Loopless-Trigger-Radar Specifications

Specification history

File date company/name

LTRspecsV11 06-03-2006 Gatsometer BV

General description

The general purpose of this Radar system is to detect vehicles. Both speed and distance of the vehicle are meas-

ured. Also a trigger output signal is present for triggering a digital camera to get a photo of the vehicle.

Absolute Maximum Ratings:

Supply voltage: -16V...+16V (security against polarity change)

Input voltage at RS422 inputs A and B: -7V...+12V

Output current at RS422 outputs: short circuit proofed

Operating temperature: -20...+70°C

Storage temperature: -30...+100°C

Precautions have to be taken against high humidity or water.

All electrical interfaces are connected to 24V/600W trans.-supp-diodes.

The supply voltage is secured against false polarity.

Electrical Characteristics:

Supply voltage: 9...16V

Supply current: 170mA (typ.)

Transmit frequency: 24.000...24.250GHz

Transmit power: 20dBm (EIRP)

Antenna pattern: horizontal: 3.5° (+/-1.75°) (typically)

vertical: 15° (+/-7.5°) (typically)

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.
