Sharp >
User manual
P/N 316495032 TINSEB156WRRZ-EL81
Use & Care Guide
Over the Range Microwave Oven
Guía de Uso y Cuidado
Horno microondas sobre la estufa
Mode d’emploi et d’entretien
Four à micro-ondes au dessus de la cuisinière
ORM_Eng.indd 1ORM_Eng.indd 1 08.2.27 6:23:29 PM08.2.27 6:23:29 PM
*** DRAFT ***
E
2
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result
in harmful exposure to microwave energy. It is important not to defeat or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or
loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
Purchase date
Electrolux model number
Electrolux serial number (see picture for location)
Please read and save this guide
Thank you for choosing Electrolux, the new premium brand in home appliances. This Use & Care Guide
is part of our commitment to customer satisfaction and product quality throughout the service life of your
new appliance.
We view your purchase as the beginning of a relationship. To ensure our ability to continue serving you,
please use this page to record important product information.
Keep a record for quick reference
Questions?
For toll-free telephone support in the U.S.:
1-877-4ELECTROLUX (1-877-435-3287)
For online support and Internet production information visit http://www.electroluxappliances.com
©2008 Electrolux Home Products, Inc. All rights reserved. Printed in Thailand
FINDING INFORMATION
NOTE
Registering your product with Electrolux enhances
our ability to serve you. You can register online at
www.electroluxappliances.com or by dropping
your Product Registration Card in the mail.
ORM_Eng.indd 2ORM_Eng.indd 2 08.2.27 6:23:30 PM08.2.27 6:23:30 PM
E
3
FINDING INFORMATION .................................. 2
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
............... 2
TABLE OF CONTENTS .................................... 3
IMPORTANT SAFETY INSTRUCTIONS .......... 4
UNPACKING AND EXAMING YOUR OVEN .... 5
GROUNDING INSTRUCTIONS ........................ 6
INFORMATION YOU NEED TO KNOW ........... 7-10
About Your Oven ............................................ 7
About Microwave Cooking ............................. 7
About Safety ................................................. 8
About Children and the Microwave ................ 8
About Food .................................................... 9
About Utensils and Coverings ....................... 10
PART NAMES ................................................... 11
CONTROL PANEL ............................................ 12
BEFORE OPERATING ..................................... 13
To Set the Clock ............................................. 13
Stop/Clear ..................................................... 13
MANUAL OPERATION ..................................... 14-15
Time Cooking ................................................. 14
To Set Power Level ........................................ 14
Using the Rack ............................................... 14
Manual Defrost ............................................... 15
SENSOR MODES ............................................ 15-19
Sensor Cook .................................................. 16
Sensor Cook chart ......................................... 17
Popcorn/Fresh Veggies/Frozen Veggies/
Baked Potato/Sensor Reheat ........................ 18
Popcorn chart ............................................... 18
Fresh Veggies chart ....................................... 19
Frozen Veggies chart ..................................... 19
Baked Potato chart ....................................... 19
Sensor Reheat chart ..................................... 19
AUTO MODES ................................................. 20-26
Auto Cook ...................................................... 20
Auto Cook chart ............................................. 20
Dinner recipes ................................................ 21
Keep Warm..................................................... 22
Melt, Soften .................................................... 23
Melt, Soften chart ........................................... 23
Snacks ........................................................... 24
Snacks chart .................................................. 24
Auto Reheat ................................................... 25
Auto Reheat chart .......................................... 25
Auto Defrost ................................................... 26
Auto Defrost chart .......................................... 26
CONVENIENT FEATURES .............................. 27-29
User Pref ........................................................ 27
Multiple Sequence Cooking ........................... 28
More or Less Time Adjustment ...................... 28
Add 30 Seconds ............................................ 28
Help ................................................................ 29
Timer .............................................................. 29
Turntable ON/OFF .......................................... 29
Quick Start ..................................................... 29
Demonstration Mode ..................................... 29
Light ............................................................... 29
Fan ................................................................. 29
CLEANING AND CARE .................................... 30-31
SERVICE CALL CHECK .................................. 32
SPECIFICATIONS ............................................. 33
WARRANTY INFORMATIONS ......................... 34
TABLE OF CONTENTS
ORM_Eng.indd 3ORM_Eng.indd 3 08.2.27 6:23:30 PM08.2.27 6:23:30 PM
E
4
When using electrical appliances basic safety precautions should be followed, including the following:
To reduce the risk of burns, electric shock, fire, injury to persons or exposure
to excessive microwave energy:
SAVE THESE INSTRUCTIONS
1. Read all instructions before using the appli-
ance.
2. Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on page 2.
3. This appliance must be grounded. Connect only
to properly grounded outlet. See “Grounding
Instructions” on page 6.
4. Install or locate this appliance only in accordance
with the provided installation instructions.
5. Some products such as whole eggs and sealed
containers—for example, closed glass jars—are
able to explode and should not be heated in
this oven.
6. Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type
of oven is specifically designed to heat, cook
or dry food. It is not designed for industrial or
laboratory use.
7. As with any appliance, close supervision is
necessary when used by children.
8. Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly or if it
has been damaged or dropped.
9. This appliance should be serviced only by
qualified service personnel. Contact nearest
Electrolux Authorized Servicer for examination,
repair or adjustment.
10. Do not cover or block any openings on the appli-
ance.
11. Do not store or use this appliance outdoors. Do
not use this product near water—for example,
near a kitchen sink, in a wet basement, near a
swimming pool, or similar locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or
counter.
15. See door surface cleaning instructions on page
30 - 31.
16. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend
to appliance when paper, plastic or other
combustible materials are placed inside the
oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic
bags before placing bag in oven.
c. If materials inside the oven ignite, keep oven
door closed, turn oven of f and disconnect the
power cord or shut off power at the fuse or
circuit breaker panel.
d. Do not use the cavity for storage purposes. Do
not leave paper products, cooking utensils or
food in the cavity when not in use.
17. Liquids, such as water, coffee or tea are able to
be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or
boiling when the container is removed from
the Microwave Oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN A SPOON
OR OTHER UTENSIL IS INSERTED INTO THE
LIQUID.
To reduce the risk of injury to persons:
a. Do not overheat the liquid.
b. Stir the liquid both before and halfway through
heating it.
c. Do not use straight-sided containers with narrow
necks. Use a wide-mouthed container
.
d. After heating, allow the container to stand in the
Microwave Oven at least for 20 seconds before
removing the container.
e. Use extreme care when inserting a spoon or other
utensil into the container.
18.
Clean ventilation openings and grease filters
frequently—grease should not be allowed to accu-
mulate on ventilation openings, louver or grease
filters.
19. Use care when cleaning the louver and the grease
filters. Corrosive cleaning agents, such as lye-based
oven cleaners, may damage the louver and the
grease filters.
20. When flaming food under the hood, turn the fan on.
21. This appliance is suitable for use above both gas and
electric cooking equipment 36” wide or less.
IMPORTANT SAFETY INSTRUCTIONS
ORM_Eng.indd 4ORM_Eng.indd 4 08.2.27 6:23:31 PM08.2.27 6:23:31 PM
E
5
Open the bottom of the carton, bend the carton flaps back and tilt the oven over to rest on plasticfoam
pad. Lift carton off oven and remove all packing materials, WALL and TOP CABINET TEMPLATES. SAVE
THE CARTON AS IT MAY MAKE INSTALLATION EASIER.
1. Remove the feature sticker from the outside of the door, if
there is one.
2. Check to see that there is a WALL TEMPLATE and TOP
CABINET TEMPLATE. Read enclosures and SAVE the Use
and Care Guide.
Check the oven for any damage, such as misaligned or bent
door, damaged door seals and sealing surfaces, broken or
loose door hinges and latches and dents inside the cavity or on
the door. If there is any damage, do not operate the oven and
contact your dealer or ELECTROLUX AUTHORIZED SERVICER.
See Installation Instructions for more details.
UNPACKING AND EXAMING YOUR OVEN
ORM_Eng.indd 5ORM_Eng.indd 5 08.2.27 6:23:31 PM08.2.27 6:23:31 PM
E
6GROUNDING INSTRUCTIONS
Figure 1
Ground
Receptacle
Opening for
Power Cord
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a ground-
ing plug. It must be plugged into a wall receptacle that is properly installed and grounded in accordance
with the National Electrical Code and local codes and ordinances. In the event of an electrical short circuit,
grounding reduces risk of electric shock by providing an escape wire for the electric current.
Improper use of the grounding plug can result in a risk of electric shock.
Electrical Requirements
The oven is equipped with a 3-prong grounding plug. DO
NOT UNDER ANY CIRCUMSTANCES CUT OR REMOVE
THE GROUNDING PIN FROM THE PLUG.
DO NOT USE AN EXTENSION CORD.
The Power Supply Cord and plug must be connected to
a separate 120 Volt AC, 60 Hz, 15 Amp, or more branch
circuit, single grounded receptacle. The receptacle should
be located inside the cabinet directly above the Microwave
Oven mounting location as shown in Figure 1.
NOTES:
1. If you have any questions about the grounding or electri-
cal instructions, consult a qualified electrician or service
person.
2. Neither Electrolux nor the dealer can accept any liability
for damage to the oven or personal injury resulting from
failure to observe the correct electrical connection
procedures.
Radio or TV Interference
Should there be any interference caused by the microwave
oven to your radio or TV, check that the microwave oven is
on a different electrical circuit, relocate the radio or TV as
far away from the oven as feasible or check position and
signal of receiving antenna.
ORM_Eng.indd 6ORM_Eng.indd 6 08.2.27 6:23:31 PM08.2.27 6:23:31 PM
E
7
About Your Oven
This Use and Care Guide is valuable: read it carefully
and always save it for reference.
NEVER use the oven without the turntable and
support nor turn the turntable over so that a large
dish could be placed in the oven. The turntable will
turn both clockwise and counterclockwise.
ALWAYS have food in the Microwave Oven when it
is on to absorb the microwave energy.
When using the oven at power levels below 100%,
you may hear the magnetron cycling on and off. It
is normal for the exterior of the oven to be warm to
the touch when cooking or reheating.
About Microwave Cooking
• Arrange food carefully. Place thickest areas
towards outside of dish.
• Watch cooking time. Cook for the shortest
amount of time indicated and add more as
needed. Food severely overcooked can smoke
or ignite.
• Cover foods while cooking. Check recipe or
cookbook for suggestions: paper towels, wax
paper, microwave plastic wrap or a lid. Cov-
ers prevent spattering and help foods to cook
evenly.
• Shield with small flat pieces of aluminum foil any
thin areas of meat or poultry to prevent over-
cooking before dense, thick areas are cooked
thoroughly.
• Stir foods from outside to center of dish once or
twice during cooking, if possible.
• Turn foods over once during microwaving to
speed cooking of such foods as chicken and
hamburgers. Large items like roasts must be
turned over at least once.
• Rearrange foods such as meatballs halfway
through cooking both from top to bottom and
from the center of the dish to the outside.
• Add standing time. Remove food from oven
and stir, if possible. Cover for standing time
which allows the food to finish cooking without
overcooking.
• Check for doneness. Look for signs indicating
that cooking temperatures have been reached.
Doneness signs include:
- Food steams throughout, not just at edge.
- Center bottom of dish is very hot to the
touch.
- Poultry thigh joints move easily.
- Meat and poultry show no pinkness.
- Fish is opaque and flakes easily with a fork.
INFORMATION YOU NEED TO KNOW
Condensation is a normal part of microwave cook-
ing. Room humidity and the moisture in food will
influence the amount of moisture that condenses in
the oven. Generally, covered foods will not cause as
much condensation as uncovered ones. Ventilation
openings must not be blocked.
The Microwave Oven is for food preparation only. It
should not be used to dry clothes or newspapers.
Your Microwave Oven is rated 1000 watts by using
the IEC Test Procedure. In using recipes or package
directions, check food a minute or two before the
minimum time and add time accordingly.
ORM_Eng.indd 7ORM_Eng.indd 7 08.2.27 6:23:32 PM08.2.27 6:23:32 PM
E
8
Children below the age of 7 should use the
microwave oven with a supervising person very
near to them. Between the ages of 7 and 12, the
supervising person should be in the same room.
The child must be able to reach the oven comfort-
ably; if not, he/she should stand on a sturdy stool.
At no time should anyone be allowed to lean or swing
on the oven door.
About Children and the Microwave
About Safety
• Check foods to see that they are cooked to the
United States Department of Agriculture’s recom-
mended temperatures.
Temp Food
160˚F For fresh pork, ground meat, fish,
seafood, egg dishes and frozen
prepared food.
165˚F For leftover, ready-to-reheat refriger-
ated, deli and carry-out “fresh” food
and boneless white poultry.
170˚F White meat of poultry.
180˚F Dark meat of poultry.
To test for doneness, insert a meat thermometer in
a thick or dense area away from fat or bone. NEVER
leave the thermometer in the food during cooking,
unless it is approved for microwave use.
• ALWAYS use potholders to prevent burns when
handling utensils that are in contact with hot food.
Enough heat from the food can transfer through
utensils to cause skin burns.
• Avoid steam burns by directing steam away from
the face and hands. Slowly lift the farthest edge
of a dish’s covering and carefully open popcorn
and oven cooking bags away from the face.
• Stay near the oven while it’s in use and check
cooking progress frequently so that there is no
chance of overcooking food.
• NEVER use the cavity for storing cookbooks or
other items.
• Select, store and handle food carefully to pre-
serve its high quality and minimize the spread of
foodborne bacteria.
• Keep waveguide cover clean. Food residue can
cause arcing and/or fires.
• Use care when removing items from the oven so
that the utensil, your clothes or accessories do
not touch the safety door latches.
• Keep aluminum foil used for shielding at least
1 inch away from walls, ceiling and door.
INFORMATION YOU NEED TO KNOW
Children should be taught all safety precautions:
use potholders, remove coverings carefully, pay
special attention to packages that crisp food
because they may be extra hot.
Don’t assume that because a child has mastered one
cooking skill he/she can cook everything.
Children need to learn that the microwave oven is
not a toy. See page 27 for Child Lock feature.
ORM_Eng.indd 8ORM_Eng.indd 8 08.2.27 6:23:32 PM08.2.27 6:23:32 PM
E
9
About Food
Food Do Don't
Eggs,
sausages,
nuts, seeds,
fruits &
vegetables
• Puncture egg yolks before cooking to
prevent “explosion”.
• Pierce skins of potatoes, apples,
squash, hot dogs and sausages so
that steam escapes.
• Cook eggs in shells.
• Reheat whole eggs.
• Dry nuts or seeds in shells.
Popcorn • Use specially bagged popcorn for
microwave cooking.
• Listen while popping corn for the
popping to slow to 1 or 2 seconds or
use special popcorn pad.
• Pop popcorn in regular brown bags
or glass bowls.
• Exceed maximum time on popcorn
package.
Baby food • Transfer baby food to small dish and
heat carefully, stirring often. Check
temperature before serving.
• Put nipples on bottles after heating
and shake thoroughly. “Wrist” test
before feeding.
• Heat disposable bottles.
• Heat bottles with nipples on.
• Heat baby food in original jars.
General • Cut baked goods with filling after
heating to release steam and avoid
burns.
• Stir liquids briskly before and after
heating to avoid “eruption”.
• Use deep bowl, when cooking liquids
or cereals, to prevent boilovers.
• Heat or cook in closed glass jars or
air tight containers.
• Can in the microwave as harmful
bacteria may not be destroyed.
• Deep fat fry.
• Dry wood, gourds, herbs or wet
papers.
INFORMATION YOU NEED TO KNOW
ORM_Eng.indd 9ORM_Eng.indd 9 08.2.27 6:23:32 PM08.2.27 6:23:32 PM
E
10
About Utensils and Coverings
The following coverings are ideal:
• Paper towels are good for covering foods for
reheating and absorbing fat while cooking
bacon.
• Wax paper can be used for cooking and
reheating.
• Plastic wrap that is specially marked for micro-
wave use can be used for cooking and reheating.
DO NOT allow plastic wrap to touch food. Vent
so steam can escape.
• Lids that are microwave-safe are a good choice
because heat is kept near the food to hasten
cooking.
• Oven cooking bags are good for large meats or
foods that need tenderizing. DO NOT use metal
twist ties. Remember to slit bag so steam can
escape.
How to use aluminum foil in your Over the Range
Microwave Oven:
• Small flat pieces of aluminum foil placed smoothly
on the food can be used to shield areas that are
either defrosting or cooking too quickly.
• Foil should not come closer than one inch to any
surface of the oven.
Should you have questions about utensils or cover-
ings, check a good microwave cookbook or follow
recipe suggestions.
Accessories
There are many microwave accessories available for
purchase. Evaluate carefully before you purchase
so that they meet your needs. A microwave-safe
thermometer will assist you in determining cor-
rect doneness and assure you that foods have
been cooked to safe temperatures. Electrolux is
not responsible for any damage to the oven when
accessories are used.
It is not necessary to buy all new cookware. Many
pieces already in your kitchen can be used success-
fully in your new Over the Range Microwave Oven.
Make sure the utensil does not touch the interior
walls during cooking.
Use these utensils for safe microwave cooking
and reheating:
• glass ceramic (Pyroceram®), such as
Corningware®.
• heat-resistant glass (Pyrex®)
• microwave-safe plastics
• paper plates
• microwave-safe pottery, stoneware and
porcelain
• browning dish (Do not exceed recommended
preheating time. Follow manufacturer's
directions.)
These items can be used for short time reheating
of foods that have little fat or sugar in them:
• wood, straw, wicker
DO NOT USE
• metal pans and bakeware
• dishes with metallic trim
• non-heat-resistant glass
• non-microwave-safe plastics (margarine
tubs)
• recycled paper products
• brown paper bags
• food storage bags
• metal twist-ties
Should you wish to check if a dish is safe for
microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which
becomes very hot should not be used.
INFORMATION YOU NEED TO KNOW
ORM_Eng.indd 10ORM_Eng.indd 10 08.2.27 6:23:32 PM08.2.27 6:23:32 PM
E
11
1 Microwave oven door with see-through win-
dow
2 Door hinges
3 Waveguide cover:
DO NOT REMOVE.
4 Turntable motor shaft
5 Microwave oven light
It will light when microwave oven is operating or
door is open.
6 Rack holders
7 Safety door latches
The microwave oven will not operate unless the
door is securely closed.
8 Handle
9 Light pad
Touch the light pad once for high, twice for
medium, three times for low and four times to
turn off the light.
(Front of microwave oven)
(Rear of microwave oven)
BOTTOM VIEW
PART NAMES
10 Fan pad
Touch the fan pad once for high speed, twice for
medium speed, three times for low speed and
four times to turn off the fun.
11 Auto-Touch control panel
12 Time display: Digital display, 99 minutes, 99
seconds
13 Ventilation openings
14 Removable turntable
The turntable will rotate clockwise or counter-
clockwise. Only remove for cleaning.
15 Removable turntable support
First, carefully place the turntable support in the
motor shaft in the center of the microwave oven
floor. Then, place the turntable on the turntable
support securely.
16 Rack for 2-level cooking/ reheating
17 Light cover
18 Grease filters
19 Menu label
ORM_Eng.indd 11ORM_Eng.indd 11 08.2.27 6:23:32 PM08.2.27 6:23:32 PM
E
12
Number next to the control panel illustration
indicates pages on which there are feature descriptions and usage information.
Words in the lower portion of the display will light to indicate what function is in progress.
CONTROL PANEL
18
18
-
19
19
18
-
19 24
24
24
14
14
14
29
29
29 29
29
29
29
29
29 13
13
13 27-28
27-28
27-28 28
28
28
29
29
29
13
25
25
25 26
26
26
29
29
29
22 2320-2118-191816
ORM_Eng.indd 12ORM_Eng.indd 12 08.2.27 6:23:33 PM08.2.27 6:23:33 PM
E
13
• Before operating your new oven make sure you
read and understand this Use and Care Guide
completely.
• Before the Over the Range Microwave Oven can
be used, follow these procedures:
1. Plug in the oven. Close the door. The oven display
will show ENJOY YOUR OVEN TOUCH CLEAR
AND TOUCH CLOCK.
2. Touch the STOP/CLEAR pad. : will
appear.
3. Set clock. See below.
To Set the Clock
• Suppose you want to enter the correct time of
day 12:30 (A.M or P.M.).
Procedure
Step Touch
1. Touch the set clock pad. set
clock
2. Enter the correct time
of day by touching the
numbers in sequence.
12
30
3. Touch the set clock pad
again.
set
clock
This is a 12 hour clock. If you attempt to enter an
incorrect clock time, ERROR will appear in the
display. Touch the STOP/CLEAR pad and re-set
the clock.
• If the electrical power supply to your microwave
oven should be interrupted, the display will
intermittently show after the power is reinstated.
If this occurs during cooking, the program will
be erased. The time of day will also be erased.
Simply touch STOP/CLEAR pad and reset the
clock for the correct time of day.
NOTE
Your Over the Range Microwave Oven can
be programmed with the door open except for
START add 30 sec, popcorn, fresh veggies,
frozen veggies, baked potato and sensor
reheat.
Stop/Clear
Touch the STOP/CLEAR to:
1. Erase if you make a mistake during programming.
2. Cancel timer.
3. Stop the oven temporarily during cooking.
4. Return the time of day to the display.
5. Cancel a program during cooking, touch twice.
BEFORE OPERATING
ORM_Eng.indd 13ORM_Eng.indd 13 08.2.27 6:23:33 PM08.2.27 6:23:33 PM
E
14
• Suppose you want to defrost for 5 minutes at
30%.
Procedure
Step Touch
1. Enter defrosting time. 005
2. Touch the power level
pad eight times to enter a
power level of 30%.
power
level x 8
3. Touch the START
add 30 sec pad.
START
add 30 sec
When the defrost time is complete, cooking comple-
tion signal will sound and END will appear in the
display.
Using the Rack
The rack allows several foods to be cooked or
reheated at one time. However, for the best cooking
and reheating, use Turntable ON function and cook
with SENSOR MODES or AUTO MODES without
the rack. When the rack is used, set time and
power level manually. Allow plenty of space around
and between the dishes. Pay close attention to the
cooking and reheating progress. Reposition the
foods and reverse them from the rack to turntable
and/or stir them at least once during any cooking
or reheating time. After cooking or reheating, stir
if possible. Using a lower power level will assist in
better cooking and reheating uniformity.
Avoid:
• Storing the rack in the microwave oven when not
in use.
• Popping popcorn with the rack in the microwave
oven.
• Using any browning dish on the rack.
• Using SENSOR MODES and AUTO MODES with
the rack.
• Cooking directly on the rack—use microwave-
safe cookware.
NOTE
Turntable ON/OFF function can be used in
Manual Operation. See page 29.
MANUAL OPERATION
Time Cooking
Your Over the Range Microwave Oven can be
programmed for 99 minutes 99 seconds (99.99).
Always enter the seconds after the minutes, even if
they are both zeros.
• Suppose you want to cook for 5 minutes at
100%.
Procedure
Step Touch
1. Enter cooking time. 005
2. Touch the START
add 30 sec pad.
START
add 30 sec
To Set Power Level
There are eleven preset power levels.
Using lower power levels increases the cooking time
which is recommended for foods such as cheese,
milk and long slow cooking of meats. Consult cook-
book or recipes for specific recommendations.
Touch power
level pad number
of times for
desired power
Approx.
Percentage
of power
Common
words for
power
levels
power level x 1 100% High
power level x 2 90%
power level x 3 80%
power level x 4 70% Medium
High
power level x 5 60%
power level x 6 50% Medium
power level x 7 40%
power level x 8 30% Med Low/
Defrost
power level x 9 20%
power level x 10 10% Low
power level x 11 0%
ORM_Eng.indd 14ORM_Eng.indd 14 08.2.27 6:23:33 PM08.2.27 6:23:33 PM
E
15
MANUAL OPERATION
The sensor is a semi-conductor device that detects
the vapor (moisture and humidity) emitted from the
food as it heats. The sensor adjusts the cooking
times and power level for various foods and
quantities.
Using Sensor Settings:
1. After oven is plugged in, wait 2 minutes before
using Sensor Settings.
2. Be sure the exterior of the cooking container
and the interior of the oven are dry. Wipe off any
moisture with a dry cloth or paper towel.
3. The oven works with foods at normal storage
temperature. For example, popcorn would be at
room temperature.
4. Any Sensor Settings selection can be pro-
grammed with More or Less Time Adjustment.
See page 28.
5. More or less food than the quantity listed in the
chart should be cooked following the guidelines
in any microwave cookbook.
6.
During the first part of SENSOR MODES, food
name will appear on the display. Do not open
the oven door or touch STOP/CLEAR during
this part of the cycle. The measurement of vapor
will be interrupted. If this occurs, an error mes-
sage will appear. To continue cooking, touch the
STOP/CLEAR pad and cook manually.
When the sensor detects the vapor emitted from
the food, remainder of cooking time will appear.
Door may be opened when remaining cooking
time appears on the display. At this time, you
may stir or season food, as desired.
7. If the sensor does not detect vapor properly
when popping popcorn, the oven will turn off,
and the correct time of day will be displayed. If
the sensor does not detect vapor properly when
cooking other foods, ERROR will be displayed,
and the oven will turn off.
8. Check food for temperature after cooking. If
additional time is needed, continue to cook
manually.
9. Each food has a cooking hint. Touch user pref
pad when the HELP indicator is lighted in the
display.
Covering Foods:
Some foods cook better when covered. Use the
cover recommended in the food charts.
1. Casserole lid.
2. Plastic wrap: Use plastic wrap recommended for
microwave cooking. Cover dish loosely; allow
approximately 1/2 inch to remain uncovered to
allow steam to escape. Plastic wrap should not
touch food.
3. Wax paper: Cover dish completely; fold excess
wrap under dish to secure. If dish is wider than
paper, overlap two pieces at least one inch
to cover.
Be careful when removing any covering to allow
steam to escape away from you.
SENSOR MODES
Manual Defrost
If the food that you wish to defrost is not listed on
the Defrost chart or is above or below the limits in
the Amount column on the Defrost chart (see page
26), you need to defrost manually.
You can defrost any frozen food, either raw or
previously cooked, by using Power Level for 30%
Follow the exact 3-step procedure found under To
set power level. Estimate defrosting time and touch
power level pad eight times for 30% power.
For either raw or previously cooked frozen food the
rule of thumb is approximately 4 minutes per pound.
For example, defrost 4 minutes for 1 pound of frozen
spaghetti sauce.
Always stop the oven periodically to remove or
separate the portions that are defrosted. If food is
not defrosted at the end of the estimated defrosting
time, program the oven in 1 minute increments on
power level 30% until totally defrosted.
When using plastic containers from the freezer,
defrost only long enough to remove from the plastic
in order to place in a microwave-safe dish.
ORM_Eng.indd 15ORM_Eng.indd 15 08.2.27 6:23:34 PM08.2.27 6:23:34 PM
E
16
Sensor Cook
There are 5 foods (frozen entrees, ground meat,
rice, flash/seafood, and chicken breast) under the
SENSOR COOK that uses the sensor.
You can cook many foods by touching the sensor
cook pad and the food number. You don’t need to
calculate cooking time or power level.
• Suppose you want to cook Frozen Entrees.
Procedure
Step Touch
1. Touch the sensor
cook pad, number 1
for Frozen Entrees.
sensor
cook
1
2. At end, follow the directions in the display.
3. Touch the START add
30 sec pad.
START
add 30 sec
SENSOR MODES
SENSOR MODES has 6 functions, such as Sensor
Cook, popcorn, fresh veggies, frozen veggies, baked
potato and sensor reheat.
NOTES
1. SENSOR MODES can be programmed with
More or Less Time Adjustment. Touch the
power level pad once or twice before cook-
ing is started. See page 28.
2. Each food has a cooking hint. Touch the user
pref pad when the HELP indicator is lighted
in the display.
3. Should you attempt to enter more or less
than the allowed amount, an error message
will appear in the display.
More or less than the quantity listed in the
chart should be cooked following the guide-
lines in any microwave cookbook.
4. The final cooking result will vary according
to the food condition (e.g. initial temperature,
shape, quality). Check food for temperature
after cooking. If additional time is needed,
continue to cook manually.
5. When sensor detects the vapor emitted from
the foods, manipulation message or remain-
ing cooking time will be displayed.
6. Stay near the oven while it’s in use and check
cooking progress frequently so that there is
no chance of overcooking food.
ORM_Eng.indd 16ORM_Eng.indd 16 08.2.27 6:23:34 PM08.2.27 6:23:34 PM
E
17
SENSOR MODES
Sensor Cook chart
Food Amount Procedure
1. Frozen Entrees*6 - 17 oz
0.17 - 0.48 kg
Use this pad for frozen, convenience foods. It will give
satisfactory results for most brands. You may wish to try
several and choose your favorite. Remove package from
outer wrapping and follow package directions for covering.
After cooking, let stand, covered for 1 to 3 minutes.
2. Ground Meat*0.25 - 2.0 lb
0.2 - 0.9 kg
Use this setting to cook ground beef or turkey as patties
or in a casserole to be added to other ingredients. Place
patties on a microwave-safe rack and cover with wax paper.
Place ground meat in a casserole and cover with wax paper
or plastic wrap. When oven stops, turn patties over or stir
meat in casserole to break up large pieces. Re-cover and
touch the START add 30 sec pad. After cooking, let stand,
covered, for 2 to 3 minutes.
3. Rice*0.5 - 2.0 cups
Place rice into a deep casserole dish and add double quantity of
water. Cover with lid or plastic wrap. After cooking, stir, cover and
let stand 3 to 5 minutes or until all liquid has been absorbed.
Rice Water Size of casserole dish
.5 cup 1 cup 1.5 quart
1 cup 2 cups 2 quart
1.5 cups 3 cups 2.5 or 3 quart
2 cups 4 cups 3 quart or larger
4. Fish/Seafood*0.25 - 2.0 lb
0.2 - 0.9 kg
Arrange in ring around shallow glass dish (roll fillet with
edges underneath). Cover with plastic wrap. After cooking,
let stand, covered, 3 minutes.
5. Chicken Breast*0.5 - 2.0 lb
0.3 - 0.9 kg
Cover with vented plastic wrap. When oven stops, turn over.
Shield with small, flat pieces of aluminum foil any areas that
are cooking too rapidly. Re-cover and touch the START add
30 sec pad. After cooking, let stand, covered 3 to 5 minutes.
Chicken should be 160˚F.
* It is not necessary to enter amount.
ORM_Eng.indd 17ORM_Eng.indd 17 08.2.27 6:23:34 PM08.2.27 6:23:34 PM
E
18
• Suppose you want to reheat soup.
Procedure
Step Touch
Touch the sensor reheat pad
for soup.
sensor
reheat
• Suppose you want to cook popcorn.
Procedure
Step Touch
<Regular>
Touch the popcorn pad once.
<Snack>
Touch the popcorn pad twice.
pop
corn
pop
corn
x2
NOTES
1. Fresh veggies is same procedure for popcorn and can be selected by touching the pad once or
twice depending on Soft or Hard. See Fresh Veggies chart on page 19.
2. Frozen veggies, baked potato are same procedure for sensor reheat. Follow the above procedure.
3. The popcorn, fresh veggies, frozen veggies, baked potato and sensor reheat can only be accepted
within 3 minutes after cooking, opening and closing the door or touching the STOP/CLEAR pad to
prevent from misusing.
4. Cooking can be also started by touching the START add 30 sec pad within 2 seconds after touching
the START add 30 sec pad.
Popcorn/Fresh Veggies/Frozen Veggies/Baked Potato/
Sensor Reheat
Popcorn chart
Food Amount Procedure
Popcorn 1 package
Regular: 3.0 - 3.5 oz,
0.085 kg - 0.1 kg
Snack:
1.5 - 1.75 oz,
0.045 kg - 0.05 kg
Use only popcorn packaged for the microwave. Try several
brands to decide which you like. Do not try to pop unpopped
kernels. The amount is selected by pressing the pad once
(Regular) or twice (Snack).
SENSOR MODES
ORM_Eng.indd 18ORM_Eng.indd 18 08.2.27 6:23:35 PM08.2.27 6:23:35 PM
E
19
Sensor Reheat chart
Food Amount Procedure
Sensor Reheat*4 - 36 oz
0.12 - 1.0 kg
Place in dish or casserole slightly larger than amount to be
reheated. Flatten, if possible. Cover with lid, plastic wrap
or wax paper. Use covers such as plastic wrap or lids with
larger quantities of more dense foods such as stews. After
reheating, stir well, if possible. Re-cover and allow to stand
2 to 3 minutes. Foods should be very hot. If not, continue to
heat with variable power and time.
* It is not necessary to enter amount or number.
SENSOR MODES
Fresh Veggies chart
Food Amount Procedure
1. Fresh Vegetables, soft
Broccoli
Brussels sprouts
Cabbage
Cauliflower (flowerets)
Cauliflower (whole)
Spinach
Zucchini
Baked apples
0.25 - 2.0 lb, 0.2 - 0.9 kg
0.25 - 2.0 lb, 0.2 - 0.9 kg
0.25 - 2.0 lb, 0.2 - 0.9 kg
0.25 - 2.0 lb, 0.2 - 0.9 kg
0.25 - 2.0 lb, 0.2 - 0.9 kg
1 medium
0.25 - 1.0 lb, 0.2 - 0.45 kg
0.25 - 2.0 lb, 0.2 - 0.9 kg
2 - 4 medium
Wash and place in casserole. Add no water if veg-
etables have just been washed. Cover with lid for
tender vegetables. Use plastic wrap for tender-crisp
vegetables. Touch the fresh veggies pad once.
After cooking, stir, if possible. Let stand, covered,
for 2 to 5 minutes.
2. Fresh Vegetables, hard
Carrots, sliced
Corn on cob
Green beans
Winter squash
- diced
- halves
0.25 - 2.0 lb, 0.2 - 0.9 kg
0.25 - 1.5 lb, 0.2 - 0.6 kg
2 - 4 pcs.
0.25 - 1.5 lb, 0.2 - 0.6 kg
0.25 - 1.5 lb, 0.2 - 0.6 kg
1 - 2
Place in casserole. Add 1-4 tbsp. water. Cover with
lid for tender vegetables. Use plastic wrap cover for
tender-crisp vegetables. Touch the fresh veggies
pad twice. After cooking, stir, if possible. Let stand,
covered, for 2 to 5 minutes.
Frozen Veggies chart
Food Amount Procedure
Frozen Veggies*0.25 - 1.25 lb
0.2 - 0.5 kg
Add no water. Cover with lid or plastic wrap. After cooking,
stir and let stand, covered, for 3 minutes.
* It is not necessary to enter amount or number.
Baked Potato chart
Food Amount Procedure
Baked Potato*1 - 8 med. Pierce with fork in several places. Place on paper towel on
turntable. After cooking, remove from oven and let stand
wrapped in foil for 5 to 10 minutes.
* It is not necessary to enter amount or number.
ORM_Eng.indd 19ORM_Eng.indd 19 08.2.27 6:23:35 PM08.2.27 6:23:35 PM
E
20
Food Amount Procedure
1. Frozen
Breakfast*3 -6 oz
0.085 - 0.17 kg
This setting works well for frozen breakfast entrees, pancakes, waffles,
burritos etc. Follow manufacturer’s directions for how to prepare for
microwaving. Allow to stand 1 or 2 minutes after cooking.
2. Scrambled
Eggs
1 - 8 eggs
For each egg, use 1 teaspoon of butter or margarine and 1 tablespoon of
milk. Place butter or margarine in dish, measuring cup or casserole large
enough for the egg to expand. Mix egg and milk together. Pour on to butter
or margarine in dish. Cover with wax paper. Place in oven and program.
Touch number 2 to increase quantity and touch the START add 30 sec pad.
When oven stops, stir egg mixture moving the cooked portion to the center
of the dish, uncooked portion to the outside, close the door and touch the
START add 30 sec pad. After cooking, stir and let stand, covered, until set.
Note that eggs will be slightly undercooked when removed from the oven.
3. Hot Cereal 1- 6 servings
Use individual packets or bulk cereal in your favorite variety: oatmeal, oat
bran, cream of wheat, farina or wheatena. Follow package directions for the
correct amount of water or milk. To prevent boilovers, it is very important
to choose a large container because microwave cooking of cereal causes
high boiling. Touch number 3 to increase quantity and touch the START
add 30 sec pad. When oven stops, stir and touch the START add 30 sec
pad. After cooking, stir and let stand, covered, for 2 minutes.
4. Soup 1 - 8 cups Place in bowl or casserole. Cover with lid or plastic wrap. Touch number
4 to increase quantity and touch the START add 30 sec pad. At end,
stir, recover and let stand 1 to 3 minutes.
* It is not necessary to enter amount or number.
AUTO MODES has 6 functions, such as auto cook, keep
warm, melt/soften, snacks, auto reheat and auto defrost.
NOTES
1.
AUTO MODES except keep warm can be pro-
grammed with More or Less Time Adjustment.
Touch the power level pad once or twice
before cooking is started. See page 28.
2. Each food has a cooking hint. Touch the user
pref pad when the HELP indicator is lighted
in the display for a helpful hint.
Auto Cook
Auto cook is divided into 2 parts, Quick Meal (frozen break-
fast, scrambled eggs, hot cereal, soup) and Dinner Recipes
(yellow rice & chicken, dressed-up meat loaf, herb roast
pork, creamy seafood pasta and orzo vegetarian medley).
• Suppose you want to cook hot cereal for 1 serv-
ing with Less Time Adjustment.
Procedure
Step Touch
1. Touch the auto cook
pad, number 3
for hot cereal.
auto
cook
3
AUTO MODES
2. Repeat touching same
number pad at Step 1
to increase quantity.
Ex: 1 serving.
3
x1
3. Touch the power level
pad twice for Less Time
Adjustment.
power
level
x2
4. Touch the START add
30 sec pad.
START
add 30 sec
5.
Midway through the cooking, cooking stop melody will
be heard and your oven will stop. Open the door, follow
the instruction shown in the display and close the door.
6. Touch the START add
30 sec pad to
continue cooking.
START
add 30 sec
NOTES
1. Skip Step 3, when More or Less Time Adjust-
ment is not needed.
2.
Scrambled eggs, hot cereal and soup are same
procedure. Follow the above procedure.
3. Frozen breakfast is not needed to enter
amount or number. Skip Step 2.
4.
If mute is set, the melody will not be heard at Step
5. See 2, Audible Signal Elimination on page 27.
Auto Cook chart
ORM_Eng.indd 20ORM_Eng.indd 20 08.2.27 6:23:35 PM08.2.27 6:23:35 PM
E
21
AUTO MODES
Dinner recipes (recipes serve 6)
5. YELLOW RICE AND CHICKEN
Place in a 3 quart casserole:
1 package (5 - 8 ounces) yellow rice mix
with flavor packet
2 cups chicken broth
Stir well and cover. Touch the auto cook pad,
number 5 and touch the START add 30 sec pad.
At pause, stir well and add:
1 cup frozen peas
1 red pepper, diced
11/4 pounds boneless chicken cutlets,
sliced into thin strips
Re-cover. Touch the START add 30 sec pad.
At end, garnish with parsley.
6. DRESSED-UP MEAT LOAF
Mix together well:
11/2 pounds lean ground beef
1/2 cup soft bread crumbs
1/2 cup red wine
1 egg, beaten
2 tablespoons chopped onion
1/2 teaspoon salt
1/2 teaspoon dry mustard
1/4 teaspoon pepper
1 teaspoon instant beef bouillon
2 tablespoons chopped green pepper
Place in a 9 x 5-inch glass loaf dish.
Touch the auto cook pad, number 6 and touch the
START add 30 sec pad.
If desired, spread top of meat loaf with 1/2 cup catsup
during last 2 minutes of cooking time.
At end, remove from oven, cover with foil and allow
to stand 3 to 5 minutes before serving.
7. HERB ROAST PORK
Combine in small dish:
1 tablespoon butter, melted
2 cloves garlic, minced
1 teaspoon dried marjoram leaves, crushed
1/2 teaspoon dried oregano leaves, crushed
1/2 teaspoon pepper
Stir well. Brush on:
1 (3 pound) boneless, pork loin, center cut
Place loin in a 13 x 9 x 2-inch casserole. Cover with
vented plastic wrap.
Touch the auto cook pad, number 7 and touch the
START add 30 sec pad.
8. CREAMY SEAFOOD PASTA
Place in a 3 quart casserole:
8 - 9 ounces fresh tortellini
2 cups water
Stir well and cover. Touch the auto cook pad,
number 8 and touch the START add 30 sec pad.
At pause, stir well and add:
1 jar (17 ounces) creamy Alfredo sauce or
13/4 cups of medium, white cheese sauce
11/4 pounds combination raw shellfish,
fresh or thawed (shrimp, bay scallops,
crabmeat)
3 cups mixed, fresh vegetables (sliced
mushrooms, thinly julienned carrots,
green beans)
Re-cover. Touch the START add 30 sec pad.
At end, garnish with:
1/3 cup grated Parmesan cheese
9. ORZO VEGETARIAN MEDLEY
Place in a 3 quart casserole:
1 cup orzo or other tiny shaped pasta
31/2 cups vegetable or chicken broth
1/4 cup pesto sauce (fresh or reconstituted
from dry)
1/2 cup small pieces of sundried tomatoes
1 tablespoon minced garlic
1 tablespoon Italian seasoning
Stir well and cover. Touch the auto cook pad,
number 9 and touch the START add 30 sec pad.
At pause, stir well and add:
3 cups chopped green, red, orange or yel-
low peppers
1 onion, thinly sliced
1 can (14 ounces) artichoke hearts, drained
and quartered
1 can (3 ounces) pitted, ripe olives, drained
and halved
Re-cover. Touch the START add 30 sec pad.
At end, stir and garnish top with:
1/2 cup freshly shredded Parmesan cheese
1/4 cup pine nuts
ORM_Eng.indd 21ORM_Eng.indd 21 08.2.27 6:23:35 PM08.2.27 6:23:35 PM
E
22 AUTO MODES
Keep warm allows you to keep food warm for
30 minutes at the maximum.
Direct use
• Suppose you want to keep a cup of soup warm
for 30 minutes.
Procedure
Step Touch
1. Touch the keep warm
pad.
keep
warm
2. Enter the desired time.
Ex : 30 minutes.
3
0
0
0
3. Touch the START add
30 sec pad.
START
add 30 sec
The oven will start. The display will show 30.00 and
count down. KEEP WARM will be displayed every
10 seconds during the countdown.
You can program Keep warm with manual cooking
to keep food warm continuously after cooking.
With manual cooking
• Suppose you want to cook a cup of soup for
2 minutes at 70% and keep the soup warm for
15 minutes.
Procedure
Step Touch
1. Enter cooking time. 2
0
0
2. Touch the power level
pad 4 times for 70%
power.
power
level x 4
3. Touch the keep warm
pad.
keep
warm
4. Enter the desired time
by touching the number
pads 1, 5, 0 and 0 for
15 minutes.
1
5
0
0
5. Touch the START add
30 sec pad.
START
add 30 sec
The operation will start. When the cooking time is
complete, cooking completion melody will sound
and Keep warm will start. KEEP WARM will appear
in the display every 10 seconds and count down
for 15 minutes.
NOTES
1. Keep warm cannot be programmed in
conjunction with SENSOR MODES or AUTO
MODES.
2. Keep warm can be used in conjunction with
sequence cooking in Auto Start function. See
Auto Start on page 27.
3. Turn table ON/OFF function can be used in
keep warm. See page 29.
Keep Warm
ORM_Eng.indd 22ORM_Eng.indd 22 08.2.27 6:23:36 PM08.2.27 6:23:36 PM
E
23
AUTO MODES
Melt, soften automatically compute the correct
heating time and microwave power level for melting
and softening foods shown in the chart.
There are 4 foods (butter, chocolate, ice cream and
cream cheese) under the melt, soften.
• Suppose you want to melt 1 square of chocolate
with More Time Adjustment.
Procedure
Step Touch
1. Touch the melt, soften
pad once, number 2 for
chocolate.
melt,
soften
2
2. Repeat touching same
number pad at Step 1 to
select quantity.
Ex: Touch number 2 two
more times for 1 square.
2
x 2
3. Touch the START add
30 sec pad.
START
add 30 sec
Melt, Soften chart
Food Amount Procedure
Melt
1. Butter
2. Chocolate
2 tbsp
1/2 cup
1 cup chips
1 square
Use a Pyrex measuring cup. Cover with plastic wrap. Stir after cooking.
After touching the melt, soften pad, touch number 1 two times for 2 tbsp.
After touching the melt, soften pad, touch number 1 three times for 1/2 cup.
After touching the melt, soften pad, touch number 2 two times for 1 cup chips.
After touching the melt, soften pad, touch number 2 three times for 1 square.
Soften
3. Ice cream
4. Cream
cheese
1 pint
1/2 gallon
3 oz, 0.085 kg
8 oz, 0.225 kg
DO NOT COVER.
After touching the melt, soften pad, touch number 3 two times for 1 pint.
After touching the melt, soften pad, touch number 3 three times for 1/2 gallon.
Use a small plate. DO NOT COVER.
After touching the melt, soften pad, touch number 4 two times for 3 oz
or 0.085 kg.
After touching the melt, soften pad, touch number 4 three times for 8 oz
or 0.225 kg
.
NOTES
1. To melt, soften other food or foods except the
quantity listed in the melt, soften, use manual
operation.
2. Skip Step 2, if More Time Adjustment is not
needed.
3. Butter, chocolate, ice cream and cream
cheese are same procedure. Follow the
procedure on the left side.
Melt, Soften
ORM_Eng.indd 23ORM_Eng.indd 23 08.2.27 6:23:36 PM08.2.27 6:23:36 PM
E
24 AUTO MODES
Snacks
Snacks are for cooking/heating foods that take a
short amount of time!
There are 7 foods (frozen mw pizza, hand held snacks
(3-4 oz / 0.085-0.113 kg), hand held snacks (5-6 oz /
0.142-0.17 kg), chicken nuggets, hot dogs, frozen kind's
meal and pizza) under the snacks.
•
Suppose you want to reheat a slice of pizza with snacks.
Procedure
Step Touch
1. Touch the snacks pad
and number 7 for pizza. snacks
7
2. Repeat touching same
number pad at Step 1
to increase quantity.
7
x1
3. Touch the START add
30 sec pad.
START
add 30 sec
Snacks chart
Food Amount Procedure
1. Frozen MW
Pizza*
6 - 8 oz
0.17 - 0.225 kg
Use for frozen microwave pizza. Remove from package and unwrap. Fol-
low package directions for use of package and/or silver crisping disk.
2. Hand Held
Snacks*
3 - 4 oz
0.085 - 0.113 kg
Use for frozen French fries, cheese sticks, appetizers etc. Remove from
outer package. Follow package directions for how to wrap or cover. Be
careful when removing from the oven as snack may be very hot.
3. Hand Held
Snacks*
5 - 6 oz
0.142 - 0.17 kg
Use for frozen French fries, cheese sticks, appetizers etc. Remove from
outer package. Follow package directions for how to wrap or cover. Be
careful when removing from the oven as snack may be very hot.
4. Chicken
Nuggets
0.3 - 1.0 lb
0.2 - 0.4 kg
Place frozen chicken nuggets on a flat plate allowing space between each. It is not necessary
to cover them. When oven stops, rearrange and touch the START add 30 sec pad.
5. Hot Dogs 1 - 6 pieces Place hot dog in bun. Wrap each with paper towel or napkin. Touch num-
ber 5 to increase quantity and touch the START add 30 sec pad.
6. Frozen Kid's
Meal*
6 - 8 oz
0.17 - 0.225 kg
Use this pad for frozen, convenience foods. It will give satisfactory results
for most brands. You may wish to try several and choose your favorite.
Remove package from outer wrapping and follow package directions
for covering. After cooking, let stand, covered for 1 to 3 minutes.
7. Pizza 1 - 6 slices Use this setting to reheat refrigerated leftover pizza, 1 slice is approxi-
mately 1/8th of a 12-inch pizza or 1/12th of a 16-inch pizza. If possible,
place on paper towel on a microwave-safe rack. Touch number 7 to
increase quantity and touch the START add 30 sec pad.
* It is not necessary to enter amount.
• Suppose you want to heat 0.3 pound or 0.3
kilogram chicken nuggets with snacks.
Procedure
Step Touch
1. Touch the snacks
pad and number 4 for
chicken nuggets.
snacks
4
2.
Enter amount by touch-
ing the number 3.
Ex: 0.3 lb or 0.3 kg
chicken nuggets.
3
3. Touch the START add
30 sec pad.
START
add 30 sec
NOTES
1. Above other 6 foods except chicken nuggets
under the snacks is same procedure. Follow
the procedure on the left side.
2. When 1.0 pound chicken nuggets is heated,
touch number 1 and 0 at Step 2.
3. Frozen mw pizza, hand held snacks and
Frozen Kid's Meal are not needed to enter
amount or number. Skip Step 2.
ORM_Eng.indd 24ORM_Eng.indd 24 08.2.27 6:23:36 PM08.2.27 6:23:36 PM
E
25
AUTO MODES
There are 4 foods (fresh rolls/muffins, frozen
rolls/muffins, pasta and beverage) under the auto
reheat.
• Suppose you want to reheat 2 fresh muffins with
auto reheat.
Procedure
Step Touch
1. Touch the auto
reheat pad and num-
ber 1 for fresh muffin.
auto
reheat
1
2.
Repeat touching same
number pad at Step 1
to increase quantity.
Ex : 2 muffins.
1
x2
3. Touch the START add
30 sec pad.
START
add 30 sec
NOTES
1. Auto reheat can be programmed with More or
less time adjustment. See page 28.
2. Fresh rolls/muffins, frozen rolls/muffins, pasta
and beverage are same procedure. Follow the
left side procedure.
Auto Reheat
Auto Reheat chart
Food Amount Procedure
1. Fresh Rolls/
Muffins
1 - 10 pieces Use this pad to warm rolls, muffins, biscuits, bagels etc. Large items
should be considered as 2 or 3 regular size. Arrange on plate; cover
with paper towel. For refrigerated rolls or muffins, it may be necessary
to double the entered amount to ensure the proper serving temperature.
For example, enter quantity of 2 for 1 refrigerated muffin. Touch the
auto reheat pad and number 1 to increase quantity and touch the
START add 30 sec pad.
2. Frozen Rolls/
Muffins
1 - 10 pieces Use this pad to warm rolls, muffins, biscuits, bagels etc. Large items
should be considered as 2 or 3 regular size. Arrange on plate; cover
with paper towel. Touch the auto reheat pad and number 2 to increase
quantity and touch the START add 30 sec pad.
3. Pasta 1 - 6 cups
Use this pad to reheat refrigerated canned or homemade pasta with sauce.
For room temperature pastas, use Less option. Pasta without sauce
double the quantity per setting. For example, measure 2 cups of cooked
noodles and program for 1 cup. Cover with lid or plastic wrap. Touch the
auto reheat pad, number 3 to increase quantity and touch the START
add 30 sec pad. After cooking, let stand, covered, 2 to 3 minues.
4. Beverage 0.5 - 2.0 cups This setting is good for restoring a cool beverage to a better drinking
temperature. Stir liquid briskly before and after heating to avoid "erup-
tion". Touch the auto reheat pad, number 4 to increase quantity and
touch the START add 30 sec pad.
ORM_Eng.indd 25ORM_Eng.indd 25 08.2.27 6:23:37 PM08.2.27 6:23:37 PM
E
26
Auto Defrost chart
Food Amount Procedure
1. Ground Meat 0.5 - 3.0 lb
0.3 - 1.3 kg
Remove any thawed pieces after each stage. Let stand, covered, for
5 to 10 minutes.
2. Steaks/Chops/
Fish
0.5 - 4.0 lb
0.3 - 1.8 kg
After each stage, rearrange and if there are warm or thawed portions,
shield with small flat pieces of aluminum foil. Remove any meat or fish
that is almost defrosted. Let stand, covered, for 10 to 20 minutes.
3. Chicken Pieces 0.5 - 3.0 lb
0.3 - 1.3 kg
After each stage, rearrange pieces or remove portions should they
become warm or thawed. Let stand, covered, for 10 to 20 minutes.
4. Roast 2.0 - 4.0 lb
1.0 - 1.8 kg
Start defrosting with fat side down. After each stage, turn roast over
and shield the warm portions with aluminum foil. Let stand, covered,
for 30 to 60 minutes.
5. Casserole 2 - 6 cups After audible signal, stir if possible. At end, stir well and let stand,
covered, for 5 to 10 minutes.
6. Soup 1 - 6 cups After audible signal, stir if possible. At end, stir well and let stand,
covered, for 5 to 10 minutes.
AUTO MODES
Auto Defrost
There are 6 foods (ground meat, stakes/chops/fish,
chicken pieces, roast, casserole and soup) under
the auto defrost.
Auto defrost automatically defrosts all the foods
found in the Defrost chart below.
• Suppose you want to defrost a 1.8 pound or 1.8
kilogram steak.
Procedure
Step Touch
1.
Touch the auto defrost pad
and number 2 for steak.
auto
defrost
2
2. Enter weight by touching
number 1 and 8.
Ex: 1.8 lb or 1.8 kg steak.
1
8
3. Touch the START add 30
sec pad.
START
add 30 sec
4. Midway through the cook-
ing, cooking stop melody
will be heard and your
oven will stop. Open the
door, follow the instruction
shown in the display and
close the door. Touch the
START add 30 sec pad.
START
add 30 sec
After defrost cycle ends, let stand, covered.
NOTES
1.
To defrost other food or foods above or below the
weights allowed on the Defrost chart, use time and
30% power. See Manual defrost on page 15.
2.If you attempt to enter more or less than the
amount as indicated in the chart below, an
error message will appear in the display.
3. Check foods when your oven stops. After final
stage, small sections may still be icy. Let stand
to continue thawing. Do not defrost until all ice
crystals are thawed.
4. If mute is set, the melody will not be heard at
Step 4. See 2, Audible Signal Elimination on
page 27.
5. Shielding prevents cooking from occurring
before the center of the food is defrosted. Use
small smooth strips of aluminum foil to cover
edges and thinner sections of the food.
6. Touch number 5 to enter 0.5 pound or 0.5
kilogram at Step 2.
7. Touch desired number for casserole and soup
at Step 2.
ORM_Eng.indd 26ORM_Eng.indd 26 08.2.27 6:23:37 PM08.2.27 6:23:37 PM
E
27
CONVENIENT FEATURES
User Pref
User pref provides 4 features that make using
your oven easy because specific instructions are
provided in the interactive display.
1. Child Lock
The Child Lock prevents unwanted oven operation
such as by small children. The oven can be set so
that the control panel is deactivated or locked. To
set, touch the user pref pad, the number 1 and then
touch the START add 30 sec pad. Should a pad be
touched, LOCKED will appear in the display.
To cancel, touch the user pref pad and the START
add 30 sec pad. Child Lock will not be canceled if
other pads except the START pad are touched after
touching the user pref pad.
2. Audible Signal Elimination
If you wish to have the oven operate with no audible
signals, touch the user pref pad, number 2 and the
STOP/CLEAR pad.
To cancel and restore the audible signal, touch the user
pref pad, number 2 and the START add 30 sec pad.
3. Auto Start
If you wish to program your oven to begin cooking
automatically at a designated time of day, follow
this procedure:
• Suppose you want to start cooking a stew for
20 minutes on 50% and set keep warm 15 min-
utes at 4:30. Before setting, check to make sure
the clock is showing the correct time of day.
Procedure
Step Touch
1. Touch the user pref pad. user
pref
2. Touch number 3. 3
3. Enter the start time.
Ex : 4:30
4
3
0
4. Touch the set clock pad. set
clock
Procedure
Step Touch
5. Enter cooking time.
Ex : 20 minutes
2
0
0
0
6. Touch the power level
pad six times for 50%
power.
power
level x 6
7. Touch the keep warm
pad.
keep
warm
8. Enter desired time.
Ex : 15 minutes
1
5
0
0
9. Touch the START add 30
sec pad.
START
add 30 sec
NOTES
1. Auto Start can be used for manual cook-
ing and keep warm set in conjunction with
sequence cooking if clock is set.
2. If the oven door is opened after program-
ming Auto Start, it is necessary to touch the
START add 30 sec pad for Auto Start time
to appear in the display so that the oven will
automatically begin programmed cooking at
the chosen Auto Start time.
3. Be sure to choose foods that can be left in the
oven safely until the Auto Start time. Acorn or
butternut squash are often a good choice.
4. If you wish to know the time of day, simply
touch the set clock pad. As long as your finger
is touching the set clock pad, the time of day
will be displayed.
5.
After programming Auto Start, open the door and
close the door to cancel auto start function.
ORM_Eng.indd 27ORM_Eng.indd 27 08.2.27 6:23:37 PM08.2.27 6:23:37 PM
E
28 CONVENIENT FEATURES
4. Language Selection
The oven comes set for English and U.S. Customary
Unit-pounds. Your oven can be selected 3 Languages,
English, Spanish or French, and 2 units, pounds or
kilograms for each language. To change, touch the
user pref pad and number 4. Continue to touch the
number 4 until your choice is selected from the table
below. Then, touch the START add 30 sec pad.
Press the user pref
pad and number 4 Language Units
once
twice English LB
3 times English KG
4 times Spanish LB
5 times Spanish KG
6 times French LB
7 times French KG
8 times English LB
Multiple Sequence Cooking
Your oven can be programmed for up to 4 automatic
cooking sequences, switching from one power level
setting to another automatically.
Sometimes cooking directions tell you to start on
one power level and then change to a different power
level. Your oven can do this automatically.
•
Suppose you want to cook roast beef for 5 minutes
at 100% and then continue to cook for 30 minutes at
50%.
Procedure
Step Touch
1. Enter cooking time for
1st stage. 5
0
0
2. Touch the power
level pad once for 100%
power for 1st stage.
power
level x 1
3. Enter second cooking
time for 2nd stage.
3
0
0
0
4. Touch the power level
pad 6 times for 50%
power for 2nd stage.
power
level x 6
5. Touch the START add
30 sec pad for 2nd
stage.
START
add 30 sec
NOTES
1. If power level pad is touched, HIGH will be
displayed.
2.
If 100% is selected as the final sequence, it is
not necessary to touch the power level pad.
3. Keep warm can be programmed even if 4
cooking sequences have been set.
More or Less Time Adjustment
Should you discover that you like any of SENSOR
MODES or AUTO MODES slightly more done, touch
the power level pad once after touching your
choice of pads or before touching the START add
30 sec pad. The display will show MORE.
Should you discover that you like any of SENSOR
MODES or AUTO MODES slightly less done, touch
the power level pad twice after touching your
choice of pads or before touching the START add
30 sec pad. The display will show LESS.
Add 30 Seconds
Add 30 seconds allows you to cook for 30 seconds
at 100% by simply touching the START add 30 sec
pad. You can also extend cooking time in multiples
of 30 seconds by repeatedly touching the START
add 30 sec pad until maximum 99 minutes during
manual cooking.
• Suppose you want to heat a cup of soup for 30
seconds.
Procedure
Step Touch
Touch the START add
30 sec pad.
START
add 30 sec
ORM_Eng.indd 28ORM_Eng.indd 28 08.2.27 6:23:37 PM08.2.27 6:23:37 PM
E
29
CONVENIENT FEATURES
Help
Each setting has a cooking hint. If you wish to check,
touch the user pref pad whenever HELP is lighted
in the Interactive Display for these and other manual
operation hints.
Timer
• Suppose you want to time a 3-minute long
distance phone call.
Procedure
Step Touch
1. Touch the timer on-off
pad.
timer
on-off
2. Enter time. 300
3. Touch the timer on-off
pad. The timer will count
down.
timer
on-off
NOTES
1. Timer operates as a kitchen timer and cannot
be used when the oven is operating.
2. To cancel the timer, touch the STOP/CLEAR
pad once.
Turntable ON/OFF
Turntable OFF function is useful when a rack or a
large casserole which stop the turntable's rotating
are used, for example lasagne or meat.
Reposition
the foods and/or stir them at least once during any
cooking or reheating time. After cooking or reheating,
stir if possible. Using a lower power level will assist in
better cooking or reheating uniformity.
Turntable ON/OFF function can be used in Manual
Cooking and keep warm in AUTO MODES. When
Turntable ON is set, Turntable is turned and when
Turntable OFF is set, Turntable is stopped. When
SENSOR MODES and AUTO MODES are selected,
Turntable ON is automatically set.
Turntable ON/OFF can be set during Manual Cook-
ing and cooking programming by touching the
turntable on-off pad.
Quick Start
Quick start is very useful function to start or add to
cook from 1 minute to 6 minutes by touching number
from 1 to 6 at 100% power without touching the
START add 30 sec pad. Touch number from 1 to
6 within 3minutes after cooking, closing the door,
touching the STOP/CLEAR pad.
• Suppose you want to cook 2 minutes at 100%
power.
Procedure
Step Touch
Touch number 2. 2
Demonstration Mode
To demonstrate, touch the set clock pad, number 0
and then touch the START add 30 sec pad and hold
for three seconds. DEMO ON DURING DEMO NO
OVEN POWER will appear in the display. Cooking
operations and specific special features can now
be demonstrated with no power in the oven. For
example, touch the START add 30 sec pad and
the display will show .30 and count down quickly
to END.
To cancel, touch the set clock pad, number 0 and
the STOP/CLEAR pad. If easier, unplug the oven
from the electrical outlet and replug.
Light
Touch the light pad once for high, twice for medium,
three times for Low and four times to turn off.
Fan
The fan will automatically start when heat rises from
range surface units or burners. This protects the
Over the Range Microwave Oven from excessive
temperature rise. The fan will stay on until the tem-
perature decreases. It cannot be turned off manually
during this time.
For other uses, touch the fan pad once for high
speed, twice for medium speed, three times for low
speed and four times to turn off.
ORM_Eng.indd 29ORM_Eng.indd 29 08.2.27 6:23:38 PM08.2.27 6:23:38 PM
E
30
(Front of microwave oven)
(Rear of microwave oven)
Grease filters Tabs
BOTTOM VIEW
CLEANING AND CARE
EXTERIOR
The outside surface is precoated steel and plastic.
Clean the outside with mild soap and water; rinse
and dry with a soft cloth. Do not use any type of
household or abrasive cleaner.
DOOR
Disconnect the power cord or deactivate the oven
with setting Child Lock before cleaning to prevent
unexpected manipulation. See Child Lock on page
27. Wipe the window on both sides with a soft cloth
to remove any spills or spatters. Metal parts will be
easier to maintain if wiped frequently with a soft cloth.
Avoid the use of spray and other harsh cleaners as
they may stain, streak or dull the door surface.
EASY CARE™ STAINLESS STEEL (SOME
MODELS)
Your microwave oven finish may be made with Easy
Care™ Stainless Steel (some models). Clean the
stainless with warm soapy water using a clean sponge
or cloth. Rinse with clean water and dry with a soft
clean cloth. DO NOT use ANY store bought cleaners
like Stainless Steel cleaners or any other types of
cleaners containing any abrasive, chlorides, chlorines
or ammonia. It is recommended to use mild dish soap
and water or a 50/50 solution of water and vinegar.
INTERIOR
Cleaning is easy because little heat is generated
to the interior surfaces; therefore, there is no
baking and setting of spills or spattering. To clean
the interior surfaces, wipe with a soft cloth and
warm water. DO NOT USE ABRASIVE OR HARSH
CLEANERS OR SCOURING PADS. For heavier soil,
use baking soda or a mild soap; rinse thoroughly with
hot water. The rack can be cleaned with hot soapy
water, rinsed and dried.
WAVEGUIDE COVER
The waveguide cover is located on the ceiling in
the microwave oven cavity. It is made from mica so
requires special care. Keep the waveguide cover
clean to assure good microwave oven performance.
Carefully wipe with a damp cloth any food spatters
from the surface of the cover immediately after they
occur. Built-up splashes may overheat and cause
smoke or possibly catch fire. DO NOT REMOVE THE
WAVEGUIDE COVER.
ODOR REMOVAL
Occasionally, a cooking odor may remain in the
microwave oven. To remove, combine 1 cup water,
grated peel and juice of 1 lemon and several whole
cloves in a 2-cup glass measuring cup. Boil for several
minutes using 100% power. Allow to set in microwave
oven until cool. Wipe interior with a soft cloth.
TURNTABLE/TURNTABLE SUPPORT
The turntable and turntable support can be removed
for easy cleaning. Wash them in mild, sudsy water; for
stubborn stains use a mild cleanser and non-abrasive
scouring sponge. They are also dishwasher-proof. Use
upper rack of dishwasher. The turntable motor shaft is
not sealed, so excess water or spills should be wiped
up immediately.
GREASE FILTERS
Filters should be cleaned at least once a month. Never
operate the fan or microwave oven without the filters
in place.
1. Pull down slightly on the tab toward the front of
the microwave oven and remove the filter. Repeat
for the other filter.
2. Soak the filters in a sink or dish pan filled with hot
water and detergent. DO NOT use ammonia or
other alkali; they will react with the filter material
and darken it.
3. Agitate and scrub with a brush to remove embed-
ded dirt.
4. Rinse thoroughly and shake dry.
5. Replace by fitting the filter back into the opening.
Disconnect the power cord before cleaning or leave the door open to deactivate
the oven during cleaning.
ORM_Eng.indd 30ORM_Eng.indd 30 08.2.27 6:23:38 PM08.2.27 6:23:38 PM
E
31
CLEANING AND CARE
CHARCOAL FILTERS
Charcoal Filters, which are attached with Hood
Louver, are used for nonvented, recirculated instal-
lation. The filter should be changed every 6 to 12
months depending on use.
1. Disconnect power to the microwave oven at the
circuit breaker panel or by unplugging.
2. Remove three Houver Louver Screws.
3. Push the upper tabs and pull the louver away
from the unit.
4. Remove the charcoal filters from hood louver and
replace new charcoal filters by piercing tabs into
the holes in charcoal filters.
5. Carefully push the louver back into place and
replace the screws removed at step 2.
Figure 1
Oven Light Cover
Hood Louver
Upper Tab
Hood Louver
Screws
Figure 2
Charcoal Filters
Inside of Hood Louver
Tabs
MICROWAVE OVEN LIGHT
Remove the louver per instructions 1-3 above, if
used.
1. To replace an old krypton light bulb, first discon-
nect power to the microwave oven at the circuit
breaker panel or by unplugging.
2. Open oven light cover by carefully pulling up on
the front edge. See figure 1.
3. Remove an old light bulb and replace a new 40
watts krypton light bulb. DO NOT USE BULB
LARGER THAN 40 WATTS.
4. Close the Oven Light Cover by carefully push-
ing into place. Push the louver back into place
(engaging both the bottom and top tabs) and
replace three Houver Louver Screws.
LIGHT BULB
1. To replace an old krypton light bulb, first discon-
nect power to the microwave oven at the circuit
breaker panel or by unplugging.
2. To open Light Cover, remove the screw on the
light cover. (See Figure 3.)
3. Replace the old 40 watts krypton light bulb with
new one. DO NOT USE A BULB LARGER THAN
40 WATTS.
4. Close the Light Cover and secure with screw
removed at step 2.
(Front of microwave oven)
(Rear of microwave oven)
Light Bulb
Light Cover
Figure 3 Screw
BOTTOM VIEW
CAUTION
Light Cover may become very hot. Do not touch
glass when light is on.
Disconnect the power cord before cleaning or leave the door open to deactivate
the oven during cleaning.
ORM_Eng.indd 31ORM_Eng.indd 31 08.2.27 6:23:39 PM08.2.27 6:23:39 PM
E
32 SERVICE CALL CHECK
Please check the following before calling for service:
Place one cup of water in a glass measuring cup in the oven and close the door securely.
Operate the oven for one minute at HIGH 100%.
A Does the oven light come on? YES ____ NO ____
B Does the cooling fan work?
(Put your hand over the left side of louver.)
YES ____ NO ____
C Is the water in the oven warm? YES ____ NO ____
If “NO” is the answer to any of the above ques-
tions, please check electrical outlet, fuse and/
or circuit breaker. If they are functioning prop-
erly, CONTACT YOUR NEAREST ELECTROLUX
AUTHORIZED SERVICER.
A microwave oven should never be serviced by
a “do-it-yourself” repair person.
NOTES
1. If time appearing in the display is counting
down very rapidly, check Demonstration Mode
on page 29 and cancel.
2. If the oven is set for 40 minutes and over at
80, 90 or 100 percent power level, after the
first 40 minutes the power level will automati-
cally adjust itself to 70 percent power to avoid
overcooking.
ORM_Eng.indd 32ORM_Eng.indd 32 08.2.27 6:23:39 PM08.2.27 6:23:39 PM
E
33
SPECIFICATIONS
AC Line Voltage: UL Rating: Single phase 120V, 60Hz, AC only
AC Power Required: UL Rating: 1650 W 14.3 amps.
Output Power:* 1000 watts
Frequency: 2450 MHz
Outside Dimensions (including handle): 29 15/16"(W) x 17 1/16"(H) x 18 15/32"(D)
Cavity Dimensions: 22 1/2"(W) x 10 1/16"(H) x 14 31/32"(D)
Microwave Oven Capacity**: 2.0 Cu. Ft.
Weight: Approx. (net) 61 lb, (gross) 73 lb
* The International Electrotechnical Commission’s standardized method for measuring output wattage.
This test method is widely recognized.
** Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for
holding food is less.
In compliance with standards set by:
FCC - Federal Communications Commission Authorized.
DHHS - Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21,
Chapter I, Subchapter J.
- This symbol on the nameplate means the product is listed by Underwriters Laboratories,
Inc.
ORM_Eng.indd 33ORM_Eng.indd 33 08.2.27 6:23:39 PM08.2.27 6:23:39 PM
E
34 WARRANTY INFORMATIONS
Over the range microwave oven warranty
Your Over The Range Microwave Oven is protected by this warranty
Warranty
period
Through our authorized servicers,
We will:
The consumer will be
Responsible for:
FULL ONE YEAR
WARRANTY
One year from
original pur-
chase date.
Pay all costs for repairing or replacing any
parts of this appliance which prove to be
defective in materials of workmanship.
Costs of service calls that are listed under
NORMAL RESPONSIBILITIES OF THE
CONSUMER.*
UNLIMITED
WARRANTY
(Applicable to the
State of Alaska)
Time periods
listed above.
All of the provisions of the full warranties
above and the exclusions listed below
apply.
Costs of the technician’s travel to the home
and any costs for pick up and delivery of the
appliance required because of service.
In the U.S.A., your appliance is warranted by Electrolux Home Products North America, a division of White Consolidated
Industries, Inc. We authorize no person to change or add to any of our obligations under this warranty. Our obligations for service
and parts under this warranty must be performed by us or an authorized Electrolux Home Products North America servicer. In
Canada, your appliance is warranted by Electrolux Canada Corp.
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
This warranty applies only to products in ordinary household use, and the consumer is
responsible for the items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the
appliance and in accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses,
repair of loose connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., which are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
EXCLUSIONS This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND
INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED
WARRANTY.
NOTE: Some states do not allow the exclusion or limitation of incidental or consequential
damages, so this limitation or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for
appliances not in ordinary household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Electrolux Home Products
North America or its authorized servicers; use of parts other than genuine Electrolux Home
Products parts; obtained from persons other than such servicers; or external causes such as
abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily
determined.
IF YOU NEED SERVICE Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the
bill establishes the warranty period should service be required. If service is performed, it is in your
best interest to obtain and keep all receipts. This written warranty gives you specific legal rights.
You may also have other rights that vary from state to state. Service under this warranty must be
obtained by contacting Electrolux Home Products:
USA
1-800-944-9044
Electrolux Home Products
North America
P.O. Box 212378
Augusta, GA 30917
This warranty only applies in the 50 states of the U.S.A., Puerto Rico, and Canada.
Product features or specifications as described or illustrated are subject to change
without notice. All warranties are made by Electrolux Home Products North America,
a division of White Consolidated Industries, Inc.
ORM_Eng.indd 34ORM_Eng.indd 34 08.2.27 6:23:39 PM08.2.27 6:23:39 PM
E
35
ORM_Eng.indd 35ORM_Eng.indd 35 08.2.27 6:23:40 PM08.2.27 6:23:40 PM
