User Manual Draft
Introduction
Thank you for purchasing “ SHV40”.
Be sure to read this manual before and during use to ensure proper operation.
zThe screens and illustrations in this manual are shown as
examples. The actual screens and illustrations may differ.
zNote that “SHV40” is referred to as “handset” in this manual.
zThis manual refers to microSD Card, microSDHC Card or
microSDXC Card as “microSD Card” or “microSD”.
zReproduction of this manual in part or in whole without prior
permission is prohibited.
zThe contents of this manual are subject to change without
prior notice.
1
Contents/Precautions
Basic package
モSHV40
(includes warranty)
Basic manual
(in Japanese only)
Notes on usage
(in Japanese only)
(This drawing is not final)
Setting guide
(in Japanese only)
•Purchase a specified charger (sold separately).
The following items are not included in the package.
•microSD memory card
•AC adapter
•Earphone
•microUSB cable
7
Contents/Precautions
Precautions (ALWAYS FOLLOW
THESE DIRECTIONS)
Before use, read these “Precautions” carefully and use your
handset properly.
These precautions contain information intended to prevent
bodily injury to the user and to surrounding people, as well
as damage to property, and must be observed at all times.
The following symbols indicate the different degrees of
injury or damage that may occur if information provided is
not observed and the handset is used improperly.
Danger
This symbol indicates that
“death or serious bodily
injury (*1) may directly and
immediately result from
improper use”.
Warning
This symbol indicates that
“death or serious bodily
injury (*1) may result from
improper use”.
Caution This symbol indicates that
“minor injury (*2) and/or
property damage (*3) may
result from improper use”.
*1 Serious bodily injury: This refers to loss of eyesight, bodily
injury, burns (high- and low-temperature), electric shock,
broken bones, injuries with residual aftereffects from
poisoning, etc., and injuries requiring hospital admission for
treatment or long-term hospital attendance as an outpatient.
*2 Minor injury: This refers to bodily injury, burns (high- and
low-temperature), electric shock, etc. that do not require
hospital admission for treatment or long-term hospital
attendance as an outpatient.
*3 Property damage: This refers to extended damage to
buildings, furniture, livestock, pets, etc.
The following symbols indicate specific directions.
Indicates a
prohibited action.
Indicates not to
handle the device
with wet hands.
Indicates not to
disassemble the
device.
Indicates that
instructions
specified are
compulsory
(must be
followed).
Indicates not to
use the device
near water or get
it wet.
Indicates that the
power cord must
be unplugged from
the outlet.
8
Contents/Precautions
“Precautions” is explained in the following sections.
zHandling the handset, adapters, nano UIM card and TV
antenna cable (general) ..............................P. 8
zHandling the handset ...............................P.10
zHandling adapters .................................P.14
zHandling nano UIM card
............................P.16
zHandling near electronic medical equipment .............P.16
zMaterial list ......................................P.17
zHandling the sample (SIM eject tool) ...................P.18
Handling the handset, adapters, nano UIM
card and TV antenna cable (general)
Danger
Do not use, store or leave the equipment in
locations subject to high temperatures or
accumulation of heat (near a fire or heating unit, in
a kotatsu or bedding, under direct sunlight, inside
a vehicle on a hot day, etc.).
May cause fires, burns, bodily injury, electric shock, etc.
Do not place the equipment inside cooking
appliances such as microwave ovens and induction
cookers or high pressure vessels such as pressure
cookers, or near them.
May cause fires, burns, bodily injury, electric shock, etc.
Do not sprinkle sand, soil or dirt on the equipment
or put the equipment directly on it. Also, do not
touch the equipment when sand etc. is adhering to
your hand.
May cause fires, burns, bodily injury, electric shock, etc.
Refer to the following for details on waterproofness/
dustproofness.
☞P. 26 “Waterproof/Dustproof”
Do not charge the equipment while it is wet with
liquids such as water (drinking water, sweat,
seawater, pet urine, etc.).
May cause fires, burns, bodily injury, electric shock, etc.
Refer to the following for details on waterproofness.
☞P. 26 “Waterproof/Dustproof”
Do not press the equipment strongly or broken it.
Especially when you put and carry it in the pocket,
do not let it hit or caught in the object .
May cause fires, burns, bodily injury, etc. because of
catching fire, exploding, overheating or leaking of the
internal battery.
※Take particular care with the followings
zSitting or squatting down while you are putting the
equipment in your pocket of trousers or skirt
zLetting the equipment caught in the door or vehicular
door while you are putting the equipment in your pocket
of outerwear
zStepping on the equipment while it is placing on the soft
object such as the sofa or bedding, floor
9
Contents/Precautions
Do not attempt to disassemble or modify the
equipment.
May cause fires, burns, bodily injury, electric shock, etc.
Do not get the equipment wet with liquids such as
water (drinking water, sweat, seawater, pet urine,
etc.).
May cause fires, burns, bodily injury, electric shock, etc.
Refer to the following for details on waterproofness.
☞P. 26 “Waterproof/Dustproof”
Do not allow liquids such as water (drinking water,
sweat, seawater, pet urine, etc.) to get inside the
charger terminal or external connection jack.
May cause fires, burns, bodily injury, electric shock, etc.
Refer to the following for details on waterproofness.
☞P. 26 “Waterproof/Dustproof”
Use only optional parts specified by ●●●.
May cause fires, burns, bodily injury, electric shock, etc.
Warning
Do not subject the equipment to strong force,
impacts or vibration such as letting it fall, stepping
on it or throwing it.
May cause fires, burns, bodily injury, electric shock, etc.
Do not allow conductive materials (such as metal
objects and pencil lead) to come into contact with
the charger terminal or external connection jack or
dust to get inside it.
May cause fires, burns, bodily injury, electric shock, etc.
Do not cover or wrap the equipment with bedding
etc. when using or charging.
May cause fires, burns, etc.
If charging is not completed after the specified
charging time, stop charging.
May cause fires, burns, bodily injury, etc. because of
overcharging.
Be sure to turn off the handset and not to charge
the battery in locations where flammable gas may
be generated such as gas stations and where dust
is generated.
May cause explosions, fires etc. if using the equipment in
location where flammable gas etc. is generated.
To use Osaifu-Keitai in locations such as gas stations, be
sure to turn off the power in advance (If NFC/Osaifu-Keitai
lock is set, disable the lock before turning off the power).
10
Contents/Precautions
If any trouble such as an unusual odor, unusual
noise, smoking, overheating, discoloration or
deformation is found during use, charge or storage,
follow the instructions below.
zUnplug the power plug from the outlet or accessory
socket.
zTurn off the handset.
May cause fires, burns, bodily injury, electric shock, etc. if
you do not follow the instructions above.
Caution
Do not use a damaged equipment.
May cause fires, burns, bodily injury, etc.
Do not leave the equipment on unstable surfaces,
such as on a wobbly table or sloped surface. Be
very careful while the vibrator is set.
May fall and cause injury etc.
Do not use or store the equipment in locations that
are subject to humidity, dust or high temperatures.
May cause fires, burns, electric shock, etc.
Refer to the following for details on waterproofness/
dustproofness.
☞P. 26 “Waterproof/Dustproof”
If being used by a child, have a guardian teach him/
her the proper handling procedures and do not
have him/her use it improperly.
May cause bodily injury etc.
Do not place the equipment where the young
children can reach it.
A young child may swallow the equipment, or suffer bodily
injury, electric shock, etc.
Be careful when using the handset continuously
for a long time or charging because it may become
warm. Also, be careful not to touch it
unintentionally for a long time when you fall asleep
etc.
The handset or adapter may become warm when using an
app, a call, data communication, watching TV or video, etc.
for a long time or charging.
Directly touching a warmed part for a long time may cause
redness, itching, rashes, low-temperature burns, etc. on
your skin depending on your constitution or health condition.
Handling the handset
Danger
Do not throw the handset into a fire or heat it.
May cause fires, burns, bodily injury, etc. because of
catching fire, exploding, overheating or leaking of the
internal battery.
11
Contents/Precautions
Do not apply excessive force on the handset such
as puncturing it with a nail (sharp object), hitting it
with a hammer (hard object) or stepping on it.
May cause fires, burns, bodily injury, etc. because of
catching fire, exploding, overheating or leaking of the
internal battery.
If the substance etc. inside the handset comes into
contact with your eyes or mouth, immediately rinse
the contacted area with clean water. Then seek
prompt medical treatment.
May result in loss of eyesight, sick, etc. because of the
substance etc. inside the handset.
Warning
Do not point the illuminated light directly at
someone's eyes. Especially when you use it for
young children, keep sufficient distance from them.
Do not use Mobile light near people's faces. Eyesight may
be temporarily affected leading to accidents etc.
Do not illuminate or emit the mobile light at anyone
driving a car or other vehicles.
May prevent a driver from driving safely and cause a traffic
accident etc.
Do not watch the screen which is flashing
repeatedly for a long time.
May cause spasm or loss of consciousness.
Do not allow water or other liquids (drinking water,
sweat, seawater, pet urine, etc.), metal, flammable
material or other foreign object to enter the slot of
the nano UIM Card and microSD Card tray on the
handset.
Also, do not insert the nano UIM card or microSD
Card in the wrong place or wrong side.
May cause fires, burns, bodily injury, electric shock, etc.
Do not expose the camera lens to direct sunlight
etc. for an extended period.
May cause fires, burns, bodily injury etc. because of the
light-collecting mechanism of the lens.
Turn off the handset or set it to Airplane mode
before going aboard an airplane.
Since using the handset on airplanes is restricted, follow
the instructions given by the respective airlines.
May interfere with the operation of electronic devices
installed on the airplane.
If you commit a prohibited act while using the handset on
an airplane, you may be punished by law.
Follow the instructions given by the respective
medical facility regarding the use of the handset in
a hospital.
Turn off the handset in areas where the use of mobile
phones is prohibited.
May interfere with the operation of electronic devices and
electronic medical equipment.
12
Contents/Precautions
Keep the handset away from the ears during a call
in which hands-free is set, while the ringtone is
ringing loudly, during stand-by, etc.
When you attach the earphone/microphone etc. to
the handset to play games, video/music, etc., do
not make the volume too loud.
During a call in which hands-free is set, loud sounds are
being emitted from the handset.
Even during stand-by, the ringtone or alarm sound may
activate suddenly.
Hearing loud sounds for a long time may damage your
hearing such as deafness.
Also, excessively high volume prevent you from hearing
ambient sounds and cause an accident.
If you have a weak heart, take extra precautions
when setting functions such as the vibrator and
ringtone volume for incoming calls.
May have harmful effects on your heart.
If you are using electronic medical equipment etc.,
contact the respective manufacturer or dealer to
check whether the operation of the equipment is
affected by signals.
May interfere with the operation of electronic medical
equipment etc.
Turn off the handset near high-precision electronic
devices or devices that use weak electronic
signals.
May interfere with the operation of electronic devices.
※Take particular care with the following devices
Hearing aids, implanted cardiac pacemakers, implanted
cardioverter-defibrillators, other electronic medical
equipment, other equipment controlled by electronic signals,
etc. If you use an implanted cardiac pacemaker, implanted
cardioverter-defibrillator or other electronic medical
equipment, contact the respective manufacturer or dealer to
check whether the operation of the equipment is affected by
signals.
If the display part or camera lens is damaged, be
careful of broken glass and the exposed inside of
the handset.
May cause burns, bodily injury, electric shock, etc. if you
touch the broken or exposed parts.
If the internal battery leaks or emits an unusual
odor, immediately stop using the handset and
move it away from any naked flames or fire.
The battery fluid is flammable and could ignite, causing a
fire, explosion, etc.
Do not allow a pet etc. to bite the handset.
May cause fires, burns, bodily injury, etc. because of
catching fire, exploding, overheating or leaking of the
internal battery.
13
Contents/Precautions
Caution
For using a motion sensor and geomagnetic
sensor, check the safety around, hold the handset
and do not swing it more than necessary.
May cause an accident such as bodily injury.
If the display is broken and the internal substance
etc. then leaks, do not get it on your skin (face,
hands, etc.), clothes, etc.
May result in damage to your eyes, skin, etc.
If the internal substance etc. comes into contact with your
eyes, mouth, skin or clothes, immediately rinse the
contacted area with clean water.
Also, if it comes into contact with your eyes or mouth, seek
medical treatment immediately after rinsing the contacted
area.
Do not dispose of the handset in ordinary garbage.
May cause fires, burns, bodily injury, etc. because of
catching fire. Also, may damage to the environment. Take
the unnecessary handset to a sales outlet such as a ●●●
Shop or follow the instructions by a local institution that
handles used handsets.
If the substance etc. inside the internal battery
leaks, do not get the liquid on your skin (face,
hands, etc.).
May result in damage to your eyes, skin, etc.
If the internal substance etc. comes into contact with your
eyes, mouth, skin or clothes, immediately rinse the
contacted area with clean water.
Also, if it comes into contact with your eyes or mouth, seek
medical treatment immediately after rinsing the contacted
area.
When removing the nano UIM card, be careful
with the tip of the SIM eject tool or paper clip not
to injure any part of your body such as fingers.
May cause bodily injury etc. if you touch the tip of the
SIM eject tool or paper clip.
If you use the handset in a vehicle, contact the
vehicle manufacturer or dealer to check whether
the operation of the vehicle is affected by signals.
May interfere with the operation of electronic equipment in
some vehicle models. In this case, stop using the handset.
If any trouble on your skin occurs due to using the
handset, immediately stop using it and seek
medical treatment. Use of the handset may cause
itching, rashes, eczema, etc. depending on your
constitution or health condition.
Refer to the following for details on materials of each part.
☞P. 17 “Material list”
14
Contents/Precautions
Make sure that there is no metal (a blade of cutter,
staple, etc.) on the handset because the earpiece
section, speaker section and back camera section
contain parts that generate magnetic waves.
May cause bodily injury etc. because of the adhered object.
Look at the display in a well-lit place, keeping a
certain distance.
Eyesight may be weakened etc. if you look at it in a dark
place or closely.
Handling adapters
Warning
Do not use if the cord of the adapter is damaged.
May cause fires, burns, electric shock, etc.
Never use the adapter in humid locations such as a
bathroom.
May cause fires, burns, electric shock, etc.
The DC adapter should only be used in negative
grounded vehicles. Never use it in positive
grounded vehicles.
May cause fires, burns, electric shock, etc.
Do not touch adapters if you hear thunder.
May cause electric shock etc.
Do not short-circuit the charger terminal when
connected to an outlet or accessory socket. Also,
do not allow any part of your body (hands, fingers,
etc.) to come into contact with the charger terminal.
May cause fires, burns, electric shock, etc.
Do not place heavy objects on the cord of the
adapter or apply excessive force on it such as
pulling it.
May cause fires, burns, electric shock, etc.
When plugging/unplugging an AC adapter into/
from the outlet, do not allow metallic objects to
come into contact with the prongs of the plug.
May cause fires, burns, electric shock, etc.
Do not connect the voltage converter for overseas
travel (travel converter) to the AC adapter.
May catch fire, or cause overheat, electric shock, etc.
Do not apply excessive force on the connection
part with the adapter connected to the handset.
May cause fires, burns, bodily injury, electric shock, etc.
Do not handle the cord, charger terminal or power
plug of the adapter with wet hands.
May cause fires, burns, electric shock, etc.
15
Contents/Precautions
Always use the specified power supply and voltage.
When using overseas, use the AC adapter that is
available overseas.
Using the incorrect power supply and voltage may cause
fires, burns, electric shock, etc.
AC adapter: 100V AC (Connect only with a household AC
outlet)
AC adapter available overseas: 100 to 240V AC (Connect
only with a household AC outlet)
DC adapter: 12/24V DC (for negative grounded vehicles
only)
If you replace the fuse in the DC adapter, always
replace it with a specified fuse.
May cause fires, burns, electric shock, etc. if you use the
fuse other than specified one. Refer to the respective
manuals for information on specified fuses.
Wipe off any dust on the power plug.
May cause fires, burns, electric shock, etc. if you use the
power plug with dust adhering.
Fully plug the adapter into the outlet or accessory
socket.
May cause fires, burns, electric shock, etc. if you do not
insert it securely.
Always grasp the adapters when unplugging the
power plug from the outlet or accessory socket. Do
not apply excessive force on it such as pulling the
cord of the adapter.
May cause fires, burns, electric shock, etc. since the cord of
the adapter is damaged by pulling it.
When plugging/unplugging an adapter into/from
the handset, plug/unplug it straightly toward the
terminal to connect, not applying excessive force
on it such as pulling the cord.
May cause fires, burns, bodily injury, electric shock, etc. if
you do not plug/unplug it correctly.
If the charger terminal is deformed such as bending
it, immediately stop using. Also, do not use the
deformed one by returning it to the original shape.
May cause fires, burns, bodily injury, electric shock, etc.
because of short circuit of it.
Unplug the power plug of the adapter from the
outlet or accessory socket when not using.
May cause fires, burns, electric shock, etc. if you leave the
power plug with it plugged into the outlet or accessory
socket.
If water or other liquids (drinking water, sweat,
seawater, pet urine, etc.) enter the equipment,
immediately remove the power plug from the outlet
or accessory socket.
May cause fires, burns, electric shock, etc.
Always unplug the power plug from the outlet or
accessory socket before cleaning the equipment.
May cause fires, burns, electric shock, etc. if you do not
unplug it.
16
Contents/Precautions
Caution
Do not touch the adapter for a long time when
connected to an outlet or accessory socket.
May cause burns etc.
Handling nano UIM card
Caution
Be careful with the cutting surface not to injure any
part of your body such as fingers when handling
the nano UIM card.
May cause bodily injury etc.
Handling near electronic medical equipment
Warning
If you have electronic medical equipment such as
an implanted cardiac pacemaker or an implanted
cardioverter-defibrillator, always carry or use your
handset at least 15 cm away from your implant.
Electromagnetic signals may have harmful effects on the
operation of the electronic medical equipment.
Patients receiving medical treatment away from a
medical facility (e.g. home treatment) who are
using electronic medical equipment other than
implanted cardiac pacemakers or implanted
cardioverter-defibrillators should consult the
respective manufacturers etc. for information
regarding the effects of signals on the equipment.
Electromagnetic signals may have harmful effects on the
operation of the electronic medical equipment.
17
Contents/Precautions
If there is any chance that the distance between the
handset and a person closest to you may get
shorter than 15 cm such as when you cannot freely
move around, set the handset not to emit radio
wave in advance (by setting Airplane mode, turning
the power off, etc.).
Somebody nearby may be equipped with electronic medical
equipment such as an implanted cardiac pacemaker or an
implanted cardioverter-defibrillator. Electromagnetic signals
may have harmful effects on the operation of the electronic
medical equipment.
Follow the instructions given by the respective
medical facilities regarding the use of the handset
on their premises.
May have harmful effects on the operation of the electronic
medical equipment.
Material list
Handset
Part Material/Surface treatment
Display side (Glass section)
Surrounding area of display side
Back
Power key
Volume up/down key
Fingerprint sensor
Camera panel
Mobile light
Earpiece (Receiver) mesh
Card tray (Exterior section)
au IC Card and microSD Card tray
Gasket of au IC Card and microSD Card tray
Slot of au IC Card and microSD Card tray
IMEI plate
Reinforced glass/Antifouling coating
PA resin/Hard coating
PC resin + ABS resin/Painting
Aluminum/Anodizing
Aluminum/Anodizing
Epoxy resin/Hard coating
Acryl resin + PC resin/Hard coating
PC resin
PC resin
PC resin/Painting
POM resin
Silicon rubber
PA resin
PET resin
18
Contents/Precautions
SIM eject tool
Part Material/Surface treatment
Handling the sample (SIM eject tool)
Warning
The tip of the SIM eject tool is sharp. Do not use it
pointing at yourself or others.
May hit you or others around you, resulting in bodily injury,
loss of eyesight, etc.
Handling precautions
General notes
zSHV40 is waterproof/dustproof, however, do not allow liquid
such as water (drinking water, sweat, seawater, pet urine,
etc.) and foreign object such as dust to get inside the
handset and do not allow them to adhere to accessories or
optional parts.
●●●●●
●●●●●
19
Contents/Precautions
The adapter, nano UIM card and TV antenna cable are not
waterproof/dustproof. Do not use in humid or steamy areas such as
bathrooms and avoid exposing to rain and other forms of moisture. If
they are carried close to the skin, perspiration may cause internal
components to corrode and result in malfunction. If a problem is found
to be due to moisture, the handset and parts are not covered by
warranty. For details on repair, contact the number listed in
“Repairs” (in Japanese only) on the last page or a repair counter that
●●● specifies.
zClean only with a soft and dry cloth (such as the type used
for eyeglasses).
yForceful rubbing of the display with a dry cloth etc. may scratch its
surface.
yWater drops, dirt, etc. left on the display may cause stains to form
on its surface.
yNever use chemicals such as alcohol, thinners, benzene or
detergents, as these agents may erase the printing or cause
discoloration.
zOccasionally clean terminals, the fingerprint, etc.
When using unclean terminals etc., they may not work properly.
Be careful with the terminals etc. while cleaning them.
zDo not place the equipment near an air conditioning vent.
Condensation formed due to rapid changes in temperature may cause
internal corrosion and lead to a malfunction.
zDo not apply excessive force on the handset when using it.
Carrying the equipment in a tightly packed bag or sitting on it put in
your pocket may cause damage to the display, internal components,
internal battery, etc. or result in a malfunction.
Keeping an external connector device plugged into the external
connection jack may cause damage or a malfunction.
zUse only optional parts specified by ●●●.
May cause a malfunction or damage when optional parts other than
those specified by ●●● are used.
zRead the respective user's guides supplied with supported
optional parts carefully.
zDo not drop or otherwise subject the equipment to severe
impact.
May cause a malfunction or damage.
Notes about the handset
zDo not forcefully press the display or operate with a pointed
object.
May scratch it and cause malfunction or damage.
zAvoid using the handset in extremely high or low
temperatures.
Use the handset within the range of a temperature between 5℃ and
35℃ and a humidity between 45% and 85%.
Refer to the following for details on using it at a bathroom.
zUsing the handset close to land-line phones, TVs, radios,
etc. may have harmful effects on the operation of such
equipment. Move as far away as possible from such items
before use.
zBack up to the microSD Card, PC, cloud, etc. or keep a
separate memo noting data stored on the handset.
●●● shall not be liable for any loss of content.
20
Contents/Precautions
zWhen connecting an external connector device to the
external connection jack, do not put it in obliquely and do
not pull it while it is plugged in.
May cause a malfunction or damage.
zThe handset becomes warm during use or charging but this
is not a malfunction.
zDo not leave the camera lens in direct sunlight.
May cause discoloration or burn-in of pixels.
zUse the handset with the nano UIM Card and microSD Card
tray closed.
Liquid such as water (drinking water, sweat, seawater, pet urine, etc.)
or foreign object such as dust may get inside and cause a malfunction.
zDo not give a strong impact on the fingerprint sensor or
scratch the surface.
May cause not only malfunction of the fingerprint sensor but also
disabling authentication.
zWhile using a microSD Card, do not remove the card or turn
off the handset.
May cause data loss or a malfunction.
zNever place a magnetic card or magnetized items near the
handset.
The stored magnetic data in cash cards, credit cards, telephone
cards, floppy disks, etc. may be erased.
Putting highly magnetized items closer may cause an error.
zDo not decorate the handset with films, stickers, etc.
The operation such as each function for using the proximity sensor/
brightness sensor may not work normally.
Refer to the following for details on the position of the proximity
sensor/brightness sensor.
☞P. 28 “Part names and functions”
zThe internal battery is not covered by warranty because it is
a consumable product.
Depending on usage, the internal battery may swell as it approaches
the end of its usable life. Change the battery if the its life becomes
extremely shorter or the it swells even after fully charged.For details
on replacing the internal battery, contact the number listed in
“Repairs” (in Japanese only) on the last page or a repair counter that
●●● specifies.
zCharge battery in areas where ambient temperature is
between 5℃ and 35℃.
zThe battery life depends on the usage and deterioration of
the battery.
zDo not store the handset under the following situations
because they may lower the performance or shorten the
usable life of the internal battery.
yStorage with the internal battery fully charged (immediately after
charging is completed)
yStorage with no battery level (cannot turn the handset on)
Approximately 40% is recommended as the proper battery level for
storage.
zThe following is the type of the internal battery built into the
handset.
Label Battery type
Li-ion00 Lithium-ion
zThe surface of the handset uses the aluminum material.
Note that dent and abrasion are easily remained as
aluminum is a soft material.
21
Contents/Precautions
Notes about adapters
zCharge the battery in areas where the ambient temperature
is between 5℃ and 35℃.
zDo not charge the internal battery in the following locations.
yAreas with high humidity or dust, or in areas exposed to frequent
vibrations
yClose to land-line phones, TVs, radios, etc.
zAdapters may become warm during charging but this is not
a malfunction.
zDo not use the DC adapter to charge the battery when the
car engine is not running.
May cause the car battery to run down.
zWhen using an outlet with a feature to prevent the plug from
being removed accidentally, follow the instructions in the
outlet user's guide.
zDo not subject to strong impacts. Also, do not deform the
charger terminals.
May cause a malfunction.
Notes about nano UIM card
zDo not apply unnecessary force when inserting/removing
the nano UIM card.
zCustomer is responsible for malfunctions arising from
inserting nano UIM card into a different IC card reader/
writer etc.
zOccasionally clean IC area.
When using the nano UIM card while IC area is not clean, it may not
work properly.
zClean only with a soft and dry cloth (such as the type used
for eyeglasses).
zBack up to the microSD Card, PC, cloud, etc. or keep a
separate memo noting data stored on the nano UIM card.
●●● shall not be liable for any loss of content.
zTo protect the environment, please take any unneeded nano
UIM cards to a sales outlet such as a ●●● Shop.
zDo not damage, touch haphazardly or short-circuit the IC.
May cause data loss or a malfunction.
zDo not drop or otherwise subject the nano UIM card to
severe impact.
May cause a malfunction.
zNever bend the nano UIM card or place heavy objects on it.
May cause a malfunction.
zDo not insert the nano UIM card to the handset with a label,
sticker, etc. attached on the card.
May cause a malfunction.
22
Contents/Precautions
Notes on using Bluetooth function
zThe handset supports the security function that meets the
Bluetooth specification for security during communication
using Bluetooth functions. However, the security may not
be sufficient depending on the configuration etc. Take care
of the security while making communication using
Bluetooth function.
zEven if any leak of data or information occurs while making
communication using Bluetooth function, ●●● shall not be
liable for any loss of content.
zRadio frequencies
In the home screen, [
]▶[Settings]▶[About phone]▶
[Authentication] to confirm the radio frequencies the Bluetooth
function of the handset uses. The followings are the descriptions:
① ② ③ ④ ⑤
⑥
①2.4: This radio equipment uses the 2,400 MHz band.
②FH: The modulation system is the FH-SS system.
③1: The estimated coverage distance is 10 m or less.
④XX: Another modulation system is used.
⑤4: The estimated coverage distance is 40 m or less.
⑥: All radio frequencies between 2,400 MHz and
2,483.5 MHz are used and the frequencies for mobile object
identifiers cannot be avoided.
zCautions on using Bluetooth devices
Bluetooth operates at radio frequencies assigned to the in-house
radio stations for a mobile object identifier that have to be
licensed and are used in production lines of a factory, specific
unlicensed low power radio stations, and amateur radio stations
(hereafter, referred to as “another radio station”) in addition to
industrial, scientific and medical devices or home electric
appliances such as microwave ovens.
1. Before using the handset, make sure that “another radio
station” is not operating nearby.
2. If radio interference between the handset and “another
radio station” occurs, avoid interference by moving
immediately to another place or “turning off the power”.
3. Contact the number listed in “General Inquiries” on the
last page for further details.
Notes about wireless LAN (WLAN)
zWireless LAN (WLAN) uses radio waves to communicate
information. Therefore, it has an advantage of freely
connecting to the LAN within the service area. On the other
hand, if security setting is not set, it is possible for a
malicious third party to intercept the communication
contents or hack. It is recommended to set security setting
at your own risk and judgement.
zWireless LAN
Do not use wireless LAN near magnetic devices such as electric
appliances or AV/OA devices or in radio waves.
yMagnetism or radio waves may increase noises or disable
communications (especially when using a microwave oven).
23
Contents/Precautions
yWhen used near TV, radio, etc., reception interference may occur
or channels on the TV screen may be disturbed.
yIf there are multiple wireless LAN access points nearby and the
same channel is used, search may not work correctly.
zRadio frequencies
In the home screen, [ ]▶[Settings]▶[About phone]▶
[Authentication] to confirm the radio frequencies the WLAN-installed
devices use. The followings are the descriptions:
① ② ③ ④
⑤
①2.4: This radio equipment uses the 2,400 MHz band.
②DS: The modulation system is the DS-SS system.
③OF: The modulation system is the OFDM system.
④4: The estimated coverage distance is 40 m or less.
⑤ : All radio frequencies between 2,400 MHz
and 2,483.5 MHz are used and the frequencies for mobile object
identifiers can be avoided.
Available channels for the handset's wireless LAN are between 1 and
13. Note that other channel access points cannot be connected.
Available channels may vary depending on the country.
For use in an aircraft, contact the airline beforehand.
zCautions on using 2.4 GHz devices
WLAN-installed devices operate at radio frequencies assigned
to the in-house radio stations for a mobile object identifier (radio
stations requiring a license) used in production lines of a factory,
specific low power radio stations (radio stations requiring no
license), and amateur radio stations (radio stations requiring a
license) in addition to industrial, scientific and medical devices or
home electric appliances such as microwave ovens.
1. Before using this device, make sure that the in-house radio
stations for a mobile object identifier, specific low power radio
stations and amateur radio stations are not operating nearby.
2. If the device causes harmful radio interference to the in-house
radio stations for a mobile object identifier, immediately
change the radio frequency or stop use, and contact the
number listed in “General Inquiries” on the last page for
crosstalk avoidance, etc. (e.g. partition setup).
3. If the device causes radio interference to specific low power
radio stations for a mobile object identifier or amateur radio
stations, contact the number listed in “General Inquiries” on
the last page for further details.
24
Contents/Precautions
Voluntary control for radio wave interference
zThis product satisfies technical requirements based on
VCCI Rules for Voluntary Control Measures and its satisfied
mark is displayed on the electronic nameplate of the
product.
You can see the electronic nameplate by operating the product
as follows.
In the home screen, [ ]▶[Settings]▶[About phone]▶
[Authentication]
FeliCa and NFC reader/writer
zThe FeliCa, NFC reader/writer and P2P function of the
handset use weak radio waves whose handling does not
require a license of radio station.
zThe frequency in use is the 13.56 MHz band. When another
FeliCa, NFC reader/writer or P2P function is being used
nearby, keep enough distance from it. Make sure that there
is no radio station using the same frequency band in the
nearby area.
zFor use in an aircraft, contact the airline beforehand. Use of
the function may be restricted in some countries.
Check conditions such as regulations of the country/region
to use the function.
Notes about the sample (SIM eject tool)
zDo not insert the SIM eject tool into the hole etc. other than
those for ejecting the nano UIM Card and microSD Card
tray.
May cause a malfunction or damage.
zDo not apply excessive force on the SIM eject tool when
using it.
May cause a malfunction or damage.
zWhen discarding, segregate it according to the local rules.
zUse the SIM eject tool only for the intended purpose in this
manual.
May cause a malfunction or damage.
zDo not use the SIM eject tool for other mobile phones.
May cause malfunction or damage of other mobile phones.
25
Contents/Precautions
Caution
zNever use the handset that is modified. Using a modified
device violates the Radio Law and/or the
Telecommunications Business Law.
The handset follows the regulations regarding the certification of
conformity with technical regulations for specific radio stations etc.
based on the Radio Law and authentication of conformity with
technical regulations for devices etc. based on the
Telecommunications Business Law, and the “Technical Conformity
Mark ” can be displayed on the electronic nameplate of the
handset as a proof. You can see it by operating as follows. In the home
screen, [ ]▶[Settings]▶[About phone]▶[Authentication]
If the screws of the handset are removed and a modification is given
to the inside, the certification of conformity with technical regulations
etc. will become invalid. Never use the handset without the valid
certification etc. Doing so violates the Radio Law and/or the
Telecommunications Business Law.
zBe careful when using the handset while driving a motor
vehicle.
Using the handset in hand while driving is regarded as a punishable
act.
However, the punishment has no application in some cases such as
when rescuing sick and injured people or maintaining public safety.
zThe FeliCa reader and NFC reader/writer function of the
handset conform to the domestic radio wave standards.
When you use it overseas, check conditions such as
regulations of the country/region in advance.
zNever change the basic software improperly.
This may be regarded as a conversion of software and repairs may be
refused.
28 Before Using the Handset
Before Using the Handset
Part names and functions
1 Nano UIM Card and microSD Card tray
zThe tray for inserting the nano UIM Card and
microSD Card is stowed.
P.31“nano UIM card”
zFor details on nano UIM card
zF
or details on microSD Card P. 33 “microSD Card”
2 Earphone/Microphone terminal
3 Front camera
zFor details on using camera ☞P. 119 “SHCamera”
4 Proximity sensor/Brightness sensor*1
zThe proximity sensor detects the distance to the face and
prevents inadvertent operation of touch panel during a call.
zThe brightness sensor detects the brightness of the
surrounding area and adjusts the brightness of the backlight.
5 Earpiece
6 Display/Touch panel
zFor details on operation of the touch panel ☞P. 38
“Operation of touch panel”
7 Fingerprint sensor
zUse to unlock the touch panel etc. by fingerprint
authentication.
zFor details on using fingerprint sensor ☞P. 161 “Fingerprint
authentication”
8 Incoming/Charging lamp
zFor details on incoming/charging lamp ☞P. 55 “Incoming/
Charging lamp”
☞
☞
(This drawing is not final)
29 Before Using the Handset
9 Microphone
zUse when recording videos.
zUse to measure ambient noises for communicating by making
your voices sound clear when using Clear talk.
zUse as a mouthpiece during a hands-free call.
a 1/2: Volume up/down key
zAdjusts the volume in each function.
b 0: Power key
zUse to turn the power on/off, etc.
zUse to turn the display on/off.
zFor details on operation of the power key ☞P. 37 “Turning
power on/off”
c Back camera
zFor details on using camera ☞P. 119 “SHCamera”
d Mobile light
e
#mark
zIC card is contained (It cannot be removed).
zFor details on using # mark ☞P. 108 “Osaifu-Keitai”,
P. 176 “NFC communication”
(This drawing is not final)
30 Before Using the Handset
f Mouthpiece/Microphone
zUse as a microphone when recording videos or talking to
EMOPA.
g USB Type-C connection jack
zFor details on connection to an external device ☞P. 35
“Charging”, P. 36 “PC connection”, P. 179 “USB host
function”
h Speaker
zRingtone, music, etc. can be heard from here.
zThe other party's voice can be heard from here during a
hands-free call.
i LTE/FOMA antenna*2
j Wi-Fi/Bluetooth antenna*2
k Wi-Fi antenna*2
l GPS/LTE/FOMA antenna*2
*1 Do not cover the sensor area with your hand or paste a
sticker etc. on the sensor area. The sensor may not work
properly.
*2 The antenna of back is built into the main body. At sides of
the handset, the metal sections of surface are used as the
antenna. Covering the antenna area with your hand may
influence the communication quality.
zThe back cover cannot be removed. Removing it forcibly may
cause damage or malfunction.
Mobile light
zThe mobile light may be automatically turned off if you use the
handset for a long time or the handset becomes warm after the
mobile light is turned on. Also, you may not be able to use the
mobile light if the handset is warm.
Microphone
zWhen using functions which support the microphone, do not
cover the hole of the microphone.
Earphone/Microphone
zDepending on the type of the earphone/microphone, it may not
be available.
(This drawing is not final)
36 Before Using the Handset
Charging with AC adapter
When charging with AC Adapter (sold separately), carry out
the following operations.
1 Insert the Type-C plug of the AC adapter
horizontally into the USB Type-C connection
jack on the handset
2 Erect the AC adapter power plug and insert it
into an outlet
zThe charging lamp illuminates and charging starts.
zWhen charging is complete, the charging lamp turns off.
3 When charging is complete, pull the AC adapter
power plug from the outlet and remove the
Type-C plug of the AC adapter horizontally from
the USB Type-C connection jack
zRefer to user's guide of AC Adapter.
zThe shape of the plug for the AC adapter is for 100V AC (for
domestic use). To use the AC adapter of 100 to 240V AC
overseas, a conversion plug adapter applicable to your
country of stay is required. Do not use a voltage converter for
overseas travel to charge the battery.
zNote that inserting or removing the equipment forcibly may
cause damage to the USB Type-C connection jack and the
Type-C plug or result in a malfunction.
Charging with DC adapter
The DC adapter (sold separately) supplies the power for
charging from a car accessory socket (12 and 24 V).
zThe DC adapter should only be used in negative grounded
vehicles (12 and 24V DC).
zDo not use with the car engine shut off. May drain the car
battery.
zThe DC adapter fuse is a consumable product. For
replacement, purchase a new fuse at a nearest auto parts
retailer etc.
zRefer to the user's guide of DC Adapter for details.
Charging lamp
USB Type-C
connection jack
Type-C plug
AC adapter
(This drawing is not final)
37 Before Using the Handset
Charging with USB Cable
You can charge the handset by connecting the handset to
a PC with USB cable (sold separately) etc.
zFor details on connecting to a PC ☞P. 178 “PC connection”
Turning power on/off
Turning power on
1 0(for at least 2 seconds)
zWhen you turn the power on for the first time, make the initial
settings (☞P. 48 “Initial settings”).
Turning power off/Reboot/Emergency mode
1 0(for at least 1 second)
2 Select an item
Power off：Turn off the handset.
Restart：Reboot the handset.
Emergency mode：For details ☞P. 41 “Emergency mode”
Turning display on/off
The display is turned off when 0 is pressed or the handset is not
in use for a set length of time.
Press 0 while the display is turned off to turn it on.
Touch panel lock
When the power or the display is turned on, the touch panel is
locked.
Touch [ ] to unlock.
Operations in touch panel lock screen
zTo set/disable the manner mode: 2 (for at least 2 seconds)
zTo activate SHCamera: [ ]
zTo activate Clock: Touch the clock
zTo display the detailed information on notifications: Drag the
clock down
zTo display the status panel: Drag the status bar down
39 Before Using the Handset
Touch
Touch a key or an item displayed on the screen and then release
your finger from it to select or set it.
Touch and hold
When you keep your finger on the touch panel, a menu may appear
depending on the function and screen in use.
Slide (Swipe)/Drag
Move your finger while keeping it on the touch panel to scroll the
screen or move an icon, a widget, etc. to the desired position.
In addition, when you touch a menu or an item by mistake, move
your finger away from it to cancel the selection.
Flick
Move your finger like sweeping the touch panel in the home screen
etc. to switch pages.
Pinch out/Pinch in
You may be able to zoom the screen in/out etc. by putting two
fingers on the touch panel and moving them with putting a distance
between two fingers apart (pinch out)/closer (pinch in) depending
on the function and screen in use.
Operation while using function
Navigation keys
Use the navigation keys displayed at the bottom of the screen to
perform the basic operations.
1 A/@:Back key/Close key
zReturn to the previous screen.
zClose the keyboard.
2 B:Home key
zDisplay the home screen.
3 C/D:Recent Apps key/Multi window key
zDisplay Recent Apps (☞P. 61 “Recent Apps”).
zIndicates you are using Multi window (☞P. 62 “Multi
window”).
50 Before Using the Handset
Wi-Fi settings
If you use Wi-Fi function of the handset, you can use mail or
Internet by connecting to access points of your home,
corporate network or public wireless LAN service.
Radio interference with Bluetooth devices
zWireless LANs (IEEE 802.11b/g/n) use the same frequency
band (2.4 GHz) as Bluetooth devices. Therefore, using the
wireless LAN device near a Bluetooth device may cause radio
interference, lowering of communication speed, noise or
connection failure. In this case, turn off the Bluetooth device or
keep the handset and the wireless LAN device at least
approximately 10 m away from the Bluetooth device.
zPacket communication is also available while [Wi-Fi] is set to On.
Wi-Fi connection is prioritized while Wi-Fi connection is set, but
the connection is automatically switched to that of LTE/3G/GPRS
network once Wi-Fi connection is terminated. Note that packet
communication charges may be incurred in this case.
zRefer to the manual of your wireless LAN base unit when using
the access point at home etc.
zOperate access point registration near the access point.
1 In the home screen, [ ]▶[Settings]▶[Wi-Fi]
2 Set to On
3 Select an access point
zIf you select an access point protected by security, enter the
password (security key) and select [CONNECT].
zTo register access points manually: [Add network]▶enter the
network name▶set security▶[SAVE]
zWhen you select an access point and connect to it with a
wrong password (security key), [IP Configuration Failure], [WiFi
Connection Failure], [Authentication problem] or [Connected
(Limited)] is displayed. Confirm the password (security key).
When [IP Configuration Failure] or [Connected (Limited)] is
displayed after entering the correct password (security key),
you may not have acquired the correct IP address. Connect to
the access point again after confirming signal status.
zAs for the manual registration of an access point, this function
supports WEP, WPA/WPA2 PSK and 802.1xEAP as the security
setting.
zIf you connect to an access point which is not connected to the
Internet, [ ] is displayed and the communication may be
made by mobile networks, not Wi-Fi connection.
To make Wi-Fi communication by using such an access point,
enable [Using this AP without internet connection] of Advanced
options before connecting to the access point.
201
Appendix/Index
Specific Absorption Rate (SAR) of
Mobile Phones
This model SHV40 mobile phone complies with Japanese
technical regulations and international guidelines regarding
exposure to radio waves.
This mobile phone was designed in observance of Japanese
technical regulations regarding exposure to radio waves (*1) and
limits to exposure to radio waves recommended by a set of
equivalent international guidelines. This set of international
guidelines was set out by the International Commission on
Non-Ionizing Radiation Protection (ICNIRP), which is in
collaboration with the World Health Organization (WHO), and the
permissible limits include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health
condition.
The technical regulations and international guidelines set out limits
for radio waves as the Specific Absorption Rate, or SAR, which is
the value of absorbed energy in any 10 grams of tissue over a
6-minute period. The SAR limit for mobile phones is 2.0 W/kg. The
highest SAR value for this mobile phone when tested for use near
the head is ●●●● W/kg (*2) and when worn on the body is
This mobile phone can be used in positions other than against your
head. Please keep the mobile phone farther than 1.0 cm away
from your body by using such as a carrying case or a wearable
accessory without including any metals. This mobile phone satisfies
the technical regulations and international guidelines.
The World Health Organization has stated that “a large number of
studies have been performed over the last two decades to assess
whether mobile phones pose a potential health risk. To date, no
adverse health effects have been established as being caused by
mobile phone use.”
Please refer to the WHO website if you would like more detailed
information.
(
http://www.who.int/docstore/peh-emf/publications/facts_press/ fact_
english.htm
)
Please refer to the websites listed below if you would like more
detailed information regarding SAR.
Ministry of Internal Affairs and Communications Website:
（
http://www.tele.soumu.go.jp/e/sys/ele/index.htm
）
Association of Radio Industries and Businesses Website:
（
http://www.arib-emf.org/01denpa/denpa02-02.html
）
(in Japanese
only)
SHARP Corporation Website:
（
http://k-tai.sharp.co.jp/support/sar/ (in Japanese only)
）
*1 Technical regulations are defined by the Ministerial
Ordinance Related to Radio Law (Article 14-2 of Radio
Equipment Regulations).
●●●● W/kg (*3). There may be slight differences between the SAR
levels for each product, but they all satisfy the limit.
The actual SAR of this mobile phone while operating can be well
below that indicated above. This is due to automatic changes to
the power level of the device to ensure it only uses the minimum
required to reach the network. Therefore in general, the closer you
are to a base station, the lower the power output of the device.
●.●●●
●.●●●
202
Appendix/Index
*2 Including other radio systems that can be simultaneously
used with LTE/FOMA.
*3 Including other radio systems that can be simultaneously
used with LTE/FOMA.
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines were
developed by the independent scientific organization ICNIRP and
include safety margins designed to assure the protection of all
persons, regardless of age and health.
The guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is
2 W/kg and the highest SAR value for this device when tested at
the ear is 0.536 W/kg* and when worn on the body is 1.250 W/kg*.
For body-worn operation, this mobile device has been tested and
meets the RF exposure guidelines when used with an accessory
containing no metal and positioning the handset a minimum of 5
mm from the body. Use of other accessories may not ensure
compliance with RF exposure guidelines.
As SAR is measured utilizing the devices highest transmitting
power the actual SAR of this device while operating is typically
below that indicated above. This is due to automatic changes to the
power level of the device to ensure it only uses the minimum level
required to reach the network.
* The tests are carried out in accordance with international
guidelines for testing.
Regulatory information
* The following EU and EFTA member countries:
Belgium (BE), Bulgaria (BG), Czech Republic (CZ), Denmark
(DK), Germany (DE), Estonia (EE), Ireland (IE), Greece (EL),
Spain (ES), France (FR), Croatia (HR), Italy (IT), Cyprus (CY),
Latvia (LV), Lithuania (LT), Luxembourg (LU), Hungary (HU),
Malta (MT), Netherlands (NL), Austria (AT), Poland (PL),
Portugal (PT), Romania (RO), Slovenia (SI), Slovakia (SK),
Finland (FI), Sweden (SE) and United Kingdom (UK),
Switzerland (CH), Liechtenstein (LI), Iceland (IS), Norway (NO).
Norway: Use of this radio equipment is not allowed in the
geographical area within a radius of 20 km from the centre of
Ny-Alesund, Svalbard.
Hereby, SHARP CORPORATION declares that the radio equipment type
SHV40 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
(
http://www.sharp.co.jp/k-tai/
)
Manufacturer's Address:
SHARP CORPORATION,
1 Takumi-cho, Sakai-ku, Sakai-shi, Osaka 590-8522, Japan
203
Appendix/Index
zDescription of accessories
Headset, Handsfree Φ3.5 audio jack, Bluetooth.
USB cable For charging, peripherals, etc.
microSD Card microSD/microSDHC/microSDXC
nano UIM card
zFrequency range of supported bands in EU
GSM 900 Tx 880.2 to 914.8 MHz
Rx 925.2 to 959.8 MHz
DCS 1800 Tx 1710.2 to 1784.8 MHz
Rx 1805.2 to 1879.8 MHz
WCDMA FDD I Tx 1922.4 to 1977.6 MHz
Rx 2112.4 to 2167.6 MHz
LTE Band 1 Tx 1922.5 to 1977.5 MHz
Rx 2112.5 to 2167.5 MHz
LTE Band 3 Tx 1710.7 to 1784.3 MHz
Rx 1805.7 to 1879.3 MHz
Bluetooth Tx 2402 to 2480 MHz
Rx 2402 to 2480 MHz
WLAN 2.4 GHz Tx/Rx 2412 to 2472 MHz (BW: 20MHz only)
NFC Tx/Rx 13.56 MHz
GNSS GPS:
Rx L1 (1575.42 MHz)
GLONASS:
Rx G1(1598.0625 to 1605.375MHz)
au Nano IC Card 04/non-au Nano IC
Cards non-au Nano IC Cards can be
used after SIM-unlocking the handset.
WCDMA FDD VIIITx 882.4 to 912.6 MHz
Rx 927.4 to 957.6 MHz
LTE Band 8Tx 880.7 to 914.3 MHz
Rx 925.7 to 959.3 MHz
204
Appendix/Index
zMaximum transmit power
GSM 900 +33 dBm (Power Class4)
DCS 1800 +30 dBm (Power Class1)
WCDMA FDD I +24 dBm (Power Class3)
LTE Band 1 +23 dBm (Power Class3)
LTE Band 3 +23 dBm (Power Class3)
Bluetooth +7.3 dBm (Power Class1)
WLAN 2.4 GHz +14.0 dBm
NFC
Volume level caution
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
Earphone Signal Level
The maximum output voltage for the music player
function, measured in accordance with EN 50332-2, is
120.0mV.
FCC Notice
zThis device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
zChanges or modifications not expressly approved by the
manufacturer responsible for compliance could void the user's
authority to operate the equipment.
0 dBμA/m at 10 m
Battery - CAUTION
Use specified Charger only.
Non-specified equipment use may cause malfunctions, electric
shock or fire due to battery leakage, overheating or bursting.
The battery is embedded inside the product. Avoid removing the
embedded battery since this may cause overheating or bursting.
Do not dispose of the product with ordinary refuse. Take the product
to an au Shop, or follow the local disposal regulations.
Charge battery in ambient temperatures between 5°C and 35°C;
outside this range, battery may leak/overheat and performance
may deteriorate.
WCDMA FDD VIII +24 dBm (Power Class3)
LTE Band 8+23 dBm (Power Class3)
205
Appendix/Index
The exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg.
The tests are performed in positions and locations (e.g., at the ear
and worn on the body) as required by the FCC for each model.
The highest SAR value for this model handset when tested for use
at the ear is 0.55 W/kg and when worn on the body, as described
in this user guide, is 0.69 W/kg.
For body worn operation, this phone has been tested and meets
the FCC RF exposure guidelines. Please use an accessory
designated for this product or an accessory which contains no
metal and which positions the handset a minimum of 1.0 cm from
the body.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
The FCC has granted an Equipment Authorization for this model
handset with all reported SAR levels evaluated as in compliance
with the FCC RF emission guidelines. SAR information on this
model handset is on file with the FCC and can be found under the
Display Grant section of http://transition.fcc.gov/oet/ea/fccid/
）
after
searching on FCC ID APYHRO00252.
Additional information on Specific Absorption Rates (SAR) can be
found on the FCC website at
（
http://www.fcc.gov/encyclopedia/
radio-frequency-safety
）
.
）
FCC ID Location
The device is electronically labeled and the FCC ID can be
displayed via the About phone & the Authentication under the
Settings menu.
Information to User
This equipment has been tested and found to comply with the limits
of a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation; if this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
1. Reorient/relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for
help.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed the emission limits
for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The guidelines are based on standards that were developed by
independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health.
