Model Description
Rev1.0
Model Description
FCC ID : APYHRO00093
Destination : Japan Market only
Emission Type : CDMA (800M Cellular)------ F9W
Model Name : CDMA E05SH
Brand Name : au by KDDI
Type of Equipment :
Cellular Phone/Bluetooth enabled
RF-section
Items
Technical Specification 3GPP2 Release A
Release 0 operates in USA.
Frequency Band
CDMA2000 Band Class0 (800MHz cellular band) :
TX : 824.7MHz (1013ch) － 848.37MHz (779ch)
RX : 869.7MHz (1013ch) － 893.37MHz (779ch)
CDMA2000 Band Class3 (JTACS band) (Japan) :
TX : 824.76MHz － 829.23MHz
898.75MHz － 900.25MHz
915.75MHz － 924.25MHz
RX : 843.75MHz － 845.25MHz
860.75MHz － 869.25MHz
869.76MHz － 874.23MHz
CDMA2000 Band Class6 (IMT-2000) (Japan) :
TX : 1925.75MHz － 1939.25MHz
RX : 2115.75MHz － 2129.25MHz
NOTE: Band Class 3 and 6 do not operate in USA
Tx Power
CDMA2000 (Band Class0/3 ) : 23.7dBm+1dB/-1dB
CDMA2000 (Band Class6 ): 22.5dBm+1db/-1dB
NOTE: Band Class 3 and 6 do not operate in USA
CDMA2000 : MC- CDMA, FDD
Transmission Technology CDMA2000 , 1xEV-DO (HDR):CDMA/TDMA,FDD
NOTE: 1xEV-DO does not operate in USA
Data Transmission
CDMA2000 : High Speed Packet Data (SO33)
Medium Speed Packet Data (SO25)
Low Speed Packet Data (SO15)
BPSK,HPSK/QPSK
CDMA2000 1xEV-DO: BPSK,QPSK,8-PSK,HPSK,16-QAM
NOTE : 1xEV-DO does not operate in USA
CDMA SO15 and 25 do not operate in USA
Voice Codec CDMA2000: EVRC
Cellular Phone
Antenna Integrated Antenna: Type L Antenna ------ See attached assembled drawing
Technical Specification Bluetooth Version 2.0 (With EDR)
Frequency Band TX 2402MHz to 2480MHz
RX 2402MHz to 2480MHz
Tx Power Class2, Nominal 0dBm (Max +4dBm / min -6dBm)
Type of Modulation GFSK
Transmission Technology FHSS
Bluetooth
Antenna Integrated Antenna ---- See attached assembled drawing
Reversed Mono-pole Type L / Gain= 0 dBi
Technical Specification NFCIP-1 (ISO/IEC18092)
Frequency Band 13.56 -13.56MHz
Type of Modulation ASK (10%)
Antenna Integrated Loop Antenna
RF ID (FeliCa)
NOTE: FeliCa does not operate in USA
Class B Personal computer PERIPHERAL DEVICE
Items
Clock Frequency 19.2MHz, 768MHz
USB
USB Data Cable / Connector Shielded / Unshielded
Feature
SIM Plug-in 3V SIM card slot
Display
Main 2.6inch, 262,144 color TFT (ASV), 240x400 (WQVGA) with Backlight
Camera
Main C-MOS 2.0 Mega pixel
Battery/ Talk time
Capacity 930mAh (3.5Wh)
Battery type Rechargeable Lithium-Ion Battery
standby time 300hrs
talk time 270min
Dimensions
Target size 48.4(W) x 138.0(D) x 17.8(H)mm
Target weight 130g (Battery included)
Cell Phone Feature
Key Layout
Phone book key ,Application key ,Mail key ,EZ Web access key , Decision key ,
Off hook key ,Clear/Memo key ,On hook/Power key ,0-9numeric keys ,* key ,
# key , Multi Selector key ,and 2 side keys
Interface
Headset connector None (Common with MCPC connector)
MCPC connector For Stereo Headset or USB Cable or PC Link cable or AC Charger
R-UIM(SIM) card terminal 1 slot
SD Card connector For micro SD card (1 slot)
Integrated charger circuit The terminals of charging are for using a cradle.
External I/F
Accessory
AC Adapter Optional accessories
input AC 100 to 240V, 50/60Hz Output DC 5.0V/600mA
Battery Inbox accessories
Lithium-ion, DC3.7V 930mAh (3.5Wh)
Stereo Handsfree(Headset) Optional accessories
Accessory
USB data cable Optional accessories
L=800mm typ.
