Manual
i
First Step Guide
See Online User Guide for "Safety Precautions."
Before Using Handset ii
Handset Functions vii
General Notes xiv
Customer Service xvii
Accessory
Battery (SHBCR1)
Battery Installation
Remove cover
Press and slide as shown.
.
Insert battery
Close cover
Charging
Use specified AC Charger ZTDAA1 (sold
separately) only.
AC 100V Outlet
Blades
AC
Charger
Release
Tabs
1
External
Device Port
Illumination Light
Port Cover
Charger
Connector
Arrows 2
3
Open Port Cover to insert
Charger Connector
Plug AC Charger into AC
outlet
Illumination Light (center LED only)
.
glows red while charging.
Illumination Light goes out when
.
battery is full.
After charging, unplug AC
Charger, then disconnect
handset
Before Using Handset
ii
USIM Card Installation
1
2
3
Notch
Using Tab, pull out Tray
until it clicks
Slide in USIM Card with IC
chip facing up
Push in Tray fully
Insert battery (P.ii)
First power off handset and remove
.
battery.
Do not force USIM Card into/out of
.
handset.
USIM Card must be inserted to use
.
handset.
USIM PIN
4-digit code (
9999
by default); activate
PIN Entry to restrict usage. Change PIN
as needed.
PIN Lock & Cancellation (PUK Code*)
■
Entering incorrect PIN three consecutive
times activates PIN Lock, limiting
handset use. Enter PUK Code to unlock.
For details, contact SoftBank Mobile
Customer Center, General Information.
Each USIM Card has a unique Personal *
Unblocking Key (PUK Code). Do not
disclose it to unauthorized persons.
iii
Display Indicators & Key Assignments
Signal strength Manner mode active
Within 3G range Battery strength
Packet transmission available New Voicemail
Unread mail Alarm set
Reading Memory Card
BOpen Messaging menu or
execute Softkey functions
'Open Shortcuts menu. In
text entry windows, toggle
upper/lower case
$
Delete entries, escape/
return to previous window
!
Initiate/answer calls
1
|
#
Enter numbers/characters
~
Open Dictionary
)
Select handset mode
|
Activate mobile camera
Multi Selector
Select menu items, move cursor,
or scroll pages, etc. Multi
Selector operations are indicated
in this guide as shown below:
%: Press center
c: Press left side
d: Press right side
a: Press top
b: Press bottom
AOpen Yahoo! Keitai Main
Menu or execute Softkey
functions
&Activate TV or switch entry
modes
"
Turn handset power on/off
Side Key
Volume Key operation is indicated
in this guide as shown below:
L: Press E or F
iv
Manner Mode
Minding Mobile Manners
■
Please use handset responsibly. Inappropriate
handset use can be both dangerous and
bothersome. Please take care not to disturb
others when using handset. Adjust handset
use according to your surroundings.
Activating/Canceling Manner Mode
)
, (Long)
Security Codes
Handset Code
■
9999
by default; use or change some
functions.
Administrator Code
■
9999
by default; required for Reset
Settings, Reset All, Direct Browser Lock
and Proxy Setting.
Center Access Code
■
4-digit code selected at contract; access
Optional Services via landlines or change
contract details.
Network Password
■
4-digit code selected at contract; restrict
incoming/outgoing calls (Call Barring).
Message appears for incorrect code
.
entries; retry.
If Network Password is incorrectly
.
entered three times consecutively, Call
Barring settings are locked. To resolve,
Network Password and Center Access
Code must be changed. For details,
contact SoftBank Mobile Customer
Center, General Information.
Specifications
Weight* 130 g
Continuous
Talk Time*
●● minutes (3G)
●● minutes (GSM)
Continuous
Standby Time*
●● hours (3G)
●● hours (GSM)
(clamshell closed)
Charging Time
(power off)*
AC Charger: ●● minutes
In-Car Charger: ●● minutes
Dimensions
(W
x
H
x
D)*
51
x
111
x
16 mm
(clamshell closed, without
protruding parts)
Maximum
Output
●● W (3G)
●● W (GSM)
Values calculated with battery installed.
.
*Approximate value.
v
Before Using Handset
vi
Basic Operations
Handset Power On/Off
Power On
■
" (Long)
After Power On Graphic, follow these steps:
"S"S%SbS%
Change interface to English (below).
Power Off
■
" (Long)
English Interface
%S
設定
S%S
Language
S%S
English
S%
Network Settings
A prompt appears when %, a, B or A
is pressed for the first time. Follow these
steps to retrieve Network Information
to use Network-related services and TV;
retrieval automatically sets Clock:
Yes
S%S Retrieval starts S%
My Phone Number
%S0
Calling
Voice Call
Enter number S!
"
• S Call ends
Redialing
cS A record S!
"
• S Call ends
Video Call
Enter number S%S
Video Call
S%
"
• S Call ends
Incoming Image
Outgoing Image
Other Party's
Number/Name
vi
Menu List
Messaging
Received Msg.
Create Message
Retrieve New Msg.
Drafts
Templates
Sent Messages
Unsent Messages
Chat Folder
Server Mail Box
Create New SMS
Settings
Memory Status
Yahoo!
Yahoo! Keitai
Menu List
Bookmarks
Saved Pages
Web Search
Enter URL
History
PC Site Browser
Direct Browser
Browser Settings
S! Appli
S! Appli Library
Osaifu-Keitai
Notification History
Settings
Information
Entertainment
S! Information Channel/Weather
S! Quick News
Free Contents
S! Contents Store
Media Player
S! Friend's Status
S! Circle Talk
Near chat
Blog Tool
Digital Media Viewer
BookSurfing
e-Book Viewer
Camera
Easy Auto Camera
Pro Auto Camera
Instant Camera
Fine Video Camera
Video Camera for Mail
Various Cameras
Album
Scan Barcode
Scan Card
Kanji Grabber
Review
Set Camera Key
Videos/Music
Tools
PIM/Life
Calendar
Alarms
Wakeup TV
Relaxation Time
Tasks
Calculator
Expenses Memo
Osaifu-Keitai
Simulated Call
Clock/Gauge
Stopwatch
Countdown Timer
World Clock
Hour Minder
Pedometer
Compass
S! GPS Navi
Battery Meter
Doc./Rec.
Dictionary
Search
Document Viewer
Notepad
Scratch Pad
ASCII Art
Voice Recorder
Barcode/Scan
Phone Help
Connectivity
Wi-Fi
Bluetooth
Infrared
IC Transmission
USB Mode
USB Charge
Memory Card
Backup/Restore
Data Folder
Pictures
DCIM
Ring Songs•Tones
S! Appli
Widget
Music
Videos
Lifestyle-Appli
Books
Customized Screen
Status Templates
Decoration Call
Flash®
Other Documents
Memory Status
Widget
Widget Store
Widget Contents
Widget History
Settings
TV
Digital TV
TV Player
TV-Image Folder
TV Link
TV Listing
Familink Remote
Reservation List
Settings
Recorder Contents
Phone
Phone Book
Add New Entry
Information
Call Log
Play Messages
Call Voicemail
S! Addressbook Backup
My Details
Set Category
Mail Groups
Speed Dial/Mail
Ph.Book Settings
Call Log Setting
Manage Entries
Settings
Sound/Display
Mode Settings
Display
Customized Screen
Sounds & Alerts
Date & Time
言語選択
(Language)
Ringer Output
Earpiece Volume
Change Menu
Phone/
User Dictionary
Set Key Shortcut
Viewer Position
Motion Control
Vector Pad Settings
Touch Panel
Set Key Light
Double Number
Video/Music Menu Updates
Memory Card
Backup/Restore
Locks
Software Update
Master Reset
Call
Call Time/Data Counter
Answer Phone
Voicemail/Divert
Video Call
Show My Number
Missed Calls
Int'l Calling
Call Barring
Decoration Call
Auto Answer
Call Waiting
Network
Select Network
Select Service
Re-search Signal
Offline Mode
Retrieve NW Info
Network Info
Wi-Fi
External Device
vii
Before Using Handset Handset Functions
ixviii
International Call
Enter number SBS
Int'l Call
S%S
A country S%S!
"
• S Call ends
940SH is Global Roaming eligible. •
See SoftBank Mobile Website for details:
http://mb.softbank.jp/en/global_services/
Answering a Call
When a call arrives, !
"
• S Call ends
Answer Phone
Activating
■
$ (Long)
To cancel, • $ (Long)
Playing Messages
■
$S A record S%
To stop, • %
Text Entry
Switching Entry Modes
In text entry windows, &S A mode S%
S Enter text
Example: Entering no
In text entry windows, &S
Abc
S%S
66SdS666S%
Messaging
SMS/S! Mail
SMS
■
Exchange up to 160 alphanumerics with
SoftBank handsets.
S! Mail
■
Exchange up to 30,000 characters with
e-mail compatible handsets, PCs, etc.;
attach media files, etc.
Customizing Address
Change alphanumerics before @ of
the default handset mail address.
Customizing handset mail address helps
reduce spam.
BS
Settings
S%S
Address Settings
S
%S
English
S%S Onscreen instructions
Sending Messages
BS
Create Message
(S! Mail) or
Create
New SMS
S%S Enter recipient S Enter
subject (S! Mail) S Attach files (S! Mail)S
Enter text SA
Receiving Messages
Information window opens for new mail.
% to open message list.
Phone Book
Phone Book Entry Items
Phone Number
■
Enter up to five numbers on handset
(32 digits each).
Mail Address
■
Enter up to five addresses on handset
(128 single-byte alphanumerics each).
Saving to Phone Book
bSBS
Add New Entry
S%S
Last
Name:
S%S Enter S%S
First Name:
S%S Enter S%S
Add Phone Number:
S%S Enter number S%S A type S%S
Add Email Address:
S%S Enter address
S%S A type S%SA
Editing Entries
bS An entry SBS
Edit
S%S An item
S%S Edit S%SA
Dialing via Phone Book
bS Enter reading S A name S%S
A phone number S!
Voicemail
Activating
%S
Settings
S%S
Call
(tab) S
Voicemail/
Divert
S%S
Voicemail
S%S
Activate
S%S
Always
or
No Answer
S%S Ring
time (for
No Answer
)S%
Playing Messages
%S
Phone
S%S
Call Voicemail
S%S
Follow the voice guidance
Mobile Camera
Capturing Still Images
|S Frame subject on Display S%S%
Recording Video
|SAS Frame subject on Display S%
S%S%
Handset Functions
x
Digital TV
Area Setup
Follow these steps when activating TV
for the first time:
&S
Yes
S%S A region
S%S
A prefecture S%S A locality
S%S%
Watching TV
&S A channel
S L to adjust volume
To end, • "S
Yes
S%
Panel Description
■
Signal
strength
Program
name Sound
Channel
Channel
Volume
Channel
key
Area name Station
name
Recording/Playing Programs
Recording
■
&S A channel
S ! (Long) to start
S
! (Long) to end
Playing
■
&SBS
TV Player
S%S A file
S%
To stop, • A (Long)
Yahoo! Keitai
Using Yahoo! Keitai
AS Highlight menu item S%
Using PC Site Browser
%S
Yahoo!
S%S
PC Site Browser
S%S
Homepage
S%S (Onscreen prompts S)
Highlight menu item S%
Media Player
Playing Music
%S
Entertainment
S%S
Media Player
S%S
Music
S%S
My Music
S%S
All
Music
S%SA fileS%
Sound
Effects
Volume
control
Playback
slider
Rewind
Fast forward
Pause
Title
Information
link
Elapsed
time
Volume
Artist name
Track
number
Status
Playback Mode
Adding Playlists
%S
Entertainment
S%S
Media Player
S%S
Music
S%S
My Music
S%SBS
Add New Playlist
S%S Enter name S%
xi
Managing Files
Opening Files
%S
Data Folder
S%S A folder S%S
A file S%
Format Memory Card
%S
Settings
S%S
Phone/
(tab) S
Memory Card
S%S
Format Card
S%S
Yes
S%S Handset Code S%S
Yes
S%
Software Update
Precaution
Before updating software, end all active
functions/applications.
Updating Software
%S
Settings
S%S
Phone/
(tab) S
Software Update
S%S
Software
Update
S%S Onscreen instructions
Touch Panel
Touch Display to select menu items,
move pointer, scroll pages, etc.; supports
most handset operations.
Calibrating Touch Panel
Calibrate Touch Panel to improve precision.
Hold handset normally during calibration.
%S
Settings
S%S
Phone/
(tab) S
Touch Panel
S%S
Correct Touch Panel
S%S
Yes
S%S Onscreen instructions
Important Usage Notes
Touch Panel may not respond in these
.
situations:
Use with gloved fingers/fingernails
,
Use of pens, pencils or other sharp objects
,
Use with objects placed on/against Display
,
Do not:
.
Touch Display with wet fingers
,
Subject Display to force/pressure
,
Place labels or stickers over Display
,
Handset Functions
xii
Selection & Execution
Tap
■
Tap Display to open windows or execute
Softkey functions/operations.
Camera
Tap twice to execute certain operations.
•
Long Touch
■
Touch and hold Display to execute
certain functions/operations.
Dictionary
ヨミ
Special Operations (Double Tap)
Tap twice in rapid succession (within
approximately ● seconds) to enlarge/
reduce images, etc.
Move/Draw (Drag)
Touch and drag target item to move it;
release your finger to stop/save.
Screen Scroll (Swipe)
To see items outside Display area, swipe a
finger across Display in opposite direction.
●
ＡＡＡＡＡＡＡＡＡＡ
●
ＢＢＢＢＢＢＢＢＢＢ
●
ＣＣＣＣＣＣＣＣＣＣ
●
ＤＤＤＤＤＤＤＤＤＤ
●
ＥＥＥＥＥＥＥＥＥＥ
●
ＥＥＥＥＥＥＥＥＥＥ
●
ＦＦＦＦＦＦＦＦＦＦ
●
ＧＧＧＧＧＧＧＧＧＧ
●
ＨＨＨＨＨＨＨＨＨＨ
●
ＩＩＩＩＩＩＩＩＩＩ
xiii
Enlarge/Reduce (Spread/Pinch)
Pinch or spread your fingers to reduce
or enlarge images, etc.
Handset Functions
European RF Exposure Information
■
Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits
for exposure to radio waves recommended by
international guidelines. These guidelines were
developed by the independent scientific
organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The guidelines use a unit of measurement
known as the Specific Absorption Rate, or SAR.
The SAR limit for mobile devices is 2 W/kg.
As mobile devices offer a range of functions,
they can be used in other positions, such as on
the body as described in this user guide*.
Highest SAR value:
Model At the Ear** On the Body
940SH 0.481 W/kg0.446 W/kg
As SAR is measured utilizing the device's highest
transmitting power the actual SAR of this device
while operating is typically below that indicated
above. This is due to automatic changes to the
power level of the device to ensure it only uses
the minimum level required to reach the Network.
The World Health Organization has stated that
present scientific information does not indicate
the need for any special precautions for the use
of mobile devices. They note that if you want to
reduce your exposure then you can do so by
limiting the length of calls or using a handsfree
device to keep the mobile phone away from the
head and body.
*Please see Electromagnetic Waves on P.xiv
for important notes regarding body-worn
operation.
**Measured in accordance with international
guidelines for testing.
FCC Notice
This device complies with part 15 of the FCC
.
Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
Changes or modifications not expressly
.
approved by the manufacturer responsible for
compliance could void the user's authority to
operate the equipment.
FCC Information to User
■
This equipment has been tested and found to
comply with the limits of a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation; if this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
1.
Reorient/relocate the receiving antenna.
2. Increase the separation between the
equipment and receiver.
3. Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/
TV technician for help.
General Notes
xiv
Electromagnetic Waves
For body-worn operation, this phone has been
tested and meets RF exposure guidelines when
used with accessories containing no metal, that
position handset a minimum of 15 mm from
the body. Use of other accessories may not
ensure compliance with RF exposure guidelines.
CE Declaration of Conformity
In some counties/regions, such as France, there are
restrictions on the use of wireless LAN. If you intend to use
wireless LAN on the handset abroad, check the local laws
and regulations beforehand.
Hereby, Sharp Telecommunications of Europe Ltd, declares
that 940SH is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
A copy of the original declaration of conformity for each
model can be found at the following Internet address:
http://www.sharp.co.jp/k-tai/
Battery - CAUTION
■
Use specified battery or Charger only.
Non-specified equipment use may cause
malfunctions, electric shock or fire due to
battery leakage, overheating or bursting.
Do not dispose of an exhausted battery with
ordinary refuse; always tape over battery
terminals before disposal. Take battery to a
SoftBank Shop, or follow the local disposal
regulations.
Charge battery in ambient temperatures
between 5℃ and 35℃; outside this range,
battery may leak/overheat and performance
may deteriorate.
Mobile Light
■
Do not use Mobile Light near people's
faces.
Eyesight may be temporarily affected leading to
accidents.
CAUTION:
CLASS 1
LED Product
EN60825-1:1994 A1:2002 & A2:2001
Use of controls, adjustments
or performance of procedure
other than those specified
herein may result in hazardous
radiation exposure. As the emission level from
Mobile Light LED used in this product is harmful
to the eyes, do not attempt to disassemble the
cabinet. Servicing is limited to qualified servicing
station only.
Mobile Light
■ Mobile Light LED Properties
a) Emission Duration: Continuous
b) Wavelength
White: 400 - 700 nm
c) Maximum Emission Output
White: 1.4 mW (4.8 mW inside handset)
xv
xvi
FCC RF Exposure Information
■
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed
the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission of the U.S.
Government.
The guidelines are based on standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of
scientific studies. The standards include a
substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless handsets
employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg.
Highest SAR value:
Model FCC ID At the Ear On the Body
940SH APYHRO00108 0.305 W/kg0.382 W/kg
This device was tested for typical body-worn
operations with the back of the handset kept
1.5 cm from the body. To maintain compliance
with FCC RF exposure requirements, use
accessories that maintain a 1.5 cm separation
distance between the user's body and the back
of the handset. The use of beltclips, holsters and
similar accessories should not contain metallic
components in its assembly.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF
exposure requirements, and should be avoided.
The FCC has granted an Equipment
Authorization for this model handset with all
reported SAR levels evaluated as in compliance
with the FCC RF emission guidelines. SAR
information on this model handset is on file
with the FCC and can be found at https://
fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.
cfm under the Display Grant section after searching
on the corresponding FCC ID (see table on the left).
Additional information on Specific Absorption
Rates (SAR) can be found on the Cellular
Telecommunications & Internet Association
(CTIA) Website at http://www.phonefacts.net.
xvii
General Notes
For SoftBank handset or service information, call General Information.
For repairs, call Customer Assistance.
SoftBank Mobile Customer Center
From a SoftBank handset, dial toll free at
157 (General Information) 113 (Customer Assistance)
SoftBank Mobile Global Call Center
From outside Japan, dial
+81-3-5351-3491 (International charges apply)
Call this number immediately if handset/USIM Card is lost or stolen while outside Japan.
Call these numbers toll free from landlines.
■
Subscription Area Service Center Phone Number
Hokkaido, Aomori, Akita, Iwate, Yamagata,
Miyagi, Fukushima, Niigata, Tokyo, Kanagawa,
Chiba, Saitama, Ibaraki, Tochigi, Gunma,
Yamanashi, Nagano, Toyama, Ishikawa, Fukui
General Information m 0088-240-157
Customer
Assistance m 0088-240-113
Aichi, Gifu, Mie, Shizuoka
General Information m 0088-241-157
Customer
Assistance m 0088-241-113
Osaka, Hyogo, Kyoto, Nara, Shiga, Wakayama
General Information m 0088-242-157
Customer
Assistance m 0088-242-113
Hiroshima, Okayama, Yamaguchi, Tottori,
Shimane, Tokushima, Kagawa, Ehime, Kochi,
Fukuoka, Saga, Nagasaki, Oita, Kumamoto,
Miyazaki, Kagoshima, Okinawa
General Information m 0088-250-157
Customer
Assistance m 0088-250-113
Customer Service
