network Port: 100M Ethernet port

Operating System: Microsoft Windows 10, Windows 7, Windows XP

IE browser version: Microsoft Internet Explorer 8.0 or above

1.5 Specifications

Model

numbers

V942B-

W312MIR

V944B-W312MIR

V942B-

W310MIR-XW

V942B-

W312MIR-XS

I mage Sensor 1/3" CMOS 1/3" CMOS 1/2.8" CMOS 1/1.9" CMOS

Lens

Configuration

Motorized zoom

lens, F1.4,

f=2.7~12mm

Motorized zoom

lens, F1.4,

f=2.7~12mm

Motorized

zoom lens,

F1.4,

f=3.0~10.5mm

Motorized

zoom lens,

F1.5,

f=3.6~10mm

Lens Mount Φ14

IR Lamp

Wave Length

850nm

Night Vision

Distance

30m 30m 30m 30m

Day/Night

Switching

ICR

Sensitivity Color mode:

0.01 lux@F1.4

(30IRE, AGC

ON);

B/W mode: 0 lux

(IR ON)

Color mode: 0.01

lux@F1.4 (30IRE,

AGC ON);

B/W mode: 0 lux

(IR ON)

Color mode:

0.01Lux@F1.4,

AGC ON

B/W mode:

0.001Lux@F1.4,

AGC ON

0 lux (IR ON)

Color mode:

0.002@F1.5,

AGC ON

B/W mode:

0.0006@F1.5,

AGC ON

0 lux (IR ON)

Exposure Scene, Manual, Shutter

Shutter Auto/Manual (adjustment range 1/1s~1/32000s)

AGC Auto/Manual adjustable, max. 64X

White Balance

Auto/Manual/Outdoor

5

WDR Supports multi-

frame integration

mode wide

dynamic range up

to 120dB

Supports multi-

frame integration

mode wide

dynamic range up

to 120dB

Supports multi

-

frame

integration

mode wide

dynamic range

up to 132dB

Supports multi-

frame

integration

mode wide

dynamic range

up to 120dB

Video

Adjustment

Brightness, contrast, saturation, hue, sharpness

Noise

Reduction

3D

Defog Available

EIS Available

Corridor Mode

Available

Image Mirror Horizontal/Vertical mirror

Video

Compression

H.265/H.264/M-JPEG

Max.

Encoding

Capacity

1080P@30fps+

720P@30fps+

MJPEG640×

480@5fps

2592×1520@20fps

+720×480@30fps+

MJPEG640×

480@5fps

1080P@30fps

+

720P@30fps+

MJPEG640×

480@5fps

1080P@30fps

+

720P@30fps+

MJPEG640×

480@5fps

6

Optional

Resolution

Major stream

(H.265/H.264):

1920×1080/1280×

960/1280×720;

Minor stream

(H.265/H.264):

1920×1080/1280×

960/1280×720/720×

576/704×576/640×

480/352×288/320×

240;

Third stream

(H.265/H.264/

M-JPEG):

640×480/352×288/

320×240

Major stream

(H.265/H.264):

2592×1520/2560×

1440/2048×1520/

2304×1296/1920×

1080/1280×960/1280

×720;

Minor stream

(H.265/H.264):

1920×1080/1280×

960/1280×720/720×

576/704×576/640×

480/352×288/320×

240;

Third stream

(H.265/H.264/

M-JPEG):

640×480/352×288/

320×240

Major stream

(H.265/H.264):

1920×1080/1280

×960/1280×720;

Minor stream

(H.265/H.264):

1920×1080/

1280

×960/1280×720/

720×576/704×

576/640×480/

352×288/320×

240;

Third stream

(H.265/H.264/

M-JPEG):

640×480/352×

288/320×240

Major stream

(H.265/H.264):

1920×1080/1280

×960/1280×720;

Minor stream

(H.265/H.264):

1920×1080/1280

×960/1280×720/

720×576/704×

576/640×480/3

52×288/320×

240;

Third stream

(H.265/H.264/

M-JPEG):

640×480/352×

288/320×240

Output Code

Rate

Variable;

Constant: major stream: 256Kbps~10000Kbps; minor stream:

256Kbps~2000Kbps

Audio Compression: G.711a, G.711u, AAC

Sampling rate: 8KHz, 16KHz, 32K, 44.1K, 48K optional

Port: 1 linear input, 1 linear output

Smart

Functions

Abnormal Video detection, line cross detection, and intrusion detection

Network

Delay

≤250ms

Motion

Detection

Supports up to 4 motion detecting areas

Privacy Mask Up to 4 masks

ROI Up to 8 regions

Internal

Storage

Supports a Micro SD/SDHC/SDXC card (128G)

7

Mirroring

Storage

Supports uploading of recordings saved on TF card during network

disconnection to the VMS or NVR after network recovery

Local PC

Recording

Available

Remote

Network

Upgrade

Available

Password

Protection

Available

Network Port One RJ45 10/100M self-adaptive Ethernet port

Analog Video

Output

Available, BNC connector

Alarm 2 alarm inputs, 1 on-off output

Network

Protocols

IPv4, IPv6, TCP, UDP, IGMP, DHCP, FTP, SNMP (V3), SMTP, NTP, RTP,

RTSP, RTCP, HTTP, HTTPS, TSL, SSL, 802.1X, QoS, PPPoE, DNS, DDNS,

ARP, ICMP, UPnP, ONVIF

IP Address

Filter

Available

Power Supply PoE (IEEE 802.3af)/12VDC/24VAC

Power <13W

Protection

Design

Lighting protection (network port and power supply connector): protection

differential mode 2KV, common mode 4KV surge;

Anti-static (all ports): contact protection 6KV static

Operating

Temperature

-40°F ~ 140°F (-40°C ~ 60°C)

Storage

Temperature

-4°F ~ 140°F (-20°C ~ 60°C)

Operating

Humidity

0%~90% RH (non-condensing)

Unit

Dimensions

(H×W×D))

3.33"×3.54×11.83" (84.6 mm×90 mm×300.4 mm)

Box

Dimensions

(L×W×H)

14.96"×5.98×5.12" (380 mm×152 mm×130 mm)

8

Unit Weight 2.09 lb (0.95 kg)

Shipping

Weight

2.76 lb (1.25 kg)

Certifications and Approval

Product

Certifications

CE/FCC, ISO 9001:2008

1.6 Notes

1. After login, first perform network settings. The gateway IP address should be

set as that of the connected network camera.

2. The IP address cannot conflict with that of other devices; if there are conflicts,

the camera cannot be viewed.

3. If the camera utilizes a PoE power supply, connect equipment strictly

according to the parameters of the Power Supply Switcher. Additionally, a

practical test of maximum network cable length for the Power Supply

Switcher must be performed, to avoid camera failure caused by insufficient

power supplied to the Power Supply Switcher or to avoid the harm to the

Switcher.

These units should only be installed by a qualified technician using approved

materials in conformance with federal, state, and local codes. Read these

instructions thoroughly before beginning an installation. Always refer to Vicon’s

website to assure you have the most up-to-date manual, www.vicon-security.com.

The camera is supplied with an accessory kit that includes mounting hardware

(screws, anchors and grommets), an RJ-45 connector protective cover, a power

connector (2-pin screw terminal), replacement/spare locking screws (screws that

secure the camera module in its cradle), and an Allen tool to loosen the screws.

9

Chapter II Installation

2.1 Installation Precautions

- Do not drop the camera or subject it to strong movement.

- Do not point the camera lens toward the sun or other strong light.

- Do not install the camera in environment with temperature beyond the

acceptable range ((-40°F to 140°F -40°C to 60°C), or with high humidity,

frequent vibrations and shocks.

2.2 Dimensions

(Unit: inch, in the parentheses is mm)

Figure 2-1

2.3 Installation of Camera

Select a location that is clear of obstacles and can support the weight of the unit.

Exercise maximum caution when installing the unit to the wall or ceiling. It is

recommended to install the camera 2-4 meters from the floor. As a failsafe

against falling, attach the unit by chain, wire cable or other safety restraint to an

appropriate anchor point. Cabling should be routed to the installation location.

The infrared laser will turn on in the low light conditions and 5 tiny red dots will

10

be visible. Do not look directly at the lens of the camera as it may impair eyesight.

Step 1: Prepare the mounting holes.

Prepare three mounting holes in the specified location, as shown in the figure

below.

∅2.76(70.2)

∅1.35(35.0)

3-120°

Figure 2-2 Location of Mounting Holes

Note: Make sure there is a proper position for a cable hole. The cables are

connected to a pigtail cable assembly on the camera.

Step 2: Install the camera.

Fix the camera to the ceiling with three M4x25 supplied umbrella-type self-

tapping screws (or fastening hardware appropriate for the mounting surface).

Figure 2-3 Install the camera.

11

Step 3: Adjust the camera angle.

Loosen the angle adjustment screw, adjust the camera angle and direction to the

desired position and then tighten the screws. The camera installation is complete.

Figure 2-4 Adjust the camera angle

Refer to the figure below for connection and utilization of alarm input and output.

12

13

CHAPTER III IE BROWSER SETTINGS

When viewing the video, the user needs to adjust the Internet Explorer (IE)

browser and set proper system functions based on the following instructions:

- Support IE browser version: Internet Explorer 8.0 or above, however IE

10 or above is required for full functionality, including the file upgrade

function.

- Make sure the system has installed the player control component.

3.1 Equipment Connection

The V940B cameras can be connected directly to a computer or a network.

Note: Check that the connection is correct and secure before power-on.

3.2 Software Installation

The installation procedure of V940B series of cameras software is as follows:

(1) Login

Open the IE browser and enter IP address. Enter user name and password in the

pop-up login interface. For first time users, the default admin login is ADMIN

(case sensitive; password: 1234). For increased security, it is recommended to

change the password.

(2) Install control

There are two ways to install control.

Method 1:

The prompt message below will display in Live view window after a successful

login. Click the link to run, or store, the .exe file; then run the file.

Figure 3-1

14

If the installation fails, check whether there is video viewed through other IE

window or page. You should close the video or the IE window immediately. If

it succeeds, click refresh; live video can be viewed.

Method 2:

The prompt message below will display in the page after a successful login.

Right click “Add-on Disabled” and select “Run Add-on”.

Figure 3-2

A security warning will pop up to remind the user to install video player control

(Web_VideoPlayer). Click “Install”.

The video player control is installed, live video can be viewed. If a reboot

prompt pops up, cancel reboot. Then close all the IE windows and install video

player control again. The live video will display as below:

Figure 3-4

Note:

15

If the video player control installation falls, the live video won’t display. In that

case, the IE security level should be changed.

1. Click “Tool” in the menu bar and then select “Internet Options” from the

drop-down menu.

2. Select “Security” in the pop-up Internet options.

3. Click the “Internet” icon and then click “Custom Level.”

4. In the options of “Download unsigned ActiveX controls” select “Enable” or

“Prompt.” Click OK.

5. Select “Privacy” option, clear (deselect) “Block pop-ups.” Click Apply and

OK. Reopen the screen and install control as per the prompt. The live video

will display.

16

Chapter IV Basic Function Operation

This chapter will explain the settings and operation that the admin can perform

for the V940B series.

4.1 Live View

After the server is powered on for about 90 seconds, open the IE browser, and

then enter IP address in the address field.

The user login interface is displayed as shown in figure below.

Figure 4-1 User Login

Note that the dome camera defaults to using DHCP. If DHCP is enabled and

the product cannot be accessed, run the Discovery Tool utility to search for and

allocate an IP address for the camera. The Discovery Tool (IPCConfig.exe) can

be found on Vicon’s website, www.vicon-security.com, on the Software

Downloads page for Vicon cameras.

When running the software and logging in for the first time, use the default

admin username and password. The default User is ADMIN (uppercase, case

sensitive) and the password is 1234.

It is recommended to modify the password of the admin user to ensure the

safety and security of the system.

When the login is successful, the following interface will display:

17

Figure 4-2 Live View

The V940B Bullet Camera supports H.265, H.264 and M-JPEG video

compression formats. After the login, users will enter the Live view interface

displaying the major stream at H.264 format.

Stream Type: Users can select H.265 or H.264 from the Stream type dropdown

list.

Video Type: Users can select major stream, minor stream or M-JPEG from the

Video type dropdown list. In the H.265/H.264 major or minor stream type, users

can record and take a snapshot.

Video Size: Users can select a video scale from the dropdown (Fit, Full, 1x,

1/2x, 1/4x). Fit allows the video to be the size of the window without changing

the aspect ratio; Full spreads over the entire window and the aspect ratio

changes with the size of the window; 1X maintains the full resolution of the

video and 1/2x and 1/4x reduces the resolution by ½ or ¼, respectively.

Play Mode: Users can select Live or Smooth; Smooth will produce an image

with less noise and better quality.

Corridor Mode: When the mode is enabled, the horizontal angle narrows while

the vertical angle stretches, as shown in Figure 4-3.

Note: 90°clockwise rotation is needed for angle adjustment when using

corridor mode.

18

Figure 4-3 Corridor Mode

Video info: Show or hide video information (Bite rate and frame rate). If the

video type or stream type is changed, video info is set to off automatically.

Video Profile: For H.264 stream type, the video profile can be set to High,

Main or Base.

Snapshot: Click the button to take a snapshot. Click the button to

access the saving path of the snapshot; default: C:\VideoPlayerAX\Picture.

Local recording: V940B Series supports local recording. Click the recording

button to start recording; the button changes to ; click the button to stop

recording. During local recording, “REC” appears on the video screen. Click

the button to enter the recording storage path; default: C:\VideoPlayerAX\

Video.

Users can set the snapshot and recording storage path in the Audio & Video

settings interface.

Function buttons:

Indicate audio input/output are disabled. Click the buttons to enable

audio input/output and then the buttons will be shown a s .

Indicate that the motion detection and privacy mask functions are

disabled. Click the buttons to enable them and then the buttons will be shown

as .

19

Indicates that the Video Content Analysis functions are disabled. Click the

buttons to enable them; the button will be shown as 。

Note: The motion detection and privacy mask settings can only be set in the

Live view settings interface when they are enabled in the Audio & Video

Settings. Refer to Sections 4.5.3 or 4.5.4 for details.

Note: The login web page language should be set to the same as that of PC's

operating system.

Click the option tab “Settings” to enter the system Settings interface.

Figure 4-4 Settings Interface

Using the navigation menu on the left, admin can perform the following

operations: Basic Information view, Time settings and Advanced settings,

Network settings, Camera settings (including Basic Set, Exposure Set, Effect Set,

White Balance, Focus, IR Set, Reset), Video and Audio settings, Video Contents

Analysis, Alarm settings, Storage settings, Users settings (Add/Delete User,

Change Password), Log, etc.

Note: The following instructions are for the admin use.

20

4.2 System

Click “System” in the left navigation bar to display the following three option

tabs: System, Time and Advanced, as shown in Figure 4-4.

4.2.1 System Information

The initial interface of System settings displays related system information, such

as Basic system information, Network settings, Alarm settings, NTP settings,

H.265/H.264/MJPEG video settings, etc.

4.2.2 Time Settings

Figure 4-5 “Time” Settings

Time Zone Settings

Time Zone: Select the desired time zone from the dropdown list. There are 33

time zones available to select from.

21

If Daylight Saving Time is used in the location, users can enable the Daylight

saving option by selecting the On radio button and enter the correct dates for the

daylight saving time period.

When settings are completed, click “Save.

Time format settings

Select the time format from 24 hour or 12 hour. The date format can be set as

MMDDYYY, DDMMYYYY or YYYYMMDD in the OSD menu.

When settings are completed, click “Save.

NTP Settings

To set the NTP, check the On radio button; select Off if this will not be used. Set

NTP server’s IP address and synchronization time and interval parameters.

When settings are completed, click “Save”.

Sync now

There are two sync modes: local sync and NTP sync.

PC sync means the device time is consistent with that of local PC. In the NTP

sync mode, the system will check time with the NTP server automatically to

adjust time.

Be sure to save settings before leaving the interface or cancel any changes

made.

22

4.2.3 Advanced Settings

Figure 4-6 “Advanced” Settings

Software Update

Free software update is provided for V940B Series cameras on the Vicon website

on the Software Downloads page and can be downloaded to a PC or other media

device.

Follow the steps below to update software:

Under File import, click “Browse” button on the interface and the file selection

dialog box will pop up.

23

Figure 4-7

Select update file and press “Open” button. The selected update file will be

displayed in the Software Update box. Click “Submit” button to update software,

the following information will appear:

Figure 4-8

Click “Yes” button and run the program to finish the update.

The response time depends on the program type; it may take a long time for some

programs. Do not power off during the update process; power-off will cause the

update to fail or damage the original program or disrupt update again.

After a successful update, a reboot of the system is required. There is a time

prompt in the web page during reboot. After reboot, a new web page will open

to run new program.

Note: This is only available for the admin.

24

Factory Settings

V940B series camera provides online reset function, which greatly facilitates

reset adjustment.

Select “Keep current IP unchanged,” click “Reset” button and the system will

pop up the message to confirm factory reset:

Figure 4-9

Click “OK”, all the parameters (excluding IP address) will be reset to the factory

default settings.

If “Keep current IP unchanged” is unselected, the IP address will be reset to

DHCP mode.

There is time prompt in the web page during reset. After reset, a new web page

will open.

Note:

1. To avoid any errors from happening, the online reset function operation

should be performed under qualified personnel’s guidance.

2. Do not power off during reset or the reset will fail.

Online Reboot

Click “Reboot” button; the dialog box “This operation will take 90 seconds, are

you sure to continue？” will pop up. Click “OK” and the system will restart.

There is time prompt in the web page during reboot. After reboot, a new web

page will open.

Note: This is only available for the admin.

25

4.3 Network Settings

Click “Network” in the left navigation bar; the following interface will display:

Figure 4-10 Network Settings

There are 14 option tabs for settings: Network, FTP, SMTP, HTTPS, 802.1X,

QOS, IGMP, SIP, DDNS, UPnP, NAS, RTSP, IP Filter and Monitor.

26

4.3.1 Network Settings

IP mode: There is support for both IPv4 and IPv6 modes. The configuration of

Network parameters will differ depending on the mode selected.

Figure 4-11 Network Settings

Users can enable (On) or disable (Off) DHCP. When it is disabled, users can set

unit IP address, Subnet mask, Gateway and DNS server IP address manually.

Note: The system indicator quickly flickers for 5s after the network settings

completed.

Enter Host name and Port settings for Onvif, Http and Https.

Users can enable/disable PPPoE in this interface. If enabled, users can set the

user name and password.

Telnet service can be turned On or Off as required.

In SNMP settings, the cameras support a heartbeat function. Set and save the

Heartbeat server IP address and Heartbeat interval; the heartbeat package will be

sent to the server or client, which greatly facilitates the server or client to know

about the camera’s network status.

Be sure to save settings before leaving the interface or cancel any changes made.

27

4.3.2 FTP Settings

Figure 4-12 FTP Settings

V940B cameras support the function of alarm associated with FTP image upload

(alarm triggered image snapshot). Configure server IP, user name and password

in the FTP settings. Then activate the alarm associated FTP uploading function

in the alarm setting interface to activate the FTP image uploading function upon

alarms.

Be sure to save settings before leaving the interface or cancel any changes made.

4.3.3 SMTP Settings

Figure 4-13 SMTP Settings

The cameras support the function of alarm associated email sending. The email

server and receiver information are set in the SMTP setting interface.

- Server IP: Set mail server address.

- From: Set sender’s mail address.

28

- To: Mail address of recipient.

- CC: Mail address of the recipient of a copy.

- Authentication: Enable or disable authentication function. This function

should be set according to authentication requirements of mail server.

- User name: Sender’s name; this can be set according user’s needs.

- Password: Set sender’s password.

Note: There is no limit for Sender’s name and password settings.

After setting, click “Set” Save to take effect.

If user selects “Mail” in “Alarm Settings” interface, system will send mails

according to SMTP settings.

4.3.4 HTTPS Settings

Figure 4-14 HTTPS Settings

V940B cameras support HTTPS protocol. You can import the CA certificate in

the interface.

4.3.5 802.1X Settings

Figure 4-15 802.1X Settings

29

V940B Series supports 802.1X protocol. Enable 802.1X authentication when

needed. Then, select an EAP method and enter the user name and password.

Be sure to save settings before leaving the interface or cancel any changes made.

4.3.6 QOS Settings

Figure 4-16 QOS Settings

Select the network service quality in the QoS setting interface. There are 4

network QoS modes:

(1) Normal Service

(2) Max Reliability

(3) Max Throughput

(4) Min Delay

Recommended/Default: Normal Service.

Be sure to save settings before leaving the interface or cancel any changes made.

4.3.7 IGMP Settings

Figure 4-17 IGMP Settings

30

V940B cameras support multicast function. In the IGMP interface, users can

select the stream type and set the state, multicast IP address and RTP port. For

auto multicast, users can set the status as On or Off and set the stream type as TS

stream or ES stream.

4.3.8 SIP Settings

Figure 4-18 SIP Settings

SIP Server: Configure SIP server for device:

SIP Server IP: IP address of SIP server

Port: Port number of SIP server

Server ID: ID of SIP server

Device ID: Device ID used for registration with SIP server

Alarm ID: ID registered for device alarm

Register Interval: Interval for re-registration of device in seconds

31

Heat Beat Interval: Interval to send heartbeat information by the device in

seconds

After configuration is completed, click Save and the device sends a registration

request to the server.

Position Information: Mounting information or instruction for device.

Longitude: Longitude of mounting position, precisely to two decimal places

Latitude: Latitude of mounting position, precisely to two decimal places

Be sure to save settings before leaving the interface or cancel any changes made.

4.3.9 DDNS Settings

Figure 4-19 DDNS Settings

Dynamic Domain Name System (DDNS) can enable continuous synchronization

of the host name and dynamic IP address. Users only need to input the dynamic

domain name to connect to a network camera instead of memorizing the dynamic

IP address.

To employ this method, a PC with a static IP address needs to be available and,

additionally, a dynamic domain name server must be running at the PC.

Operation: Select the Server enable option and then select the DDNS type. Enter

the IP address of the DDNS server into the address bar, configure Domain, User

name, Password and Update time. Then Save the settings. Open the IE browser,

enter the domain name to access the web search page of the device.

Be sure to save settings before leaving the interface or cancel any changes made.

32

4.3.10 UPnP Settings

A mapping relation between a private network and an external network is built

via UPnP protocol. Select UPnP option to enter the configuration page. The

mapping list added will appear on the page.

Figure 4-20UPnP Settings

In “Operate” column, click to delete and to edit user information.

Click Add button to add the mapping.

Figure 4-21

Be sure to save settings before leaving the interface or cancel any changes made.

33

4.3.11 NAS Settings

Figure 4-22

The camera supports NAS (Network Attached Storage) function that allows you

to save the recorded videos on the network server.

Server Configuration: Set the NFS server IP, NFS server path, CIFS shared name,

video held days, stream type, what to do when disk is full and recording control.

Storage Information: View the storage state, total space, used space, available

space and used percent.

Media Server: Set the Rtsp IP address and Rtsp path. Be sure to save settings

before leaving the interface or cancel any changes made.

34

4.3.12 RTSP

Figure 4-23 RTSP Setting

Allowed anonymity: If “On” is selected, there will be no need for the client to

have user authentication when a video by RTSP is requested.

Login Type: Select Login Type from the drop-down menu. You can choose

Basic (send general text password through network to verify user password) or

Digest (system uses encryption information to verify user password). You need

to set Login Type when Allowed anonymity is “On.”

RTP Packet max size: Select the maximum size of standard data packet with

“byte” as its unit.

Be sure to save settings before leaving the interface or cancel any changes made.

4.3.13 IP Filter

The IP filter interface allows you to add IP addresses that have access permission

(i.e. white list) and those which do not have access permission (i.e. black list) and

to configure the IP Filter Mode.

Figure 4-24

35

Click the icon to add IP address on the popup page.

Figure 4-25

Click the Save button after an IP address is added. Then the added IP address

will appear in the IP list.

Figure 4-26

If you select the white list mode under the IP Filter Mode, only the IP addresses

that are added to the white list are able to be accessed. If you select the black list

mode under the IP Filter Mode, the IP addresses that are added to the black list

cannot access the device.

Note: If the white list mode is selected, a valid IP address must be available; be

sure to remember the IP address..

On the IP list, in the Operate column use the icon “ ” to delete and “ ” to edit.

36

4.3.14 Monitor Connect

Figure 4-27 Monitor Connect

You can monitor connection status of devices and platform on Monitor Connect

page. You can also do some settings on the Alarm page to realize automatic

record once disconnecting.

Procedures:

1. Click icon to set Host IP (the IP of computer where the server

platform locates), Port and Interval.

2. Select Heart Beat Lost and SD Card on Alarm page and then set alarm time.

For more information, see “Alarm Settings” in section 4.7.

3. SD card shall record automatically once the disconnecting between devices

and platforms is monitored, and it stops recording one minute after the devices

and platforms reconnect.

Monitor Mode: “Or” and “And” are selectable. When the monitor mode is “Or”,

SD card shall be enabled once one of the platforms disconnects; when the

monitor mode is “And”, SD card shall be enabled once all of the platforms

disconnect.

37

4.4 Camera Settings

Click “Camera” in the navigation bar to enter the interface shown as below:

Figure 4-28 Basic Settings

There are 7 included in the camera settings page: Basic set, Exposure, Effect set,

White balance, Focus, IR set and Reset.

4.4.1 Basic Settings

Basic settings allows the following parameters to be configured:

Flicker frequency: 50Hz or 60Hz.

CVBS: Automatically depending on the flicker frequency. (Note: analog videos

38

are shut off after MJPEG stream is enabled. To enable analog videos, disable

MJPEG stream.)

Enable or disable mirror vertical, mirror horizontal, WDR, BLC, HLC and EIS

(stabilization).

Defog: Optional, set to Auto or Off.

Defog level: If set to Auto, set the defog level to 0~255.

Be sure to save settings before leaving the interface or cancel any changes made.

4.4.2 Exposure Settings

Figure 4-29 Exposure Settings

From this screen, set Exposure set, Auto aperture, Scene, AGC, Shutter speed

and Manual AGC.

Exposure Set: Select Manual, Scene and Shutter priority from the dropdown.

Auto Aperture: Enable or disable autoiris.

Scene mode: Indoor or outdoor can be selected.

AGC: Select from 8X, 16X, 32X, 48X, 64X options; if set to Manual Exposure

mode, Shutter speed can be set from 1/30s to 1/10000s and manual AGC can be

set as 1X, 2X, 4X, 8X, 16X, 32X, and 64X, but then scene and AGC are not

adjustable; if set to Shutter priority mode, the Min shutter speed

39

(1/100s~1/32000s adjustable), Max shutter speed (1/1s~1/32000s adjustable) and

AGC can be set.

Be sure to save settings before leaving the interface or cancel any changes made.

4.4.3 Effect Settings

In the Effect Settings interface, users can adjust the brightness, sharpness, hue,

contrast, saturation and 3D de-noise (DNR) in two ways: General or Mode, as

shown in the figure below:

Figure 4-30 Effect Set -General

General: Drag the sliding block to adjust the brightness, sharpness, hue, contrast,

saturation and 3D de-noise (DNR) parameters.

40

Figure 4-31 Effect Set - Mode

The camera supports 6 video effect modes. Users can set and save a Name;

Brightness, Sharpness, Hue, Contrast, Saturation, 3D de-noise, WDR, HLC, EIS

and Defog for each mode. Click “Factoryset” to restore it to default settings.

In the Mode call, users can set Effect Mode call status and start and end period.

41

4.4.4 White Balance

Figure 4-32 White Balance Settings

The camera has a selection of white balance modes, including Auto and Outdoor.

If set to Manual mode, the red gain and blue gain can be set.

42

4.4.5 Focus Settings

Figure 4-33 Focus Settings

The camera has a built-in motorized zoom lens for remote focal length

adjustment. Click “Focus” in camera settings interface to enter focus settings.

On this page, select focus mode, zoom/focus and call focus limit.

Auto focus:

In auto focus mode, the interface is shown as Figure 4-33.

Click button to focus wide; click button to focus tele.

Click Stop button during focusing to stop auto focus.

43

Left-click in one section of the video; the frame of this section will turn to green

and the camera will automatically focus for this area.

Manual focus: Click Manual focus to enter the interface as below.

Figure 4-34

Click to zoom wide/zoom tele.

Click focus near/focus far.

Focus Limit: The camera can call focus limit. There are 5 options: Wide, Middle,

Tele, User set 1, User set 2. The effects for Near, Middle and Far are default; but

User set 1 and User set 2 can be specified by users.

Reset: If the camera cannot focus clearly using auto focus, click Reset button to

restart the motor.

Be sure to save settings before leaving the interface or cancel any changes made.

44

4.4.6 IR Set

Figure 4-35

IR mode: Set IR illuminators working mode.

Options: Day, Night, Auto (turn on or off as per ambient light).

Switch time: In auto mode, the response time for day/night switch.

Be sure to save settings before leaving the interface or cancel any changes

made.

4.4.7 Reset

From this interface, restore all the camera parameters to the factory default

settings.

45

4.5 Video and audio Settings

Click the button Video and audio in the navigation bar to display the following

interface.

Figure 4-36 Video Settings

The Video and audio Settings page allows setting Video, OSD, Motion, Privacy,

ROI, Path, Audio and Reset.

Click the related option tab to enter the setting interface.

4.5.1 Video Settings

Users can set the video parameters for H.265, H.264 and MJPEG stream,

including resolution, frame rate, GOP number, and bit rate.

46

Resolution for H.265/H.264 major stream:

The resolution of 4 MP camera is up to 2592×1520, with 2560×1440,

2048×1520, 2304×1296, 1920×1080, 1280×960 and 1280×720 options.

The resolution of 2 MP camera is up to 1920×1080, with 1280×960 and

1280×720 optional.

Resolution for H.265/H.264 minor stream:

The resolution is up to 1920×1080, with 1280×960, 1280×720,

720×576/720×480, 704×576/704×480, 640×480, 352×288/352×240, 320×240

and closed options.

Resolution for third stream:

For the third stream, the stream type can be set as H264, H265 and MJPEG.

The resolution can be 640×80/352×240/320×240.

Frame Rate: This is the number of compressed frames produced by camera per

second. The larger the frame rate is, the better the image continuity will be, but

the CPU performance is lowered. The smaller the frame rate is, the worse the

image continuity will be, but the CPU can handle more events.

The maximum frame rate for H.265 and H.264 is 30fps. The maximum frame

rate for MJPEG is 5fps.

The Max. Encoding Capacity of 4 MP camera is

2592×1520@20fps+720×480@30fps+ MJPEG640×480@5fps.

The Max. Encoding Capacity of 2 MP camera is 1080P@30fps+720P@30fps+

MJPEG 640×480@5fps.

GOP number: GOP number is the ratio of I frame (complete image) to P frame in

(changes in image) in compressed video images. The larger the value is, the less the

data quantity is and the less network resource it occupies.

Max. GOP number can be set to 60.

Bit Rate: There are 2 modes of bit rate: variable rate (VBR) and constant rate

(CBR).

47

With variable bit rate, the system can automatically adjust the bandwidth of the

images per the complexity of the images. In practical use, the complexity of the

video images varies constantly, as the details of the scene and the moving speed

change. If the video includes too much detail and images in it move fast, then the

bandwidth it uses will be larger. If not, the bandwidth is smaller. If the Bit Rate

is set as “Constant bit rate,” then the images are transferred by fixed bandwidth

capacity, no matter how the complexity of the images changes.

Bit Rate: If “VBR” is selected, the upper limit of bit rate has to be set; if

“CBR” is selected, the stream size will be fixed and the stream size is defined

in the “Bit Rate.” For major stream, the bit rate upper limit can be

256kbps~10000kbps; for minor stream, the bit rate upper limit can be

256Kbps~2000Kbps.

Image Quality: Set under MJPEG (third) stream. Options: Highest, High, Average,

Low and Lowest. The higher the image quality is, the more bandwidth it will use.

48

4.5.2 OSD

Figure 4-37 OSD

From the OSD (On Screen Display) screen, set Text 1, Context 2, Context 3 and

date to display on the video image.

Mode: BlackEdge (text has a black outline) or SingleColor.

Margin: Set the margin of the text overlay area from the edge of image. 1

indicates one-tenth character size and 10 indicates one character size. For

example, set X to 10 and Y to 20, which means the left side of text area is only

one character size from the left edge of image and the upper side of the text area

is 2 character sizes from the upper edge of the image.

Note that the size of overlay characters can be set separately. When the character

sizes are not the same, the actual margin size is different, even if the same margin

is set. For example, for Context 3, if the font size is set to 3 point, a margin of 1

indicates the size of one-tenth of 3 point font; for Text 1, if the font size for text

is set to 8 point, the margin of 1 indicates the size of one-tenth of 8 point font.

49

Text 1: Text or Image options or turn the option Off.

Text: Select Text and enter the text content in the content box, which allows up

to 40 characters (a~z, A~Z and 0~9). Also set the font size and text coordinates

(where the text will display on the screen).

Image: The camera supports image overlaying on the video, for example

inserting a logo. Click Image to set the image overlay information. Click the

Browse button, select the image to be uploaded, and then, click Upload. Drag the

slider for transparency to adjust the image transparency. Select “Clean white” to

make a transparent background for the image. Additionally, set the coordinates

for the image for where it will display.

Notes:

(1) A bitmap is required.

(2) The maximum size of image is 352×288, with both the width and height

required to be an even number, such as 160×130.

Context 2: Select “ON” and enter the text content in the text box, which allows

up to 40 characters (a~z, A~Z and 0~9). Also set the font size and text coordinates.

Context 3: Select “On” and enter the text content in the text box from line 1 to 5,

which allows up to 40 characters (a~z, A~Z and 0~9). Also set the font size and

text coordinates.

Align: Multiple lines of texts can be aligned at the left or right. Set the interval

between two lines that are next to each other; 1 indicates the one-tenth size of a

character.

Note: X/Y Coordinate: Set the coordinates of text. For text 1, context 2 and

context 3, the origin of coordinates is the upper left corner of the text display area.

50

Date OSD: Select “On” and set the font size, display position and format

(MMDDYYY, DDMMYYYY or YYYYMMDD). Size: Set the character size of

the text. The larger value indicates larger character size.

After settings are finished, click the Save button. The OSD displays on the video.

To cancel OSD, click “Off” and “Save” button.

The OSD is displayed as below:

Figure 4-38

51

4.5.3 Motion Detection

Figure 4-39 Motion Detection Settings

The motion detection function is supported. Up to 4 motion zones can be

configured.

Note: Turn on motion detection function in Live View interface before motion

detection setting (see Section 4.1).

Check the box of the Zone number to be set. If this motion detection area has

already been set, a blue frame will be displayed on the screen.

Setting the motion detection area:

Check the box of motion detection area number. Click the “Draw” button with

the mouse and then left click on the mouse and draw a blue frame on the screen.

Then, click the “Save” button to save the zone; the blue frame will turn green,

indicating the setting is complete.

Enter the area name in the Name field and use the slide bar to set the sensitivity;

moving the slide towards the plus sign heightens the sensitivity for detection.

To cancel a motion detection area, uncheck the box.

52

Museum search, one of the record video playback search functions, allows you

to search for moving objects in recorded video. Museum search sensitivity is

the threshold for regulating the smallest moving range objects that can be

searched. Use the slide bar to adjust the Museum search sensitivity

4.5.4 Privacy Mask

V940B Series camera supports 4 privacy masks. If certain sensitive areas within

the surveillance area should not viewed, a Privacy Mask can be applied. The

camera system covers and shields the sensitive area via Privacy Mask setting to

prevent operators from observing this location.

Note: Turn on privacy mask function in Live View interface before privacy mask

setting (see Section 4.1).

Figure 4-40 Privacy Mask Settings

How to set the privacy masks:

Check the box of privacy Zone number. Click the “Draw” button with the

mouse and then left click on the mouse and draw a blue frame on the screen.

Then click the “Save” button and the blue frame changes into black, masking

that area of the image.

To cancel a privacy mask, uncheck the box.

53

4.5.5 ROI

The camera supports ROI (Region of Interest) function, with eight zones settable.

The areas selected are of particular importance in the scene, for example a face

or license plate. When this enabled, the selected areas will be encoded to include

more detail.

Figure 4-41 ROI Settings

ROI settings method:

Check the Zone number of the region for setting and click the “Draw” button.

Left click on the mouse and draw a blue frame on the screen. Click the “Save”

button and when the color of the regional border changes from blue to green,

ROI setting is complete. Use the slide bar to adjust the definition of the region.

To cancel an ROI, uncheck the box.

54

4.5.6 Storage Path

Figure 4-42 Storage Paths

Default photo saving path: C:\VideoPlayerAX\Picture.

Default video saving path: C:\VideoPlayerAX\Video.

Photo and video formats can also be set. The default photo format is .jpg and

the default video format is .avi.

To change the saving path, click the “Browse” button and select the path from

the popup dialog box.

4.5.7 Audio Settings

Figure 4-43 Audio Settings

55

Audio: ON or OFF for optional.

Format: G.711-U, G.711-A and AAC.

Sample rate: For G.711-U, G.711-A, sample rate is 8K; for AAC, 16K, 32K,

44.1K, 48K are options.

Bit rate: For G.711-U, G.711-A, bit rate is 64Kbps; for AAC, 32K, 64K are

options.

4.6 Video Content Analysis Functions

Click the “Video Content Analysis” button on the navigation bar. The setting

page of the VCA functions shows as below:

Figure 4-44 Settings of Video Contents Analysis Functions

From the Video Content Analysis tab, set Camera Tampering, Line Cross

Detection and Intrusion Detection. Click the tabs respectively to enter each

setting page.

In the VCA setting page, users can enable or disable the VCA function to allow

setting the other functions.

4.6.1 Camera Tampering

From this screen, set the sensitivity for scene changes, defocus detection and low

or high brightness detection.

56

Figure 4-45 Scene change

Figure 4-46 Defocus detection

Figure 4-47 Low brightness detection

Figure 4-48 High brightness detection

Scene Change: When the monitoring scene is changed, an alarm is triggered.

Defocus detection: When focus is not clear, an alarm is triggered.

57

Low brightness detection and High brightness detection: When the low

brightness or high brightness is detected, an alarm is triggered.

Under Scene change, set the sensitivity. Sensitivity varies from 1 to 5.

Under Defocus Detection, Low brightness detection, and High brightness

detection, set the sensitivity and threshold. Sensitivity varies from 1 to 5 and

threshold from 0 to 20.

4.6.2 Line Cross Detection

Figure 4-49 Line Cross Detection

58

The camera supports line cross detection. This allows the placement of four

virtual lines on the scene, marking where the allowed and prohibited entry

direction is. These are set using the mouse. When people or objects cross a line

in the wrong direction, an alarm is triggered.

Note: Enable the VCA functions in the Live view page ( ) before setting

the line cross detection function (refer to Section 4.1).

From the Settings page, select Line Cross. Check Line Cross Detection to enable

the function. If a line has been placed, a green line with two direction arrows

appears on the screen. The solid arrow indicates the prohibited direction while

the hollow arrow indicates the allowed direction.

Draw a virtual line:

To draw a virtual line, select Line 1, click the Begin button with the mouse, place

a start point on the screen, move the mouse and place an end point on the screen.

Then click the direction arrows on the line to set it solid or hollow.

When finished, click the End button. To edit a line, click the green line until it

turns blue with red endpoints. Then click the endpoints and move the mouse to

edit the line.

To redraw the line, click the Cancel button and draw it again.

When finished, click the Save button to save the line.

Set the sensitivity and threshold of the line cross detection function.

59

4.6.3 Intrusion Detection

Figure 4-50 Intrusion Detection

The camera supports Intrusion Detection. One intrusion detection area can be

set. When objects move into this area, an alarm is triggered.

Check “Intrusion Detection” to enable the function. If an area has been set, a

green frame appears on the screen. If not, a default rectangle frame appears.

60

Draw an intrusion detection area:

Click the Begin button and then left click the mouse on the video to draw the

first point; move the mouse and left click to draw the second point, and so on.

Up to eight points can be drawn. When the last point is drawn, move the mouse

to the first point. When a small red box appears, click to display a green closed

area.

Note: Up to eight points are allowed. After the last point is drawn, a green area

from the first point to the last point appears automatically.

When the area is finished, click the End button. To edit the area, click the green

frame of the area. After the frame turns blue from green, click the points and

move the mouse to change the area.

To redraw the area, click the Cancel button and draw it again.

When finished, click the “Save” button to save the area.

The sensitivity and threshold of the Intrusion Detection function can also be set.

4.7 Alarm Settings

Click “Alarm” in the left navigation bar to display the following Alarm Settings

interface:

61

Figure 4-51 Alarm Settings

Alarm Configuration

The camera supports 2 alarm inputs, I/O in 1 and I/O in 2 and 1 alarm output, I/O

out. Users can set the status of each alarm input: Grounded Circuit or Open

62

Circuit. Grounded Circuit: “0;” Open Circuit: “1.”

Alarm out Contact: Set the transfer mode of the alarm signal, Local contact or

Net contact.

Local Contact: I/O out is triggered by I/O alarm in, motion detection alarm, video

contents analysis, TF card out, network link down or heart beat lost. Default:

Local Contact.

When the value of I/O out 1 is “1,” the switch status will be on.

When the value of I/O out 1 is “0,” the switch status will be off.

Net Contact: I/O out is controlled by the surveillance management software.

Note: This function can work with some Digital Video Surveillance

Management software. If Net contact is selected, users must set the IP of the

Alarm server as the server IP of the system. After the necessary settings in

software, users can control the relay switches remotely via the software. For

detailed information, refer to the Digital Video Surveillance Management

Software Operation manual.

Alarm Server IP: Set the IP address of alarm server. When an alarm occurs, the

alarm server is notified.

Alarm out Contact

Users can set the responding action for each switch signal I/O alarm in, motion

detection alarm, video contents analysis, TF card out, network link down or IP

address conflict from the options: Alarm out 1 (if Net Contact is selected, this

option is unavailable), TF card, Mail, FTP or Audio. When setting is completed,

click “Save” button.

Note: When “FTP” or “Mail” is selected, FTP or SMTP parameters must be set

in Network Settings; refer to Section 4.3.2 or Section 4.3.3 for details.

63

Alarm Schedule

The effective alarm schedule can be set. Users can select the alarm period. For

example, if Sunday is selected, on each Sunday the alarm will be in effect in the

set time; if Everyday is selected, alarm will be in effect in the set time every day.

The start time and end time is set up in the 24-hour format. The end time must be

after the start time. Press the “Save” button to activate the settings.

4.8 Storage Management

The camera supports storage with TF card. Click the Storage button to display

the Storage Management interface to set the recording parameters, replay and

download the recorded videos.

4.8.1 Record Settings for Recording

Figure 4-52 Storage Settings

Capture Settings:

Record picture: Open or close picture record.

Capture Type: Alarm trigger

64

Capture interval: Set the capture interval (in seconds).

Recording control:

Recording video type: Select the type of videos to record, major stream or minor

stream.

Recording audio: Open or close audio recording.

Prerecorded time: Select prerecord time in seconds, No record or No limit.

Delay time: Select delay time from 5s up to 10 minutes.

Recording mode: Set the recording mode; choose from Alarm triggered, Always

or Close options. When Alarm triggered is selected, and the setting of alarm

associated with TF card is set in the alarm interface (refer to section 4.7), when

the alarm occurs, recording is triggered automatically.

SD card full: Select what happens when the SD card is full from Overwrite or

Stop options. In Overwrite mode, when the TF card is full, the newly recorded

videos automatically overwrite the old videos; in Stop mode, when the TF card

is full, recording stop automatically.

Peripheral equipment:

View the total size, used space and state of TF card and also format it.

4.8.2 Replay

Figure 4-53 Replaying

65

Video Search: Set the start and end times at the top right and then click the Search

button. The recordings during this period of time will be listed.

Replay: To replay a video, double click a file in the list or select a file and then

press the “Play” button . During playing, click or to pause or stop

playback.

Click the button on the right of video window to collapse the right window

and view the video full screen. Click the button to return to the page as Figure

4-53.

Download: The videos stored in the TF card can be downloaded to a local PC.

Select the file from the video list (multiple files can be selected simultaneously

using the “Ctrl” or “Shift” key) and then click the “Download” button to enter

the downloading interface.

Save to: Set the path to save the downloaded files. The default local storage

path is displayed. If a different location is required, click the “Browse” button.

AVI/H.264 drop-down list box: Select the downloaded file format.

In the download list, file total size, status and download progress will display.

Click the “Start” button and the files in the list will be downloaded in order.

The progress shows 100% after downloading is finished.

Click the “Open” button to enter download content.

4.9 User Settings

The default admin user is ADMIN (uppercase; password: 1234). The admin can

add or delete other users and change their passwords. The user name ADMIN

cannot be changed but it is recommended to change the ADMIN password for

increased security. A maximum of 7 users are supported.

Detailed instructions on how to add and delete user are addressed below.

Click the Users option tab in the Settings interface; the following user

information will display. The “Num” item shows the number of the user and then

66

the user name. The “Property” column shows the authority of the user. In the

“Operation” column, use to delete and to edit user information. See

figure below:

Figure 4-54 User Settings

1. Add Users

(1) Click “ ”to open the “Add a User” interface.

Figure 4-55 Add a User

(2) Enter the desired User Name and Password (user name and password can

include letters, numbers and underline only. No special characters are allowed.

The string length of user name can be between 1 and 30 characters and that of

the password is between 5 and 20 characters.)

For the User Type, select Ordinary user or Operator. An ordinary user can view

videos and an Operator can view videos and configure video settings.

(3) Click “OK” button. If the setting is successful, the new user name will appear

in the account list, like new user “user1” in the example below:

67

Figure 4-56

2. Delete Users

In the “User setting” interface, click button under “Operation” for the user to

be deleted. The following dialog box will display:

Figure 4-57

Click “OK” button; the selected user will be deleted and the user list will be

automatically updated.

3. User Password Change

Click button in the user list and the Edit User Information dialog box pops

up:

Figure 4-58

68

Input the old password, enter the desired new password (twice, once to confirm)

and then click “OK” button; the following popup will display; click OK:

Figure 4-59

4.10 System Log

Click the “Log” option tab to enter the system log interface. The date, time and

log information will appear on the screen.

Figure 4-60

Up to 30 logs can display on a page. The user can turn over the page by clicking

the arrows at the bottom or skip to a designated page by clicking Goto. To remove

a log, click “Delete logs;” a prompt will display. Click “Yes” to clear logs.

69

Appendix I Questions & Solutions

The following table describes the symptoms causes and solutions for the

problems.

Symptoms

Possible Causes

Solutions

The network

camera does

not perform

initiation after

power-on

Wrong power connection

Reconnect power cable

Power supply failure

Repair or replace power

supply

Immediate startup after

power-off

Restart 10 seconds later

after power-off

If PoE power supply is used,

too long transmission distance

may make the power of the

Power Supply Switcher

insufficient.

Shorten the length of the

power supply network

cable or replace Power

Supply Switcher with more

power

If PoE power supply is used,

connection to other electric

appliance makes the ground

level not in the correct level

Disconnect other electrical

appliances

No video signal

displayed

The plug-in for viewing image

is installed incorrectly

Refer to the plug-in

installation to reinstall it.

Network camera’s IP address

conflicts with other user’s IP

address

Set a unique IP address

Vague image Manual focus is not precise Manually adjust the camera

focus

Shipping Instructions

Use the following procedure when returning a unit to the factory:

1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record

the name of the Vicon employee who issued the R.A.

Vicon Industries Inc.

135 Fell Court

Hauppauge, NY 11788

Phone: 631-952-2288; Toll-Free: 1-800-645-9116; Fax: 631-951-2288

For service or returns from countries in Europe, contact:

Vicon Industries Ltd

Unit 4, Nelson Industrial Park,

Hedge End, Southampton

SO30 2JH, United Kingdom

Phone: +44 (0)1489/566300; Fax: +44 (0)1489/566322

2. Attach a sheet of paper to the unit with the following information:

a. Name and address of the company returning the unit

b. Name of the Vicon employee who issued the R.A.

c. R. A. number

d. Brief description of the installation

e. Complete description of the problem and circumstances under which it occurs

f. Unit’s original date of purchase, if still under warranty

3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum

protection.

4. Mark the R.A. number on the outside of the carton on the shipping label.

Vicon Standard Equipment Warranty

Vicon Industries Inc. (the “Company”) warrants your equipment to be free from defects in material and

workmanship under Normal Use from the date of original retail purchase for a period of three years, with the

following exceptions:

1. All IQEYE Cameras: Two years if purchased before 1/1/2011.

2. Alliance-mini (IQD3xx), Alliance-mx (IQMxxx) and 3 Series (IQ03xx): Five years if purchased

between 1/2/2011 – 12/31/2014.

3. Alliance-Pro (IQA3xx): Five years if purchased between 3/2/2012 – 12/31/2014. Three years if the

motorized lens (IQA3xx-A3) option.

4. Access Control System Components: Two year from date of original retail purchase.

5. Uninterruptible Power Supplies: Two years from date of original retail purchase.

6. VDR-700 Recorder Series: One year from date of original retail purchase.

7. V5616MUX: One year from date of original retail purchase.

8. Arecont Cameras: One year from date of original retail purchase.

9. FMC series fiber-optic media converters and associated accessories: Lifetime warranty.

10. For PTZ cameras, “Normal Use” excludes prolonged use of lens and pan-and-tilt motors, gear

heads, and gears due to continuous use of “autopan” or “tour” modes of operation. Such

continuous operation is outside the scope of this warranty.

11. Any product sold as “special” or not listed in Vicon’s commercial price list: One year from date of

original retail purchase.

NOTE:

• If the product is to be used outdoors or in dusty, humid, or other hostile environments, it must be

suitably protected.

• Camera products must be protected, whether in use or not, from exposure to direct sunlight or

halogen light as the light may damage the camera image sensor. This applies to both indoor and

outdoor use of the cameras.

• For camera products supplied without a lens, extreme care should be used when mounting a lens

on these products. Damage to the product due to incorrectly mounted lenses will invalidate this

limited hardware warranty.

• Failure to comply with any of the aforementioned requirements will invalidate this Limited Hardware

Warranty.

Date of retail purchase is the date original end-user takes possession of the equipment, or, at the sole

discretion of the Company, the date the equipment first becomes operational by the original end-user.

The sole remedy under this Warranty is that defective equipment be repaired or (at the Company’s option)

replaced, at Company repair centers, provided the equipment has been authorized for return by the Company,

and the return shipment is prepaid in accordance with policy. Repaired or replacement hardware will be

warranted for the remainder of the original Warranty Period or ninety (90) days, whichever is longer. When a

product or part is exchanged the replacement hardware becomes the property of the original purchaser and

all hardware or part thereof that is replaced shall become the property of Vicon.

The warranty does not apply (a) to faulty and improper installation, maintenance, service, repair and/or

alteration in any way that is not contemplated in the documentation for the product or carried out with Vicon

consent in writing, operation adjustments covered in the operating manual for the product or normal

maintenance, (b) to cosmetic damages, (c) if the product is modified or tampered with, (d) if the product is

damaged by acts of God, misuse, abuse, negligence, accident, normal wear and tear and deterioration,

improper environmental conditions (including, but not limited to, electrical surges, water damage, chemical

exposure, an/or heat/cold exposure) or lack of responsible care, (e) if the product has had the model or serial

number altered, defaced or removed, (f) to consumables (such as storage media or batteries) (g) to products

that have been purchased “as is” and Vicon the seller or the liquidator expressly disclaim their warranty

obligation pertaining to the product, (h) to any non-Vicon hardware product or any software (irrespective of

packaged or sold with Vicon hardware product) and Vicon products purchased from an unauthorized

distributor/reseller, (i) to damage that occurs in shipment or (j) to damages by any other causes not related to

defective design, workmanship and/or materials.

The warranty for the products shall run from Vicon to End User customers only (including product purchased

through authorized partners and resellers). Vicon is not obligated under any circumstances to honor warranties

on product(s) purchases from internet auction sites including eBay, uBid or from any other unauthorized

resellers. Except as explicitly provided herein, Vicon disclaims all other warranties, including the implied

warranties of fitness for a particular purpose and merchantability.

Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not

warrant that such software shall be error (bug) free. Software support via telephone, if provided at no

cost, may be discontinued at any time without notice at Vicon’s sole discretion. Vicon reserves the

right to make changes to its software in any of its products at any time and without notice.

The Warranty and remedies provided above are exclusive and in lieu of all other express or implied

warranties including, but not limited to, the implied warranties of merchantability or fitness for a

particular purpose. Certain jurisdictions do not allow the exclusion of implied warranties. If laws under

such jurisdictions apply, then all express and implied warranties are limited to the warranty period

identified above. Unless provided herein, any statements or representations made by any other

person or firm are void. Except as provided in this written warranty and to the extent permitted by law,

neither Vicon nor any affiliated shall be liable for any loss, (including loss of data and information),

inconvenience, or damage, including, but not limited to, direct, special, incidental or consequential

damages, resulting from the use or inability to use the Vicon product, whether resulting from breach

of warranty or any other legal theory. Notwithstanding the foregoing, Vicon total liability for all claims

under this warranty shall not exceed the price paid for the product. These limitations on potential

liabilities have been an essential condition in setting the product.

No one is authorized to assume any liability on behalf of the Company, or impose any obligations on it in

connection with the sale of any Goods, other than that which is specified above. In no event will the Company

be liable for indirect, special, incidental, consequential, or other damages, whether arising from interrupted

equipment operation, loss of data, replacement of equipment or software, costs or repairs undertaken by the

Purchaser, or other causes.

This warranty applies to all sales made by the Company or its dealers and shall be governed by the laws of

New York State without regard to its conflict of laws principles. This Warranty shall be enforceable against the

Company only in the courts located in the State of New York.

The form of this Warranty is effective August 1, 2015.

THE TERMS OF THIS WARRANTY APPLY ONLY TO SALES MADE WHILE THIS WARRANTY IS IN

EFFECT. THIS WARRANTY SHALL BE OF NO EFFECT IF AT THE TIME OF SALE A DIFFERENT

WARRANTY IS POSTED ON THE COMPANY’S WEBSITE, WWW.VICON-SECURITY.COM. IN THAT

EVENT, THE TERMS OF THE POSTED WARRANTY SHALL APPLY EXCLUSIVELY.

Vicon Part Number: 8006-9010-03-12 Rev 0815

VICON INDUSTRIES INC.

For ofce locations, visit the website: www.vicon-security.com
