■When Asking for Repair
For repair, contact Keitai Guarantee Service Center.
■Performance Parts for Repair
The Company retains performance parts for repair of the SHL24 main unit and
its peripheral devices for 4 years after discontinuation of production.
“Performance parts for repair” refers to parts required for maintaining the
functions of the product.
■Warranty Card
At the store of purchase, thoroughly check and read the name of the retailer,
date of purchase and other necessary details filled in on the warranty card,
and be sure to keep it in a safe place.
■Keitai Guarantee Service Plus LTE
An after-sales service membership program on a monthly basis called “Keitai
Guarantee Service Plus LTE” (monthly fee: 380 yen, tax excluded) is available
for using your au cell phone for a long time without worries.
This service expands coverage for many troubles including malfunction, theft
and loss. For details of this service, check on the au homepage or contact
Keitai Guarantee Service Center.
■au Nano IC Card (LTE)
The au Nano IC Card (LTE) is lent to you by au. In case of loss or damage, the
card will be replaced at your expense. When malfunction is suspected, or in
case of theft or loss, contact an au shop or PiPit.
After-Sales Service
During the
warranty period
Repairs will be done based on the <<terms of services
of the free-of-charge repair warranty>> described on the
warranty card.
Outside the
warranty period
We shall repair the product for a charge as requested by
the customer if repair renders it usable.
◎Before handing in the product for repair, make a backup of the contents
of memory since they may disappear during repair. Note that the
Company shall not be liable for any damages and loss of income should
the contents of memory be altered or lost.
◎Recycled parts that meet the Company’s quality standards are
sometimes used for repair.
◎au cell phones collected by Replacement cell phone delivery service
which you used before are recycled to cell phones for replacement after
repairs. Also parts replaced by au after-sales service are collected and
recycled by the Company. They are not returned to customers.
◎You can apply for membership only at the time of purchasing your au cell
phone.
◎Once you cancel the membership, you cannot reapply for it until you
purchase an au cell phone next time.
◎Note that when changing the model or purchasing an extra cell phone,
this service only covers the most recently purchased au cell phone.
◎When an au cell phone is handed over to you or someone else, the “Keitai
Guarantee Service Plus LTE” membership is also handed over to the
successor of the cell phone.
◎When you get a new au cell phone by changing the model, purchasing
an extra cell phone, etc., the “Keitai Guarantee Service Plus” or “Keitai
Guarantee Service Plus LTE” membership for the old au cell phone is
automatically canceled.
◎Service contents are subject to change without notice.
23
■After-Sales Service
If you are unsure about anything regarding after-sales service, contact the
following service counter.
Customer Service Center (for service canceling procedure or operation in
case of loss or theft)
From a fixed-line phone, 0077-7-113 (toll free)
From an au cell phone, 113 without area code (toll free)
Keitai Guarantee Service Center (for loss, theft or damage)
From a fixed-line phone/an au cell phone,
0120-925-919 (toll free)
Business hours 9:00 to 21:00 (7 days a week)
■au After-Sales Service Information
* Charge amounts are all tax excluded.
Service contents
Keitai Guarantee
Service Plus LTE
member
Non-Keitai
Guarantee Service
Plus LTE member
Replacement cell phone
delivery service
(spontaneous failure: 1st year)
Free N/A
Replacement cell phone
delivery service
(spontaneous failure: 2nd year
and later)
Customer charge
1st: 5,000 yen
2nd: 8,000 yen
N/A
Replacement cell phone
delivery service
(partial damage, water soak,
irreparable damage, theft and
loss)
Customer charge
1st: 5,000 yen
2nd: 8,000 yen
N/A
Holding over and repair
(spontaneous failure: 1st year) Free Free
Holding over and repair
(spontaneous failure: 2nd year
and later)
Free (three-year
warranty) Actual cost
Holding over and repair
(partial damage)
Customer charge
Upper limit: 5,000
yen
Actual cost
Holding over and repair
(water soak and irreparable
damage)
Customer charge
10,000 yen Actual cost
Holding over and repair
(theft and loss) N/A
N/A
(By model
replacement)
Replacement cell phone delivery service
◎When you have trouble with your au cell phone, you can have a cell
phone for replacement (same model and color as your old one) delivered
to any destination that you specify by calling us. Please return your old
faulty au cell phone within 14 days after the cell phone for replacement is
delivered to you.
◎You can use this service up to twice within one year starting from the day
when you first use this service. If you have not used this service over the
past one year at the time of your application for this service, the
application will be regarded as your first time. If you have, the application
will be regarded as your second time.
* For details, check on the au homepage.
Holding over and repair
◎Damages and malfunctions intentionally caused by the customer as well
as those due to modification (e.g. disassembly, change of parts, painting,
etc.) by the customer are not covered by this service.
◎You cannot receive a refund for replacement of the outer casing due to
stains, scratches, paint removal, etc. on the outer casing.
24
*1 The 1Seg continuous watching time varies depending on the usage.
*2 It changes according to objects obstructing devices and signal reception.
*3 This is the specification provided in Bluetooth® standards for making
communication between Bluetooth®-compatible devices in accordance with their
intended use.
*4 Some contents of address books data may not be properly displayed on the
device of the other party.
*5 This profile supports Bluetooth® Standard Ver.4.0.
*6 Supported for some car navigation systems only. See the au homepage for usage.
*7 Supported for Wi-Fi CERTIFIED™ ac. Refer to the respective companies’ websites
for information on supported products.
Main Specifications
Display Approx. 4.5 inches, approx. 16.77 million colors, IGZO,
1,080×1,920 (FHD)
Weight Approx. 115 g (including the internal battery)
Size (W×H×D) Approx. 63 mm×124 mm×9.9 mm (thickest part approx.
10.3 mm)
Memory (built-in) ROM: Approx. 16 GB
RAM: Approx. 2 GB
Continuous talk
time (in Japan)
Approx. 980 min.
Continuous talk
time (overseas
(GSM))
Approx. 620 min.
Continuous
standby time (in
Japan)
Approx. 510 hours (while LTE is used)
Approx. 610 hours (while 3G is used)
Continuous
tethering time
Approx. 420 min. (LTE on WAN)
Approx. 600 min. (3G on WAN)
Maximum Wi-Fi®
tethered
connections
10 devices
Continuous
standby time
(overseas (GSM))
Approx. 600 hours
Charging time Common AC adapter 04 (sold separately): Approx. 120
min.
Common DC adapter 03 (sold separately): Approx. 260
min.
1Seg continuous
watching time*1
Approx. 8 hours and 00 min. (earphone)
Approx. 7 hours and 30 min. (speaker)
Camera device Out camera
CMOS image sensor
In camera
CMOS image sensor
Effective pixels Out camera
Approx. 13.10 million pixels
In camera
Approx. 1.20 million pixels
Bluetooth®
function
Communication method: Bluetooth® Standard Ver.4.0
Output: Bluetooth® Standard Power Class 2
Communication distance*2: Within 10 m with no
obstacles in the range
Compatible Bluetooth® profiles*3: HSP (Headset Profile),
HFP (Hands-Free Profile), A2DP (Advanced Audio
Distribution Profile), AVRCP (Audio/Video Remote
Control Profile) Ver.1.3, OPP (Object Push Profile), SPP
(Serial Port Profile), PBAP (Phone Book Access
Profile)*4, HID (Human Interface Device Profile), HDP
(Health Device Profile), PAN (Personal Area Networking
Profile), PXP (Proximity Profile)*5, FMP (Find Me
Profile)*5, ANP (Alert Notification Profile)*5, PASP (Phone
Alert Status Profile)*5, TIP (Time Profile)*5, DUN (Dial-up
Networking Profile)*6
Frequency bands: 2.4 GHz band
Network
environment
Wireless LAN (Wi-Fi®) function: IEEE 802.11a/b/g/n (2.4
GHz/5 GHz)/ac*7 conformant
Interface microUSB jack, 3.5φ (quadrupoles) earphone/
microphone jack (supported earphones: tripolar
headphone (Lch/Rch/GND) and quadrupolar earphone
with microphone (Lch/Rch/GND/MIC))
◎The continuous talk time and continuous standby time may drop to less
than half depending on the battery charging status, usage environment
such as temperature, reception condition at the location where the
product is used, and the function settings.
25
This model 【SHL24】 mobile phone complies with Japanese technical
regulations and international guidelines regarding exposure to radio waves.
This mobile phone has been designed in observance of the Japanese
technical regulations regarding exposure to radio waves (*1) and limits to
exposure to radio waves recommended by equivalent international guidelines.
These international guidelines were set out by the International Commission on
Non-Ionizing Radiation Protection (ICNIRP), which is in collaboration with the
World Health Organization (WHO), and the permissible limits include a
substantial safety margin designed to assure the safety of all persons,
regardless of age and health condition. The Japanese technical regulations
and international guidelines define the limits using a unit of measurement
known as the Specific Absorption Rate (SAR), which represents the average
amount of radio frequency energy absorbed by the human head. The SAR limit
for mobile phones is 2.0 W/kg. The highest SAR value for this mobile phone
when tested for use at the ear is 0.473 W/kg. There may be slight differences in
SAR levels among individual products, but they all satisfy the limit. The actual
SAR of this mobile phone while talking on the phone can be well below that
indicated above. This is due to automatic changes in the power level of the
mobile phone to ensure it only outputs the minimum power required to
communicate with a base station. Therefore in general, the closer you are to a
base station, the lower the power output of the mobile phone.
This mobile phone can be used in positions other than against your ear. This
mobile phone satisfies the international guidelines when used with au Carrying
Case F Black (0105FCA) (sold separately)/au Carrying Case G Black
(0106FCA) (sold separately) recommended by KDDI (*2).
In case you are not using the au Carrying Case F Black (0105FCA) (sold
separately)/au Carrying Case G Black (0106FCA) (sold separately), use a
product that contains no metal parts, and one that can hold the mobile phone
at least 1.5 cm away from your body.
The World Health Organization has stated that “a large number of studies have
been performed over the last two decades to assess whether mobile phones
pose a potential health risk. To date, no adverse health effects have been
established as being caused by mobile phone use”. If you would like to know
more detailed information, please refer to the WHO website.
(http://www.who.int/docstore/peh-emf/publications/facts_press/
fact_english.htm)
Please refer to the websites listed below if you would like to know more
detailed information regarding SAR.
*1 Technical regulations are defined by the Ministerial Ordinance Related to the Radio
Law (Article 14-2 of Radio Equipment Regulations).
*2 Regarding the method of measuring SAR when using mobile phones in positions
other than against the ear, international standards (IEC62209-2) were set in March
of 2010.
On the other hand, regarding the technical standards of Japan, ministerial
ordinance to revise part of the Ministerial Ordinance related to Radio Law (Article
14-2 of Radio Equipment Regulations) has been issued in August 2013, and will be
enforced on April 1, 2014.
Specific Absorption Rate (SAR) of Cell
Phones
○Ministry of Internal Affairs and Communications website:
(http://www.tele.soumu.go.jp/e/sys/ele/index.htm)
○Association of Radio Industries and Businesses website:
(http://www.arib-emf.org/index02.html)
○au homepage:
(http://www.au.kddi.com/english/)
○SHARP homepage:
(http://www.sharp.co.jp/products/menu/phone/cellular/sar/index.html)
5.2
142
71 134 10
2.0
1
SHL25
26
In some countries/regions including Europe, there are restrictions on the
use of 5GHz WLAN that may limit the use to indoors only.
If you intend to use 5GHz WLAN on the device, check the local laws and
regulations beforehand.
■Mobile Light
Do not point the illuminated light directly at someone’s eyes.
Be especially careful not to shoot small children from a very close distance.
Do not use Mobile light near people’s faces. Eyesight may be temporarily
affected leading to accidents.
■AC Adapter
Any AC adapter used with this handset must be suitably approved with a 5Vdc
SELV output which meets limited power source requirements as specified in
EN/IEC 60950-1 clause 2.5.
■Battery - CAUTION
■Volume Level Caution
■Headphone Signal Level
The maximum output voltage for the music player function, measured in
accordance with EN 50332-2, is 120 mV.
■European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed not to
exceed the limits for exposure to radio waves recommended by international
guidelines. These guidelines were developed by the independent scientific
organization ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR
value for this device when tested at the ear is 0.287 W/kg* and when worn on
the body is 0.274 W/kg*.
For body-worn operation, this mobile device has been tested and meets the RF
exposure guidelines when used with an accessory containing no metal and
positioning the handset a minimum of 1.5 cm from the body. Use of other
accessories may not ensure compliance with RF exposure guidelines.
As SAR is measured utilizing the devices highest transmitting power the actual
SAR of this device while operating is typically below that indicated above. This
is due to automatic changes to the power level of the device to ensure it only
uses the minimum level required to reach the network.
The World Health Organization has stated that present scientific information
does not indicate the need for any special precautions for the use of mobile
devices. They note that if you want to reduce your exposure then you can do
so by limiting the length of calls or using a hands-free device to keep the
mobile phone away from the head.
CE Declaration of Conformity
Hereby, Sharp Telecommunications of Europe Ltd, declares that this
SHL24 is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
A copy of the original declaration of conformity can be found at the
following Internet address:
(http://www.sharp.co.jp/k-tai/)
Use specified Charger only.
Non-specified equipment use may cause malfunctions, electric shock or fire
due to battery leakage, overheating or bursting.
The battery is embedded inside the product. Avoid removing the embedded
battery since this may cause overheating or bursting.
Do not dispose of the product with ordinary refuse. Take the product to an au
Shop, or follow the local disposal regulations.
Charge battery in ambient temperatures between 5°C and 35°C; outside this
range, battery may leak/overheat and performance may deteriorate.
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
* The tests are carried out in accordance with international guidelines for testing.
27
- This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
- Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the
equipment.
■Information to User
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation; if this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
■5 GHz WLAN Operation in USA
Within the 5.15-5.25 GHz band, UNII devices are restricted to indoor
operations to reduce any potential for harmful interference to co-channel
Mobile Satellite Services (MSS) operations.
■FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the
U.S. Government.
The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age and health.
The exposure standard for wireless handsets employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is
1.6 W/kg.
Highest SAR value:
This device was tested for typical body-worn operations with the back of the
handset kept 1.0 cm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain a 1.0 cm separation
distance between the user’s body and the back of the handset. The use of belt
clips, holsters and similar accessories should not contain metallic components
in its assembly.
The use of accessories that do not satisfy these requirements may not comply
with FCC RF exposure requirements, and should be avoided.
The FCC has granted an Equipment Authorization for this model handset with
all reported SAR levels evaluated as in compliance with the FCC RF emission
guidelines. SAR information on this model handset is on file with the FCC and
can be found at (http://transition.fcc.gov/oet/ea/fccid/) under the Display Grant
section after searching on the corresponding FCC ID (see table above).
Additional information on Specific Absorption Rates (SAR) can be found on the
FCC website at (http://www.fcc.gov/encyclopedia/radio-frequency-safety).
FCC Notice
Model SHL24
FCC ID APYHRO00201
At the Ear 1.01 W/kg
On the Body 0.91 W/kg
131
0.50
0.37
25
00206
0.64
0.59
6+/

Navigation menu
