Contents

Manual 4

Model Description
FCC ID : APYHRO00069 Model Name : 825SH
Brand Name : SoftBank
Destination : Ja
p
an Market onl
y
Emission Type : GSM(PCS) ----- GXW Type of Equipment :
Cellular Phone / Bluetooth enable
RF-section
Items
Cellular Phone
Technical Specification 3GPP R99
Frequency Band
WCDMA
2000MHz(band I) : Tx 1922.6 to 1977.4MHz, Rx 2112.6 to 2167.4MHz
NOTE: Band I does not operate in USA
GSM
900MHz : Tx 880.2 to 914.8MHz, Rx 925.2 to 959.8MHz
1800MHz : Tx 1710.2 to 1784.8MHz, Rx 1805.2 to 1879.8MHz
1900MHz : Tx 1850.2 to 1909.8MHz, Rx 1930.2 to 1989.8MHz
NOTE: GSM900/1800MHz Band do not operate in USA
Tx Power
WCDMA : 24dBm+1dB/-3dB
GSM
900MHz : 33dBm±2dB(GSM/GPRS)
1800MHz: 30dBm±2dB(GSM/GPRS)
1900MHz: 30dBm±2dB(GSM/GPRS)
Transmission Technology WCDMA : DS/CDMA, FDD
GSM : FDMA/TDMA
Data Transmission GSM GPRS: GMSK
GSM GPRS Class 10 (Total 5slots, TX: max 2 / RX: max 4)
Voice Codec WCDMA : AMR
GSM : EFR/ FR
Antenna WCDMA Antenna: Reversed F Type Antenna
GSM Antenna: Reversed L Type (See attached construction drawing)
Bluetooth
Technical Specification Bluetooth Version 2.0 (without EDR)
Frequency Band TX 2402MHz to 2480MHz
RX 2402MHz to 2480MHz
Tx Power Class2, Nominal 0dBm (Max +4dBm / min -6dBm)
Type of Modulation GFSK
Transmission Technology FHSS
Antenna Antenna : See attached construction drawing
Reversed L-Type / Gain= 0 dBi
Rev1.0
Feature
Cell Phone Feature
SIM Plug-in 3V SIM card slot
Display
Main 2.8inch, 262,144 colors TFT(ASV), 240x400(WQVGA) with Backlight
Ｓub None
Camera
Main C-MOS 2M pixel
Ｓub None
Battery/ Talk time
Battery Capacity 720mAh
Battery type Rechargeable Lithium-Ion Battery
standby time WCDMA 330h / GSM 310h
talk time WCDMA 240min. / GSM 210min.
Dimensions
Target size 49.0(W) x 102.9(D) x 16.7(H)mm (Close position)
Target weight 112g
Key Layout Soft key (2keys), Navigation key (4keys), Center key, Custom key
(2keys), 0-9 numeric keys, Send/End keys, “*”, ”#”, “Clear” and 6 side
keys
FeliCa Faver1.5 (Card mode only ----- Passive Device)
Interface
External I/F
Headset connector For Stereo Headset (10 pins)
MCPC connector For USB Cable or PC Link cable or AC Charger
SIM card terminal 1 slot
SD Card connector For micro SD card (1 slot)
Integrated charger circuit The terminals of charging are for using a cradle.
Accessory
Accessory
AC Charger Optional Accessories,
Input AC 100 to 240V Output DC 5.4V/700mA
Battery Inbox Accessories,
Lithium-Ion,DC3.7V 720mAh
Stereo Handsfree(Headset) Optional Accessories
USB Data Cable Optional Accessories
