manual model description
![](/img.php?id=1039378&img=bg1.png)
Model Description
FCC ID : APYHRO00084
Destination : Taiwan Market only
Model Name : WX-T930
Brand Name : FAREASTONE/SHARP
Emission Type : GSM(PCS) ----- GXW Type of Equipment :
Cellular Phone / Bluetooth enable
RF-section
Items
Technical Specification 3GPP R99
WCDMA
2000MHz(band I) : Tx 1922.6 to 1977.4MHz Rx 2112.6 to 2167.4MHz
NOTE: Band I does not operate in USA
Frequency Band GSM
900MHz : Tx 880.2 to 914.8MHz Rx 925.2 to 959.8MHz
1800MHz : Tx 1710.2 to 1784.8MHz Rx 1805.2 to 1879.8MHz
1900MHz : Tx 1850.2 to 1909.8MHz Rx 1930.2 to 1989.8MHz
NOTE: GSM900/1800MHz Band do not operate in USA
WCDMA : 24dBm+1dB/-3dB
Tx Power GSM
900MHz : 33dBm±2dB(GSM/GPRS)
1800MHz: 30dBm±2dB(GSM/GPRS)
1900MHz: 30dBm±2dB(GSM/GPRS)
Transmission Technology WCDMA : DS/CDMA, FDD
GSM : FDMA/TDMA
Data Transmission GSM : GMSK
GSM GPRS Class 10 (Total 5slots, TX: max 2 / RX: max 4)
Voice Codec WCDMA : AMR
GSM : EFR/ FR
Cellular Phone
Antenna Integrated Antenna: Reversed L Type Antenna
See attached construction drawing
Technical Specification Bluetooth Version 2.0 (without EDR)
Frequency Band TX 2402MHz to 2480MHz
RX 2402MHz to 2480MHz
Tx Power Class2, Nominal 0dBm (Max +4dBm / min -6dBm)
Type of Modulation GFSK
Transmission Technology FHSS
Bluetooth
Antenna Integrated Antenna --- See attached construction drawing
Reversed L-Type / Gain = 0dBi
Class B Personal computer PERIPHERAL DEVICE
Items
Clock Frequency 32.768kHz, 26MHz, 208MHz
USB
USB Data Cable / Connector Shielded / Unshielded
Rev1.0
![](/img.php?id=1039378&img=bg2.png)
Feature
SIM Plug-in 3V SIM card slot
Display
Main 2.95inch, 16,777,216 colors TFT(ASV), 854x480(FWVGA) with Backlight
Sub 0.8inch, (Organic EL), 96x16 dots
Camera
Main C-MOS 8.5M pixel
Sub CIF-CMOS
Battery/ Talk time
Capacity 680mAh
Battery type Rechargeable Lithium-Ion Battery
standby time TBD
talk time TBD
Dimensions
Target size 48.0(W) x 105.0(D) x 17.3(H)mm (Close position)
Target weight 110g
Key Layout Left Soft Key ,Right Soft Key ,Navigation keys (4Keys) ,Center key ,Shortcut
Key ,Multimedia Key ,Send/End keys ,function keys (3keys) ,0-9 unmeric key
,* key ,# key ,Clear key ,and 4 side keys
Cell Phone Feature
Interface
Headset connector For Stereo Headset (10 pins)
MCPC connector For USB Cable or AC Charger
SIM card terminal 1 slot
SD Card connector For micro SD card (1 slot)
Integrated charger circuit
External I/F
Accessory
AC Charger Inbox Accessory,
Input AC 100 to 240V Output DC 5.2V/650mA
Battery Inbox Accessory,
Lithium-Ion, DC3.7V 680mAh
Stereo Handsfree(Headset) Inbox Accessory
USB Data Cable Optional Accessory
Accessory
