OWNER’S GUIDE

V2950A

www.sharkclean.com

2TOLL FREE: 1-800-798-7398

1 Read all label, operational and marking instructions

before using the appliance.

2 Use ONLY as described in this manual. Use only

manufacturer’s recommended attachments.

3 To reduce the risk of injury, DO NOT allow to be

used as a toy. Close attention is necessary when

used by or near children.

4 DO NOT use for any purpose other than described

in this user’s guide.

5 DO NOT use with damaged cord or plug. Do not

use the cordless floor and carpet sweeper if it has

been dropped, damaged, left outdoors, or dropped

in water. Return it to EURO-PRO Operating LLC for

examination, repair or adjustment.

6 DO NOT abuse the charger cord. Never carry the

charger or base by the cord or yank to disconnect

from an outlet; instead grasp the charger and pull

to disconnect.

7 Keep the charger cord away from heated surfaces.

8 DO NOT use the charger with an extension cord.

Plug the charger directly into an electrical outlet.

Use charger only in a standard electrical outlet.

9 DO NOT attempt to use the charger with any

other product or attempt to charge this product

with another charger. Use only the charger model

YLS0041-T110025 supplied with this cordless

floor and carpet sweeper.

10 DO NOT charge this unit outdoors.

11 DO NOT use outdoors or on wet surfaces.

12 DO NOT handle plug or appliance with wet hands.

13 Use only on dry, indoor surfaces.

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

14 DO NOT put any object into openings. Do not use

with brush roll blocked; keep free of fiber, lint, hair

and anything that may prevent the brush roll from

working.

15 Keep hair, loose clothing, fingers and all parts of

body away from openings and moving parts.

16 DO NOT pick up anything that is burning or

smoking, such as cigarettes, matches or hot

ashes.

17 DO NOT use to pick up flammable or combustible

liquids such as gasoline or use in areas where they

may be present.

18 DO NOT attempt to change accessories while the

unit is running.

19 DO NOT use the cordless floor and carpet sweeper

without the dust cup in place.

20 Use extra care when cleaning on stairs.

21 Store the cordless floor and carpet sweeper

indoors. Store after use to prevent accidents.

22 Leaks from battery cells can occur under extreme

conditions. If the liquid, which is 20-35% solution

of potassium hydroxide, gets on the skin - wash

immediately with soap and water or neutralize with

a mild acid such as lemon juice or vinegar. If the

liquid gets into the eyes, flush them immediately

with clean water for a minimum of 10 minutes and

seek medical attention.

23 This product includes rechargeable nickel metal

hydride batteries. Batteries must be recycled

or disposed of properly. Do not incinerate the

batteries or expose to high temperatures as they

may explode.

24 The cordless floor and carpet sweeper must

be disconnected from the power supply when

removing the battery.

25 To reduce the risk of electrical shock, do not put

the charger and sweeper body in water or other

liquid. Do not place or store the appliance where it

can fall or be pulled into a tub or sink.

READ ALL INSTRUCTIONS BEFORE USING YOUR

SHARK® CORDLESS FLOOR AND CARPET SWEEPER.

WHEN USING YOUR SHARK CORDLESS FLOOR AND

CARPET SWEEPER, BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE OBSERVED, INCLUDING THE

FOLLOWING:

WARNING: TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK OR INJURY:

3www.sharkclean.com

TO MAXIMIZE THE LIFE OF YOUR

NI-MH BATTERIES:

1 Charge for 7 hours before initial use. Failure

to do so will reduce the product’s battery life

significantly.

2 Always remove the charging adapter fom the unit

after the charging period has completed.

3 Do not store the unit with the charging adapter

attached and plugged in.

4 For maximum battery life, only recharge the unit

when the batteries are close to fully discharged. It

is best to fully discharge the batteries at least once

a month.

5 DO NOT store in areas of high temperature or

humidity.

6 After 3 months of non-use, the product should be

fully discharged and then recharged to maximize

battery power.

7 Ni-MH batteries have a long useful life but at some

time they will need to be replaced. To purchase

replacement batteries, visit www.sharkclean.com.

NOTE: The On/Off switch must be in the “Off”

position in order to charge the unit. If the charging

indicator does not light, press the On/Off button

once.

SAVE THESE INSTRUCTIONS

Warning: Changes or modifications to this unit

not expressly approved by the party responsible for

compliance could void the user’s authority to operate

the equipment.

Note: This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If this equipment

does cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to try

to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV

technician for help.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and (2) this device must accept any interference

received, including interference that may cause

undesired operation.

4TOLL FREE: 1-800-798-7398

IMPORTANT: Before you can start using your new

cordless floor and carpet sweeper, you’ll need to

charge it for 7 hours.

ASSEMBLE

1 Assemble the upper and lower

handle into the elbow joint to

form the Shark® Backsaver™

folding handle. Then insert it

into the base of your cordless

floor and carpet sweeper.

(fig. 1)

Fig. 1

Fig. 2

Fig. 3

QUICK START

CLEAN

2 Pull back on the handle and

press lightly on the body of the

unit with your foot to engage the

steering. (fig. 2)

3 Using your foot, press the

On/Off button and push your

cordless floor and carpet

sweeper forward over the

surface you wish to clean.

(fig. 3)

4 Press the speed button on the

right with your foot to change

the speeds. One light indicates

the speed optimized to clean

bare floors and two lights

indicate the speed optimized to

clean carpets and larger debris

on bare floors.

Thank you

for purchasing

the Shark®

Cordless

Floor and

Carpet

Sweeper

5www.sharkclean.com

5 The Shark® Backsaver™ folding

handle makes cleaning under

furniture a breeze. Just press

the button on the handle with

your thumb to engage the

Shark® Backsaver™ function.

(fig. 4)

EMPTY

6 When you’re finished cleaning,

empty the No-Touch dust cup.

Simply press the dust cup

release pedal and lift out the

dust cup. (fig. 5)

Fig. 5

Fig. 6

Fig. 4

7 Over a trash can, empty the

dust cup by pressing the

bottom-empty button on the

lower portion of the handle.

When it’s empty, gently snap

the No-Touch dust cup back into

place. (fig. 6)

Thank you

for purchasing

the Shark®

Cordless

Floor and

Carpet

Sweeper

6TOLL FREE: 1-800-798-7398

ASSEMBLY OF YOUR FLOOR

AND CARPET SWEEPER:

1 Slide the upper pole (the tube

with the handle) into the end

of the Shark® Backsaver™ joint

that has a small notch in it (a).

Then slide the lower pole into

the other end of the joint (b).

Push it in until it clicks into

place. (fig. 1)

COMPONENTS:

A Floor and Carpet Sweeper Base

B Speed Control Button

C On/Off Button

D Upper Pole with Handle

E Backsaver™ Release Button

F Shark® Backsaver™ Joint

G Lower Pole

H Dust Cup Empty Lever

I Charging Adapter

Fig. 1

Fig. 2

Model Number: V2950A 32

Voltage: 7.2 V

A S SE M B LY

B

E

H

C

A

D

FG

I

2 Insert the Shark® Backsaver™

folding handle you just

assembled into the base. You

should hear the locking tab click

into place. (fig. 2)

IMPORTANT: You must charge

the batteries for 7 hours before

using the floor and carpet

sweeper for the first time.

See page 8 for instructions on

charging your unit.

a

b

7www.sharkclean.com

1 Press the On/Off button to start

the floor and carpet sweeper.

The lights on the base will

illuminate. When finished

cleaning, press the On/Off

button again to turn the unit off.

(fig. 3)

Fig. 3

Fig. 4

FLOOR

CARPET

Fig. 5

Fig. 6

If the brush roll stops

moving, it’s probably due

to the anti-jam feature.

This feature protects the

motor from becoming

overheated. If the brush

becomes overloaded, it

will stop turning and both

speed indicator lights will

stay on. Turn off your unit by

pressing the On/Off button

once. Then remove the brush

roll cover from the floor and

carpet sweeper base and

remove any hair or fiber

that may be on the brush

roll. Wait for 10 seconds

to let your unit cool down.

Now press the On/Off button

again and you’re ready to

resume cleaning!

See page 9 for further

instructions on removing or

cleaning the brush roll.

USING YOUR CORDLESS FLOOR AND CARPET SWEEPER

2 You can adjust the speed of

the brush roll to suit the floors

that you are cleaning. Press the

button on the right (opposite

the On/Off button) to switch

between speeds. One light

indicates the speed optimized to

clean bare floors and two lights

indicate the speed optimized to

clean carpets and larger debris

on bare floors. (fig. 4)

3 To clean under furniture, use

the Shark® Backsaver™ folding

handle. Press the handle

release button and apply a bit

of pressure to bend the handle

forward. (fig. 5) The Shark®

Backsaver™ joint will release

from the locked position to

reach messes under furniture.

(fig. 6)

8TOLL FREE: 1-800-798-7398

3 To re-insert the dust cup,

position it over the floor and

carpet sweeper base and press

down gently until it snaps into

place. (fig. 12)

For easy insertion into the

base, tip the dust cup slightly

forward.

IMPORTANT: Although many

adapters look similar, it’s

important to use only the

adapter that came with your

floor and carpet sweeper

(XA2950).

OFF

1 Always make sure that the unit

is turned off. (fig. 7)

2 Insert the charger plug into the

hole on the back of the floor

and carpet sweeper base.

(fig. 8) Plug the charger into a

wall outlet. The light next to the

On/Off button will illuminate

when the unit is charging. If

the unit is plugged in and the

light is not illuminated, press

the On/Off button once. The

light should now be illuminated

indicating that the unit is

charging. (fig. 9)

Fig. 7 Fig. 8

1 Press the dust cup release

pedal on the floor and carpet

sweeper base to remove the

No-Touch dust cup. (fig. 10)

Fig. 10 Fig. 11 Fig. 12

CHARGING YOUR CORDLESS FLOOR AND CARPET SWEEPER

EMPTYING THE DUST CUP

3 Let the battery recharge for 7

hours. Your cordless floor and

carpet sweeper is powered by

Ni-MH batteries that need this

time to build up their charge.

4 Always remove the charging

adapter from the unit after the

charging period has completed.

Storing the unit with the adapter

attached and plugged in will

reduce battery life.

2 Hold the dust cup over a trash

can and push the bottom-empty

button located on the lower

portion of the handle. The

trap door will spring open and

release the debris into the trash

can. (fig. 11)

Fig. 9

9www.sharkclean.com

Fig. 14

1 Once a month, wipe down your

unit with a dry cloth, including

the area under the dust cup.

Wipe away any hair, fiber or

other dirt that may have built

up in the chamber and on the

rotating brush. Do not use any

harsh sweeper or chemicals.

2 Do not immerse your floor and

carpet sweeper in water or use

it to pick up liquids or clean wet

floors. (Fig. 13)

3 Do not use it on concrete, tar or

other rough surfaces.

4 Do not use it to pick up pieces

of string or fabrics. (fig. 14) Do

not use the floor and carpet

sweeper to clean tasseled or

frayed carpets.

CLEANING THE ROTATING BRUSH

1 Press the dust cup release

lever with your foot and remove

it from the floor and carpet

sweeper base. (fig. 10)

2 Turn the unit upside down. Be

careful not to accidently turn

the unit on!

Fig. 13

3

Fig. 15

Fig. 18

Fig. 19

MAINTENANCE

3 Remove all hair, strings or fibers

wrapped around the brush

bar. Using a pair of scissors,

carefully cut along the raised

guide to remove anything

wound around the brush bar.

Avoid damaging or cutting the

bristles. (fig. 15)

4 Use a coin to unlock and

remove the trap door. (Fig. 16)

5 Carefully lift and remove the

brushbar from the belt.

(Fig. 17) To reinsert the

brushbar, slide the brushbar

into the bushing and then place

the belt over the ridges of the

brushbar cap. Replace the trap

door and lock in place.

REMOVING AND REPLACING THE

BATTERY

1 Press the dust cup release

lever with your foot and remove

it from the floor and carpet

sweeper base.

(fig. 10 on page 8)

2 Turn the unit upside down. Be

careful not to accidently turn

the unit on!

3 Push in the locking tab and lift

off the battery compartment

cover. (fig. 18)

4 Carefully lift out the battery

pack and disconnect the wire

terminals by pressing on the

latch and pulling apart the wire

terminal connectors. Remove

the battery pack. (fig. 19)

5 Connect the wire terminal from

the unit to the wire terminal

connector of the new battery

pack and replace the battery

pack into your unit.

6 Follow the instructions on page

8 to charge your new battery

pack. Please call customer

service at 1-800-798-7398

if you have any problems

removing the battery pack.

Fig. 16

Ni-MH BATTERY

MUST BE RECYCLED

OR DISPOSED OF

PROPERLY

Fig. 17

10 TOLL FREE: 1-800-798-7398

TROUBLESHOOTING GUIDE & REPLACEMENT PARTS

PROBLEM

The cordless floor and carpet

sweeper will not operate

The cordless floor and carpet

sweeper will not pick up

Dust is escaping from the

cordless floor and carpet

sweeper

Rotating brush will not pick

up

The cordless floor and carpet

sweeper will not charge

POSSIBLE REASONS AND SUGGESTED SOLUTION

Batteries need to be recharged.

Batteries are dead and need to be replaced.

There is no power in the electrical outlet being used. Try to charge using a

different outlet.

Ensure the wire terminal connectors on the battery pack are securely attached.

Clear any obstruction from the rotating brush.

If your unit still doesn’t work, call Customer Service at 1-800-798-7398.

Empty the dust container.

Recharge the battery

Empty the dust container.

Check for and remove any excessive material on the brush roll or in the

bottom of the unit.

Empty the dust container.

Press the power button once to turn the unit “OFF”.

There is no power in the electrical outlet being used. Try to charge using a

different outlet.

Ensure the wire terminal connectors on the battery pack are securely

attached.

Charging adapter may not be working. Call Customer Service at

1-800-798-7398.

Batteries are dead and need to be replaced

REPLACEMENT PARTS

A XB2950 Battery Pack

B XA2950 AC Adapter

C 1137FK-2950A Brush Bar Replacement Kit

To order any of the above replacement parts, go to www.sharkclean.com or call 1-800-798-7398.

ORDERING REPLACEMENT PARTS

11www.sharkclean.com

WARRANTY & PRODUCT REGISTRATION

EURO-PRO ONE-YEAR (1) LIMITED WARRANTY

EURO-PRO Operating LLC warrants this product to be free from defects in material and workmanship for a period

of one (1) year from the date of the original purchase, when utilized for normal household use, subject to the

following conditions, exclusions and exceptions.

If your appliance fails to operate properly while in use under normal household conditions within the warranty

period, return the complete appliance and accessories, freight prepaid to:

• U.S.: EURO-PRO Operating LLC

For customer service support call 1-800-798-7398

or visit www.sharkclean.com

• Canada: EURO-PRO Operating LLC

4400 Bois Franc, St. Laurent, Québec H4S 1A7

If the appliance is found to be defective in material or workmanship, EURO-PRO Operating LLC will repair or

replace it free of charge. Proof of purchase date and $19.95 to cover the cost of return shipping and handling must

be included.*

Non-durable parts including, without limitation, filters, brushes and electrical parts which normally require

replacement are specifically excluded from warranty.

The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at our

option. This warranty does not cover normal wear of parts and does not apply to any unit that has been tampered

with or used for commercial purposes. This limited warranty does not cover damage caused by misuse, abuse,

negligent handling or damage due to faulty packaging or mishandling in transit. This warranty does not cover damage

or defects caused by or resulting from damages from shipping or repairs, service or alterations to the product or any

of its parts, which have been performed by a repair person not authorized by EURO-PRO Operating LLC.

This warranty is extended to the original purchaser of the unit and excludes all other legal and/or conventional

warranties. The responsibility of EURO-PRO Operating LLC if any, is limited to the specific obligations expressly

assumed by it under the terms of the limited warranty. In no event is EURO-PRO Operating LLC liable for incidental

or consequential damages of any nature whatsoever. Some states do not permit the exclusion or limitation of

incidental or consequential damages, so the above may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or

province to province.

* IMPORTANT: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase date

and to attach tag to item before packing with your name, complete address and phone number with

a note giving purchase information, model number and what you believe is the problem with item. We

recommend you insure the package (as damage in shipping is not covered by your warranty). Mark the

outside of your package “ATTENTION CUSTOMER SERVICE”. We are constantly striving to improve our

products, therefore the specifications contained herein are subject to change without notice.

PRODUCT REGISTRATION

Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark® product within ten (10)

days of purchase. You will be asked to provide the store name, date of purchase and model number along with your

name and address.

The registration will enable us to contact you in the unlikely event of a product safety notification. By registering

you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying

instructions.

Copyright © 2013 Euro-Pro Operating LLC

USA: Newton, MA 02459

CANADA: Ville St-Laurent, QC H4S 1A7

Printed in China

Illustrations may differ with actual product.

V2950A 32_130405.1

Euro-Pro and Shark, are trademarks

of Euro-Pro Operating LLC.

www.sharkclean.com

1- 80 0 -798 -7398
