Users Manual
Preface
Dear Users :
Welcome to purchase “SeeMeHere“’s product ,please read this user manual
carefully before using it .Thanks , Let’s enjoy music together !
The “SeeMeHere” keeps the final right of interpretation of this manual .
Logo:
Model: BV210
Warnings
z Please use and store this product at room temperature
z Do not expose this product to rain or wet conditions
z Do not throw and drop this product to avoid product damage
z Do not self-dismantling ,repair and transform the product
z Do not use chemical solvent cleaning the product
z Please don’t arbitrarily discarded or placed the lithium battery in the fire in order
to avoid the risk of explosion
Packing Content :
1.Bluetooth speaker 1pc
2. USB cable 1pc
3.3.5mm audio cable 1pc
4.hook 1pc
5. user manual 1pc
Features
z With wireless Bluetooth technology
z Support one button Bluetooth reconnection
z With built-in Mic ,support handfree function
z Play main APE/FLAC MP3/WMA/WAV format audio files stored in TF card
z Support Line in , with built in card reader to exchange data directly
z Automatic shutdown after suspension without operation for 5 minutes
z Built in efficient li-on battery ,USB charging is available
z With voice broadcast ,support the phone ring
Technique Parameters
Interfaces Micro USB port
TF card slot
Product size W93.8*D83*H40mm
Product weight 218g(Including battery)
Speaker type Bluetooth Speaker
Speaker structure Single track+ Low frequency radiator
Functions Bluetooth wireless connection, Handfree function ,Voice
prompt ,TF card music play, AUX Input, Card reader ,USB
Charging
Supported cards Max. 32GB TF card
Power supply Built-in 800 mAh li-on battery
DC 5V—500mA USB charging
Loudspeaker 1.5inch
Output power 3W 4Ω
Frequency
Response
80Hz~18KHz
Wireless connection Bluetooth 2.1+EDR
USB USB2.0 Compatible with USB1.1
File formats APE、FLAC、WAV、WMA、MP3
Bit Rate MP3：8Kbps-320Kbps
WMA：32Kbps—384Kbps
APE：600Kbps—1000Kbps
FLAC：600Kbps—1000Kbps
WAV：32Kbps—1000Kbps
Key Functions
1. Prev / Volume- : Short press to previous song , long press to decrease the volume
2. Next/Volume+: Short press to next song . long press to increase the volume
3. Power button : Pressing 3 second to power on or power off
Play/ Pause : Short press to play or pause music play
Call answer button :Short press to answer the call, short press again to hang up the call
4. Mode key: Exchange model among Bluetooth mode ,TF Card music mode and Line in mode
Bluetooth disconnected or reconnected : Short press two times to open or shut down the
voice prompt; long press to disconnect under bluetooth connection mode.
5. Reset button : Press to reset the device.
6. TF card slot: Insert TF card
Micro USB port :Data exchange / Charging port /Line-in port
Main Function Operation Instruction :
Bluetooth Connection :
1. Press 3 seconds to power on :
Power on: After “Ding-dong” , there is an another voice prompt “Bluetooth mode”, and then
blue indicator flashing
2. Bluetooth Connection :
Open the Bluetooth function of mobile phone , MID and other music players with Bluetooth
function ,and search the devices , when you find the “BV210” ,click to connect
3. Connected and play
The speaker says, “Connected” ,and the blue indicator always light up, and then you can enjoy the
music with this speaker .
Bluetooth signal valid distance 10M
1. If need password , please input “0000” and confirm to connect
2. The Bluetooth can reconnect the last paired device automatically
TF Card music play
1. Insert TF card and power on
2. Short press M button to exchange to TF card music play mode ,the speaker will say”TF card
mode “,and then the speaker play the music stored in TF card .
Kind reminder : If the speaker is on , when you insert the TF , it will switch to TF card music
automatically
Handfree Function :
1.The speaker connected with a mobile phone , when the call coming , short press to answer the
phone , short press again to hang up the phone , long press M to reject the call .
Under line-in mode
Power one the speaker , after “Ding-dong” , the speaker says” Bluetooth Mode “ , short press
to switch to line in mode , connect the speaker to the music player to play music stored in other
players .
Card reader Mode
1. Under power off condition
When the speaker is off , connect the speaker to the computer through the attached USB cable
(speaker’s micro SD port )and insert the TF card ,the speaker says”card reader mode “and the
user can edit the files stored in TF card
Charging
The user can choose DC5V-500mA USB adaptor to charge the device
Connect the speaker(micro USB port ) to the computer through attached USB cable , and then the
speaker is charging , when the charging completed , red indicator lights off.
Speaker power supply voice prompt :
Battery low :speaker will prompt “Di,Di “ every 30 seconds
FAQ
Questions Settlement
Fail to Bluetooth connect 1.Restart the speaker
2.If need password , please input “0000”
Music Play Break Please check the Bluetooth connection valid distance or if
something cut off the signal
TF card music play wrong 1. Check if the TF card format right (the speaker just can support
FAT 32 format TF card )
2.Check if the music file format store in TF card right ,the
speaker just can support APE、FLAC、WAV、WMA、MP3 format
files
No Sound 1.Check the volume the speaker
2.Check if the speaker is in mute or pause
Line-in no sound Check if the audio cable connect right
Fail to power on Check if the batter is low
Speaker halt Reset the speaker
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the
party Responsible for compliance could void the user’s authority to operate this equipment.
(Example- use only shielded interface cables when connecting to computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules.Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate the
equipment.
Warranty Card
Please fill up this “Warranty Card” after purchasing this product .
Date of purchase :------------------------------------------------------------------------
Name:--------------------------------------------------------------------------------------
Address:------------------------------------------------------------------------------------
Telephone:-------------------------- Zip code:--------------
Authorized dealer stamp::----------------------------------- --------
Dealer Address:-----------------------------
Phone:-------------------------------Zip Code :------------------------------------
