802.11 a/b/g/n Module
EUB600-DM
User’s Manual
- 2 -
PRODUCT DESCRIPTION
The EUB600-DM is a 2.4G/5G dual band 2T2R USB module base
on RT5572N solution.
PRODUCT SPECIFICATION
RF
Sp
ec
i
f
i
c
a
t
i
o
n
Radio
1
Support 2 . 4 G H z a n d
5
G
H
z
Interface USB 2.0
Operating Voltage 5V
Antenna Connectors I-PEX
Frequency
B
and
802
.
11a
/b/g/
n
2400~2483.5 MHz and 5150~5850 MHz
Data
r
a
t
e 300Mbps
Receive
Sensitivity
(
Ty
p
i
ca
l
)
802.11g
≤ -89dBm@1~11Mbps
802.11g
≤ -89dBm@6Mbps
≤ -73dBm@54Mbps
802.11g/n_HT20 ≤ -89dBm @ MCS0/8
≤ -71dBm @ MCS7/15
802.11g/n_HT40 ≤ -89dBm @ MCS0/8
≤ -69dBm @ MCS7/15
802.11a
≤ -89dBm@6Mbps
≤ -72dBm@54Mbps
802.11a/n_HT20 ≤ -89dBm @ MCS0/8
≤ -70dBm @ MCS7/15
802.11a/n_HT40 ≤ -89dBm @ MCS0/8
≤ -68dBm @ MCS7/15
- 3 -
PRODUCT Pin Define
List of certificated antennas
Type
Connector
2412~2484MHz
PCB Dipole
U.FL
2
Type
Connector
5150~5250MHz 5250~5350MHz
5470~5725MHz
5725~5850MHz
PCB Dipole
U.FL
Gain : 3dBi
Manufacturer :Senao Networks
Model name : PCB DM AIOS core module ANT Dual-1.00 T:0.6*1L-45*10(HASL)P24 PAL
Note: The EUT has two antennas. (2TX/2RX)
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm separation
with the antenna while this end product is installed and operated. The end user has to be informed that
the IC radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end
user has to also be informed that any changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate this equipment. IC statement is required to be
available in the users manual: This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference
and (2) this device must accept any interference received, including interference that may cause
undesired operation.
3 3 3
