SC3901W

OWNER’S GUIDE

PRO PORTABLE

STEAM POCKET®

WWW.SHARKCLEAN.COM

TOLL FREE: 1-800-798-7398

WHEN USING YOUR SHARK®

Portable Steam Pocket®,

BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE

FOLLOWED, INCLUDING THE

FOLLOWING:

WARNING:

TO

REDUCE THE RISK OF FIRE,

ELECTRIC SHOCK OR INJURY

READ ALL INSTRUCTIONS

BEFORE USING YOUR

PORTABLE STEAM POCKET®.

DANGER OF SCALDING.

Please use caution when using

the Portable Steam Pocket®.

The steam emitted from the

Portable Steam Pocket® is very

hot.

POLARIZED PLUG:

This appliance has a polarized

plug (one blade is wider than

the other). As a safety feature,

this plug will fit into a polarized

outlet only one way. If the

plug does not fit fully into the

outlet, reverse the plug. If it still

does not fit, contact a qualified

electrician. Do not attempt to

defeat this safety feature.

1. Use the system only for its

intended use.

2. DO NOT use outdoors.

3. DO NOT leave the appliance

unattended when plugged in.

Always unplug the power cord

from the electrical outlet when not

in use and before servicing.

4. DO NOT allow the appliance to be

used by children. Close attention

is necessary when used by or near

children, pets or plants.

5. Use only as described in this

manual.

6. Use only manufacturer’s

recommended accessories.

7. DO NOT use with damaged

cord or plug. If appliance is not

working as it should, has been

dropped, damaged, left outdoors,

or dropped into water. Return the

appliance to EURO-PRO Operating

LLC for examination and repair.

Incorrect re-assembly or repair

can cause a risk of electrical shock

or injury to persons when the

appliance is used.

8. To protect against a risk of electric

shock, DO NOT immerse the

Portable Steam Pocket® into water

or any other liquids.

9. DO NOT handle plug or Portable

Steam Pocket® with wet hands or

operate appliance without shoes.

10. DO NOT pull or carry by cord, use

cord as a handle, close a door on

cord, or pull cord around sharp

edges or corners. Do not run

appliance over cord. Keep cord

away from heated surfaces.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

For Household Use Only

TOLL FREE: 1-800-798-7398

English

www.sharkclean.com

11. DO NOT unplug by pulling on

power cord. To unplug, grasp the

plug not the power cord. Do not

use extension cords or outlets

with inadequate current carrying

capacity.

12. DO NOT put any objects into

openings. Do not use with any

opening that is blocked.

13. DO NOT put hands or feet under

the Portable Steam Pocket®. Unit

gets very hot.

14. In mop mode use ONLY on flat,

horizontal surfaces. Do not use on

walls, counters or windows.

15. DO NOT use on leather, wax

polished furniture or floors,

synthetic fabrics, velvet or other

delicate, steam sensitive materials.

16. DO NOT add cleaning solutions,

scented perfumes, oils or any other

chemicals to the water used in this

appliance as this may damage the

unit or make it unsafe for use. If

you live in a hard water area, we

recommend using distilled water in

your Portable Steam Pocket®.

17. When in use, NEVER turn the

appliance over or on its side.

NEVER DIRECT STEAM TOWARDS

PEOPLE, ANIMALS OR PLANTS.

18. NEVER LEAVE THE PORTABLE

STEAM POCKET® IN ONE SPOT ON

ANY SURFACE FOR ANY PERIOD

OF TIME WHEN MICRO-FIBER

PAD IS ATTACHED AS THIS WILL

DAMAGE YOUR FLOORS.

19. Carefully remove the micro-fiber

cleaning pad immediately after you

have unplugged and allowed the

Portable Steam Pocket® to cool.

20. When cleaning the Portable Steam

Pocket®, unplug the power cord

from the electrical outlet and clean

with a dry or damp cloth. Do not

pour water or use alcohol, benzene

or paint thinner on the unit.

21. Extreme caution should be

exercised when using this

appliance to clean stairs.

22. Never use Portable Steam Pocket®

without micro-fiber cleaning

pad attached.

23. Keep your work area well lit.

24. Store Portable Steam Pocket®

indoors in a cool, dry place.

25. To avoid circuit overload, do not

operate another appliance on the

same socket (circuit) as the steam

cleaner.

26. If an extension cord is absolutely

necessary, an extension cord rated

a minimum of 15 ampere, 14 gage

cord should be used. Cords rated

for less amperage may overheat.

Care should be taken to arrange

cord so that it cannot be pulled or

tripped over.

27 Always unplug and allow the

Portable Steam Pocket® to cool

before removing or changing mop

heads.

WARNING: Your Portable Steam

Pocket® is designed to clean hard

floor surfaces that will withstand

high heat. Do not use on unsealed

wood or unglazed ceramic floors.

On surfaces that have been treated

with wax or some no wax floors,

the sheen may be removed by the

heat and steam action. It is always

recommended to test an isolated

area of the surface to be cleaned

before proceeding. We also

recommend that you check the use

and care instructions from the floor

manufacturer.

TOLL FREE: 1-800-798-7398

This manual covers model number: SC3901W 11

TECHNICAL SPECIFICATIONS

Voltage: 120V., 60Hz.

Power: 1550 Watts

Water Capacity: 300ml (10.14 oz.)

TOLL FREE: 1-800-798-7398

1

English

www.sharkclean.com

Contents

Getting Started ......................................................................2

Using Your Portable Steam Pocket® ..............................4

Care of Your Portable Steam Pocket® ...........................7

Troubleshooting Guide .......................................................8

Warranty ...................................................................................9

Notes ..........................................................................................10

Thank you for

purchasing

the Shark®

Pro Portable

Steam Pocket®.

2TOLL FREE: 1-800-798-7398

When assembling your Portable Steam

Pocket® there may be a little water in or

around the water tank. This is because

we test all our Portable Steam Pocket®s

100% before you buy them, so you get

a quality Shark® Pro Portable Steam

Pocket®.

f Attachment Release Button

g Steam Trigger

h Portable Steam Pocket® Handle

i Water Tank Cap (not shown)

j Power Light

k Water Tank

a Portable Portable Steam Pocket®

b Direct Steam Nozzle

c Flat Scrubber Tool

d All Purpose Scrubbing Pad

e Accessory Hose

Getting Started

a

c

bf

d

e

g

h

i

k

j

TOLL FREE: 1-800-798-7398

3

English

www.sharkclean.com

Getting Started with Your Portable Steam Pocket®

1 Turn the water tank cap counter

clockwise and remove from the tank.

(fig. 1)

Use the filling flask and pour water

into the tank. Do not overfill. Replace

the cap on the water tank.

(fig. 2)

IMPORTANT: Your Portable Steam

Pocket® needs water to make steam!

Never use your Portable Steam

Pocket® without water in the tank.

2 Plug into a 120-volt electrical outlet.

The Power Light will flash blue. If the

light does not turn on, reference the

troubleshooting section on page 14.

(fig. 3)

NOTE: To prolong the life of your

Portable Steam Pocket®, we

recommend using distilled water.

Your Shark® Pro Portable

Steam Pocket® is designed to clean

surfaces that will withstand high heat

and moisture. Do not use on unsealed

wood surfaces (especially wooden

antique furniture), unglazed ceramic

tile, painted surfaces or surfaces that

have been treated with wax, oils,

varnishes, or shellac. The sheen may be

removed by the heat, steam, and friction

of the cleaning tools. Lacquer and

polyurethane coatings provide a hard

durable protective finish that withstands

moisture, but it is always recommended

to test an isolated area of the surface to

be cleaned before proceeding.

We also recommend you check the use

and care instructions from the surface

manufacturer.

When cleaning finished wood surfaces,

use broad, continuous cleaning strokes.

To prevent surface damage, avoid

focusing steam or allowing the cleaning

tools to sit in one spot for any amount

of time.

fig. 1

fig. 2

fig. 3

4TOLL FREE: 1-800-798-7398

Cleaning Tip: The Direct Steam Nozzle creates direct steam spray to clean

and sanitize hard to reach nooks & crannies and other places where germs

may build up. Use the Direct Steam nozzle to loosen and dislodge compact

dirt often found in corners and tight places where traditional methods and

cleaning tools tend to push dirt into, making it tough to reach and clean.

Spray direct steam and wipe clean with a wet cloth or paper towel.

Using Your Portable Steam Pocket®

with Direct Steam Nozzle

CAUTION: Do not press steam

trigger until the Direct Steam Nozzle

is snapped into the main nozzle of

your Portable Steam Pocket®.

3 To remove the Direct Steam Nozzle

attachment, press and hold down the

release buttons. Then slide off of the

handheld steamer.

CAUTION: Do not press steam

trigger while removing the Direct

Steam Nozzle. Avoid touching the tip

of the Direct Steam Nozzle, as this

will be very hot after steaming.

NOTE: The Portable Steam Pocket®

may continue to emit steam for a few

seconds after the trigger is released.

This is normal, and the steaming will

eventually come to a stop.

1 For spot cleaning and steaming, first

attach the Direct Steam Nozzle by

pressing the nozzle onto the Portable

Steam Pocket® until it clicks

into place. (fig. 4)

2 Then press and hold the steam

trigger button to start steaming.

While the steam trigger button is

pressed and held down, the

Power Light will be solid blue. When

released, the Power Light will return

to flashing blue. (fig. 5).

For effective cleaning, hold the

steam output nozzle 1-2 inches away

from the surface you’re cleaning.

fig. 4

fig. 5

TOLL FREE: 1-800-798-7398

5

English

www.sharkclean.com

Using Your Portable Steam Pocket®

with Accessory Hose

CAUTION: Do not press steam

trigger while attaching or removing

the Accessory Hose.

CAUTION: Do not use the

Accessory Hose without cleaning

tool attached.

1 Attach the Accessory Hose to the

Portable Steam Pocket® by snapping

the Accessory Hose into the main

nozzle.(fig. 6)

2 Select the desired cleaning tool

for use. Follow the cleaning tool

sub-assembly instructions for the

selected tool.

3 To remove the hose, press and hold

down the attachment release button.

Then the Accessory Hose. (fig. 7)

fig. 6

fig. 7

6TOLL FREE: 1-800-798-7398

Using Your Portable Steam Pocket®

with Flat Scrubber

4 To remove the Flat Scrubber Tool,

press and hold down the release

button. Then slide the Flat Scrubber

off of the hose.

CAUTION: Do not press steam

trigger while attaching or removing

the Flat Scrubber Tool.

CAUTION: Do not use the Flat

Scrubber without All-purpose

cleaning pad attached.

Cleaning Tip: The Flat Scrubber is designed for cleaning a variety of surfaces and is

exceptional on those that are large and flat including counter tops, table tops, walls

mirrors, windows, stairs, shelves and other similar surfaces. Super absorbent micro-

fiber loosens, lifts, and locks in dirt and grime while sanitizing at the same time.

1 To attach the All-Purpose Scrubber

pad, pull the pad gently over the Flat

Scrubber frame until the pad fits

snugly.

2 Press the Flat Scrubber Tool onto the

Accessory hose until it clicks into place.

(fig. 8)

3 Press and hold the steam trigger

to create steam. While the steam

trigger button is pressed and held

down, the Power Light will be solid

blue. When released, the Power Light

will return to flashing blue. (fig. 9).

fig. 8

fig. 9

TOLL FREE: 1-800-798-7398

7

English

www.sharkclean.com

AFTER USE AND STORAGE

1 If you are also done cleaning, unplug

the cord from the outlet and place the

Handheld Scrubber on a flat surface.

Let the unit cool for 2-3 minutes.

2 Empty the water tank before

storage. Remove the water tank cap

and empty the tank over a sink.

Replace the water cap. (fig. 10)

Care of Your Portable Steam Pocket®

fig. 10

CARE OF YOUR MICRO-FIBER

CLEANING PAD

1 We recommend washing your

micro-fiber cleaning pad separately

from other fabrics to avoid picking

up lint. Only use liquid detergent

(no powder detergent). Don’t use

any fabric softeners or bleach. Line

dry or dry on a low dryer setting.

(fig. 11)

2 If there are loose threads on the

micro-fiber cleaning pad carefully

cut the thread with scissors. Don’t

pull on them or cut at the base.

IMPORTANT: The micro-fiber

cleaning pad may be very hot

from the steam. Use caution when

removing. Let the unit cool for 2-3

minutes.

CLEANING THE NOZZLE

1 Your Portable Steam Pocket® should

not normally require cleaning,

however, should you notice a

decrease in the steam output, it may

be necessary to remove mineral

deposits built up around the nozzles.

2 Unplug the cleaner from the

electrical outlet.

3 Use the provided nozzle cleaner or a

small diameter stiff metal wire, such

as a straightened metal paperclip,

and carefully insert the end of the

wire into the nozzle orifice. See

illustration above. (fig. 12)

4 Move the wire back and forth several

times to remove any deposits.

5 Plug in the appliance to the power

outlet and test steam output.

fig.12

fig.11

8TOLL FREE: 1-800-798-7398

Troubleshooting Guide

PROBLEM POSSIBLE REASONS & SOLUTIONS

The Shark® Pro

Portable Steam

Pocket® will not turn-

on.

Your Portable Steam Pocket® should be securely plugged into a

120V AC electrical outlet only.

Check your fuse or breaker.

If your unit still does not work, call 1-800-798-7398.

The unit will not

make steam.

Is there water in the water tank? If not, add water to your

Portable Steam Pocket® following instructions on page 4.

If the unit still does not make steam, follow the instructions on

page 13 to clean the nozzle.

The Shark® Pro

Portable Steam

Pocket® leaves water

on surfaces.

Check to see if your micro-fiber cleaning pad is too wet. We

recommend you unplug the Portable Steam Pocket® and

change the micro-fiber cleaning pad.

Make sure the micro-fiber cleaning pad is attached correctly.

The Shark® Pro

Portable Steam

Pocket® left a white

spot on the surface.

Do not leave your Portable Steam Pocket® on the floor with a

damp or wet cleaning pad.

If you’re using tap water, we recommend switching to

distilled water.

Make sure the cap is securely on the water tank.

Surfaces are cloudy,

streaky or spotty

after steaming.

The micro-fiber cleaning pad might be dirty. Flip or change the

cleaning pad.

If you washed the cleaning pad with powder detergent, then it

might be ruined. Replacement pads are available at

sharkclean.com.

This could also be an indication of prior soap or grease residue

that has accumulated on the surfaces. As our Portable Steam

Pockets use only a small amount of water, it may not be wet

enough to rinse off the accumulation that the steam is bringing

to the surface. We suggest rinsing the floor with nothing but

water, letting it dry, and then steaming again with a clean pad.

One or more rinses generally removes the residue.

A more stubborn case may require you to rinse the floor with a

mix of one part vinegar and two parts water.

TOLL FREE: 1-800-798-7398

9

English

www.sharkclean.com

SC3901W 11

ONE (1) YEAR LIMITED WARRANTY

EURO-PRO Operating LLC warrants this product to be free from defects in material and

workmanship for a period of one (1) year from the date of the original purchase, when utilized for

normal household use, subject to the following conditions, exclusions and exceptions.

If your appliance fails to operate properly while in use under normal household conditions

within the warranty period, return the complete appliance and accessories, freight prepaid. For

Customer Service support, call 1 (800) 798-7398 or visit our website www.sharkclean.com.

If the appliance is found to be defective in material or workmanship, EURO-PRO Operating LLC

will repair or replace it free of charge. Proof of purchase date and $ 14.95 to cover the cost of

return shipping and handling must be included. *

The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or

replacement of the unit at our option. This warranty does not cover normal wear of parts and

does not apply to any unit that has been tampered with or used for commercial purposes. This

limited warranty does not cover damage caused by misuse, abuse, negligent handling or damage

due to faulty packaging or mishandling in transit. This warranty does not cover damage or

defects caused by or resulting from damages from shipping or repairs, service or alterations to

the product or any of its parts, which have been performed by a repair person not authorized by

EURO-PRO Operating LLC.

This warranty is extended to the original purchaser of the unit and excludes all other legal and/

or conventional warranties. The responsibility of EURO-PRO Operating LLC warranty if any,

is limited to the specific obligations expressly assumed by it under the terms of the limited

warranty. In no event is EURO-PRO Operating LLC liable for incidental or consequential

damages of any nature whatsoever. Some states/provinces do not permit the exclusion or

limitation of incidental or consequential damages, so the above may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights which vary from

state to state or province to province.

*Important: Carefully pack item to avoid damage in shipping. Be sure to include proof of

purchase date and to attach tag to item before packing with your name, complete address and

phone number with a note giving purchase information, model number and what you believe

is the problem with the item. We recommend you insure the package (as damage in shipping

is not covered by your warranty). Mark the outside of your package “ATTENTION CUSTOMER

SERVICE”. We are constantly striving to improve our products, therefore the specifications

contained herein are subject to change without notice.

OWNERSHIP REGISTRATION CARD FOR

CANADIAN CONSUMERS ONLY

Please complete and return within ten (10) days of purchase. The registration will enable

us to contact you in the event a product defect is discovered. By returning this card you

acknowledge to have read and understood the instructions for use, and warnings set

forth in the accompanying instructions.

RETURN TO: EURO-PRO Operating LLC, 4400 Bois Franc, St. Laurent, Quebec H4S 1A7

PURCHASER: ……………………………………………………………………………………............................………............

ADDRESS: ………………………………………………………………………………………………...........................................

DATE OF PURCHASE: ………………….........….. MODEL: ……………….....................................................

NAME AND ADDRESS OF STORE: …………………………………...........................………………………………..

10 TOLL FREE: 1-800-798-7398

Notes

TOLL FREE: 1-800-798-7398

11

English

www.sharkclean.com

Notes

U.S.: EURO-PRO Operating LLC

Newton, MA 02459

Canada: EURO-PRO Operating LLC

4400 Bois Franc

Ville St. Laurent, Québec H4S 1A7

1-800-798-7398

www.sharkclean.com

COPYRIGHT© EURO -PRO OPERATING LLC 2011

PRINTED IN CHINA

SC 3901W.E.110225

Illustrations may dif fer from actual product.
