Sharp DMR0173 Microwave Oven User Manual

Sharp Corporation Microwave Oven

User manual

Mi c r o w a v e Dr a w e r
KB-6525P, KB-6524P
OPERATION MANUAL
MODELS
KB-6525P, KB-6524P
Followed by indicating color: K = black, W = white, S = stainless steel
Customer AssistAnCe ......................................3
PreCAutions to Avoid Possible exPosure to
exCessive miCrowAve energy ............................3
Consumer limited wArrAnty.............................4
imPortAnt sAfety instruCtions .........................5
informAtion you need to know..... .................. 6-8
PArt nAmes..... ...............................................9
before oPerAting .......................................... 10
miCrowAve drAwer™ Cooking ..................... 11-16
other feAtures ........................................ 17-18
CleAning And CAre ........................................ 19
before you CAll for serviCe ........................... 20
Cookbook informAtion ................................... 21
Cookbook order form ................................... 21
Auto-touCh guide ..........................23-bACk Cover
KB-6525PS
518_KB-6524P,6525P OM.indd 1 12/17/08 9:11:44 AM
518_KB-6524P,6525P OM.indd 2 12/17/08 9:11:44 AM
CUSTOMER ASSISTANCE
To aid in reporting this appliance, please record below the model number and serial number located on the unit. We also suggest you
record all the information listed and retain for future reference.
MODEL NUMBER SERIAL NUMBER
DATE OF PURCHASE / /
DEALER TELEPHONE
SERvICER TELEPHONE
TO PHONE:
DIAL 1-800-BE-SHARP (237-4277) for:
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your authorized parts distributor)
ADDITIONAL CUSTOMER INFORMATION
TO WRITE:
Sharp Electronics Corporation
Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing
address (including zip code), your daytime telephone number (including area code) and description of the problem.
TO ACCESS INTERNET: www.sharpusa.com
3
PRECAUTIONS TO AvOID POSSIBLE EXPOSURE
TO EXCESSIvE MICROWAvE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure
to microwave energy. It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that
there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing
surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualied service personnel.
518_KB-6524P,6525P OM.indd 3 12/17/08 9:11:44 AM
CONSUMER LIMITED WARRANTY
4
The Product Information Card should be completed within ten days of purchase and returned. We will keep it on le and help you
access the information if needed. This will also enable us to contact you in the unlikely event that any adjustments or modications
are ever required for your Microwave Drawer.
PRODUCT INFORMATION CARD
SHARP ELECTRONICS CORPORATION warrants to the rst consumer purchaser that this Sharp brand product (the “Product”),
when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option,
either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the
purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any
Product the exterior of which has been damaged or defaced, which has been subjected to misuse, abnormal service or handling, or
which has been altered or modied in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of
purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL
IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE
LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein,
or to extend the duration of any warranties beyond the time period described above on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive
remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall constitute
complete fulllment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and shall constitute
full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable,
or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed
by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incident or consequential
economic or property damage. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion
may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE.
Your product model number &
description
KB-6525P, KB-6524P or Home Use Microwave Drawer. (Be sure to have this information
available when you need service for your Product.)
Warranty period for this product: One (1) year parts and labor including in-home service. The warranty period continues
for an additional four (4) years, for a total of ve (5) years, with respect to the magnetron
tube in the Product for parts only; labor and service are not provided free of charge for this
additional period.
Additional item(s) excluded from
warranty coverage (if any):
Non-functional accessories and light bulbs.
Where to obtain service: From a Sharp Authorized Servicer located in the United States. To nd the location of the near-
est Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP (1-800-237-4277).
What to do to obtain service: In-home service is provided for one year from date of purchase. In-home service can be
arranged by calling 1-800-BE-SHARP. Be sure to have Proof of Purchase available.
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP or visit www.sharpusa.com.
SAVE THE PROOF OF PURCHASE AS IT IS NEEDED SHOULD YOUR OVEN EVER REQUIRE WARRANTY SERVICE.
518_KB-6524P,6525P OM.indd 4 12/17/08 9:11:45 AM
5
imPortAnt sAfety instruCtions
READ ALL INSTRUCTIONS BEFORE USING
When using the appliance, basic safety precautions should
be followed, including the following:
WARNING
To reduce the risk of burns, electric shock,
re, injury to persons or exposure to excessive microwave
energy:
1 Read all instructions before using the appliance.
2 Read and follow the specic “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on page 3.
3 This appliance must be properly grounded. See page 6
for grounding instructions.
4 Install or locate this appliance only in accordance with
the provided Installation Manual.
5 Some products such as whole eggs and sealed containers
- for example, closed glass jarsare able to explode and
should not be heated in the appliance.
6 Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals or vapors
in this appliance. This appliance is specically designed
to heat, cook or dry food. It is not designed for industrial
or laboratory use.
7 As with any appliance, close supervision is necessary
when used by children.
8 Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly or if it has been
damaged or dropped.
9 This appliance should be serviced only by qualied
service personnel. Contact nearest Sharp Authorized
Servicer for examination, repair or adjustment.
10 Do not cover or block any openings on the appliance.
11 Do not store or use this appliance outdoors. Do not use
this product near waterfor example, near a kitchen
sink, in a wet basement, near a swimming pool or similar
locations.
1 2 Do not immerse cord or plug in water.
1 3 Keep cord away from heated surfaces.
1 4 Do not climb or sit on the appliance.
1 5 Be sure that ngers or other objects or materials are
not around the appliance opening when the appliance
is closed.
1 6 Do not put ngers or clothes around the drawer guides
when the appliance is opened or closed. They could be
caught in the guides when the appliance is closed.
17 Be sure that the food and container are shorter than the
drawer before closing it. You can refer to the height of
the side walls of the drawer.
1 8 When cleaning appliance sealing surfaces that
come together on closing the drawer, use only mild,
nonabrasive soaps or detergents applied with a sponge
or soft cloth. See cleaning instructions on page 19.
19 To reduce the risk of re in the appliance cavity:
a Do not overcook food. Carefully attend appliance
when paper, plastic or other combustible materials are
placed inside the appliance to facilitate cooking.
b Remove wire twist-ties from paper or plastic bags
before placing bag in appliance.
c If materials inside the appliance ignite, keep
appliance door closed, turn microwave off and shut
off power at the fuse or circuit breaker panel.
d Do not use the appliance for storage purposes. Do
not leave paper products, cooking utensils, or food
in the appliance when not in use.
2 0 Liquids, such as water, coffee or tea are able to be
overheated beyond the boiling point without appearing
to be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from
the appliance is not always present. THIS COULD
RESULT IN VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN A SPOON OR OTHER
UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
a Do not overheat the liquid.
b Stir the liquid both before and halfway through
heating it.
c Do not use straight-sided containers with narrow
necks. Use a wide-mouthed container.
d After heating, allow the container to stand in the
appliance at least for 20 seconds before removing
the container.
e Use extreme care when inserting a spoon or other
utensil into the container.
21 If the appliance light fails, consult a SHARP
AUTHORIZED SERVICER.
SAVE THESE INSTRUCTIONS
518_KB-6524P,6525P OM.indd 5 12/17/08 9:11:45 AM
6
ABOUT UNPACKING AND EXAMINING
YOUR MICROWAVE DRAWER
1 Remove all packing
materials from inside
the Microwave Drawer.
DO NOT REMOVE
THE WAVEGUIDE
COVER, wh ich is
located on the top
of t he Microwave
Drawer.
2 Remove the feature
sticker, if there is one.
Check the drawer for
any damage, such as
misaligned or bent
drawer, damaged drawer seals and sealing surfaces, broken
or loose drawer guides and dents inside the cavity or on the
front side of the drawer. If there is any damage, do not operate
the Microwave Drawer and contact your dealer or a SHARP
AUTHORIZED SERVICER.
RADIO OR TV INTERFERENCE
Should there be any interference caused by the Microwave
Drawer to your radio or TV, check that the Microwave Drawer
is on a different electrical circuit, relocate the radio or TV as far
away from the drawer as feasible or check position and signal
of receiving antenna.
GROUNDING
INSTRUCTIONS
This appliance must be grounded. The Microwave Drawer
is equipped with a cord having a grounding wire with a
grounding plug. It must be plugged into a wall receptacle that
is properly installed and grounded in accordance with the
National Electrical Code and local codes and ordinances. In
the event of an electrical
short circuit, grounding
reduces risk of electric
shock by providing an
escape wire for the electric
current.
Improper
use of the grounding plug
can result in a risk of
electric shock. Do not use
an extension cord. If the
power supply cord is too short, have a qualied electrician
or serviceman install an outlet near the appliance.
If you have any questions about the grounding or electrical
instructions, consult a qualified electrician or service
person.
ABOUT YOUR MICROWAVE DRAWER
ALWAYS have food in the Microwave Drawer when it is on to
absorb the microwave energy.
The vent under the Microwave Drawer must not be blocked.
During microwaving, steam may come from the right side of
the vent.
When using the Microwave Drawer at power levels below 100%,
you may hear the magnetron cycling on and off. It is normal for
the exterior of the Microwave Drawer to be warm to the touch
when cooking or reheating.
Condensation is a normal part of microwave cooking. Room
humidity and the moisture in food will inuence the amount of
moisture that condenses in the Microwave Drawer. Generally,
covered foods will not cause as much condensation as uncovered
ones.
The Microwave Drawer is for food preparation only. It should
not be used to dry clothes or newspapers.
Your Microwave Drawer is rated 1000 watts by using the IEC
Test Procedure. In using recipes or package directions, check
food a minute or two before the minimum time and add time
accordingly.
When opening or closing the Microwave Drawer quickly, food
in the Microwave Drawer may be spilled. To clean, please refer
to the Cleaning and Care section on page 19.
A good microwave cookbook is a valuable asset. Check it for
microwave cooking principles, techniques, hints and recipes.
See page 21 for ordering the Sharp Carousel Microwave
Cookbook.
ABOUT MICROWAVE COOKING
Arrange food carefully. Place thickest areas towards outside
of dish.
Watch cooking time. Cook for the shortest amount of time
indicated and add more as needed. Food severely overcooked
can smoke or ignite.
Cover foods while cooking. Check recipe or cookbook for
suggestions: paper towels, wax paper, microwave plastic wrap
or a lid. Covers prevent spattering and help foods to cook
even ly.
Shield with small at pieces of aluminum foil any thin areas
of meat or poultry to prevent overcooking before dense, thick
areas are cooked thoroughly.
Stir foods from outside to center of dish once or twice during
cooking, if possible.
Waveguide
Cover
Sealing
Surface
Oven
Cavity
Sealing
Surface
INFORMATION YOU NEED TO KNOW
3-Prong plug
Grounding pin
3-Prong receptacle
Grounded receptacle box
Permanent and Correct Installation
Grounding adapter
Grounded receptacle box
Screw
Tab for grounding screw
Temporary Use
518_KB-6524P,6525P OM.indd 6 12/17/08 9:11:57 AM
7
Turn foods over once during microwaving to speed cooking
of such foods as chicken and hamburgers. Large items like
roasts must be turned over at least once.
Rearrange foods such as meatballs halfway through cooking
both from top to bottom and from right to left.
Add standing time. Remove food from Microwave Drawer
and stir, if possible. Cover for standing time which allows
the food to nish cooking without overcooking.
Check for doneness. Look for signs indicating that cooking
temperatures have been reached.
Doneness signs include:
- Food steams throughout, not just at edge.
- Center bottom of dish is very hot to the touch.
- Poultry thigh joints move easily.
- Meat and poultry show no pinkness.
- Fish is opaque and akes easily with a fork.
ABOUT UTENSILS AND COVERINGS
It is not necessary to buy all new cookware. Many pieces already
in your kitchen can be used successfully in your new Microwave
Drawer. Make sure the utensil does not touch the interior walls
during cooking.
Use these utensils for safe microwave cooking and reheating:
glass ceramic (Pyroceram®), such as Corningware®.
heat-resistant glass (Pyre)
microwave-safe plastics
microwave-safe paper plates
microwave-safe pottery, stoneware and porcelain
browning dish (Do not exceed recommended preheating
time. Follow manufacturer’s directions.)
These items can be used for short time reheating of foods that
have little fat or sugar in them:
wood, straw, wicker
DO NOT USE
metal pans and bakeware
dishes with metallic trim
non-heat-resistant glass
non-microwave-safe plastics (margarine tubs)
recycled paper products
brown paper bags
food storage bags
metal twist-ties
Should you wish to check if a dish is safe for microwaving,
place the empty dish in the oven and microwave on HIGH for 30
seconds. A dish which becomes very hot should not be used.
The following coverings are ideal:
Paper towels are good for covering foods for reheating and
absorbing fat while cooking bacon.
Wax paper can be used for cooking and reheating.
Plastic wrap that is specially marked for microwave use can
be used for cooking and reheating. DO NOT allow plastic
wrap to touch food. Vent so steam can escape.
Lids that are microwave-safe are a good choice because heat
is kept near the food to hasten cooking.
Oven cooking bags are good for large meats or foods that
need tenderizing. DO NOT use metal twist ties. Remember
to slit bag so steam can escape.
How to use aluminum foil in your Microwave Drawer:
Small at pieces of aluminum foil placed smoothly on the
food can be used to shield areas that are either defrosting or
cooking too quickly.
Foil should not come closer than one inch to any surface of
the Microwave Drawer.
Should you have questions about utensils or coverings, check a
good microwave cookbook or follow recipe suggestions.
ACCESSORIES There are many microwave accessories
available for purchase. Evaluate carefully before you purchase
so that they meet your needs. A microwave-safe thermometer
will assist you in determining correct doneness and assure you
that foods have been cooked to safe temperatures. Sharp is not
responsible for any damage to the Microwave Drawer when
accessories are used.
ABOUT CHILDREN AND THE
MICROWAVE
Children below the age of 7 should use the Microwave Drawer
with a supervising person very near to them. Between the
ages of 7 and 12, the supervising person should be in the same
room. The child must be able to reach the Microwave Drawer
co m for t ably.
At no time should anyone be allowed to lean or swing on the
Microwave Drawer.
Children should be taught all safety precautions: use potholders,
remove coverings carefully, pay special attention to packages
that crisp food because they may be extra hot.
Donʼt assume that because a child has mastered one cooking
skill he/she can cook everything.
Children need to learn that the Microwave Drawer is not a toy.
See page 17 for Control Lock feature.
INFORMATION YOU NEED TO KNOW
518_KB-6524P,6525P OM.indd 7 12/17/08 9:11:58 AM
8
ABOUT SAFETY
Check foods to see that they are cooked to the United States
Department of Agricultureʼs recommended temperatures.
145˚F - Fish.
160˚F - Pork, ground beef/veal/lamb, egg dishes
165˚F - For leftover, ready-to-reheat refrigerated, and deli
and carry-out fresh” food. Whole, pieces and
ground turkey/chicken/duck.
To test for doneness, insert a meat thermometer in a thick or dense
area away from fat or bone. NEVER leave the thermometer in the
food during cooking, unless it is approved for microwave use.
ALWAYS use potholders to prevent burns when handling
utensils that are in contact with hot food. Enough heat from
the food can transfer through utensils to cause skin burns.
INFORMATION YOU NEED TO KNOW
Avoid steam burns by directing steam away from the face
and hands. Slowly lift the farthest edge of a dishs covering
and carefully open popcorn and oven cooking bags away
from the face.
Stay near the Microwave Drawer while it’s in use and check
cooking progress frequently so that there is no chance of
overcooking food.
NEVER use the Microwave Drawer for storing cookbooks
or other items.
Select, store and handle food carefully to preserve its high
quality and minimize the spread of foodborne bacteria.
Keep waveguide cover clean. Food residue can cause arcing
and/or res. See page 19.
ABOUT FOODS
FOOD DO DON’T
Eggs, sausages, fruits &
vegetables
• Puncture egg yolks before cooking to prevent
“explosion”.
• Pierce skins of potatoes, apples, squash, hot
dogs and sausages so that steam escapes.
• Cook eggs in shells.
• Reheat whole eggs.
• Dry nuts or seeds in shells.
Popcorn • Use specially bagged popcorn for the
microwave.
• Listen while popping corn for the popping to
slow to 1 or 2 seconds or use special Sensor
Popcorn pad.
• Pop popcorn in regular brown bags or glass bowls.
• Exceed maximum time on popcorn package.
Baby food • Transfer baby food to small dish and heat
carefully, stirring often. Check temperature
before serving.
• Put nipples on bottles after heating and shake
thoroughly. “Wrist” test before feeding.
• Heat disposable bottles.
• Heat bottles with nipples on.
• Heat baby food in original jars.
General • Cut baked goods with lling after heating to
release steam and avoid burns.
• Stir liquids briskly before and after heating
to avoid “eruption”.
• Use deep bowl, when cooking liquids or
cereals, to prevent boilovers.
• Food should be shorter than the Microwave
Drawer. Please refer to the height of side walls
of the drawer.
• Heat or cook in closed glass jars or airtight
containers.
• Can in the microwave as harmful bacteria may not be
destroyed.
• Deep fat fry.
• Dry wood, gourds, herbs or wet papers.
518_KB-6524P,6525P OM.indd 8 12/17/08 9:11:58 AM
9
PART NAMES
MICROWAVE DRAWER
2
18
5
4
3
7
6
KEYSHEET
Numbers next to the keysheet illustration indicate pages on which there
are feature descriptions and usage information.
1 Control panel
2 Waveguide cover DO NOT REMOVE
3 Microwave Drawer Menu Label
4 Drawer sealing surfaces
5 Drawer light
6 Microwave Drawer guides
7 Vent
8 Name plate: open the Microwave Drawer fully. The label
is beyond the back wall of the microwave cavity facing
up from the at surface.
121518
14 1017 15 1016
17 11
10
1716
13 12
518_KB-6524P,6525P OM.indd 9 12/17/08 9:12:00 AM
10
BEFORE OPERATING
Before operating your new Microwave Drawer make sure you
read and understand this operation manual completely.
Before the Microwave Drawer can be used, follow these
steps:
1 Plug in the Microwave Drawer. ENJOY YOUR MICRO-
WAVE TOUCH CLEAR AND TOUCH CLOCK will
appear.
2 Touch the Stop/Clear pad. : will appear.
3 Set clock.
TO SET THE CLOCK
1 Touch Timer/Clock pad and number 2.
2 Touch number pads for correct time of day and touch
Timer/Clock pad again.
This is a 12 hour clock. If you attempt to enter an incorrect
clock time, ERROR will appear in the display. Touch the
Stop/Clear pad and re-enter the time.
If the electrical power supply to your Microwave Drawer
should be interrupted, the display will intermittently show
ENJOY YOUR MICRO- WAVE TOUCH CLEAR
AND TOUCH CLOCK after the power is reinstated. If
this occurs during cooking, the program will be erased. The
time of day will also be erased. Simply touch Stop/Clear
pad and reset the clock for the correct time of day.
Note:
The Microwave Drawer can be programmed with the
drawer open except for START/Minute Plus.
TIMER
1 Touch Timer/Clock pad and number 1.
2 Enter time.
3 Touch Timer/Clock pad again.
To cancel timer, touch Stop/Clear.
STOP/CLEAR
Touch the Stop/Clear pad to:
1 Erase if you make a mistake during programming.
2 Cancel timer.
3 Stop the Microwave Drawer temporarily during timed
cooking.
4 Return the time of day to the display.
5 Cancel a program during cooking, touch twice for timed
cooking.
OPEN OR CLOSE MICROWAVE DRAWER
To open the Microwave Drawer, pull the drawer handle a
little so that the drawer will open automatically. To close
the Microwave Drawer, push the drawer with light pressure
so that the drawer will close automatically. In case the
Microwave Drawer is stopped in the middle, open or close
the drawer manually to full open or close position by gently
pulling or pushing with even pressure near the middle of the
drawer handle.
If you wish to use key operation to open/close the Microwave
Drawer, touch the OPEN or CLOSE pad on the control panel
to open or close the Microwave Drawer.
518_KB-6524P,6525P OM.indd 10 12/17/08 9:12:01 AM
11
TIME COOKING
Your Microwave Drawer can be programmed for 99 minutes
99 seconds (99.99). Always enter the seconds after the
minutes, even if they are both zeros.
Suppose you want to cook for 5 minutes at 100%.
1 Enter cooking time 5 0 0. 5.00 TOUCH START
OR TOUCH POWER LEVEL
2 To cook at 100% power (High), touch START/Minute
Plus pad.
TO SET POWER LEVEL
There are eleven preset power levels.
Using lower power levels increases the cooking time, which
is recommended for foods such as cheese, milk and long slow
cooking of meats. Consult a microwave cookbook or recipes
for specic recommendations.
Suppose you want to defrost for 5 minutes at 30%.
1 Enter defrost time 5 0 0. 5.00
2 Touch Power Level pad 8 times.
3 Touch START/Minute Plus pad.
TOUCH POWER
LEVEL PAD
NUMBER OF
TIMES FOR
DESIRED POWER
APPROXIMATE
PERCENTAGE
OF POWER
COMMON
WORDS
FOR POWER
LEVELS
Power Level x 1 100% High
Power Level x 2 90%
Power Level x 3 80%
Power Level x 4 70% Medium High
Power Level x 5 60%
Power Level x 6 50% Medium
Power Level x 7 40%
Power Level x 8 30% Med Low/Defrost
Power Level x 9 20%
Power Level x 10 10% Low
Power Level x 11 0%
SENSOR SETTINGS
Sharp's Sensor is a semi-conductor device that detects the
vapor (moisture and humidity) emitted from the food as it
heats. The sensor adjusts the cooking times and power levels
for various foods and quantities.
USING SENSOR SETTINGS:
1 After the Microwave Drawer is plugged in, wait 2
minutes before using any sensor setting.
2 Be sure the exterior of the cooking container and the
interior of the Microwave Drawer are dry. Wipe off any
moisture with a dry cloth or paper towel.
3 The sensor works with foods at normal storage
temperature. For example, popcorn would be at room
temperature.
4 Any sensor selection can be programmed with More or
Less Time Adjustment. See page 17.
5 More or less food than the quantity listed in the charts
should be cooked following the guidelines in any
microwave cookbook.
6 During the rst part of sensor use, the food name will
appear on the display. Do not open the Microwave Drawer
or touch Stop/Clear during this part of the cycle. The
measurement of vapor will be interrupted. If this occurs,
an error message will appear. To continue cooking, touch
the Stop/Clear pad and cook manually.
When the sensor detects the vapor emitted from the
food, the remainder of cooking/reheating time will
appear. The Microwave Drawer may be opened when
the remaining time appears on the display. At this time,
you may stir or season food, as desired.
7 Except for Popcorn, if the sensor does not detect vapor
properly when cooking other foods, ERROR will be
displayed, and the microwave will turn off.
8 Check food temperature after cooking. If additional
time is needed, continue to cook manually.
9 Each food has a cooking hint. Touch the Custom Help
pad when the HELP indicator is lighted in the display.
MICROWAVE DRAWER COOKING
518_KB-6524P,6525P OM.indd 11 12/17/08 9:12:01 AM
12
COVERING FOODS:
Some foods work best when covered. Use the cover
recommended in the charts for these foods. You may refer to
the hints by touching the Custom Help pad. See page 18.
1 Casserole lid.
2 Plastic wrap: Use plastic wrap recommended for
microwave cooking. Cover dish loosely; allow
approximately 1/2 inch to remain uncovered to allow
steam to escape. Plastic wrap should not touch food.
3 Wax paper: Cover dish completely; fold excess wrap
under dish to secure. If dish is wider than paper, overlap
two pieces at least one inch to cover.
Be careful when removing any covering to allow steam to
escape away from you.
SENSOR POPCORN / SENSOR REHEAT CHART
FOOD AMOUNT PROCEDURE
Sensor Popcorn Only 1 package at a time
2.85 - 3.5 oz.
(Regular / Regular light)
1.2 - 1.75 oz.
(Mini / Snack)
Use only popcorn packaged for the microwave. Try several brands to decide
which you like. Do not try to pop unpopped kernels.
Touch Sensor Popcorn pad once.
Touch Sensor Popcorn pad twice.
Sensor Reheat 4 - 36 oz. Place in dish or casserole slightly larger than amount to be reheated. Flatten, if
possible. Cover with lid, plastic wrap or wax paper. Use covers such as plastic wrap
or lids with larger quantities of more dense foods such as stews. After reheating,
stir well, if possible. Re-cover and allow to stand 2 to 3 minutes. Foods should
be very hot. If not, continue to heat with variable power and time.
MICROWAVE DRAWER COOKING
SENSOR POPCORN / SENSOR REHEAT
You can pop popcorn and reheat many foods and dont need to
calculate cooking time or power level.
Touch Sensor Reheat or Sensor Popcorn and START/
Minute Plus pad.
When the sensor detects the vapor emitted from the food, the
remainder of cooking/reheating time will appear.
Note:
The Sensor Popcorn setting has 2 choices. Follow
directions in the display to choose desired option.
518_KB-6524P,6525P OM.indd 12 12/17/08 9:12:02 AM
13
MICROWAVE DRAWER COOKING
SENSOR COOKING
1 Touch Sensor Cook pad once. SEE LABEL SELECT
FOOD NUMBER
2 See Menu Label. Select desired food by touching number
pad. Ex: Touch 5 for baked potatoes.
3 Touch START/Minute Plus pad.
Note:
To heat or cook other foods or foods above or below the
quantity allowed on the SENSOR COOK CHART, cook
ma nua l ly.
SENSOR COOK CHART
FOOD AMOUNT PROCEDURE
1 Fresh vegetables: Quick
Broccoli
Brussels sprouts
Cabbage
Cauliower (owerets)
Cauliower (whole)
Spinach
Zucchini
Baked apples
.25 - 2.0 lb.
.25 - 2.0 lb.
.25 - 2.0 lb.
.25 - 2.0 lb.
1 med.
.25 - 1.0 lb.
.25 - 2.0 lb.
2 - 4 med.
Wash and place in casserole. Add no water if vegetables have just been washed. Cover
with lid for tender vegetables. Use plastic wrap for tender-crisp vegetables. After cooking,
stir, if possible. Let stand, covered, for 2 to 5 minutes.
2 Fresh vegetables: Longer
Carrots, sliced
Corn on the cob
Green beans
Winter squash:
diced
halves
.25 - 1.5 lb.
2 - 4
.25 - 1.5 lb.
.25 - 1.5 lb.
1 - 2
Place in casserole. Add 1 - 4 tablespoons water. Cover with lid for tender vegetables.
Use plastic wrap cover for tender-crisp vegetables. After cooking, stir, if possible. Let
stand, covered, for 2 to 5 minutes.
3 Frozen vegetables .25 - 1.25 lb. Add no water. Cover with lid or plastic wrap. After cooking, stir and let stand, covered,
for 3 minutes.
4 Frozen entrees 6 - 17 oz. Use this pad for frozen convenience foods. It will give satisfactory results for most
brands. You may wish to try several and choose your favorite. Remove package from
outer wrapping and follow package directions for covering. After cooking, let stand,
covered, for 1-3 minutes
5 Baked potatoes
6 Sweet potatoes
1 - 6 med.
1 - 6 med.
Pierce. Place on paper-towel-lined Microwave Drawer. After cooking, remove from
microwave, wrap in aluminum foil and let stand 5 to 10 minutes.
7 Ground meat .25 - 2.0 lb. Use this setting to cook ground beef or turkey as patties or in a casserole to be added to other
ingredients. Place patties on a microwave-safe rack and cover with wax paper. Place
ground meat in a casserole and cover with wax paper or plastic wrap. When microwave
stops, turn patties over or stir meat in casserole to break up large pieces. Re-cover and touch
START/Minute Plus. After cooking, let stand, covered, for 2 to 3 minutes.
8 Fish/seafood .25 - 2.0 lb. Arrange in ring around shallow glass dish (roll llet with edges underneath). Cover with
vented plastic wrap. After cooking, let stand, covered for 3 minutes.
9 White rice
10 Brown rice
.5 - 2.0 cups
.5 - 2.0 cups
Place rice into a deep casserole and add double quantity of water. Cover with lid or plastic
wrap. After cooking, stir, cover and let stand 3 to 5 minutes or until all liquid has been
absorbed.
Rice Water Size of casserole
.5 cup ...................1 cup ................... 1.5 quart
1 cup .................... 2 cups .................. 2 quart
1.5 cups ................3 cups .................. 2.5 or 3 quart
2 cups ................... 4 cups .................. 3 quart or larger
518_KB-6524P,6525P OM.indd 13 12/17/08 9:12:02 AM
14
DEFROST
Use this feature to defrost the foods shown in the DEFROST
CHART below.
1 Touch Defrost pad.
SEE LABEL SELECT FOOD NUMBER
2 See Menu Label. Select desired food by touching the
number pad. Ex: Touch 2 for steaks/chops. STEAKS
CHOPS ENTER WEIGHT
3 Enter weight by touching number pads. 1.0
4 Touch START/Minute Plus pad.
The oven will stop so that the food can be checked.
5 After the first stage, open the Microwave Drawer.
Turn steak over and shield any warm portions. Close the
Microwave Drawer. Touch START/Minute Plus pad.
6 After the second stage, open the Microwave Drawer. Shield
any warm portions. Close the Microwave Drawer. Touch
START/Minute Plus pad.
7 After defrost cycle ends, cover and let stand as indicated
in the chart below.
Note:
Defrost can be programmed with More or Less Time
Adjustment. See page 17.
To defrost other foods or foods above or below the weights
allowed on the DEFROST CHART, see MANUAL
DEFROST below.
Check foods when oven signals. After nal stage, small
sections may still be icy. Let stand to continue thawing.
Do not cook until all ice crystals are thawed.
Shielding prevents cooking from occurring before the
center of the food is defrosted. Use small smooth strips
of aluminum foil to cover edges and thinner sections of
the food.
DEFROST CHART
FOOD AMOUNT PROCEDURE
1 Ground meat .5 - 2.0 lb Remove any thawed pieces after each audible signal. Let stand, covered, for 5 to 10 minutes.
2 Steaks/chops .5 - 3.0 lb After each audible signal, rearrange and if there are warm or thawed portions, shield with small
at pieces of aluminum foil. Remove any meat or sh that is almost defrosted. Let stand, covered,
for 10 to 20 minutes.
3 Boneless poultry .5 - 2.0 lb After each audible signal, if there are warm or thawed portions, rearrange or remove. Let stand,
covered, for 10 to 20 minutes.
4 Bone-in poultry .5 - 3.0 lb After each audible signal, rearrange pieces or remove portions should they become warm or thawed.
Let stand, covered, for 10 to 20 minutes.
5 Roast 2.0 -4.0 lb Start defrosting with fat side down. After each stage, turn roast over and shield the warm portions
with aluminum foil. Let stand, covered, for 30 to 60 minutes.
6 Casserole
Soup
2 - 6 cups
1 - 6 cups
After each audible signal, break apart and remove any defrosted part. At end, stir well and let stand,
covered, for 5 to 10 minutes.
MICROWAVE DRAWER COOKING
MANUAL DEFROST
If the food that you wish to defrost is not listed on the
DEFROST CHART or is above or below the limits in the
AMOUNT column on the DEFROST CHART, you need to
defrost manually.
You can defrost any frozen food, either raw or previously
cooked, by using Power Level at 30%. Follow the exact 3-step
procedure found under TO SET POWER LEVEL on page 11.
Estimate defrosting time and touch Power Level pad eight times
for 30% power.
For either raw or previously cooked frozen food the rule of
thumb is approximately 4 minutes per pound. For example,
defrost 4 minutes for 1 pound of frozen spaghetti sauce.
Always stop the oven periodically to remove or separate
the portions that are defrosted. If food is not defrosted at
the end of the estimated defrosting time, program the oven
in 1 minute increments on Power Level 30% until totally
defrosted.
When using plastic containers from the freezer, defrost only
long enough to remove from the plastic in order to place in
a microwave-safe dish.
518_KB-6524P,6525P OM.indd 14 12/17/08 9:12:03 AM
15
MICROWAVE DRAWER COOKING
REHEAT CHART
FOOD AMOUNT PROCEDURE
1 Fresh rolls/mufns 1 - 8 pcs Use this pad to warm rolls, mufns, biscuits, bagels etc. Large items should be considered as 2
or 3 regular size. Arrange on plate; cover with paper towel. For refrigerated rolls or mufns, it
may be necessary to double the entered amount to ensure the proper serving temperature. For
example, enter quantity of 2 for 1 refrigerated mufn.
2 Frozen rolls/mufns 1 - 8 pcs Use this pad to warm frozen rolls, mufns, biscuits, bagels etc. Large items should be considered
as 2 or 3 regular size. Arrange on plate; cover with paper towel.
BEVERAGE CENTER CHART
FOOD AMOUNT PROCEDURE
1 Reheat beverage .5 - 2.0 cups This setting for good for restoring cooled beverage to a better drinking temperature. Touch
number 1 pad for a 0.5 cup increase per touch. Stir after heating.
2 Hot water 1 - 6 cups Use this setting for heating COLD TAP WATER to a temperature somewhat below the boiling
point to make instant coffee or tea. Touch number 2 pad for 1 cup increase per touch. Stir liquid
briskly before and after heating to avoid “eruption.
REHEAT
Reheat automatically computes the correct warming time and
microwave power level for foods shown in the chart below.
1 Touch Reheat pad once. SEE LABEL SELECT
FOOD NUMBER
2 See Menu Label. Select desired food by touching number
pad. Ex: Touch 2 for frozen rolls or mufns.
3 Touch the number pad to select quantity. Ex: Touch 2 for
2 rolls or mufns.
4 Touch START/Minute Plus pad.
BEVERGE CENTER
Beverage Center enables you to reheat coffee or tea to restore
to a more suitable drinking temperature or to make instant
coffee or tea.
Suppose you want to make 2 cups of coffee.
1 Touch Beverage Center pad once. SEE LABEL
SELECT FOOD NUMBER
2 See Menu Label. Select desired selection by touching
number pad. Ex: Touch 2 to make coffee.
3 Repeating touching same number pad to select quantity.
Ex: Touch 2 two more times for 2 cups of coffee.
4 Touch START/Minute Plus pad.
Note:
Reheat can be programmed with More or Less Time
Adjustment. See page 17.
To reheat other foods or foods above or below the quantity
allowed on the REHEAT CHART, heat manually.
Note:
Beverage Center can be programmed with More or Less
Time Adjustment. See page 17.
Should you attempt to enter more or less than the allowed
amount, an error message will appear in the display.
518_KB-6524P,6525P OM.indd 15 12/17/08 9:12:04 AM
16
MICROWAVE DRAWER COOKING
MELT/SOFTEN/WARM
Melt, Soften and Warm automatically compute the correct
heating time and microwave power level for melting, softening
and warming foods shown in the chart below.
1 Touch Melt pad once. SEE LABEL SELECT FOOD
NUMBER
2 See Menu Label. Select desired food by touching number
pad. Ex: Touch 2 for chocolate.
3 Repeat touching same number pad to select quantity.
Ex: Touch 2 two more times for 1 square.
4 Touch START/Minute Plus pad.
Note:
Melt, Soften and Warm can be programmed with More or
Less Time Adjustment. See page 17.
To melt, soften or warm other food or foods above or below
the quantity allowed on the MELT / SOFTEN/WARM
CHART, use manual operation.
MELT/ SOFTEN /WARM CHART
FOOD AMOUNT PROCEDURE
Melt Use a Pyrex measuring cup. Cover with plastic wrap.
1 Butter 2 tbsp
. 5 c u p
After touching Melt, touch 1 two times for 2 tbsp.
After touching Melt, touch 1 three times for .5 cup.
2 Chocolate 1 cup chips
1 square
After touching Melt, touch 2 two times for 1 cup chips.
After touching Melt, touch 2 three times for 1 square.
Soften DO NOT COVER.
1 Ice cream 1 pint
. 5 g a l l o n
After touching Soften, touch 1 two times for 1 pint.
After touching Soften, touch 1 three times for .5 gallon.
2 Cream cheese 3 oz.
8 oz.
After touching Soften, touch 2 two times for 3 oz.
After touching Soften, touch 2 three times for 8 oz.
Warm Use a Pyrex measuring cup. DO NOT COVER.
1 Syrup
1/4 cup
1/2 cup
After touching Warm, touch 1 two times for 1/4 cup.
After touching Warm, touch 1 three times for 1/2 cup.
2 Dessert toppings
1/4 cup
1/2 cup
After touching Warm, touch 2 two times for 1/4 cup.
After touching Warm, touch 2 three times for 1/2 cup.
518_KB-6524P,6525P OM.indd 16 12/17/08 9:12:04 AM
17
KEEP WARM
Keep Warm allows you to keep food warm up to 30
minutes.
DIRECT USE
1 Touch Keep Warm pad. ENTER TIME UP TO
30 MINUTES
2 Enter desired time by touching the number pads. To enter
30 minutes, touch 3000. 30.00 TOUCH START
3 Touch START/Minute Plus pad.
The oven will start. The display will show 30.00 and count
down. KEEP WARM will be displayed intermittently
during the count down.
WITH MANUAL COOKING
1 Enter desired cooking time and power level.
2 Touch Keep Warm pad.
3 Enter desired warming time up to 30 minutes.
4 Touch START/Minute Plus pad.
The operation will start. When the cooking time is complete,
a long tone will sound and Keep Warm will start. The
display will count down. KEEP WARM will be displayed
intermittently during the count down.
Note:
If you attempt to enter more than 30 minutes for Keep
Warm, an error message will appear in the display.
Keep Warm cannot be programmed with Sensor Popcorn,
Sensor Reheat, Sensor Cook, Defrost or Reheat.
MULTIPLE SEQUENCE COOKING
Your Microwave Drawer can be programmed for up to 4
automatic cooking sequences, switching from one power
level setting to another automatically.
Sometimes cooking directions tell you to start on one
power level and then change to a different power level. Your
Microwave Drawer can do this automatically.
1 First enter cooking time. Then touch Power Level pad
once for 100% cooking or repeat touching Power Level pad
for a lower power level.
2 Enter second cooking time. Repeat touching Power Level
pad for desired level. You can follow this procedure up to 4
times. TOUCH START
3 Touch START/Minute Plus pad.
Note:
If Power Level pad is touched once, HIGH will be
displayed.
If 100% is selected as the nal sequence, it is not necessary
to touch the Power Level pad.
If you wish to know power level during cooking, simply
touch the Power Level pad. As long as your nger is
touching the Power Level pad, the power level will be
displayed.
Keep Warm can be programmed even if 4 cooking
sequences have been set.
HELP
Each setting of Sensor Reheat, Sensor Cook, Sensor Popcorn,
Keep Warm, Reheat and Defrost has a cooking hint. If you
wish to check, touch Custom Help whenever HELP is
lighted in the Interactive Display for these and other manual
operation hints.
MINUTE PLUS™
Minute Plus allows you to cook for a minute at 100% by
simply touching the Minute Plus pad. You can also extend
cooking time in multiples of 1 minute by repeatedly touching
the Minute Plus pad during manual cooking.
Note:
To use Minute Plus, touch pad within 3 minutes after
cooking, closing the drawer or touching the Stop/Clear pad.
Minute Plus cannot be used with Sensor settings, Reheat
or Defrost.
MORE OR LESS TIME ADJUSTMENT
Should you discover that you like any of the Sensor, Reheat
or Defrost settings slightly more done, touch the Power
Level pad once after touching your selection. The display
will show MORE .
For slightly less done, touch the Power Level pad twice after
touching your selection. The display will show LESS .
CONTROL LOCK
The Control Lock prevents unwanted drawer operation such
as by small children. The Microwave Drawer can be set so
that the control panel and the automatic door mechanism are
deactivated or locked.
TO LOCK
Touch Control Lock pad and hold for 3 seconds. The display
shows LOCK ON .
TO UNLOCK
Touch Control Lock pad and hold for 3 seconds. The display
shows LOCK OFF .
The Control Lock is canceled when the electrical power supply
to your oven is interrupted. Set the Control Lock again when
power to the oven is restored.
OTHER FEATURES
518_KB-6524P,6525P OM.indd 17 12/17/08 9:12:05 AM
18
OTHER FEATURES
SETUP/CUSTOM HELP
If the electrical power supply to your Microwave Drawer
should be interrupted, the display will intermittently show
ENJOY YOUR MICRO- WAVE TOUCH CLEAR
AND TOUCH CLOCK after the power is reinstated. If
this occurs, the Setup/Custom Help option you input will
be erased. Simply touch Stop/Clear pad and reset.
AUDIBLE SIGNAL ELIMINATION
At the end of timed cook, beeps will sound. The audible signal
can be turned off if you prefer quiet operation.
TO TURN SOUND OFF
1 Touch Setup/Custom Help pad. TOUCH AGAIN
2 Touch Setup/Custom Help pad again. SOUND OFF ?
TOUCH START
3 Touch START/Minute Plus pad. The display shows
SOUND OFF
TO RESTORE SOUND
1 Touch Setup/Custom Help pad. TOUCH AGAIN
2 Touch Setup/Custom Help pad again. SOUND ON ?
TOUCH START
3 Touch START/Minute Plus pad. The display shows
SOUND ON
END OF COOKING REMINDER
At end of timed cooking, the microwave will signal every 10
seconds for the rst minute; then every 3 minutes until Stop/
Clear pad is touched, up to one hour.
TO TURN REMINDER OFF
1 Touch Setup/Custom Help pad three times. The display
shows REMIND SIGNAL OFF ? TOUCH START .
2 Touch START/Minute Plus pad. The display shows
REMIND SIGNAL OFF .
TO TURN REMINDER SIGNAL BACK ON
1 Touch Setup/Custom Help pad three times. The display
shows REMIND SIGNAL ON ? TOUCH START .
2 Touch START/Minute Plus pad. The display shows
REMIND SIGNAL ON .
AUTO START
If you wish to program the Microwave Drawer to begin
cooking automatically at a designated time of day, follow this
procedure.
1 Touch Setup/Custom Help pad 4 times. The display shows
AUTO START TOUCH START
2 Touch START/Minute Plus pad.
ENTER START TIME
3 Enter start time. 4:30 TOUCH CLOCK
4 Touch Timer/Clock pad. ENTER COOKING TIME
5 Touch the number pads to enter cooking time. 20.00
TOUCH START OR TOUCH POWER LEVEL
Touch Power Level pad repeatedly until the desired power
level is reached. TOUCH START
6 Touch START/Minute Plus pad.
DEMONSTRATION MODE
TO SELECT DEMO MODE
1 Touch Setup/Custom Help pad ve times. The display
shows DEMO ON? HOLD START 3 SEC .
2 Hold START/Minute Plus pad for 3 seconds. The display
shows DEMO ON .
TO CANCEL DEMO MODE
1 Touch Setup/Custom Help pad ve times. The display
shows DEMO OFF ? TOUCH START .
2 Touch START/Minute Plus pad. The display shows
DEMO OFF
Note:
Microwave Drawer doesnt heat in Demo Mode.
Display counts down quickly.
SLEEP MODE
The backlight of the display will automatically turn off after 15
minutes if the unit has not been in operation. The information in
the display will remain, but the display will not remain lighted.
The display will not go into the Sleep Mode during cooking or
while the Demo Mode is set.
If the display is “sleeping”, simply touch the control panel or
open/close the door to turn the back light on. The Sleep Mode
feature can be deactivated, if desired.
TO TURN SLEEP MODE OFF
1 Touch Setup/Custom Help pad 6 times. The display shows
SLEEP MODE OFF ? .
2 Touch START/Minute Plus pad. The display shows
SLEEP MODE OFF .
TO TURN SLEEP MODE BACK ON
1 Touch Setup/Custom Help pad 6 times. The display shows
SLEEP MODE ON ? .
2 Touch START/Minute Plus pad. The display shows
SLEEP MODE ON .
518_KB-6524P,6525P OM.indd 18 12/17/08 9:12:07 AM
19
CLEANING AND CARE
EXTERIOR
The outside surface is precoated metal and plastic. Clean the
outside with mild soap and water; rinse and dry with a soft
cloth. Do not use any type of household or abrasive cleaner.
STAINLESS STEEL SURFACE
(SELECT MODELS)
The exterior should be wiped often with a soft damp cloth and
polished with a soft dry cloth to maintain its beauty. There
are also a variety of products designed especially for cleaning
and shining the stainless exterior of the oven. We recommend
that the cleaner be applied to a soft cloth and then carefully
used on the stainless exterior rather than sprayed directly on
to it. Follow package directions carefully.
FRONT SIDE OF THE DRAWER
Wipe the window on both sides with a soft damp cloth to
remove any spills or spatters. Metal parts will be easier to
maintain if wiped frequently with a soft damp cloth. Avoid
the use of spray and other harsh cleaners as they may stain,
streak or dull the drawer surface.
TOUCH CONTROL PANEL
If desired, the touch pads may be deactivated before cleaning.
See the Control Lock information on page 16 of this manual.
Wipe the panel with a cloth dampened slightly with water
only. Dry with a soft cloth. Do not scrub or use any sort of
chemical cleaners. Close drawer and follow directions on page
16 for turning Control Lock off. Touch Stop/Clear.
INTERIOR
Before cleaning the the Microwave Drawer, touch and hold
the Control Lock button for 3 seconds to lock the control
pad and the automatic door mechanism. The drawer can
be locked in either the open or closed position. The display
will show LOCK ON . This will prevent the drawer from
accidentally opening or closing during cleaning. After
cleaning, touch and hold the Control Lock button for
3 seconds to turn the lock off. The display will show
LOCK OFF .
Cleaning is easy because no heat is generated to the interior
surfaces; therefore, there is no baking and setting of spills or
spattering. To clean the interior surfaces, including drawer
sealing surfaces, wipe with a soft damp cloth. DO NOT USE
ABRASIVE OR HARSH CLEANERS OR SCOURING
PADS. For heavier soil, use mild soap; wipe clean with a soft
damp cloth. Do not use any chemical oven cleaners.
MICROWAVE DRAWER GUIDES
Remove the food crumbs from the Microwave Drawer guides.
Wipe with a soft dry cloth in order to keep the Microwave
Drawer opening and closing smoothly.
WAVEGUIDE COVER
ATTENTION The waveguide cover, located on the inside
top of the Microwave Drawer area, is made from mica, so
it requires special care. Keep the waveguide cover clean to
assure good microwave performance. Carefully wipe with
a soft damp cloth any food spatters from the surface of
the cover immediately after they occur. Built-up splashes
may overheat and cause smoke or possibly catch re. Do
not remove the waveguide cover.
ODOR REMOVAL
Occasionally, a cooking odor may remain in the Microwave
Drawer. To remove odor, combine 1 cup water, grated peel
and juice of one lemon and several whole cloves in a 2-cup
glass microwave-safe measuring cup. Boil for several minutes
using 100% power. Leave in the Microwave Drawer until
water cools. Wipe interior with a soft cloth.
518_KB-6524P,6525P OM.indd 19 12/17/08 9:12:07 AM
20
Please check the following before calling for service. It may save you time and expense.
PROBLEM POSSIBLE CAUSE SOLUTION
1 Part or all of Micro-
wave Drawer does not
operate.
Power cord of Microwave Drawer is not com-
pletely connected to the electrical outlet.
Power outage.
Fuse/circuit breaker at home doesnt work.
Microwave Drawer is in Demo Mode.
Make sure the power cord is tightly connected
to the outlet.
Check house lights to be sure. Call your local
electric company for service.
Replace the fuse or reset the circuit breaker.
See page 18 for how to cancel Demo Mode.
2 Food in Microwave
Drawer is not heated.
No power to the appliance.
Drawer controls improperly set.
Drawer is in Demo Mode.
See SOLUTION for PROBLEM 1.
Check if the controls have been properly set.
See page 18.
3 Microwave Drawer
light does not work.
Light bulb is loose or burned out. Call for service.
4 Touch controls will not
operate.
Control Lock is on. See page 17 to unlock.
5 Display ashes. Power failure. Touch Clear pad and reset the clock. If the
Microwave Drawer was in use, you must reset
the cooking function.
6 Steam from the vent During microwaving, steam may come from
the right side of the vent.
BEFORE YOU CALL FOR SERVICE
518_KB-6524P,6525P OM.indd 20 12/17/08 9:12:08 AM
PERSONAL RECIPES AND NOTES
I have enclosed a check made payable to Sharp Electronics Corporation.
Please bill my VISA MASTERCARD AMERICAN EXPRESS
Acct. No. _____________________________________ Expiration date _____ / ______
Signature_________________________________________________________________
(All credit card orders must be signed.)
Name ___________________________________________________________________________
Address _________________________________________________________________________
City ____________________________________ State ____________ Zip ____________________
Daytime Phone No. ( ) _________________________________________________________
Please send me ______ cookbooks at $18.50 each $ _______
Illinois sales tax, (if applicable) per book $.91 no. of books _____________ $ ______ _
TOTAL ORDER AMOUNT $ ______ _
Price is subject to change without notice.
COOKBOOK ORDER FORM
Mail to: Sharp Electronics Corporation
Attention: Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
Cut along this line.
2121
TO ORDER
Simply call this toll-free number: 1-800-237-4277.
Please have your credit card ready.
If you prefer to order by mail, complete and return the order
form. Please include check or money order (payable to Sharp
Electronics Corporation) for $14.00 plus $4.50 shipping &
handling and tax, if applicable, per book.
SATISFACTION GUARANTEED
You must be completely satisfied with the Sharp
Microwave Oven Cookbook. If, within 14 days, you are
dissatisfied for any reason, simply return the book and
we'll gladly refund your $14.00 plus tax.
125 GREAT RECIPES
All about your
microwave
Color photos
Step-by-step
instructions
Durable wipe-clean
soft cover with 192
7" x 10" pages
Helpful tips and
special techniques
(SOLAMENTE ESCRITO EN INGLES!)
MICROWAVE OVEN
COOKBOOK
COOKBOOK INFORMATION
518_KB-6524P,6525P OM.indd 21 12/17/08 9:12:09 AM
22
NOTES
22
518_KB-6524P,6525P OM.indd 22 12/17/08 9:12:09 AM
MICROWAVE DRAWER
AUTO-TOUCH GUIDE
23
CONTROL LOCK
The Control Lock prevents unwanted oven/drawer operation
such as by small children. The Microwave Drawer can be set so
that the control panel is deactivated or locked.
To Lock
Touch Control Lock pad and hold for
3 seconds.
LOCK ON
To Unlock
Touch Control Lock pad and hold for
3 seconds.
LOCK OFF
CUSTOM HELP
Check operation manual for specic details.
Touch Setup/Custom Help pad.
2 times for Sound Off/On.
3 times for End of Cooking Reminder.
4 times for Auto Start.
5 times for Demonstration Mode.
6 times for Sleep Mode.
OTHER FEATURES
KEEP WARM
Micro Warm allows you to keep food warm up to 30 minutes.
Direct Use
1 Touch Keep Warm pad. ENTER TIME
UP TO 30
MINUTES
2 Enter desired time by touching the
number pads. To enter 30 minutes,
touch 3000.
30:00 TOUCH
START
3 Touch START/Minute Plus pad.
With Manual Cooking
1 Enter desired cooking time and power level.
2 Touch Keep Warm pad.
3 Enter desired warming time up to 30 minutes.
4 Touch START/Minute Plus pad.
ME LT / SOFTEN / WARM
Use these features to melt or soften the foods shown on the
Menu Label.
1 Touch Melt pad once. SEE LABEL
SELECT FOOD
NUMBER
2 See Menu Label. Select desired food
by touching the number pad.
Ex: Touch 2 for chocolate.
CHOCO- LATE
3 Repeat touching same number pad
to select quantity. Ex: touch 2 two
more times for 1 square.
4 Touch START/Minute Plus pad.
518_KB-6524P,6525P OM.indd 23 12/17/08 9:12:10 AM
AUTO-TOUCH GUIDE
24
For more complete information and safety precautions, refer to your Operation Manual.
SET CLOCK
1Touch Timer/Clock pad and number 2.
2Touch number pads for correct time of day and touch
Timer/Clock pad again.
If the electrical power supply to
your range should be interrupted,
the display will intermittently show:
ENJOY YOUR
MICRO- WAVE
TOUCH CLEAR
AND TOUCH
CLOCK
TIME COOKING
High Power Cooking
1 Enter cooking time by touching
number pads. (Ex: 5 minutes)
5.00 TOUCH
START OR
TOUCH POWER
LEVEL
2 Touch START/Minute Plus pad.
variable Power Cooking
1
After step 1 above, touch Power Level pad until desired
power level is in the display.
2 Touch START/Minute Plus pad.
SENSOR COOK
Sensor Cook automatically computes the correct time and power
level to cook foods on the Menu Label perfectly.
1Touch Sensor Cook pad once. SEE LABEL
SELECT FOOD
NUMBER
2See Menu Label. Select desired food by touching number
pad. Ex: Touch 5 for baked potatoes.
3 Touch START/Minute Plus pad.
MINUTE PLUS
Touch START/Minute Plus for one minute at 100% microwave
power or to add a minute during manual cooking. Continue to
touch for additional minutes.
SENSOR POPCORN/SENSOR REHEAT
Touch Sensor Popcorn or Sensor Reheat and START/
Minute Plus pad.
REHEAT
Reheat automatically computes the correct warming time and
microwave power level for foods shown on the Menu Label.
1 Touch Reheat pad once. SEE LABEL
SELECT FOOD
NUMBER
2 See Menu Label. Select desired food
by touching the number pad. Ex:
Touch 2 for frozen rolls or mufns.
FROZEN ROLLS
MUFFINS ENTER
NUMBER
3 Touch the number pad to select
quantity. Ex: Touch 2 for 2 rolls or
mufns.
2 PCS
4 Touch START/Minute Plus pad.
DEFROST
Use this feature to defrost the foods shown on the Menu
Label.
1 Touch Defrost pad. SEE LABEL
SELECT FOOD
NUMBER
2 See Menu Label. Select desired
food by touching the number pad.
Ex: Touch 2 for steaks/chops.
STEAKS CHOPS
ENTER WEIGHT
3 Enter weight by touching number
pads.
1.0
4 Touch START/Minute Plus pad.
5 Microwave will stop to allow food to be turned over,
shielded and/or removed. Close the Microwave Drawer.
Touch START/Minute Plus pad.
TIMER
1 Touch Timer/Clock pad and number 1.
2 Enter time.
3 Touch Timer/Clock pad again.
To cancel timer, touch Stop/Clear.
MICROWAVE DRAWER
TINSEB518MRK0
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
518_KB-6524P,6525P OM.indd 24 12/17/08 9:12:12 AM

Navigation menu
