TETRA DATASHEET SRG3900
A fully featured TETRA mobile radio, the SRG3900 offers a wide
range of installation options, dual remote console support, an
intuitive user interface, missed event notifications and Short Data
Application (SDA) support.
Going further in critical communications
SRG3900
MOBILE RADIO
Extends radio coverage
A 10W RF TETRA engine, and the most proven gateway and repeater
technology on the market, extends communication into areas previously
beyond network coverage.
Improved ease of use
With three presentation styles – grid, list and compatibility mode – the
SRG3900 uses the same enhanced user interface as the STP9000 and
STP8X, reducing the need for retraining.
Reduced cost of ownership
The SRG3900’s compatibility with all accessories from the SRG3500 range,
the Radio Manager 2 fleet management tool and the CMC encryption
management suite allows you to maximise the value of existing
investments.
Short Data Applications (SDAs)
Built and deployed on Radio Manager 2, SDAs permit the user to simply
and intelligently interact with a back-end IT system, allowing the
automation of work flows, job allocation and remote control.
WAP and SDS URL shortcuts
SDS text messages now support URL shortcuts that allow the user to
browse images and text, organised into a convenient and intuitive
WAP site. Accessed over the TETRA network, these sites allow the rapid
dissemination of data, such as missing person information.
GPS and Glonass satellite tracking
Uniquely, the SRG3900 integral GPS module tracks both GPS
satellites and the Glonass satellite network. Together with the latest
SBAS differential GPS support and CW anti-jamming technology, this
provides a greater degree of accuracy and security, and allows precise
location of resources.
When a team is operating on DMO with the SRG3900 functioning as a
network Gateway, it will automatically translate any received GPS location
messages so that DMO users of Sepura handhelds can continue to be
tracked.
Macro keys
Allow a complex sequence of functions to be combined and activated at
the touch of a single key.
Status triggered functions
Facilitate the remote control of SRG3900 over-the-air, from an authorised
Sepura radio or backend control system.
Network Performance monitoring
The SRG3900 can be remotely interrogated for a report on the signal level,
location, neighbour cells and data latency of a TETRA network, allowing
monitoring and auditing of the network service quality.
Enhanced user safety
Fully-configurable emergency call behaviour includes live microphone,
emergency status messaging and GPS/Glonass location reporting
options.
Flexible installation
Multiple installation options are supported, allowing tailored use in a
variety of vehicles and scenarios:
- Transceiver only for remote RCU/SCADA telemetry operation.
- Single console for car-, motorcycle-, marine-, desk-, air-1 and rack-
based solutions.
- Dual console for larger vehicles and train1 installations that require
SRG3900 CONSOLE OPTIONS
HANDSET BASED CONSOLE SCC BLUE BEZEL
SCC BLACK BEZEL
› Powerful
• Class-leading 10 Watts RF power
• Gateway licence-enabled option brings network coverage to groups of
DMO users
• Repeater licence-enabled option extends off-network coverage
• Loud, clear audio: 8W audio drive, allowing two speakers to be driven
7
.
Plus up to 2x1W of additional audio drive available via speaker mics or
speaker handsets attached to up to two SCC1 colour consoles
› Flexible
• Backwards compatible with existing Sepura mobile installations
• Multiple installation options: transceiver only, dual console, virtual console,
handset-based console
• Audio presentation options support PA broadcast, local recording and
third-party radio equipment.
• Additional features available via optional feature licence codes
› Intelligent
• Short Data Application and WAP support
• Night mode for easy low-glare viewing
• Over-the-air remote control via Sepura status-triggered functions
• Macro key support
• Performance monitoring for network analysis
• Combined GPS, Glonass trackin`g with differential GPS and ‘predictive
ephemeris’ support
• Over-the-air remote control via Sepura status-triggered functions.
• Variety of encryption options.
• Performance monitoring feature facilitates network analysis.
multiple control points, each of which can be mounted up to 30m
away from the transceiver. With automatic screen resolution and
colour adjustment to cater for differing consoles4
Control heads to suit your needs Sepura offers the widest range of
control heads on the market, each designed to match varying user
needs.
- SCC1: high-resolution colour console, IP54 certified, AMPS or DIN
slot mounted
- SCC2: high-resolution colour console, IP67 certified, dustproof and
waterproof
- HBC2: space-saving, high-resolution colour handset-based console,
IP55 certified
- HCU: IP67 certified handlebar mounted control unit
- Virtual console: integrates SRG3900 control from a PC/tablet
running Microsoft Windows
- Air approved consoles1
- Embedded car consoles
Specialist options
An international market leader within the TETRA policing, security
and surveillance markets, Sepura has created a number of specialist
options maximising the potential of the SRG for these sectors:
- Full and semi-covert installation solutions
- Suitcase-transportable variants
- Remote crypto smart-card reader
MOBILE SRG3900
- Tamper-proof security processors and a range of software license-enabled
E2E encryption options3
Direct mode gateway
Extending network coverage to DMO teams
Improved coverage
Links groups of users operating off-network in direct mode with the trunked
TETRA radio network, extending coverage into network dead spots
Intelligent communication
With Sepura Intelligent Call Conversion, the calling party only needs to call
the TETRA identity of the SRG3900. Once switched to DMO gateway mode,
the SRG3900 automatically converts and relays the incoming call or message
to the associated team of direct mode users.
Operational effectiveness
Status messaging and SDS-based messaging, including text and GPS
location reports, are seamlessly transferred between the network and direct
mode users. A control room dispatcher is able to track the positions of
individual users.
Extended coverage
Where no network coverage is available, the 10 watt DMO repeater allows
multiple direct mode users to exchange voice and data messages over a
wider area with increased reliability. The DMO repeater is ETSI-compliant
Type 1A, and uses a single frequency, saving scarce spectrum.
Note: Direct mode gateway and repeater services are enabled by a feature
licence code.
VIRTUAL CONSOLE SCREEN
SIZE AND WEIGHT
TRANSCEIVER
980g; 177mm x 50mm x 110mm
SEPURA COLOUR CONSOLE (SCC1)
220g; 185mm x 58mm x 33mm
HANDSET-BASED CONSOLE (HBC2)
225g; 69mm x 162mm x 28mm
FREQUENCY BANDS
344 - 400MHz
380 - 430MHz
407 - 473MHz
806 - 870MHz
POWER SUPPLY
10.8 to 15.6V DC, typical 13.8V DC
RF PERFORMANCE
10 watt RF power output (Class 2)
RF power adjustable in steps of 5dB, independently
adjustable for TMO and DMO operations.
Adaptive power control supported
Receiver static sensitivity -112dBm (-116dBm typical)
Receiver dynamic sensitivity -103dBm (-107dBm typical)
Receiver class A & B
AUDIO
Rated audio output - 8 W @1kHz into 4 Ohms
Dual speaker configuration capable of driving two 4 Ohms
speakers
Fixed level line-out audio option enabling broadcast and
recording support
2x1W of additional audio drive via speaker mics or
handsets attached to up to two SCC1 colour consoles
Line-in audio for third-party console interface support
Five independent volume controls for loudspeaker and
audio accessories 2, 4
Three audio accessories per console
ENVIRONMENTAL
Dust & water protection to IEC529 IP54
ETS 300 019 -2-5 drop, vibration & humidity
Storage temperature -40°C to +85°C5
Operating temperature -30°C to +70°C6
IP67 radio marine enclosure option
IP67 SCC2 console option
PRODUCT OPTIONS
GPS/Glonass location tracking
DMO Repeater Type 1A (license enabled)
DMO gateway (licence enabled)
Air Interface encryption options
End to end encryption options
Wide range of languages supported including Cyrillic,
Chinese, Korean & Arabic
Coloured bezels (on SCC1/SCC2 and HBC2 consoles)
Smart card support
Virtual console support (licence enabled)
Line in/out audio support (licence enabled)
Consoles: SCC1, SCC2 (IP67), HBC2 and Virtual Console
USER INTERFACE
Normal, large & very large mode text4
Night mode
262k colours plus mono chrome support
Dual remote console support
Call history
Phone book (2000 entries)
9900 talkgroups in TMO/DMO
5000 multi-level talkgroup folders
Intelligent search facility
Up to 50 dynamic group number assignment (DGNA) with
support for lifetime timers
Efficient management of talkgroups using up to 5000
folders in a multilevel folder structure with up to 75
talkgroups per folder
Talkgroup folder management via PEI and SDS
Priority group scanning with support for background
groups
Fast talkgroup access supports up to five TMO and five
DMO groups
Query selected talkgroup
Macro keys – operation of a single key will perform a
sequence of complex functions
Quick Groups
Transmit inhibit with on/off status messaging
Fixed & definable scan lists
Missed call indicator
Intuitively-enhanced user interface
Choice of three user interface presentation styles
(compatibility, grid & list)
Auto-capitalisation during SDS text entry
Two context keys
User profiles
CONSOLE: SCC1
High resolution 320 x 240 pixels QVGA TFT display
Large 57.6mm x 43.2mm active area
Three accessories supported: one front-mounted & two
rear-mounted audio accessories
Front-mounted connector for data & configuration via
Radio Manager
AMPS, on-dash & single DIN mount options
Fully compatible with existing accessories, cables & legacy
mounting options
Common enhanced Sepura user interface
Two context-sensitive keys4
Missed event LED and soft key
Tri-colour status LED
16 configurable soft keys
Dual remote console support, each up to 30m from the
transceiver
IP54 certified. IP67 variant available9
Optional coloured keymat bezels
CONSOLE: HBC2
Large high resolution 320x240 pixels QVGA 2.2” TFT
display
Hands-free mic & PTT option
Fist mic mode & handset installation modes
Magnetic cradle, AMPS mountable
Fully compatible with existing console cables
Common enhanced Sepura user interface
Two context-sensitive keys4
Missed event LED & soft key
Tri-colour status LED
16 configurable soft keys
Dual remote console support, each up to 30m from the
transceiver
IP55 certified
Optional coloured keymat bezels
Also available: virtual console, embedded car console,
handlebar control unit & air-approved console
VOICE SERVICES
Full duplex calls (to MS and PABX/PSTN)
Half duplex calls (Individual and Group)
Priority call
Emergency call (pre-emptive priority)
Intelligent alarm reporting
Talking party identity
Calling line identity presentation
DTMF dialling
MSISDN dialling
Abbreviated dialling
Dynamic group number assignment
Background (hidden) groups
Ambience listening
Privacy mode
Whisper mode
Group focus
DMO individual call
DMO group call
DMO emergency call
DMO intelligent emergency call
Independent volume control
Gateway pairing
DATA SERVICES
Status messaging (in TMO & DMO)
SDS messaging (in TMO & DMO)
SDS store & forward
SDS via DMO gateway
Auto-capitalisation on SDS text entry
Concatenated SDS messaging
Multi-slot packet data
Circuit mode data
TETRA paging and call out
WAP browsing
WAP shortcuts in SDS
Battery status advised immediately on start-up
Short Data Applications (SDAs)
Lone worker feature
Missed event application
LOCATION-BASED SERVICES (OPTIONAL)
34-channel concurrent GPS and GLONASS receiver
SBAS differential gps support
-191dBW (-161dBm) acquisition sensitivity
-191dBW (-161dBm) tracking sensitivity
Over-The-Air GPS reporting using the following protocols:
– ETSI location standard reporting (LIP)
– NMEA & Sepura compact messaging
Enhanced indoor start-up and acquire through ‘predictive
ephemeris’
Active anti-jamming of Continuous Wave (CW) jammers
Multipath mitigation
GPS-based compass
SECURITY SERVICES
Authentication – mutual and SwMI initiated
TMO & DMO Air Interface encryption support: TEA1, TEA2,
TEA3 & TEA43
Trunked mode class 1, 2, 3 & 3G TETRA security
Direct mode DM-2C support
PIN and PUK entry temporary enable and disable
Fully integrated E2E hardware with tamper protection
Public & private algorithm E2E support enabled via
software upgrade3
Integral SIM connector for smart card-based
E2EE options3
Optional remote smart card reader
Dual E2EE algorithm support with dynamic switching
of active algorithm3
Software authenticity and protection employing
digital signature
GATEWAY SERVICES (LICENCE REQUIRED)
Group voice call between DMO & TMO
Individual voice calls between DMO &TMO
Emergency group call from DMO to TMO & TMO to DMO
Pre-emption (in either direction) of existing call
SDS messaging in either direction
Configurable routing of SDS messages to console or
PEI intelligent handling of point to point calls and SDS
messages whilst operating as a gateway
REPEATER SERVICES (LICENCE REQUIRED)
DMO voice repeated
DMO tone signalling repeated
Group status & SDS repeated
Type 1A efficient operation over one RF channel
Presence signal support
Emergency call
Monitoring & participation in calls
CONNECTIVITY
TETRA voice and data
PEI Data via RS232, or USB data cables direct to radio or
via SCC1
Accessory connections via Consoles and AIU
SASI high speed interface for feature-rich audio
accessories (on SCC1 and SCC2)
Digital I/O lines (3 in, 1 out), expandable via AIU
Line level audio connection
Remote control via status-triggered functions
1 – Further information available on request
2 – Accessories connected at the rear of a console use the same volume level
3 – Functionality is subject to an export license
4 – Display mode and audio support will change when the legacy console, HBC or Virtual
Console are connected
5 – As defined in ETSI EN300 019-2-1 and EN300 019-2-2
6 – Operating at temperature extremes may limit some aspects of operational performance
7 – Speakers to be wired in parallel by installer
Sepura’s policy is to continually improve its products and services. The features and facilities de-
scribed in this document were correct at publication, but are subject to change without notice.
© Sepura plc. For more information visit sepura.com 0004_0414_V1_english
SRG3900
MOBILE RADIO

Navigation menu
