Shaoxing Longxin Electronics S970-1020 WIFI-MOBILE INTERNET DEVICE (MID) User Manual SX UE312 En O
Shaoxing Longxin Electronics Co., Ltd. WIFI-MOBILE INTERNET DEVICE (MID) SX UE312 En O
Users Manual
2. Features
1. Introduction
3. Specification
5.
Input/Output Ports
8. Troubleshooting
6. KeyBoard name and function
• Power Input: 19V 2.1A
• Stock temperature: -20~60°C
• Operating temperature: 0~40°C
• Unit size: 190*246*15mm
• One year limited Warranty on parts and labor
4. Package Contents
• 9.7”SKYTAB X 1 • HDMI Cable X 1
• Power Adapter X 1
• Quickstart guide X 1
Quick Start Guide
9.7”SKYTAB Tablet PC
• Warranty card X 1
• eMusic gift card X 1
7. Charging
- P1- - P2- - P3- - P4-
• User Manual X 1
• Capacitive touch with 4-points of touch recognition
• CPU:Intel Atom N550 1.5GHz Dual-Core
• RAM:2GB DDR3 667MHz
• Wireless 802.11b/g/n
• Bluetooth 2.1 + EDR
• STORAGE:320GB 5400RPM Hard Drive
• GRAPHICS: Intel GMA3150 (Support HDMI to 1080P)
• CAMERA:1.3MP webcam
• Operating System:Windows 7 Home Premium
• Battery: Lithium Battery 36Wh (7.4V/4800mA)
1
2 3 4 5
• 1.Power switch
• 2.Volume up
• 3.Volume down
• 4.Enter key (Short click:enter and confirm,long click:right mouse click)
• 5.SAS Key (long click: the same as Ctrl+Alt+Del)
Enter
Enter
12
3
4
5
6
7
8
• 1.Microphone
• 2.MicroSD card slot
• 3.19V 2.1A DC input
• 4.Headphone
• 5.HDMI Output
• 6.Dock connector
• 7.USB 2.0
• 8.USB 2.0
• Power On: LED Red
• Charging: LED Red
• Charged: LED Off
LED Green
1. There is no audio coming from the earphones.
• Please check to see that the earphone plug is inserted completely into the jack.
2. The SKYTAB does not turn on .
• Plug in the power adapter and try again
• If still does not turn on after battery is fully charged or while the device is
plugged in，please contact customer service/tech support.
3. Excess noise/distortion .
• Please check to see if the earphone plug is clean，dirt may cause noise or
distortion.
• Check that the audio file has not been damaged. Play other music files to see
if the issue is widespread. If the file is corrupt, delete it from the device.
For contact information and/or troubleshooting, please visit our website at:
http://www.skytex.com/.
FCC Statement:
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
