Data Display/Edit/Management
Use the FOMA terminal’s Infrared port from i-appli software
to operate equipment supporting the infrared remote control
such as TVs and VCRs.
To use the infrared remote control function, download compatible
i-appli software.
Start i-
a
ppli software that supports Ir remote control functions, point the
FOMA terminal’s Ir port to the front of the remote control sensor on the TV,
VCR or other device to operate, and perform remote control operations.
Actual operational methods will differ with each i-appli software
application.
Control devices from a distance of up to approximately 4 m
(Distance will vary depending on the device, the ambient brightness
and other factors).
Use iC transmission to send and receive data to and from
other FOMA terminals which also support iC transmission
function.
During iC transmission, the FOMA terminal status is the same as
when outside the service area, such that making/receiving calls,
i-mode, and data communications are not possible.
iC transmission is not available while a call is in progress or the IC
card is locked.
Data that can be sent and received or operations when various lock
functions are set are same as for Ir exchange (nP. 333).
For details on starting iC transmission from i-appli nP. 251
Note
When i-
a
ppli To is set to [No], i-
a
ppli is not activated from Ir exchange.
Cannot be activated as i-appli stand-by.
Infrared remote control
Using the infrared remote control function
Remote control operation
15°
Approx. 4 m
15°
Infrared port
Note
When in the Self mode, the Ir remote control function cannot be
used.
Depending on the device, operation may not run properly.
Remote control operation may not run properly directly under
fluorescent lights, near other equipment using infrared signals, or
in areas of direct sunlight.
iC transmission
iC transmission
dt25_E.book 337 ページ ２００８年５月１４日　水曜日　午後３時１１分
338
e15_dt25_7e.fm
[338/346]
Data Display/Edit/Management
Use while placing FeliCa mark (b) of receiving side FOMA
terminal on that of sending side FOMA terminal as shown above.
Do not move the FOMA terminal until all data are sent and received.
Sending and receiving data may be difficult according to other
party’s FOMA terminal. In such cases, make the clearance between
the FeliCa marks (b) closer or farther, or move them up/down/left/
right alternately.
During iC transmission, FOMA terminal called LED flashes (
n
P. 121).
Example: Phonebook
1In stand-by, press a.
2Select a name/C/[Send data]/[iC
transmission]/[Send]/[Yes].
In the details screen: Press C/[Send data]/[iC
transmission]/[Send]/[Yes].
3Place FeliCa mark (b) on that of the other party’s
FOMA terminal.
1Place FeliCa mark (b) on that of the other party’s
FOMA terminal.
2Select [Yes].
Terminal security code and authentication password entry are required for
sending or receiving all data items. The authentication password is a
password exclusively for iC transmission. Before starting data transfer, the
sender and receiver must enter the same user-specified four-digit password.
Example: Phonebook
1In stand-by, press a/C/[Send data]/[iC
transmission]/[Send all].
2Enter the terminal security code/t.
Precautions for using iC transmission function
Sending and receiving data individually
Sending a single data item <Send>
FeliCa mark
Receiving a single data item <Receive>
Note
When receiving phonebook, a confirmation message to store in
PushTalk phonebook appears. To store, select [Yes]. When
multiple phone numbers are stored, select the phone number.
However, if the 2in1 mode is set to [B mode], the PushTalk
phonebook confirmation screen does not appear.
Sending and receiving all data items
Sending all data items <Send all>
dt25_E.book 338 ページ ２００８年５月１４日　水曜日　午後３時１１分
e15_dt25_7e.fm
[339/346]
339
Continued on next page
Data Display/Edit/Management
3Enter the authentication password/t/[Yes].
4Place FeliCa mark (b) on that of the other party’s
FOMA terminal.
1In stand-by, place the FeliCa mark (b) on that of
the other party’s FOMA terminal.
2Select [Yes].
3Enter the terminal security code/t.
4Enter the authentication password/t/[Yes].
To cancel Receive: While receiving data, press C.
Use the FOMA terminal as a voice recorder (microSD Card is
required).
Save up to 400 recordings on the [Multimedia] folder of microSD
Card (Actual number varies depending on recording time). Record
up to 6 hours per recording.
When recording is attempted after the 400th recording, the message
stating that recording is failed appears and Voice recorder ends.
Record up to approximately 10 hours when saving to a 64 MB
microSD Card.
Recording within a distance of approximately 1.5 m is recommended.
Play back recorded voice or audio with i-motion player (nP. 309).
Recording start sound is heard and recording starts. The Camera
LED flashes during recording.
1In the Custom menu, select [Media tool]/[Voice
recorder]/t.
To pause/play: Press i.
2Press t to end recording.
Recording stops automatically in the following cases.
When the remaining time goes to 00:00:00
When recording time reaches approximately 6 hours
When microSD Card has no available space
3Select [Save].
Recorded voice is saved.
To play back a recorded voice: Select [Play].
To cancel a recorded voice: Select [Cancel]/[Yes].
Receiving all data items <Receive all>
Voice recorder
Using the FOMA terminal handset
as a voice recorder
Recording
Note
Recorded data is saved as the file without file restrictions.
Recording continues even if the FOMA terminal is closed during
recording.
When a call is received during recording, recording automatically
stops and the call can be answered. After the call ends, the save
confirmation screen appears.
Related Operations
Display files in the Data box <Display Data box>
In the Voice recorder screen, press
C/
[Display Data box].
Minimize audio noise <Noise reduction>
In the Voice recorder screen, press C/[Noise
reduction]/[ON].
Set Auto timer <Auto timer>
In the Voice recorder screen, press C/[Auto timer]/
select the auto timer duration/t.
dt25_E.book 339 ページ ２００８年５月１４日　水曜日　午後３時１１分
e22_dt25_7e.fm
[499/502]
499
Continued on next page
Appendix/External Devices/Troubleshooting
This model phone FOMA SH906iTV meets the MIC’s*
technical regulation for exposure to radio waves.
The technical regulation established permitted levels of radio frequency
energy, based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of
scientific studies. The regulation employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit is 2 watts/
kilogram (W/kg)
**
averaged over ten grams of tissue. The limit includes
a substantial safety margin designed to assure the safety of all persons,
regardless of age and health. The value of the limit is equal to the
international guidelines recommended by ICNIRP
***
.
All phone models should be confirmed to comply with the regulation,
before they are available for sale to the public. The highest SAR value
for this model phone is 0.318 W/kg. It was taken by the Telecom
Engineering Center (TELEC), a Registered Certification Agency on the
Radio Law. The test for SAR was conducted in accordance with the
MIC testing procedure using standard operating positions with the
phone transmitting at its highest permitted power level in all tested
frequency bands. While there may be differences between the SAR
levels of various phones and at various positions, they all meet the
MIC’s technical regulation. Although the SAR is determined at the
highest certified power level, the actual SAR of the phone during
operation can be well below the maximum value.
For further information about SAR, please see the following websites:
Specific Absorption Rate (SAR)
World Health Organization (WHO)
http://www.who.int/peh-emf/
ICNIRP
http://www.icnirp.de/
MIC
http://www.tele.soumu.go.jp/e/ele/body/index.htm
TELEC
http://www.telec.or.jp/ENG/Index_e.htm
NTT DOCOMO
http://www.nttdocomo.co.jp/english/product/
SHARP Corporation
http://www.sharp.co.jp/products/menu/phone/cellular/sar/index.html
* Ministry of Internal Affairs and Communications
** The technical regulation is provided in Article 14-2 of the Ministry
Ordinance Regulating Radio Equipment.
***International Commission on Non-Ionizing Radiation Protection
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed
not to exceed the limits for exposure to radio waves recommended
by international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety
margins designed to assure the protection of all persons, regardless
of age and health.
The guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg
and the highest SAR value for this device when tested at the ear was
1.270 W/kg*.
As SAR is measured utilizing the devices highest transmitting power
the actual SAR of this device while operating is typically below that
indicated above. This is due to automatic changes to the power level
of the device to ensure it only uses the minimum level required to
reach the network.
The World Health Organization has stated that present scientific
information does not indicate the need for any special precautions for
the use of mobile devices. They note that if you want to reduce your
exposure then you can do so by limiting the length of calls or using a
hands-free device to keep the mobile phone away from the head.
* The tests are carried out in accordance with international
guidelines for testing.
e22_dt25_7e.fm 499 ページ ２００８年５月２０日　火曜日　午前１０時３６分
500
e22_dt25_7e.fm
[500/502]
Appendix/External Devices/Troubleshooting
FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The guidelines are based on standards that were developed by
independent scientific organisations through periodic and thorough
evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons, regardless
of age and health.
The exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg.
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model handset when tested for use at the ear is
0.370 W/kg and when worn on the body, as described in this user
guide, is 0.748 W/kg.
Body-worn Operation; This device was tested for typical body-worn
operations with the back of the handset kept 1.5 cm from the body. To
maintain compliance with FCC RF exposure requirements, use
accessories that maintain a 1.5 cm separation distance between the
user’s body and the back of the handset. The use of beltclips, holsters
and similar accessories should not contain metallic components in its
assembly.
The use of accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements, and should be avoided.
The FCC has granted an Equipment Authorization for this model
handset with all reported SAR levels evaluated as in compliance with
the FCC RF emission guidelines. SAR information on this model
handset is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/fccid after searching on FCC
ID APYHRO00068.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association
(CTIA) Website at http://www.phonefacts.net.
FCC Notice
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s
authority to operate the equipment.
Hereby, Sharp Telecommunications of Europe Ltd, declares
that this FOMA SH906iTV is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC.
A copy of the original declaration of conformity can be
found at the following Internet address:
http://www.sharp.co.jp/k-tai/
Declaration of Conformity
e22_dt25_7e.fm 500 ページ ２００８年５月２０日　火曜日　午前１０時３７分
501
e22_dt25_7e.fm
[501/502]
Appendix/External Devices/Troubleshooting
The Japan Export Control Regulations (“Foreign Exchange
and International Trade Law” and its related laws) will be
applied to this product and its accessories under certain
conditions. The Export Administration Regulations are also
applied. To export or reexport this terminal and its
accessories, conduct all legally required procedures at your
own risk and expense. For details on the procedures, contact
the Ministry of Economy, Trade and Industry or the US
Department of Commerce.
Export Control Regulations
dt25_E.book 501 ページ ２００８年５月１４日　水曜日　午後３時１１分
518
e24_dt25_7e.fm
[518/529]
Index/Quick Manual
Remove the Quick Manual attached to the end of this manual by cutting along the perforations and fold it as shown below.
Carry the Quick Manual “Overseas Use” when the mobile phone is used with the International Roaming (WORLD WING) overseas.
■Folding the Quick Manual
Be careful of injuries when cutting out the Quick Manual.
Quick Manual
How to use the Quick Manual
(Completed)
<Cut here>
Cut along the perforations.
This manual is produced using recyclable material. Please recycle when no longer needed.
dt25_E.book 518 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
FOMA SH906iTV
General Inquiries <DOCOMO Information Center>
(In English)
※Can be called from mobile phones and PHSs.
(In Japanese only)
※Can only be called from DOCOMO mobile phones.
Please confirm the phone number before you dial.
(In Japanese only)
※Can only be called from DOCOMO mobile phones.
(In Japanese only)
※Can be called from mobile phones and PHSs.
Please confirm the phone number before you dial.
1In stand-by, press a (for 1+ seconds)/[Phone].
2Enter a name/t/9/enter a phone
number/t/select a phone type icon/t/
S/enter a mail address/t/select a mail
address type icon/t/i/t/select Add to
PushTalk PB/t.
■Other save items
Q: Group F: Secret code
a: Company/school <: Select ring tone
q: Department V: Mail ring tone
r: Title q: Called LED color
N: Postal code -: Called LED pattern
O: Postal address :: Mail/Message LED color
P: Birthday +: Mail LED pattern
G: Memo 8: Picture call set
;: Secret 1: Substitute image
1In stand-by, press r (I)/q (M)/select a
phone number/C/[Add to phonebook]/
[Save new to phone]/add to the phonebook.
1In stand-by, press a/select a name/C/[Edit
data]/[Edit]/select an item/t/edit.
Quick Manual
Registration/Contacts
s0120-005-250 (toll free)
r(No prefix) 151 (toll free)
If you have problems with your FOMA
r(No prefix) 113 (toll free)
s0120-800-000 (toll free)
Adding to the phonebook (Phone) Adding to the phonebook from Redials/
Received calls
Editing phonebook entries
1In the text input screen, press a/select the
input mode/t.
1In the text input screen, press m.
1Move the cursor to the text and press c.
To delete all text: At the end of the message, press c
(for 1+ seconds).
1In the text input screen, press a (for 1+
seconds)/select a phrase/t/t.
1In the text input screen, press i.
To switch between Pictograph and Deco-mail
pictograph: Press i.
To switch between single- and double-byte symbols:
Press C.
1In the text input screen, press m (for 1+
seconds)/select an emoticon/t.
1In the text input screen, move the cursor to the
start point/C/[Copy]/[Cut]/t.
2Move the cursor to the end point/t.
3Move the cursor to the paste location/* (for
1+ seconds).
Ex.) 今日のテニス3時t
1In the text input screen,
press 2 (twice)/p/[今
日].
As each hiragana character is
entered, conversion
candidates appear and they
can be selected.
Text input
Changing the input mode
Switching upper/lower case
Deleting text
Using phrases
Entering pictographs/symbols
Entering emoticons
Cutting/Copying/Pasting text
Text input example
–1– –2–
–4––3– –5–
dt25_E.book 519 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
2Press p/[の].
3Press 453/o/[テニス].
Use o for One-touch conversion.
4Press a (five times)/t/3.
Press a (five times) for single-byte alphanumeric
mode.
5Press a (twice)/t/3 (twice)/*/p/
[時].
Use * for dakuten mark.
6Press i/t.
1In the Custom menu, select [Settings]/[Disp/
LED/Power saver]/[Font style]/[Font style
setting]/select the font/t.
1In the Custom menu, select [Settings]/[Disp/
LED/Power saver]/[Font style]/[Font size]/
[Individual setting]/select the [Input] field/
t/select the font size/t/[Yes].
To change collectively: In stand-by, press 5 (for 1+
seconds).
1In stand-by, press C/t/t.
■Shooting panoramic pictures
1In the still picture shooting screen, press m/
t/move the FOMA terminal to either direction
of left or right/t/t.
1In the still picture shooting screen, press C/
[Switch camera-mode]/[Movie]/t/t/
[Save].
1In the Custom menu, select [Data box]/[My
picture]/select a still picture/t.
Changing the font (font style)
Changing the font size
Camera
Shooting still pictures
Shooting movies
Displaying still pictures
1In the Custom menu, select [Data box]/
[i-motion]/select a movie/t.
1In the Custom menu, select [1Seg]/[Channel
setting].
2Select the number to save/C/[Auto channel
set]/[Yes].
3Select a prefecture/district/t/t/[Yes].
1In the Custom menu, select [1Seg]/[Channel
setting]/select a channel list/t.
1In stand-by, press x.
To record a movie of 1Seg programs: While watching
1Seg, press i (for 1+ seconds)/(record)/i.
To record 1Seg programs as a still picture: While
watching 1Seg, press i.
1In the Custom menu, select [Data box]/[1Seg]/
select a video/t.
1In the Custom menu, select [Data box]/
[MUSIC]/select the data type/t/select
music data/t.
1In stand-by, press m (for 1+
seconds)/select the [To]
field/t/select the input
method.
Select [Search
phonebook]/select a
recipient/t.
Select [Direct input]/enter
an address/t.
Select [Sent messages]/select a recipient/t/
t.
Playing back movies
Watching 1Seg
Performing the Automatic channel setting
Selecting a channel list
Watching 1Seg
Watching videos
Music playback
Using the MUSIC Player
Key operations during playback
To pause/play t
To stop m
To adjust the volume u
To play previous song/return to
the beginning of song
q
To play next song r
To end MUSIC Player c/H/[Yes]
Mail
Composing and sending i-mode mail
–7–
–10–
–6– –8–
–11––9–
dt25_E.book 520 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
Select [Rcvd messages]/select a recipient/t/
t.
Select [Mail members]
/
select a mail member
/
t
.
2Select the [Sub] field/t/enter a subject/
t/[Msg]/enter the message text/t/i.
1In the text input screen, press C/[Decorate
mail]/select a decoration type/t/specify
decoration/t/input text/t/i.
1In stand-by, press m (for 1+ seconds)/select
the attachment field (No attachment)/t/
select the file to attach.
Select [Image]/select an image/i.
Select [Melody]/select a melody/i.
Select [i-motion]/select an i-motion/i.
Select [ToruCa]/select a ToruCa/i.
Select [PDF]/select a PDF/i.
Select [Phonebook]/select a save destination/
t/select a name/t.
Select [Schedule]/select a save destination/
t/(select a day/i)*/select a schedule/t.
* No operation is needed if [microSD] is selected as the
save destination
Select [Bookmark]/select a save destination/
t/select a bookmark/t.
Select [Document]/select a file/i.
Select [Other]/select a file/t.
Select [Start cam (still)]/t/t.
Select [Start cam (movie)]/t/t/[Save].
1In stand-by, press m/[Compose SMS]/select
the [To] field/t/[Direct input]/enter an
address/t/[Msg]/enter the message/
t/i.
1Mail is automatically received.
2Select [Mail]/select the mail/t.
1In stand-by, press m/[Check new message].
SMS: Press m/[Check new SMS].
1In the received message details screen, press
C/[Reply/Forward].
2Select the reply method/t.
3Compose and send a mail.
1In the received message details screen, press
C/[Reply/Forward]/[Forward].
2Enter an address and send a mail.
Sending Deco-mail
Attaching a file Composing and sending SMS
Receiving mail automatically
Checking for new i-mode mail
Replying to i-mode mail
Forwarding i-mode mail
1In the Custom menu/Basic menu, press a.
1In the Basic menu, enter a function number.
Menu list
Switching between the Custom menu/Basic menu
Recalling a function number
USnd/Vibrator/Manner
USelect volume phone ring vol, Mail ring vol, PushTalk
tone vol, Key/Standby i-motion, Charge
start sound, Charge end sound, Timer
sound
VSelect sound Select ring tone, Select mail tone,
PushTalk tone, Shutter sound, Timer
sound
WVibrator Vibration mode, Mail vibration
XManner mode ON (Normal, Silent, Original), OFF
YHeadset setting
ZRing time
setting
Mail ring time set, PT ring time set
[Set mute ring time
\Hold/On hold
tone
Set on hold tone, Set hold tone
]Snd playbck
(melody)
Stereo effects, Equalizer
VDisp/LED/Power saver
USet screen Stand-by display, Clock display,
Calendar display, Stand-by memo disp,
Desktop clock, Scrn rotation set, Sub)
Caller ID disp, Sub) Clock display
VFont style Font style setting, Font size
WThemes Kisekae Tool, Call/Rcv display, Send/
Rcv display, Submenu image, Dial
image set, Animate notices, Signal/
batt/s clock, Color theme setting
USnd/Vibrator/Manner
XLED settings Called LED, Mail LED, Notice LED,
In-call LED, Alarm/Timer LED, IC card
LED, open-clos/rotatLED
YDisplay img
quality
Vibrant image mode, Control by scene
ZLight/Power
saver
Norm (auto bright), Norm (fixed bright),
Eco mode (Pwr saver), Original Eco
mode
[VeilView Linked manner, Pattern
\Menu priority
VDisp/LED/Power saver
–13– –14–
–16––15– –17–
–12–
dt25_E.book 521 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
WGeneral settings
UCheck status Owner Information, Check memory,
Battery level, Check settings
VText input
setting
User dictionary, Dwnld dictionary, Edit
phrase, Clear memory terms
WAuto power
ON/OFF
Auto power ON, Auto power OFF, Link
alarm/power ON
XDate settings
YSelect language
ZTOUCH
CRUISER set
Usage settings, Pointer speed, Scroll
speed
[USB mode setting
\Scanning
function
Update, Set auto-update, Set scan,
Version
]Software update
TReset settings
XNW Services
UVoice Mail Check messages, Play Messages,
Activate VoiceMail, Set ring time,
Deactivate VoiceMail, Check setting,
Voice Mail setting, Notification setting,
Notification
VCall waiting Activate, Deactivate, Check setting
WCall forwarding Activate, Deactivate, Register number,
Forwarding No. busy, Check setting
XBar nuisance
calls
Register caller, Register selected No,
Delete all entries, Delete last entry,
Check No of entries
YNotify caller ID Check setting, Notify caller ID
ZCaller ID
request
Activate, Deactivate, Check setting
[Talk time/cost
\2in1 setting Mode switching, Phonebook 2in1 set,
Stand-by display, Set call/receive No.,
2in1 function OFF, Receive avoidance
]In-call arrival
act
Set arrival act, Arrival Call Act
YOther NW Services
URemote control Activate, Deactivate, Check setting
VDual network Switching, Status request
WEnglish
guidance
Guidance setting, Check setting
XService
number
ドコモ故障問合せ,
ドコモ総合案内・受付
YAdditional
service
USSD, Reply message
ZMulti number Set multi number, Check setting,
Number setting
[Chaku-moji Create message, Message display
\Roaming
guidance
Activate, Deactivate, Status request
XNW Services
ZPhone settings
UIn-call settings Noise reduction, Reconnect signal,
Quality alarm
VHeadset sw to call
WIncoming
settings
Any key answer, Auto answer setting,
Melody Call setting, Rotation-link repl
XVideophone set Redial voice call, Set sending image,
Display setting, Subscreen position,
Visual preference, Notify switch mode,
Hands-free V.phone, V-phone while
packet
YRecord
message
Record message, Answering duration,
Reply message, V.phone reply image
ZSet PushTalk Set PT arrival act, Hands-free PT
[Set when
folded
Phone/Videophone, PushTalk
\Self mode
]Other settings Int’l prefix, Sub address, Int’l dial
assist, International Roam., In-area
status
[Security
USecret mode
VUIM Settings PIN1 code input set, Change PIN1
code, Change PIN2 code
WAccept/Reject
calls
Accept calls, Reject calls, Reject
unknown, User unset, Reject
payphone, Reject not support
XShow call/
received
Show rcvd calls, Show redial
YShow sent/
received
Show sent messages,
Show rcvd messages
ZLock settings All lock, Keypad dial lock,
Function lock, IC card lock,
Multi easy lock set,
Multi lock auto-set
[Change security code
\Delete all data Delete user data, Del secret data
Other settings
\Initial setting
TOwn number
–19–
–22–
–18– –20–
–23––21–
dt25_E.book 522 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
]UData box
UMy picture
VMUSIC
WMusic&Video ch
Xi-motion
Y1Seg
ZMelody
[My Documents
\Kisekae Tool
]Machi-chara
TChara-den
]VLifeKit
UBar code reader
VReceive Ir data
WmicroSD
manager
View microSD data, Backup/restore,
Import, New manager info, Format,
USB mode setting
XBluetooth
Accept Registered, Receive Bluetooth,
List/cnnct/discnnct, Register new device,
Bluetooth Power OFF, Bluetooth setting
YCard reader
ZText memo
[Character reader
\Schedule
]Timer/Alarm Timer, Alarm, Wakeup TV
TCalculator
rUData Sec. Service
]WMedia tool
UManga&BookReader
VDocument Viewer
WPDF Viewer
XVoice recorder
YVoice memo/Rec msg
ZQuick search
Other menus
]XMUSIC
]YOsaifu-Keitai
]Z1Seg
※In the confirmation screen, select [Yes].
Voice Mail Service is a paid option (monthly fees apply) that
requires subscription.
1In the Custom menu, select [Settings]/[NW
Services]/[Voice Mail].
2Select [Activate VoiceMail]/[Activate
VoiceMail].
To deactivate: Select [Deactivate VoiceMail].
To play messages: Select [Play Messages].
To check messages: Select [Check messages].
Call Waiting is a paid option (monthly fees apply) that requires
subscription.
1In the Custom menu, select [Settings]/[NW
Services]/[Call waiting].
2Select [Activate].
To deactivate: Select [Deactivate].
To check settings: Select [Check setting].
Call Forwarding Service is a free option (no monthly fees) that
requires subscription.
1In the Custom menu, select [Settings]/[NW
Services]/[Call forwarding].
2Select [Activate]/[Activate].
To deactivate: Select [Deactivate].
To check settings: Select [Check setting].
Subscription is not required (no monthly fees).
1In the Custom menu, select [Settings]/[NW
Services]/[Caller ID request].
2Select [Activate].
To deactivate: Select [Deactivate].
To check settings: Select [Check setting].
Other functions
Manner mode enable/disable # (for 1+ seconds)
Public mode (Drive mode)
activate/deactivate
* (for 1+ seconds)
Multi easy lock
activate/deactivate t (for 1+ seconds)
Show i-Channel list c (J)
Activate Quick search p
Show i-mode menu i
Show i-appli software list screen i
(
,
) (for 1+ seconds)
Supportbook $
Activate Multi Assistant
(Multitask)
$ while using a
function
Display Shortcut menu o
Register Shortcut menu $ (for 1+ seconds)
when m appears
Side Key Guard Set/Disable & (q) (for 1+ seconds)
VeilView ON/OFF y (for 1+ seconds)
Network services
Voice Mail Service
Call Waiting
Call Forwarding Service
Caller ID Request Service
–25– –26–
–28––27– –29–
–24–
dt25_E.book 523 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
※Icons are shown in the order of Main display and Sub display.
Icon list
Main display
Sub display
1]/aSignal status
2"/bBattery level
{/kCharging
37=AABNO i-mode/Full Browser
4oSSL
5GNIQ i-appli
6mShortcut menu
7UhHv[/xi-mode mail/SMS/Area Mail
received
8AB
GISTz8
<9>07! Message R/F
9^ (gray)/mmicroSD Card is inserted
^ (pink)/lmicroSD Card is being used
aClock display
ba1Seg being recorded
c]
D to PkRecord message
d[Silent
ebVibrator
※Refer to P. 34 to P. 37 of the manual for detailed explanations
of displayed icons.
fZ/fManner mode
g_/dPublic mode (Drive mode)
hWXStorage status of i-mode center
iH/cIC card lock
jRSTUVW
KX/ie Restriction indicator
k;Hands-free
MBluetooth hands-free
l\Alarm
m0Music&Video Channel program
reservation
n=; i-mode mail send reservation
osEarphone/Microphone connection
pxUSB mode
qR/jFOMA card is malfunctioning or not
inserted
B/hNon-FOMA card is inserted
rg/gSelf mode
saPushTalk
tL/yBluetooth
uJ#tuNIr exchange/Bluetooth
communication/External device
vPVeilView
w4KJ 3G/GSM
xIH Status of Comics setting
yQTor u C a
zMultitask
<wOperation in progress
<Emergency contacts in case of
loss or other accidents>
Omakase Lock
※Omakase Lock is a paid service.
If Omakase Lock is subscribed while or at the same time
as when the use of the FOMA terminal is suspended, the
usage fee of Omakase Lock is not charged.
Enable/Disable Omakase Lock
s0120-524-360
Office hours: 24hours
Other contacts
<Contacts: >
<Contacts: >
<Contacts: >
※Please confirm the phone number before you dial.
–31–
–34–
–30– –32–
–35––33–
dt25_E.book 524 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
FOMA SH906iTV
For DOCOMO mobile phones
※If you use the SH906iTV, you should dial the number
+81-3-5366-3114 (to dial “+”, press the “0” key for 1+ seconds).
For fixed-line telephones
<Universal number>
※See P.19 to P.20 and P.21 to P.22 for international call access
codes of major countries (Table1) and international prefix
number for the universal number (Table2).
For DOCOMO mobile phones
※If you use the SH906iTV, you should dial the number
+81-3-6718-1414 (to dial “+”, press the “0” key for 1+ seconds).
For fixed-line telephones
<Universal number>
※See P.19 to P.20 and P.21 to P.22 for international call access
codes of major countries (Table1) and international prefix
number for the universal number (Table2).
■Setting in Japan
1In stand-by, press i/[iMenu]/[English]/
[Options]/[International Settings]/[i-mode
services Settings]/[Yes]/select the [Enter
i-mode Password] field/t/enter the i-mode
password/t/[OK].
■Setting in overseas
1In stand-by, press i/[iMenu]/[English]/
[International Settings]/[i-mode services
Settings]/[Yes]/select the [Enter i-mode
Password] field/t/enter the i-mode
password/t/[OK].
Quick Manual “Overseas Use”
Loss or theft of FOMA terminal or payment of
cumulative cost overseas
<DOCOMO Information Center> (24-hour service)
International call access code of
your country of stay (Table 1)
-81-3-5366-3114*
(toll free)
* Communication charges to Japan will apply when you make a call
from a fixed-line telephone.
International prefix number for
the universal number (Table 2)
-800-0120-0151*
*
Communication charges or other charges to your country of stay will apply.
Failures encountered overseas
<Network Technical Operation Center>
(24-hour service)
International call access code
of your country of stay (Table 1)
-81-3-6718-1414*
(toll free)
* Communication charges to Japan will apply when you make a call
from a fixed-line telephone.
International prefix number for
the universal number (Table 2)
-800-5931-8600*
* Communication charges or other charges to your country of stay
will apply.
Preparing for overseas use
Setting i-mode
■Setting in Japan
1In the Custom menu, select [Settings]/[Other
NW Services]/[Remote control]/[Activate]/
[Yes].
■Setting in overseas
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Remote access(Int.)]/[Yes]/operate
according to the voice guidance.
1In the Custom menu, select [Settings]/[General
settings]/[Date settings]/select the [Auto time
correction] field/t/[ON]/i.
1In the Custom menu, select [Settings]/[General
settings]/[Date settings]/select the [Auto time
correction] field/t/[OFF].
2Press C/select a time zone/t/select a
city/t/i.
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[3G/GSM setting]/select the
communication method/t.
Unable to use 64K data communication by connecting a PC,
etc. overseas.
Setting the remote access
Correcting the date and time automatically
Setting the time zone manually
Available network
3G network Available
GSM network Available
GPRS network Available
Setting network communication system
Services available overseas
Communication
service 3G GSM GPRS
Voice call AAA
Videophone ABB
i-mode mail ABA
i-mode ABA
i-Channel ABA
SMS AAA
Data communication
(packet transmission) ABA
–1– –2–
–4––3– –5–
dt25_E.book 525 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
Default setting: Auto (Automatically switches telecommunications
carriers)
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Network search mode].
2Select [Auto]/[Yes].
To manually switch telecommunications carriers:
Select [Manual]/select a telecommunications
carrier/t.
To re-search for the host network: Select [Network
re-search].
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Network search mode]/[PLMN
setting]/select the number of the priority
order/C.
2Select [PLMN manual select]/enter a country
code (MCC)/t/enter a network code
(MNC)/t/select a communication method/
t/[Yes].
To save from a telecommunications carrier list: Select
[UPLMN by list]/select a telecommunications
carrier/t/select a communication method/t/
[Yes].
To save the telecommunications carrier currently
connected to: Select [Set VPLMN to PLMN]/[Yes].
To change the priority: Select [Change priority]/
select a destination/t/[Yes].
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Operator name disp]/[Display on]/
[Yes].
Setting a search method of
telecommunications carrier
Network search mode
Setting a telecommunications carrier to
preferentially connect to
Displaying a telecommunications carrier
name in stand-by
Tel e co m -
munications
carrier name
If Network search mode is set to [Auto], reset Network search
mode to the FOMA network (DOCOMO) automatically when the
power is turned on after homecoming.
■Setting to the FOMA network (DOCOMO)
manually
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Network search mode]/[Manual]/
[DoCoMo].
■Using + to make an international call
1In stand-by, press 0 (for 1+ seconds)/enter
the country code, area code (city code) and other
party’s phone number/s (Phone)/i
(V.phone).
When the area code (city code) begins with 0, omit the
0 when dialing. However, include 0 when making a call
to landline phones in some countries or regions such
as Italy.
■Making an international call outside your country
of stay using country code conversion
0 at the beginning of a phone number is automatically converted to
the country code set in Country code conversion.
Example: Make a call from the phonebook
1In stand-by, press a/select the other party/
s (Phone)/i (V.phone)/[Call].
■Making an international call
Save a country number using Set country code to select a country
code before making an international call.
The following operation is available overseas only.
1In stand-by, enter a phone number/C/[Add
prefix setting]/[International Call]/select the
country code/t/s (Phone)/i (V.phone).
1In stand-by, enter a phone number/s (Phone)/
i (V.phone).
■Making a call to the phone in your country of
stay using the phonebook
1In stand-by, press a/select the other party/
s (Phone)/i (V.phone)/[Original number].
■
Making a call to a WORLD WING subscriber overseas
Even when making a call to the phone in your country of stay,
make an international call to Japan if the call recipient is a
“WORLD WING” subscriber overseas.
Setting after homecoming Making calls
Making a call outside your country of stay
(including Japan)
Making a call in your country of stay
–7–
–10–
–6– –8–
–11––9–
dt25_E.book 526 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
1In stand-by, press 0 (for 1+ seconds)/81/
enter the other party’s mobile phone number
excluding the first 0/s (Phone)/i (V.phone).
1Press s to answer an incoming call.
■Having calls made to your FOMA terminal from
Japan
Enter the phone number in the same way as it is entered in Japan
and make a call.
■Having calls made to your FOMA terminal from
countries other than Japan
Enter international access code of the country of the
caller-81-user’s phone number excluding the first 0 and make a
call.
Make this setting while still in Japan
※In the confirmation screen, select [Yes].
1In the Custom menu, select [Settings]/[Other
NW Services]/[Roaming guidance].
2Select [Activate].
To deactivate: Select [Deactivate].
To check settings: Select [Status request].
Depending on the overseas telecommunications carrier, the
setting cannot be made.
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Call barring].
2Select [Activate]/[Yes]/select the barring
method/t/enter the network security code/
t.
To deactivate: Select [Deactivate]/[Yes]/enter the
network security code/t.
To check settings: Select [Status request].
Receiving calls
Setting the roaming guidance Call barring
To use network service overseas, set Remote control to
“Activate”.
※In the confirmation screen, select [Yes].
※Operate according to the voice guidance.
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Voice Mail(Int.)].
2Select [Activate Voice Mail].
To deactivate: Select [Deactivate].
To play messages: Select [Play Messages].
To set the service: Select [Voice Mail settings].
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Call Forward (Int.)].
2Select [Activate].
To deactivate: Select [Deactivate].
To set the service: Select [Settings].
1In the Custom menu, select [Settings]/[Phone
settings]/[Other settings]/[International
Roam.]/[Roam. guidance(Int.)].
The following shows “Country code” used when making
international calls or setting International dial assist.
(As of $$ 2008)
Using network service
Voice Mail (Int.)
Call Forward (Int.)
Roaming guidance (Int.)
Country codes of major countries
Country/Region Code Country/Region Code
Australia 61 Hong Kong 852
Austria 43 Hungary 36
Belgium 32 India 91
Brazil 55 Indonesia 62
Canada 1 Italy 39
China 86 Japan 81
Czech 420 Macau 853
Egypt 20 Malaysia 60
Fiji 679 Maldives 960
Finland 358 Netherlands 31
France 33 New Caledonia 687
Germany 49 New Zealand 64
Greece 30 Norway 47
–13– –14–
–16––15– –17–
–12–
dt25_E.book 527 ページ ２００８年５月１４日　水曜日　午後３時１１分
<Cut here>
※For other country codes and details, refer to the DOCOMO
“International Services website”.
The following shows the International call access codes of major
countries.
(As of March 2008)
Peru 51 Tahiti
(French Polynesia)
689
Philippines 63
Russia 7 Taiwan 886
Singapore 65 Thailand 66
South Korea 82 Turkey 90
Spain 34 U.K. 44
Sweden 46 U.S.A. 1
Switzerland 41 Vietnam 84
Country/Region Code Country/Region Code International call access codes of major
countries (Table 1)
Country/Region Code Country/Region Code
Australia 0011 Hungary 00
Belgium 00 India 00
Brazil 0021/
0014
Indonesia 001
Ireland 00
Canada 011 Italy 00
China 00 Luxemburg 00
Czech 00 Macau 00
Denmark 00 Malaysia 00
Finland 00 Monaco 00
France 00 Netherlands 00
Germany 00 New Zealand 00
Greece 00 Norway 00
Hong Kong 001 Philippines 00
Poland 00 Taiwan 002
Portugal 00 Thailand 001
Russia 810 Turkey 00
Singapore 001 U.A.E. 00
South Korea 001 U.K. 00
Spain 00 U.S.A. 011
Sweden 00 Vietnam 00
Switzerland 00
Country/Region Code Country/Region Code
The following shows the International prefix number for the
universal number of each country.
(As of March 2008)
For lost, stolen, and cost settlement, or
malfunction of the FOMA terminal overseas,
refer to “Loss or theft of FOMA terminal or
payment of cumulative cost overseas” on the
cover of Quick Manual “Overseas Use” or
“Failures encountered overseas” on P.1.
Add the “International call access code” or
“International prefix number for the universal
number” that is assigned to your country of stay, to
the head of your phone number for inquiries.
International prefix number for the
universal number (Table 2)
Country/Region Code Country/Region Code
Argentina 00 Hong Kong 001
Australia 0011 Hungary 00
Austria 00 Ireland 00
Belgium 00 Israel 014
Brazil 0021 Italy 00
Bulgaria 00 Luxemburg 00
Canada 011 Malaysia 00
China 00 Netherlands 00
Columbia 009 New Zealand 00
Denmark 00 Norway 00
Finland 990 Peru 00
France 00 Philippines 00
Germany 00 Portugal 00
Singapore 001 Switzerland 00
South Africa 09 Taiwan 00
South Korea 001 Thailand 001
Spain 00 U.K. 00
Sweden 00 U.S.A. 011
Country/Region Code Country/Region Code About inquiries overseas
–19–
–22–
–18– –20–
–23––21–
dt25_E.book 528 ページ ２００８年５月１４日　水曜日　午後３時１１分
e24_dt25_7e.fm
[529/529] ~~~~~ ~~~~~ ~~~~~ ~~~
When using your FOMA terminal, please be considerate of those around you.
■When in an area where use is prohibited
There are places where the use of mobile phones is prohibited. Be sure to turn
off your FOMA terminal in the following places.
★On an aircraft ★In a hospital
※
There are people outside hospital wards who also use electric medical equipment.
Please make sure that your FOMA terminal is turned off in the lobby and waiting room.
■While driving
Using a mobile phone in hand while driving is regarded as a punishable act.
※If there is no choice but to receive a call, use Hands-free and tell the caller
that you will “call back”, and then pull over to a safe place to make a call.
■When in crowded places such as rush-hour trains in case
somebody nearby is using an implanted cardiac
pacemaker or implanted cardioverter-defibrillator
Your FOMA terminal may affect the operation of such equipment.
■
When in public places such as theaters, movie theaters, or museums
Use of your FOMA terminal in quiet public places will annoy others.
■When using your FOMA terminal in a restaurant or a hotel
lobby, lower your voice.
■
In crowded places, be careful not to obstruct other pedestrians.
Access DOCOMO e-site for procedures to change your address or billing plan and for request of information materials.
iMenu/料金＆お申込・設定 (Charges & Applications/Setting)/各種手続き (ドコモeサイト) (Application procedure (DOCOMO e-site))
My docomo (http://www.mydocomo.com/)/各種手続き (ドコモeサイト) (Application procedure (DOCOMO e-site))
※You will need your “Network Security Code” to access e-site from i-mode.
※No packet communication charges are incurred when accessing e-site from i-mode. Accessing from overseas will incur charges.
※You will need your “docomo ID/Password” to access e-site from PC.
※If you do not have or you have forgotten your “Network Security Code” or “docomo ID/Password”, contact the number listed in General Inquiries on the back of this manual.
※DOCOMO e-site may not be available depending upon the content of your subscription.
※You may not be able to access some e-site services due to system maintenance, etc.
From i-mode
Packet communication charges free
From a PC
Please follow proper etiquette
Turn off your FOMA terminal in the following places
Be careful of where you use your FOMA terminal and the
volume of your voice and the ring tone
Be considerate of the privacy of the individuals around you
tPlease be considerate of the privacy of individuals around
you when taking and sending images using a
camera-enabled mobile phones.
The following functions will help you to keep your manners in public
There are useful functions you can use to set your FOMA
terminal not to answer incoming calls, and to silence all sounds.
●Manner mode (nP. 110)/Original manner mode (nP. 111)
Silences the Key/Standby i-motion sound and all the sounds from the FOMA
terminal, and Record message is set (Manner mode). When in the Manner
mode, automatically set functions (Record message, Vibrator, Mic sensitivity up,
Ring tone, Mail ring tone, alarm tone, Key/Standby i-motion sound and Low
battery alarm) can be set to ON (enable)/OFF (disable) (Original manner mode).
●Public mode (Drive mode) (nP. 71)
The caller hears a guidance message that informs the receiver is driving
and unable to answer. The call then disconnects. Your FOMA terminal
does not sound even when it receives calls, so you can drive safely.
●Vibration mode (nP. 108)
Notifies incoming calls by vibration.
●Record message (nP. 74)
When you are unable to take a call, the Record message function records
the caller’s message.
※You can also use optional services such as Voice Mail Service
(nP. 410) and Call Forwarding Service (nP. 413).
dt25_E.book 529 ページ ２００８年５月１４日　水曜日　午後３時１１分

Navigation menu
