Operating manual
Contents
Safety Precautions
Basic Operations
Character Input
Phone
Address Book
Mail
LINE
Internet
Camera
1Seg
Settings
Appendix
Basic Manual
SHF31
Preface
Thank you for buying the “AQUOS SHL31” (simply called the “SHL31”
or the “product” from here on).
Before using the product, be sure to read the “Basic Manual” (this
manual) and “Setting Guide” available on the au homepage to ensure
correct use. After you have finished reading the manuals, be sure to
keep them accessible and store the printed manuals (“取扱説明書”
(Basic Manual) and “設定ガイド” (Setting Guide)) (Accessories) in
safe places so that you can refer to them whenever you need them. If
you lose the printed manuals (Accessories), contact an au shop or
Customer Service Center.
Operating Instructions
“” (Basic Manual) and “”
(Setting Guide)
The “Basic Manual” (this manual) and “Setting Guide” available on the
au homepage describe basic operations of major functions. Initial
settings, charging, and other preparations before using the product
for the first time are explained in the “Setting Guide”.
For detailed descriptions of various functions, refer to the “Full
Instruction Manual” (Japanese) available on the au homepage:
（http://www.au.kddi.com/english/support/manual/）
Safety Precautions
Before you start using the product, be sure to read the “Safety
Precautions” to ensure correct use.
Before you assume that the product is malfunctioning, check for
possible remedies in the following au Customer Support site of au
homepage:
（http://www.au.kddi.com/english/support/）
When Using the Product
•Communication is not possible even inside the service area in
places where the signal does not reach (e.g. tunnels and
basements). Also, communication may not be possible in poor
reception areas. Communication may be interrupted if you move into
a poor reception areas during communications.
•Since this product uses radio waves, the possibility of
communication intercepts by third parties cannot be eliminated.
(Though the LTE/CDMA/GSM/UMTS system has highly secure
confidential communication features.)
•The product is compatible with the international roaming service.
Each network service varies depending on the area and service
content.
For details, refer to “auのネットワークサービス・海外利用” (au
Network Services/International Roaming) described in “Full
Instruction Manual” (Japanese) available on the au homepage.
•Since the product is a radio station under the Radio Law, you may
be asked to temporarily submit the product for inspection in
accordance with the Radio Law.
•The IMEI information of your cell phone is automatically sent to KDDI
CORPORATION for maintenance and monitoring operational status
of your cell phone.
•The product initiates data transmission regularly to obtain information
required for the product to operate including the time.
Communication charges are incurred separately.
•Take care not to inconvenience people around you when you use the
product in a public place.
•If you are using the product overseas, check the relevant laws and
regulations of the country/region you visit.
•When the product is used by a child, parents or guardians should
thoroughly read the “Basic Manual” (this manual) or “Setting Guide”/
“Full Instruction Manual” (Japanese) available on the au homepage
and teach the child how to use it.
ii
Cell Phone Etiquette
Use of cell phones is not allowed in the following
places!
•Do not use a cell phone while driving a car or riding a motorbike or
bicycle. It may cause a traffic accident. Use of a cell phone while
driving a car or motorbike is prohibited by law. Use of a cell phone
while riding a bicycle may be punishable by some regulations.
•Since using the product on airplanes is restricted, follow the
instructions given by the respective airlines.
Be considerate of where you use the cell phone
and how loudly you talk!
•Do not make calls in theaters, museums, libraries, and other similar
places. Turn power off or turn on manner mode so as not to disturb
others around you with your ringtones.
•Do not use the cell phone outside in town where you might hinder
other pedestrians.
•Viewing a cell phone screen while walking is a serious hazard. Do
not suddenly stop to talk on/operate the cell phone or do so while
walking.
•Move to areas where you will not inconvenience others on bullet
trains, in hotel lobbies, etc.
•Refrain from talking in a loud voice.
•Obtain the permission of other people before you take their photos
with the cell phone’s camera.
Be considerate of people around you!
•Some people close to you in crowded places such as packed trains
may be using a cardiac pacemaker. Turn on “Airplane mode” or turn
the cell phone off in such places.
•Abide by the rules of hospitals and other medical institutions where
it is forbidden to use or carry cell phones.
List of Packaged Items
Before you start using the product, make sure that you have all the
following packaged items with the product.
Warranty (Japanese)
SHF31
Battery Pack
(SHF31UAA)
•取扱説明書 (Basic Manual) (Japanese) (This manual)
•設定ガイド (Setting Guide) (Japanese)
The following items are not included in the package.
•Desktop holder
•microSD memory card
•AC adapter
•Earphone
•microUSB 3.5mm conversion cable
•microUSB cable
•Purchase a specified charger (sold separately).
•Illustrations of cell phones in this manual are only for reference. They
may look different from the actual product.
1
Illustrations and Descriptions in This
Manual
Note on Key Illustrations
In this manual, the key illustrations are simplified as shown below.
uo
jl
m,.
123
456
789
-0^
b n
z
q
v
k
Pressing e or c ................w
Pressing s or f ................x
Pressing e, c, s, or f ...d
Description of Operations for Selecting Item/Icon/
Key etc.
In this manual, descriptions enclosed in [ ] abbreviate the steps for
selecting an item/icon/onscreen button/etc. in the w or d menu and
then pressing k (OK/Check/Set/Commit/Done).
Example: Editing address book contacts
1 When the standby screen is displayed, press u
Select contact to edit u (Submenu) [Edit].
Indicates to select “Edit” with w and commit with k.
◎For details on key operation, refer to “Learn Basic Key
Operations” (▶P. 44).
2
Notes on Screenshots
The screenshots in this manual are simplified and may look different
from the actual screens. Also, part of the screen may be omitted.
Actual screen In this manual
In this manual, part of the screen
such as icons are omitted.
◎In this manual, keys, screenshots, and icons are described
based on default settings of the product with the body color
“red”. However, actual keys, screenshots, and icons may differ or
be partially omitted.
◎Content at the bottom of the screen that can be operated by
pressing k, u, o, j, or l are indicated in parentheses, such
as u (Submenu).
* However, k (OK), k (Check), k (Set), k (Commit), and k (Done)
are abbreviated as k only.
◎Menu items, layers and icons described in this manual may be
different according to functions being used and conditions.
◎In this manual, “microSD™ memory card (commercially
available)” and “microSDHC™ memory card (commercially
available)” are abbreviated as “microSD memory card” or
“microSD”.
◎All of the indicated amounts exclude tax unless otherwise
specified.
3
Using au Disaster Countermeasure
Application
au Disaster Countermeasure is an application in which you can use
Disaster Message Board, Emergency Rapid Mail (Earthquake Early
Warning, Disaster and Evacuation Information, and Tsunami Warning),
Disaster Voice Messaging Service and Disaster Information.
1
When the standby screen is displayed, press k
[Service] [au] (au Disaster Countermeasure).
The au Disaster Countermeasure menu is displayed.
If terms of use or an initial settings screen is displayed, check the
contents and follow the on-screen instructions.
Using Disaster Message Board
Disaster Message Board is a service to enable customers in disaster
areas to register their safety information via LTE NET when large-scale
disasters, such as an earthquake whose Japan seismic scale is
approximately 6-lower or more, occur. The registered safety
information can be checked by customers using au phones, and also
from other carriers’ cell phones, PCs, etc.
For details, refer to “Disaster Message Board Service” on the au
homepage.
1 From the au Disaster Countermeasure menu, [
] (Disaster Message Board).
Follow the on-screen instructions for registration/confirmation.
◎To register the safety information, an e-mail address (～ezweb.
ne.jp) is required. Set the e-mail address in advance.
◎Deletion of the safety information and configurations for Safety
Notification Mail are not available during wireless LAN (Wi-Fi®)
connection.
◎The Company does not guarantee the quality of this service. The
Company, regardless of the cause, shall not be liable for any
problems related to registration of safety information due to the
concentration of access to this service or equipment errors, any
loss due to the damage, ruination, etc. of safety information or
any loss arising from registered safety information.
Using Emergency Rapid Mail
Emergency Rapid Mail is a service to collectively deliver Earthquake
Early Warning and Tsunami Warning provided by the Japan
Meteorological Agency, and Disaster and Evacuation Information
provided by the national government or the local governments to au
phones in the specified areas.
•At the time of purchase, receiving setting of Emergency Rapid Mail
(Earthquake Early Warning, and Disaster and Evacuation
Information) is set to “受信する” (Receive). You can receive Tsunami
Warning by setting 災害・避難情報 (Disaster and Evacuation
Information).
When receiving Earthquake Early Warning, secure your safety and
act composedly according to the surrounding situations.
When receiving Tsunami Warning, leave sea coasts immediately and
evacuate to safe places such as hills and strongly-built tall buildings.
1 From the au Disaster Countermeasure menu, [
] (Emergency Rapid Mail).
The inbox is displayed.
Select a mail to check to display the details of the mail.
削除
(Delete)
Delete received mails.
4
設定
(Settings)
(Earthquake Early Warning)
•受信設定 (Receive settings)
Set whether to receive Earthquake Early
Warning.
･[受信する] (Receive)/[受信しない] (Not
receive).
•音量 (Volume)
Set the volume of the receiving sound.
•マナー時の鳴動 (Linkage to the manner mode)
Set whether to make the product ring at the
time of reception while the manner mode is
applied.
•バイブ (Vibrator)
Set whether to activate the vibrator at the time
of reception.
(Disaster and Evacuation
Information)
•受信設定 (Receive settings)
Set whether to receive Disaster and Evacuation
Information, and Tsunami Warning.
･[受信する] (Receive)/[受信しない] (Not
receive).
•音量 (Volume)
Set the volume of the receiving sound.
•マナー時の鳴動 (Linkage to the manner mode)
Set whether to make the product ring at the
time of reception while the manner mode is
applied.
•バイブ (Vibrator)
Set whether to activate the vibrator at the time
of reception.
◎This service is available only in Japan (Not available overseas).
◎Emergency Rapid Mail is free of both information charges and
communication charges.
◎Emergency Rapid Mail cannot be received while the power is
turned off or during a call.
◎Emergency Rapid Mail may not be received during
communication such as while sending and receiving e-mails/
SMSs and while using the browser or when you are in a place
where the signal cannot be received (e.g. tunnels and
basements) or the signal is weak, even within the service area.
◎Emergency Rapid Mail which failed to be received will not be
able to be received again.
◎When you receive Emergency Rapid Mail, you will be notified by
the dedicated alarm tone and the vibrator. The alarm tone cannot
be changed.
* When you receive Earthquake Early Warning, you will be notified by
the alarm tone, voice (“地震です” (Jishin-desu)) meaning that an
earthquake has occurred and the vibrator.
◎Information intended for the areas of other than your present
location may be received.
◎As for this service, the Company shall not be liable for any
damage incurred on the users resulted from failure or delay of
information delivery due to communication disturbance or system
failure, contents of the information or other problems that are not
supposed to be blamed on the Company.
◎For details on Earthquake Early Warning and Tsunami Warning
provided by the Japan Meteorological Agency, refer to the
agency’s homepage.
（）
Earthquake Early Warning
◎Earthquake Early Warning notifies areas where a strong shaking
(Japan seismic scale 4 or more) is expected when an earthquake
whose maximum Japan seismic scale is predicted of 5-lower or
more has been detected.
5
◎This service detects an earthquake (P-wave, preliminary tremors)
near the seismic center immediately after the earthquake occurs
and automatically calculates its location, scale and predicted
strength of the shaking. After that, you will be notified of the
earthquake as soon as possible within a few seconds to dozens
of seconds before a strong shaking from the earthquake (S-wave,
principal shock) occurs.
◎In the vicinity of the seismic center, a strong shaking may reach
you before Earthquake Early Warning.
◎The Earthquake Early Warning distribution system provided by
this service is different from that provided by TV, radio and other
communication media and thus the arriving time of Earthquake
Early Warning may be different among those media.
Tsunami Warning
◎Tsunami Warning notifies areas including target sea coasts of
Major Tsunami Warning and Tsunami Warning provided by the
Japan Meteorological Agency.
Disaster and Evacuation Information
◎Disaster and Evacuation Information notifies information related
to the safety of citizens, such as evacuation advisories,
evacuation orders or various alarms delivered by the national
government or the local governments.
Using Disaster Voice Messaging Service
Disaster Voice Messaging Service is a service to record voices with a
cell phone and deliver them as a voice message to people to whom
you want to deliver the information that you are safe when large-scale
disasters occur.
1 From the au Disaster Countermeasure menu, [
] (Disaster Voice Messaging
Service).
Follow the on-screen instructions.
Sending voices (Send)
Tap “声をお届け” (Send voices) and then “あて先入力”* (Enter
recipient) → “声を録音” (Record voices to send).
* You can also select to whom to send your voices from the address book.
Receiving voices (Receive)
You will be notified via a pop-up screen or an SMS that a voice
message has been received. You can listen to the message by
receiving (downloading) and playing the voice message.
•If the recipient’s cell phone does not have an au災害対策 (au
Disaster Countermeasure) application activated that supports 災害
用音声お届けサービス (Disaster Voice Messaging Service), SMS is
sent instead.
•If the receivers are notified via an SMS, the information will not be
saved in the au Disaster Countermeasure application.
◎
To use this service via Wi-Fi®, making initial settings via 4G (LTE)/3G
networks is required.
◎Voice messages can be recorded for up to 30 seconds.
◎Voice messages can be exchanged among au phones as well as
other carriers’ cell phones and PHS devices.
◎Voices may not be heard when the media sound volume is set to
low.
◎When no free space is left on the internal memory, voice
messages may not be saved or played.
◎Some cell phones cannot receive voice messages. For details,
refer to the au homepage.
Using Disaster Information
You can check the histories of Disaster and Evacuation Information
delivered by the local governments, Disaster Information portal, etc.
1 From the au Disaster Countermeasure menu, [
] (Disaster Information).
Select an item to check.
6
Contents
Preface ........................................................................................ ii
Operating Instructions .............................................................. ii
Safety Precautions .................................................................... ii
When Using the Product ........................................................... ii
Cell Phone Etiquette .................................................................. 1
List of Packaged Items .............................................................. 1
Illustrations and Descriptions in This Manual......................... 2
Using au Disaster Countermeasure Application .................... 4
Contents ..................................................................................... 7
Safety Precautions ..................................................... 9
Exemptions ......................................................................................9
Safety Precautions (Observe Strictly) ...........................................9
Handling Precautions ...................................................................20
Available Security Codes .............................................................25
Security Codes ...............................................................................25
PIN ..................................................................................................25
Notes on Waterproof Property .....................................................26
Notes on Using Bluetooth®/Wireless LAN (Wi-Fi®) Functions ..30
Frequency Band .............................................................................30
Precautions about Bluetooth® ........................................................30
Precautions about Wireless LAN (Wi-Fi®) .......................................31
Notes on Packet Communication Charge ...................................32
Notes on Applications ..................................................................32
Basic Operations ..................................................... 33
Names and Functions of Parts ....................................................33
Using Touch Cruiser EX ...............................................................35
Contents Operation with Touch Cruiser EX ....................................................36
Switching the Display Language to English ...............................37
Using the Standby Screen ...........................................................37
Using shortcuts in the Standby Screen ..........................................38
Using the Status Bar .....................................................................38
Icons ...............................................................................................38
Using the Notification/Status Panel.................................................39
Using the Sub display ..................................................................40
Using the Main Menu ....................................................................41
About Applications .........................................................................44
Learn Common Operations ..........................................................44
Learn Basic Key Operations ...........................................................44
Using Checkboxes .........................................................................45
Character Input ........................................................ 46
Learn How to Enter Characters ....................................................46
Phone ........................................................................ 49
Making Calls ..................................................................................49
Entering a Phone Number and Making a Call ................................49
Using Call Histories and Making a Call ..........................................50
Using Speed Dial and Making a Call ..............................................52
Using Kantan Hasshin and Making a Call ......................................52
Calling Overseas from au Phones (au International Call Service) ..52
Receiving Calls .............................................................................53
Answering an Incoming Call ...........................................................53
Putting a Call on Hold .....................................................................53
Rejecting an Incoming Calls ...........................................................54
Sending SMS to an Incoming Call ..................................................54
Checking Your Phone Number .....................................................54
Checking Your Profile......................................................................54
Editing Your Profile ..........................................................................54
7
Contents
Address Book ........................................................... 55
Registering to the Address Book .................................................55
Using the Contacts List ................................................................55
Displaying the Contacts List ...........................................................55
Using Information Registered for Contacts ................................56
Mail ............................................................................ 57
Sending E-mail ..............................................................................57
Sending an E-mail...........................................................................57
Receiving E-mail ...........................................................................58
Receiving an E-mail ........................................................................58
Inquiring for and Receiving New Mail .........................................58
Sending SMS .................................................................................59
Receiving SMS ..............................................................................60
Checking SMS ................................................................................60
Checking the Inbox/Outbox .........................................................60
Operations in the Mail Menu ...........................................................63
LINE ........................................................................... 64
Using LINE .....................................................................................64
Internet ...................................................................... 65
Accessing the Internet..................................................................65
Using Packet Communication .....................................................65
Using the Browser ........................................................................66
Using the Browser Menu ................................................................66
Operating the Browser with Touch Cruiser EX ................................66
Camera ...................................................................... 67
Before Using the Camera .............................................................67
Capturing Still Pictures/Video ......................................................68
1Seg .......................................................................... 70
1Seg ...............................................................................................70
Making Initial TV Settings .............................................................71
Viewing TV Programs ....................................................................71
Viewing a TV Program ....................................................................71
Settings ..................................................................... 73
Displaying the Settings Menu ......................................................73
Appendix ...................................................................74
Introduction of Peripheral Devices ..............................................74
Using an Earphone Microphone with Switch/Earphone
Microphone/Earphone ..................................................................75
Troubleshooting ............................................................................76
Updating Software ........................................................................77
After-Sales Service .......................................................................79
Main Specifications ......................................................................81
Specific Absorption Rate (SAR) of Cell Phones .........................82
CE Declaration of Conformity ......................................................83
FCC Notice.....................................................................................85
Export Administration Regulations .............................................86
Intellectual Property Rights .........................................................86
8
Safety Precautions
Exemptions
•The Company is not liable for any damages arising from
earthquakes, lightning, storms, floods or other natural disasters, as
well as fires, actions by third parties, other accidents, intentional or
mistaken operation by the customer, or use under other unusual
conditions outside the responsibility of the Company.
•The Company is not liable for any incidental damages (change/
disappearance of saved content, loss of business income, disruption
of business, etc.) arising from use of or inability to use the product. It
is recommended that you keep a copy of important phone numbers
etc.
•The Company is not liable for any damages arising from failure to
observe the described content of this manual.
•The Company is not liable for any damages arising, for example,
from malfunction caused by combination with connected devices or
software not related to the Company.
•Captured image data or downloaded data may sometimes be
altered or lost due to faults, repair or other handling of the product.
The Company is not liable for any damage or lost income resulting
from recovery of these data.
•It is recommended you keep a copy of important data on your PC's
hard disk, etc. Whatever the cause of the defect or malfunction may
be, the Company assumes no responsibility for alteration or loss of
saved data.
* “The Company” as appears in this manual refers to the following companies:
Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: SHARP CORPORATION
◎Reproduction of the content of this manual in part or in whole is
prohibited.
◎The content of this manual is subject to change without notice.
◎Every effort has been made in the preparation of this manual.
Should you notice any unclear points, omissions, etc., feel free to
contact us.
Safety Precautions (Observe Strictly)
Before using the product, thoroughly read these safety
precautions for proper use. After reading, store the
precautions in a safe place.
These “Safety Precautions” describe instructions that should be
observed to prevent damage to property or injury to the customer or
others using the product.
These instructions are divided into the following categories.
Explanation of Indications Used in This Manual
DANGER
This symbol indicates the potential and
imminent danger of death or serious injury*1
to a person.
WARNING This symbol indicates the possibility of death
or serious injury*1 to a person.
CAUTION
This symbol indicates the possibility of
personal minor injury*2 to a person or
physical damage*3.
*1 Serious injury: This refers to loss of sight, injury, burns (high- and
low-temperature), electric shock, broken bones, injuries with residual
aftereffects from poisoning, etc., and injuries requiring hospital admission
for treatment or long-term hospital attendance as an outpatient.
*2 Minor injury: This refers to injuries, burns (high- and low-temperature),
electric shock, etc. that do not require hospital admission for treatment or
long-term hospital attendance as an outpatient.
*3 Physical damage: This refers to extended damage to buildings, furniture,
livestock or pets.
9
Safety Precautions
Explanation of Graphic Symbols Used in This
Manual
Prohibited
Indicates an action
that is not allowed.
Wetting with
water prohibited
Indicates that use in
a place where the
product is likely to
get wet or allowing
the product to get
wet is not allowed.
Wet hands
prohibited
Indicates that
handling with wet
hands is not allowed.
Instruction
Indicates an action
that must be done.
Disassembly
prohibited
Indicates that
disassembly is not
allowed.
Disconnect plug
from power outlet
Indicates that the
power plug must be
disconnected from
the power outlet.
Precautions Common to the Main Unit, battery
pack, back cover, Charger, au Nano IC Card (LTE),
Peripheral Devices
DANGER Be sure to read the following
hazards before use.
Instruction
Be sure to use only the specified peripheral devices. Use
of other peripheral devices might cause overheating,
ignition, rupture, fault, or leakage of liquid.
Prohibited
Do not use, store or leave the product in hot places (e.g.
by the fire, near a heater, under a kotatsu, in direct
sunlight, in a car in the hot sun). Doing so might cause
ignition, rupture, fault, fire or injury.
Instruction
Before entering an area where flammable gas is generated
such as a gas station, be sure to turn off the product. Do
not charge the battery. Failure to observe these
precautions might cause the gas to catch fire. In addition,
when using Osaifu-Keitai® payment function at a gas
station, be sure to turn off the power in advance. (If
Osaifu-Keitai® has been locked, cancel the lock before
turning off the power.)
Prohibited
Do not put the product in a cooking apparatus such as
microwave oven or a pressure vessel. Doing so might
cause leakage of liquid, ignition, rupture, fault, fire or injury.
Prohibited
Do not throw the product into a fire or heat it. Doing so
might cause ignition, rupture or fire.
10
Safety Precautions
Prohibited
Do not short-circuit the charger terminal and external
connection jack. Do not allow conductive foreign objects
(metal fragments, pencil leads, etc.) to come into contact
with or get inside a jack. Doing so might cause a fire,
burns, a fault due to heat generation.
Prohibited
When using a metal accessory etc., do not allow the metal
part to come in contact with the connection jack or power
outlet. Doing so might cause electric shock, ignition, injury
or a fault.
Prohibited
Do not expose the camera lens to direct sunlight for an
extended period. Doing so might cause ignition, rupture or
fire by the light-collecting mechanism of the lens.
Disassembly
prohibited
The customer is not allowed to disassemble, modify or
repair the product. Doing so might cause a fault, ignition,
electric shock, or injury. The Company is not liable even in
the event of any nonconformities arising on the product or
peripheral devices as a result of modification, etc.
Modification of the product is in violation of the Radio Law.
WARNING Be sure to read the following
warnings before use.
Prohibited
Do not drop or subject to strong impact, such as throwing.
Doing so might cause rupture, overheating, ignition or a
fault.
Prohibited
Do not use outside when you can hear thunder. Doing so
might risk lightning strikes and electric shock.
Prohibited
Do not let your hands, fingers and other parts of the body
touch the charger terminal or external connection jack.
Doing so might cause electric shock, injury or a fault.
Prohibited
If the product is damaged because it is dropped, etc. and
its display is cracked or internal parts are exposed, do not
touch the cracked display or exposed parts. Doing so
might cause electric shock or injury from damaged parts.
Contact an au shop or Keitai Guarantee Service Center.
Prohibited
Never connect the microUSB plug when the product or
specified charger (sold separately) is wet.
While the product is water resistant, any water or foreign
matter on the product or microUSB plug when inserting the
microUSB plug while wet might cause electric shock or
short circuit/corrosion causing abnormal overheating,
burnout, fire, burns, or a fault.
Wetting with
water prohibited
Although the product has waterproof capability, do not use
if liquid such as water gets inside the product from a gap
in the back cover, etc. Continued use of the product in this
state might cause overheating, ignition or a fault.
Prohibited
When removing the back cover, do not apply excessive
force. Doing so might cause the battery pack to fly out,
causing injury or malfunction.
Instruction
If charging is not completed after the specified charging
time, stop charging. Failure to do so might cause leakage
of liquid, overheating, rupture or ignition.
Prohibited
Do not leave in places within the reach of small children.
Small children might swallow part of the equipment by
mistake and choke on them, or might drop them by
mistake and cause accidents or injury.
11
Safety Precautions
CAUTION Be sure to read the following
cautions before use.
Prohibited
Do not store the product in places subject to direct sunlight
(e.g. in automobiles), places that get hot, places that get
extremely cold, and in humid or dusty places. Doing so
might cause overheating, ignition, deformation or a fault.
Prohibited
Do not leave on unstable places such as rocky stands or
tilting surfaces especially while the vibration mode is set.
Dropping the product may cause injury or damage. Also,
pay sufficient attention to impact, etc.
Prohibited
Do not cover or wrap the product with cloth, bedding, etc.
while using or charging the product. Doing so might cause
fire, fault or injury.
Prohibited
Do not touch the product or specified chargers (sold
separately) for a long time while charging. Doing so might
cause low-temperature burns.
Prohibited
Do not use power outlets or wiring apparatus beyond its
rating. Also, exceeding rating, for example, by connecting
multiple devices to a single power strip might cause
overheating and fire.
Prohibited
Do not leave or store the product with its back cover
removed. Doing so might allow dust or other foreign
particles to enter and cause malfunction.
Prohibited
Do not use with the back cover removed.
Prohibited
Do not place near corrosive chemicals or in places where
corrosive gas is generated. Doing so might cause a fault
or loss of internal data.
Instruction
Stop use if there is smoke, abnormal odor or noise,
excessive overheating, or other abnormalities. During
charging, disconnect the specified charger (sold
separately) from the power outlet or the socket, make sure
that the product is not overheating before turning the
power off, remove the battery pack and contact an au
shop or Keitai Guarantee Service Center. Also, if you have
dropped or damaged the product, do not continue to use
it in that state, and contact an au shop or Keitai Guarantee
Service Center.
Instruction
When inserting an earphone, etc. into the product, adjust
the volume to the proper level. Setting too loud a volume or
using the earphone continuously for a long period of time
might adversely affect your ears. Also, raising the volume
too high might prevent you from hearing sounds around
you, which might in turn lead to a traffic accident at a
railroad crossing or pedestrian crossing.
Instruction
When adjusting the volume with an earphone, etc. inserted
into the product, raise the volume a little at a time. If you
raise the volume too much from the outset, sudden loud
noise from the earphone, etc. might adversely affect your
ears.
Instruction
When using a charger or external device, insert/remove
the connector straight to/from the jack. Inserting/removing
in an incorrect orientation might cause damage or a fault.
12
Safety Precautions
Instruction
When small children use the equipment, have the guardian
teach them the proper handling procedures so as to avoid
potential dangerous situations. In addition, check that they
are using the equipment as directed during use. Failure to
do so might cause injury etc.
Main Unit
WARNING Be sure to read the following
warnings before use.
Prohibited
Do not use a cell phone while driving a car or riding a
motorbike or bicycle. Doing so may cause a traffic
accident. Use of a cell phone while driving a car or
motorbike is prohibited by law. Use of a cell phone while
riding a bicycle may be punishable by some regulations.
Instruction
Follow the instructions given by the respective medical
institution regarding the use of the product in a hospital.
Turn off the product in areas where the use of cell phones is
prohibited.
Failure to do so might cause interference with the operation
of electronic devices and electronic medical devices.
Instruction
Turn off the product or set it to Airplane mode before going
aboard an airplane. Since using the product on airplanes
is restricted, follow the instructions given by the respective
airlines.
If you commit a prohibited act while using the product on
an airplane, you might be punished by law.
Instruction
When using the product near an implanted pacemaker,
implanted cardioverter-defibrillator or other electronic
medical device, radio waves might affect these units and
devices. So, please observe the following.
1. Those with an implanted pacemaker or implanted
cardioverter-defibrillator should carry or use the product
at least 15 cm away from where the implant is.
2. Change to Airplane mode on the product beforehand or
turn the product off before entering a place where it may
not be possible to maintain a distance of 15 cm, such as
where movement is restricted, since there may be
people with a cardiac pacemaker or implanted
cardioverter-defibrillator nearby.
3. When a medical institution has laid down designated
areas where use of the product is prohibited or is not
allowed to be brought in, abide by the instructions of
that medical institution.
4. When using electronic medical devices other than an
implanted pacemaker and implanted cardioverter-
defibrillator outside a medical institution (e.g. home
medical treatment), check individually with the
manufacturer of the electronic medical device regarding
the influence of radio waves.
Instruction
Stay alert to your surroundings when calling, messaging,
browsing the Internet, shooting photos, watching TV(1Seg)
or listening to music. Failure to do so might cause a fall or
traffic accident.
Prohibited
Do not send data by infrared communication with the
infrared port pointing toward eyes. Doing so might affect
eyes. Also, sending data with the infrared port pointing
toward some other infrared device might cause false
operation, etc.
13
Safety Precautions
Prohibited
Do not point the illuminated light directly at someone’s
eyes. Be especially careful not to shoot small children from
a very close distance. Do not use Mobile light near people’
s faces.
Eyesight may be temporarily affected leading to accidents.
Prohibited
Do not light the mobile light toward a driver of a car,
motorbike or bicycle. If dazzled by the light, the driver
might become unable to drive and cause an accident.
Instruction
Sometimes, very rarely some people demonstrate
symptoms such as temporary muscle spasms, loss of
consciousness, etc. by watching repeatedly flickering
screens. Those with a past history of this should consult
with a physician beforehand.
CAUTION Be sure to read the following
cautions before use.
Prohibited
Use of the main unit in an automobile might sometimes
affect on-vehicle electronic devices, though this rarely
happens. If this happens, do not use since this may impair
safe travel.
Instruction
If you feel any abnormality with your skin, immediately
consult a dermatologist. Itching, rashes, eczema, etc.
sometimes occurs depending on your physical constitution
and condition.
The materials of parts used on the product are as follows.
Main Unit (SHF31)
Part Material
Surface treatment
Outer case (operation key
sheet)
PET Acrylic UV
cured coating
Part Material
Surface treatment
Outer case (lower key
circumference)
Glass fiber
polyamide resin
Acrylic UV
cured coating
Outer case (lower back) Glass fiber
PC+ABS resin
Acrylic coating
Outer case (main display
frame)
Acrylic resin Hard coating
Outer case (main display
back)
Acrylic resin Acrylic UV
cured coating
Outer case (main display
side/hinge side/tip)
Glass fiber
polyamide resin
Acrylic UV
cured coating
Main display Acrylic resin Hard coating
Sub display Acrylic resin Acrylic UV
cured coating
Hinge stopper POM resin None
Hinge cover PC+ABS resin Acrylic UV
cured coating
Hinge panel Acrylic resin Acrylic UV
cured coating
Camera lens Acrylic resin Hard coating
Camera lens fringe Aluminum Dye anodized
Mobile light lens PC resin None
Infrared port cover Acrylic resin None
Center key Acrylic resin None
Cursor key Acrylic resin None
Key cosmetic (Cursor key,
Address book key, etc.)
Acrylic resin None
Address book key
Camera key
Mail key
Browser/Apps key
Acrylic resin None
14
Safety Precautions
Part Material
Surface treatment
Call key
Clear key
Power/End call key
Number keys
Acrylic resin None
Recent Apps key
Tethering key
Acrylic resin None
Volume UP/DOWN key PC resin Acrylic UV
cured coating
Shutter/Manner key PC resin Acrylic UV
cured coating
Charger terminal SUS Gold plating
Back cover Glass fiber PC
rasin+Silicon
Acrylic UV
cured coating
Connection jack Copper alloy All-surface
Ni-base plating,
Gold plating
Cushion pads Silicon None
au Nano IC Card (LTE) tray POM resin None
Magnetic sheet Ferrite (mainly
iron oxide)
PET film
(polyethylene
terephthalate)
External connection jack
(metal exterior)
SUS Tin plating
External connection jack
(metal terminal reinforcement)
SUS Tin plating
External connection jack
(resin terminal portion)
Polyamide resin None
External connection jack
(terminal connection)
Corson alloy Gold plating
Screw SUS None
Rubber seal Silicon rubber None
Back cover cushion Urethane foam None
Battery Pack
Part Material
Surface treatment
Outer PC resin+PET None
Contacts Copper alloy Gold plating
Prohibited
Do not bring the product close to magnetized objects such
as cash cards, floppy disks, credit cards, and prepaid
cards. Doing so might result in loss of recorded
information.
Prohibited
Do not allow liquids, metal objects, burnable items, and
other foreign matter to get inside the microSD memory
card slot. Doing so might cause fire, electric shock, a fault,
or injury.
Prohibited
Do not swing the product around by holding the strap, etc.
Doing so might cause an accident or damage.
Instruction
If you have a weak heart, be careful when setting the
ringtone vibration and incoming volume to prevent adverse
effects on your heart.
Instruction
Pay attention to items becoming stuck to the main unit. The
speaker uses magnets, and so thumbtacks, pins, craft
knife blades, staples, and other metal objects sometimes
become stuck to the main unit, and cause unexpected
injury.
Prohibited
Do not put the product directly on sand at a beach, etc.
Sand or other small particles might get inside the earpiece,
mouthpiece, speaker causing the volume to drop. If sand
gets inside the product, it might cause overheating or a
fault.
15
Safety Precautions
Instruction
The product may become hot by prolonged use especially
in high-temperature environment. Be careful when using
the product touching your skin for a long time, as it might
cause low-temperature burns.
Prohibited
When using the product for calling or data communication,
do not keep the product in direct contact with your skin for
a prolonged period, or do not cover the product with
paper, cloth, bedding, etc. The product might get hot,
causing fire, injury or a fault.
Battery Pack
(The battery pack of the product is a lithium-ion battery.)
The battery pack is not fully charged at the time of purchase. Charge
the battery before using the product.
DANGER Be sure to read the following
hazards before use.
Prohibited
Do not short-circuit the plus (+) and minus (-) terminals on
the battery pack.
Prohibited
Do not fail to connect the battery pack to the product in the
correct orientation. Connecting in an incorrect orientation
might cause rupture, fire or overheating. Do not try to
forcibly connect the battery pack, instead thoroughly
check the contact terminal before connection.
Prohibited
Do not puncture the battery pack with a nail, hit it with a
hammer or step on it. Doing so might cause ignition,
overheating, rupture or damage.
Prohibited
Do not allow metal objects (such as necklaces and
hairpins) to come in contact with the contact terminal when
carrying or storing the battery pack. Short-circuiting might
cause overheating, ignition, fire, leakage, or malfunction.
Disassembly
prohibited
Do not disassemble, modify or directly solder the battery
pack. Doing so might cause battery fluid to spurt, causing
blindness if entering eyes, etc. or causing overheating,
ignition, rupture, or injury.
Prohibited
Do not use a battery pack that has been dropped, stepped
on, damaged, or that is leaking battery fluid. Doing so
might cause overheating, ignition, leakage, malfunction, or
injury. Immediately move the battery pack away from fire if
you notice leakage of fluid or unusual odor. Failure to do
so might cause the leaked fluid to catch fire resulting in
ignition or rupture.
Wetting with
water prohibited
Do not wet the battery pack with water, seawater, pet urine,
etc. A wet battery pack might cause overheating, rupture,
ignition, malfunction, or injury. If you drop the product into
water by mistake, immediately turn off the power, remove
the battery pack, and contact an au shop or the Keitai
Guarantee Service Center. Never charge a wet battery
pack.
Instruction
If the liquid leaking from inside gets on your skin or
clothes, immediately rinse it off with water to avoid injury. If
the liquid gets into your eyes, do not rub but wash your
eyes with water, and immediately consult a doctor to avoid
the risk of losing your eyesight.
16
Safety Precautions
Instruction
The battery pack is a consumable item. If the performance
of a battery pack does not recover (e.g. the usable time
after each charge has become extremely short), the
battery pack is at the end of service life, so stop use and
buy a new one of the specified type. Failure to do so might
cause overheating, ignition, rupture or leakage. Note that
the length of service life varies depending on the usage
condition, etc.
Instruction
Be careful not to let a pet bite the battery pack.
Letting it do so might cause leakage, overheating, rupture,
ignition, fire, injury, etc.
Charger
WARNING Be sure to read the following
warnings before use.
Prohibited
Do not use at other voltages than the specified power
supply voltage. Doing so might cause ignition, fire,
overheating, electric shock or injury.
•Specified AC adapter (sold separately): 100 V AC to
240 V AC
Do not charge with voltage converter for overseas travel.
•Specified DC adapter (sold separately): 12/24 V DC (for
negative grounded vehicles only)
Instruction
Firmly insert the power plug of the specified charger (sold
separately) into the power outlet or cigarette lighter socket
down to the base of its pins. Incomplete insertion of the
power plug might result in electric shock, overheating,
ignition, fire, or injury. Do not use damaged specified
charger (sold separately) or loose power outlets or
cigarette lighter sockets.
Instruction
If the fuse in the common DC adapter 03 (sold separately)
blows, replace it with a fuse of the specified type (250 V, 1
A). Replacing with a different type of fuse might cause
overheating or ignition. (For information about fuse
replacement, carefully read the manual for the common
DC adapter 03 (sold separately).)
Prohibited
Do not damage, modify, twist, pull or place a heavy object
on the cable of the specified charger (sold separately). Do
not use a damaged cable. Doing so might cause electric
shock or short circuit causing fire, a fault, or injury.
Prohibited
Do not let your hands, fingers or other parts of your body
touch the charger terminal. Doing so might cause electric
shock, injury or malfunction.
17
Safety Precautions
Prohibited
If you hear thunder, do not touch the AC adapter. Doing so
might cause an electric shock as a result of a lightning
strike.
Disconnect plug
from power outlet
Before cleaning the specified charger (sold separately),
unplug its power plug from the outlet or cigarette lighter
socket. If the plug remains plugged in when you clean the
charger, it might cause electric shock or short circuit
causing fire, a fault, or injury.
Instruction
Wipe off dust on the power plug. Failure to do so might
cause fire, burns or electric shock.
Instruction
Place the common DC adapter 03 (sold separately) where
it does not hinder driving or safety equipment such as
airbags. Failure to do so might cause a traffic accident.
Place the common DC adapter 03 (sold separately)
following the instructions of its manual.
Disconnect plug
from power outlet
When the charger is not to be used for a long time,
disconnect the charger’s power plug from the power outlet
or cigarette lighter socket. Failure to do so might cause fire
or a fault.
Wetting with
water prohibited
Specified chargers (sold separately) are not waterproof.
Never use in places subject to direct splashing with water,
pet urine, etc. or in humid places such as a bathroom.
Doing so might cause overheating, fire, electric shock, or
injury. In the event that a charger is splashed with liquid,
immediately disconnect its power plug.
Wet hands
prohibited
Do not plug in or unplug the specified charger (sold
separately) with wet hands. Doing so might cause electric
shock, a fault, or injury.
Prohibited
Do not use the desktop holder (sold separately) inside a
car. Doing so could hinder driving and cause an accident.
CAUTION Be sure to read the following
cautions before use.
Disconnect plug
from power outlet
When unplugging the power plug of the specified charger
(sold separately) from the outlet or cigarette lighter socket,
hold the charger to do so. If you pull the cable, it might be
damaged, causing overheating, ignition, electric shock, or
injury.
Prohibited
Do not leave the specified charger connected to the
product with the battery pack removed. Doing so might
cause ignition, electric shock, or injury.
18
Safety Precautions
au Nano IC Card (LTE)
WARNING Be sure to read the following
warnings before use.
Prohibited
Do not put the au Nano IC Card (LTE) in a cooking
apparatus such as a microwave oven or a pressure vessel.
Doing so might cause melting, overheating, fuming, loss of
data or a fault.
CAUTION Be sure to read the following
cautions before use.
Instruction
Be careful not to injure your hand or finger when attaching/
removing the au Nano IC Card (LTE).
Instruction
Use only the devices specified by the Company to insert
the au Nano IC Card (LTE) in. Using a device not specified
by the Company might cause loss of data or a fault.
For the specified devices, contact an au shop or Customer
Service Center.
Disassembly
prohibited
Do not disassemble or modify the au Nano IC Card (LTE).
Doing so might cause loss of data or a fault.
Prohibited
Do not use or leave the au Nano IC Card (LTE) in hot
places such as by a fire or a heater. Doing so might cause
melting, fuming, loss of data or a fault.
Prohibited
Do not throw the au Nano IC Card (LTE) into a fire or heat
it. Doing so might cause melting, fuming, loss of data or a
fault.
Prohibited
Do not touch the IC (metal) part of the au Nano IC Card
(LTE) or short-circuit it. Doing so might cause loss of data
or a fault.
Prohibited
Do not drop the au Nano IC Card (LTE) or subject it to
strong impact. Doing so might cause loss of data or a fault.
Prohibited
Do not fold, bend or place a heavy object on the au Nano
IC Card (LTE). Doing so might cause loss of data or a fault.
Wetting with
water prohibited
Do not wet the au Nano IC Card (LTE). Doing so might
cause loss of data or a fault.
Prohibited
Do not scratch the IC (metal) part of the au Nano IC Card
(LTE). Doing so might cause loss of data or a fault.
Prohibited
Do not store the au Nano IC Card (LTE) in dusty places.
Doing so might cause loss of data or a fault.
Prohibited
Do not store the au Nano IC Card (LTE) in places exposed
to direct sunlight or hot and humid places. Doing so might
cause loss of data or a fault.
Instruction
Store the au Nano IC Card (LTE) out of reach of small
children. Accidental swallow might cause asphyxiation,
injury, etc.
19
Safety Precautions
Handling Precautions
These precautions are provided to ensure that performance can be
fully demonstrated.
Thoroughly read these precautions to ensure correct use.
Precautions common to the main unit, battery pack, back
cover, charger, au Nano IC Card (LTE), peripheral devices
●Do not apply excessive force to the product during use. Be sure
not to put the product into a tightly packed bag or place a heavy
object on the product in a bag. Sitting on the product in your
pocket might damage the display or internal circuit board resulting
in a malfunction.
Keeping an external device connected to the external connection
jack might damage the connector resulting in a malfunction. Such
damage and malfunction are not covered by the warranty, even if
there is no external damage.
●To ensure waterproof property (equivalent to IPX5 and IPX7) of the
product, use the product with a specified back cover tightly closed.
Note that the waterproof property is not guaranteed in every usage
condition. Do not allow water to get inside the product or splash
water on the battery pack, charger, or optional accessories. Do not
open/close the back cover in the rain or with any water on the
surface of the product. Doing so might cause water intrusion
resulting in internal corrosion.
Malfunctions determined to be caused by such water intrusion are
not covered by the warranty.
●Do not use the product in extremely hot, cold or humid places. (Use
within an ambient temperature range of 5°C to 35°C and humidity
range of 35% to 85%.)
•Charger
•Conversion cables
●Do not use the product in extremely hot, cold or humid places. (Use
within an ambient temperature range of 5°C to 35°C and humidity
range of 35% to 85%. Using at a temperature of 36°C to 40°C is
allowed only when you use the product temporarily.)
•SHF31
•Battery pack (installed in SHF31)
•au Nano IC Card (LTE) (inserted into the SHF31)
●Do not use in places subject to lots of dust or vibration.
●Clean the product with a soft dry cloth (such as the type used for
eyeglasses). Forceful rubbing with a dry cloth may scratch the
display. The display may be stained if splash or smear is left
attached to the surface. Wiping the product using alcohol, thinner,
benzene, detergent, etc. might erase the printing on the outer
casing or cause discoloration.
●Use as far away as possible from fixed-line phones, TVs and
radios. Use nearby might affect them.
●The product may become warm while charging or during other
operations, depending on the situation, but this is not abnormal.
●When the temperature of the product gets high during use, the
product may temporarily lower the screen brightness or may stop
part of its functions to protect the main unit.
●Turn off the power of the product before removing the battery pack.
If you remove the battery pack with the power on, saved data might
be altered or lost.
Main unit
●Do not forcefully press, tap or intentionally subject the display to
strong impact. Doing so might cause scratching or damage.
●Do not forcefully press sharp objects or hard objects against keys
or display surface. Doing so might cause scratching or damage.
●The product’s keypad (touch area) can be operated with your
fingers as a touchpad (Touch Cruiser EX). However, in the following
cases, the touch area may not respond to touch operation. These
may also result in malfunction.
•with gloves on
•with fingernails
•with another object placed on the operation area
•with a sticker adhered
•with any water or condensation on the touch area
•with wet or sweaty fingers
20
Safety Precautions
●Do not remove the sticker printed with the IMEI number in the
battery compartment visible when the battery pack is removed.
This sticker bears a “Technical Conformity Mark ” certificating
that the product and the communication module you are using
comply with the Radio Law and Telecommunications Business Law.
●Never use modified au cell phones. Use of a modified device
violates the Radio Law.
The product has acquired the certification of conformity with
technical regulations for a specified radio station based on the
Radio Law and certification of conformity with technical regulations
for the terminal based on the Radio Law, and the “Technical
Conformity Mark ” can be confirmed on the product nameplate
sticker.
If the screws of the product are removed and modifications are
made to the internal components, the certification of conformity
with technical regulations will become invalid. Never use the
product without this valid certification. Doing so violates the Radio
Law.
●To prevent unlawful modification, the product has been designed
so that it cannot be easily disassembled. Modifying the product is
prohibited by the Radio Law.
●Contents saved in the product, such as contacts, mails and
bookmarks might be altered or lost by an accident, fault, repair or
mishandling. Be sure to keep a copy of important contents. Note
that the Company assumes no responsibility for any damages or
lost profits resulting from altered or lost contents.
●Note that content data (both charged or free content) saved on the
product cannot be returned to the customer when the product is
replaced for repair of a fault, for example.
●The product uses liquid crystal for its main display. Wearing
polarizing sunglasses may result in the display appearing dark or
distorted due to the characteristics of the sunglasses and the angle
viewed at.
●The product uses liquid crystal for its main display. The main
display response speed may become slow when the ambient
temperature is low, which is due to the characteristics of liquid
crystal and is not a malfunction. The main display response speed
will return to normal at room temperature.
●Although the main display used on the product is made using
high-precision technology, some pixels (dots) might be lit or out at
all times. This is not a malfunction.
●The product uses an OEL display in its sub display. While OEL
displays may experience lowered partial brightness if same images
are displayed for a long time or if used for an extremely long time,
this is due to the characteristics of the OEL display and is not a
malfunction.
●OEL displays are manufactured with high-precision technology,
and may experience very limited instances of pixels not lighting or
being always on.
Brightness may also appear unevenly in bands depending on the
angle. This is due the structure of the OEL display, and is not a
malfunction.
●Leaving an OEL display under direct sunlight might cause
malfunction. Use caution when placing near a window or outdoors.
●Take care not to inconvenience people around you when you use
the product in a public place.
●You are recommended to store copies of individual data such as
still pictures/videos you took and music in your PC by sending each
file as mail attachment, etc. Note, however, that you may not be
able to make copies of some copyrighted data even by the
above-mentioned means.
●Take care not to place magnetized items such as magnetic cards,
speakers and TV sets near the product, as it might cause
malfunction.
Putting strong magnetism close to the product might cause false
operation.
21
Safety Precautions
●When you put the product in your pocket or bag, take care so that
the display does not come in contact with metal objects or other
hard objects, as it might cause scratching or damage. Straps with
metal or other hard parts that may come in contact with the display
may cause scratching or breakage.
●When suddenly brought into a warm place from a cold place, or
when in a humid location, or when used where temperature
suddenly changes (e.g. near the air discharge port of an air
conditioner), water drops (i.e. condensation) sometimes are formed
inside the product. Note that when used under conditions such as
this, humidity might cause corrosion or a fault.
●When wiping the display, wipe with a soft, dry cloth. Use of a
moistened cloth, glass cleaner or other similar liquid might cause a
fault.
●When connecting/disconnecting an external device to/from the
external connection jack make sure to insert/remove the connector
of the external device straight to/from the jack.
●Note that applying unnecessary force with an external device
connected to the external connection jack may cause damage.
●Do not discard the product together with regular trash. Please
cooperate in the collection of the product when it is no longer
needed to protect the environment and effectively use resources.
Old products are collected at au shops and other places.
●Insert only a microSD memory card into the microSD memory card
slot on the product.
●Do not exert excessive force when attaching/removing a microSD
memory card. Doing so might injure your hands or fingers.
●While writing/reading data to/from a microSD memory card, do not
subject the product to vibration or impact or turn off the power.
Doing so might cause loss of data or a fault.
●When hearing the other party’s voice, make sure that the earpiece
is placed at the center of your ear. If the earpiece (audio output
port) is closed by the ear lobe, it may be hard to hear the voice.
●Even if you cover the mouthpiece to make your voice inaudible to
the other party, the other party can hear your voice.
●When using handsfree call, take care to keep the speaker at a safe
distance from your ears, as the speaker volume may be too loud.
●Putting a sticker, etc. on the main display or a key may cause
malfunction or shortened usage time. Also, doing so may damage
the product.
●Be careful not to pinch your fingers when opening/closing the
product.
●If you put magnetized objects, metal straps, etc. close to the
product, the speaker section sometimes emits sounds. This is not a
fault.
●Bright places such as under the direct sunlight sometimes make it
hard to see the display. This is not a fault.
22
Safety Precautions
Battery pack
●Use in very hot or cold environments, for example, when left in an
automobile with the windows closed in summer, will cause the
battery capacity to drop and shorten the available battery usage
time. This will also shorten the battery pack’s service life. Try to use
the battery pack as much as possible at room temperature.
●When the battery pack is not to be used for a long time, remove the
battery pack from the main unit, and store it away from hot and
humid places.
●Charge the battery before using the product for the first time after
purchase, or if you have not used the product for a long time.
●The battery pack is a consumable item. If the performance of a
battery pack does not recover after charge, the battery pack is at
the end of service life, so buy a new one of the specified type. Note
that the length of service life varies depending on the usage
condition, etc.
●Do not discard battery packs together with regular trash. Please
cooperate in the collection of used battery packs to protect the
environment and effectively use resources. au shops and other
retailers collect used battery packs.
●Battery packs sometimes swell up as they approach the end of
their service life depending on the usage condition.
This is due to the properties of lithium-ion batteries, and is not a
problem in terms of safety.
Charger
●When not using the specified charger (sold separately), remove its
power plug from the power outlet or the cigarette lighter socket.
●Do not wrap the power cord of the specified charger (sold
separately) around the power plug or desktop holder (sold
separately). Doing so might cause electric shock, overheating, fire,
a fault, or injury.
●Do not forcibly bend the charger’s plug or the connection between
the connector and power cord. Doing so might cause electric
shock, overheating, fire, a fault, or injury.
●Do not use the common DC adapter 03 (sold separately) with the
car engine stopped. Doing so might result in draining of the car
battery.
au Nano IC Card (LTE)
●The au Nano IC Card (LTE) is lent to you by au. In case of loss or
damage, the card will be replaced at your expense. When
malfunction is suspected, or in case of theft or loss, contact an au
shop or PiPit.
●Do not forcibly remove or insert the au Nano IC Card (LTE). Be
careful not to exert excessive force when inserting the card into
your au cell phone.
●You are responsible for any damage caused by inserting your au
Nano IC Card (LTE) into some other IC card reader/writer, etc.
●Keep the IC (metal) part of your au Nano IC Card (LTE) clean. Wipe
the card with a dry, soft cloth (such as for cleaning eyeglasses) for
cleaning.
●Do not put stickers, etc. on the au Nano IC Card (LTE).
Camera
●When using the camera, follow common rules of etiquette regarding
camera use.
●Image data might be altered or lost due to malfunction, repair or
mishandling of the product. The Company takes no responsibility
for recovery of altered or lost data, damages resulting from altered
or lost data, and lost profits.
●When photographing important occasions (such as a wedding),
take a trial shot and check the shot image to make sure it is
correctly shot.
●Do not use the camera for recording commercially available books
or information of which photographing is not allowed.
●Do not leave the camera lens exposed to direct sunlight. Imaging
elements might be discolored or burnt.
23
Safety Precautions
Music, videos and TV (1Seg)
●Do not listen to music, watch videos or TV (1Seg) while driving a
car or motorbike, or riding a bicycle. Use of cell phones while
driving a car or motorbike is prohibited by law. (Use of cell phones
while riding a bicycle may also be punishable by law.) In addition,
stay alert to the traffic around you even when walking. Surrounding
sounds might not be heard clearly, and gazing at the screen may
distract your attention causing a traffic accident. Be especially
careful at railroad crossings, station platforms and pedestrian
crossings.
●Take care not to listen at ear-splitting volume for a long time, as it
might affect hearing.
●Be careful of sound leakage from earphones in trains or other
places with many people around you.
Copyrights and rights of portrait
●If the data you shot or recorded using the product or the data you
downloaded from the Internet etc. is in part or in whole protected
by the third party’s copyright, you are not allowed to copy,
distribute, publicly send, modify the data without consent of the
copyright holder, except for personal use, under the copyright law.
In addition, do not use or modify portraits or names of other
individuals without their consent, as it may infringe on rights of
portrait.
Note that shooting and recording might be restricted at some live
performances, shows and exhibitions even for personal use.
●Be careful about the copyright and portrait right when posting still
pictures you shot, etc. on Internet homepages.
Back up content on the product
●Please back up important content recorded or downloaded to the
product to an outside source. Content recorded to memory on the
product sometimes disappears or is altered by unexpected factors,
such as static electricity or a fault, or by repair, mishandling, etc.
* How to make backups: Store important data such as phonebook data,
music, shot still pictures and videos on external memory devices such
as a microSD memory card or PC. You can also send files as mail
attachment or transfer to your PC. Note, however, that there are some
data that cannot be copied by using these means.
24
Safety Precautions
Available Security Codes
Security Codes
The product has various security codes that you can use.
The available security codes are as follows. Do not forget the various
security codes that are set as they are necessary for various
operations and contracts.
Security code
Example
of usage
① To do remote operation of voice mail and call
forwarding services from a landline phone
② To use Customer Service Center and to do various
inquiries, applications, and modifications on the au
homepage
Initial
value
A four digit number chosen by the customer and noted on
the application form
Security key (Passcode/Password)
Example
of usage
To set/cancel voice calling restrictions, etc. or lock
Osaifu-Keitai®
Initial
value
1234
PIN code
Example
of usage
To prevent unauthorized use of the au Nano IC Card (LTE)
by third parties
Initial
value
1234
PIN
PIN Code
To prevent unauthorized use of the au Nano IC Card (LTE) by a third
party, you can set the product to require PIN code entry every time the
power is turned on. You also need to enter PIN code when setting
whether PIN code entry is required.
If PIN code is incorrectly entered three times consecutively, the PIN
code will be locked. You can unlock the PIN code using PUK code.
•PIN code is “1234” and PIN code entry is set to not be required at
the time of purchase. You can change PIN code to any four- to
eight-digit number, and set PIN code entry to be required as
necessary.
PUK Code
In case PIN code is locked, you can unlock it by entering PUK code.
•PUK code is an eight-digit number given at the time of purchase,
which is printed on the back side of the plastic card on which your
au Nano IC Card (LTE) is attached.
•After entering PUK code, you need to set a new PIN code.
•If PUK code is incorrectly entered ten times consecutively, contact
an au shop, PiPit or Customer Service Center.
•PIN code is not reset by initializing the product.
◎When the PIN code is locked, the product may restart for the
security reasons.
25
Safety Precautions
Notes on Waterproof Property
Before using the product, thoroughly read the contents of “Notes on
Waterproof Property” to ensure correct use. Failure to follow the
contents described in these sections may cause intrusion of water,
sand or other foreign material, resulting in overheating, ignition,
electric shock, injury or fault.
Proper operations of the product are not guaranteed in every possible
condition during actual use. Faults determined, after an inspection, to
be caused by mishandling by the customer such as by using the
product without following the contents written on “Notes on Waterproof
Property” are not covered by the warranty.
Waterproof Property of the Product
The product has a protection rating (JIS C 0920) for waterproof
property equivalent to IPX5*1 and IPX7*2 on the condition that the back
cover is securely closed (based on testing by the Company).
The product does not have dustproof property.
*1 IPX5 means that the cell phone continues to function as a phone after
being subjected to a water jet (approximately 12.5 liters/min) discharged
from a water pouring nozzle (inner diameter: 6.3 mm), from all directions
and approximately 3 meters away from the cell phone for at least 3
minutes.
*2 IPX7 means that the cell phone continues to function as a phone after
being gently lowered into a tank filled with still tap water (at room
temperature) to the depth of 1 meter, immersed at the bottom for
approximately 30 minutes and then taken out of the tank.
Waterproof property of the product enables you
•To talk on the product in the rain without an umbrella (with a
precipitation of 20 mm/hour or smaller).
•To use the product at the poolside. However, do not get it wet with
water other than tap water such as water in the swimming pool or
submerge it in water in the swimming pool.
•To wash the product with the low-pressure water flow of a tap water
(6 liters/min or lower) at the room temperature (5°C to 35°C).
Handling the product
•Close the back cover securely. Even a fine particle (a hair, grain of
sand, tiny fiber, etc.) pinched between contact surfaces may allow
intrusion of water.
•If liquid such as water is splashed onto the product with the back
cover opened, the liquid may seep inside and cause electric shock
or malfunction. Discontinue using the product, turn off the power and
then contact an au shop near you or the Keitai Guarantee Service
Center.
•When the product is wet, wipe it with a dry and clean cloth.
•When your hand or the product is wet, never open/close the back
cover.
•The product is resistant to fresh and tap water at room temperature
(5°C to 35°C) only. If you let the product get wet with or submerged
into the liquids other than fresh and tap water at room temperature,
stop using it and wash it with fresh and tap water at room
temperature.
•Do not use the external connection jack when the jack is wet or sand
or dust is attached to it. Doing so may cause impairment of the
waterproof property or cause electric shock, short circuit, etc.
resulting in a fire, burns, or a fault.
Notes on Using the Product
•Do not let the product get wet with or submerged into the following
liquids.
･Water containing soap, detergent or bath powder
･Seawater or water from a swimming pool
･Hot spring, hot water, etc.
•If the product gets wet with seawater, water from a swimming pool,
soft drink, etc. or dust, sand, mud, etc. is attached on the product,
immediately wash it away with fresh and tap water at room
temperature (5°C to 35°C). When it gets dry and coagulated on the
product, the stains get hard to get rid of and may cause fault.
•Using the product without completely washing sand or mud away
may cause fault such as scratches and damages on the product.
26
Safety Precautions
•Do not immerse the product in a bathtub or swimming pool. Also, do
not use it under water. (including key operations.)
•The product is not designed to withstand high water pressure. Do
not expose the product to a strong water flow with tap water, shower,
etc. (6 liters/min or more) or submerge it under water.
•To prevent condensation, wait until the product reaches room
temperature before you bring it from a cold place into a warm place.
If condensation occurs, leave it in room temperature until the
condensation is removed.
•Do not get the product wet with hot water, use it in saunas or expose
it to hot air from hair dryer etc.
•Do not place the product where it gets extremely hot or cold such as
near a stove or in a refrigerator.
•Volumes may temporarily become lower due to water entering in the
earpiece, mouthpiece and speaker. Drain water and dry the product
well before use.
•The product does not float on water.
•Do not use the product in heavy rain.
•Do not leave the product wet. Doing so may let the liquids freeze on
the product in cold places or otherwise cause fault.
•Do not drop or otherwise subject the product to strong impact or jab
the earpiece, mouthpiece, speaker, etc. with a sharp object. Doing
so may cause scratching, deformation, etc. on/of the product,
resulting in impairment of waterproof property.
•Do not place the product directly on sand at a beach, sandbox, etc.
or on mud. Grains of sand may get into the earpiece, speaker, etc.,
causing the volume to drop.
•The battery pack, desktop holder (sold separately), and optional
accessories are not waterproof. Do not use in a bathroom, shower
room, kitchen, sink, or other location where water is regularly used.
•If the back cover degrades or is damaged, the waterproof property
cannot be maintained. In such case, contact an au shop near you.
Maintaining the Waterproof Property
Rubber seal
The rubber seal on the back cover is important in maintaining the
waterproof property. Be sure to observe the following items.
•Do not remove or scratch it.
•When closing the back cover, do not let the rubber seal caught.
Also, do not insert sharp objects into gaps around the back cover or
the external connection jack section. Doing so may damage the
rubber seal and allow intrusion of water.
•It is recommended to replace the parts for maintaining the
waterproof property (pay service) once every two years regardless
of whether any abnormality is present. For information on part
replacement, contact an au shop near you.
Precautions on Charging
The battery pack, desktop holder (sold separately), specified charger
(sold separately), and optional accessories are not waterproof. Be
sure to check the following items before and after charging.
•Check that the product is not wet. If it is wet or after it gets wet, drain
water well and wipe remaining water off with a clean dry cloth etc.
before mounting in the desktop holder (sold separately) or inserting
the microUSB plug into the external connection jack.
•Never connect the microUSB plug when the product, desktop holder
(sold separately), or specified charger (sold separately) is wet.
Although the product is water resistant, any water or foreign matter
on the product or microUSB plug when inserting the microUSB plug
while the product/specified charger is wet might cause electric
shock or short circuit/corrosion causing abnormal overheating,
burnout, fire, burns, or malfunction.
•Do not touch the desktop holder (sold separately) or specified
charger (sold separately) with wet hands. Doing so may cause
electric shock.
27
Safety Precautions
•Do not splash water onto the desktop holder (sold separately),
specified charger (sold separately), or optional accessories when
using the equipment. Do not use the equipment in places where
water is regularly used such as a bathroom, shower room, kitchen,
and lavatory. Doing so may cause fire, electric shock, malfunction,
or injury.
Washing the Product
If any stain, dust, sand, soft drink, etc. is attached to the surface of the
product, gently wipe it off with a cloth and wash the product under a
mild water flow (up to 6 liters/min) of tap water at room temperature
(5°C to 35°C) approximately 10 cm away from the faucet or shower
head.
Hold the back cover so that it does not open, and wash the product
with your hands without using a brush or sponge. After washing the
product, drain water off and before using the product.
•Make sure that the back cover is securely closed before washing the
product.
•Do not wash the product with a washing machine or an ultrasound
bath.
•The external connection jack section is especially subject to stain
such as dust or sand adhesion. Wash away stain carefully so as not
to keep it remaining in the sections. Also, after washing it away,
make sure the sections get sufficiently dried off before using the
product. Using the product with sand or water drops remaining in
the jack sections may cause fault.
•When cleaning the external connection jack section, do not use tools
such as a cotton swab or jam a cloth into the jack sections. Doing so
may cause impairment of waterproof property etc., resulting in fire,
burns, or a fault.
•Never put the product in a microwave oven for drying it. Doing so
may cause the battery pack to leak liquid, overheat, rupture or ignite.
Also, doing so may cause the product to overheat, emit smoke,
ignite or cause destruction of circuit components.
•Do not expose the product to hot air from a hair dryer or leave it in a
high temperature environment for drying it. Doing so may cause the
product to deform, discolor, get out of order, etc.
Draining Water
If the product gets wet, make sure to drain water remaining in the
“external connection jack section”, “earpiece (receiver) section”,
“mouthpiece (microphone) section”, “speaker section”, “key section”,
“hinges (joint)”, etc.
1 Wipe off water on the surface of the product
carefully with a dry and clean cloth etc.
If a strap is attached, dry it sufficiently as well.
2 Hold the product securely at its hinges (joint) and
shake it approximately 20 times until there is no
more water splashing.
Make sure of the safety around you and shake the product while
holding it securely not to let it drop.
Hinges (joint)
Earpiece
(Receiver) section
28
Safety Precautions
External connection
jack section
Mouthpiece
(Microphone)
section
Speaker section
3 Wipe off water remaining in the grooves of each
section by gently putting the product against a dry
and clean cloth etc.
Since water is sometimes left in the grooves of each section, clear
them of water by putting a cloth against their openings and gently
patting them.
Make sure that there is no more water or foreign objects remaining
in them.
4 Lay out a dry cloth etc. beneath and leave the
product on the cloth at room temperature for
approximately 2 to 3 hours to dry it.
Water, if any, remaining in the product may ooze up after wiping
off.
Do not wipe off water remaining in the grooves directly by a
cotton swab etc.
Precautions to be taken after water draining
Do not use the product with water drops still left on it.
•Doing so may cause call disruption or cause clothes or bags to get
wet.
•Doing so may cause the external connection jack, etc. to short-
circuit, causing fire or malfunction.
•Doing so in a cold region may cause a fault due to water drops
freezing.
29
Safety Precautions
Notes on Using Bluetooth®/Wireless
LAN (Wi-Fi®) Functions
Frequency Band
Bluetooth® and wireless LAN (Wi-Fi®) functions (2.4 GHz band) of the
product use frequencies in the 2.4 GHz band ranging from 2.402 GHz
to 2.480 GHz.
The frequency bands used by this product’s Bluetooth® and wireless
LAN (Wi-Fi®) functions are given on the sticker located in the battery
compartment.
•Bluetooth® function: 2.4FH1/XX4
The product uses the 2.4 GHz band.
FH1 uses FH-SS as the modulation scheme. The interference
distance is about 10 m or less.
XX4 uses other schemes. The interference distance is about 40 m or
less.
Bands of mobile unit identification devices cannot be avoided.
•Wireless LAN (Wi-Fi®) function: 2.4DS/OF4
The product uses the 2.4 GHz band.
DS-SS and OFDM are used as the modulation schemes. The
interference distance is about 40 m or less.
Bands of mobile unit identification devices can be avoided.
Channels available with the 2.4 GHz band wireless LAN (Wi-Fi®) of
the product are between 1 to 13.
Available channels differ depending on the country.
For use in airplane, check with the airline company in advance.
Precautions about Bluetooth®
•The Bluetooth® function of the product conforms to the domestic
standards of Japan and FCC standards and EC directives, and has
been certified.
•The 2.4 GHz band used by wireless LAN (Wi-Fi®) and Bluetooth®
devices is shared by various other devices. For this reason,
Bluetooth® devices use technologies for minimizing effects from
other devices using the same radio frequency band. In some cases,
however, the communication speed and connectable range may be
decreased, or disconnection may occur, due to interference by other
devices.
•The communication speed and connectable range vary depending
on the distance between communication devices, obstacles and the
Bluetooth® devices used.
Bluetooth® function precautions
The frequencies used by the Bluetooth® function of the product are in
the 2.4 GHz band. In this frequency band, in addition to home
electrical appliances such as microwave ovens and industrial,
scientific and medical devices, other similar wireless stations, in-plant
wireless stations for mobile unit identification that require a license for
use such as factory production lines, specific small power wireless
stations that do not require licenses, and amateur wireless stations
(collectively called “other wireless stations” from here on) are
operated.
1. Before using the product, make sure that “other wireless stations”
are not in operation nearby.
2. In the event that instances of radio wave interference have
occurred between the product and “other wireless stations”,
immediately either relocate the product or stop operation of the
device (stop emission of radio waves).
3. If you are unclear on any points or are troubled by anything,
contact an au shop or Customer Service Center.
30
Safety Precautions
Precautions about Wireless LAN (Wi-Fi®)
•The wireless LAN (Wi-Fi®) function of the product conforms to the
domestic standards of Japan, FCC standards and EC directives,
and has been certified.
•Do not use the product in places where electromagnetic waves are
generated or near electric products, AV and OA equipment, or other
magnetized devices.
•Subjecting the product to magnetic or electrical noise might increase
noise and prevent it from performing communications. (The product
is particularly susceptible to noise when it is used near a microwave
oven.)
•Using the product near a TV, radio or similar appliance might cause
reception interference and disrupt TV images.
•Searching might not be successful if there are multiple wireless LAN
(Wi-Fi®) access points near the product and the same channel is
being used.
2.4 GHz band wireless LAN (Wi-Fi®) precautions
The frequencies used by the wireless LAN (Wi-Fi®) function of the
product is in the 2.4 GHz band. In the 2.4 GHz frequency band, in
addition to home electrical appliances such as microwave ovens and
industrial, scientific and medical devices, other similar wireless
stations, in-plant wireless stations for mobile unit identification that
require a license for use such as factory production lines, specific
small power wireless stations that do not require licenses, and
amateur wireless stations (collectively called “other wireless stations”
from here on) are operated.
1. Before using the product, make sure that “other wireless stations”
are not in operation nearby.
2. In the event that instances of radio wave interference have
occurred between the product and “other wireless stations”,
immediately either relocate the product or stop operation of the
device (stop emission of radio waves).
3. If you are unclear on any points or are troubled by anything, contact
an au shop or Customer Service Center.
◎Connections between the product and all other Bluetooth® and
wireless LAN (Wi-Fi®) devices have not been confirmed.
Therefore, connections with all Bluetooth® and wireless LAN
(Wi-Fi®) devices are not guaranteed.
◎The product supports security features for wireless
communications that are compliant with the Bluetooth® and
wireless LAN (Wi-Fi®) standard specifications, but the security
may not be sufficient depending on the usage environment and
configuration. Be careful when making data communication
using Bluetooth® or wireless LAN (Wi-Fi®) function.
◎Wireless LAN (Wi-Fi®) has the advantage that it can be freely
connected anywhere within the radio wave range, as it uses
radio waves for exchanging information. At the same time, there
is a risk that a malicious third party may obtain unauthorized
access if security settings have not been configured. You are
recommended to configure security settings before using
wireless LAN (Wi-Fi®) at your decision and responsibility.
◎The Company assumes no responsibility for leakage of data or
information that may occur during Bluetooth®/wireless LAN
(Wi-Fi®) communication.
◎Since Bluetooth® and wireless LAN (Wi-Fi®) functions use the
same frequency band, using the both functions at the same time
may cause radio wave interference resulting in decreased
communication speed or disconnection from the network. If
connection fails, stop using either of the Bluetooth® and wireless
LAN (Wi-Fi®) functions.
31
Safety Precautions
Notes on Packet Communication
Charge
•Since constant Internet connection is possible with the product,
packet communication may be performed automatically by some
applications, resulting in high packet communication charges.
Therefore, subscription to the flat-rate/discount service for packet
communication charges is recommended.
•To browse homepages, download applications, communicate using
applications, send/receive e-mails and configure various settings,
connection to the Internet is required, to which packet
communication charge applies.
* Packet communication charge does not apply to wireless LAN (Wi-Fi®).
Notes on Applications
•To download applications, first set an au ID and access au スマート
パス(au Smart Pass). For details on setting an au ID, refer to the
“Setting Guide”.
This product does not permit use of Google Play™ or EZweb.
•Be sure to check the security of the application, then install it at your
own risk. Some applications might cause virus infection, damage
various data, and send out your location information, usage history
or personal information stored in your cell phone via the Internet.
•The Company assumes no responsibility for any problems that might
be caused by applications you have installed. In such case, you
may be charged a repair fee even during the warranty period.
•The Company assumes no responsibility for any disadvantage
brought to you or any third party by applications you have installed.
•Insertion of a microSD memory card is necessary to use some
applications.
•Some applications keep the screen turned on while they are active,
or rapidly drain the battery while running in the background.
•Operation procedures and screen appearances of the applications
preinstalled in the product and those installed by you are subject to
change without notice as a result of version upgrade. In addition,
operation procedures described in the “Basic Manual” available on
the au homepage and on the product or “Setting Guide”/“Full
Instruction Manual” (Japanese) available on the au homepage may
differ from the actual procedures.
32
Basic Operations
Names and Functions of Parts
Front/Back
⑪
⑫
⑬
⑭
⑯
⑮
⑩
①
②
③
④
⑤
⑦
⑧
⑨
⑥
⑱
⑰
⑲
⑳
⑲
Main display
dCursor key
sLeft key/incoming call history
fRight key/outgoing call history
eUp key
cDown key
uAddress book key
jMail key
,Clear key
mCall key
09
-
^Number keys
bRecent Apps key
Displays list of running applications. Hold down to set/cancel
VeilView.
Mouthpiece (Microphone)
Transmits your voice to the other party during a call. It is also used
for recording sounds. Take care not to cover the microphone with
your fingers etc. when using it.
Earpiece (Receiver)
Hear the other party during a call, Answering memo messages,
etc.
kCenter key
oCamera key
lBrowser/Apps key
Displays browser menu. Hold down to display applications list.
.Power/End call key
While using the product, end call or exit functions. Hold down to
turn the power on, or to display a power menu for power off, reboot,
or other operations.
33
Basic Operations
Touch area (Touch Cruiser EX)
Use your fingers in the touch area to operate in the same way as a
touchpad. (▶P. 35)
nTethering key
Wi-Fi®/Bluetooth® antenna
@ mark
Hold it over a reader/writer when using Osaifu-Keitai®.
Internal antennas
Used when making calls or using the Internet or 4G (LTE)/3G.
TV antenna
The product contains an antenna for viewing TV (1Seg).
Back cover
Folded (Front/Back/Side)
External connection jack
Use for connecting the common AC adapter 05 (sold separately),
microUSB cable 01 (sold separately), or a USB cable (commercially
available) for peripheral devices.
When you connect the common AC adapter 05 (sold separately),
the microUSB cable 01 (sold separately), etc. to the product, some
applications may not function properly since the geomagnetic
sensor is affected by the magnetism of connected devices. Use the
product after removing the cable.
Charger terminal
Terminal for charging with the desktop holder (sold separately).
Sub display
Notifies you with information when a call is arriving, new mail is
received, an alarm sounds, etc.
Strap eyelet
Charging/Incoming indicator
Lights red/green while charging depending on the battery level.
Flashes for an arriving call or new mail according to settings.
vShutter/Manner mode key
34
Basic Operations
zqVolume UP/DOWN key
Adjust the volume.
Hold down z when the product is folded to turn on the mobile light.
Speaker
Ringtones, alarms, etc. sound from here.
Infrared port
Transfer data by infrared communication.
Camera lens
Mobile light
au Nano IC Card (LTE) tray/slot
microSD memory card slot
Internal antennas, Wi-Fi®/Bluetooth® antenna and TV antenna
◎Antennas are built into the product. Do not cover with hand
during calls or data communication, or place stickers over
antennas. Doing so may affect call/communication quality.
About IMEI
◎IMEI (international mobile station equipment identity) is a unique
identifying code assigned to each device. The product’s IMEI
can be found on the sticker visible in the battery compartment.
◎As the IMEI is required information for requesting repairs or
after-sales service, do not remove the sticker with the IMEI
printed on it.
Using Touch Cruiser EX
Use your fingers in the touch area to operate in the same way as a
touchpad (Touch Cruiser EX). Activating a function/application
supporting Touch Cruiser EX enables Touch Cruiser EX and allows the
on-screen pointer to be operated.
1 Activate function/application supporting Touch
Cruiser EX.
Touch Cruiser EX is enabled and “ ” (pointer) is displayed.
•Hold down m to toggle Touch Cruiser EX on/off.
•If an operation description for Touch Cruiser EX is displayed,
press k (OK). Checkmark “Don't show again” and press k
(OK) to no longer display the operation description when next
activating Touch Cruiser EX.
•Ending a function/application supporting Touch Cruiser EX
disables Touch Cruiser EX.
•Key operation is still possible even when Touch Cruiser EX is
enabled (Except for some applications).
35
Basic Operations
Operation with Touch Cruiser EX
When using the browser, LINE, etc., the on-screen pointer can be
operated like a mouse.
Touch area
Tap/Double-tap
Gently tap the touch area. To double-tap, tap
the same position twice.
•Select items and icons under the pointer.
Double-tapping a displayed photo, etc. to
zoom in or out. Zooming is carried out
centered around the pointer. Zoom after
placing the pointer where you want to
zoom.
Long-Touch
Keep gently touching the touch area. “ ”
changes to “ ”. Tap the touch area or, after
releasing your finger and several seconds of
no operation, the indication returns to “ ”.
•Display menus, etc.
Slide
Long-touch the touch area to change “ ” to
“ ”.
While gently touching the touch area, slide in
the desired direction or to the desired
position.
•Slide in the desired direction to scroll and
switch pages.
Flick
Long-touch the touch area to change “ ” to
“”.
While touching the touch area, flick up,
down, left, or right.
•Flick in the desired direction to quickly
scroll the screen, switch pages, etc.
36
Basic Operations
Pinch
While touching the touch area with two
fingers, widen (pinch out) or close (pinch in)
your fingers.
•Zoom in or out on the browser, etc.
Zooming is carried out centered around
the pointer. Zoom after placing the pointer
where you want to zoom.
◎The touch area is designed to be touched gently. Avoid pressing
forcefully or using sharp objects (ballpen, pin, etc.).
◎The touch area might not respond to the following types of
operation, and may also cause malfunction.
•with gloves on
•with fingernails
•with another object placed on the operation area
•with a sticker adhered
•with any water or condensation on the touch area
•with wet or sweaty fingers
Switching the Display Language to
English
You can switch the display language for function names and other
items to English.
1 When the standby screen is displayed, press k
[](Settings).
2 [](Other settings) [(Language)]
(Select language).
3 [English].
Using the Standby Screen
Check the status of the product in the standby screen.
Viewing the Standby Screen
①
③
②
④
⑥
⑤
《Standby Screen》
Status Bar
Search
Calendar
Indicator icons
Indicators for missed calls, unread e-mail/SMS, and notifications
are displayed.
Kantan Hasshin icon
When displayed, you can use “Kantan Hasshin (voice recognition)”
to make a call (▶P. 52).
Clock
37
Basic Operations
Using shortcuts in the Standby Screen
You can use the calendar and indicator icons in the standby screen as
shortcuts.
1 When the standby screen is displayed, press w
Select item k.
•Selecting an indicator icon displays its content in a balloon.
Using the Status Bar
Icons
The notification icons to notify you of a missed call, a new mail
message, a running operation, etc. are displayed on the left side of
the status bar, while the status icons to show the status of the product
are on the right side.
Main Notification Icons
Icon Description
Missed call
New mail message
1Seg signal strength
～: Level display
Making a call, talking, receiving a call
Call on hold
Answering memo
Available space on the internal memory being run out
Software update available
Icons collected
◎Some icons are displayed with their number superimposed on
them.
Main Status Icons
Icon Description
Time
～Battery level
～: Battery level display : No battery
•While charging, the battery icon is displayed with
superimposed.
Airplane mode set
～Signal strength (Receiving electric field)
～: Level display : Out of service area
•The icon indicating network is displayed at the upper
left.
: 4G (LTE) available : 3G available
: Roaming
•During a communication, the icon is displayed with
superimposed.
: Kanji : 1-byte alphabet : 1-byte digits
: 1-byte katakana : 2-byte alphabet : 2-byte
digits
: 2-byte katakana : Kuten code
Manner mode status
: Standard manner mode : Drive manner mode
: Silent manner mode
During a call using hands-free
Arriving call volume set to “Silent”
Microphone set to “Mute” during a call
～Wi-Fi® signal strength
～: Level display
•During a communication, the icon is displayed with
superimposed.
38
Basic Operations
Icon Description
Answering memo set
: No Answering memo
: Answering memo (one to nine entries)
: Answering memo full (ten entries)
Using the Notification/Status Panel
In the notification/status panel, you can check the details on
notification icons and status icons or activate an application
corresponding to the icon.
You can also set the manner mode and check Answering memo.
1 When the standby screen is displayed, press w
Select the status bar k.
2 Select the notification k.
The application corresponding to the notification is activated.
Viewing the Notification/Status Panel
①
②
《Notification/Status panel》
Music controller
Displayed when playing music with LISMO. Only allows
pausing.
Notification area
Check the status of the product and contents of notifications.
Using notifications
1 Select the desired notification in the notification/
status panel o (Operate).
Options corresponding to the content of the notification are
displayed.
2 Select an option k.
You can activate a corresponding application, etc.
Deleting 1 notification
1 Select the notification to delete in the notification/
status panel u (Submenu) [Delete one item]
k.
Deleting all notifications
1 u (Submenu) in the notification/status panel
[Delete all] k.
•You may not be able to delete a notification depending on the
notification.
39
Basic Operations
Using the Sub display
The sub-display shows information including manner mode, battery
level, and other product status, the date and time, and caller and other
information.
Press z/q/v to switch displays.
Viewing the Sub-display
z/q/v
《time》 《icon + time》 《icon + time +
month/date/day》
Main Icons
Icon Description
Signal strength (Receiving electric field)
Strong / Fair / Weak / Faint /
Out of range
* Not displayed in airplane mode.
～Battery level
～: Battery level display
: No battery
•While charging, the battery icon is displayed
with superimposed.
Missed call
•Displays number of calls.
: New mail (e-mail/SMS)
•Displays number of new mails
: Earthquake Early Warning
Icon Description
Manner mode status
: Standard manner mode
: Drive manner mode
: Silent manner mode
Answering memo set
•Displays number of unread Answering memo
messages.
Screen locked
Airplane mode set
Displayed Information
Status Display
Voice
call
arriving
Display caller
(Registered in address
book)
Registered name
Display caller
(Not registered in
address book)
Phone number
Not display caller “Incoming call”
Answering memo Answering: “Playing answering
memo guidance”
Recording: “Recording answering
memo”
In call In call “In call”
Sound memo “Recording sound memo”
Volume change Volume change screen
Call on hold “Answering on hold”
40
Basic Operations
Status Display
Mail
arriving
Display caller
(Registered in address
book)
Registered name
Display caller
(Not registered in
address book)
E-mail address
Not display caller “Received mail”
SMS
arriving
Display caller
(Registered in address
book)
Registered name
Display caller
(Not registered in
address book)
Phone number
Not display caller “Received message”
Alarm Alarm sounding Alarm time, alarm name
Snoozed “Snoozing”
Emergency Rapid Mail “Emergency Rapid Mail”
Manner
mode
When set: normal “Standard manner set.”
When set: drive “Drive manner set.”
When set: silent “Silent manner set.”
When not set: normal “Standard manner canceled.”
When not set: drive “Drive manner canceled.”
When not set: silent “Silent manner canceled.”
Music
playing
Volume change Volume change screen
LINE application notification Message from LINE application
is displayed.
Using the Main Menu
In the main menu, applications are grouped in menus. Select a menu
and then an item to activate an application.
1 When the standby screen is displayed, press k.
The main menu is displayed.
2 Select menu k.
Menus have correspondence with the dial keys (0 to 9, -,
^). Press any key to select a menu.
3 Select application k.
Viewing the Main Menu
《Main Menu》
41
Basic Operations
Main Application List
Menu Description
auスマートパス
(au Smart Pass)
All-you-can-download applications for a
monthly 372 yen (tax excl.). Plus, this service
also has benefits such as bargain coupons
and presents, photo upload storage service,
and security software for enjoying using the
product with security and freedom.
Browser
View webpages the same way as with a PC. (▶P. 66)
au WALLET Allows you to get the most convenience from
your au WALLET card. In addition to loading
cash to your card, use the screen optimized for
cell phones to check your card’s cash balance,
point balance, bonuses, and more.
Camera Capture still pictures and video. (▶P. 68)
Datafolder
View captured still photos/videos, downloaded files, etc.
LINE This communication app allows you to enjoy
calling and texting as much as you want, any
time and any place. (▶P. 64)
Application*
au ID Setting Set au ID.
auナビウォーク (au navi walk)
LISMO
au Wi-Fi接続ツール (au Wi-Fi connection tool)
GLOBAL PASSPORT
au災害対策 (au Disaster Countermeasure)
Safety Access
au Backup App
OfficeSuite This application allows viewing of Microsoft
Word, Excel, PowerPoint and PDF files created
on a PC or other device.
Use easily whenever you want to view these
types of files.
Menu Description
Tools
Alarm Use alarms.
Timer Use a timer.
Calendar Use a calendar.
Notepad Use a notepad.
Calculator Use a calculator.
PASSNOW Pair with and use a compatible tablet or other
device to enjoy photos and videos captured
with the product and view notifications arriving
on the product.
TV (One Seg) View digital terrestrial TV broadcast service for
mobile devices. (▶P. 71)
Infrared Transfer data between the product and another
device with an infrared communication
function.
Widget sheet Add and use widgets.
Osaifu-Keitai Use services compatible with Osaifu-Keitai®.
GLOBAL
PASSPORT
When overseas, use this application to confirm
fees applicable for your country of stay, how to
make settings, the method of making
international calls, etc.
au Wi-Fi接続
ツール (au Wi-Fi
connection tool)
Allows simple connection to a HOME SPOT
CUBE or other wireless LAN (Wi-Fi®) base set
in your home. All au Wi-Fi SPOTs become
available when outside. Spot searching also
possible.
StopWatch Use a stopwatch.
World clock Use a world clock.
TOUCH
CRUISER EX
Guide
Display operating instructions for Touch Cruiser
EX. (▶P. 35)
42
Basic Operations
Menu Description
Service
LISMO Play music and look for the latest music
information. Also, listen to samples and buy
songs you searched for.
auナビウォーク
(au navi walk)
View navigation for a best route that combines
transportation and walking.
Safety Access Filtering application that restricts access to
webpages and use of applications that are
likely inappropriate, allowing your child to use
the cell phone worry free.
au災害対策
(au Disaster
Countermeasure)
This is an application in which you can use
Disaster Message Board, Emergency Rapid
Mail (Earthquake Early Warning, Disaster and
Evacuation Information, and Tsunami Warning)
and Disaster Voice Messaging Service.
(▶P. 4)
au Backup App Allows all the different data stored on your au
phone to be backed up or restored using a
microSD memory card.
The auto backup function automatically backs
up data on the day and at the time you set.
メーカーサービ
ス（SHSHOW）
(Manufacturer
service
(SHSHOW))
Download, view, etc. contents.
Menu Description
Call/mail
Incoming/
outgoing call
history
View incoming and outgoing call histories.
(▶P. 50)
Address Book Register contacts to the address book and use
registered information. (▶P. 55)
Call settings Make call settings.
Speed dial View a speed dial list. (▶P. 52)
Mail Use an e-mail (～ezweb.ne.jp) address to send
and receive e-mail. Send and receive SMS
using a phone number as the recipient.
(▶P. 57)
Profile Check and edit your profile. (▶P. 54)
Settings Specify and manage settings in the settings
menu. (▶P. 73)
* Additionally downloaded applications are displayed in “DOWNLOAD”.
(▶P. 44)
◎When activating applications and using their functions,
communication charges may result for some functions.
◎After upgrading an application version or in similar instances, the
design of applications, icons, etc. on the product may differ from
this manual.
43
Basic Operations
About Applications
“Application” allows you to use applications pre-installed at time of
purchase as well as additionally downloaded applications.
1 When the standby screen is displayed, press k
[Application].
The application list is displayed.
Switching tabs
1 When the application list is displayed, press x.
The “PRESET”/“DOWNLOAD” tabs switch.
Searching for applications
1 When the application list is displayed, press o
(AppSearch).
The auスマートパス(au Smart Pass) site is displayed. Follow the
on-screen instructions to search for and download applications.
Learn Common Operations
Learn Basic Key Operations
Using Functions that Appear at the Bottom of the
Screen
Press the key corresponding to a function that appears at the bottom
of the screen.
①
②
③
④
⑤
① For “Done”, press k.
② For “Submenu”, press u.
③ For “あA1”, press j.
④ For “Emoji/Sym”, press o.
⑤ For “Select area”, press l.
44
Basic Operations
To Select Items
To select a displayed item, select the item using w or d and press k.
If 0 to 9, -, ^, etc. are displayed in the menu, you can also
press a corresponding dial key.
•You can also sometimes press f.
To Return to Previous Screen
You can press , to go back one screen.
•You can also sometimes press s, u, or j to return to the previous
screen.
To Return to the Standby Screen
To return to the standby screen from any function, press ..
•After a certain period of no key operation, the product may return to
the standby screen automatically.
•If activating a function while in a call, the call may be interrupted.
•The function or application being used is ended.
To Enter Numbers
You can press 0 to 9 to enter numbers.
If “▲” and “▼” are displayed above and below the number entry field,
you can press w to increase or decrease the number.
To Move to Previous or Next Data
While displaying mail, etc., you can press l to move to the previous
data or j to move to the next data.
To Scroll the Page
When browsing a webpage or displaying a mail list, message, data
list, etc., you can press j to scroll up or l to scroll down.
Using Checkboxes
If a checkbox is displayed next to a setting item, you can select the
item or the checkbox to enable or disable the item.
When performing operations on data such as “Move selected”, “Save
selected”, or “Delete selected”, you can select checkboxes to select
or deselect items.
Icon example
Description
Setting is enabled or item is selected.
Setting is disabled or item is not selected.
45
Character Input
Learn How to Enter Characters
Key Assignments for Character Entry
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
1
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
Character
type
Kanji
Alphabet (2-byte)
Digits
(2-byte/1-byte)
2
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
3
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
4
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
5
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
6
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
7
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
8
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
9
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
*
46
Character Input
Character
type
Kanji Alphabet (2-byte)
Digits
(2-byte/1-byte)
0
Kana (2-byte/1-byte) Alphabet (1-byte) Dial entry
2-byte
1-byte
* When entering at the start of a line, a capital letter is displayed first.
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
-
Sh ort-press....
toggle large/small
(where characters
allow)
Add ゛(ten-ten) or
゜(maru) (where
characters allow)
Sh ort-press....
toggle large/
small (where
characters allow)
2-byte
1-byte
Sh ort-press
....(decimal
point)
:
Long-press....Paste recently-copied/cut text
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
^
When entering characters, display 1
character before (back function)
When not entering characters, linebreak
Linebreak
#
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
u
From submenu, display function quote, useful
phrases, etc.
Switch 2-byte/1-byte symbol lists
Display facemark edit screen (when category other
than history is displayed in facemark list)
During normal conversion, shorten the selected text
range (when character type is “kanji” and entering
characters)
Cancel selected range
－
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
o
Display list for Pict (Emoji) → D-Emoji → Symbol (Full
size: 2-byte) / (Half size: 1-byte) → Facemark
(D-Emoji displayed only when entering e-mail text)
Switch prediction conversion candidates and normal
conversion candidates (when word prediction is
“ON”, character type is “kanji” and entering
characters)
During normal conversion, expand the selected text
range (when character type is “kanji” and entering
characters)
Select entire selected range (when range is selected)
－
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
j
Switch character types
Kana/alphabet/number conversion (when character
type is “kanji” and entering characters)
Change character type to “kanji” (when character
type is type other than “kanji”, “alphabet (1-byte)”, or
“digits (1-byte))
Switch pages/categories (when emoji, symbols,
facemarks, or conversion candidates are selected)
－
47
Character Input
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
l
Start range select
Switch pages/categories (when emoji, symbols,
facemarks, or conversion candidates are selected)
－
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
m
Finalize characters and return to preceding state
Restore deleted characters (up to 5 times in a row)
Delete learned conversion candidates / search for
conversion candidates in browser / search for and
quote conversion candidates in other application
(when character type is “kanji” or “alphabet (large/
small, 1-byte)” and conversion candidates selected)
－
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
s
Move cursor left
Select conversion candidate
During prediction conversion, shorten the selected
text range
Delete 1 “*” character when entering ** (wild card)
－
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
f
Move cursor right
Select conversion candidate
During prediction conversion, enlarge the selected
text range
Enter 1 “*” character when entering ** (wild card)
when unfinalized characters are entered (when
character type is “kanji” or “alphabet (large/small,
1-byte)” and word prediction is “ON”)
When cursor is at end of text string, enter 1-byte
space
－
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
eMove cursor up
Select conversion candidate －
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
c
Move cursor down
Select conversion candidate
When cursor is at end of text string, linebreak
－
Character
type
Kanji
Kana (2-byte/1-byte)
Alphabet (large/small,
2-byte/1-byte)
Digits
(2-byte/1-byte)
Dial entry
,
Short-press.... Delete 1 character to right of cursor
If no characters are to right of cursor,
delete 1 character to left of cursor
Stop conversion (return to character
entry screen)
S hort-press
....Delete
1 place
Long-press.... Delete all characters to right of cursor
When cursor is at start or end of text
string, delete all characters
L ong- press
....Delete
all
◎When entering characters, check that the following is selected: in
the standby screen, k → [Settings] → [Other settings] → [Text
input] → [Keyboard & input methods] and “SH Input”. The
Android keyboard (AOSP) does not support Japanese entry and
it may not be possible to enter characters.
48
Phone
Making Calls
Entering a Phone Number and Making a
Call
1 When the standby screen is displayed, enter phone
number.
The dial screen is displayed and the number is entered.
•You can press m in the standby screen to display the dial
screen with no number entered.
x: Move cursor position
,: Delete digit to left of cursor
, (Long-press): Delete all digits
o (Addr. book): Display address book (▶P. 55)
m: Redial previous number*
* Available when no number is entered.
2 m Talk.
k (Speaker/OFF): Hands-free call on/off
o (Mute/Unmute): Mute on/off
j (Address): Display address book (▶P. 55)
l (Profile): Display profile (▶P. 54)
w/z/q: Adjust call volume (volume of other party’s voice)
3 ..
You can select “Register to address book” to register a number in
the address book that a call was made to.
•You can also fold the product to end a call.
◎In functions including “Calculator”, “Timer”, “Schedule (Calendar)”,
and “Alarm”, you can also quote numbers entered in the dial
screen. Follow the on-screen display after entering the number.
Usable functions depend on the number that was entered.
◎Even when “In Call” is displayed, the other party may not have
taken the call. Start talking after making sure that the other party
has taken the call.
◎Call charges for calls made with “1401” added are subtracted
from the registered balance on an au prepaid card that you have
bought.
◎Note that even if you cover the mouthpiece, the sound can be
conveyed to the other party.
◎Even if “Airplane mode” is set, you can call to the emergency
number (110, 119, 118) and Customer Service Center (157).
◎You can press the dial keys during a call to send push signals for
the entered number.
◎To return to the call screen after activating an application during
a call, press , to end the application.
Emergency Call Location Notification
The product supports “Emergency call location notification” so that if
you make an emergency call to Police, Fire and Ambulance or
Regional Coast Guard Headquarters, your current location (GPS
information) will be transmitted to the agency receiving the emergency
call.
◎In this section, Police (110), Fire and Ambulance (119) and
Regional Coast Guard Headquarters (118) are collectively
referred to as the emergency call receiving agency.
◎This feature may not yet be available at some emergency call
receiving agencies.
◎If you add “184” before the Japan emergency call number
110/119/118, the emergency call responding agency will not be
notified of your location and phone number.
◎In places where signal reception from GPS satellites or a base
station is relatively poor, such as in an underground mall, inside
a building or behind a tall building, the emergency call receiving
agency may be notified of some other place different from your
actual location.
49
Phone
◎When GPS cannot be used to notify of your location, base station
signal is used instead.
◎When making an emergency call to Police, Fire and Ambulance
or Regional Coast Guard Headquarters, always confirm where
you are, and tell them your exact location on the phone. Note that
depending on the area where you are calling, your call may not
be connected to the agency having jurisdiction over that area.
◎If the emergency call receiving agency determines that human
lives and health are in danger, they will be able to acquire the
caller’s location information during the call or within a certain
period of time after the call.
Using P (Pause) Dialing and Making a Call
Enter the push signals to send beforehand and then select “Yes”
during the call to send the push signals. This is a convenient feature
when using information services and automatic reservation services.
Example: To dial “03-0001-XXXX (bank phone number)” and send
the branch “22X” and the account “123XX”
1 Enter bank phone number “030001XXXX”.
2 k (Call etc) [Add Prefix] [Add P] Enter the
branch “22X”.
3 k (Call etc) [Add Prefix] [Add P] Enter the
account “123XX”.
You can enter P (pause) between numbers to enter several push
signals at the same time.
4 m [Yes] [Yes].
After dialing, a confirmation screen is displayed. Confirm that the
destination has answered the call and then select “Yes”. A push
signal is sent each time you select “Yes” and press k.
Using Call Histories and Making a Call
1 When the standby screen is displayed, press f
(Outgoing)/ s (Incoming).
Press x to toggle the outgoing and incoming call histories.
2 Select contact to call from history k.
The outgoing/incoming call history details screen is displayed.
•When a history with a group icon displayed is select and o
(Switch) is pressed, collected outgoing/incoming call history
information is displayed.
3 m.
You can also dial by selecting the contact in the outgoing/
incoming call history list and pressing m.
◎Up to 100 calls can be saved in the outgoing/incoming call
histories. Once more than 100 calls are made/received, calls are
deleted starting with the oldest. The number of calls that can be
saved may be fewer depending on available memory.
50
Phone
Viewing the Outgoing/Incoming Call History Lists
③
④
⑤
① ②
《Outgoing Call History List》
《Incoming Call History List》
③
⑦
⑤
⑥
①
④
②
Call date and time
Name, number, reason for withheld number, network
service information
Portrait photo registered in address book
Number of calls
The number of calls are displayed for a same contact in the
incoming/outgoing call histories.
Call time
Ring time
Incoming call status icon
: Missed call
: Missed call (one-ring phone scam*)
: Call rejected
* Missed calls of less than 3 seconds are deemed to be one-ring
phone scam calls. These may be calls to get the customer to
call back and connect them to a malicious pay-for program.
Use caution. 51
Phone
Using Speed Dial and Making a Call
You can make calls quickly to contacts registered to speed dial.
Registering to Speed Dial
1 When the standby screen is displayed, press k
[Call/mail] [Speed dial].
2 Select <Not registered> for the number to register
k (Register).
•If a number is selected with a destination already registered,
operations such as dialing are available.
3 Select the destination to register k (Set).
Dialing with Speed Dial
1 When the standby screen is displayed, enter the
speed dial number (0 to 99).
2 m.
◎Entering an unregistered speed dial number and pressing m
displays the speed dial list. From the list, you can dial or register
a new speed dial.
◎If an e-mail address is registered to a destination registered in
speed dial, you can enter the speed dial number and press j
(Mail) to create e-mail.
Using Kantan Hasshin and Making a Call
You can use Kantan Hasshin (voice recognition) to make a call by
voice command to a speed dial contact without using the dial keys.
•For details on registering contacts to speed dial, refer to “Registering
to Speed Dial” (▶P. 52).
1 Open the product/In the standby screen, - (hold
down).
is displayed in the main display.
•If “Screen lock” is set, unlock the screen, then in the standby
screen, - (hold down).
2 Say the information for the contact into the product.
Say the name of the contact and then say “Dennwa” or “Hasshin”.
Example: “Bob, dennwa”, “Taro, hasshin”
3 Confirm the contact as displayed [Yes].
◎This feature may not work correctly if several phone numbers are
given for a contact in the address book or several contacts by
the same name are registered.
Calling Overseas from au Phones (au
International Call Service)
You can make international calls without any special procedure from
the product.
Example: To call “212-123-XXXX” in the USA from the product
1 Enter the international access code “010”.
Entering 0 (hold down) in the dial screen enters a “+” and
adds “010” when the number is dialed.
2 Enter the country code of the USA “1”.
52
Phone
3 Enter the area code “212”.
If the area code starts with “0”, dial it without including the “0”
(There are some exceptions such as fixed-line phones in some
countries or regions including Italy and Moscow).
4 Enter the phone number of the other party
“123XXXX” m.
◎You can also press u (Submenu) → [Add Prefix] → [International
call] to enter the country code when entering a phone number.
◎The monthly limit fee is set for the au International Call Service.
The au International Call Service is unavailable from when the
limit fee is confirmed to be exceeded until the end of the same
month.
◎Even if you cannot use the service by exceeding the limit fee,
you can use from the first day of the next month. Also, you can
use the domestic call as usual while the service is stopped.
◎International call charges are billed together with monthly local
call charges.
◎If you do not wish to use the service, you can set not to use the
au International Call Service.
For au International Call Service:
From au phones 157 (area code not required) (toll free)
From fixed-line phones 0077-7-111 (toll free)
Open 9:00 to 20:00 (everyday)
Receiving Calls
Answering an Incoming Call
1 When a call is arriving, m/k.
Press o (Silent) to stop the ringtone.
2 Talk ..
◎If you are not subscribed to LTE NET or LTE NET for DATA,
disable “Data transmission” for “Mobile networks” and set
“Network Mode” to “CDMA Home” before using the product.
◎If a call arrives while using the address book, e-mail, etc., the call
is given priority and the function can be used again once the call
ends.
Putting a Call on Hold
1 While a call is arriving, ..
The call is put on hold, and audio guidance plays for the caller.
2 k (Answer).
The call is taken off hold.
◎You can also press u (Submenu) → [Hold answering] to put a
call on hold.
◎The call charges are charged on the other party who has made a
call to you while the call is put on hold as well.
◎Pressing . while a call is on hold ends the call put on hold.
◎If you disable the hold state once, you cannot put the call on hold
again.
◎You can put the call on hold only when the product is used in
Japan.
53
Phone
Rejecting an Incoming Calls
1 While a call is arriving, l (Reject).
The ringtone stops and the incoming call is disconnected. The
other party will hear voice guidance.
◎You can also press u (Submenu) → [Reject] to reject a call.
Sending SMS to an Incoming Call
1 While a call is arriving, u (Submenu) [Quick
reply].
2 Select a message to send k.
The incoming call is disconnected. The other party will hear voice
guidance.
◎You can select “Write your own...” with the message to create
and send an SMS.
◎You can edit the message to send beforehand with “Quick
responses” in “Call settings”.
◎If the other party’s phone number is not notified, Quick reply is
not available. Also, Quick reply may not be available depending
on the communication condition.
◎A ring call is audible to the caller until the SMS is sent.
Answering memo may answer the call before the SMS is sent.
Checking Your Phone Number
Checking Your Profile
1 When the standby screen is displayed, press k
[Profile].
Editing Your Profile
1 When the standby screen is displayed, press k
[Profile] o (Edit).
The profile edit screen is displayed.
2 Enter required items.
3 o (Save).
◎Items to note when editing your profile are the same as for editing
the address book. For details, refer to “Registering to the
Address Book” (▶P. 55).
54
Address Book
Registering to the Address Book
You can register contact information including phone number and
e-mail address. You can also set ringtone, vibration, etc. individually
for contacts.
1 When the standby screen is displayed, press u (hold
down).
The address book registration screen is displayed.
2 Set required items.
3 o (Save).
◎You can also press o (Add contact) in the contacts list (▶P. 55)
to add a new entry.
◎If the number is a landline number, enter the area code first.
◎If the name includes 1-byte letters and numbers, it may be
displayed in the order of given name, family name.
◎To register GPS information, “Location” must be set to “ON”
beforehand.
◎If a caller’s number is withheld, “Ring Set” does not operate.
◎Numbers and names registered in the address book can become
erased due to accident or malfunction. Keeping a separate copy
of numbers and other important information is recommended.
The Company is not liable for any damages or lost profits
whatsoever due to alteration or loss of contact information
resulting from accident or malfunction.
Using the Contacts List
Displaying the Contacts List
1 When the standby screen is displayed, press u.
When the contacts list is in “Group” view, a list of groups is
displayed. Selecting a group displays a contacts list for that
group.
Viewing the Contacts List
①
②
③
④
《Contacts list (name order)》
Search by dial key
You can search for contacts by pressing the dial keys in the
contacts list and entering yomigana readings. Pressing the
, key deletes yomigana and ends search.
Contacts
Contacts are displayed for the selected tab.
Tabs
55
Address Book
Face image
A face image is displayed if registered.
◎Press x to switch tabs.
Using Information Registered for
Contacts
1 When the standby screen is displayed, press u
Select the contact k.
Viewing Address Book Details
①
②
③
④
《Address Book Details》
Name
Registered information
Face image
Main phone number/main e-mail address
◎You can create e-mail, etc. by selecting registered information
and pressing k.
◎When several phone numbers or e-mail addresses are set, you
can select a phone number/e-mail address and press k → [Set
main phone number]/[Set main mail address] to set as the main
phone number/e-mail address.
◎You can press o (Edit) to edit registered information.
56
Mail
Sending E-mail
Sending an E-mail
1 When the standby screen is displayed, press j (hold
down) [E-mail].
The e-mail create screen is displayed.
•If a screen for initial settings is displayed, follow the on-screen
instructions to complete initial settings.
2 Select the destination entry field k [Edit].
3Address Book Enter an e-mail address from the address
book as the recipient.
Send/Receive
history
Select an e-mail address from the sent or
received history as the recipient.
•Select u (Submenu) → [Delete selected]
→ Select e-mail address → k →
o (Delete) → [Yes] to delete history.
Mail Group Enter all e-mail addresses registered for a
group in the address book as the recipients.
•If the number of e-mail addresses exceeds
the limit, addresses are entered up to the
limit.
Profile Enter your own e-mail address as the
recipient.
Direct entry Enter a recipient directly.
4 Select the subject field k (Edit) Enter the
subject k (Done).
5 Select the mail text field k (Edit) Enter the text
k (Done).
6 o (Send).
◎You can save e-mail to the unsent box without sending it by
pressing u (Submenu) → [Save] before step 6.
◎ デコレーションアニメ (decoration anime) is not supported.
◎Up to 1000 e-mails as the total for all recipients can be sent in
one day.
◎One e-mail can be sent to up to 30 recipients (including To, Cc,
Bcc, up to 64 1-byte characters per recipient) at a time.
◎Emoji sent to an other-brand cell phone, PC, etc. may sometimes
be converted to the other-brand emoji or may not be displayed
properly. Emoji sent to another au phone may sometimes be
converted to an older-version au emoji.
◎Using “Sending reservation” enables e-mail to be sent at on
specified date at a specified time or when returning from an
out-of-range area where an au phone signal was not possible.
Adding Recipients
1 In the e-mail create screen, select the destination
entry field k (Edit).
2 Select <Enter destination> k (Edit).
A submenu for selecting the recipient entry method is displayed.
Refer to step 3 of “Sending an E-mail” (▶P. 57).
3 o [Completed].
Deleting Recipients/Changing Recipient
Categories
1 In the e-mail create screen, select the recipient entry
field k (Edit).
2 Select the recipient to delete/change u
(Submenu).
57
Mail
3Change to To Change category of selected recipient to
“To”.
Change to Cc Change category of selected recipient to
“Cc”.
Change to Bcc Change category of selected recipient to
“Bcc”.
Delete Delete selected recipient.
Receiving E-mail
Receiving an E-mail
1 Receive an e-mail in the standby screen.
Once an e-mail is received, you are notified of the new mail in the
following ways.
•A notification for new e-mail is displayed in the status bar, and a
ringtone sounds.
If “Reception notification display” in “Mail settings” is set to
“Sender”, the name of the sender appears in the status bar. If
the e-mail address is registered in the address book, the name
registered there is given priority.
•A new e-mail icon is displayed in the standby screen, and
in the status bar.
•The charging/incoming indicator flashes blue.
•If the product is folded, is displayed in the sub-display.
2 When the standby screen is displayed, press j
[Inbox] Select folder k.
The mail (e-mail/SMS) list is displayed.
3 Select the received e-mail k.
The received mail (e-mail) message is displayed.
◎E-mail is received in the background even while using e-mail or
other functions. is displayed in the status bar and a ringtone
sounds.
◎Packet fees may be incurred even if mail is not properly received
due to reception conditions or the data being received.
◎The maximum amount of data for the text body that can be
received per e-mail is about 10KB.
◎Received e-mail may not be correctly displayed depending on
the content of the mail.
Inquiring for and Receiving New Mail
You can inquire for and receive new mail if “Auto-receive mail” is
disabled or there was an e-mail receive failure.
1 When the standby screen is displayed, press j.
The mail menu is displayed.
2 o (Receive).
Confirm whether there is new e-mail.
•You can also inquire for new mail by pressing o (Receive) in
the folder list.
58
Mail
Sending SMS
Send messages (mail text body) with kanji, hiragana, katakana,
alphabet and numbers, emoji, symbols, and facemarks.
Before sending SMS overseas, enter “010” and the “country code” at
the start of the phone number for the recipient.
“010” + “country code” + “phone number for recipient”
* If quoting the cell phone number for the recipient from the address book,
etc., select the contact again and enter “010” and the “country code”.
* If the cell phone number for the recipient starts with a “0”, enter the number
without the “0”.
1 When the standby screen is displayed, press j (hold
down) [SMS].
The SMS create screen is displayed.
2 Select the destination entry field k (Edit).
3Address Book Enter a phone number from the address
book as the recipient.
Send/Receive
history
Select from the received mail history to
enter a phone number as the recipient.
Profile Enter your own phone number as the
recipient.
Direct entry Enter a recipient directly.
4 Select the mail text field k (Edit) Enter the text
k (Done).
5 o (Send).
◎You can save SMS to the unsent box without sending it by
pressing u (Submenu) → [Save] before step 5.
◎SMS is held (accumulated) at the SMS center for 72 hours. SMS
that has accumulated for more than 72 hours is erased. There is
no limit on the number of SMS that can be held.
◎It may not be possible for the SMS center to hold SMS depending
on conditions of the receiving customer’s phone/service use or
the sending customer’s phone model.
◎Accumulated SMS is delivered at the following times:
•Delivery soon after SMS accumulation: as new SMS is
accumulated at the SMS center, all SMS that had been held is
delivered.
•Delivery with the retry function: if SMS cannot be delivered as
soon as it has accumulated due to the recipient being where
there is an inadequate signal or their phone is switched off, the
retry function repeatedly sends SMS to the recipient for up to
72 hours.
•Delivery after ending a call: if SMS cannot be delivered as soon
as it has accumulated, all SMS that had been held at the SMS
center is delivered as soon as the customer ends their call.
* The time that SMS is delivered may differ with international SMS.
◎When sending SMS, The number of the sender is displayed for
the recipient regardless of the “Send caller ID” setting
◎Emoji sent to an other-brand cell phone may sometimes be
converted to the other-brand emoji or may not be displayed
properly. Emoji sent to another au cell phone may sometimes be
converted to an older-version au emoji.
◎A may be displayed, although rarely, for a sent message that
was sent successfully but where signal was weak, etc.
◎For details on international SMS, refer to the au homepage.
（http://www.au.kddi.com/mobile/service/global/sms/）
59
Mail
Receiving SMS
Checking SMS
1 Receive an SMS.
Once an SMS is received, you are notified of the new mail in the
following ways.
•A new SMS icon is displayed in the standby screen, in the
status bar, and a mail ringtone sounds.
•If the product is folded, is displayed in the sub-display.
•The charging/incoming indicator flashes blue.
2 When the standby screen is displayed, press j
[Inbox] Select folder k.
The mail (e-mail/SMS) list is displayed.
3 Select the SMS to check k.
The received mail (SMS) message is displayed.
◎Receiving SMS is free.
◎You can confirm the phone number of the sender with received
SMS.
◎Received SMS may not be correctly displayed depending on the
content of the mail.
Checking the Inbox/Outbox
Received mail (e-mail/SMS) is saved in the inbox. Sent mail (e-mail/
SMS) is saved in the outbox. Mail that is saved without being sent
(e-mail/SMS) is saved in the unsent box.
1 When the standby screen is displayed, press j.
The mail menu is displayed.
•If there is unread mail (including mail where the mail text has not
been received), the total number is displayed at the top right of
the inbox icon.
•If there is unsent mail (including send failure mail, excluding
drafts), the total number is displayed at the top right of the
unsent box icon.
60
Mail
2 [Inbox]/[Outbox].
The folder list is displayed.
3 [All Mails]/[E-mail]/[SMS].
The mail (e-mail/SMS) list is displayed.
•If there is unread mail (including mail where the mail text has not
been received), the total number is displayed at the top right of
each folder icon.
•If “Spam mail” is selected in the inbox, you can check mail that
was sorted as spam.
4 Select the mail (e-mail/SMS) k.
The mail (e-mail/SMS) message is displayed.
Viewing the Mail (E-mail/SMS) List
①
②
③
④
《Received Mail (E-mail/SMS) List》《Sent Mail (E-mail/SMS) List》
①
②
③
④
《Unsent Mail (E-mail/SMS) List》
①
②
③
⑤
61
Mail
: Unread/unsent e-mail
: Read e-mail
/ : Unread e-mail with unreceived mail text / Read e-mail
with unreceived mail text
: Unread/unsent SMS
: Read SMS
/ : Sent e-mail/SMS
/ : E-mail/SMS saved as draft
: E-mail text unreceivable due to no mail on server / Send
failure mail (e-mail/SMS) / Forwarding failure e-mail due to
no original mail (received mail) on server
: E-mail set as sending reservation
/ : SMS delivery report (unread) / (read)
: Replied-to mail (e-mail/SMS)
: Forwarded original mail (e-mail/SMS)
: Protected mail (e-mail/SMS)
: Electronic file attached
Subject
Name, phone number, or e-mail address of recipient/sender
If the e-mail address or phone number is registered in the address
book, the name registered in the address book is displayed.
If display of a sender designation is set in the received e-mail, the
set name is displayed.
If the sender of an e-mail is not registered in the address book, and
display of a sender designation is not set, the e-mail address is
displayed.
•If the e-mail address is registered in the address book, the name
registered in the address book is displayed with priority.
If the sender of an SMS is not registered in the address book, the
phone number is displayed.
Mail text preview
You can view the mail text of the selected mail.
Number of sending reservations (excluding drafts)
Viewing a Mail (E-mail/SMS) Message
④
②
③
⑤
《Received Mail (E-mail/SMS)
Message》
①
《Sent Mail (E-mail/SMS)
Message》
④
②
③
⑤
①
《Unsent Mail (E-mail/SMS)
Message》
②
③
⑤
④
①
62
Mail
: Read e-mail
: Read e-mail with unreceived mail text
: Read SMS
/ : Sent e-mail/SMS
: E-mail text unreceivable due to no mail on server / Send
failure mail (e-mail/SMS) / Forwarding failure e-mail due to
no original mail (received mail) on server
: Replied-to mail (e-mail/SMS)
: Forwarded original mail (e-mail/SMS)
: Protected mail (e-mail/SMS)
: Electronic file attached
: Senders name or e-mail address, phone number
: Recipients name or e-mail address, phone number
•If there are several recipients, select “ ” and press k to
display the list of recipients.
Subject (e-mail only)
Received/sent date and time
•You can select “ ” and press k when a date or other
event-related text is included in the mail text to display a calendar
and enter an event (Enabled when the text is Japanese).
•If “Delivery report” is “ON” for sent SMS, a “ ” is displayed
when the recipient checks the SMS. You can select “ ” and
press k to check the delivery report.
Mail text
◎You can select mail (e-mail/SMS) saved as a draft in the unsent
mail (e-mail/SMS) list to display the mail (e-mail/SMS) create
screen and edit the mail.
Operations in the Mail Menu
1 When the standby screen is displayed, press j.
2Inbox Display the received mail (e-mail/SMS) list.
(▶P. 61)
Outbox Display the sent mail (e-mail/SMS) list.
(▶P. 61)
Unsent box Display the unsent mail (e-mail/SMS) list.
(▶P. 61)
Create mail Create a new e-mail. (▶P. 57)
Template Insert a message in a template and easily
create and send a decorated mail.
Create SMS Create a new SMS. (▶P. 59)
Settings Make mail settings (e-mail/SMS).
63
LINE
Using LINE
This communication app allows you to enjoy calling and texting as
much as you want, any time and any place.
•Registration of an account is required for using LINE. For details on
using LINE, from the LINE screen → [More] → [Settings] → [Help]
and refer to the help.
1 When the standby screen is displayed, press k
[LINE].
The LINE top page is displayed.
When activating the first time, terms of use and a login screen are
displayed. Confirm the content and follow the on-screen
instructions.
After activating LINE, Touch Cruiser EX is enabled. For details on
operating Touch Cruiser EX, refer to “Using Touch Cruiser EX”
(▶P. 35).
◎Games and some other functions cannot be used on the product.
64
Internet
Accessing the Internet
You can access the Internet by packet communication or the wireless
LAN (Wi-Fi®) function.
◎Packet communication is available only with subscription to LTE
NET or LTE NET for DATA.
Using Packet Communication
This product provides easy access to the Internet for packet
communication with use of “LTE NET” or “LTE NET for DATA”. Settings
for connecting to the Internet with LTE NET are pre-installed on the
product, and activating an application that requires an Internet
connection automatically connects the product to the Internet.
To access the Internet with LTE NET for DATA, in the standby screen,
k → [Settings] → [Communication/network] → [Network settings] →
[Mobile networks] → [Au network settings] → [Advanced settings] →
[Connection mode settings] → [LTE NET for DATA].
◎Subscription to LTEフラット (LTE flat) or other packet
communication flat-rate/discount service allows you to use an
Internet connection with flat-rate charges.
For details on LTE NET, LTE NET for DATA, and packet
communication flat-rate/discount services, refer to the latest au総
合カタログ (au general catalog)/the au homepage.
Precautions when Using Packet Communication
•Using large-volume data communication, such as browsing websites
containing images, downloading video and other data, and using
applications that use data communication, results in high packet
communication charges. Therefore, subscription to a flat-rate/
discount service for packet communication charges is
recommended.
•To prevent excessive burdens on the network, communication speed
is sometimes reduced due to continued large-volume data transfers,
busy network conditions, etc.
How to Confirm Your Packet Communication
Charges
You can confirm your packet communication charges at the following
URL.
https://cs.kddi.com/ (auお客さまサポート(au Customer Support))
•Subscription required for first-time use.
65
Internet
Using the Browser
You can use the browser to view webpages the same as with a PC.
•After a webpage is displayed in the browser, Touch Cruiser EX is
enabled. For details on operating Touch Cruiser EX, refer to “Using
Touch Cruiser EX” (▶P. 35).
•When a webpage is displayed for the first time, a permission screen
is displayed. Confirm the content and follow the on-screen
instructions.
Using the Browser Menu
1 When the standby screen is displayed, press l.
The browser menu is displayed.
2Homepage Connect to the Internet and view webpages.
Bookmark Use and manage registered bookmarks.
auお客さまサ
ポート(au
Customer
Support)
Display the au Customer Support webpage.
URL input/
Web search
Enter a URL directly to display a site. You can
also enter keywords to search for information
on webpages.
History Display the browsing history.
Downloads Display the download history.
Settings Change browser settings.
Operating the Browser with Touch Cruiser
EX
You can use Touch Cruiser EX’s features to smoothly browse
webpages. For details on Touch Cruiser EX, refer to “Using Touch
Cruiser EX” (▶P. 35).
•After activating the browser, Touch Cruiser EX is enabled.
1 Use Touch Cruiser EX to operate the browser.
Tap: select or finalize items.
Flick: Long-touch the screen to display “ ” and then scroll up or
down.
Double-tap: Zoom out or in on images.
◎If the d key does not respond while using the browser, enabling
Touch Cruiser EX sometimes enables the cursor to be operable.
66
Camera
Before Using the Camera
•Fingerprints and smudges on the lens prevents capture of clear still
pictures/video. Before capturing images, wipe the lens clean with a
soft cloth. Rubbing forcefully may scratch the lens.
•Avoid fingers, hair, strap, etc. from covering the lens or mobile light
during image capture. Hold the strap if it interferes with capture.
•If capturing images with the mobile light on, its light reflecting from
fingers, a cover, etc. around the lens can cause capture still pictures/
video to turn out whitish.
•When capturing video, avoid covering the microphone with fingers.
Loudness of voices and surroundings during video capture may
affect the sound quality of the microphone.
•When using the self-timer for image capture and the product is
placed on an unstable surface, the product vibrating such as when
a call arrives or other conditions may cause the product to fall.
•Even in manner mode, the focus lock beep and shutter click for still
pictures and start and stop beeps for video sound. The volume
cannot be adjusted.
•Exposure of the lens for extended periods to direct sunlight or other
sources of strong light may discolor the internal color filter and
cause discoloration in still pictures/video.
•Capturing or saving still pictures/video after the product has been
left in a warm place for an extended period may affect the still
pictures/video.
•The camera comprises high-precision components, and includes
pixels that are always on or that do not light. Image capture in
extremely dark conditions will result in blue, red, and white dots, etc.
•Release the shutter after confirming that the subject is properly
displayed in the main display. Moving the camera while releasing the
shutter may cause still pictures to be blurry.
•When capturing images indoors under fluorescent lighting, faint
stripes may be visible on the screen from fluorescent light flickering
(very faint, invisible to the human eye), but is not a malfunction.
•The color of still pictures/video captured with the product camera
may differ from the actual subject. Images may appear partially
darker or brighter due to the characteristics of the lens and
depending on the subject and illumination when capturing. Subjects
may also appear partially distorted.
•Subjecting the product to shock while capturing images may cause
the camera to lose focus. If focus is lost, activate the camera again.
•Focusing may not be possible for the following types of subjects.
･Low-contrast subjects such as plain walls
･Subjects with strong backlighting
･Shiny subjects that reflect light brightly
･Subjects with a pattern that repeats horizontally such as blinds
･Several subjects with differing distances from the camera
･Subjects in dark conditions
･Fast-moving subjects
•Do not shine the mobile light near eyes. Do not look directly into
shining mobile light. Do not shine mobile light at other persons’ eyes.
Doing so may affect vision or cause other impairment.
•Faint sound may audible when using the camera such as when
activating the camera. This is from the internal components and is
normal.
•Directly capturing the sun, a lamp, or other strong source of light
may cause still pictures/video to be dark or noise may appear.
•The screen may appear momentarily white or dark when capturing a
moving subject or when moving from light to dark conditions. Noise
may also momentarily appear.
•Noise may increase and result in grainy still pictures when capturing
in dark conditions.
•Immediately after switching camera modes or changing camera
settings, it may take time for brightness, color, etc. to be displayed
optimally.
•Creating a public nuisance with use of the product camera may be
punishable by law.
•If the battery level is less than (about 10%), the camera cannot
be activated.
67
Camera
•It may not be possible to use the camera in the following instances.
･When the temperature of the product is high after using for an
extended period
･When using the product in extremely low temperatures such as
outdoors in the winter
･When other applications are activated
Capturing Still Pictures/Video
You can capture still pictures and video. You can also switch camera
settings to match the subject you want to capture.
After activating the camera, Touch Cruiser EX is enabled. For details
on operating Touch Cruiser EX, refer to “Using Touch Cruiser EX”
(▶P. 35).
Capturing Still Pictures
1 When the standby screen is displayed, press o.
The still picture viewfinder is displayed.
x: Zoom in/zoom out
w: Adjust brightness
u (Settings): Display camera settings menu
o (Preview): Display captured still pictures
j (Focus): Lock focus
l (VideoCam): Switch to video capture
-: Toggle screen icon show/hide
2 k (Shutter)/v
The still picture is captured and saved.
Viewing the Still Picture Viewfinder
②
③
①
⑥
⑤
⑦
⑧
⑨
⑩
⑪
⑫
⑬
《Still Picture Viewfinder》
④
Voice recognition
Focus mark
If “Face AF” is set, faces are detected for focusing. You can
specify where to focus by tapping the subject’s position with
the pointer.
Zoom
Flashlight
Capture mode
Auto-add location information
Resolution
NightCatch
68
Camera
HDR
HQ mode
Adjust brightness
Shots remaining
Displayed when 99 or fewer shots remain.
Minipreview
Display thumbnail of preceding captured data.
◎Select an icon or minipreview with the Touch Cruiser EX pointer
to activate the function corresponding to the icon or play a
captured still picture.
Capturing Video
1 When the standby screen is displayed, press o (hold
down).
The video viewfinder is displayed.
w: Adjust brightness
x: Zoom in/zoom out
u (Settings): Display camera settings menu
o (Preview): Play back captured video
l (StillCam): Switch to still picture capture
-: Toggle screen icon show/hide
2 k (Start)/v.
Video capture begins.
•You can press o (capture) during recording to capture a still
picture.
3 k (Stop)/v.
Capture ends and the video is saved.
Viewing the Video Viewfinder
①
②
③
⑬
《Video Viewfinder》
④⑤⑥⑦⑧⑨ ⑩ ⑫⑪
Mobile light
Focus mark
Zoom
Capture mode
Auto-add location information
Video Size
NightCatch
HDR
Recording time remaining
Battery level
Minipreview
Display thumbnail of preceding captured data.
Adjust brightness
Capture time
◎Select an icon or minipreview with the Touch Cruiser EX pointer
to activate the function corresponding to the icon or play a
captured video.
69
1Seg
1Seg
1Seg is a digital terrestrial TV broadcast service for mobile devices,
and allows reception of image and audio as well as data broadcast.
For details on the “1Seg” service, refer to the below website.
The Association for Promotion of Digital Broadcasting
http://www.dpa.or.jp/
Precautions when Using 1Seg
•No communication charges or packet communication charges are
incurred for using 1Seg. However, packet communication charges
are incurred for use of additional services associated with data
broadcast that use data transmission. Regarding NHK reception
fees, inquire with NHK.
•While displaying the 1Seg screen, the product may become warm
and cause low-temperature burns, etc. if used in contact with the
skin for an extended period.
•Listening at a volume that is loud to the ears continuously for an
extended period may affect hearing.
•1Seg is for digital terrestrial TV broadcast 1Seg in Japan only.
•Overseas, 1Seg cannot be used due to differing broadcast formats
and frequencies. Also, BS and 110-degree CS digital broadcasts
cannot be viewed.
•Do not use 1Seg while operating a vehicle or riding a bicycle,
motorcycle, etc. or while walking. Doing so may prevent surrounding
sound from being heard and may distract you, causing a traffic
accident.
Signal
Signal may be weak in the following places and may affect picture/
sound quality or prevent reception.
•Areas that are distant from or extremely close to the broadcast
station
•In a moving train/car, underground shopping district, tunnel, indoors,
etc.
•In a valley or shade of a building
•Near high-power lines, neon lighting, a radio station, railway track,
highway, etc.
•Other places where interfering signals are strong or signals are
blocked
To improve signal reception, try the following.
•When viewing indoors, view near a window for better reception.
TV Antenna
The product has a built-in antenna.
Operation Based on Battery Level
TV cannot be activated if the battery level is less than (about
10%).
70
1Seg
Making Initial TV Settings
Set a channel list for viewing the first time activating TV. Once settings
are complete, you can view TV programs.
1 When the standby screen is displayed, press k
[Tools] [TV (One Seg)].
If a license screen is displayed, confirm the content and select
“Agree”.
2 [Create by selecting the area].
If the area cannot be determined, select “Create by searching
channels” and follow the on-screen instructions.
3 Select the region k.
4 Select the prefecture k.
5 Select the area k.
Scanning for broadcast stations starts.
6 Confirm the channel list o (Set).
Viewing TV Programs
Viewing a TV Program
1 When the standby screen is displayed, press k
[Tools] [TV (One Seg)].
o (Data mode/TV mode): Switch data operation mode/TV viewing
mode
l (Rotate): Switch screen display between vertical and horizontal
Key Operation in TV Viewing Mode
You can switch channels and adjust volume.
w*1*2/z*2/q*2 : Adjust volume (volume at 15 levels or mute)
x*1: Switch channels, hold down to search channels
0 to 9 , - , ^: Switch channels
.: End
*1 Operation depends on the screen view.
*2 While connected by Bluetooth®, volume adjustment from a Bluetooth®
remote control is possible.
However, may not be possible depending on the Bluetooth® device.
Key Operation in Data Operation Mode
You can use information (data broadcast) in the information display
area.
w: Move cursor, scroll
0 to 9 , - , ^: Select item as assigned by contents
k: Select item
,: Go back one page in data broadcast
71
1Seg
◎When activating TV or changing channels, it may take time to
obtain data for data broadcast and TV image due to digital
broadcasting characteristics.
◎Image and sound may be disrupted or stop due to signal
conditions.
◎The camera is unavailable while TV is activated.
◎No communication charges or packet communication charges
are incurred for viewing data broadcast. However, packet
communication charges are incurred for accessing related sites
in information obtained from data broadcast or obtaining
additional information.
Viewing the TV Screen
《TV Screen》
①
②
③
④
⑤
Program information
Displays the program title and station name.
Subtitles
If subtitles are enabled, subtitles are displayed in the subtitle
area.
Information display area
Volume
72
Settings
Displaying the Settings Menu
Set and manage functions from the settings menu.
1 When the standby screen is displayed, press k
[Settings]
Item Description
Wallpaper/display Set wallpaper and screen brightness,
change text fonts, etc.
Sound/lamp Change manner mode settings, volume and
sound of ringtone, etc.
au ID setting Set an au ID.
Lock/security Set product lock and security feature and
secret mode.
Energy saving/
battery
Set energy saving mode and check battery
usage.
Wi-Fi Set Wi-Fi®.
Bluetooth Set Bluetooth®.
Communication/
network
Make network settings for airplane mode,
tethering, VPN, etc.
Data transfer/reset Transfer data or initialize the product.
Other settings Set the date and time, select language,
screensaver, etc.
73
Appendix
Introduction of Peripheral Devices
Battery Pack (SHF31UAA) (sold separately)
au Carrying Case F Black (0105FCA) (sold separately)
au Carrying Case G Black (0106FCA) (sold separately)
au Carrying Case H Black (0107FCA) (sold separately)
au Carrying Case F Black
Common AC Adapter 03 (0301PQA) (sold separately)
Common AC Adapter 05 (0501PWA) (sold separately)
Common AC Adapter 03 Navy (0301PBA) (sold separately)
Common AC Adapter 03 Green (0301PGA) (sold
separately)
Common AC Adapter 03 Pink (0301PPA) (sold separately)
Common AC Adapter 03 Blue (0301PLA) (sold separately)
AC Adapter JUPITRIS (White) (L02P001W) (sold
separately)
AC Adapter JUPITRIS (Red) (L02P001R) (sold separately)
AC Adapter JUPITRIS (Blue) (L02P001L) (sold separately)
AC Adapter JUPITRIS (Pink) (L02P001P) (sold separately)
AC Adapter JUPITRIS (Champagne) (L02P001N) (sold
separately)
Common AC adapter 05
•Illustrations and forms may not match depending on the AC
adapter you use.
Common DC adapter 03 (0301PEA) (sold separately)
Portable charger 02 (0301PFA) (sold separately)
Desktop holder (SHF31PUA) (sold separately)
microUSB cable 01 (0301HVA) (sold separately)
Sharp microUSB 3.5mm conversion cable 01 (SHX11QVA)
(sold separately)
◎For the latest information about available peripheral devices,
check the au homepage (http://www.au.kddi.com/english/) or
contact Customer Service Center.
◎The product does not support ASYNC/Fax transmission.
◎The above-mentioned peripheral devices can be purchased from
au Online Shop. You may not be able to purchase one depending
on the stock status.
http://auonlineshop.kddi.com/
74
Appendix
Using an Earphone Microphone with
Switch/Earphone Microphone/
Earphone
You can connect a “Sharp microUSB 3.5mm conversion cable 01 (sold
separately)” to the product and use an earphone.
1 Insert microUSB plug of Sharp microUSB 3.5mm
conversion cable 01 (sold separately) in external
connection jack on product in direction shown,
confirming its orientation.
External
connection jack
Protruding
edges
Sharp microUSB
3.5mm conversion cable 01
(sold separately)
2 Insert earphone microphone with switch, earphone
microphone, or earphone in earphone jack of sharp
microUSB 3.5mm conversion cable 01 (sold
separately).
Answering a Call with an Earphone Microphone
with Switch
1 Press switch on earphone microphone with switch
while call is arriving.
To end the call, press the switch on the earphone microphone
with switch again.
◎You may not be able to use this feature depending on the type of
earphone microphone with switch or earphone microphone.
◎For information on operation-tested 3.5mm-plug earphone
microphone with switch, (commercially available), refer to the
following support page.
http://k-tai.sharp.co.jp/support/a/shf31/
75
Appendix
Troubleshooting
Before you assume that the product is malfunctioning, check the
following:
Trouble Detail
Battery usage
time is short.
•Make sure you do not often use the product in
places where (out of service area) is
displayed. (▶P. 38)
•Is the battery charged enough?
Cannot make
calls.
•Is an au Nano IC Card (LTE) inserted? (▶P. 35)
•Was the number entered correctly? (Was the area
code entered?) (▶P. 49)
•Is “Airplane mode” set? (▶P. 38)
•Is the power turned on?
•Did you press m after entering the number?
(▶P. 49)
Cannot
receive calls.
•Is reception good enough? (▶P. 38)
•Is the product within the service area? (▶P. 38)
•Is “Airplane mode” set? (▶P. 38)
•Is the power turned on?
•Is an au Nano IC Card (LTE) inserted? (▶P. 35)
1Seg is not
displayed,
image stops,
audio stops,
noise
appears.
•Is the digital terrestrial TV broadcast signal
adequate? (▶P. 38)
•Is your hand covering the TV antenna area?
(▶P. 34)
Camera does
not operate.
•Is the battery low? (▶P. 38)
•Check how to use the camera. (▶P. 67)
Cannot
operate the
keys panel.
•Turn off the power and then turn it on.
•Is the power turned on?
Trouble Detail
Cannot
operate/The
screen does
not respond/
Cannot turn
off the power.
•You can force the power off by holding down .
for at least 8 seconds and releasing your finger
after the product vibrates. Turn the product on
again after a while.
The power is
turned off
automatically.
•Make sure the battery has not run out.
The power is
turned off
while the
wake-up logo
is displayed.
•Make sure the battery has not run out.
(out of
service area)
is displayed.
•Is reception good enough? (▶P. 38)
•Is the product within the service area? (▶P. 38)
•Is your hand off the area around the internal
antenna? (▶P. 34)
•Is the au Nano IC Card (LTE) inserted? (▶P. 35)
•Is the “Network Mode” correct?
A message
indicating
that charging
is necessary
is displayed.
•The battery is almost empty. (▶P. 38)
The product
answers calls
when it
shouldn’t.
•Is Answering memo set? (▶P. 38)
•Is manner mode set? (▶P. 38)
•Is auto answer set?
76
Appendix
Trouble Detail
When making
a call, a
beeping
sound is
heard from the
earpiece and
a connection
cannot be
established.
•Is reception good enough? (▶P. 38)
•Is the product within the service area? (▶P. 38)
•The line traffic is busy or the other party is in a
call. Dial again.
If symptoms do not improve after checking each of the above,
information is provided through au Customer Support on the au
homepage below.
http://www.au.kddi.com/english/support/
Updating Software
The product supports the software update.
The software update function can also be used for operating system
updates. An operating system update is a software update which also
includes updating of the product’s operating system.
1 When the standby screen is displayed, press k
[Settings] [Other settings] [Device info]
[Software update].
The first time activating this feature, an important notice
confirmation screen is displayed. Confirm the content and select
“OK” → k.
2Software
update
Check whether a software update is necessary or
not.
Press k (Exec) to start a check. When an update
is necessary, you can download data for a
software update.
•To update immediately, press k (Exec) and
follow the on-screen instructions.
•To update later, select “後で更新” to end the
application. is displayed in the status bar.
To update software, select “Software update” in
the status bar and follow the on-screen
instructions.
•If a software update is possible, “新しいソフト
ウェアのダウンロードが可能です。” is
displayed. If an operating system update is
possible, “OSアップデートが可能です。” is
displayed.
77
Appendix
Auto-check
settings
Set whether to regularly check presence of data
for software update available.
•If set to “Auto-check”, is displayed in the
status bar when a software update is required.
Select “Software update” in the status bar and
follow the on-screen instructions.
Notes on Software Update
•You are charged for data communication when connecting to the
Internet from the product by using packet communication.
Large-volume data communication occurs in particular for operating
system updates. Use of Wi-Fi® is recommended.
•When software update is necessary, you will be informed on au
homepage, etc. For details, contact an au shop or Customer Service
Center (call toll-free 157). In addition, users of the product will
receive a notice from au, when software update is necessary to
improve the functionality of the product.
•It is recommended to back up your data before updating software.
•If the software update is performed, the product will reboot before
and after the update.
•If the software update has failed or stopped, perform the same
procedures again.
•If the software update fails, it may become impossible to operate the
product. If this happens, bring it to an au shop or PiPit (not accepted
by some shops).
•Charge the battery sufficiently before starting update. If the battery
level is insufficient or the battery runs out during the update, the
software update will fail.
•Check out the signal reception status. The software update may fail
if the product is in a place with bad signal reception status.
•Various data registered on the product (address books, mails, still
pictures, music data, etc.) and information of settings will not be
changed even after software is updated. However, note that data
may not be protected depending on the state of the product (fault,
damage, getting wet with water, etc.).
•After software is updated, the download of next update software may
automatically start (consecutive update).
•During international roaming, the software update function can only
be used with a Wi-Fi® connection. As this function cannot be used
without a Wi-Fi® connection, be sure to first connect via Wi-Fi®
before updating software.
•After you have updated the operating system, you cannot return it to
the previous version.
Do not conduct the following operations during the software
update
•Do not move during software update.
The following operations are not available during the software
update
•Operations are not available during software update. Making a call
to 110 (Police), 119 (Fire and Ambulance), 118 (Regional Coast
Guard Headquarters) or 157 (Customer Service Center) is not
available either. Also, the alarm etc. does not function.
78
Appendix
After-Sales Service
When Asking for Repair
For repair, contact Keitai Guarantee Service Center.
During the
warranty
period
Repairs will be done based on the <<terms of
services of the free-of-charge repair warranty>>
described on the warranty card.
Outside the
warranty
period
We shall repair the product for a charge as requested
by the customer if repair renders it usable.
◎Before handing in the product for repair, make a backup of the
contents of memory since they may disappear during repair.
Note that the Company shall not be liable for any damages and
loss of income should the contents of memory be altered or lost.
◎Recycled parts that meet the Company’s quality standards are
sometimes used for repair.
◎au cell phones collected by Replacement cell phone delivery
service which you used before are recycled to cell phones for
replacement after repairs. Also parts replaced by au after-sales
service are collected and recycled by the Company. They are not
returned to customers.
Performance Parts for Repair
The Company retains performance parts for repair of the SHF31 main
unit and its peripheral devices for 4 years after discontinuation of
production.
“Performance parts for repair” refers to parts required for maintaining
the functions of the product.
Warranty Card
At the store of purchase, thoroughly check and read the name of the
retailer, date of purchase and other necessary details filled in on the
warranty card, and be sure to keep it in a safe place.
Keitai Guarantee Service Plus LTE
An after-sales service membership program on a monthly basis called
“Keitai Guarantee Service Plus LTE” (monthly fee: 380 yen, tax
excluded) is available for using your au cell phone for a long time
without worries.
This service expands coverage for many troubles including
malfunction, theft and loss. For details of this service, check on the au
homepage or contact Keitai Guarantee Service Center.
◎You can apply for membership only at the time of purchasing
your au cell phone.
◎Once you cancel the membership, you cannot reapply for it until
you purchase an au cell phone next time.
◎Note that when changing the model or purchasing an extra cell
phone, this service only covers the most recently purchased au
cell phone.
◎When an au cell phone is handed over to you or someone else,
the “Keitai Guarantee Service Plus LTE” membership is also
handed over to the successor of the cell phone.
◎When you get a new au cell phone by changing the model,
purchasing an extra cell phone, etc., the “Keitai Guarantee
Service Plus” or “Keitai Guarantee Service Plus LTE” membership
for the old au cell phone is automatically canceled.
◎Service contents are subject to change without notice.
au Nano IC Card (LTE)
The au Nano IC Card (LTE) is lent to you by au. In case of loss or
damage, the card will be replaced at your expense. When malfunction
is suspected, or in case of theft or loss, contact an au shop or PiPit.
79
Appendix
After-Sales Service
If you are unsure about anything regarding after-sales service, contact
the following service counter.
Customer Service Center (service cancelation procedure in case
of loss or theft)
From a fixed-line phone, 0077-7-113 (toll free)
From an au cell phone, 113 without area code (toll free)
Business hours: 24 hours (7 days a week)
Keitai Guarantee Service Center (for loss, theft or damage)
From a fixed-line phone/an au cell phone,
0120-925-919 (toll free)
Business hours 9:00 to 21:00 (7 days a week)
Servicing requests online (24 hours)
* From the product, PCs and smartphones only
https://cs.kddi.com/support/n_login.html
•Applications for servicing can be made via the Internet for
“damage”, “water seepage”, “theft”, or “loss”. Naturally-occurring
malfunction (power does not turn on, the screen is frozen, etc. due
to causes other than damage or water seepage) require consultation
by telephone.
•Applications via the Internet require that you provide your e-mail
address.
au After-Sales Service Information
Service contents
Keitai Guarantee
Service Plus LTE
member
Non-Keitai
Guarantee Service
Plus LTE member
Replacement cell phone
delivery service
(spontaneous failure: 1st
year)
Free N/A
Replacement cell phone
delivery service
(spontaneous failure: 2nd
year and later)
Customer charge
1st: 5,000 yen
2nd: 8,000 yen
N/A
Replacement cell phone
delivery service
(partial damage, water
soak, irreparable damage,
theft and loss)
Customer charge
1st: 5,000 yen
2nd: 8,000 yen
N/A
Holding over and repair
(spontaneous failure: 1st
year)
Free Free
Holding over and repair
(spontaneous failure: 2nd
year and later)
Free (three-year
warranty) Actual cost
Holding over and repair
(partial damage)
Customer charge
Upper limit: 5,000
yen
Actual cost
Holding over and repair
(water soak and
irreparable damage)
Customer charge
10,000 yen Actual cost
Holding over and repair
(theft and loss) N/A
N/A
(By model
replacement)
* Charge amounts are all tax excluded.
80
Appendix
Replacement cell phone delivery service
◎When you have trouble with your au cell phone, you can have a
cell phone for replacement (same model and color as your old
one, new battery pack included) delivered to any destination that
you specify by calling us. Please return your old faulty au cell
phone within 14 days after the cell phone for replacement is
delivered to you.
◎You can use this service up to twice within one year starting from
the day when you first use this service. If you have not used this
service over the past one year at the time of your application for
this service, the application will be regarded as your first time. If
you have, the application will be regarded as your second time.
* For details, check on the au homepage.
Holding over and repair
◎Damages and malfunctions intentionally caused by the customer
as well as those due to modification (e.g. disassembly, change of
parts, painting, etc.) by the customer are not covered by this
service.
◎You cannot receive a refund for replacement of the outer casing
due to stains, scratches, paint removal, etc. on the outer casing.
Main Specifications
Main display Approx. 3.4 inches, approx. 16.77 million
colors, TFT, 960×540 (QHD)
Sub display Approx. 0.9 inches, 1 color, OEL display
Weight Approx. 128 g (including the battery pack)
Size (W×H×D) Approx. 51 mm×113 mm×16.9 mm
(thickest part approx. 17.4 mm)
Memory (built-in) ROM: Approx. 8 GB
RAM: Approx. 1 GB
Continuous talk
time (in Japan)
Approx. 620 min.
Continuous talk
time (overseas
(GSM))
Approx. 390 min.
Continuous
standby time (in
Japan)
Approx. 470 hours (while 4G (LTE) is used)
Approx. 610 hours (while 3G is used)
Continuous
standby time
(overseas (GSM))
Approx. 610 hours
Continuous
tethering time
Approx. 280 min. (4G (LTE) on WAN)
Approx. 380 min. (3G on WAN)
Maximum Wi-Fi®
tethered
connections
10 devices
Charging time Common AC adapter 05 (sold separately):
Approx. 110 min.
Common DC adapter 03 (sold separately):
Approx. 180 min.
1Seg continuous
watching time*1
Approx. 6 hours and 20 min.
81
Appendix
Camera device CMOS image sensor
Effective pixels Approx. 13.10 million pixels
Bluetooth®
function
Communication method: Bluetooth® Standard
Ver.4.0
Output: Bluetooth® Standard Power Class 1
Communication distance*2: Within 10 m with no
obstacles in the range
Compatible Bluetooth® profiles*3: HSP, HFP,
A2DP, AVRCP, OPP, SPP, PBAP*4, HID, PAN,
PAN NAP, PAN U, SCMS-T, HOGP*5, DUN*6
Frequency bands: 2.4 GHz band
Network
environment
Wireless LAN (Wi-Fi®) function: IEEE802.11b/g/
n (2.4 GHz) conformant
Interface microUSB jack
*1 Possible continuous watching time depends on usage conditions.
*2 It changes according to objects obstructing devices and signal reception.
*3 This is the specification provided in Bluetooth® standards for making
communication between Bluetooth® compatible devices in accordance
with their intended use.
*4 Some contents of address books data may not be properly displayed on
the device of the other party.
*5 This profile supports Bluetooth® Standard Ver.4.0.
*6 Supported for some car navigation systems only. See the au homepage
for usage.
◎The continuous talk time and continuous standby time may drop
to less than half depending on the battery charging status, usage
environment such as temperature, reception condition at the
location where the product is used, and the function settings.
Specific Absorption Rate (SAR) of
Cell Phones
This model 【SHF31】 cell phone complies with Japanese technical
regulations for exposure to radio waves and international guidelines
on radio wave protection.
This cell phone has been designed in observance of the Japanese
technical regulations regarding exposure to radio waves(*1) and limits
to exposure to radio waves recommended by equivalent international
guidelines.
These international guidelines were set out by the International
Commission on Non-Ionizing Radiation Protection (ICNIRP), which is
in collaboration with the World Health Organization (WHO), and the
permissible limits include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health
condition. The Japanese technical regulations and international
guidelines define the limits using a unit of measurement known as the
Specific Absorption Rate (SAR), which represents the average amount
of radio frequency energy absorbed by the human body. The SAR limit
for cell phones is 2.0 W/kg. The highest SAR value for this cell phone
when tested for use at the ear is 0.484 W/kg, and when worn on the
body, is 0.562 W/kg(*2). There may be slight differences in SAR levels
among individual products, but they all satisfy the limit.
The actual SAR of this cell phone while talking on the phone can be
well below that indicated above. This is due to the cell phone being
designed to only output the minimum power required to communicate
with a base station. Therefore in general, the closer you are to a base
station, the lower the power output of the cell phone.
This cell phone can be used in positions other than against your ear.
Use a carrying case or similar accessory that holds the phone at least
1.5 cm separated from the body and ensure no metal parts are
located between you and the cell phone. Under these conditions, this
cell phone satisfies Japanese technical regulations and international
guidelines for radio wave protection.
82
Appendix
The World Health Organization has stated that “a large number of
studies have been performed over the last two decades to assess
whether mobile phones pose a potential health risk. To date, no
adverse health effects have been established as being caused by
mobile phone use”.
If you would like to know more detailed information, please refer to the
WHO website.
(http://www.who.int/docstore/peh-emf/publications/facts_press/
fact_english.htm)
Please refer to the websites listed below if you would like to know
more detailed information regarding SAR.
○ Ministry of Internal Affairs and Communications website:
http://www.tele.soumu.go.jp/e/sys/ele/index.htm
○ Association of Radio Industries and Businesses website:
http://www.arib-emf.org/index02.html
○ SHARP homepage:
http://www.sharp.co.jp/products/menu/phone/cellular/sar/index.
html
○ au homepage:
http://www.au.kddi.com/english/
*1 Technical regulations are defined by the Ministerial Ordinance Related to
the Radio Law (Article 14-2 of Radio Equipment Regulations).
*2 The value is under simultaneous transmission use condition.
CE Declaration of Conformity
In some countries/regions, such as France, there are restrictions
on the use of Wi-Fi®. If you intend to use Wi-Fi® on the handset
abroad, check the local laws and regulations beforehand.
Hereby, Sharp Telecommunications of Europe Ltd, declares that this
SHF31 is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
A copy of the original declaration of conformity can be found at the
following Internet address:
（http://www.sharp.co.jp/k-tai/）
Mobile Light
Do not point the illuminated light directly at someone's eyes.
Be especially careful not to shoot small children from a very close
distance.
Do not use Mobile light near people's faces. Eyesight may be
temporarily affected leading to accidents.
AC Adapter
Any AC adapter used with this handset must be suitably approved
with a 5Vdc SELV output which meets limited power source
requirements as specified in EN/IEC 60950-1 clause 2.5.
83
Appendix
Battery - CAUTION
Use specified Charger only.
Non-specified equipment use may cause malfunctions, electric shock
or fire due to battery leakage, overheating or bursting.
The battery is embedded inside the product. Avoid removing the
embedded battery since this may cause overheating or bursting.
Do not dispose of the product with ordinary refuse. Take the product
to an au Shop, or follow the local disposal regulations.
Charge battery in ambient temperatures between 5°C and 35°C;
outside this range, battery may leak/overheat and performance may
deteriorate.
Volume Level Caution
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
Headphone Signal Level
The maximum output voltage for the music player function, measured
in accordance with EN 50332-2, is 125 mV.
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed
not to exceed the limits for exposure to radio waves recommended by
international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety margins
designed to assure the protection of all persons, regardless of age
and health.
The guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg
and the highest SAR value for this device when tested at the ear is
0.370 W/kg* and when worn on the body is 0.514 W/kg*.
For body-worn operation, this mobile device has been tested and
meets the RF exposure guidelines when used with an accessory
containing no metal and positioning the handset a minimum of 1.5 cm
from the body. Use of other accessories may not ensure compliance
with RF exposure guidelines.
As SAR is measured utilizing the devices highest transmitting power
the actual SAR of this device while operating is typically below that
indicated above. This is due to automatic changes to the power level
of the device to ensure it only uses the minimum level required to
reach the network.
The World Health Organization has stated that present scientific
information does not indicate the need for any special precautions for
the use of mobile devices. They note that if you want to reduce your
exposure then you can do so by limiting the length of calls or using a
hands-free device to keep the mobile phone away from the head.
*The tests are carried out in accordance with international guidelines for
testing.
84
Appendix
FCC Notice
- This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
- Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user's
authority to operate the equipment.
Information to User
This equipment has been tested and found to comply with the limits of
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation; if this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government.
The guidelines are based on standards that were developed by
independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons, regardless
of age and health.
The exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg.
Highest SAR value:
Model SHF31
FCC ID APYHRO00215
At the Ear 0.56 W/kg
On the Body 1.30 W/kg
This device was tested for typical body-worn operations with the back
of the handset kept 1.0 cm from the body. To maintain compliance with
FCC RF exposure requirements, use accessories that maintain a 1.0
cm separation distance between the user's body and the back of the
handset. The use of belt clips, holsters and similar accessories should
not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements, and should be avoided.
85
Appendix
The FCC has granted an Equipment Authorization for this model
handset with all reported SAR levels evaluated as in compliance with
the FCC RF emission guidelines. SAR information on this model
handset is on file with the FCC and can be found at (http://transition.fcc.
gov/oet/ea/fccid/) under the Display Grant section after searching on
the corresponding FCC ID (see table above).
Additional information on Specific Absorption Rates (SAR) can be
found on the FCC website at (http://www.fcc.gov/encyclopedia/
radio-frequency-safety).
Export Administration Regulations
The product and its accessories may be subject to the Japan Export
Administration Regulations (“Foreign Exchange and Foreign Trade
Law” and its related laws). In addition, U.S. Re-export Regulations
(Export Administration Regulations) may apply to the product and its
accessories. To export and re-export the product and its accessories,
take the required measures on your responsibility and at your
expenses. For details on the procedures, contact the Ministry of
Economy, Trade and Industry or the U.S. Department of Commerce.
Intellectual Property Rights
Trademarks
The company names and product names appearing in this manual
are trademarks or registered trademarks of their respective
holders.
•The microSD logo and microSDHC logo are trademarks of SD-3C,
LLC.
•The Bluetooth® word mark and logo are registered trademarks
owned by the Bluetooth SIG, Inc., and SHARP CORPORATION is
licensed to use these trademarks.
•Wi-Fi®, Wi-Fi CERTIFIED logo, Wi-Fi Protected Setup logo, Wi-Fi
Direct®, and Miracast® are registered trademarks of Wi-Fi Alliance®.
•Wi-Fi CERTIFIED™ and Wi-Fi Protected Setup™ are trademarks of
Wi-Fi Alliance®.
•The official name for Microsoft® Windows® is Microsoft® Windows®
Operating System.
•Microsoft®, Windows®, Windows Vista®, Microsoft® Excel®,
Microsoft® PowerPoint®, Windows Media® and Exchange® are
trademarks or registered trademarks of Microsoft Corporation in the
U.S.A. and other countries.
86
Appendix
•Microsoft® Word and Microsoft® Office are product names of
Microsoft Corporation in the U.S.A.
•QR code is a registered trademark of DENSO WAVE
INCORPORATED.
•FeliCa is a contactless IC card technology developed by Sony
Corporation.
FeliCa is a registered trademark of Sony Corporation.
•@ is a registered trademark of FeliCa Networks, Inc.
•Google™, the Google logo, Android™, the Android logo, Google™
Search and the Google Search logo are trademarks of Google Inc.
•“LINE” is a trademark of LINE Corporation.
•The internal voice recognition engine uses by
Advanced Media, Inc.
•Oracle and Java are registered trademarks of Oracle and/or its
affiliates. Other names may be trademarks of their respective
owners.
•“NightCatch/ナイトキャッチ”, “翻訳ファインダー”, “AQUOS/アクオ
ス” and the “AQUOS” logo, “AQUOS K” and the “AQUOS K” logo,
the “SHSHOW” logo, “フレーミングアドバイザー/FramingAdviser”,
“PASSNOW”, “TOUCH CRUISER EX”, “LCフォント/LCFONT” and
the LC logo symbol are registered trademarks or trademarks of
Sharp Corporation.
•iWnn of OMRON SOFTWARE Co., Ltd. is used for conversion
methods for Japanese language, and for phrase prediction methods
for English.
iWnn © OMRON SOFTWARE Co., Ltd. 2008-2015 All Rights
Reserved.
iWnn IME © OMRON SOFTWARE Co., Ltd. 2009-2015 All Rights
Reserved.
•The font type pre-installed in this product, Shin Go M, is licensed by
Morisawa Inc. solely for the use with this product.
“Morisawa” and “Shin Go” are registered trademarks or trademarks
of Morisawa Inc.
•Portions Copyright ©2004 Intel Corporation
•The product includes pictograms that SHARP CORPORATION is
licensed by NTT DOCOMO, INC.
87
Appendix
Open Source Software
•The product includes software based on GNU General Public
License (GPL), GNU Lesser General Public License (LGPL) and
other licenses.
For details on licenses of related software, in the standby screen, k
→ [Settings] → [Other settings] → [Device info] → [Legal
information] → [Open source licenses].
•Source codes of software based on GPL, LGPL and Mozilla Public
License (MPL) can be referred to on the following site for free. For
details, refer to the following site.
https://sh-dev.sharp.co.jp/android/modules/oss/
OpenSSL License
【OpenSSL License】
Copyright © 1998-2009 The OpenSSL Project. All rights reserved.
This product includes software developed by the OpenSSL Project for
use in the OpenSSL Toolkit. (http://www.openssl.org/)
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ''AS
IS'' AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT
OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT
OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED
AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.
【Original SSLeay License】
Copyright © 1995-1998 Eric Young (eay@cryptsoft.com) All rights
reserved.
This product includes cryptographic software written by Eric Young
(eay@cryptsoft.com)
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ''AS IS'' AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE
LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY
OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
88
Appendix
Windows Notations
The names of operating systems (Japanese versions) used in this
manual are as follows.
•Windows 8 is the abbreviation for Microsoft® Windows® 8,
Microsoft® Windows® 8 Pro and Microsoft® Windows® 8 Enterprise.
•Windows 7 is the abbreviation for Microsoft® Windows® 7 (Starter,
Home Basic, Home Premium, Professional, Enterprise, Ultimate).
•Windows Vista is the abbreviation for Microsoft® Windows Vista®
(Home Basic, Home Premium, Business, Enterprise, Ultimate).
More
The software installed on this product or part of it may not be altered,
translated/adapted, reverse-engineered, decompiled or reverse-
assembled and any such actions are prohibited.
Under the MPEG-4 Visual Patent Portfolio License, customers have
licensed permission for the following use of this product to engage in
non-profit personal use. Other uses are not permitted.
•Recording MPEG-4 Visual standard video (henceforth referred to as
MPEG-4 Video)
•Playing back MPEG-4 Video that a customer engaged in personal
and non-profit activities has recorded
•Playing back MPEG-4 Video obtained from a provider licensed by
MPEG-LA When using for promotion, in-house use, profit use, and
other intended uses, contact MPEG LA. LLC.
•This product is licensed under the AVC patent portfolio license for
the personal and noncommercial use of a consumer to (i) encode
video in compliance with the AVC standard (henceforth referred to
as AVC video) and/or (ii) decode AVC video that was encoded by a
consumer engaged in a personal and noncommercial activity and/or
was obtained from a video provider licensed to provide AVC video.
No license is granted or shall be implied for any other use. Additional
information may be obtained from MPEG LA, L.L.C.
Visit http://www.mpegla.com
•This product is licensed under the VC-1 Patent Portfolio License for
the personal and noncommercial use of a consumer to (i) encode
video in compliance with the VC-1 standard (henceforth referred to
as VC-1 video) and/or (ii) decode VC-1 video that was encoded by a
consumer engaged in a personal and noncommercial activity and/or
was obtained from a video provider licensed to provide VC-1 video.
No license is granted or shall be implied for any other use. Additional
information may be obtained from MPEG LA, L.L.C.
Visit http://www.mpegla.com
This product is licensed under the MPEG-4 Visual Patent Portfolio
License for the personal and non-commercial use of a consumer to (i)
encode video in compliance with the MPEG-4 Video Standard (“MPEG-
4 Video”) and/or (ii) decode MPEG-4 Video that was encoded by a
consumer engaged in a personal and non-commercial activity and/or
was obtained from a licensed video provider. No license is granted or
implied for any other use. Additional information may be obtained from
MPEG LA. See http://www.mpegla.com.
This product is licensed under the MPEG-4 Systems Patent Portfolio
License for encoding in compliance with the MPEG-4 Systems
Standard, except that an additional license and payment of royalties
are necessary for encoding in connection with (i) data stored or
replicated in physical media which is paid for on a title by title basis
and/or (ii) data which is paid for on a title by title basis and is
transmitted to an end user for permanent storage and/or use. Such
additional license may be obtained from MPEG LA, LLC. See http://
www.mpegla.com for additional details.
89
Customer Service Center
For general information, charges,
and operation assistance (toll free)
For inquiries, call:
From fixed-line phones: From au cell phones:
From fixed-line phones: From au cell phones:
In case above numbers are not available, call toll-free:
0120−977−033
(except Okinawa)
0120−977−699
(Okinawa)
For service cancelation procedure
in case of loss or theft (toll free)
Pressing “zero” will connect you to an operator,
after calling “157” on your au cellphone .
Keitai Guarantee Service Center
For loss, theft or damage (toll free)
From fixed-line phones/au cell phones:
Business hours: 9:00 to 21:00 (7 days a week)
Business hours: 24 hours (7 days a week)
Business hours: 9:00 to 20:00 (7 days a week)
0120−925−919
area code not required
area code not required
Cell phone and PHS operators collect and recycle
unused telephones, batteries and battery
chargers at stores bearing the logo regardless
of brand and manufacturer to protect the
environment and reuse valuable resources.
January 2015, 1st Edition
Sold by: KDDI CORPORATION,
OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: SHARP CORPORATION
