UV440

Owner’s Guide

WWW.SHARKCLEAN.COM

2

TOLL FREE: 1-800-798-7398

WARNING:

To reduce the risk of

electric shock or injury, do not use

outdoors or on wet surfaces.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR INJURY:

GENERAL ELECTRICAL SAFETY:

1. Unplug from electrical outlet when not in use

and before servicing.

2. DO NOT use vacuum with a damaged cord

or plug. If appliance is not working as it

should, has been dropped, damaged, left

outdoors, or dropped into water, return it to

EURO-PRO Operating LLC for examination,

repair, or adjustment.

3. DO NOT pull or carry vacuum by the cord.

4. DO NOT unplug by pulling on cord; to unplug,

grasp the plug, not the cord.

5. DO NOT handle plug or appliance with

wet hands.

6. DO NOT run the vacuum over the power cord.

7. DO NOT use the cord as a handle.

8. DO NOT close a door on the cord.

9. DO NOT pull cord around sharp corners. The

use of an extension cord is not recommended.

10. DO NOT leave appliance when plugged in.

11. Keep cord away from heated surfaces.

12. Turn off all controls before plugging or

unplugging vacuum cleaner.

13. Always turn off this appliance before connecting

or disconnecting motorized nozzle.

14. Store your appliance with the power cord

secured around the two cord holders-as

shown in the storage instructions.

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

WHEN USING AN ELECTRICAL

APPLIANCE, BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE OBSERVED,

INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING

YOUR SHARK NAVIGATOR® LIFT-AWAY®

DELUXE.

POLARIZED PLUG:

To reduce the risk of electric shock, this appliance

has a polarized plug (one blade is wider than the

other). As a safety feature, this plug will fit into

a polarized outlet only one way. If the plug does

not fit fully into the outlet, reverse the plug. If it

still does not fit, contact a qualified electrician.

DO NOT force into outlet or try to

modify to fit.

3

www.sharkclean.com

HOSE ATTACHMENTS:

1. DO NOT use if air flow is restricted; if the air

paths, the hose, or the accessories become

blocked, turn the vacuum cleaner off. Remove

all obstructions before you turn on the

unit again.

2. Keep the end of the hose and accessory

openings away from face and body.

3. Keep cleaning tools and hose suction openings

away from hair, face, fingers, uncovered feet,

or loose clothing.

4. Only use manufacturer’s recommended

attachments.

GENERAL USE:

1. Use only as described in this manual.

2. DO NOT put any objects into openings. DO

NOT use with any opening blocked; keep free

of dust, lint, hair, and anything that may reduce

air flow.

3. Keep your work area well lit.

4. Keep the vacuum moving over the carpet

surface at all times to avoid damaging the

carpet fibers.

5. DO NOT place vacuum on unstable surfaces

such as chairs or tables.

6. DO NOT allow young children to operate

the vacuum or use as a toy. Close attention is

necessary when used by or near children.

7. DO NOT use vacuum cleaner if it has been

dropped, damaged, left outdoors, or submerged

in water. Return to EURO-PRO Operating LLC

for examination, repair, or adjustment.

8. DO NOT use without dust cup and/or filters

in place.

DUST CUP/FILTERS/ACCESSORIES:

Before turning on the vacuum:

1. Make sure that all filters are thoroughly dry

after routine cleaning.

2. Make sure that dust cup and all filters are in

place after routine maintenance.

3. Make sure accessories are free of blockages.

4. Only use filters and accessories provided by

EURO-PRO Operating LLC. [Failure to do so will

void the warranty.]

GENERAL CLEANING:

1. DO NOT pick up large-sized objects.

2. DO NOT pick up hard or sharp objects such as

glass, nails, screws or coins that could damage

the vacuum cleaner.

3. DO NOT pick up smoking or burning objects

such as hot coals, cigarette butts, or matches.

4. DO NOT pick up flammable or combustible

materials such as lighter fluid, gasoline, or

kerosene or use vacuum in areas where they

may be present.

5. DO NOT pick up toxic solutions such as

chlorine bleach, ammonia, or drain cleaner.

6. DO NOT use in an enclosed space where

vapors are present from paint, paint thinner,

moth-proofing substances, flammable dust or

other explosive or toxic materials.

7. DO NOT vacuum up any liquids.

8. DO NOT immerse vacuum cleaner in water or

other liquids.

9. DO NOT use outdoors or on wet surfaces; use

only on dry surfaces.

10. Use extra care when cleaning on stairs.

SAVE THESE

INSTRUCTIONS

4

TOLL FREE: 1-800-798-7398

This manual covers model numbers:

UV440 26

TECHNICAL SPECIFICATIONS

Voltage: 120V., 60Hz

Watts: 1200W

Amps: 10A

Euro-Pro, Shark, and Navigator are trademarks of Euro-Pro Operating LLC. All other brand

names may be trademarks of their respective owners.

5

www.sharkclean.com

Getting Started 6

Mode 1: Upright Vac 8

Mode 2: Portable Lift-Away® 10

Above-Floor Cleaning 11

Storage 12

Maintenance 13

Emptying the Dust Cup 13

Cleaning the Pre-Motor Filters 13

Cleaning the Post-Motor HEPA Filter 14

Cleaning the Pet Power Brush 14

Cleaning the Motorized Floor Brush 14

Checking for Blockages 15

Troubleshooting Guide 16

Ordering Parts 17

Warranty & Product Registration 19

Contents

Thank you for

purchasing

the Shark

Navigator®

Lift-Away®

Deluxe

6

TOLL FREE: 1-800-798-7398

FIRST THING’S FIRST, YOU NEED TO KNOW

WHAT’S IN THE BOX YOU JUST OPENED:

a Handle with Stretch Hose

b Accessory Holder

c Extension Wand

d Portable Lift-Away®

e Motorized Floor Brush

f Dusting Brush

g Crevice Tool

h Power Brush

i Extension Wand

f

hACCESSORIES:

CREVICE TOOL

Reach deep into narrow spaces and clean between

cushions, under radiators and baseboards and in

hard to reach crevices and corners. (Fig. 1)

DUSTING BRUSH

Dust shelves, lamp shades, window blinds, books,

furniture and other upholstered household items.

(Fig. 2)

POWER BRUSH

This unique tool was engineered for fast and

easy removal of pet hair and ground in dirt from

carpeted stairs and upholstery. (Fig. 3)

ACCESSORY HOLDER

Designed to hold the crevice tool and dusting brush.

For quick access to tools when vacuuming and

cleaning around the house. (Fig. 4)

EXTENSION WAND

Reach even further and attach the crevice tool, the

dusting brush or the power brush for cleaning all

around the house. (Fig. 5)

Fig. 1

Fig. 4

Fig. 2

Fig. 3

a

e

c

d

b

g

Getting Started

Fig. 5

i

7

www.sharkclean.com

Your new Shark Navigator® Lift-Away® Deluxe vacuum cleaner can easily be configured into

different cleaning modes to meet all your cleaning needs: upright vacuum and portable Lift-

Away® - both with constant suction power.

MODES:

1 UPRIGHT VAC

Upright vacuuming - floors and carpets. (Fig. 6)

Fig. 6

Fig. 7

2 PORTABLE LIFT-AWAY®

Take the Lift-Away® with you around the house to

clean hard to reach places. (Fig. 7)

8

TOLL FREE: 1-800-798-7398

To reduce the risk of electric shock, unplug the unit before assembling, adding or removing attachments or

converting modes.

WARNING: The On/Off switch is on the top of the Lift-Away® canister. Always ensure the power is OFF

(“O” position) before plugging and unplugging.

TO ASSEMBLE:

1 Place the floor nozzle on a level surface.

2 Align the tube of the floor nozzle with the tube on

the Lift-Away® canister and lower until you hear

the two pieces click into place. (Fig. 8)

When attaching the motorized floor brush, ensure

that the latching mechanism is fully locked in place

to ensure electrical connection has been made.

3 Attach the end of the extension wand to the tube

on the back of the Lift-Away® canister until it

clicks into place. (Fig. 9)

4 Slide the accessory holder (a) positioned opposite

the upper cord wrap, over the extension wand.

Align the tab with the groove and push down.

(Fig. 10)

5 Push the handle (b) onto the top of the extension

wand until you hear it click into place. (Fig. 10)

6 Insert the end of the stretch hose (c) into the

connector on the back of the Lift-Away® canister.

(Fig. 10)

7 Store the dusting brush (d) and the crevice tool (e)

on the mounts of the accessory holder. (Fig. 10)

Fig. 8 Fig. 9

Fig. 10

Mode 1: Upright Vac

c

Upper Cord

Storage Wrap

a

d

e

b

9

www.sharkclean.com

TO USE:

1 Rotate the cord release to quickly release the

power cord.

2 Secure the power cord in the cord hook.

= Brush Roll ON

= Bare Floor

= OFF

3 Press the On/Off switch (a) to the “I” position to

vacuum bare floors (straight suction only) or to the

“II” position to engage the motorized floor brush

(for vacuuming carpets and rugs). (Fig. 11)

IMPORTANT: The motorized brush indicator light

(b) will illuminate green when motorized floor

brush is on, or red if there is a blockage or jam.

(Fig. 11) This feature is designed to protect your

Lifetime Belt that powers your motorized floor

brush. See Checking for Blockages on page 15.

4 Gently press the floor nozzle down with your foot

while you grasp the handle and tilt it back towards

you. (Fig. 12)

NOTE: The rotating brush on the motorized

floor brush will not spin unless the nozzle is flat

against the floor and the handle is tilted back.

5 Due to the huge suction power of this

vacuum, it may become necessary at

times to adjust the suction release (c) on

the handle. (Fig. 11) If the vacuum seems

difficult to push or pull or if it is lifting

up area rugs, adjust the suction release

by rotating the collar 90° counterclockwise

to open the valve. Rotate the collar

clockwise to close the valve when you need

high suction and for vacuuming floors.

6 Empty dust cup after vacuuming and periodically

during use when it appears full. (See

“Maintenance” section for instructions.)

7 When you are finished vacuuming, turn the

vacuum off.

Fig. 12

Fig. 11

Release suction

for easier push &

pull on high pile

carpets and

area rugs.

b

a

Suction

Release Collar

c

10

TOLL FREE: 1-800-798-7398

a

You can carry your vacuum cleaner

in both modes by the carry handle

located on top of the dust cup.

Fig. 15

Fig. 14

Fig. 13

Mode 2: Portable Lift-Away®

b

a

PORTABLE LIFT-AWAY®

1 Separate the portable Lift-Away® canister from

the floor nozzle by pressing the red release

button (a) on the side of the canister. Gently

hold the nozzle to the floor with your foot and

pull the canister up. (Fig. 13)

2 Press the handle release button (a) and pull the

handle up or press the extension wand release

button (b) and pull the extension wand up.

(Fig. 14)

3 Attach desired accessory onto the end of either

the extension wand or the handle.

4 Press the On/Off switch to the “I” position to

turn the vacuum on for above-floor cleaning and

hold the handle in one hand while you carry the

portable Lift-Away® around the house with the

other hand. (Fig. 15)

11

www.sharkclean.com

Fig. 16

Suction

Release Collar

a

Above-Floor Cleaning

CLEAN ABOVE THE FLOOR IN UPRIGHT VAC OR

PORTABLE LIFT-AWAY® MODE

1 Press the handle release button and pull the

handle up or press the extension wand release

button and pull the extension wand up.

2 Attach desired accessory onto the end of either the

extension wand or the handle. (Fig. 16)

3 Your vacuum has tremendous suction

power. Adjust the amount of suction with

the suction release on the handle. Open

the valve (a) by rotating the collar 90˚

counterclockwise for low suction when

doing light jobs such as drapes or fine

surfaces. Close the valve (a) by rotating the

collar clockwise 90˚ for high suction and

when using the hand held power brush.

(Fig. 16)

4 Press the On/Off switch to the “I” position to turn

the vacuum on for above-floor cleaning.

IMPORTANT: Ensure vacuum is in upright

position. Do not use position “II” when cleaning

above the floor in the upright vac mode as this

will engage the motorized floor brush. The

rotating brush may damage your floor if run for a

prolonged period of time in one area.

Release suction when

dusting delicate objects,

furniture or draperies.

12

TOLL FREE: 1-800-798-7398

Fig. 17

Quick

Cord Release

Lower Cord

Storage Clip

Storage and Maintenance

STORE YOUR VACUUM SAFELY

1 Convert your vacuum back to upright vac mode.

2 Rotate the upper quick cord release to its upright

position and coil the power cord loosely around

the two clips. Clip the plug onto the cord to secure.

(Fig. 17)

3 Store the dusting brush and the crevice tool on the

mounts on the accessory holder.

4 Store your vacuum cleaner safely in a cool dry area

where it will not be a hazard, will not get damaged

and will not cause damage to anyone or anything.

NOTE: Empty dust cup after cleaning and prior

to storing. (See “Maintenance” section for

instructions.)

To reduce the risk of electric shock, unplug the unit

before performing any cleaning, maintenance, or

troubleshooting checks.

Reassemble all parts securely before operating

vacuum.

DO NOT operate the vacuum without the filters

and dust cup in place.

DO NOT operate the vacuum with WET filters.

IMPORTANT: Make sure all filters are completely

dry before inserting back into vacuum.

WARNING: Never insert sharp objects into any

opening to clear an obstruction.

IMPORTANT: Damages caused while clearing

or attempting to clear blockages are not covered

under your product’s limited warranty.

13

www.sharkclean.com

IMPORTANT: Loss of Suction may

occur if foam filters are not cleaned

every 3 months. Rinse and allow to

air dry completely. Also, tap loose dirt

off filter between washes as needed.

Foam filters may appear dirty after

use - this is normal.

Fig. 18 Fig. 19

COMPONENT

MAINTENANCE SCHEDULE

Rinse and air dry every 3 months under normal use.

Empty each time you vacuum.

Pre-Motor Foam Filter

Dust Cup

Rinse and air dry every 3 months under normal use.

Pre-Motor Felt Filter

Clean once every 2 years or as needed.

Post-Motor HEPA Filter

1

2

3

4

CLEANING THE PRE-MOTOR FILTERS

1 Remove the dust cup.

2 Pull the 2 filters out from the top of the motor

base. (Fig. 21)

3 Rinse the filters thoroughly in lukewarm water until

the water runs clear.

DO NOT put the filter in the washing machine or

dishwasher.

NOTE: The material in the filter will discolor over

time. This is NORMAL and will not affect the

performance of the filter.

4 Squeeze out excess water and let air-dry for at

least 24 hours before replacing. Do not use a hair

dryer or other heating methods to dry.

5 Place the felt filter in first, then the foam filter.

6 Replace the dust cup.

EMPTYING THE DUST CUP

The dust cup needs to be emptied each time you

vacuum and periodically during cleaning, when the

dust cup appears full.

1 Undo the latches on the sides of the dust cup by

lifting them up and outwards to remove the dust

cup from the motor base. (Fig. 18)

2 Hold the dust cup over a trash receptacle and

press the bottom door release button. (Fig. 19)

Tap gently to empty contents. Press the door shut

again until it clicks.

3 If needed, turn the dust cup upside down over the

trash receptacle and press the top door release

button. (Fig. 20) Tap gently to remove contents.

Use a dry cloth or paper towel to remove debris

stuck to the screen filter inside the dust cup. Press

the door shut again until it clicks.

4 Replace the dust cup on top of the motor base.

Hook the two latches onto the tabs on the sides of

the dust cup and push down to lock.

Screen

Filter

Fig. 20

Fig. 21

Pre-Motor

Foam Filter

Felt Filter

Post Motor

HEPA Filter

Maintenance

14

TOLL FREE: 1-800-798-7398

CLEANING THE POWER BRUSH

1 Slide the locking latch (a) forward and gently tilt

brush housing upward to remove. (Fig. 25)

2 Carefully remove any blockage or debris and

cut away any build-up of hair or string wrapped

around the rotating bristle brush with scissor.

3 To reassemble, insert the tabs on the front edge

of the bottom cover into the matching holes in the

top half and tilt it back down until it clicks into

place. (Fig. 26)

Fig. 23

Fig. 22

Fig. 24

CLEANING THE POST-MOTOR HEPA FILTER

1 Remove the filter cover from the front of the

vacuum by pulling up on the tab and pulling the

cover away from the vacuum. (Fig. 22)

2 Take out the HEPA filter by pulling it straight out.

3 Turn the filter over so that the dirty side is on

the bottom and vigorously tap it clean against a

garbage can to remove any dust. (Fig. 23)

4 Wash the filter under the tap using lukewarm

water with the dirty side face down until the water

runs clear. (Fig. 24)

DO NOT put the filter in the washing machine or

dishwasher.

NOTE: The material in the filter will discolor over

time. This is NORMAL and will not affect the

performance of the filter.

5 Allow the filter to air dry for 24 hours. Do not use a

hair dryer or other heating methods to dry.

6 Once the HEPA filter is dry, replace it back into the

vacuum.

7 Replace the cover by inserting the two tabs into

the holes at the top and then swinging the cover

down until it clicks into place.

Fig. 26

Fig. 25

CLEANING THE MOTORIZED FLOOR BRUSH

When your motorized floor brush needs cleaning or

locks onto an object, it automatically shuts down to

prevent damage to your lifetime belt. The indicator

light will illuminate red warning you to turn off the

vacuum and clear blockage immediately. The light will

reset itself once blockage has been cleared and power

has been cycled on/off or vacuum has been locked in

the upright position.

1 Detach the motorized floor brush from the portable

Lift-Away® canister.

2 Inspect the opening underneath and the rotating

brush. If a build-up of debris is present, remove it.

Carefully cut anything wound around the rotating

brush with scissors. Avoid damaging or cutting the

bristles. (Fig. 27)

Maintenance - cont’d

Rotating

Brush

Fig. 27

a

15

www.sharkclean.com

CHECKING FOR BLOCKAGES

Blockages may cause your vacuum to overheat and

shut down. To prevent this from happening, check

potential blockage areas after heavy use or if you

detect a loss of suction or poor cleaning performance.

1 Dust Cup

Dust cup may be full. Empty dust cup.

2 Pre-Motor & Post-Motor Filters

 • Pre-motorltersrequirewashingevery3

months for optimum performance.

The post-motor HEPA filter needs to be washed

every 2 years.

 • Ensurethatalltheltersareclean.

3 Accessories

 • Checkintakeopenings:

- Extension Wands

- Dusting Brush

- Crevice Tool

- Power Brush

4 Hose and Connections to Vacuum

 • Detachthestretchhosefromthebackofthe

portable Lift-Away® canister by squeezing

the tabs together and pulling up. (Fig. 28)

Straighten out the hose and look inside for

blockages.

 • Removethedustcupandextensionwandand

separate the portable Lift-Away® canister

from the motorized floor brush. Look in all 4

openings for any blockages. (Fig. 29)

5 Motorized Floor Brush

(Side suction models)

 • Detachthehoseonthemotorizedoorbrush

at the top by squeezing the tabs together and

pulling out, and at the bottom by pulling out

the connector. Inspect inside the 3 holes.

(Fig. 30)

Make sure you are working in a well

lit area and use a flashlight to help

search for blockages.

Fig. 30

Fig. 29

Fig. 28

16

TOLL FREE: 1-800-798-7398

PROBLEM POSSIBLE REASONS & SOLUTIONS

Vacuum is not

picking up dirt.

Check filters to see if they need cleaning. Follow instructions for rinsing

and drying the filters before re-inserting back into the vacuum. (See

“Maintenance” sections for instructions.)

Dust cup may be full; empty dust cup.

Check hose and hose connections for blockages; clear blockages if required.

If dust cup is empty, and attachment inlets are clear, check for other

blockages. (See “Checking for Blockages” for instructions.)

Vacuum lifts scatter rugs

(lightweight, movable

rugs).

Suction is powerful. Take care when vacuuming scatter-type rugs or rugs with

delicately sewn edges. Open the suction release on the handle to decrease

suction power.

Move the On/Off switch to “I - Suction Only” position to disengage the

brush roll

Airflow is restricted. No

suction or light suction.

Check filters to see if they need cleaning. Follow instructions for rinsing and

drying the filters before re-inserting back into the vacuum.

Dust cup may be full; empty dust cup.

Check hose, hose connections, nozzles and accessories for blockages; clear

blockages if required.

Close the suction release on the handle to increase suction power.

If dust cup is empty, and attachment inlets are clear, check for other

blockages.

Brush roll does not spin

Immediately turn off and unplug vacuum, disconnect the nozzle and remove

blockage before reconnecting and turning vacuum back on.

Pull the handle toward you and release the floor nozzle to disengage the

auto-off feature.

Move the On/Off switch to the “II - Brush Roll On” position.

Vacuum turns off

on its own.

This vacuum cleaner is equipped with a motor protective thermostat. If for

some reason your vacuum overheats, the thermostat will automatically turn

the unit off. Should this occur, perform the following steps to restart the

motor thermostat:

1. Move the On/Off switch to the “O” (Off) position.

2. Unplug the vacuum.

3. Empty the dust cup and clean filters.

4. Check for blockages in hose, accessories and inlet openings.

5. Allow the unit to cool for a minimum of 45 minutes.

6. Plug in the vacuum.

7. Turn the On/Off switch to the “I” (On) position to restart the vacuum.

Note: If vacuum still does not start, contact Customer Service at:

1-800-798-7398.

Troubleshooting Guide

17

www.sharkclean.com

PART PART NO.

1 Pre-Motor Filter Set XFF350

2 HEPA Filter XHF350

3 Dusting Brush & Crevice Tool 112FFJ

4 Power Brush 119FFJ

5 Extension Wand 1116FC

4

3

1

2

5

Ordering Parts

To purchase replacement parts, please visit our website: www.sharkclean.com

or contact customer service: 1-800-798-7398.

18

TOLL FREE: 1-800-798-7398

Notes

19

www.sharkclean.com

EURO-PRO FIVE-YEAR (5) LIMITED WARRANTY

EURO-PRO Operating LLC warrants this product to be free from material defects and workmanship for a period of

five (5) years from the date of purchase when utilized for normal household use, subject to the following conditions,

exclusions and exceptions.

The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at

our option. This Limited Warranty does not cover normal wear of parts and does not apply to any unit that has been

tampered with or used for commercial purposes. This Limited Warranty does not cover damage caused by misuse,

abuse, negligent handling or damage due to faulty packaging or mishandling in transit. This Limited Warranty does

not cover damage or defects caused by or resulting from damages from shipping or repairs, service or alteration

to the product or any of its parts, which have been performed by a repair person not authorized by EURO-PRO

Operating LLC.

If your appliance fails to operate properly while in use under normal household conditions within the warranty

period, you may return the complete appliance and accessories with proof of purchase and date, freight prepaid. For

customer service support, call 1-800-798-7398 or visit our website at www.sharkclean.com.

If the appliance is found by EURO-PRO Operating LLC to be defective, in EURO-PRO Operating LLC’s sole

discretion, we will repair or replace it free of charge. Proof of purchase date and a check made payable to EURO-

PRO Operating LLC in the amount of $19.95 to cover the cost of return shipping and handling must be included.*

Non-durable parts including, without limitation, filters, brushes and electrical parts which normally require

replacement are specifically excluded from warranty.

This Limited Warranty is extended to the original purchaser of the unit and excludes all other legal, implied and/or

conventional warranties. The responsibility of EURO-PRO Operating LLC if any, is limited to the specific obligations

expressly assumed by it under the terms of this Limited Warranty. In no event is EURO-PRO Operating LLC liable

for incidental or consequential damages to anyone of any nature whatsoever. Some states do not permit the exclusion

or limitation of incidental or consequential damages, so the above may not apply to you.

This Limited Warranty gives you specific legal rights, and you may also have other rights which vary from state to state

or province to province.

*IMPORTANT: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase

date and to attach a tag to item before packing including your name, complete address and phone

number with a note giving purchase information, model number and what you believe is the problem

with the item. We recommend you insure the package (as damage in shipping is not covered by your

warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”. We are constantly

striving to improve our products, therefore the specifications contained herein are subject to change

without notice.

Product Registration

Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark® product within ten (10)

days of purchase. You will be asked to provide the store name, date of purchase and model number along with your

name and address.

The registration will enable us to contact you in the unlikely event of a product safety notification. By registering

you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying

instructions.

EURO-PRO Operating LLC

U.S.: Newton, MA 02459

Canada: Ville St. Laurent, Québec H4S 1A7

1-800-798-7398

www.sharkclean.com

Copyright © Euro-Pro Operating LLC 2013

Printed in China

Illustrations may differ from actual product.

Euro-Pro, Shark, and Navigator are trademarks of Euro-Pro Operating LLC. All other

brand names may be trademarks of their respective owners.

UV440.26.E.130419.1
