User Manual 2
412
簡
易
英
語
English Simple Manual （簡易英語版）
Turning Power On and Off
●Turning Power On
Hold down F for at least a few seconds.
●Turning Power Off
Hold down F for at least a few seconds.
Switching the Screen to English
From the stand-by screen: Press c. z Press 3. z Press 6.
z Press 2.
Checking Your Own Phone Number and
E-mail Address
From the stand-by screen: Press c. z Press 0.
Making and Answering a Call
●Making a Call
From the stand-by screen: Enter the phone number you want to call.
z Press N.
To end a call: Press F.
SH005
Light sensor
Display
Cursor key
Address book key
Mail/Character key
Talk/Pair key
Number keys
Microphone
Center key
Application key
EZ key
Clear/Memo key
Power/End key
Camera lens
Internal antennas
Earpiece
Quick key Direct/Veil View key
Mobile light/flash
Internal au
IC-Card
Battery pack/cover
microSD memory
card slot
Speaker
Infrared port
Strap eyelet
External connection
jack/cover
Internal antennas
Charging/Incoming
indicator
FeliCa mark
◆
◆Lock slider
j20_c185_7j.fm 412 ページ ２００９年１１月５日 木曜日 午後９時１７分
413
簡
易
英
語
●Answering a Call
When the phone starts ringing, press N.
To adjust the earpiece volume during a call: Use j.
Storing and Recalling Address Book Entries
●Storing an Entry
From the stand-by screen: Hold down & for at least one second.
z Use j to select the item you want to edit. z Press c (Select).
z Enter the data. z Press % (Reg).
●Recalling an Entry
From the stand-by screen: Press & to display the Address Book screen.
z Use s to select the tab for the record you want to recall.
z Use j to select the name of the record.
z Press c (Detail) to view the record in detail.
Using the Camera (Movie and Snapshot)
●Recording a Movie Clip
From the stand-by screen: Press c. z Use a to select “Camera”.
z Press c (Select). z Select “Movie”. z Press c (Select).
z Press c (Record) to start recording.
z Press c (Stop) to stop recording.
z Press c (Save) to store the movie.
Press & ( ) (Pause) during recording to pause recording.
Press & ( ) in the Movie mode to change to the Photo mode.
●Taking a Snapshot
From the stand-by screen: Press c. z Use a to select “Camera”.
z Press c (Select). z Select “Photo”. z Press c (Select).
z Press c (Shoot) to take a snapshot.
z Press c (Save) to store the photo.
Press & ( ) in the Photo mode to change to the Movie mode.
Making an International Call
Ex: To call 212-123-△△△△ in the USA
Other Handy Features
●Setting the Manner Mode
From the stand-by screen: Hold down # for at least one second.
Repeat the above operation to disable the Manner Mode.
●Setting the Answer Memo (Voice Recording)
From the stand-by screen: Hold down C for at least one second.
Repeat the above operation to disable the Answer Memo.
001010 z 1 z 212
Area code
International access code Country code (USA)
z123z
△△△△ zN
Number you want to call
For inquiries, please contact
au Customer Service Center (General Information)
●If you are calling from a landline phone: 0077-7-111 (toll free)
●If you are calling from an au mobile phone: 157 (toll free)
c185_j_torisetsu.book 413 ページ ２００９年１１月５日 木曜日 午後６時２４分
