Shantou Chunchen Plastics & Metals Industrial Co., Ltd. RC Electric Toy Car Users Manual
Users Manual
OPERATING INSTRUCTIONS:
BATTERY REQUIREMENTS
(BATTERIES INCLUDED)
FOR VEHICLE: (SEE PICTURE #1)
1×Ni-Cd Rechargeable Cell Pack
(1.2V×5pc, 6V, 700mAh)
FOR TRANSMITTER: (SEE PICTURE #2)
1×9V 6F22 Dry Battery
(or 6LR61 Dry Battery)
ＤＥＬＵＸＥ ＲＣ ＴＯＹ ＳＰＯＲＴＳＣＡＲ
OR 5×AA Dry Battery(AA Batteries Not Provided)
HOW TO INSTALL BATTERIES IN VEHICLE:
[1] For the Ni-Cd Rechargeable Cell Pack: ( SEE PICTURE # 3)
1. Push the ON/OFF Switch to the OFF position;
2. Remove the screw by a Cross Screwdriver and open the battery cover on the back of the Sportscar;
3. Correctly push the Cell Pack’s plug into the Socket and put the Cell Pack into the box;
4. Put the battery cover on and screw it up.
5. Push the ON/OFF Switch to the ON position.
ATTENTION PARENTS:
It is recommended that this toy car and its accessories be periodically examined for potentialhazards and
that any potentially hazardous parts be repaired or replaced.
[2] For 5×AA Dry Batteries: (SEE PICTURE # 4)
1. Push the ON/OFF Switch to the OFF position;
2. Remove the screw by a Cross Screwdriver and open the battery cover on the back of the Sportscar;
3. Correctly push the Battery Shelf’s plug into the Socket and put the Battery Shelf into the box;
4. Insert 5 AA dry batteries into the Shelf by following the “+”/“-” polarity symbols;
5. Put the battery cover on and screw it up;
6. Push the ON/OFF Switch to the ON position.
HOW TO INSTALL BATTERIES IN TRANSMITTER: (SEE PICTURE # 5)
1. Remove the Screw by a Cross Screwdriver and open the battery cover of the Transmitter;
2. Insert a 9V Dry Battery (6F22 or 6LR61) into the box by following the “+”/“-” polarity symbols;
3. Put the battery cover on and screw it up.
PERFORMANCE TIPS:
1. If choose AA dry batteries for the vehicle’ s power supply, it is recommended to
use 5 pieces of Fresh Alkaline batteries (LR6) and not use fresh batteries and
used ones together;
2. Do not overcharge the Ni-Cd Cell Pack; the charge time should be no more than
3 hours;
3. When not used, it is recommend to remove the Cell Pack (AA dry batteries) and
9V dry battery from the vehicle and remote control respectively;
4. Do not drive the vehicle through Water;
5. Do not drive the vehicle in Grass, Sand;
6. Be sure to rest the vehicle for 30 Minutes after every 15 minutes of operation;
7. This toy is NOT suitable for children under 3 years old.
(PICTURE #1)
(PICTURE #2)
(PICTURE #3)
(PICTURE #4)
(PICTURE #5)
WARNING STATEMENT:
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
followingmeasures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that
changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment. In cases where the manual is provided only in a form other than paper
such as on a computer disk or over the Internet, the information required by this section may be included in the manual
in that alternative form,provided the user can reasonably be expected to have the capability to access information in that
form.
