Safety Precautions
Before Using Handset
Use specified battery, Charger and other •
optional accessories only.
Using non-specified equipment may cause
malfunction, battery leakage, overheating, bursting
or ignition. Fire, burn injuries or electric shock may
result.
Do not short-circuit handset/battery/Charger •
terminals.
May cause fire, electric shock or malfunction; battery
may leak, overheat, burst or ignite. Keep Charger
terminals/blades and External Device Port away from
conductive objects (wire, metallic necklace/strap,
pencil lead, etc.).
Do not open, modify or disassemble handset •
and related hardware.
May cause malfunction, or battery may leak,
overheat, burst or ignite. Fire, injury or electric shock
may also result. Contact SoftBank Customer Center,
Customer Assistance for repairs.
Do not expose handset and related hardware to •
liquids.
May cause malfunction, overheating, fire or electric
shock. Avoid exposure to water, pet urine, etc.
Do not use/leave handset and related hardware •
near heat sources or in direct sunlight or
extreme heat (inside vehicles, etc.).
May cause malfunction/distortion, or battery may
leak, overheat, burst or ignite. Handset or battery
may become hot to the touch, leading to burn
injuries.
Do not dispose of battery in fire.•
May leak, overheat, burst or ignite.
Do not apply strong shocks or excessive force.•
Do not drop or throw handset or related hardware;
may cause damage or malfunction. Battery may
leak, overheat, burst or ignite. Fire, injury or electric
shock may also result. Discontinue use of battery if
damaged or deformed. Do not sit down with handset
in a back pocket, and do not place heavy objects on
handset or related hardware in a bag.
Keep handset, battery or Charger away from •
humidity, dust or extreme temperatures.
Malfunction may result.
If battery fluid contacts eyes, do not rub them. •
Rinse with clean water and consult a doctor
immediately.
Eyes may be severely damaged.
Do not force battery into handset.•
Battery may leak, overheat, burst or ignite; make sure
the direction and install properly.
Keep handset or related hardware away from •
microwave ovens or other cooking appliances.
Battery, handset or related hardware may leak, burst,
overheat or ignite, leading to malfunction, accidents
or injury.
Keep handset off and Charger disconnected •
near filling stations or places with fire/explosion
risk. Handset use near petrochemicals or other
flammables may cause fire/explosion; turn
handset off before using S! FeliCa at filling
stations (cancel IC Card Lock beforehand).
Do not use Mobile Light near people's faces.•
May temporarily affect sight leading to accidents.
Never use handset while driving.•
Accidents may result. Park beforehand. Mobile phone
use while driving is prohibited by the Road Traffic
Law.
If an abnormality occurs:•
If there is abnormal odor, excessive heat, discoloration
or distortion, unplug Charger, turn off handset and
remove battery immediately; may cause overheating,
bursting, fire or battery leakage.
If battery does not charge properly, stop •
charging.
Battery may leak, overheat, burst or ignite.
If there is leakage or abnormal odor, avoid fire •
sources.
Battery may catch fire or burst.
For more information, see Instruction Manual P.xviii
Manner Mode
Minding Mobile Manners•
Please use your handset responsibly. Inappropriate handset use can be both
dangerous and bothersome. Please take care not to disturb others when using your
handset. Adjust handset use according to your surroundings.
Activating/Canceling Manner Mode
Press
, ) for 1+ seconds
USIM Card Installation
Slide in USIM Card with IC chip facing up
1
Insert battery (right)
2
Turn handset off and remove battery beforehand.•
Do not force USIM Card into or out of handset.•
USIM Card must be inserted to use handset.•
USIM PINs
PIN1•
A 4-digit Security Code to prevent unauthorized use
of handset; required when PIN Entry is active.
PIN2•
Required to clear Call Costs and to set Max Cost.
PIN1 and PIN2 are
9999
by default; change as
needed.
PIN Lock & Cancellation (PUK Code*)•
Entering incorrect PIN1 or PIN2 three consecutive
times locks USIM Card, disabling handset. Enter
PUK Code to unlock. For details, contact SoftBank
Customer Center, General Information.
USIM Personal Unblocking Key (PUK Code) unblocks a USIM *
Card blocked after the wrong PIN has been entered three
consecutive times. Each USIM Card has a unique PUK Code.
Do not disclose it to unauthorized persons.
Security Codes
Handset Code•
9999
by default; required to use or change some
handset functions.
Center Access Code•
4-digit number selected at initial subscription;
required to access Voicemail via landlines or subscribe
to fee-based information.
Network Password•
4-digit number selected at initial subscription;
required to restrict handset services.
A message appears for incorrect code entry; try •
again.
If Network Password is incorrectly entered three •
times consecutively, Call Barring settings are
locked. To resolve, Network Password and Center
Access Code must be changed. For details, contact
SoftBank Customer Center, General Information.
Battery Installation
Press down and slide as
1
shown
Lift and remove cover.•
Insert battery
2
Close cover
3
Charging
Use specified AC Charger (ZTDAA1; optional accessory) only.
Open Port Cover to connect Charger
1
Plug Charger into AC outlet
2
Small Light illuminates red while charging.•
When charging completes Small Light goes out.•
After charging, unplug Charger, then
3
disconnect handset
AC 100V
Outlet
Blades
AC Charger
Port Cover
Release Tabs
Charger Connector
Arrows
Up
Small Light
External
Device Port
2
1
3
Specifications
SoftBank 920SH
Weight Approximately 144 g
Continuous
Talk Time
Approximately 270 minutes (3G)
Approximately ●● minutes (GSM)
Continuous Standby
Time(closed position)
Approximately 370 hours (3G)
Approximately ●● hours (GSM)
Charging Time
(power off)
AC Charger: Approximately 150 minutes
In Car Charger: Approximately 155
minutes
SoftBank 920SH
Continuous Video Call
Talk Time Approximately 110 minutes
Dimensions
(W x H x D)
Approximately 50 x 108 x 23 mm
(closed position)
Maximum Output 0.25 W (3G)
2.0 W (GSM)
Values were calculated with battery installed.•
First Step Guide
Call these numbers toll free from landlines. ■
Subscription Area Service Center Phone Number
Hokkaido, Aomori, Akita, Iwate, Yamagata, Miyagi,
Fukushima, Niigata, Tokyo, Kanagawa, Chiba,
Saitama, Ibaraki, Tochigi, Gunma, Yamanashi,
Nagano, Toyama, Ishikawa, Fukui
General Information m 0088-240-157
Customer Assistance m 0088-240-113
Aichi, Gifu, Mie, Shizuoka General Information m 0088-241-157
Customer Assistance m 0088-241-113
Osaka, Hyogo, Kyoto, Nara, Shiga, Wakayama General Information m 0088-242-157
Customer Assistance m 0088-242-113
Hiroshima, Okayama, Yamaguchi, Tottori, Shimane,
Tokushima, Kagawa, Ehime, Kochi, Fukuoka, Saga,
Nagasaki, Oita, Kumamoto, Miyazaki, Kagoshima,
Okinawa
General Information m 0088-250-157
Customer Assistance m 0088-250-113
Customer Service
SoftBank
Customer Centers
From a SoftBank handset,
dial toll free at
157 (General Information)
or
113 (Customer Assistance)
SoftBank International
Call Center
From outside Japan, dial
+81-5351-3491
(International charges
will apply.)
More Information
Yahoo! Keitai•
Open Yahoo! Keitai Main
Menu and click
メニューリスト
,
English
then
User Support
.
Online Manual•
Please go to the SOFTBANK
MOBILE Corp. Website
(http://www.softbank.jp) for
the full manual.
Emergency Call
Call these numbers.
Police station• ...........................110
Fire station• ..............................119
The Maritime Safety Agency• ....118
on PC
on handset
First Step Guide
Use English InterfaceEmergency Call
Call from Outside Japan
Customer Service
Customize Handset Address
More Information
Read First
...etc.
Accessories
Battery (SHBBA1)• Headphones (with •
Microphone) (SHLAX1)
USB Cable*• Utility Software (Japanese)*•
Complimentary sample, not available for purchase.*
Getting Started
Handset Functions
Basic Operations
Handset Power On/Off
Power On ■
" (Long Press)
If Japanese appears the first time handset is powered
up, press % then choose
はい
and press %. In
Standby, press %, choose
いいえ
and press, then
change to English mode (below).
Power Off ■
" (Long Press)
Network Settings
Retrieve Network Information to use
Network-related services; the first time
you press %, A or B, a prompt appears.
%, A or B S
Yes
S%
English Interface
%S
設定
S%S
Language
S%S
English
S%
My Phone Number
%S0
Setting Clock
%S
Settings
S%S
Date & Time
S%
S
Set Date/Time
S%S Enter date and
time (24-hour format) S%
Calls
Placing a Voice Call
Enter number S!
"• S Call ends
Redialing
cS A record S%S!
"• S Call ends
Placing a Video Call
Enter numberS! (Long Press)
"• S Call ends
Placing an International Call
Enter number SBS
Int'l Call
S%S
A country S%S!
"• S Call ends
Answering a Call
When a call arrives, !
"• S Call ends
Answer Phone
Activating ■
$ (Long Press)
:
• appears for recorded message
To cancel, • $ (Long Press)
Playing Messages ■
$
To delete messages, • $ during playback
Text Entry
Toggling Entry Modes
In text entry windows, &S A mode S
%S Enter text
AKanji (hiragana)
BDouble-byte katakana
CSingle-byte katakana
D/EDouble-byte alphanumerics
F/GSingle-byte alphanumerics
HSingle-byte number
ICharacter Codes
Example: Entering no
In text entry windows, &S
Abc
S%S
66SdS666S%
Messaging
SMS/S! Mail
SMS ■
Exchange short text messages of up to 160
alphanumerics with SoftBank handsets.
S! Mail ■
Exchange text messages of up to 30,000
characters with e-mail compatible SoftBank
handsets, other mobiles and PCs, etc. Attach
image/sound files.
Customizing Handset Address
Change alphanumerics before @ of the
default handset mail address. Customizing
handset mail address helps reduce spams.
BS
Settings
S%S
Address Settings
S%S
English
S%S Onscreen
instructions
Sending Text Messages
BS
Create Message
(S! Mail) or
Create
New SMS
S%S Recipient field S%S
Enter S%S Enter (S! Mail) S%S
C (Text) S%S Enter S%Sk to attach
files (S! Mail) S%SA
Receiving Text Messages
Delivery Notice appears and Information
window opens (C appears) for new mail.
% to open Received Msg. folder.
Phone Book
Phone Book Entry Items
Phone Number ■
Enter up to five numbers on handset
(32 digits each).
E-mail Address ■
Enter up to five addresses on handset
(128 single-byte alphanumerics each).
Saving to Phone Book
%S
Phone
S%S
Add New Entry
S%S
Last Name:
S%S Enter S%S
First Name:
S%S Enter S%S
Add
Phone Number:
S%S Enter number
S%S An icon S%S
Add Email
Address:
S%S Enter address S%S
An icon S%SA
Editing Entries
bS An entry SBS
Edit
S%S
An item S%S Edit S%SA
Dialing from Phone Book
bS Enter reading S A name S%S
A phone number S!
Voicemail
Activating
%S
Settings
S%SfS
Call/Video Call
S
Voicemail/Divert
S%S
Voicemail
S%S
Activate
S%S
Always
or
No
Answer
S%S Ring time (for
No Answer
)
S%
Playing Messages
%S
Phone
S%S
Call Voicemail
S%
S Follow the voice guidance
Mobile Camera
Capturing Still Images
%S
Camera
S%S Frame image on
Display S%S%
Recording Video
%S
Camera
S%SAS Frame image
on Display S%S%S%
Yahoo! Keitai
Accessing Yahoo! Keitai
AS
メニューリスト
S%S
English
S%S Highlight a menu item S%
Using PC Site Browser
%S
Yahoo! Keitai
S%S
PC Site
Browser
S%S
Enter URL
S%S URL
S%S Highlight a menu item S%
Media Player
Playing Music
%S
Media Player
S%S
Music
S%S
My Music
S%S
Music Folder
or
Ring
Songs•Tones
S
All Music
S%SA file
S%
Adding Playlists
%S
Media Player
S%S
Music
S%S
My Music
S%SBS
Add New Playlist
S%S A nameS%
Using Playlists
%S
Media Player
S%S
Music
S%S
My Music
S%S A Playlist S%S
A fileS%
Managing Files
Opening Files
%S
Data Folder
S%S A folder S%S
A file S%
Format Memory Card
%S
Settings
S%SfS
Connectivity
S
Memory Card
S%S
Format Card
S%S
Yes
S%S Handset Code S%S
Yes
S%
Software Update
Precaution
Before updating software, turn power off
to end all active functions/applications, then
restart handset.
Updating Software
%S
Settings
S%S
Software Update
S%S
Software Update
S%
First Step Guide
Communication
S! Town
S! Loop
S! Friend's Status
S! Circle Talk
Near chat
Yahoo! Keitai
Yahoo! Keitai
Bookmarks
Saved Pages
Enter URL
History
PC Site Browser
Common Settings
Media Player
Music
Videos
Streaming
Setting
Messaging
Received Msg.
Create Message
Retrieve New Msg.
Drafts
Templates
Sent Messages
Unsent Messages
Chat Folder
Server Mail Box
Create New SMS
Settings
Memory Status
Camera
Data Folder
Pictures
DCIM
My Pictograms
Ring Songs•Tones
S! Appli
Music
Videos
Lifestyle-Appli
Books
Custom Screens
Flash®
Flash®Ringtones
Other Documents
Memory Status
S! Appli
S! Appli
Osaifu-Keitai
Settings
Information
TV
Digital TV
TV Player
TV Link
TV Listing
Reservation List
Settings
Entertainment
S! Quick News
S! Magazine/Weather Icon
BookSurfing
e-Book Viewer
Tools
Tools 1
Calendar
Alarms
Wakeup TV
Tasks
Calculator
Expenses Memo
Osaifu-Keitai
Tools 2
Stopwatch
Countdown Timer
World Clock
Hour Minder
Tools 3
Document Viewer
Notepad
Voice Recorder
Barcode/Scan
Phone Help
Phone
Phone Book
Add New Entry
Information
Call Log
Play Messages
Call Voicemail
Category Control
My Details
Speed Dial List
Mail Groups
S! Addressbook Backup
Ph.Book Settings
Manage Entries
Settings
Phone Settings
Mode Settings
Display
Custom Screens
Sounds & Alerts
Date & Time
言語選択 (Language)
User Dictionary
Set Screen Rotation
Ringer Output
Earpiece Volume
Change Menu
Locks
Software Update
Master Reset
Connectivity
Bluetooth
Infrared
USB Mode
USB Charge
Memory Card
Call/Video Call
Call Time & Cost
Answer Phone
Voicemail/Divert
Video Call
Show My Number
)Missed Calls
Int'l Calling
Disp. Time/Call
Call Barring
Minute Minder
Auto Answer
Call Waiting
Network Settings
Select Network
Select Service
Offline Mode
Retrieve NW Info
Location Info
Network Info
Menu List
Display Indicators & Key Assignments
nSignal Strength
"Packet Transmission Available
CUnread Mail
7Memory Card in Use
JManner Mode Active
KBattery Strength
NVoicemail Active
PAlarm Set
BOpen Messaging menu or
execute Softkey functions
!Initiate/answer calls
$Delete entries, escape/return to
previous window
'Open Shortcuts menu. In text entry
windows, toggle upper/lower case
1
|
#Enter numbers/characters
Basic Multi Selector Operations
Select menu items, move cursor and
scroll, etc. In this manual, Multi Selector
operations are indicated as shown below.
e
, : Press a or b
f
, : Press c or d
g
, : Press a, b, c or d
AOpen Yahoo! Keitai Main Menu
or execute Softkey functions
"Turn handset power on/off
&Activate TV or change character
entry mode
)Activate/cancel Manner mode or
toggle multiple active function
windows
