Sharp DMR0142 Household Microwave Oven User Manual R 55TSgennkou
Sharp Corporation Household Microwave Oven R 55TSgennkou
Sharp >
User Manual
![](/img.php?id=304774&img=bg1.png)
®
®
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING
CONTENTS
• Precautions to Avoid Possible
Exposure to Excessive Microwave
Energy................................ Inside Front Cover
•For Customer Assistance... Inside Front Cover
•Consumer Limited Warranty ................... 1
•Product Information Card ........................ 1
•Important Safety Instructions .................. 2
• Unpacking and Installation Instructions... 3
•Grounding Instructions ............................ 3
•Information You Need to Know ............... 4-7
•Part Names ............................................. 8-9
•Before Operating..................................... 10
•Manual Operation.................................... 10-12
•Special Features ..................................... 12-15
Automatic Cooking................................ 12
Instant Action ........................................ 16
Express Defrost .................................... 18
Manual Defrost ..................................... 19
•Other Convenient Features..................... 20-21
•Cleaning and Care .................................. 22
•Service Call Check.................................. 23
• Specifications .......................................... 24
TOASTER OVEN
WITH MICROWAVE
OPERATION MANUAL
MODELMODEL
MODELMODEL
MODEL
R-55TS
** DRAFT **
![](/img.php?id=304774&img=bg2.png)
TO PHONE:
DIAL 1-800- BE-SHARP ( 237-4277 ) for :
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your authorized parts distributor)
ADDITIONAL CUSTOMER INFORMATION
DIAL 1-800-642-2122 for :
ACCESSORIES
TO WRITE:
Sharp Electronics Corporation
Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
TO ACCESS INTERNET:
www.sharpusa.com
To aid in reporting this toaster oven with microwave in case of loss or theft, please record below the model number
and serial number located on the unit. We also suggest you record all the information listed and retain for future
reference.
Please provide the following information when you write or call: model number, serial number, date of purchase, your com-
plete mailing address (including zip code), your daytime telephone number (including area code) and description of the prob-
lem.
MODEL NUMBER________________ SERIAL NUMBER______
DATE OF PURCHASE ____________
DEALER ________________________ TELEPHONE __________
SERVICER ______________________ TELEPHONE __________
PRECAUTIONS TO AVOID POSSIBLEPRECAUTIONS TO AVOID POSSIBLE
PRECAUTIONS TO AVOID POSSIBLEPRECAUTIONS TO AVOID POSSIBLE
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVEEXPOSURE TO EXCESSIVE
EXPOSURE TO EXCESSIVEEXPOSURE TO EXCESSIVE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGYMICROWAVE ENERGY
MICROWAVE ENERGYMICROWAVE ENERGY
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper with
the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c)Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken
or loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
FOR CUSTOMER ASSISTANCE
![](/img.php?id=304774&img=bg3.png)
1
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand
product (the “Product”), when shipped in its original container, will be free from defective workmanship and
materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part
thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the
period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s)
set forth below nor to any Product the exterior of which has been damaged or defaced, which has been
subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or
modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth
below and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted
to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE
OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other
than those described herein, or to extend the duration of any warranties beyond the time period described
herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall
be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for
the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities
of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims,
whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any
way responsible, for any damages or defects in the Product which were caused by repairs or attempted
repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way
responsible for any incidental or consequential economic or property damage. Some states do not allow the
exclusion of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
Your Product Model Number
& Description:
Warranty Period for this Product:
Additional Item(s) Excluded from
Warranty Coverage (if any):
Where to Obtain Service:
What to do to Obtain Service:
R-55TS, Home Use Carousel Microwave Oven. (Be sure to have this
information available when you need service for your Product.)
One (1) year parts and labor. The warranty period continues for an
additional four (4) years, for a total of five (5) years, with respect to the
magnetron tube in the Product for parts only; labor and service are not
provided free of charge for this additional period.
Non-functional accessories, turntable and light bulb.
From a Sharp Authorized Servicer located In the United States. To find
the location of the nearest Sharp Authorized Servicer, call Sharp toll
free at 1-800-BE-SHARP (1-800-237-4277).
Ship prepaid or carry in your Product to a Sharp Authorized Servicer.
Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.
PRODUCT INFORMATION CARD
The product information card which is on the inside of the microwave oven carton should be completed within
ten days of purchase and returned. We will keep it on file and help you access the information in case of
loss, damage or theft. This will also enable us to contact you in the unlikely event that any adjustments or
modifications are ever required for your oven.
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL
1-800-BE-SHARP
OR VISIT www.sharpusa.com
.
Save the proof of purchase as it is needed should your oven ever require warranty service.
![](/img.php?id=304774&img=bg4.png)
2
SAVE THESESAVE THESE
SAVE THESESAVE THESE
SAVE THESE
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including the following:
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to exces-
sive microwave energy:
1. Read all instructions before using the
appliance.
2. Read and follow the specific “PRECAU-
TIONS TO AVOID POSSIBLE EXPO-
SURE TO EXCESSIVE MICROWAVE
ENERGY” on inside front cover.
3. This appliance must be grounded. Connect only
to properly grounded outlet. See “GROUND-
ING INSTRUCTIONS” on page 3.
4. Install or locate this appliance only in ac-
cordance with the provided installation
instructions.
5. Some products such as whole eggs and sealed
containers —for example, closed glass jars —
are able to explode and should not be heated
in this oven.
6. Use this appliance only for its intended use as
described in this manual. Do not use corro-
sive chemicals or vapors in this appliance. This
type of oven is specifically designed to
heat, cook or dry food. It is not designed for
industrial or laboratory use.
7. As with any appliance, close supervision is
necessary when used by children.
8. Do not operate this appliance if it has a dam-
aged cord or plug, if it is not working properly
or if it has been damaged or dropped.
9. This appliance should be serviced only by quali-
fied service personnel. Contact nearest Sharp
Authorized Servicer for examination, repair or
adjustment.
10. Do not cover or block any openings on the ap-
pliance.
11. Do not store or use this appliance outdoors. Do
not use this product near water—for example,
near a kitchen sink, in a wet basement, near a
swimming pool or similar locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or
counter.
15. See door surface cleaning instructions on page
22.
16. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend
appliance when paper, plastic or other
combustible materials are placed inside
the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plas-
tic bags before placing bag in oven.
c. If materials inside the oven ignite, keep
oven door closed, turn oven off and
disconnect the power cord or shut off
power at the fuse or circuit breaker
panel.
d. Do not use the cavity for storage pur-
poses. Do not leave paper products, cook-
ing utensils or food in the cavity when not
in use.
17. Liquids, such as water, coffee or tea are able to
be overheated beyond the boiling point without
appearing to be boiling. Visible
bubbling or boiling when the container is
removed from the microwave oven is not
always present. THIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY BOILING
OVER WHEN A SPOON OR OTHER
UTENSIL IS INSERTED INTO THE LIQUID. To
reduce the risk of injury to persons:
a. Do not overheat the liquid.
b. Stir the liquid both before and halfway
through heating it.
c. Do not use straight-sided containers with
narrow necks. Use a wide-mouthed con-
tainer.
d. After heating, allow the container to stand
in the microwave oven at least for 20 sec-
onds before removing the container.
e. Use extreme care when inserting a spoon
or other utensil into the container.
18. If the oven light fails, consult a SHARP AU-
THORIZED SERVICER.
19. Do not operate any heating or cooking
appliance beneath this appliance.
20. Do not mount unit over or near any portion of
a heating or cooking appliance.
21. Do not mount over a sink.
22. Do not store anything directly on top of the
appliance surface when the appliance is in
operation.
![](/img.php?id=304774&img=bg5.png)
3
Unpacking and Examining Your OvenUnpacking and Examining Your Oven
Unpacking and Examining Your OvenUnpacking and Examining Your Oven
Unpacking and Examining Your Oven
Remove:
1. all packing materials from inside the oven cav-
ity; however, DO NOT REMOVE THE
WAVEGUIDE COVER, which is located on the
right cavity wall. Read
enclosures and SAVE
the Operation Manual.
2. the feature sticker, if
there is one, from the
outside of the door.
Check the oven for any
damage, such as mis-
aligned or bent door,
damaged door seals
and sealing surfaces, broken or loose door hinges
and latches and dents inside the cavity or on the
door. If there is any damage, do not operate the
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a
grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded in
accordance with the National Electrical Code and local codes and ordinances. In the event of an electri-
cal short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric
current.
WARNINGWARNING
WARNINGWARNING
WARNING – Improper use of the grounding plug can result in a risk of electric shock.
Electrical RequirementsElectrical Requirements
Electrical RequirementsElectrical Requirements
Electrical Requirements
The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. or more
protected electrical supply. It is recommended that a separate circuit serv-
ing only this appliance be provided.
The oven is equipped with a 3-prong grounding plug. It must be plugged
into a wall receptacle that is properly installed and grounded. Should you
only have a 2-prong outlet, have a qualified electrician install a correct wall
receptacle.
A 3-prong adapter may be purchased and used temporarily if local codes
allow. Follow package directions.
A short power-supply cord is provided to reduce risk of becoming entangled
in or tripping over a longer cord.
Extension CordExtension Cord
Extension CordExtension Cord
Extension Cord
If it is necessary to use an extension cord, use only a 3-wire extension cord
that has a 3-blade grounding plug and a 3-slot receptacle that will accept
the plug on the microwave oven. The marked rating of the extension cord
should be AC 115-120 volt, 15 amp. or more.
Be careful not to drape the cord over the countertop or table where it can be
pulled on by children or tripped over accidentally.
Notes:1. If you have any questions about the grounding or electrical in-
structions, consult a qualified electrician or service person.
2. Neither Sharp nor the dealer can accept any liability for damage
to the oven or personal injury resulting from failure to observe the
correct electrical connection procedures.
Radio or TV InterferenceRadio or TV Interference
Radio or TV InterferenceRadio or TV Interference
Radio or TV Interference
Should there be any interference caused by the microwave oven to your radio or TV, check that the
microwave oven is on a different electrical circuit, relocate the radio or TV as far away from the oven as
feasible or check position and signal of receiving antenna.
UNPACKING AND INSTALLATION INSTRUCTIONS
GROUNDING INSTRUCTIONS
oven and contact your dealer or SHARP
AUTHORIZED SERVICER.
Choosing a Location for Your OvenChoosing a Location for Your Oven
Choosing a Location for Your OvenChoosing a Location for Your Oven
Choosing a Location for Your Oven
You will use the oven frequently so plan its loca-
tion for ease of use. The oven must be placed on a
countertop which is a minimum of 36 inches from the
floor. It's wise, if possible, to have counter space
on at least one side of the oven. Allow at least 2
inches on the sides, top and at the rear of the
oven for air circulation. Do not place or install
the oven in any area where heat and steam are
generated; for example, next to or above a
conventional gas or electric range or above a
conventional wall oven. Heat and steam may
damage the electronics or the mechanical parts
of the oven.
![](/img.php?id=304774&img=bg6.png)
4
INFORMATION YOU NEED TO KNOW
ABOUT YOUR OVENABOUT YOUR OVEN
ABOUT YOUR OVENABOUT YOUR OVEN
ABOUT YOUR OVEN
Eggs, sausages,
nuts, seeds
fruits &
vegetables
Popcorn
Baby food
General
ABOUT FOODABOUT FOOD
ABOUT FOODABOUT FOOD
ABOUT FOOD
•Puncture egg yolks before cooking to pre-
vent “explosion”.
•Pierce skins of potatoes, apples, squash,
hot dogs and sausages so that steam es-
capes.
• Use specially bagged popcorn for the mi-
crowave oven.
•Listen while popping corn for the popping
to slow to 1 or 2 seconds.
•Transfer baby food to small dish and heat
carefully, stirring often. Check temperature
before serving.
•Put nipples on bottles after heating and
shake thoroughly. “Wrist” test before feed-
ing.
•Cut baked goods with filling after heating
to release steam and avoid burns.
•Stir liquids briskly before heating and al-
low to stand at least for 20 seconds after
heating before stirring or drinking to avoid
eruption.
•Use deep bowl, when cooking liquids or ce-
reals, to prevent boilovers.
•Cook eggs in shells.
•Reheat whole eggs.
•Dry nuts or seeds in shells.
•Pop popcorn in regular brown bags
or glass bowls.
•Exceed maximum time on popcorn
package.
•Heat baby food in original jars.
•Heat disposable bottles.
•Heat bottles with nipples on.
•Heat or cook in closed glass jars or
air tight containers.
•Can in the microwave as harmful
bacteria may not be destroyed.
•Deep fat fry.
•Dry wood, gourds, herbs or wet papers.
DO DONユT
FOOD
This Operation Manual is valuable: read it carefully and
always save it for reference.
Good recipes are included in this operation manual.
Check them as well as this section for cooking principles,
techniques, hints.
NEVERNEVER
NEVERNEVER
NEVER use the oven without the turntable and sup-
port nor turn the turntable over so that a large dish could
be placed in the oven. Only remove for cleaning or for the
menus specified in this manual. The turntable will turn
both clockwise and counterclockwise.
ALWAYSALWAYS
ALWAYSALWAYS
ALWAYS have food in the oven when it is on to ab-
sorb the microwave energy.
When using the oven at power levels below 100%, you
may hear the magnetron cycling on and off. It is normal
for the exterior of the oven to be warm to the touch when
cooking or reheating.
Condensation is a normal part of microwave cooking.
Room humidity and the moisture in food will influence the
amount of moisture that condenses in the oven. Gener-
ally, covered foods will not cause as much condensation
as uncovered ones. Vents on the oven back must not be
blocked.
After using, the cooling fan may come on to cool the
oven cavity. The display will show COOLING, and you
will hear the sound of the fan.
Unlike microwave-only ovens, your oven may become
hot during cooking. Be cautious.
The oven is for food preparation only. It should not be
used to dry clothes or newspapers.
Your oven is rated 650 watts by using the IEC Test
Procedure. In using recipes or package directions, check
food a minute or two before the minimum time and add
time accordingly.
![](/img.php?id=304774&img=bg7.png)
5
ABOUT UTENSILS AND COVERINGSABOUT UTENSILS AND COVERINGS
ABOUT UTENSILS AND COVERINGSABOUT UTENSILS AND COVERINGS
ABOUT UTENSILS AND COVERINGS
INFORMATION YOU NEED TO KNOW
Small flat pieces of aluminum foil placed
smoothly on food can be used to shield areas
from cooking or defrosting too quickly. Keep foil
at least 1 inch from walls of oven. Ensure not to
touch foil to the turntable.
Can be used if 3/4 filled with food. Keep 1
inch away from walls and do not cover with foil.
Do not exceed recommended preheating
time. Follow manufacturer's directions.
Excellent
Excellent. A pie plate is necessary
for popping popcorn.
Good for large meats or foods that need
tenderizing. DO NOT use metal twist ties.
For reheating
To cover for reheating and cooking. Do
not use recycled paper towels which may contain
metal filings.
Aluminum foil
Aluminum containers
Browning dish
Glass ceramic
(Pyroceram.®)
Glass, heat-resistant
Glass, non-heat-resistant
Lids, glass
Lids, metal
Metal cookware
Metal, misc: dishes
with metallic trim,
screws, bands,
handles. Metal twist
ties
Oven cooking bags
Paper plates
Paper towels
Paper, ovenable
Utensils and
Coverings Microwave Only
Yes
It is not necessary to buy all new cookware. Many pieces already in your kitchen can be used successfully in
your new convection microwave oven. The chart below will help you decide what utensils and coverings should
be used in each mode.
Grill, Bake
Yes
Yes Yes
Yes No
YesYes
Yes
Yes
No
Yes
No
Yes
No
No
No
For shielding
Excellent
Excellent
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
No
No
Yes
Excellent
![](/img.php?id=304774&img=bg8.png)
6
Use for reheating and defrosting. Some
microwave-safe plastics are not suitable for
cooking foods with high fat and sugar content.
Follow manufacturer's directions.
Use brands specially marked for
microwave use. DO NOT allow plastic wrap to
touch food. Vent so steam can escape.
Check manufacturer's recommendation for
being microwave safe.
For reheating
May be used for short periods of time. Do
not use with high fat or high sugar content
foods. Could char.
Microwave-safe
plastic containers
Plastic, Thermoset
®
Plastic wrap
Pottery, porcelain
stoneware
Styrofoam
Wicker, wood, straw
Utensils and
Coverings Microwave Only Grill, Bake
Yes No
Yes
Yes
Yes
No
Yes
Yes
Yes
No
No
DISH CHECK. If you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. If the dish becomes very hot, do NOT use it for microwaving.
ACCESSORIES There are many microwave accessories available for purchase. Evaluate carefully before
you purchase so that they meet your needs. A microwave-safe thermometer will assist you in determining
correct doneness and assure you that foods have been cooked to safe temperatures when using microwave-
only cooking. Sharp is not responsible for any damage to the oven when accessories are used.
Yes
AUTOMATIC COOKING Use the recommended container in the cooking chart in this operation manual, cookbook and
display.
INFORMATION YOU NEED TO KNOW
![](/img.php?id=304774&img=bg9.png)
7
ABOUT MICROWAVE COOKINGABOUT MICROWAVE COOKING
ABOUT MICROWAVE COOKINGABOUT MICROWAVE COOKING
ABOUT MICROWAVE COOKING
・Arrange food carefully. Place thickest areas towards
outside of dish.
・Watch cooking time. Cook for the shortest amount
of time indicated and add more as needed. Food
severely overcooked can smoke or ignite.
・Cover foods while cooking. Check recipe or cook-
book for suggestions: paper towels, wax paper,
microwave plastic wrap or a lid. Covers prevent
spattering and help foods to cook evenly.
・Shield with small flat pieces of aluminum foil any
thin areas of meat or poultry to prevent overcooking
before dense, thick areas are cooked thoroughly.
・Stir foods from outside to center of dish once or twice
during cooking, if possible.
・Turn foods over once during microwaving to
speed cooking of such foods as chicken and ham-
burgers. Large items like roasts must be turned over
at least once.
INFORMATION YOU NEED TO KNOW
・Rearrange foods such as meatballs halfway
through cooking both from top to bottom and from
the center of the dish to the outside.
・Add standing time. Remove food from oven and
stir, if possible. Cover for standing time which allows
the food to finish cooking without overcooking.
・Check for doneness. Look for signs indicating that
cooking temperatures have been reached.
Doneness signs include:
- Food steams throughout, not just at edge.
- Center bottom of dish is very hot to the touch.
-Poultry thigh joints move easily.
-Meat and poultry show no pinkness.
-Fish is opaque and flakes easily with a fork.
・Check foods to see that they are cooked to the
United States Department of Agriculture's
recommended temperatures.
To test for doneness, insert a meat thermometer in a
thick or dense area away from fat or bone. NEVER
leave the thermometer in the food during cooking,
unless using a microwave thermometer when cooking
with only microwave power.
・ALWAYS use potholders to prevent burns when
handling utensils that are in contact with hot food.
Enough heat from the food can transfer through
utensils to cause skin burns.
・Avoid steam burns by directing steam away from
the face and hands. Slowly lift the farthest edge of
a dish's covering and carefully open popcorn and
oven cooking bags away from the face.
・Stay near the oven while it's in use and check
cooking progress frequently so that there is no
chance of overcooking food.
・NEVER use the cavity for storing cookbooks or
other items.
・Select, store and handle food carefully to preserve
its high quality and minimize the spread of
foodborne bacteria.
・Keep waveguide cover clean. Food residue can
cause arcing and/or fires.
・Use care when removing items from the oven so
that the utensil, your clothes or accessories do not
touch the safety door latches.
ABOUT SAFETYABOUT SAFETY
ABOUT SAFETYABOUT SAFETY
ABOUT SAFETY
... for fresh pork, ground meat,
boneless white poultry, fish,
seafood, egg dishes and frozen
prepared food.
... for leftover, ready-to-reheat
refrigerated, and deli and carry-
out “fresh” food.
... white meat of poultry.
... dark meat of poultry.
160°F
TEMP FOOD
165°F
170°F
180°F
Children should be taught all safety precautions: use
potholders, remove coverings carefully, pay special at-
tention to packages that crisp food because they may be
extra hot.
Don’t assume that because a child has mastered one
cooking skill he/she can cook everything.
Children need to learn that the toaster oven is not a toy.
See page 21 for Child Lock feature.
ABOUT CHILDREN AND THE MICROWAVEABOUT CHILDREN AND THE MICROWAVE
ABOUT CHILDREN AND THE MICROWAVEABOUT CHILDREN AND THE MICROWAVE
ABOUT CHILDREN AND THE MICROWAVE
Children below the age of 7 should use the microwave
oven with a supervising person very near to them. Be-
tween the ages of 7 and 12, the supervising person
should be in the same room.
The child must be able to reach the oven comfortably; if
not, he/she should stand on a sturdy stool.
At no time should anyone be allowed to lean or swing on
the oven door.
• The oven cabinet, cavity, door, accessories and
dishes will become hot. To PREVENT BURNS, use
thick oven gloves when removing the food or
turntable from the oven.
• When preheating, the turntable can be left in or
removed. When preheat is over, open oven door and
quickly place turntable and foods to be baked inside.
• Do not cover turntable with aluminum foil.
• Round pizza pans are excellent cooking utensils for
many items. Choose pans that do not have extended
handles.
ABOUT GRILL, BAKE, AUTOMATIC COOKINGSABOUT GRILL, BAKE, AUTOMATIC COOKINGS
ABOUT GRILL, BAKE, AUTOMATIC COOKINGSABOUT GRILL, BAKE, AUTOMATIC COOKINGS
ABOUT GRILL, BAKE, AUTOMATIC COOKINGS
![](/img.php?id=304774&img=bga.png)
8
PART NAMES
1Door opening handle
Pull to open door.
2Oven door with see-through window
3Safety door latches
The oven will not operate unless the
door is securely closed.
4Door hinges
5Door seals and sealing surfaces
6Turntable motor shaft
7Removable turntable support
Carefully place the turntable support in
the center of the oven floor.
The turntable motor shaft should be set
into the recess of the turntable support.
8Removable turntable
Place the turntable on the turntable
support securely. The turntable will
rotate clockwise or counterclockwise.
Only remove for cleaning or for the
menus specified in this manual.
9 Top grill heater (top heater)
10 Bottom grill heater (bottom heater)
The bottom heater is under the cacvity
floor.
11 Ventilation openings (Rear)
12 Oven light
It will light when oven is operating or
door is open.
13 Waveguide cover: DO NOT REMOVE.
14 Auto-Touch control panel
15 Time display: 95 minutes
MICROWAVE OVEN PARTSMICROWAVE OVEN PARTS
MICROWAVE OVEN PARTSMICROWAVE OVEN PARTS
MICROWAVE OVEN PARTS
DISPLAYDISPLAY
DISPLAYDISPLAY
DISPLAY
Indicators will light to indicate what function is in process and quantity .
More/less bars will light to indicate the length of automatic cooking or the desired
doneness for automatic cooking.
1
2
3
3
4
5
6
7
8
9
10
11 12
13
14
15
Indicators
More/less bars
![](/img.php?id=304774&img=bgb.png)
9
PART NAMES
Number next to the control panel illustration indicates page on
which there are a feature description and usage information.
R-55TS
10, 20, 21
10
10, 20
16 - 17
10 12
11
12, 13
12, 14
12, 15
10, 12, 21
![](/img.php?id=304774&img=bgc.png)
10
PROCEDURE DISPLAY
・If the electrical power supply to your microwave
oven should be interrupted, the display will inter-
mittently show
88:88
after the power is reinstated.
If this occurs during cooking, the program will be
erased. The time of day will also be erased. Simply
touch STOP/CLEAR and reset the clock for the
correct time of day.
00 (hour) will flash.
BEFORE OPERATING
・Before operating your new microwave oven make
sure you read and understand this operation
manual completely.
・Before the oven can be used, follow these
procedures:
1. Plug in the oven. Close the door. The oven display
will then begin flashing
88:88
.
2. Touch STOP/CLEAR.
will appear.
3. Set clock. See below.
4. Condition the heaters by heating oven without
food. See page 11.
::
::
:
TO SET THE CLOCKTO SET THE CLOCK
TO SET THE CLOCKTO SET THE CLOCK
TO SET THE CLOCK
・Suppose you want to enter the correct time of day
12:30 (A.M. or P.M.).
1
Touch CLOCK.
Enter the correct hour by
rotating the TIME controller.
2
3
Touch CLOCK again.
STOPSTOP
STOPSTOP
STOP//
//
/CLEARCLEAR
CLEARCLEAR
CLEAR
Touch STOP/CLEAR to:
1. Erase if you make a mistake during programming.
2. Cancel timer.
3. Stop the oven temporarily during cooking.
4. Return the time of day to the display.
5. Cancel a program during cooking, touch twice.
MANUAL OPERATION
Your oven can be programmed for 95 minutes (95.00)
using the TIME controller. The input unit of cooking (de-
frosting) time varies from 10 seconds to five minutes. It
depends on the total length of the cooking (defrosting)
time as shown on the table below:
MICROWAVEMICROWAVE
MICROWAVEMICROWAVE
MICROWAVE TIME COOKING TIME COOKING
TIME COOKING TIME COOKING
TIME COOKING
PROCEDURE DISPLAY
1
Enter cooking time.
Touch START
2
There are six preset power levels. Using lower power
levels increases the cooking time which is recom-
mended for foods such as cheese, milk and long slow
cooking of meats. Consult cookbook or recipes for spe-
cific recommendations.
・Suppose you want to defrost for 5 minutes at 30%.
once 100% High
twice 70% Medium High
3 times 50% Medium
4 times 30% Med Low/Defrost
5 times 10% Low
6 times 0%
PROCEDURE DISPLAY
1
Touch MICRO
4 times or hold down
until the desired power
level appears.
2
3
Enter defrost time.
Touch START.
4
When the defrost time is complete, a long tone
will sound and will appear in the display.
x 4
Enter the correct minute by
rotating the TIME controller.
Touch CLOCK again.
4
5
・Suppose you want to cook for 5 minutes at 100%.
Cooking Time:Cooking Time:
Cooking Time:Cooking Time:
Cooking Time: Increasing unit:Increasing unit:
Increasing unit:Increasing unit:
Increasing unit:
0-5 minutes 10 seconds
5-10 seconds 30 seconds
10-30 minutes 1 minute
30-95 minutes 5 minutes
TO SET POWER LEVELTO SET POWER LEVEL
TO SET POWER LEVELTO SET POWER LEVEL
TO SET POWER LEVEL
You can program up to 3 automatic cooking sequences.
Follow directions on page 20. Note that the power level
must be entered first when programming multiple sequences.
00 (minute) will flash.
Touch MICRO Approximate
Percentage
of Power
Commmon Words
for
Power Level
You can rotate the TIME controller clockwise or counter-
clockwise. If you rotate it counter-clockwise, the cooking
time will decrease from 95 minutes by degrees.
![](/img.php?id=304774&img=bgd.png)
11
MANUAL OPERATION
GRILLGRILL
GRILLGRILL
GRILL
Use the GRILL setting for steaks, chops, chicken pieces
and many other foods. Your oven has 2 grill heaters, and
2 grill cooking modes. Select the desired grill mode by
touching GRILL to the desired mode. See below chart.
You can enter cooking time up to 30 minutes.
Mode Touch
GRILL
Cooking
method Display
GRILL 1
GRILL 2
Top heater
Top and bottom
heaters
Once
Twice
・ Suppose you want to grill a steak for 15 minutes on
GRILL 2.
PROCEDURE DISPLAY
1
2
3
Enter cooking time.
Touch START.
x 2
Touch GRILL twice.
You may detect smoke or a burning smell when using
the oven the first time. This is normal and not a sign
that the oven is out of order. To avoid this problem,
when first using the oven, operate both top and bottom
heaters without food for 20 minutes.
CONDITION THE HEATERSCONDITION THE HEATERS
CONDITION THE HEATERSCONDITION THE HEATERS
CONDITION THE HEATERS
Caution:
The oven cabinet, cavity, door, turntable, turntable
support and dishes will become hot. To PREVENT
BURNS, use thick oven gloves when removing the
food or turntable.
PROCEDURE DISPLAY
1
2
3
Enter cooking time.
Touch START.
4
x 2
Touch GRILL twice.
The oven will count down. When the oven has
finished cooking, open the door to cool the
oven cavity.
HINT:
Turning foof over around the half of the cooking time is
recommended for better results.
NOTE:
• After cooking is complete the cooling fan will
continue working for a short time to lower the
temperature of the electrical and mechanical parts.
![](/img.php?id=304774&img=bge.png)
12
MANUAL OPERATION
BAKEBAKE
BAKEBAKE
BAKE
Use the BAKE setting for cakes, breads and many other
foods. This microwave oven has 4 pre-set oven
temperatures which use a combination of the top and
bottom heaters. The BAKE is preprogrammed preheating.
Your oven has 3 special heater cooking modes:
• AUTOMATIC TOAST
• AUTOMATIC SNACK
• AUTOMATIC BAKE
AUTOMATIC COOKINGAUTOMATIC COOKING
AUTOMATIC COOKINGAUTOMATIC COOKING
AUTOMATIC COOKING
Press BAKE
Oven Temp (° F)
Once Twice 3 times 4 times
400 375 350 325
Caution:
The oven cabinet, cavity, door, turntable, turntable
support and dishes will become hot. To PREVENT
BURNS, use thick oven gloves when removing the
food or turntable.
PROCEDURE DISPLAY
1
2
3
Enter cooking time.
Touch START.
Preheat starts.
No food in oven.
4
x 3
Touch BAKE 3 times.
Open the door. Place food in the oven.
Close the door.
Touch START.
* Suppose you want to bake a cake for 25 minutes at
350° F.
When the oven reaches the programmed temperature,
a signal will sound 4 times.*
* If the oven door is not opened, the oven will
automatically hold at the preheat temperature for 30
minutes. After this time has elapsed, an audible
signal will sound and the oven will turn off.
SPECIAL FEATURES
Caution:
The oven cabinet, cavity, door, turntable, turntable
support and dishes will become hot. To PREVENT
BURNS, use thick oven gloves when removing the food
or turntable.
Example:
* Suppose you want to toast 2 frozen waffles.
PROCEDURE DISPLAY
1
x 3
Select desired menu by
touching AUTOMATIC
TOAST. (Ex: Touch 3
times for waffle.)
Menu
Number
More/
Less Bar
The AUTOMATIC COOKING automatically works with
the appropriate cooking mode and cooking time for
each menu. 5 popular menus are included in each
AUTOMATIC COOKING. To select a menu, touch
suitable AUTOMATIC COKING pad until the desired
menu number appears in the display.
Each menu has 5 different time settings, and they are
shown as the number of the Time bar in the display. 3
Time bars setting is programmed as a standard. You
can choose desired time setting with the TIME
controller. Refer to each AUTOMATIC COOKING chart
on page 13 - 15.
2
3
Select desired setting by
rotating the TIME controller.
(Ex: Select 5 Time bars for 2
frozen waffles.)
Touch START.
x1
NOTE:
• Touching the BAKE pad during cooking will display
the programmed temperature. This will not affect the
programme or cooking time.
• Temperature measurements taken whilst the oven is
in bake mode will differ from the displayed level.
This is due to the grill elements turning on and off in
order to regulate the oven temperature. This will not
affect the cooking results as long as the operation
manual and cook book are followed correctly.
• After cooking is complete the cooling fan will
continue working for a short time to lower the
temperature of the electrical and mechanical parts.
The urntable and turntable support should be in the oven
during the preheating.
![](/img.php?id=304774&img=bgf.png)
13
SPECIAL FEATURES
AUTOMATIC TOAST CHARTAUTOMATIC TOAST CHART
AUTOMATIC TOAST CHARTAUTOMATIC TOAST CHART
AUTOMATIC TOAST CHART
MENU PROCEDURE
AT-1 Bread
3 min. 40 sec.
4 min.
4 min. 20 sec.
4 min. 40 sec.
5 min.
AT-2 Bagles
4min.
4 min. 15 sec.
4 min. 30 sec.
4 min. 50 sec.
5 min. 20sec.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AT-3 Waffles
5 min. 1 room/frozen temp. waffle
5 min. 30 sec.
6 min. 2 room temp. waffles
6 min. 30 sec.
7 min. 2 frozen waffles
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AT-4 French Toast
7 min. 3-6 sticks
7 min. 20 sec.
8 min. 1-2 slices
8 min. 20 sec.
8 min. 40 sec.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AT-5 Toaster Pastries
3 min.
3 min. 15 sec.
3 min. 30 sec. 1-2 room temp. pastries
4 min.
6 min. 2 frozen pastries
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
Special note for AUTOMATIC TOAST:
No turntable for AUTOMATIC TOAST. Place food on the turntable support directly.
Remove the turntable from the oven.
Remove the turntable from the oven.
Remove the turntable from the oven.
Remove the turntable from the oven.
Remove the turntable from the oven.
1 - 4 slices
1 half
2 halves
![](/img.php?id=304774&img=bg10.png)
14
SPECIAL FEATURES
AUTOMATIC SNACK CHARTAUTOMATIC SNACK CHART
AUTOMATIC SNACK CHARTAUTOMATIC SNACK CHART
AUTOMATIC SNACK CHART
MENU PROCEDURE
AS-1 French Fries
AS-2 Frozen Pizza
13min.
14 min.
15 min. 5-7 oz frozen pizza
16 min.
20 min. 14 oz frozen pizza
Number
of Bars Cooking Time Recommended Quantity/
Menu
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AS-3 Hamburgers
15 min. 1 medium
16 min. 2 medium
1 welldone
18 min. 3 medium
20 min. 4 medium
3 welldone
21 min. 4 welldone
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AS-4 Frozen Appetizers
7 min.
7 min. 30 sec.
8 min. 4 - 8 pieces
9 min.
10 min.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AS-5 Frankfurters and Sausage
8 min. 1-2 pieces
8 min. 30 sec.
9 min. 3-4 pieces
9 min. 30 sec.
10 min.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
15 min. 30 sec.
16 min. 30 sec.
17 min. 30 sec. 1/2 lb Frech fries
18 min.
18 min. 30 sec.
1
2
3
4
5
![](/img.php?id=304774&img=bg11.png)
15
SPECIAL FEATURES
AUTOMATIC BAKE CHARTAUTOMATIC BAKE CHART
AUTOMATIC BAKE CHARTAUTOMATIC BAKE CHART
AUTOMATIC BAKE CHART
MENU PROCEDURE
AB-1 Baked Potatoes
14 min. 1 medium
16 min.
17 min. 2 medium
18 min.
20 min.
AB-2 Biscuits
8 min.
9 min. Convenience refrigerated
baked at 400 or450°F
10 min. Home made
11 min. Convenience frozen
12 min.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AB-3 Muffins
14 min.
15 min.
16 min. 6-cup pan
17 min.
18 min.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AB-4 Brownies
28 min.
29 min.
30 min. 8-inch pan
31 min.
32 min.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
AB-5 Cakes
25 min. 6 cupcakes
28 min.
30 min. 8 or 9-inch pan
32 min.
34 min.
Number
of Bars
1
2
3
4
5
Cooking Time Recommended Quantity/
Menu
Preheat is preprogrammed for this menu.
ADD FOOF AFTER PREHEATING.
Preheat is preprogrammed for this menu.
ADD FOOF AFTER PREHEATING.
Preheat is preprogrammed for this menu.
ADD FOOF AFTER PREHEATING.
Preheat is preprogrammed for this menu.
ADD FOOF AFTER PREHEATING.
![](/img.php?id=304774&img=bg12.png)
16
PROCEDURE
1
Select desired setting.
Touch BEVERAGE 2 times
or hold down until the
desired quantity appears.
.
Instant Action allows you to cook or reheat many of your
favorite foods by touching just one pad.
・ Suppose you want to reheat 1 cup of beverage.
NOTE:
1. To increase quantity, touch chosen pad until num-
ber in display is same as desired quantity to cook.
Ex: touch FRESH VEGETABLES pad twice for 2
cups of fresh vegetables. More or less food than the
quantity listed in the chart should be cooked follow-
ing the guidelines in any microwave cookbook.
2. Instant Action can be programmed with More or Less
Time Adjustment. See page 21.
3. The final cooking result will vary according to the
food condition (e.g. initial temperature, shape, qual-
ity). Check food for temperature after cooking. If ad-
ditional time is needed, continue to cook manually.
INSTANT ACTIONINSTANT ACTION
INSTANT ACTIONINSTANT ACTION
INSTANT ACTION
INSTANT ACTIONINSTANT ACTION
INSTANT ACTIONINSTANT ACTION
INSTANT ACTION CHART CHART
CHART CHART
CHART
FOOD PROCEDUREAMOUNT
SPECIAL FEATURES
x 2
2
Touch START.
Use to reheat precooked foods from the refrigerator. Place meaty
portions and bulky vegetables to outside of plate. Cut large items
like baked potatoes in smaller pieces. Flatten foods such as
mashed potatoes and other dense foods. Cover with lid or plastic
wrap. ONE PLATE ONLY.
After cooking, check that food is very hot throughout and that the
bottom center of the plate is very hot. If not, continue heating using
time and power level. Allow to stand, covered, 1 to 2 minutes.
Touch REHEAT once for a smaller amount of food on a dinner
plate. will appear in the display.
Touch REHEAT twice for a regular amount of food on a dinner
plate. will appear in the display.
Use to reheat refrigerated canned or homemade pasta with sauce
or other cooked casserole. For room temperature pasta or casserole,
use Less option. For pasta without sauce double the quantity per
setting. For example, measure 2 cups of cooked noodles and
program for 1 cup. Cover with lid or plastic wrap.
After cooking, stir and let stand, covered, 2 to 3 minutes.
1 - 2 cups
REHEAT: Casserole
1 plate
REHEAT: Dinner Plate
1 Small
1 Regular
4. After cooking is complete the cooling fan will
continue working for a short time to lower the
temperature of the electrical and mechanical parts.
1
2
![](/img.php?id=304774&img=bg13.png)
17
Use for frozen, convenience foods. It will give satisfactory
results for most brands. You may wish to try several and choose
your favorite. Remove package from outer wrapping and follow
package directions for covering. After cooking, let stand, covered,
for 1 to 3 minutes.
Touch FROZEN ENTREES once for packages weighing 3-6
oz. will appear in the display.
Touch FROZEN ENTREES twice for packages
weighing 7-10 oz. will appear in the display.
INSTANT ACTIONINSTANT ACTION
INSTANT ACTIONINSTANT ACTION
INSTANT ACTION CHART CHART
CHART CHART
CHART
(continued)
FOOD AMOUNT PROCEDURE
SPECIAL FEATURES
Frozen Entrees
3-6 oz.
3-10 oz.
7-10 oz.
For beans, carrots, corn and peas, add 1 tablespoon of water per cup.
For broccoli, Brussels sprouts, cabbage and cauliflower, cook immediately
after washing with no additional water. Cover with a glass lid.
If you like tender crisp vegetables, double measured quantity per
setting. For example, use 2 cups of zucchini but touch FRESH
VEGETABLES only once. After cooking, remove from oven, stir,
cover and let stand 3 to 5 minutes before serving.
Fresh Vegetables 1- 2 cups
BEVERAGE This setting is good for restoring cooled beverage to a better drinking
temperature. Stir liquid briskly before and after heating to avoid
“eruption”.
You can reheat .5 cup, 1 cup, 1.5 cups and 2 cups beverage by
touching BEVERAGE.
.5 - 2 cups
3- 6
7- 10
![](/img.php?id=304774&img=bg14.png)
18
After the 2nd stage, open the door and shield
any warm portions. Close the door.
After the 1st stage, open the door, turn steak
over and shield any warm portions. Close the
door.
After defrost cycle ends, cover and let stand
as indicated in chart below.
5
4
Express Defrost automatically defrosts all the foods
shown in the EXPRESS DEFROST CHART below.
You can defrost .5 lb, .7 lb, 1.0 lb, 1.3 lb, 1.5 lb, 1.7 lb
and 2.0 lb food by touching EXPRESS DEFROST.
(Ex: touch twice for .7 lb.)
•Suppose you want to defrost a 2.0 pound steaks.
SPECIAL FEATURES
EXPRESS DEFROSTEXPRESS DEFROST
EXPRESS DEFROSTEXPRESS DEFROST
EXPRESS DEFROST NOTE:
1. Express Defrost can be programmed with More or
Less Time Adjustment.
See page 21.
2. To defrost other foods or foods above or below the
weights allowed in the DEFROST CENTER CHART,
use time and 30% power. See MANUAL DEFROST
on page 19.
NOTE:
Check foods when oven signals. After final stage, small sections may still be icy. Let stand to continue
thawing. Do not defrost until all ice crystals are thawed.
Shielding prevents cooking from occurring before the center of the food is defrosted. Use small smooth
strips of aluminum foil to cover edges and thinner sections of the food.
FOOD AMOUNT
EXPRESS DEFROST CHARTEXPRESS DEFROST CHART
EXPRESS DEFROST CHARTEXPRESS DEFROST CHART
EXPRESS DEFROST CHART
PROCEDURE
Pull apart and remove any thawed pieces after each stage.
Let stand, covered, for 5 to 10 minutes.
Ground Meat .5 - 2.0 lb
After each stage, rearrange and if there are warm or thawed por-
tions, shield with small flat pieces of aluminum foil. Remove any
meat that is nearly defrosted. Let stand, covered, for 10 to 20 min-
utes.
Steaks/Chops
Use boneless breast of chicken or turkey. After each stage, if there
are warm or thawed portions, rearrange or remove. Let stand,
covered, for 10 to 20 minutes.
Boneless Poultry .5 - 1.5 lb
.5 - 2.0 lb
PROCEDURE
1
3
Arrange pieces with meatiest portions toward outside of glass dish
or microwave safe rack. After each stage, if there are warm or
thawed portions, rearrange or remove. Let stand, covered, for 10
to 20 minutes.
Bone-in Poultry .5 - 3.0 lb
x 4
2
Touch START.
Enter desired weight by
touching EXPRESS
DEFROST. (Ex: Touch 7
times for 2.0 lb.)
Touch START .
Touch START .
![](/img.php?id=304774&img=bg15.png)
19
MANUAL DEFROSTMANUAL DEFROST
MANUAL DEFROSTMANUAL DEFROST
MANUAL DEFROST
If the food that you wish to defrost is not listed on the
EXPRESS DEFROST CHART or is above or below the
limits in the “Amount” column on the EXPRESS DE-
FROST CHART, you need to defrost manually.
You can defrost any frozen food, either raw or previ-
ously cooked, by using 30% Power Level. See page
10. Estimate defrosting time and press MICRO 4 times
for 30% when you select the power level.
For either raw or previously cooked frozen food the
rule of thumb is approximately 5 minutes per pound.
For example, defrost 5 minutes for 1 pound of frozen
spaghetti sauce.
Always stop the oven periodically to remove or sepa-
rate the portions that are defrosted. If food is not
defrosted at the end of the estimated defrosting
time, program the oven in 1 minute increments at 30%
until totally defrosted.
When using plastic containers from the freezer, defrost
only long enough to remove from the plastic in order
to place in a microwave-safe dish.
SPECIAL FEATURES
![](/img.php?id=304774&img=bg16.png)
20
OTHER CONVENIENT FEATURES
PROCEDURE
1
Touch GRILL once for
GRILL1.
Then enter second
cooking time.
2
First touch MICRO
twice for 70% power.
Then enter cooking time.
Touch START .
3
MULTIPLE SEQUENCEMULTIPLE SEQUENCE
MULTIPLE SEQUENCEMULTIPLE SEQUENCE
MULTIPLE SEQUENCE
COOKINGCOOKING
COOKINGCOOKING
COOKING
Your oven can be programmed for up to 3 automatic
cooking sequences, switching from one power level
setting to another automatically.
Sometimes cooking directions tell you to start on one
power level and then change to a different power
level. Your oven can do this automatically.
・Suppose you want to cook for 5 minutes at MICRO
70% and then continue to cook for 10 minutes at
GRILL1.
NOTE:
1. You can program BAKE for the first sequence only.
.
2. If you wish to know power level, simply touch POWER
LEVEL . As long as your finger is touching POWER
LEVEL , the power level will be displayed.
PROCEDURE DISPLAY
1
Enter desired extending time
by rotating the TIME controller.
2
After cooking, End is
flashing in the display.
Touch START.
EXTEND THE COOKINGEXTEND THE COOKING
EXTEND THE COOKINGEXTEND THE COOKING
EXTEND THE COOKING
TIMETIME
TIMETIME
TIME
After cooking you can extend the cooking time with the
last setting.
The maximum extending time is 10 minutes.
・Suppose you want to extend 5 minutes after the GRILL
1 cooking.
NOTE:
.To use Minute Plus for 100% cooking, touch pad within
3 minutes after touching STOP/CLEAR, or closing the
door (appearing the time of day or “ : “ ).
Touch MINUTE
PLUS pad.
1
MINUTE PLUSMINUTE PLUS
MINUTE PLUSMINUTE PLUS
MINUTE PLUS
Minute Plus allows you to cook for a minute at 100% by
simply touching MINUTE PLUS . You can also
extend cooking time in multiples of 1 minute by repeatedly
touching MINUTE PLUS during manual cooking.
・Suppose you want to heat a cup of soup for one
minute at 100%.
PROCEDURE
Open and close the door.
NOTE:
1. To use Extend function, rotate the TIME controller within
3 minutes after closing the door.
2. You can extend the cooking time using the MINUTE
PLUS, which extends cooking time in multiples
of 1 minute. Touch the MINUTE PLUS within 3
minutes after closing the door. After touching the
MINUTE PLUS, the cooking starts automatically.
3. Extend function can be used with SPECIAL FEA-
TURES.
TIMERTIMER
TIMERTIMER
TIMER
・Suppose you want to time a 3-minute long distance
phone call.
Enter time.
1
PROCEDURE
2
Touch TIMER .
X 2
X 1
![](/img.php?id=304774&img=bg17.png)
21
DEMONSTRATION MODEDEMONSTRATION MODE
DEMONSTRATION MODEDEMONSTRATION MODE
DEMONSTRATION MODE
To demonstrate, touch TIMER/CLOCK, adjust TIME con-
troller to 0 and then touch the START and hold for 3
seconds.
S HO
will appear in the display. Cooking operations
and specific special features can now be demonstrated
with no power in the oven. For example, touch MINUTE
PLUS and the display will show
1.00
and count
down quickly to .
To cancel, touch TIMER/CLOCK,adjust TIME controller to 0
and STOP/CLEAR . If easier, unplug the oven from
the electrical outlet and replug.
AUDIBLE SIGNAL ELIMI-AUDIBLE SIGNAL ELIMI-
AUDIBLE SIGNAL ELIMI-AUDIBLE SIGNAL ELIMI-
AUDIBLE SIGNAL ELIMI-
NATIONNATION
NATIONNATION
NATION
If you wish to have the oven operate with no audible sig-
nals, touch TIMER/CLOCK, adjust TIME controller to 5
and then touch the START and hold for three sec-
onds.
To cancel, touch TIMER/CLOCK, adjust TIME control-
ler to 5 and STOP/CLEAR .
MORE OR LESS TIMEMORE OR LESS TIME
MORE OR LESS TIMEMORE OR LESS TIME
MORE OR LESS TIME
ADJUSTMENTADJUSTMENT
ADJUSTMENTADJUSTMENT
ADJUSTMENT
Should you discover that you like any of the Instant Ac-
tion or Express Defrost settings slightly more done, ro-
tate the TIME controller clockwise until desired Time
bar appears before touching START.
Should you discover that you like any of the Instant
Action or Express Defrost settings slightly less done,
rotate the TIME controller counterclockwise until de-
sired Time bar appears before touching START .
.
CHILD LOCKCHILD LOCK
CHILD LOCKCHILD LOCK
CHILD LOCK
The Child Lock prevents unwanted oven operation
such as by small children. The oven can be set so
that the control panel is deactivated or locked. To set,
touch TIMER/CLOCK, adjust TIME controller to 1and
then touch the START and hold for three sec-
onds. Should a button be touched,
SA FE
will
appear in the display.
To cancel, touch TIMER/CLOCK, adjust TIME controller
to 1 and STOP/CLEAR .
OTHER CONVENIENT FEATURES
![](/img.php?id=304774&img=bg18.png)
22
Disconnect the power cord before cleaning or
leave the door open to inactivate the oven dur-
ing cleaning. Ensure the oven is completly cool
before cleaning.
ExteriorExterior
ExteriorExterior
Exterior
The outside surface is painted. Clean the outside
with mild soap and water; rinse and dry with a soft
cloth. Wipe off the dust of the ventilation openings
and power supply plug. Do not use any type of
household or abrasive cleaner.
DoorDoor
DoorDoor
Door
Wipe the window on both sides with a damp cloth
to remove any spills or spatters. Metal parts will be
easier to maintain if wiped frequently with a damp
cloth. Avoid the use of spray and other harsh clean-
ers as they may stain, streak or dull the door sur-
face.
Touch Control Panel
Touch Control PanelTouch Control Panel
Touch Control Panel
Wipe the panel with a cloth dampened slightly with
water only. Dry with a soft cloth. Do not scrub or
use any sort of chemical cleaners. Close door and
touch STOP/CLEAR .
InteriorInterior
InteriorInterior
Interior
Cleaning is easy because little heat is generated to
the interior surfaces; therefore, there is no baking
and setting of spills or spattering. To clean the inte-
rior surfaces, wipe with a soft cloth and warm wa-
ter. DO NOT USE ABRASIVE OR HARSH CLEAN-
ERS OR SCOURING PADS. For heavier soil, use
baking soda or a mild soap; rinse thoroughly with
hot water. NEVER SPRAY OVEN CLEANERS DI-
RECTLY ONTO ANY PART OF THE OVEN.
InteriorInterior
InteriorInterior
Interior
Spatters may occur because of moisture and grease.
Wash immediately after use with hot, soapy water.
Rinse and polish dry. Harder to remove spatters may
occur if oven is not thoroughly cleaned or if there is
long time/high temperature cooking. If so, you may
wish to purchase an oven cleaner pad with liquid
cleaner within it--not a soap filled steel pad--for use on
stainless or porcelain surfaces. Follow manufacturer's
directions carefully and be especially cautious not to
get any of the liquid cleaner in the perforations on the
wall or ceiling or any door surfaces.
Rinse thoroughly and polish dry. After cleaning the
interior thoroughly, residual grease may be removed
from the interior ducts and heater by simply operating
the oven on 400°F. for 20 minutes without food.
Ventilate the room if necessary.
CLEANING AND CARE
- after microwave cooking.
- after grill, bake or automatic cookings.
Waveguide CoverWaveguide Cover
Waveguide CoverWaveguide Cover
Waveguide Cover
The waveguide cover is made from mica so requires
special care. Keep the waveguide cover clean to
assure good oven performance. Carefully wipe with
a damp cloth any food spatters from the surface of
the cover immediately after they occur. Built-up
splashes may overheat and cause smoke or possi-
bly catch fire. Do not remove the waveguide cover.
Odor RemovalOdor Removal
Odor RemovalOdor Removal
Odor Removal
Occasionally, a cooking odor may remain in the
oven. To remove, combine 1 cup water, grated peel
and juice of 1 lemon and several whole cloves in a
2-cup glass measuring cup. Boil for several minutes
using 100% power. Allow to set in oven until cool.
Wipe interior with a soft cloth.
TurntablTurntabl
TurntablTurntabl
Turntablee
ee
e//
//
/Turntable SupportTurntable Support
Turntable SupportTurntable Support
Turntable Support
The turntable and turntable support can be removed
for easy cleaning. Remove the turntable support care-
fully to prevent breaking the top heater. Wash them in
mild, sudsy water; for stubborn stains use a mild
cleanser and a non-abrasive scouring sponge. They
are also dishwasher-proof. Use upper rack of dish-
washer. The turntable motor shaft is not sealed, so
excess water or spills should be wiped up immedi-
ately.
![](/img.php?id=304774&img=bg19.png)
23
Please check the following before calling for service:
1. Place one cup of water in a glass measuring cup in the oven and close the door securely.
Operate the oven for one minute at MICRO 100%.
A
Does the oven light come on? YES _______ NO _______
B
Does the cooling fan work? YES _______ NO _______
(Put your hand over the rear ventilating openings.)
C
Does the turntable rotate? YES _______ NO _______
(It is normal for the turntable to turn in either direction.)
D
Is the water in the oven warm? YES _______ NO _______
2. Remove water from the oven and operate the oven for 5 minutes at BAKE 400°F.
A Do HEATER and COOK indicators light? YES _______ NO _______
B After the oven shuts off, is inside of the oven hot? YES _______ NO _______
If “NO” is the answer to any of the above questions, please check electrical outlet, fuse and/or circuit breaker.
If they are functioning properly, CONTACT YOUR NEAREST SHARP AUTHORIZED SERVICER.
A microwave oven should never be serviced by a “do-it-yourself” repair person.
NOTE:1.
If time appearing in the display is counting down very rapidly, check DEMONSTRATION MODE on page 21
and cancel.
2. If the oven is set for more than 20 minutes at MICRO 100 percent power level, after the first 20
minutes the power level will automatically adjust itself to 70 percent power to avoid overcooking.
SERVICE CALL CHECK
![](/img.php?id=304774&img=bg1a.png)
24
SPECIFICATIONS
*The International Electrotechnical Commission’s standardized method for measuring output wattage. This
test method is widely recognized.
In compliance with standards set by:
FCC –Federal Communications Commission Authorized.
DHHS –Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21, Chapter I,
Subchapter J.
–This symbol on the nameplate means the product is listed by Underwriters Laboratories, Inc.
Single phase 120V, 60Hz, AC only
980 W 8.5A
1300W 10.8 A
650 W* (IEC Test Procedure)
760 W
510 W
2450 MHz
17-3/4"(W) x 11-1/2"(H) x 15-1/4"(D)
11-1/4"(W) x 5-7/8"(H) x 11-5/8"(D)
Approx. 0.5 Cu. Ft.
Turntable system
Approx. 31lb
AC Line Voltage:
AC Power Required:
Microwave
Grill/Bake
Output Power:
Microwave
Top heater
Bottom heater
Frequency:
Outside Dimensions:
Cavity Dimensions:
Oven Capacity
Cooking Uniformity:
Weight:
![](/img.php?id=304774&img=bg1b.png)
25
®
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, NJ 07430-2135
TINSEA983WRRZ-D31
Printed in China
