UV440
Owner’s Guide
WWW.SHARKCLEAN.COM
2
TOLL FREE: 1-800-798-7398
WARNING:
To reduce the risk of
electric shock or injury, do not use
outdoors or on wet surfaces.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
GENERAL ELECTRICAL SAFETY:
1. Unplug from electrical outlet when not in use
and before servicing.
2. DO NOT use vacuum with a damaged cord
or plug. If appliance is not working as it
should, has been dropped, damaged, left
outdoors, or dropped into water, return it to
EURO-PRO Operating LLC for examination,
repair, or adjustment.
3. DO NOT pull or carry vacuum by the cord.
4. DO NOT unplug by pulling on cord; to unplug,
grasp the plug, not the cord.
5. DO NOT handle plug or appliance with
wet hands.
6. DO NOT run the vacuum over the power cord.
7. DO NOT use the cord as a handle.
8. DO NOT close a door on the cord.
9. DO NOT pull cord around sharp corners. The
use of an extension cord is not recommended.
10. DO NOT leave appliance when plugged in.
11. Keep cord away from heated surfaces.
12. Turn off all controls before plugging or
unplugging vacuum cleaner.
13. Always turn off this appliance before connecting
or disconnecting motorized nozzle.
14. Store your appliance with the power cord
secured around the two cord holders-as
shown in the storage instructions.
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING AN ELECTRICAL
APPLIANCE, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE OBSERVED,
INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING
YOUR SHARK NAVIGATOR® LIFT-AWAY®
DELUXE.
POLARIZED PLUG:
To reduce the risk of electric shock, this appliance
has a polarized plug (one blade is wider than the
other). As a safety feature, this plug will fit into
a polarized outlet only one way. If the plug does
not fit fully into the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician.
DO NOT force into outlet or try to
modify to fit.
3
www.sharkclean.com
HOSE ATTACHMENTS:
1. DO NOT use if air flow is restricted; if the air
paths, the hose, or the accessories become
blocked, turn the vacuum cleaner off. Remove
all obstructions before you turn on the
unit again.
2. Keep the end of the hose and accessory
openings away from face and body.
3. Keep cleaning tools and hose suction openings
away from hair, face, fingers, uncovered feet,
or loose clothing.
4. Only use manufacturer’s recommended
attachments.
GENERAL USE:
1. Use only as described in this manual.
2. DO NOT put any objects into openings. DO
NOT use with any opening blocked; keep free
of dust, lint, hair, and anything that may reduce
air flow.
3. Keep your work area well lit.
4. Keep the vacuum moving over the carpet
surface at all times to avoid damaging the
carpet fibers.
5. DO NOT place vacuum on unstable surfaces
such as chairs or tables.
6. DO NOT allow young children to operate
the vacuum or use as a toy. Close attention is
necessary when used by or near children.
7. DO NOT use vacuum cleaner if it has been
dropped, damaged, left outdoors, or submerged
in water. Return to EURO-PRO Operating LLC
for examination, repair, or adjustment.
8. DO NOT use without dust cup and/or filters
in place.
DUST CUP/FILTERS/ACCESSORIES:
Before turning on the vacuum:
1. Make sure that all filters are thoroughly dry
after routine cleaning.
2. Make sure that dust cup and all filters are in
place after routine maintenance.
3. Make sure accessories are free of blockages.
4. Only use filters and accessories provided by
EURO-PRO Operating LLC. [Failure to do so will
void the warranty.]
GENERAL CLEANING:
1. DO NOT pick up large-sized objects.
2. DO NOT pick up hard or sharp objects such as
glass, nails, screws or coins that could damage
the vacuum cleaner.
3. DO NOT pick up smoking or burning objects
such as hot coals, cigarette butts, or matches.
4. DO NOT pick up flammable or combustible
materials such as lighter fluid, gasoline, or
kerosene or use vacuum in areas where they
may be present.
5. DO NOT pick up toxic solutions such as
chlorine bleach, ammonia, or drain cleaner.
6. DO NOT use in an enclosed space where
vapors are present from paint, paint thinner,
moth-proofing substances, flammable dust or
other explosive or toxic materials.
7. DO NOT vacuum up any liquids.
8. DO NOT immerse vacuum cleaner in water or
other liquids.
9. DO NOT use outdoors or on wet surfaces; use
only on dry surfaces.
10. Use extra care when cleaning on stairs.
SAVE THESE
INSTRUCTIONS
4
TOLL FREE: 1-800-798-7398
This manual covers model numbers:
UV440 26
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz
Watts: 1200W
Amps: 10A
Euro-Pro, Shark, and Navigator are trademarks of Euro-Pro Operating LLC. All other brand
names may be trademarks of their respective owners.
5
www.sharkclean.com
Getting Started 6
Mode 1: Upright Vac 8
Mode 2: Portable Lift-Away® 10
Above-Floor Cleaning 11
Storage 12
Maintenance 13
Emptying the Dust Cup 13
Cleaning the Pre-Motor Filters 13
Cleaning the Post-Motor HEPA Filter 14
Cleaning the Pet Power Brush 14
Cleaning the Motorized Floor Brush 14
Checking for Blockages 15
Troubleshooting Guide 16
Ordering Parts 17
Warranty & Product Registration 19
Contents
Thank you for
purchasing
the Shark
Navigator®
Lift-Away®
Deluxe
6
TOLL FREE: 1-800-798-7398
FIRST THING’S FIRST, YOU NEED TO KNOW
WHAT’S IN THE BOX YOU JUST OPENED:
a Handle with Stretch Hose
b Accessory Holder
c Extension Wand
d Portable Lift-Away®
e Motorized Floor Brush
f Dusting Brush
g Crevice Tool
h Power Brush
i Extension Wand
f
hACCESSORIES:
CREVICE TOOL
Reach deep into narrow spaces and clean between
cushions, under radiators and baseboards and in
hard to reach crevices and corners. (Fig. 1)
DUSTING BRUSH
Dust shelves, lamp shades, window blinds, books,
furniture and other upholstered household items.
(Fig. 2)
POWER BRUSH
This unique tool was engineered for fast and
easy removal of pet hair and ground in dirt from
carpeted stairs and upholstery. (Fig. 3)
ACCESSORY HOLDER
Designed to hold the crevice tool and dusting brush.
For quick access to tools when vacuuming and
cleaning around the house. (Fig. 4)
EXTENSION WAND
Reach even further and attach the crevice tool, the
dusting brush or the power brush for cleaning all
around the house. (Fig. 5)
Fig. 1
Fig. 4
Fig. 2
Fig. 3
a
e
c
d
b
g
Getting Started
Fig. 5
i
7
www.sharkclean.com
Your new Shark Navigator® Lift-Away® Deluxe vacuum cleaner can easily be configured into
different cleaning modes to meet all your cleaning needs: upright vacuum and portable Lift-
Away® - both with constant suction power.
MODES:
1 UPRIGHT VAC
Upright vacuuming - floors and carpets. (Fig. 6)
Fig. 6
Fig. 7
2 PORTABLE LIFT-AWAY®
Take the Lift-Away® with you around the house to
clean hard to reach places. (Fig. 7)
8
TOLL FREE: 1-800-798-7398
To reduce the risk of electric shock, unplug the unit before assembling, adding or removing attachments or
converting modes.
WARNING: The On/Off switch is on the top of the Lift-Away® canister. Always ensure the power is OFF
(“O” position) before plugging and unplugging.
TO ASSEMBLE:
1 Place the floor nozzle on a level surface.
2 Align the tube of the floor nozzle with the tube on
the Lift-Away® canister and lower until you hear
the two pieces click into place. (Fig. 8)
When attaching the motorized floor brush, ensure
that the latching mechanism is fully locked in place
to ensure electrical connection has been made.
3 Attach the end of the extension wand to the tube
on the back of the Lift-Away® canister until it
clicks into place. (Fig. 9)
4 Slide the accessory holder (a) positioned opposite
the upper cord wrap, over the extension wand.
Align the tab with the groove and push down.
(Fig. 10)
5 Push the handle (b) onto the top of the extension
wand until you hear it click into place. (Fig. 10)
6 Insert the end of the stretch hose (c) into the
connector on the back of the Lift-Away® canister.
(Fig. 10)
7 Store the dusting brush (d) and the crevice tool (e)
on the mounts of the accessory holder. (Fig. 10)
Fig. 8 Fig. 9
Fig. 10
Mode 1: Upright Vac
c
Upper Cord
Storage Wrap
a
d
e
b
9
www.sharkclean.com
TO USE:
1 Rotate the cord release to quickly release the
power cord.
2 Secure the power cord in the cord hook.
= Brush Roll ON
= Bare Floor
= OFF
3 Press the On/Off switch (a) to the “I” position to
vacuum bare floors (straight suction only) or to the
“II” position to engage the motorized floor brush
(for vacuuming carpets and rugs). (Fig. 11)
IMPORTANT: The motorized brush indicator light
(b) will illuminate green when motorized floor
brush is on, or red if there is a blockage or jam.
(Fig. 11) This feature is designed to protect your
Lifetime Belt that powers your motorized floor
brush. See Checking for Blockages on page 15.
4 Gently press the floor nozzle down with your foot
while you grasp the handle and tilt it back towards
you. (Fig. 12)
NOTE: The rotating brush on the motorized
floor brush will not spin unless the nozzle is flat
against the floor and the handle is tilted back.
5 Due to the huge suction power of this
vacuum, it may become necessary at
times to adjust the suction release (c) on
the handle. (Fig. 11) If the vacuum seems
difficult to push or pull or if it is lifting
up area rugs, adjust the suction release
by rotating the collar 90° counterclockwise
to open the valve. Rotate the collar
clockwise to close the valve when you need
high suction and for vacuuming floors.
6 Empty dust cup after vacuuming and periodically
during use when it appears full. (See
“Maintenance” section for instructions.)
7 When you are finished vacuuming, turn the
vacuum off.
Fig. 12
Fig. 11
Release suction
for easier push &
pull on high pile
carpets and
area rugs.
b
a
Suction
Release Collar
c
10
TOLL FREE: 1-800-798-7398
a
You can carry your vacuum cleaner
in both modes by the carry handle
located on top of the dust cup.
Fig. 15
Fig. 14
Fig. 13
Mode 2: Portable Lift-Away®
b
a
PORTABLE LIFT-AWAY®
1 Separate the portable Lift-Away® canister from
the floor nozzle by pressing the red release
button (a) on the side of the canister. Gently
hold the nozzle to the floor with your foot and
pull the canister up. (Fig. 13)
2 Press the handle release button (a) and pull the
handle up or press the extension wand release
button (b) and pull the extension wand up.
(Fig. 14)
3 Attach desired accessory onto the end of either
the extension wand or the handle.
4 Press the On/Off switch to the “I” position to
turn the vacuum on for above-floor cleaning and
hold the handle in one hand while you carry the
portable Lift-Away® around the house with the
other hand. (Fig. 15)
11
www.sharkclean.com
Fig. 16
Suction
Release Collar
a
Above-Floor Cleaning
CLEAN ABOVE THE FLOOR IN UPRIGHT VAC OR
PORTABLE LIFT-AWAY® MODE
1 Press the handle release button and pull the
handle up or press the extension wand release
button and pull the extension wand up.
2 Attach desired accessory onto the end of either the
extension wand or the handle. (Fig. 16)
3 Your vacuum has tremendous suction
power. Adjust the amount of suction with
the suction release on the handle. Open
the valve (a) by rotating the collar 90˚
counterclockwise for low suction when
doing light jobs such as drapes or fine
surfaces. Close the valve (a) by rotating the
collar clockwise 90˚ for high suction and
when using the hand held power brush.
(Fig. 16)
4 Press the On/Off switch to the “I” position to turn
the vacuum on for above-floor cleaning.
IMPORTANT: Ensure vacuum is in upright
position. Do not use position “II” when cleaning
above the floor in the upright vac mode as this
will engage the motorized floor brush. The
rotating brush may damage your floor if run for a
prolonged period of time in one area.
Release suction when
dusting delicate objects,
furniture or draperies.
12
TOLL FREE: 1-800-798-7398
Fig. 17
Quick
Cord Release
Lower Cord
Storage Clip
Storage and Maintenance
STORE YOUR VACUUM SAFELY
1 Convert your vacuum back to upright vac mode.
2 Rotate the upper quick cord release to its upright
position and coil the power cord loosely around
the two clips. Clip the plug onto the cord to secure.
(Fig. 17)
3 Store the dusting brush and the crevice tool on the
mounts on the accessory holder.
4 Store your vacuum cleaner safely in a cool dry area
where it will not be a hazard, will not get damaged
and will not cause damage to anyone or anything.
NOTE: Empty dust cup after cleaning and prior
to storing. (See “Maintenance” section for
instructions.)
To reduce the risk of electric shock, unplug the unit
before performing any cleaning, maintenance, or
troubleshooting checks.
Reassemble all parts securely before operating
vacuum.
DO NOT operate the vacuum without the filters
and dust cup in place.
DO NOT operate the vacuum with WET filters.
IMPORTANT: Make sure all filters are completely
dry before inserting back into vacuum.
WARNING: Never insert sharp objects into any
opening to clear an obstruction.
IMPORTANT: Damages caused while clearing
or attempting to clear blockages are not covered
under your products limited warranty.
13
www.sharkclean.com
IMPORTANT: Loss of Suction may
occur if foam filters are not cleaned
every 3 months. Rinse and allow to
air dry completely. Also, tap loose dirt
off filter between washes as needed.
Foam filters may appear dirty after
use - this is normal.
Fig. 18 Fig. 19
COMPONENT
MAINTENANCE SCHEDULE
Rinse and air dry every 3 months under normal use.
Empty each time you vacuum.
Pre-Motor Foam Filter
Dust Cup
Rinse and air dry every 3 months under normal use.
Pre-Motor Felt Filter
Clean once every 2 years or as needed.
Post-Motor HEPA Filter
1
2
3
4
CLEANING THE PRE-MOTOR FILTERS
1 Remove the dust cup.
2 Pull the 2 filters out from the top of the motor
base. (Fig. 21)
3 Rinse the filters thoroughly in lukewarm water until
the water runs clear.
DO NOT put the filter in the washing machine or
dishwasher.
NOTE: The material in the filter will discolor over
time. This is NORMAL and will not affect the
performance of the filter.
4 Squeeze out excess water and let air-dry for at
least 24 hours before replacing. Do not use a hair
dryer or other heating methods to dry.
5 Place the felt filter in first, then the foam filter.
6 Replace the dust cup.
EMPTYING THE DUST CUP
The dust cup needs to be emptied each time you
vacuum and periodically during cleaning, when the
dust cup appears full.
1 Undo the latches on the sides of the dust cup by
lifting them up and outwards to remove the dust
cup from the motor base. (Fig. 18)
2 Hold the dust cup over a trash receptacle and
press the bottom door release button. (Fig. 19)
Tap gently to empty contents. Press the door shut
again until it clicks.
3 If needed, turn the dust cup upside down over the
trash receptacle and press the top door release
button. (Fig. 20) Tap gently to remove contents.
Use a dry cloth or paper towel to remove debris
stuck to the screen filter inside the dust cup. Press
the door shut again until it clicks.
4 Replace the dust cup on top of the motor base.
Hook the two latches onto the tabs on the sides of
the dust cup and push down to lock.
Screen
Filter
Fig. 20
Fig. 21
Pre-Motor
Foam Filter
Felt Filter
Post Motor
HEPA Filter
Maintenance
14
TOLL FREE: 1-800-798-7398
CLEANING THE POWER BRUSH
1 Slide the locking latch (a) forward and gently tilt
brush housing upward to remove. (Fig. 25)
2 Carefully remove any blockage or debris and
cut away any build-up of hair or string wrapped
around the rotating bristle brush with scissor.
3 To reassemble, insert the tabs on the front edge
of the bottom cover into the matching holes in the
top half and tilt it back down until it clicks into
place. (Fig. 26)
Fig. 23
Fig. 22
Fig. 24
CLEANING THE POST-MOTOR HEPA FILTER
1 Remove the filter cover from the front of the
vacuum by pulling up on the tab and pulling the
cover away from the vacuum. (Fig. 22)
2 Take out the HEPA filter by pulling it straight out.
3 Turn the filter over so that the dirty side is on
the bottom and vigorously tap it clean against a
garbage can to remove any dust. (Fig. 23)
4 Wash the filter under the tap using lukewarm
water with the dirty side face down until the water
runs clear. (Fig. 24)
DO NOT put the filter in the washing machine or
dishwasher.
NOTE: The material in the filter will discolor over
time. This is NORMAL and will not affect the
performance of the filter.
5 Allow the filter to air dry for 24 hours. Do not use a
hair dryer or other heating methods to dry.
6 Once the HEPA filter is dry, replace it back into the
vacuum.
7 Replace the cover by inserting the two tabs into
the holes at the top and then swinging the cover
down until it clicks into place.
Fig. 26
Fig. 25
CLEANING THE MOTORIZED FLOOR BRUSH
When your motorized floor brush needs cleaning or
locks onto an object, it automatically shuts down to
prevent damage to your lifetime belt. The indicator
light will illuminate red warning you to turn off the
vacuum and clear blockage immediately. The light will
reset itself once blockage has been cleared and power
has been cycled on/off or vacuum has been locked in
the upright position.
1 Detach the motorized floor brush from the portable
Lift-Away® canister.
2 Inspect the opening underneath and the rotating
brush. If a build-up of debris is present, remove it.
Carefully cut anything wound around the rotating
brush with scissors. Avoid damaging or cutting the
bristles. (Fig. 27)
Maintenance - cont’d
Rotating
Brush
Fig. 27
a
15
www.sharkclean.com
CHECKING FOR BLOCKAGES
Blockages may cause your vacuum to overheat and
shut down. To prevent this from happening, check
potential blockage areas after heavy use or if you
detect a loss of suction or poor cleaning performance.
1 Dust Cup
Dust cup may be full. Empty dust cup.
2 Pre-Motor & Post-Motor Filters
• Pre-motorltersrequirewashingevery3
months for optimum performance.
The post-motor HEPA filter needs to be washed
every 2 years.
• Ensurethatalltheltersareclean.
3 Accessories
• Checkintakeopenings:
- Extension Wands
- Dusting Brush
- Crevice Tool
- Power Brush
4 Hose and Connections to Vacuum
• Detachthestretchhosefromthebackofthe
portable Lift-Away® canister by squeezing
the tabs together and pulling up. (Fig. 28)
Straighten out the hose and look inside for
blockages.
• Removethedustcupandextensionwandand
separate the portable Lift-Away® canister
from the motorized floor brush. Look in all 4
openings for any blockages. (Fig. 29)
5 Motorized Floor Brush
(Side suction models)
• Detachthehoseonthemotorizedoorbrush
at the top by squeezing the tabs together and
pulling out, and at the bottom by pulling out
the connector. Inspect inside the 3 holes.
(Fig. 30)
Make sure you are working in a well
lit area and use a flashlight to help
search for blockages.
Fig. 30
Fig. 29
Fig. 28
16
TOLL FREE: 1-800-798-7398
PROBLEM POSSIBLE REASONS & SOLUTIONS
Vacuum is not
picking up dirt.
Check filters to see if they need cleaning. Follow instructions for rinsing
and drying the filters before re-inserting back into the vacuum. (See
“Maintenance” sections for instructions.)
Dust cup may be full; empty dust cup.
Check hose and hose connections for blockages; clear blockages if required.
If dust cup is empty, and attachment inlets are clear, check for other
blockages. (See “Checking for Blockages” for instructions.)
Vacuum lifts scatter rugs
(lightweight, movable
rugs).
Suction is powerful. Take care when vacuuming scatter-type rugs or rugs with
delicately sewn edges. Open the suction release on the handle to decrease
suction power.
Move the On/Off switch to “I - Suction Only” position to disengage the
brush roll
Airflow is restricted. No
suction or light suction.
Check filters to see if they need cleaning. Follow instructions for rinsing and
drying the filters before re-inserting back into the vacuum.
Dust cup may be full; empty dust cup.
Check hose, hose connections, nozzles and accessories for blockages; clear
blockages if required.
Close the suction release on the handle to increase suction power.
If dust cup is empty, and attachment inlets are clear, check for other
blockages.
Brush roll does not spin
Immediately turn off and unplug vacuum, disconnect the nozzle and remove
blockage before reconnecting and turning vacuum back on.
Pull the handle toward you and release the floor nozzle to disengage the
auto-off feature.
Move the On/Off switch to the “II - Brush Roll On” position.
Vacuum turns off
on its own.
This vacuum cleaner is equipped with a motor protective thermostat. If for
some reason your vacuum overheats, the thermostat will automatically turn
the unit off. Should this occur, perform the following steps to restart the
motor thermostat:
1. Move the On/Off switch to the “O” (Off) position.
2. Unplug the vacuum.
3. Empty the dust cup and clean filters.
4. Check for blockages in hose, accessories and inlet openings.
5. Allow the unit to cool for a minimum of 45 minutes.
6. Plug in the vacuum.
7. Turn the On/Off switch to the “I” (On) position to restart the vacuum.
Note: If vacuum still does not start, contact Customer Service at:
1-800-798-7398.
Troubleshooting Guide
17
www.sharkclean.com
PART PART NO.
1 Pre-Motor Filter Set XFF350
2 HEPA Filter XHF350
3 Dusting Brush & Crevice Tool 112FFJ
4 Power Brush 119FFJ
5 Extension Wand 1116FC
4
3
1
2
5
Ordering Parts
To purchase replacement parts, please visit our website: www.sharkclean.com
or contact customer service: 1-800-798-7398.
18
TOLL FREE: 1-800-798-7398
Notes
19
www.sharkclean.com
EURO-PRO FIVE-YEAR (5) LIMITED WARRANTY
EURO-PRO Operating LLC warrants this product to be free from material defects and workmanship for a period of
five (5) years from the date of purchase when utilized for normal household use, subject to the following conditions,
exclusions and exceptions.
The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at
our option. This Limited Warranty does not cover normal wear of parts and does not apply to any unit that has been
tampered with or used for commercial purposes. This Limited Warranty does not cover damage caused by misuse,
abuse, negligent handling or damage due to faulty packaging or mishandling in transit. This Limited Warranty does
not cover damage or defects caused by or resulting from damages from shipping or repairs, service or alteration
to the product or any of its parts, which have been performed by a repair person not authorized by EURO-PRO
Operating LLC.
If your appliance fails to operate properly while in use under normal household conditions within the warranty
period, you may return the complete appliance and accessories with proof of purchase and date, freight prepaid. For
customer service support, call 1-800-798-7398 or visit our website at www.sharkclean.com.
If the appliance is found by EURO-PRO Operating LLC to be defective, in EURO-PRO Operating LLCs sole
discretion, we will repair or replace it free of charge. Proof of purchase date and a check made payable to EURO-
PRO Operating LLC in the amount of $19.95 to cover the cost of return shipping and handling must be included.*
Non-durable parts including, without limitation, filters, brushes and electrical parts which normally require
replacement are specifically excluded from warranty.
This Limited Warranty is extended to the original purchaser of the unit and excludes all other legal, implied and/or
conventional warranties. The responsibility of EURO-PRO Operating LLC if any, is limited to the specific obligations
expressly assumed by it under the terms of this Limited Warranty. In no event is EURO-PRO Operating LLC liable
for incidental or consequential damages to anyone of any nature whatsoever. Some states do not permit the exclusion
or limitation of incidental or consequential damages, so the above may not apply to you.
This Limited Warranty gives you specific legal rights, and you may also have other rights which vary from state to state
or province to province.
*IMPORTANT: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase
date and to attach a tag to item before packing including your name, complete address and phone
number with a note giving purchase information, model number and what you believe is the problem
with the item. We recommend you insure the package (as damage in shipping is not covered by your
warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”. We are constantly
striving to improve our products, therefore the specifications contained herein are subject to change
without notice.
Product Registration
Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark® product within ten (10)
days of purchase. You will be asked to provide the store name, date of purchase and model number along with your
name and address.
The registration will enable us to contact you in the unlikely event of a product safety notification. By registering
you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying
instructions.
EURO-PRO Operating LLC
U.S.: Newton, MA 02459
Canada: Ville St. Laurent, Québec H4S 1A7
1-800-798-7398
www.sharkclean.com
Copyright © Euro-Pro Operating LLC 2013
Printed in China
Illustrations may differ from actual product.
Euro-Pro, Shark, and Navigator are trademarks of Euro-Pro Operating LLC. All other
brand names may be trademarks of their respective owners.
UV440.26.E.130419.1

Navigation menu
