TETRA DATASHEET 9000 SERIES
The STP9000 is the agship of a highly innovative series
of TETRA hand-portable radios, designed for users who
want the best. Waterproof, submersible, dust-proof and
marine-hardened, the IP67-rated STP9000 provides the
latest smart technology in a ‘go anywhere’ package.
Going further in critical communications
STP9000
HAND-PORTABLE
Robustness – The STP9000 boasts an IP67 (submersible, waterproof
and dustproof) environmental protection rating, which means that it
will still function after having been submerged in up to 1m of water
for up to 30 minutes. In addition, new Connector Protector technology
provides marine-hardened protection against the corrosive damage
that salt water and salt fog can
cause to exposed connectors.
Improved ease of use – The STP9000 provides an enhanced user
interface, which oers three dierent presentation styles, which users
can select according to their personal preference:
- Compatibility mode allows existing Sepura users to be immediately
familiar with the STP9000.
- Grid and List modes will appear familiar to new users who may be
accustomed to user interfaces on smartphones or other GSM devices,
rather than a radio.
These new presentation styles lower training costs for both new and
existing Sepura users.
Smart keypad and display technology – Following detailed user
feedback, Sepura has added ‘haptic’ technology to the STP9000.
Haptics produce a physical movement of the radio, felt through the
hand, which conrms to gloved users that the key press has been
successful. In addition, the ‘Twist and Zoom’ feature uses smartphone
technology to allow a portrait image to be zoomed to full-screen
size, enabling the user to see full detail of an image, such as a missing
person, as they rotate the radio. The feature also enables access to
details concerning the image.
Resource and information management – Tracking radios,
particularly in a pooled system, can be dicult, so the STP9000’s
built-in RFID tag will be of considerable benet to many users.
In addition, the micro SD card slot makes it easy to store and
manage data, such as photos, maps, missing person information
and hazardous chemical data.
EMERGENCY OPERATION
Easy to locate and with a ‘Wake-On-Alarm‘
feature, the emergency key enhances
user safety.
RFID TAG
Facilitates access control solutions,
tracking of pool radios and potential
for integration with back-end systems.
NAVIKNOB™ OPERATION
In combination with the mode key,
provides simple and quick access to
talkgroups, volume adjustments, user
prole selection and status
messaging.
PRODUCT DESIGN
The STP9000 leverages the tough
technology developed for Sepura’s
STP8X Intrinsically-Safe series to deliver
a market-leading IP67 package, proven
to perform in the most demanding
operational environments.
LARGE TACTILE PRESSTOTALK KEY
Large and glove-friendly, located
on the side of the radio.
SMA ANTENNA CONNECTOR
Delivers 1.8 Watts of RF power in TMO,
DMO and repeater modes. Increases
range, thus extending network and
direct mode coverage.
STP9000 is a rugged TETRA HAND-PORTABLE
MANDOWN PERSONAL SAFETY
Multi-dimensional motion sensing technology
automatically provides man-down detection
and reporting option.
› Robust, ‘tough technology’ inherited
from state-of-the-art development for
the STP8X ATEX/IECEX radio
› Market-leading IP67 (submersible,
waterproof and dustproof) rating
› High power RF and audio, with
improved full-duplex audio experience
› Intuitive, enhanced UI, with 3
presentation styles (Grid, List and
Compatibility modes)
› Integral RFID tag allows rapid asset
tracking of pool-issued radios
› Fully integrated Bluetooth™ option
› Enhanced key tactility through
haptic-based technology
› Automatic Man-Down reporting option
LARGE, SUNLIGHTVISIBLE,
COLOUR DISPLAY
Featuring an enhanced user interface,
which oers three presentation styles
to suit user preferences.
BOTTOM CONNECTOR
Featuring Connector Protector
technology to provide protection
from corrosive salt water and salt fog.
ERGONOMIC KEYPAD
Large, well-spaced keys, enhanced by
haptic technology, which allow the user to
feel a key press, even through thick gloves.
POWERFUL AUDIO
Large loudspeaker delivers outstanding
audio, even in the noisiest environments.
Enhanced user safety – In addition to Man-Down, enhanced GPS and
STProtect capability, the Wake-On-Alarm feature, which enables the
STP9000 to be switched on and make an emergency call by pressing the
emergency button, also helps to protect users.
Reduced cost of ownership – The STP9000 is compatible not only with
all audio accessories, batteries and chargers from Sepura’s STP8000 hand-
portable range, but also with its market-leading Radio Manager 2 eet
management tool and CMC encryption management suite - all factors
which help organisations to maximise the value of existing investments.
Indoor location capability – An STProtect module can be optionally
tted within the radio. This is a key element of the STProtect complete
indoor location and lone-worker protection solution. It allows
organisations such as prisons, airports and industrial sites to track and
protect lone workers, locate employees, control access to restricted areas
and ensure pre-dened security patrol routes are being adhered to.
› Wake-On-Alarm activation
› Micro-SD memory card slot
› End-to-End encryption option
› DMO Repeater ready (frequency
ecient Type 1A option) with Call
Participation
›
A wide range of market-leading
accessories
› Supported by Sepura’s market-leading
software tools, including Radio
Manager 2
Focussed on oering new functional
possibilities and removing obstacles
to ecient and eective operation,
the STP9000 oers a range of benets
that make it more Reliable, Robust
and Secure.
HAND-PORTABLE
Truly innovative, designed
for critical communication
users who want the very
best TETRA radios.
Dimensions
Height: 133mm
Width: 61mm (54mm)
Depth: 32mm (Standard Battery)
37 .5mm (High Capacity Battery)
9000 SERIES
STPROTECT MODULE
An option which enables use of
Sepura’s STProtect indoor location
and lone worker solution.
STP9000
HAND-PORTABLE
1 – As dened in ETSI EN300 019-2-1 and EN300 019-2-2.
2 – Availability is subject to export licence.
3 – The Man-Down Alarm should in no way be regarded as a substitute for compliance with appropriate risk assessment and other safety procedures and practices.
To enable Man-Down a Software License is also required.
4 – Operating at temperature extremes may limit some aspects of operational performance.
5 – ‘Connector protector’ must be enabled in customisation. An antenna, a battery and either an accessory or the STP9000 series RAC cover must be tted.
6 – Bluetooth and STProtect hardware options cannot both be tted at the same time.
Sepura’s policy is to continually improve its products and services. The features and facilities described in this document were correct at publication, but are subject to change without notice.
DIMENSIONS
WEIGHT
FREQUENCY BANDS
POWER SUPPLY
RF PERFORMANCE
PRODUCT PERFORMANCE
DISPLAY AND USER INTERFACE
VOICE SERVICES
DATA SERVICES AND APPLICATIONS
SECURITY SERVICES
DMO REPEATER SERVICES (LICENCE REQUIRED)
CONNECTIVITY
ACCESSORIES
Height: 133mm
Width: 61mm (54mm)
Depth: 32mm (Standard Battery)
Depth: 37.5mm (High Capacity Battery)
With Standard Battery: 250g
With High Capacity Battery: 275g
380-430MHz – STP9038
407-473MHz – STP9040
7.4V (nominal) Lithium Polymer Battery Packs
Intelligent Reporting Batteries
1160mAh Standard Battery
1400mAh Mid Capacity Battery
1880mAh High Capacity Battery
RF Power – MS Power Class 3L (1.8 Watts)
RF Power – customisable for:
TMO/DMO/Repeater
Adaptive Power Control Supported
Receiver Class – A and B
Receiver Static Sensitivity – 112dBm (typical)
Receiver Dynamic Sensitivity – 103dBm
(106dBm typical)
Audio Power – >1 Watt
Operational Temperature (Conformance tested)
-20°C to +60°C
Operational Temperature (Min/Max)
-30°C to +70°C4
Storage Temperature -40°C to +85°C1
Dust & Water Protection IP67
(waterproof, submersible and dustproof )
Shock, drop & vibration ETS 300 019
Salt fog: MIL810E 509.4(l); duration 24hr salt5
Salt water: submersion, rated at 1m depth for
30 minutes5
Large 30x38mm Active LCD Area
Hi-Resolution display (176 x 220 pixels)
Transective TFT Display, 262K colours
Normal, Large & Very Large Mode Text
18 Congurable Feature Activation Keys
Vibrate Call/message
Call History
Phone Book (2000 entries)
9900 Talkgroups in TMO/DMO
5000 Multi-Level Talkgroup Folders
Intelligent Search Facility
Quick Groups
Transmit Inhibit with on/o Status Messaging
Fixed & denable Scan Lists
Remaining Charge Time Indication
Missed Call Indicator
Intuitively-enhanced user interface
Choice of three user interface presentation styles
(Compatibility mode, Grid mode and List mode)
Haptic technology to enhance key tactility when
used with heavy gloves
Twist and zoom portrait image viewer
Auto-capitalisation during SDS text entry
Full Duplex Calls (to MS and PABX/PSTN)
Half Duplex Calls (Individual and Group)
Priority Call
Emergency Call (Pre-emptive Priority)
Intelligent Alarm Reporting
Talking Party Identity
Calling Line Identity Presentation
DTMF Dialling
MSISDN Dialling
Abbreviated Dialling
Dynamic Group Number Assignment
Background (hidden) Groups
DMO Individual Call
DMO Group Call
DMO Emergency Call
DMO Intelligent Emergency Call
Independent Volume Control
Status messaging (in TMO & DMO)
SDS Messaging (in TMO & DMO)
Auto – capitalisation on SDS text entry
Concatenated SDS messaging
Multi-slot packet data
Circuit mode data
TETRA paging and call out
WAP browsing
Short Data Applications (SDAs)
Image & map storage on memory card
Lone-Worker feature
Missed event application
Authentication
Class 1, 2 and 3 and 3G TETRA Security
Air Interface Encryption
TEA1/2/3/4 Supported2
Smart Card E2E Encryption Support2
Embedded E2E Encryption Support2
In-Country E2E Encryption Algorithm Support2
Multiple E2E Algorithm Support2
DMO Voice Repeated
DMO Tone Signalling Repeated
Group Status & SDS Repeated
Type 1A Ecient Operation over one
RF Channel
Presence Signal Support
Emergency Call
Monitoring & Participation in Calls
TETRA voice and data
Bluetooth support for voice and data (PEI)
PEI Data via RS232 and USB data cables
Accessory connections via Rugged Accessory
Connector (RAC)
High speed interface for feature-rich audio
and data connection via facility connector
MicroSD card slot
RFID tag
STProtect
Personal Charger
Vehicle DC Charger
1+1 Desktop Charger
6+6 Desktop Charger
12 and 24 Way Battery only Chargers
Wide Range of Antennas
Stud and Belt Attachments
Rugged Belt Clip
Rugged and Soft Leather Cases
Basic IP55 Remote Speaker Microphone
Advanced Remote Speaker Microphone
(with and without RF Antenna)
Hands-Free Kit
Personal Ear Pieces
Public Order Accessories
Semi-Covert Accessories
Feature-rich Car Kit
Basic Car Kit
Serial and USB Data Leads
4 & 8 Way Programming Pods
GPS
Bluetooth6
Man-Down Alarm3
DMO Repeater Type 1A
Air Interface Encryption Options
End to End Encryption Options
Wide Range of Languages supported
STProtect – in-building tracking solution6
PRODUCT OPTIONS
RFID PERFORMANCE:
LOCATION BASED SERVICES
GPS integrated option -192dBw (-162dBm) tracking
sensitivity
Over-The-Air GPS reporting using the following
protocols
• ETSI location standard reporting (LIP)
• NMEA & Sepura compact messaging
GPS-based compass
Enhanced indoor start-up and acquire through
‘predicted ephemeris’
Bluetooth Location System compliant
STProtect
RFID tag equipped
Internal tag – HITAG S2048, short range, 125KHz,
ISO11784 and ISO11785 compliant
Range: 1 cm from back of individual
radio box pack
User accessible storage – 512 bits,
pre programmed (user can overwrite):
32 bit unique identier
Serial number
Hardware code
TEI
© Sepura plc. For more information visit sepura.com DN108 STP9000 English / May 2013

Navigation menu
