Manual 4
Model Description
FCC ID : APYHRO00071
Destination : Japan Market only
Emission Type : GSM GXW
Model Name : 824SH
Brand Name : SoftBank
Type of Equipment :
WCDMA & Tri-band GSM Dual mode Mobile
Phone / Bluetooth enable
RF-section
Items
Technical Specification 3GPP R99
WCDMA
2000MHz(band I) : Tx 1922.6 to 1977.4MHz Rx 2112.6 to 2167.4MHz
NOTE: Band I does not operate in USA
Frequency Band GSM
900MHz : Tx 880.2 to 914.8MHz Rx 925.2 to 959.8MHz
1800MHz : Tx 1710.2 to 1784.8MHz Rx 1805.2 to 1879.8MHz
1900MHz : Tx 1850.2 to 1909.8MHz Rx 1930.2 to 1989.8MHz
NOTE: GSM900/1800MHz Band do not operate in USA
WCDMA : 24dBm+1dB/-3dB
Tx Power GSM
900MHz 33dBm±2dB(GSM/GPRS)
1800MHz 30dBm±2dB(GSM/GPRS)
1900MHz 30dBm±2dB(GSM/GPRS)
Transmission Technology WCDMA : DS/CDMA, FDD
GSM : FDMA/TDMA
Data Transmission GSM : GMSK
GSM GPRS Class 10 (Total 5slots, TX: max 2 / RX: max 4)
Voice Codec WCDMA : AMR
GSM : EFR/ FR
Cellular Phone
Antenna Integrated Antenna: L Type Antenna ------ See attached construction drawing.
Technical Specification Bluetooth Version 2.0 (without EDR)
Frequency Band TX 2402MHz to 2480MHz
RX 2402MHz to 2480MHz
Tx Power Class2, Nominal 0dBm (Max +4dBm / min -6dBm)
Type of Modulation GFSK
Transmission Technology FHSS
Bluetooth
Antenna Integrated Antenna ---- See attached construction drawing
Reversed Mono-pole L-Type / Gain= 0 dBi
Rev1.0
Feature
SIM Plug-in 3V SIM card slot
Display
Main 2.8inch, 262,144 color TFT(ASV), 240x400(WQVGA) with Backlight
Ｓub 0.5inch,(Organic EL), 60x32dot
Camera
Main C-MOS 3.2M pixel
Ｓub None
Battery/ Talk time
Capacity 770mAh
Battery type Rechargeable Lithium-Ion Battery
standby time TBD
talk time TBD
Dimensions
Target size 50(W) x 105.5(D) x 14.9(H)mm (Close position)
Target weight 115g
Key Layout Soft Key1 ,Soft Key2 ,Multi Selector key ,Decision key ,Shortcut Key ,TV key ,Off
hook key ,Clear key ,On hook key ,0-9unmeric key ,* key ,# key ,Multi key ,and 3 side
key
Cell Phone Feature
Interface
Headset connector For Stereo Headset (10 pins)
MCPC connector For USB Cable or PC Link cable or AC Charger
SIM card terminal 1 slot
SD Card connector For micro SD card (1 slot)
Integrated charger circuit The terminals of charging are for using a cradle.
External I/F
Accessory
AC Charger Optional Accessories,
Input AC 100 to 240V Output DC 5.4V/700mA
Battery Inbox Accessories,
Lithium-Ion, DC3.7V 770mAh
Stereo Handsfree(Headset) Optional Accessories
USB Data Cable Optional Accessories
Accessory
