User Manual 2
25
shv34_e_01.fm
[25/27]
shv34_e.book 25 ページ ２０１６年６月３日 金曜日 午前１１時２５分
In some countries/regions including Europe※1, there are restrictions on the use
of 5GHz WLAN that may limit the use to indoors only.
If you intend to use 5GHz WLAN on the device, check the local laws and
regulations beforehand.
Manufacturer's Address:
Sharp Corporation, IoT Communication BU
2-13-1 Iida Hachihonmatsu
Higashihiroshima-City
Hiroshima,
739-0192
Japan
•Description of accessories
•Frequency range of supported bands in EU
Regulatory information
※1 The following EU and EFTA member countries:
Belgium (BE), Bulgaria (BG), Czech Republic (CZ), Denmark (DK), Germany (DE),
Estonia (EE), Ireland (IE), Greece (EL), Spain (ES), France (FR), Croatia (HR),
Italy (IT), Cyprus (CY), Latvia (LV), Lithuania (LT), Luxembourg (LU), Hungary
(HU), Malta (MT), Netherlands (NL), Austria (AT), Poland (PL), Portugal (PT),
Romania (RO), Slovenia (SI), Slovakia (SK), Finland (FI), Sweden (SE) and United
Kingdom (UK), Switzerland (CH), Liechtenstein (LI), Iceland (IS), Norway (NO).
Hereby, SHARP CORPORATION declares that the radio equipment type
SHV38 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following
internet address:
(http://www.sharp.co.jp/k-tai/)
Headset, Handsfree φ3.5 audio jack, Bluetooth.
microUSB cable For Charging, Peripherals, etc.
microSD memory
card
microSD/microSDHC/microSDXC
nano UIM card au Nano IC Card/non-au Nano IC Cards
non-au Nano IC Cards can be used after
SIM-unlocking the handset.
GSM 900 Tx 880.2 to 914.8 MHz
Rx 925.2 to 959.8 MHz
DCS 1800 Tx 1710.2 to 1784.8 MHz
Rx 1805.2 to 1879.8 MHz
WCDMA FDD I Tx 1922.4 to 1977.6 MHz
Rx 2112.4 to 2167.6 MHz
LTE Band 1 Tx 1922.5 to 1977.5 MHz
Rx 2112.5 to 2167.5 MHz
LTE Band 3 Tx 1710.7 to 1784.3 MHz
Rx 1805.7 to 1879.3 MHz
Bluetooth Tx 2402 to 2480 MHz
Rx 2402 to 2480 MHz
WLAN 2.4 GHz Tx/Rx 2412 to 2472 MHz (Bandwidth: 20MHz only)
WLAN 5 GHz W52(U-NII 1):
TX/RX 5180 - 5240MHz (BW:20MHz)
TX/RX 5190 - 5230MHz (BW:40MHz)
TX/RX 5210 MHz (BW:80MHz)
W53(U-NII 2):
TX/RX 5260 - 5320MHz (BW:20MHz)
TX/RX 5270 - 5310MHz (BW:40MHz)
TX/RX 5290 MHz (BW:80MHz)
W56(U-NII 2ext):
TX/RX 5500 - 5700MHz (BW:20MHz)
TX/RX 5510 - 5670MHz (BW:40MHz)
TX/RX 5530 - 5610MHz (BW:80MHz)
NFC Tx/Rx 13.56 MHz
GPS Rx L1 (1575.42 MHz)
26
shv34_e_01.fm
[26/27]
shv34_e.book 26 ページ ２０１６年６月３日 金曜日 午前１１時２５分
•Maximum transmit power
■Mobile Light
Do not point the illuminated light directly at someone's eyes.
Be especially careful not to shoot small children from a very close distance.
Do not use Mobile light near people's faces. Eyesight may be temporarily
affected leading to accidents.
■AC Adapter
Any AC adapter used with this handset must be suitably approved with a 5Vdc
SELV output which meets limited power source requirements as specified in
EN/IEC 60950-1 clause 2.5.
■Battery - CAUTION
■Volume Level Caution
■Headphone Signal Level
The maximum output voltage for the music player function, measured
in accordance with EN 50332-2, is 136 mV.
■Stand-by Mark
: This symbol means the stand-by on/off.
■European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed not to
exceed the limits for exposure to radio waves recommended by international
guidelines. These guidelines were developed by the independent scientific
organization ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest
SAR value for this device when tested at the ear is 0.463 W/kg※2 and when
worn on the body is 1.650 W/kg※2.
For body-worn operation, this mobile device has been tested and meets the RF
exposure guidelines when used with an accessory containing no metal and
positioning the handset a minimum of 5 mm from the body. Use of other
accessories may not ensure compliance with RF exposure guidelines.
As SAR is measured utilizing the devices highest transmitting power the actual
SAR of this device while operating is typically below that indicated above. This
is due to automatic changes to the power level of the device to ensure it only
uses the minimum level required to reach the network.
The World Health Organization has stated that present scientific information
does not indicate the need for any special precautions for the use of mobile
devices. They note that if you want to reduce your exposure then you can do so
by limiting the length of calls or using a hands-free device to keep the mobile
phone away from the head.
GSM 900 +33 dBm (Power Class4)
DCS 1800 +30 dBm (Power Class1)
WCDMA FDD I +24 dBm (Power Class3)
LTE Band 1 +23 dBm (Power Class3)
LTE Band 3 +23 dBm (Power Class3)
Bluetooth +4.0 dBm (Power Class1)
WLAN 2.4 GHz +12.5 dBm
WLAN 5 GHz +10.5 dBm
NFC -10 dBμA/m at 10 m
Use specified Charger only.
Non-specified equipment use may cause malfunctions, electric shock or fire
due to battery leakage, overheating or bursting.
The battery is embedded inside the product. Avoid removing the embedded
battery since this may cause overheating or bursting.
Do not dispose of the product with ordinary refuse. Take the product to an au
Shop, or follow the local disposal regulations.
Charge battery in ambient temperatures between 5°C and 35°C; outside this
range, battery may leak/overheat and performance may deteriorate.
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
※2 The tests are carried out in accordance with international guidelines for testing.
27
shv34_e_01.fm
[27/27]
- This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
- Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user's authority to operate the
equipment.
- The device is electronically labeled and the FCC ID can be displayed via
the About phone & the Authentication under the Settings menu.
■Information to User
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation; if this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help and for
additional suggestions.
Warning
The user is cautioned that changes or modifications not expressly approved by
the manufacturer could void the user's authority to operate the equipment.
■FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the
U.S. Government.
The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age and health.
The exposure standard for wireless handsets employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is
1.6 W/kg.
Highest SAR value:
This device was tested for typical body-worn operations with the back of the
handset kept 1.0 cm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain a 1.0 cm separation
distance between the user's body and the back of the handset. The use of belt
clips, holsters and similar accessories should not contain metallic components
in its assembly.
The use of accessories that do not satisfy these requirements may not comply
with FCC RF exposure requirements, and should be avoided.
The FCC has granted an Equipment Authorization for this model handset with
all reported SAR levels evaluated as in compliance with the FCC RF emission
guidelines. SAR information on this model handset is on file with the FCC and
can be found at (http://transition.fcc.gov/oet/ea/fccid/) under the Display Grant
section after searching on the corresponding FCC ID (see table above).
Additional information on Specific Absorption Rates (SAR) can be found on the
FCC website at (http://www.fcc.gov/encyclopedia/radio-frequency-safety).
FCC Notice
Model SHV38
FCC ID APYHRO00245
At the Ear 0.58 W/kg
On the Body 0.80 W/kg
shv34_e.book 27 ページ ２０１６年６月３日 金曜日 午前１１時２５分
