●Turning Power On
Hold down f for at least two seconds.
●Turning Power Off
Hold down f for at least two seconds.
z Select [Power off]. z Select [OK].
On the desktop*: Select [ ]. z Select [設定]. z Select [言語とキーボード].
z Select [言語（Language）を選択]. z Select [English].
* The desktop represents the stand-by screen.
On the desktop: Select [ ]. z Select [Settings]. z Select [Profile].
English Simple Manual （簡易英語版）
IS05
Earpiece
External
connection
jack
HDMI jack
External
connection
jack cover
Charging/Incoming
indicator Internal antennas
Proximity
sensor/
Light sensor Power
key
Volume up/
down key
Back key
/GPW key 5GCTEJ key
*QOG key
Display
Shutter key
Internal
antennas
Microphone
Strap
eyelet
Earphone jack cover Earphone jackTelevision antenna
Out camera lens
In camera
lens
Infrared port
Mobile light
FeliCa mark
Speaker
Battery
pack
microSD
memory
card slot
au IC-
Card
Reset
button
Battery pack cover
Turning Power On and Off Switching the Screen to English
Checking Your Own Phone Number and
Mail Address
as32_j.book 312 ページ ２０１０年１２月２２日　水曜日　午後８時３０分
313
簡
易
英
語
j22_as32_9j.fm
[313/313]
●Making a Call
On the desktop: Select [ ]. z Enter the phone number you want to call.
z Select [Call].
To end a talk: Select [Disconnect].
To end a call: Select [Quit].
●Answering a Call
When the phone starts ringing, slide [ ] in the right direction.
To adjust the earpiece volume during a call: Press u/d.
●Storing an Entry
On the desktop: Select [ ]. z Select [Address Book].
z Select [e]. z Select [Add New Item]. z Select the item you want to
edit. z Select [Save]. z Select [Yes].
●Recalling an Entry
On the desktop: Select [ ]. z Select [Address Book].
z Select the record you want to recall.
●Recording a Movie Clip
On the desktop: Select [ ]. z Select [Video Camera]. z Select [ ].
z Select [ ] to stop recording. z Select [Save] to store the movie.
To zoom in or out: Slide the touch screen left or right.
●Taking a Snapshot
On the desktop: Select [ ]. z Select [Camera].
z Select [ ] to take a snapshot.
To zoom in or out: Slide the touch screen left or right.
Ex: To call 212-123-△△△△ in the USA
On the desktop: Select [ ].
●Setting the Manner Mode
Hold down f for at least a few seconds.
z Select [Manner mode].
Repeat the above operation to disable the Manner Mode.
●Setting the Answer Memo (Voice Recording)
On the desktop: Select [ ]. z Select [Settings].
z Select [Call Settings]. z Select [Call/Message].
z Select [Answering memo setting].
Repeat the above operation to disable the Answer Memo.
Making and Answering a Call
Storing and Recalling Address Book Entries
Using the Camera (Movie and Snapshot)
Making an International Call
［0］［0］［1］［0］［1］［0］z［1］z
［2］［1］［2］
International
access code
Area code
Country code (USA)
z
［1］［2］［3］
z△△△△ zSelect [Call].
Number you want to call
Other Handy Features
For inquiries, please contact
au Customer Service Center (General Information)
●If you are calling from a landline phone: 0077-7-111 (toll free)
●If you are calling from an au mobile phone: 157 (toll free)
as32_j.book 313 ページ ２０１０年１２月２２日　水曜日　午後８時３０分
-This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
-Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation; if this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of the U.S.
Government.
The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age and health.
The exposure standard for wireless handsets employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is
1.6W/kg.
Highest SAR value(W/Kg):
Model FCC ID At the Ear On the Body
CDMA SHI05 APYHRO00140 1.03 0.976
This device was tested for typical body-worn operations with the back of the
handset kept 1.5 cm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain a 1.5 cm separation
distance between the user's body and the back of the handset. The use of
beltclips, holsters and similar accessories should not contain metallic
components in its assembly.
The use of accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements, and should be avoided. The FCC
has granted an Equipment Authorization for this model handset with all reported
SAR levels evaluated as in compliance with the FCC RF emission guidelines.
SAR information on this model handset is on file with the FCC and can be found
at http://www.fcc.gov/oet/fccid under the Display Grant section after searching
on the corresponding FCC ID (see table above).
Additional information on Specific Absorption Rates (SAR) can be found on the
Cellular Telecommunications & Internet Association (CTIA) Website at
http://www.phonefacts.net.
