Model Description
FCC ID : APYHRO00080 Model Name : SH9020C
Brand Name : SHARP
Destination : China Market only
Emission Type : GSM(PCS) ----- GXW
EGPRS ----- G7W Type of Equipment :
Cellular Phone / Bluetooth enable
RF-section
Items
Cellular Phone
Technical Specification 3GPP R99
Frequency Band
GSM
900MHz : Tx 880.2 to 914.8MHz Rx 925.2 to 959.8MHz
1800MHz : Tx 1710.2 to 1784.8MHz Rx 1805.2 to 1879.8MHz
1900MHz : Tx 1850.2 to 1909.8MHz Rx 1930.2 to 1989.8MHz
NOTE: GSM900/1800MHz Band do not operate in USA
Tx Power
GSM
900MHz 33dBm±2dB(GSM/GPRS) / 33dBm±2dB(EGPRS)
1800MHz 30dBm±2dB(GSM/GPRS) / 30dBm±2dB(EGPRS)
1900MHz 30dBm±2dB(GSM/GPRS) / 30dBm±2dB(EGPRS)
Transmission Technology GSM : FDMA/TDMA
Data Transmission GSM : GMSK / 8PSK
GSM GPRS Class 10 (Total 5slots, TX: max 2 / RX: max 4)
GSM EGPRS Class 10 (Total 5slots, TX: max 2 / RX: max 4)
Voice Codec GSM : EFR/ FR
Antenna Integrated Antenna: L Type Antenna
See attached construction drawing
Bluetooth
Technical Specification Bluetooth Version 2.0 (without EDR)
Frequency Band TX 2402MHz to 2480MHz
RX 2402MHz to 2480MHz
Tx Power Class2, Nominal 0dBm (Max +4dBm / min -6dBm)
Type of Modulation GFSK
Transmission Technology FHSS
Antenna Integrated Antenna : Reversed Mono-pole L-Type / Gain= 0 dBi
See attached construction drawing
Class B Personal computer PERIPHERAL DEVICE
Items
USB
Clock Frequency 26MHz, 208MHz
USB Data Cable / Connector Shielded / Unshielded
Rev1.0
Feature
Cell Phone Feature
SIM Plug-in 3V SIM card slot
Display
Main 3.3inch, 16,777,216 colors TFT(ASV), 854x480(FWVGA) with Backlight
Ｓub 0.8inch, (Organic EL), 96x16 dots
Camera
Main C-MOS 5M pixel
Ｓub None
Battery/ Talk time
Capacity 760mAh
Battery type Rechargeable Lithium-Ion Battery
standby time TBD
talk time TBD
Dimensions
Target size 50.5(W) x 113.0(D) x 19.85(H)mm (Close position)
Target weight 135g
Key Layout Left Soft Key ,Right Soft Key ,Navigation keys (4Keys) ,Center key ,Shortcut
Key ,Multimedia Key ,Send/End keys ,function keys (3keys) ,0-9 unmeric key
,* key ,# key ,Clear key ,and 3 side keys
Interface
External I/F
Headset connector For Stereo Headset (10 pins)
MCPC connector For USB Cable or AC Charger
SIM card terminal 1 slot
SD Card connector For micro SD card (1 slot)
Integrated charger circuit
Accessory
Accessory
AC Charger Inbox Accessory,
Input AC 100 to 240V Output DC 5.0V/680mA
Battery Inbox Accessory,
Lithium-Ion, DC3.7V 760mAh
Stereo Handsfree(Headset) XN-1ER90 （Inbox Accessory）
USB Data Cable Inbox Accessory
