AR-M230/M270 Series Online Manual
(for network printer)
Start
Start
Click this "Start" button.
2
CONTENTS INDEX
Introduction
This manual describes the printer function of the AR-M230/M270 series digital multifunctional system.
Trademark Acknowledgments
●Microsoft® Windows® operating system is a trademark or copyright of Microsoft Corporation in the U.S.A. and other countries.
●Windows® 95, Windows® 98, Windows® Me, Windows NT® 4.0, Windows® 2000, and Windows® XP are trademarks or copyrights
of Microsoft Corporation in the U.S.A. and other countries.
●Acrobat® Reader Copyright© 1987- 2002 Adobe Systems Incorporated. All rights reserved. Adobe, the Adobe logo, Acrobat, and
the Acrobat logo are trademarks of Adobe Systems Incorporated.
●Macintosh, Mac OS, AppleTalk, EtherTalk, LaserWriter, and TrueType are trademarks of Apple Computer, Inc.
●PCL is a trademark of the Hewlett-Packard Company.
●PostScript® is a registered trademark of Adobe Systems Incorporated.
●All other trademarks and copyrights are the property of their respective owners.
●For information on loading paper, replacing toner cartridges, clearing paper misfeeds, handling peripheral devices, and other
copier-related information, please refer to your operation manual for copier.
●The machine's default settings and default settings for the printer function can be changed using the key operator programs. For
more information, see the key operator's guide.
●Where "AR-XXXX" appears in this manual, please substitute the name of your model for "XXXX". For the name of your model,
see "PART NAMES AND FUNCTIONS" in the operation manual for copier.
●This manual refers to the Reversing single pass feeder as the "RSPF".
●The explanations of screens and procedures in this manual are primarily for Windows® XP in Windows® environments, and Mac
OS X v10.2 in Macintosh environments. The screens may vary in other versions of the operating systems.
●For information on using your operating system, refer to your operating system's manual or online Help.
●The PS3 expansion kit (AR-PK1) and print server card (AR-NC5J) mentioned in this manual are options.
The display screens, messages, and key names shown in the manual may differ from those on the actual machine due to product
improvements and modifications.
Note
3
CONTENTS INDEX
How to use the online manual
This section explains how to view the online manual. Please read this section before using the online manual.
For information on using Acrobat Reader, see Acrobat Reader Help.
How to Control the Online Manual
In this manual, the following buttons are displayed at the
bottom of each page. Click these buttons to move quickly to
pages that you wish to view.
Displays the Contents of this manual. Click on a topic in the
Contents to jump directly to that section.
Displays the Index of this manual. Click on a topic in the Index
to jump directly to that section.
Takes you forward page by page.
Takes you back page by page.
Following Links
This manual uses a link function that allows you to jump to a
related page. If you click green, underlined text, the related
page will be displayed. (In the Contents and Index sections, the
linked areas are not underlined.)
Example: ☞Contents
To return to the previous page, click the button on the menu
bar of Acrobat Reader.
Using Bookmarks
Bookmarks have been created on the left side of this manual.
You can click on a bookmark to jump directly to that section.
How to Print Out This Manual
To print this manual, select "Print" from the "File" menu of
Acrobat Reader. Select the desired printer settings in the "Print"
dialog box, and then click the "OK" button.
CONTENTS
INDEX
4
CONTENTS INDEX
Contents (part 1)
Introduction 2
How to use the online manual 3
Basic printing 6
●When "Paper Selection" is set to "Auto Select" 7
●
When the "Paper Selection" setting is "Paper Source" or "Paper Type"
8
●Auditing mode 9
●About the "No Offset" function setting 9
Opening the printer driver from the "start" button 10
Printer driver settings 11
Two-sided printing 12
●Pamphlet style 13
Printing multiple pages on one page 14
Fitting the printed image to the paper 15
Rotating the print image 180 degrees 16
Printing a watermark 17
●How to Print a Watermark 17
Stapling printed pages (when a finisher is installed) 18
●When a finisher is installed 18
●When a saddle stitch finisher is installed 19
Print hold function 20
Printing using the print hold function 21
●
Selecting print hold settings in the printer driver at the time of printing
21
●How to print a print hold job 22
●Points to note about the Print Hold function 23
Carbon copy print 24
Printing using carbon copy print 25
Printing text and lines in black 26
●Printing text in black 26
●Printing lines in black 26
Printer utilities 27
●Before using the Printer Status Monitor 27
Using the printer utilities 28
●Starting up the printer utilities 28
●Using the printer utilities 28
●Changing the Printer Status Monitor settings 29
●Checking the printer status 30
Basic printing 31
●When "Paper Feed" is set to "Auto Select" 33
●When "Paper Feed" is set to paper tray or paper type 34
Job control function (Mac OS 8.6 to 9.x and Max OS X v10.2)
35
●Printing when auditing mode is enabled 35
●Using the print hold function 35
1PRINTING FROM WINDOWS
2ADVANCED PRINTING (WINDOWS)
3PRINTER UTILITIES (WINDOWS)
4PRINTING FROM MACINTOSH
5
CONTENTS INDEX
Contents (part 2)
Giving priority to a print job / Canceling a print job 36
●Giving priority to a print job 36
●Canceling a print job 37
Configuring the printer condition settings 38
●How to configure the settings 38
●Printer condition setting menu 40
●Printer condition settings 41
Printing the printer setting and font lists 46
Troubleshooting 47
Printing does not take place 48
●Check the connections 48
●Check Your Computer 49
●Check the machine 50
●Checking the printer driver 51
Improper printing operation 52
●Printing is slow 52
●Two-sided printing is not possible 52
●
Stapling is not possible (when a finisher or a saddle stitch finisher is installed)
52
●
Punching is not possible (when a saddle stitch finisher is installed)
53
Print quality is not satisfactory 54
●Check the paper being used 54
●The printed image is coarse 55
●The printed image is distorted 55
●Part of the printed image is missing 55
If a notice page is printed 56
●Disabling notice page printing 57
Removing the software 58
●Windows 58
●Macintosh (Mac OS 8.6 to 9.x) 58
About the Web page 59
●Accessing the Web page 59
E-mail print function 61
●Setting up the E-mail print function 61
●Using the E-mail print function 62
Directly printing a file in a computer 63
E-mail status and e-mail alert settings 64
●Information setup 64
●SMTP setup 64
●Status message setup 65
●Alerts message setup 66
Protecting information programmed in the web page ("Passwords")
67
Printer specifications 68
5OPERATION AT THE MACHINE
6TROUBLESHOOTING
7WEB PAGE IN THE MACHINE
8SPECIFICATIONS
9INDEX
1PRINTING FROM WINDOWS
6
CONTENTS INDEX
Basic printing (part 1)
The following example explains how to print a document from WordPad.
Before printing, make sure that the correct size of paper for your document has been loaded in the machine.
1Make sure that the ON LINE indicator on the
operation panel is lit.
If the ON LINE indicator is not
on, press the [PRINT] key to
switch to printer mode and then
touch the [ONLINE] key.
The status of the printer function is indicated by the ON
LINE and DATA indicators next to the [PRINT] key.
2Start WordPad and open the document that you
wish to print.
3Select "Print" from the application's "File"
menu.
The "Print" dialog box will appear.
4Make sure that "SHARP AR-XXXX" is selected
as the printer. If you need to change any print
settings, click the "Preferences" button
("Properties" button in Windows 95/98/Me/NT
4.0) to open the printer driver setup screen.
The printer driver setup screen will appear.
Windows 2000 does not have the "Preferences" button
in this dialog box. Select settings as needed on each of
the tabs in the setup screen.
☞Printer driver settings,Two-sided printing,
Printing multiple pages on one page,
Fitting the printed image to the paper,
Rotating the print image 180 degrees,
Printing a watermark,
Stapling printed pages (when a finisher is installed)
ON LINE indicator DATA indicator
Lit The machine is online
and ready to print.
There is print data in
memory that has not
been printed yet.
Blinking —The machine is
printing.
Off The machine is offline
and not ready to print.
The machine is not
printing.
COPY
PRINT
SCAN
ON LINE
DATA
DATA
1PRINTING FROM WINDOWS
7
CONTENTS INDEX
Basic printing (part 2)
5Click the "Print" button ("OK" button in
Windows 95/98/Me/NT 4.0).
Printing begins. The print job is delivered to one of the
following trays (depending on which output devices are
installed):
●Job separator tray kit is installed: Upper tray
●Finisher is installed: Center tray
When "Paper Selection" is set to "Auto Select"
If "Paper Selection" is set to "Auto Select" in the "Paper" tab of
the printer driver setup screen and the correct size of paper for
a print job is not loaded in the machine, the printing procedure
will vary depending on the "FORCED OUTPUT OF PRINT"
setting in the key operator programs (see the key operator's
guide).
When "FORCED OUTPUT OF PRINT" is disabled
If the bypass tray can be used, a message prompting you to
print from the bypass tray will appear in the touch panel.
Press the [PRINT] key on the operation panel, touch the
[BYPASS TRAY] key, load paper in the bypass tray, and then
touch the [BYPASS] key. Printing will begin automatically.
When "FORCED OUTPUT OF PRINT" is enabled
Printing will take place using a size of paper that is close to the
size of the print image.
●The output tray can be selected in the key operator
programs (see "OUTPUT TRAYS" in the key
operator's guide).
●The output tray can also be selected in the print
settings at the time of printing. To change the tray
selection, select the desired tray in "Output" in the
"Paper" tab of the printer driver setup screen.
●Printing can be canceled in the job status screen.
☞Canceling a print job
●If the paper type setting in the printer driver is different
from the bypass tray's paper type setting in the
machine, printing may stop. To resume printing, press
the [PRINT] key on the operation panel, touch the
[BYPASS TRAY] key in the touch panel, and specify
the same paper type as in the printer driver.
Note
If the paper is loaded in a different orientation than the
print image, the image is automatically rotated to match
the paper. This setting can be changed in the key
operator programs (see "ROTATED PRINT" in the key
operator's guide).
Note
1PRINTING FROM WINDOWS
8
CONTENTS INDEX
Basic printing (part 3)
When the "Paper Selection" setting is "Paper Source" or "Paper Type"
When "Paper Selection" in the "Paper" tab of the printer driver
setup screen is set to:
●"Paper Source", select the tray that you wish to use for
printing from the pull-down menu.
●"Paper Type", select the type of paper that you wish to use
for printing from the pull-down menu.
If you selected the "Paper Source" or "Paper Type" in the
printer driver setup screen but there is no paper in the trays that
matches your selection, printing will take place as follows:
You selected a tray in "Paper Source", but the size
of the paper in the selected tray does not match
the printing size.
Even though the paper size is different, printing will take place
using the paper in the selected tray.
You selected a "Paper Type", and although the
selected type of paper is loaded in the machine, its
size does not match the printing size.
Even though the paper size is different, printing will take place
using the selected paper type.
However, if "FORCED OUTPUT OF PRINT" is disabled,
printing will not take place.
You selected a "Paper Type", but the selected type
of paper is not loaded in the machine.
If the bypass tray can be used, a message prompting you to
print from the bypass tray will appear. Press the [PRINT] key on
the operation panel, touch the [BYPASS TRAY] key, load the
correct size and type of paper in the bypass tray, and then
touch the [BYPASS] key. Printing will begin automatically.
"Paper Source" and "Paper Type" cannot be
simultaneously selected.
The size and type of paper loaded in each tray and whether or
not the paper loaded in each tray can be used for printing are
specified in the "TRAY SETTINGS" of the custom settings.
(See "CUSTOM SETTINGS" in the operation manual for
copier.)
If you wish to select the "Paper Source" or "Paper Type" when
printing, be sure to select these settings in the "Configuration"
tab of the printer driver setup screen. (See "CONFIGURING
THE PRINTER DRIVER" in the software setup guide.)
Note
1PRINTING FROM WINDOWS
9
CONTENTS INDEX
Basic printing (part 4)
Auditing mode
When "AUDITING MODE" is enabled in the key operator
programs, a 5-digit account number must be entered in the
printer driver setup screen in order to print. Account numbers
are stored in the key operator programs. (See "ACCOUNT
CONTROL" in the key operator's guide.)
To open the account number entry screen, click the "Job
Control" button in the "Main" tab of the printer driver.
Enter your 5-digit account number in "Account Number" and
click the "OK" button.
About the "No Offset" function setting
If the "No Offset" checkbox is selected in the "Main" tab of the printer driver setup screen, offset output will be prohibited regardless
of the setting of "OFFSET FUNCTION SETTING" in the key operator programs.
When stapling is performed (a setting other than "None" is selected in "Staple" in the "Main" tab), "No Offset" is automatically enabled
and the offset function cannot be used.
To have the job control screen automatically appear
each time you open the printer driver to print, select the
"Auto Job Control review" checkbox in the "Main" tab of
the printer driver setup screen.
●If "CANCEL JOBS OF INVALID ACCOUNTS" is
enabled in the key operator programs and printing is
attempted without entering an account number, or an
invalid account number is entered, printing will not take
place. To allow printing without the entry of a valid
account number, disable "CANCEL JOBS OF
INVALID ACCOUNTS". In this case, the number of
pages printed is added to the [OTHERS] count.
●If the machine's PPD file is used with the Windows
standard PS printer driver, auditing mode will be
disabled and print counts will not be kept for each
account.
Note
Caution
1PRINTING FROM WINDOWS
10
CONTENTS INDEX
Opening the printer driver from the "start" button
Printer driver settings can be configured by opening the printer driver from the Windows "start" button. Settings adjusted in this way
will be the initial settings when you print from an application. (If you change the settings in the printer driver setup screen at the time
of printing, the settings will revert to the initial settings when you quit the application.)
Windows 2000/XP
1Click the "start" button, and then click "Control
Panel".
In Windows 2000, click the "Start" button and select
"Settings".
2Click "Printers and Other Hardware", and then
click "Printers and Faxes".
In Windows 2000, click "Printers".
3Click the "SHARP AR-XXXX" printer driver icon
and select "Properties" from the "File" menu.
4Click the "Printing Preferences" button in the
"General" tab.
The printer driver setup screen will appear.
☞Printer driver settings
Windows 95/98/Me/NT 4.0
1Click the "Start" button, select "Settings" and
then click "Printers".
2Click the "SHARP AR-XXXX" printer driver icon
and select "Properties" from the "File" menu.
3In Windows 95/98/Me, click the "Setup" tab.
The printer driver setup screen will appear.
☞Printer driver settings
In Windows NT 4.0, select "Document Defaults" to open
the printer driver setup screen.
Note
1PRINTING FROM WINDOWS
11
CONTENTS INDEX
Printer driver settings
To view Help for a setting, click the button in the upper right-hand corner of the window and then click the setting.
Some restrictions exist on the combinations of settings that can be selected in the printer driver setup screen. When a restriction is
in effect, an information icon ( ) will appear next to the setting. Click the icon to view an explanation of the restriction.
Tab
The settings are grouped
on tabs. Click on a tab to
bring it to the front.
Check button
Allows you to select one
item from a list of options.
Print setting image
This shows the effect of the
selected print settings.
Drop-down list
Allows you to make a
selection from a list of
choices.
Machine image
This shows:
●
The paper tray (in blue)
selected in "Paper selection"
on the "Paper" tab.
●
The output tray (in green)
selected in "Output" on the
"Paper" tab.
You can also click on a tray
to select it.
Checkbox
Click on a checkbox to
activate or deactivate a
function.
"OK" button
Click this button to save
your settings and exit the
dialog box.
"Cancel" button
Click this button to exit the
dialog box without making
any changes to the
settings.
"Apply" button
Click to save your settings
without closing the dialog box.
●Windows NT 4.0 does not
have the "Apply" button.
●The "Apply" button does
not appear when you
open this window from an
application.
"Help" button
Click this button to display
the help file for the printer
driver.
1
3
2
4
5
6
7
8
9
10
The settings and the image of the machine will vary
depending on the model.
Note
1
2
3
4
5
6
7
8
9
10
1PRINTING FROM WINDOWS
12
CONTENTS INDEX
Two-sided printing (part 1)
This feature allows you to print on both sides of the paper.
To use this function, open the printer driver setup screen and select "2-Sided (Book)" or
"2-Sided (Tablet)" from "Document Style" in the "Main" tab.
☞See Basic printing for details on how to open the printer driver.
The following example shows the result when portrait data is printed on both sides of the paper.
●Paper sizes that can be used for two-sided printing are Ledger, Letter, Letter-R, Legal, A3, A4, A4R, A5, B4, B5, B5R, and
Foolscap.
●Paper types that can be used for two-sided printing are Plain, Letter Head*, Recycled and Color.
* The use of Letter Head paper for two-sided printing can be prohibited in the "TRAY SETTINGS" of the custom settings. (See
"CUSTOM SETTINGS" in the operation manual for copier.)
●
Two-sided printing is not possible if disabled in the key operator programs (see "DISABLING OF DUPLEX" in the key operator's guide).
Print data Printing result
2-Sided (Book) 2-Sided (Tablet)
The pages are printed so that
they can be bound at the side.
The pages are printed so that
they can be bound at the top.
Note
1PRINTING FROM WINDOWS
13
CONTENTS INDEX
Two-sided printing (part 2)
Pamphlet style
Pamphlet style prints two pages each on the front and back of each sheet of paper (four pages total on
one sheet) so that the sheets can be folded down the center and bound to create a pamphlet. This
function is convenient when you wish to compile printed pages into a pamphlet.
To use this function, open the printer driver and select "Tiled Pamphlet" or "2-Up Pamphlet" in
"Document Style" in the "Main" tab.
The binding edge (left side or right side) can be selected in the "Binding Edge" in the "Main" tab. The
following examples show how 8 pages are printed when pamphlet style is selected.
Print data Printing result
Left Right
●Because four pages are printed on each sheet of paper, blank pages are automatically added at the end when the total number
of pages is not a multiple of four.
●When "Tiled Pamphlet" is selected, printing will take place on paper that is twice the size of the paper size specified in the
application.
●When "2-Up Pamphlet" is selected, each page is reduced in the same way as for 2-Up and printed on the size of paper that is
specified in the application.
●When a saddle stitch finisher is installed and "2 Staples" in "Staple" in the "Main" tab is selected, the output is stapled and folded at
the center to form a pamphlet.
●The saddle stitch tray can hold up to 20 sets when the number of sheets is 1 to 5, or 10 sets when the number of sheets is 6 to 10.
●Paper sizes that can be used for saddle stitching are Ledger, Letter-R, A3, A4R, B4, 8K, and 16KR.
Note
1PRINTING FROM WINDOWS
14
CONTENTS INDEX
Printing multiple pages on one page
This feature allows you to reduce and print two, four, six, eight or sixteen document pages on a single sheet of paper.
To use this function, open the printer driver setup screen and select the number of pages per sheet (2-Up, 4-Up, 6-Up, 8-Up, or
16-Up) in "N-Up Printing" in the "Main" tab.
The order of the pages can be changed in the "Order" menu.
☞See Basic printing for details on how to open the printer driver.
For example, when "2-Up" or "4-Up" is selected, the result will be as follows depending on the selected order.
If you select the "Border" checkbox, borderlines will be printed around each page.
The "N-Up Printing" setting is not available when "Fit To Paper Size" is selected.
☞Fitting the printed image to the paper
N-Up Left to Right Right to Left
[2-Up]
N-Up
Right , and Down Down , and Right
Left , and Down Down , and Left
[4-Up]
Examples for 2-Up and 4-Up are shown here. The order of 6-Up, 8-Up, and 16-Up is the same as 4-Up. The order can be viewed
in the print setting image in the printer driver setup screen.
☞Printer driver settings
Note
Note
1PRINTING FROM WINDOWS
15
CONTENTS INDEX
Fitting the printed image to the paper
The printer driver can adjust the size of the printed image to match the size of the paper loaded in the machine.
Follow the steps shown below to use this function. The explanation below assumes that you intend to print a Ledger size document
on letter size paper.
☞See Basic printing for details on how to open the printer driver.
1Click the "Paper" tab in the printer driver setup
screen.
2Select the original size (Ledger) of the print
image in "Paper Size".
3Check the "Fit To Page" box.
When using the PS printer driver, select "Fit To Paper
Size" in "Zoom Setting".
4Select the actual size of paper to be used for
printing (Letter).
The size of the printed image will be automatically
adjusted to match the paper loaded in the machine.
The "Fit To Paper Size" setting is not available when "N-Up Printing" is selected.
☞Printing multiple pages on one page
Note
Paper Size: Ledger
Fit To Paper Size: Letter
Ledger size document
(Paper Size)
Letter size paper
(Fit To Paper Size)
When using the PS printer driver, the print image can be
enlarged or reduced by means of numerical values. (The
vertical and horizontal ratios can be set separately.)
Select "XY-Zoom" in step 3, click the "Width/Length"
button, and adjust the ratios in the screen that appears.
Note
1PRINTING FROM WINDOWS
16
CONTENTS INDEX
Rotating the print image 180 degrees
The print image can be rotated 180 degrees.
This feature is used to enable correct printing on envelopes and other paper with flaps that can
only be loaded in one orientation.
Use this feature when automatic rotation (which takes place when the loaded paper is the same
size as the print image and the orientations are different) results in reversal of the top and bottom
of the image.
To use the feature, select the image orientation in "Image Orientation" on the "Paper" tab, and
then select the "Rotate 180 degrees" checkbox.
☞See Basic printing for details on how to open the printer driver.
Printing result
Rotate 180 degrees Rotate 180 degrees
The procedure for loading paper is explained in operation manual for copier.
ABCD
ABCD
Note
1PRINTING FROM WINDOWS
17
CONTENTS INDEX
Printing a watermark
You can print a watermark such as "CONFIDENTIAL" on your document. To print a watermark, open the printer driver, click the
"Watermarks" tab, and follow the steps below.
☞See Basic printing for details on how to open the printer driver.
How to Print a Watermark
From the "Watermark" drop-down list, select the watermark that you wish to print (for example "CONFIDENTIAL"), and start printing.
You can enter text to create your own custom watermark. For details on watermark settings, view printer driver Help.
☞Printer driver settings
Print sample
1PRINTING FROM WINDOWS
18
CONTENTS INDEX
Stapling printed pages (when a finisher is installed)
(part 1)
When a finisher is installed, printed pages can be stapled.
To use this feature, open the printer driver setup screen and select it in the "Finishing"
field of the "Main" tab.
☞See Basic printing for details on how to open the printer driver.
When a finisher is installed
The following example shows how portrait oriented pages are stapled together.
●The maximum number of sheets that can be stapled is 30. When a saddle stitch finisher is installed, up to 50 sheets can be stapled
(up to 25 sheets when the paper size is B4, Foolscap, or larger).
●Paper sizes that can be used for staple printing are Ledger, Letter, Letter-R, Legal, A3, A4, A4R, B4, B5, B5R, and Foolscap. (B5R
can only be used when a saddle stitch finisher is installed.)
●Paper types that can be used for staple printing are Plain, Letter Head, Recycled and Color.
●
Staple printing is not possible when the ROPM function is disabled. (See "CONFIGURING THE PRINTER DRIVER" in the software setup guide.)
●If the finisher is disabled in the key operator programs, the staple and punch functions cannot be used and output cannot be
delivered to the offset tray.
●Stapling is not possible if disabled in the key operator programs (see "DISABLING OF STAPLER" in the key operator's guide).
●The staple function cannot be used in combination with the "No offset" function.
Print data Printing result
The pages are stapled in the upper left-hand corner.
Note
1PRINTING FROM WINDOWS
19
CONTENTS INDEX
Stapling printed pages (when a finisher is installed)
(part 2)
When a saddle stitch finisher is installed
When a saddle stitch finisher is installed, the binding edge and number of staples can be selected to produce the following printing results:
Punch function
When a punch module is installed on a saddle stitch finisher,
the "Punch" checkbox can be selected to punch holes in the
printed output.
Select the punch hole positions in "Binding Edge".
Staple Left Right Top
1 Staple
2 Staples
Left Right Top
●The number of holes that can be punched and the spacing between the holes varies depending on the installed punch module.
●Paper sizes that can be punched vary depending on the punch module installed.
●Paper types that can be punched are Plain, Recycled, Color, Letter Head, and Heavy paper.
Note
2ADVANCED PRINTING (WINDOWS)
20
CONTENTS INDEX
Print hold function
A print job sent to the machine can be held in the machine's memory until the operator initiates printing from the operation panel of
the machine. This is called the Print Hold function.
There are four methods for holding print jobs with the Print Hold function.
Hold After Print Hold Before Print
When this method is selected, the print job is printed and then
retained in the machine's print hold job list. The job can be printed
again as needed from the operation panel of the machine.
When this method is used, the print job is held in the machine's print hold
job list without being printed. The operator can initiate printing from the
operation panel of the machine as needed. This helps prevent print jobs
from being misplaced.
Proof Print PIN (5-digit ID number)
When this method is selected, one set of copies is printed and then
the job is held in the machine's print hold job list.
The operator can check the copies to make sure that the image
position, stapling position, and other aspects of the job are
satisfactory, and then initiate printing of all sets from the operation
panel of the machine. (The initial proof set is included in the total
number of copies.)
If the proof copies are not satisfactory, the job can be canceled.
This prevents excessive misprints when printing a large number of
copies.
A PIN number can be set that must be entered at the machine's operation
panel in order to print a "Hold After Print", "Hold Before Print", or "Proof
Print" job. (☞Printing using the print hold function)
This helps maintain confidentiality when printing sensitive documents.
When a PIN number is set for "Hold After Print":
The PIN number must be entered at the operation panel to print the job
again after the initial printing.
When a PIN number is set for "Hold Before Print":
The PIN number must be entered at the operation panel to print the job.
When a PIN number is set for "Proof Print":
Following the initial printing of one set of proof copies, the PIN number must
be entered at the operation panel to print the remaining sets of copies.
●The machine can hold a maximum of 100 print hold jobs. If 100 jobs are exceeded or the memory that can be used for print hold
becomes full, no more print hold jobs will be accepted, an error will appear in the touch panel, or a Notice Page will be printed.
●Memory allocated to the print hold function can be changed in the key operator programs. (See "MEMORY FOR PRINTER" in the
key operator's guide.)
Note
2ADVANCED PRINTING (WINDOWS)
21
CONTENTS INDEX
Printing using the print hold function
(part 1)
Selecting print hold settings in the printer driver at the time of printing
Select the Print Hold function in the job control screen (see below), which is opened by clicking the
"Job Control" button in the "Main" tab of the printer driver setup screen.
☞Basic printing
"Retention" menu
Select the Print Hold method that you wish to use. After
selecting "Hold After Print", "Hold Before Print", or "Proof
Print", a PIN number can be set if desired. To set a PIN
number, enter a 5-digit number in "PIN".
☞Print hold function
"Notify Job End" checkbox
Select this checkbox if you wish to be notified when printing
is finished.
This function can only be used when the Printer Status
Monitor is running. If the Printer Status Monitor is not
running, selecting the checkbox will have no effect.
"Default Job ID" menu
Enter a default user name and job name. These names
appear in the operation panel of the machine.
The user name can be up to 16 characters long and the job
name can be up to 30 characters long.
To always use the entered names, select "Always Use This
User Name" and "Always Use This Job Name". If "Always
Use This User Name" is not selected, your Windows login
name will automatically be used. If "Always Use This Job
Name" is not selected, the file name used in the application
will automatically be used.
When you have completed the above settings, click the
"OK" button to close the window and begin printing.
To print the job from the operation panel of the machine, see
"How to print a print hold job".
1
2
3
1
2
3
2ADVANCED PRINTING (WINDOWS)
22
CONTENTS INDEX
Printing using the print hold function
(part 2)
How to print a print hold job
When you print a job using the Print Hold function, the job is stored in the print hold job list in the initial screen of printer mode. Follow
the steps below to print the print hold job.
1Press the [PRINT] key to switch to the initial
screen of printer mode.
2Select the job that you wish to print.
You can touch the or
key to change screens.
3If you set a PIN number in the printer driver,
press the numeric keys to enter the 5-digit
number.
The PIN number must be
entered to print the job. (If you
did not set a PIN number, this
step is not necessary.)
As you enter each digit, "-"
changes to " ".
4Make sure that the desired number of copies is
set.
To change the number of
copies, touch the or key.
COPY
PRINT
SCAN
ON LINE
DATA
DATA
SHARP001
PRINT HOLD JOB LIST
SHARP001 Microsoft Word -
Microsoft PowerP
product_infomati
cost.xls
SHARP002
SHARP003
SHARP004
LIST
ENTER PIN VIA THE 10-KEY.
cost.xls
CANCEL
NUMBER OF PRINTS
2ADVANCED PRINTING (WINDOWS)
23
CONTENTS INDEX
Printing using the print hold function
(part 3)
5Touch the [PRINT AND DELETE THE DATA] key or
the [PRINT AND SAVE THE DATA] key.
To delete the job after printing,
touch the [PRINT AND DELETE
THE DATA] key. To retain the job,
touch the [PRINT AND SAVE
THE DATA] key.
6Printing begins.
If another print job is already in progress, the job is stored.
The job will be printed when all previous jobs are finished.
Points to note about the Print Hold function
●The print hold function can only be used when ROPM is enabled.
●If a Notice page is printed or an error appears in the print job complete screen when you execute printing at your computer, there
are already 100 print hold jobs or the machine's memory is full. Delete any unnecessary print hold jobs and then try printing again.
☞How to print a print hold job
●The amount of memory allocated to the print hold function can be changed in the key operator programs. (See "MEMORY FOR
PRINTER" in the key operator's guide.)
If memory full errors frequently occur, it is recommended that additional memory be installed in the machine.
●Turning off the machine's power switch will erase the print hold jobs stored in the machine.
To delete a job without printing it, touch the [DELETE]
key.
PRINT AND DELETE THE DATA
CANCEL
PRINT AND SAVE THE DATA
DELETE
product_information.pdf
Note
2ADVANCED PRINTING (WINDOWS)
24
CONTENTS INDEX
Carbon copy print
Carbon copy print is used to print copies of the same page on different types of paper. Each paper type is loaded in a different tray,
and the different paper types must all be the same size.
For example, carbon copy print can be performed with standard paper in tray 1 and colored paper in tray 2 for output as an invoice
original and copy. As another example, standard paper can be loaded in tray 1 and recycled paper can be loaded in tray 2 to create
an original for presentation and a copy to be retained.
When carbon copy print is used to print a two-page job with two copies per page, "Collate" can be selected in the "Main" tab to
obtain the following print results.
Print data Printing result (when number of copies is "2")
Collate Collate
Load different types of the same size of paper in trays 1, 2, and
3, and specify tray 1 as the "Top Copy" and trays 2 and 3 as the
carbon copy trays.
☞Printing using carbon copy print
The copies are collated. The copies are grouped by page.
12
11
10
9
8
76
5
4
3
2
1
12
11
10
9
8
76
5
3
2
1
4
2ADVANCED PRINTING (WINDOWS)
25
CONTENTS INDEX
Printing using carbon copy print
To use the carbon copy print function, select the "Carbon Copy" checkbox in the "Paper" tab of the
printer driver setup screen, and then click the "Carbon Copy Settings" button to configure print
settings.
"Top Copy" menu
Select the tray that will be used for the original.
"Carbon Copy" menu
Select the tray or trays that will be used for the carbon
copies.
Be sure to select only trays that have the same size of paper
as the "Top Copy".
When you have completed the above settings, click the "OK" button to close the window and then execute printing.
1
2
●The tray selected as the "Top Copy" cannot be
selected.
●
If a tray with a size of paper different from the "Top
Copy" is selected, the paper in that tray will not be used.
1
2
Note
●Carbon copy print is not possible when two-sided printing, pamphlet style, or staple printing is selected.
●The bypass tray cannot be used for carbon copy printing.
Note
2ADVANCED PRINTING (WINDOWS)
26
CONTENTS INDEX
Printing text and lines in black
Color text and lines that are faint when printed normally can be printed in black to improve legibility.
Printing text in black
Text that is any color other than white is printed in black.
To use this function, open the printer driver setup screen and
select the "Text To Black" checkbox in the "Advanced" tab.
Printing lines in black
Lines and solids that are any color other than white are printed
in black.
To use this function, open the printer driver setup screen and
select the "Vector To Black" checkbox in the "Advanced" tab.
Print data Printing result
Text To Black Text To Black
●When using the PCL6 printer driver, if "Print as
graphics" is selected in "TrueType Mode" of "Font" in
the "Advanced" tab, this function cannot be used.
●When using the PCL5e printer driver, if "Raster" is
selected in "Graphics mode" in the "Advanced" tab,
this function cannot be used.
ABCD
EFGH
ABCD
EFGH
ABCD
EFGH
Note
Print data Printing result
Vector To Black Vector To Black
When using the PCL6 or PCL5e printer driver, if "Raster"
is selected in "Graphics mode" in the "Advanced" tab,
this function cannot be used.
Note
3PRINTER UTILITIES (WINDOWS)
27
CONTENTS INDEX
Printer utilities
The "Software" CD-ROM contains the following two printer
utilities.
Printer Status Monitor (for general users)
This allows the user to check on the computer screen whether
or not the machine is able to print.
It provides information on error states such as paper misfeeds
and shows the configuration of the machine (number of trays,
whether or not there is a finisher, etc.) by means of illustrations.
Available paper sizes and paper remaining are also indicated.
Printer Administration Utility (for administrators)
This allows the administrator to check information on supplies
and error states of the machine and other SHARP printers
(compatible with the Printer Administration Utility) that are
connected to the network. Settings can also be changed via the
utility.
Before using the Printer Status Monitor
Note the following points before using the Printer Status
Monitor.
Printing via a server
When the first print job is executed after starting up the Printer
Status Monitor, the machine's IP address is automatically set in
the Printer Status Monitor.
Direct printing without a server
Install and configure the software as explained in "USING THE
MACHINE AS A NETWORK PRINTER" in the software setup
guide for network printer. (This is not necessary if the software
has already been installed and configured.)
●In order to use the Printer Status Monitor and Printer
Administration Utility, the machine must be connected
to a network.
●To install the Printer Status Monitor and Printer
Administration Utility, see software setup guide for
network printer.
●To use the Printer Administration Utility in Windows 95,
a system file must be updated. See the detailed
information in the select packages window of the
installer (see the software setup guide for network
printer).
Note
3PRINTER UTILITIES (WINDOWS)
28
CONTENTS INDEX
Using the printer utilities (part 1)
Starting up the printer utilities
If the Printer Status Monitor or Printer Administration Utility is
not running, use the following procedure to start the utilities.
Printer Status Monitor
Click the "Start" button, point to "All Programs" ("Programs" in
operating systems other than Windows XP) and then "SHARP
Printer Status Monitor". Select "Printer Status Monitor".
Printer Administration Utility
Click the "Start" button, point to "All Programs" ("Programs" in
operating systems other than Windows XP) and then "SHARP
Printer Administration Utility". Select "Printer Administration
Utility".
Using the printer utilities
For information on using the Printer Status Monitor and Printer
Administration Utility, see the Help files for each. The Help files
can be viewed as follows:
Printer Status Monitor
Click the "Start" button, point to "All Programs" ("Programs" in
operating systems other than Windows XP) and then "SHARP
Printer Status Monitor". Select "Help".
Printer Administration Utility
Click the "Start" button, point to "All Programs" ("Programs" in
operating systems other than Windows XP) and then "SHARP
Printer Administration Utility". Select "Help".
When the Printer Administration Utility is first started up,
the TCP/IP settings window appears. To monitor the
machine on a local network, select the "Local Subnet
Search" checkbox. Otherwise, enter the machine's IP
address. For more information, see the Help file.
Note
3PRINTER UTILITIES (WINDOWS)
29
CONTENTS INDEX
Using the printer utilities (part 2)
Changing the Printer Status Monitor settings
Once installed, the Printer Status Monitor normally runs in the background in Windows. If you need to change the Printer Status
Monitor settings, follow the steps below.
1Right-click the Printer Status Monitor icon ( )
on the task bar, and select "Preferences" from
the pop-up menu.
2
Change the Printer Status Monitor settings as desired.
For information on the Printer Status Monitor settings,
see Printer Status Monitor Help. (Click the "Help" button
in the settings window.)
If the Printer Status Monitor icon does not appear on the
task bar, see "Starting up the printer utilities" to start the
Printer Status Monitor.
Note
3PRINTER UTILITIES (WINDOWS)
30
CONTENTS INDEX
Using the printer utilities (part 3)
Checking the printer status
The Printer Status Monitor allows you to check whether or not toner and paper remain in the machine.
1Right-click the Printer Status Monitor icon ( )
on the task bar, and select "SHARP AR-XXXX
Status" from the pop-up menu.
2Click the "Detail" button.
The window expands to show machine status details.
To collapse the window, click the "Hide detail" button.
The icon turns red when printing is not possible due to a
machine error or other problem.
Note
By default, the collapsed window initially appears when
"SHARP AR-XXXX Status" is selected in Step 1. If
desired, you can change the setting to have the
expanded window initially appear.
☞Changing the Printer Status Monitor settings
Note
4PRINTING FROM MACINTOSH
31
CONTENTS INDEX
Basic printing (part 1)
To use the machine as a printer for the Macintosh, the print server card (AR-NC5J) and the PS3 expansion kit must be installed and
the machine must be connected to a network. To install the PPD file and configure the printer driver settings, see the software setup
guide for network printer.
Before printing, make sure that the correct size of paper for your document has been loaded in the machine.
1Make sure that the ON LINE indicator on the
operation panel is lit.
If the ON LINE indicator is not
on, press the [PRINT] key to
switch to printer mode and then
touch the [ONLINE] key.
The status of the printer function is indicated by the ON
LINE and DATA indicators next to the [PRINT] key.
2Start the application and open the document
that you wish to print.
3Select "Print" from the application's "File"
menu.
4Make sure that the correct printer is selected.
ON LINE indicator DATA indicator
Lit The machine is online
and ready to print.
There is print data in
memory that has not
been printed yet.
Blinking —The machine is
printing.
Off The machine is offline
and not ready to print.
The machine is not
printing.
COPY
PRINT
SCAN
ON LINE
DATA
DATA
●The machine name that appears in the "Printer:" menu
is the name that was entered when AppleTalk settings
were configured from the CD-ROM for the print server
card. Unless the name was changed when configuring
the settings, it will be "SCxxxxxx" (where "xxxxxx" is a
sequence of characters that varies depending on your
machine).
●The Print window varies depending on the operating
system version, the printer driver version, and the
application.
Note
4PRINTING FROM MACINTOSH
32
CONTENTS INDEX
Basic printing (part 2)
5Configure print settings.
Click next to "Copies &
Pages" ("General" in Mac OS
8.6 to 9) and select the settings
that you wish to configure from
the pull-down menu. The
corresponding setting screen
will appear.
6Click the "Print" button .
Printing begins. The print job is delivered to one of the
following trays (depending on which output devices are
installed):
●Job separator tray kit is installed: Upper tray
●Finisher is installed: Center tray
The settings vary depending on the operating system
version, the printer driver version, and the application.
Note
●The output tray can be selected in the key operator
programs (see "OUTPUT TRAYS" in the key
operator's guide).
●The output tray can be selected when selecting print
settings at the time of printing. Select the output tray in
"Output" in the "Advanced" menu of the Print window.
●If you are using Mac OS 8.6 to 9.x, select the output
tray in "Output" in the "Output/Document Style"
menu of the Print window.
●
If you are using Mac OS X v10.1 to 10.1.5, select the
output tray in the "Output" tab in the "Printer
Features" menu of the Print Window.
●If the paper type setting in the printer driver is different
from the bypass tray's paper type setting in the
machine, printing may stop. To resume printing, press
the [PRINT] key on the operation panel, touch the
[BYPASS TRAY] key in the touch panel, and specify
the same paper type as in the printer driver.
Note
4PRINTING FROM MACINTOSH
33
CONTENTS INDEX
Basic printing (part 3)
When "Paper Feed" is set to "Auto Select"
If "Paper Feed" is set to "Auto Select" in the Print window and
the correct size of paper is not loaded in the machine, the
printing method will vary depending on the "FORCED OUTPUT
OF PRINT" setting in the key operator programs (see the key
operator's guide).
When "FORCED OUTPUT OF PRINT" is disabled
If the bypass tray can be used, a message prompting you to
print from the bypass tray will appear in the touch panel.
Press the [PRINT] key on the operation panel, touch the
[BYPASS TRAY] key, load paper in the bypass tray, and then
touch the [BYPASS] key. Printing will begin automatically.
When "FORCED OUTPUT OF PRINT" is enabled
Printing will take place using a size of paper that is close to the
size of the print image.
In Mac OS 8.6 to 9.x, the "Paper Feed" setting is
configured in "Paper Source" in the "General" menu of
the Print window.
Note
If the paper is loaded in a different orientation than the
print image, the image is automatically rotated to match
the paper. This setting can be changed in the key
operator programs (see "ROTATED PRINT" in the key
operator's guide).
Note
4PRINTING FROM MACINTOSH
34
CONTENTS INDEX
Basic printing (part 4)
When "Paper Feed" is set to paper tray or paper type
If "Paper Feed" (or "Paper Source" in "General" in Mac OS 8.6 to 9.x) is set to paper tray or paper type in the Print window but there
is no paper in the trays that matches your selection, printing will take place as follows:
You selected a tray, but the size of the paper in the selected tray does not match the printing size.
Even though the paper size is different, printing will take place using the paper in the selected tray.
You selected a paper type, and although the selected type of paper is loaded in the machine, its size does not
match the printing size.
Even though the paper size is different, printing will take place using the selected paper type.
However, if "FORCED OUTPUT OF PRINT" is disabled, printing will not take place.
You selected a paper type, but the selected type of paper is not loaded in the machine.
If the bypass tray can be used, a message prompting you to print from the bypass tray will appear. Press the [PRINT] key on the
operation panel, touch the [BYPASS TRAY] key, load the correct size and type of paper in the bypass tray, and then touch the [BYPASS]
key. Printing will begin automatically.
The size and type of paper loaded in each tray and whether or not the paper loaded in each tray can be used for printing are
specified in the "TRAY SETTINGS" of the custom settings. (See "CUSTOM SETTINGS" in the operation manual for copier.
4PRINTING FROM MACINTOSH
35
CONTENTS INDEX
Job control function (Mac OS 8.6 to 9.x and Max OS X v10.2)
Printing when auditing mode is enabled
When "AUDITING MODE" is enabled in the key operator
programs, enter your 5-digit account number in "Account
Number" in the "Job Control" menu of the Print window.
Using the print hold function
The print hold function is enabled in "Job Control" in the Print
window.
Select the function that you wish to use in the "Retention" menu.
For information on the print hold function, see "Print hold function".
To print a print hold job at the machine, see "How to print a print hold job".
●In Mac OS 8.6 to 9.x, select "On" in "Account Number"
in "Job Control" in the Print window, and enter your
5-digit account number in the box at right.
●Account numbers are stored in the key operator
programs. (See "ACCOUNT CONTROL" in the key
operator's guide.)
●
When auditing mode is enabled, a print job may not be
printed if an account number is not entered or an
incorrect account number is entered. This depends on
the key operator program settings. See "CANCEL JOBS
OF INVALID ACCOUNTS" in the key operator's guide.
●
In Mac OS X v10.1 to 10.1.5, auditing mode cannot be
used. For this reason, do not enable "CANCEL JOBS
OF INVALID ACCOUNTS" in the key operator programs
because printing will not be possible. (Printed pages will
be added to the "OTHERS" count.)
Note
Caution
●To assign a PIN number to a print job, enter a 5-digit
number in "PIN". (In Mac OS 8.6 to 9.x, select "On" in
"Confidential Print Password" and enter a 5-digit
number in the box at right.)
●In Mac OS X v10.1 to 10.1.5, the print hold function
cannot be used.
Note
5OPERATION AT THE MACHINE
36
CONTENTS INDEX
Giving priority to a print job / Canceling a print job
(part 1)
Giving priority to a print job
When a print job is waiting because the machine is copying or printing a received fax, the following procedure can be used to
interrupt the current job and immediately print the print job. Use the print job status screen to give priority to the job. For more
information on using the job status screen, see operation manual for copier.
1Press the [JOB STATUS] key.
2Make sure that the [PRINT JOB] key is
highlighted.
The print job status screen
appears when the [PRINT JOB]
key is highlighted.
If the [PRINT JOB] key is not
highlighted, touch the [PRINT
JOB] key.
3In the job keys of the jobs waiting to be printed,
touch the key of the job that you wish to print
immediately.
The touched key is highlighted.
4Touch the [PRIORITY] key.
A message appears asking you
to confirm the priority print job.
Touch the [OK] key to interrupt
the current job and begin
printing the print job selected in
Step 3.
FAX
DATA
LINE
JOB STATUS
CUSTOM SETTING
SHARP001
PRINT JOB
010 / 00
To view information on a print job, select it and then
touch the [DETAIL] key.
X JOB
DETAIL
PRIORITY
STOP/DELETE
ITING
ITING
Note
5OPERATION AT THE MACHINE
37
CONTENTS INDEX
Giving priority to a print job / Canceling a print job
(part 2)
Canceling a print job
A print job in progress or waiting to be printed can be canceled. Use the print job status screen to cancel the job.
1Press the [JOB STATUS] key.
2Make sure that the [PRINT JOB] key is
highlighted.
The print job status screen
appears when the [PRINT JOB]
key is highlighted.
If the [PRINT JOB] key is not
highlighted, touch the [PRINT
JOB] key.
3The job in progress and the jobs waiting to be
printed appear. Touch the key of the job that
you wish to cancel.
The touched key is highlighted.
4Touch the [STOP/DELETE] key.
A message appears asking you
to confirm the cancellation.
Touch the [YES] key to delete
the job.
If you do not wish to cancel the
job, touch the [NO] key.
FAX
DATA
LINE
JOB STATUS
CUSTOM SETTING
SHARP001
PRINT JOB
010 / 00
To pause a print job during printing, press the [PRINT]
key on the operation panel and then touch the
[OFFLINE] key. ([OFFLINE] is highlighted.)
•To cancel a print job, press the [CLEAR] key ( ).
•To resume printing, touch the [ONLINE] key to switch
the machine online.
X JOB
DETAIL
PRIORITY
STOP/DELETE
ITING
ITING
Note
5OPERATION AT THE MACHINE
38
CONTENTS INDEX
Configuring the printer condition settings
(part 1)
The printer condition settings allow basic printer settings to be configured. The following items can be set:
●DEFAULT SETTINGS: Basic settings used in printing.
●PCL SETTINGS: PCL symbol set, font, line feed code, and
other settings.
●PostScript SETTINGS*: Sets whether a PostScript error
page is printed or not when a
PostScript error occurs.
*Appears when the PS3 expansion kit is installed.
How to configure the settings
1Press the [PRINT] key.
The initial screen of printer
mode appears.
2Touch the [CONDITION SETTINGS] key.
Any print jobs that have
already been sent to the
machine, including print hold
jobs stored in the machine,
will be printed using the
printer condition settings that
were effect when the job was
sent.
3Touch the key of the desired item to display its
setting screen.
For information on each of the settings, see "Printer
condition settings".
When the printer condition settings and the printer driver settings do not agree, the printer driver settings take precedence. Print
settings that can be selected in the printer driver should be selected in the printer driver at the time of printing.
Note
COPY
PRINT
SCAN
ON LINE
DATA
DATA
ONLINE
OFFLINE
BYPASS TRAY
CONDITION
SETTINGS
DELETE
1/1
CONDITION SETTINGS
DEFAULT SETTINGS
EXIT
PostScript SETTINGS
PCL SETTINGS
5OPERATION AT THE MACHINE
39
CONTENTS INDEX
Configuring the printer condition settings
(part 2)
4Touch the desired setting on the setting screen
of the desired item and touch the [OK] key.
To set another item, repeat steps 3 and 4.
5When finished, touch the [EXIT] key.
More information on the condition setting screen
When a checkbox ( ) appears in front of a setting, a checkmark ( ) will appear when the checkbox is touched.
This indicates that the setting is enabled. If a checkbox with a checkmark ( ) is touched, the checkmark is cleared ( ) and the
setting is disabled.
When a key that appears in the form is touched, the setting screen of that key will appear.
If the settings continue on the following screen(s), touch the and keys to move back and forth through the screens. To
return to the category selection screen, touch the [OK] key.
The currently set numerical value is displayed.
Numerical values can be set by touching the and keys.
OK
1/4
P
1
DEFAULT SETTINGS
TONER SAVE
COPIES
ORIENTATION
CONDITION SETTINGS
DEFAULT SETTINGS
EXIT
PostScript SETTINGS
PCL SETTINGS
OK
1/4
P
1
DEFAULT SETTINGS
TONER SAVE
COPIES
ORIENTATION
1
(1 999)
1
23
4 5
The following keys appear in screens that
require the entry of numerical values.
1
2X X X
3
4
5
5OPERATION AT THE MACHINE
40
CONTENTS INDEX
Configuring the printer condition settings
(part 3)
Printer condition setting menu
Click on a setting to view an explanation of the setting.
CONDITION SETTINGS
DEFAULT SETTINGS Factory default settings
TONER SAVE Disabled
COPIES 1
ORIENTATION PORTRAIT
DEFAULT PAPER SIZE 8 ½ x 11
DEFAULT PAPER SOURCE AUTO
DEFAULT PAPER TYPE AUTO
SMOOTHING Disabled
RESOLUTION 600dpi
EXTRA PRINT MODE Disabled
2-SIDE PRINT 1-SIDED
PAGE PROTECTION Enabled
ROPM Disabled
CONDITION SETTINGS
PCL SETTINGS Factory default settings
PCL SYMBOL SET
SETTING 3 (PC-8)
PCL FONT SETTINGS INTERNAL FONT: 0
(Courier)
LINE FEED CODE 0
WIDE A4 Disabled
PostScript SETTINGS* Factory default settings
PRINT PS ERRORS Disabled
* Appears when the PS3 expansion kit is installed.
You can view the current printer condition settings by printing the "PRINTER SETTINGS LIST" in "LIST PRINT" in the custom
settings.
☞Printing the printer setting and font lists
Note
5OPERATION AT THE MACHINE
41
CONTENTS INDEX
Configuring the printer condition settings
(part 4)
Printer condition settings
Factory default settings are indicated in bold.
DEFAULT SETTINGS
(continued)
Item Selections Description
TONER SAVE Enabled, Disabled (no
checkmark)
This enables or disables toner save mode. Toner save mode conserves toner
by printing a slightly lighter image. Toner save mode does not function when
the resolution is set to 1200 dpi.
COPIES 1 - 999 This is used to select the number of copies.
ORIENTATION PORTRAIT,
LANDSCAPE
This sets the orientation of the printed page. Select "PORTRAIT" when the
image is longer in the vertical direction, or "LANDSCAPE" when the image is
longer in the horizontal direction.
DEFAULT PAPER
SIZE
5 ½ x 8 ½, 8 ½ x 11, 8
½ x 13, 8 ½ x 14, 11 x
17, A5, B5, A4, B4, A3
This sets the default paper size used for the printed image. Even if the set size
of paper is not in any of the trays, the printed image is formed in accordance
with this setting.
DEFAULT PAPER
SOURCE
AUTO,
BYPASS (MANUAL),
BYPASS (AUTO),
TRAY 1,
TRAY 2,
TRAY 3*,
TRAY 4*
Set the default paper tray. When set to "AUTO", the paper tray with the size of
paper set in "DEFAULT PAPER SIZE" is automatically selected.
*Selections available depend on the trays that are installed.
DEFAULT PAPER
TYPE
AUTO, PLAIN,
RECYCLED, LETTER
HEAD, COLOR
This is used to select the default paper type. When set to "AUTO", the paper
tray with the size of paper set in "DEFAULT PAPER SIZE" is automatically
selected.
5OPERATION AT THE MACHINE
42
CONTENTS INDEX
Configuring the printer condition settings
(part 5)
(continued)
Item Selections Description
SMOOTHING Enabled, Disabled (no
checkmark)
This enables or disables smoothing. This function improves image quality by
smoothing angles and curves in the image. When smoothing is enabled using
a resolution of 600 dpi, an image quality equivalent to 1200 dpi can be
obtained. (Printing at 1200 dpi provides high image quality, however, this uses
considerable memory and slows the printing speed. Smoothing cannot be
selected when the resolution is 1200 dpi.) When printing a bitmap image,
disabling smoothing may in some circumstances provide a better result.
RESOLUTION 300dpi, 600dpi,
1200dpi
This sets the resolution for printing. When 1200 dpi is selected, smoothing and
toner save cannot be selected. A resolution of 1200 dpi uses considerable
memory and therefore slows the printing speed.
EXTRA PRINT MODE Enabled, Disabled (no
checkmark)
When mostly single-page jobs are printed, this function can be used to increase
printing efficiency by shortening the wait time between print jobs. Normally this
function is not enabled.
When the function is enabled (a checkmark appears), multiple print jobs are
processed as a single job when all of the jobs have the same print format. The
jobs appear as a single job key in the job status screen.
When print hold, staple printing, different paper setting ("Last Page" only), or
transparency inserts is selected in the printer driver, EXTRA PRINT MODE
does not function. EXTRA PRINT MODE also does not function if the paper
size or other print format setting is changed or a notice page is printed due to
a memory error.
Print processing efficiency increases when this mode is used, and for this
reason notification that the job is finished may not appear at the same time as
completion of output of the printed pages. In addition, special print processing
may prevent the appropriate appearance of notification that the job is finished.
5OPERATION AT THE MACHINE
43
CONTENTS INDEX
Configuring the printer condition settings
(part 6)
Item Selections Description
2-SIDE PRINT 1-SIDED,
2-SIDED (Book),
2-SIDED (Tablet)
When "2-SIDED (Book)" is selected, two-sided printing takes place so as to
allow binding at the left side. When "2-SIDED (Tablet)" is selected, two-sided
printing takes place so as to allow binding at the top.
PAGE PROTECTION Enabled (
checkmark
appears
), Disabled
This enables page protection. Page protection prevents data loss errors when
printing complex jobs.
ROPM Enabled, Disabled (no
checkmark)
This enables the ROPM function. When enabled, multi-page print jobs are
stored in memory before printing, and thus the computer does not need to
repeatedly send the print data when multiple copies are printed.
5OPERATION AT THE MACHINE
44
CONTENTS INDEX
Configuring the printer condition settings
(part 7)
PCL SETTINGS
Item Selections Description
PCL SYMBOL SET
SETTING
1 - 35 This specifies which country's characters (PCL symbol set) are assigned to
certain of the symbols in the character code list. The factory default setting is
"3" (PC-8). The numbers corresponding to each PCL symbol set can be viewed
by printing "PCL SYMBOL SET LIST" in "LIST PRINT" in the custom settings.
☞Printing the printer setting and font lists
PCL FONT SETTINGS INTERNAL FONT (0 -
80), EXTENDED FONT
(1 - )
This specifies which PCL font to use for printing. One font can be specified from
among the internal fonts and extended fonts (when the barcode font kit is
installed). The factory default setting is "0" (internal font: Courier).
The fonts that are available can be viewed by printing the font list in "LIST
PRINT" in the custom settings. The font names, numbers assigned to each
font, and print samples appear in the list. A font is specified for PCL FONT
SETTINGS by entering the number assigned to the font.
☞Printing the printer setting and font lists
LINE FEED CODE 0 - 3 This specifies the line break code by means of a combination of the "CR"
(return) code, "LF" (line break) code, and "FF" (page break) code. The factory
default setting is printing based on the transmitted code. The setting can be
changed by selecting one of four combinations.
WIDE A4 Enabled, Disabled (no
checkmark)
This setting can be enabled to print 80 lines on A4 size paper with each line
10CPI font (English characters). When the setting is disabled (a checkmark
does not appear), each line is 78 characters long.
5OPERATION AT THE MACHINE
45
CONTENTS INDEX
Configuring the printer condition settings
(part 8)
PostScript SETTINGS
"PostScript SETTINGS" only appears when the PS3 expansion kit is installed.
Item Selections Description
PRINT PS ERRORS Enabled, Disabled (no
checkmark)
When this setting is enabled, an error description is printed each time a
PostScript error occurs.
5OPERATION AT THE MACHINE
46
CONTENTS INDEX
Printing the printer setting and font lists
To check the current printer condition settings or fonts that can be used, print the printer setting list or one of the font lists.
1Press the [CUSTOM SETTINGS] key.
2Touch the [LIST PRINT] key.
3Touch the [PRINTER TEST PAGE] key.
4Touch the list that you wish to print.
Printing begins.
The following lists can be printed.
●PRINTER SETTINGS LIST
●PCL SYMBOL SET LIST
●PCL INTERNAL FONT LIST
●PCL EXTENDED FONT LIST (When an option font kit
is installed.)
●PS INTERNAL FONT LIST (When the PS3 expansion
kit is installed.)
●NIC PAGE
DATA
LINE
B STATUS
CUSTOM SETTINGS
Y
T
S
LIST PRINT
RECEIVE MODE
SENDING ADDRESS LIST
FAX REPORT
PRINTER TEST PAGE
TTINGS
EST PAGE
PRINTER
SETTINGS LIST
PCL SYMBOL
SET LIST
PCL EXTENDED
FONT LIST
PS INTERNAL
FONT LIST
6TROUBLESHOOTING
47
CONTENTS INDEX
Troubleshooting
This chapter describes how to solve printer problems. Refer to the relevant section based on the problem.
To load paper, remove paper misfeeds, load staples in the finisher, remove jammed staples, or replace the toner cartridge, see
"TROUBLESHOOTING" in operation manual for copier.
Printing does not take place
●Check the connections
●USB or parallel connection in Windows
●Network connection
●Check Your Computer
●Points to check in Windows
●Points to check on the Macintosh
●Check the machine
●Checking the printer driver
●Points to check in Windows
Improper printing operation
●Printing is slow
●Two-sided printing is not possible
●Stapling is not possible (when a finisher or a saddle stitch finisher
is installed)
●Punching is not possible (when a saddle stitch finisher is installed)
Print quality is not satisfactory
●Check the paper being used
●The printed image is coarse
●The printed image is distorted
●Part of the printed image is missing
If a notice page is printed
Removing the software
●Windows
●Macintosh (Mac OS 8.6 to 9.x)
6TROUBLESHOOTING
48
CONTENTS INDEX
Printing does not take place (part 1)
Check the connections
USB or parallel connection in Windows
■
■■
■Is the interface cable compatible with the machine
and computer?
Interface cables compatible with this machine are USB and
parallel cables. Check which type of cable is supported by
your computer.
For the specifications of the interface cable, see
"CONNECTING TO A COMPUTER" in the software setup
guide for network printer.
■
■■
■Is the interface cable connected securely?
Check if the interface cable is securely plugged into the
connectors of the machine and computer.
To connect the cable, see "CONNECTING TO A COMPUTER"
in the software setup guide for network printer.
■
■■
■Are any other USB peripherals being connected
along with the machine?
If your computer is connected to the machine through a USB
hub, see if printing is possible when no other USB devices
are connected, or if printing is possible when the machine
and computer are directly connected.
■
■■
■If the interface cable becomes disconnected
If the interface cable becomes disconnected, even only once
during the machine's operation, then printing may be disrupted.
If this occurs, check the interface cable and ensure that it is
securely connected, then restart the computer.
Network connection
■
■■
■Is the LAN cable disconnected?
Make sure that the LAN cable is firmly inserted in the
connectors on the machine and the computer.
For information on connecting the LAN cable, see software
setup guide for network printer.
■
■■
■Is the machine configured for use on the same
network as the computer?
The machine cannot be used if it is not connected to the
same network as the computer, or if it is not configured for
use on the network.
For more information, consult your network administrator.
6TROUBLESHOOTING
49
CONTENTS INDEX
Printing does not take place (part 2)
Check Your Computer
■
■■
■
Is there enough computer memory or hard disk space?
To use the machine, your computer must have sufficient
memory and hard disk space. If there is insufficient hard disk
space, delete unnecessary files to increase the free space of
the hard disk. If there is insufficient memory, close unnecessary
applications to increase memory available for printing.
Points to check in Windows
■
■■
■If your computer is connected to the machine
through the parallel port, is the parallel port (LPT)
mode set to other than EPP mode? (when using a
parallel connection in Windows)
The machine may not operate correctly if the parallel port
mode is set to EPP mode. To set the parallel port mode to a
mode other than EPP mode, refer to your computer manual
or ask the manufacturer of the computer. ECP mode is
recommended to obtain the best performance from the
machine. Note that some computers may use different
names for the modes.
Points to check on the Macintosh
■
■■
■Is AppleTalk enabled?
In Mac OS X, click "Network" in "System Preferences" and
select "Built-in Ethernet" in "Show". Click the "AppleTalk" tab
and make sure that "Make AppleTalk Active" is selected.
In Mac OS 8.6 to 9.x, open the "Chooser" from the Apple
menu and make sure that "Active" is selected. Printing is not
possible if "Active" is not selected.
■
■■
■Is "Ethernet" selected for the "Connect via" of
AppleTalk? (When using Mac OS 8.6 to 9.x.)
Open "AppleTalk" from the "Control Panels" and make sure
that "Ethernet" is selected in the "Connect via" menu.
Printing is not possible if "Ethernet" is not selected.
If you are using Windows XP, the "Found New Hardware
Wizard" may appear after you change the port setting. In
this case, click the "Cancel" button to close the wizard,
and then reinstall the printer driver as explained in
"USING THE MACHINE WITH A PARALLEL OR USB
CONNECTION" in the software setup guide for network
printer.
Note
6TROUBLESHOOTING
50
CONTENTS INDEX
Printing does not take place (part 3)
Check the machine
■
■■
■Power switch on?
Turn the power switch on. (See "POWER ON AND OFF" in
the operation manual for copier)
■
■■
■Is the machine online?
When the ON LINE indicator next to the [PRINT] key on the
operation panel is lit, the machine is online and ready to
print. If the ON LINE indicator is off, press the [PRINT] key
and then touch the [ONLINE] key. (When [ONLINE] is
highlighted, the machine is online.)
■
■■
■
Has an error occurred such as a paper misfeed, staple
jam in the finisher, out of paper, or out of toner?
When one of the above errors occurs, a message will appear
in the touch panel to alert you.
Follow the instructions in the message to clear the error.
Printing will automatically resume when the error is cleared.
For information on handling errors, see "TROUBLESHOOTING"
in operation manual for copier.
■
■■
■Copy job being performed?
Wait until copying is finished. You can also select the key of
the job that you wish to print in the job status screen and then
touch the [PRIORITY] key. Copying will be interrupted and
the selected job printed.
☞Giving priority to a print job
■
■■
■Is the "I/O TIMEOUT" setting too short?
Set a longer time for "I/O TIMEOUT" in the key operator
programs.
If a Notice Page is printed, see "If a notice page is printed".
ONLINE
OFFLINE
BYPASS TRAY
CONDITION
SETTINGS
1/1
COPY
PRINT
SCAN
ON LINE
DATA
DATA
6TROUBLESHOOTING
51
CONTENTS INDEX
Printing does not take place (part 4)
Checking the printer driver
■
■■
■Is your machine selected correctly in the current
application for the print job?
Select the printer driver of the machine in the print settings
window of the application.
●If the printer drivers appear as icons, click the icon of the
machine.
●If the printer drivers are selected from a pull-down menu,
select the printer driver of the machine from the menu.
☞Windows: Basic printing
☞Macintosh: Basic printing
Points to check in Windows
■
■■
■Has the printer driver been installed properly?
Follow the steps below to make sure that the printer driver is
installed correctly.
1 Click the "start" button, click "Control Panel", click
"Printers and Other Hardware", and then click
"Printers and Faxes".
On Windows 95/98/Me/NT 4.0/2000, click the "Start" button,
select "Settings" and then click "Printers".
2 Check if the "SHARP AR-XXXX" printer driver icon
is shown.
If the printer icon of the machine does not appear, the printer
driver is not installed correctly. Follow the instructions in the
software setup guide for network printer to correctly install the
printer driver.
■
■■
■Is the port configured correctly?
It is possible that there is a problem with the port
configuration, for example another printer driver may be
using the port. Open the printer driver properties and
correctly configure the port that you are using.
☞See the software setup guide for network printer.
If for some reason the printer driver does not operate
correctly, delete the printer driver and then reinstall it as
explained in the software setup guide for network printer.
☞Removing the software
6TROUBLESHOOTING
52
CONTENTS INDEX
Improper printing operation (part 1)
Printing is slow
■
■■
■Simultaneous use of two or more application
software programs?
Start printing after quitting all unused application software
programs.
■
■■
■Is an appropriate print quality selected in the printer
driver?
It takes longer to process the print data when
"SMOOTHING" is enabled or the resolution is set to 1200
dpi, and this may slow the printing speed. Be sure to select
print quality settings that are appropriate for the image being
printed.
Windows: Change the print quality settings in the "Advanced"
tab of the printer driver setup screen.
Macintosh: Change the print quality settings in the
"Advanced" menu in the Print window. (In Mac
OS X v10.1 to 10.1.5, change the print quality
settings in the "Advanced" tab of the "Printer
Features" menu.)
Two-sided printing is not possible
■
■■
■Is two-sided printing disabled in the key operator
programs?
Enable two-sided printing as explained in "DISABLING OF
DUPLEX" in the key operator's guide.
Stapling is not possible (when a finisher or
a saddle stitch finisher is installed)
■
■■
■Is stapling disabled in the key operator programs?
Enable stapling in the key operator programs (see
"DISABLING OF STAPLER" in the key operator's guide).
■
■■
■Is the finisher disabled in the key operator programs
(when a saddle stitch finisher is installed)?
Enable the finisher in the key operator programs. (See "USING
THE KEY OPERATOR PROGRAMS" in the operation manual
for the saddle stitch finisher, and "DISABLING OF STAPLER"
in the key operator's guide.)
■
■■
■Did you attempt to print more pages than can be
stapled?
When a finisher is installed, up to 30 sheets can be stapled.
When a saddle stitch finisher is installed, up to 50 sheets can
be stapled (up to 25 sheets when the paper size is B4,
Foolscap, or larger).
The saddle stitch tray can hold up to 20 sets when the
number of sheets is 1 to 5, or 10 sets when the number of
sheets is 6 to 10.
■
■■
■Are pages of different width mixed together in the
print job?
Stapling is not possible when pages of different width are
mixed together in a print job.
6TROUBLESHOOTING
53
CONTENTS INDEX
Improper printing operation (part 2)
■
■■
■
Does the print job include page sizes that cannot be
stapled?
Stapling is not possible if the print job includes page sizes that
cannot be stapled.
■
■■
■Is the paper tray that is selected in the printer driver
set to a paper size or paper type that cannot be used
for stapling?
On the machine, set the paper tray to be used for staple
printing to a paper size and paper type that can be used for
stapling.
Punching is not possible (when a saddle
stitch finisher is installed)
■
■■
■Is the finisher disabled in the key operator
programs?
Enable the finisher in the key operator programs. (See "USING
THE KEY OPERATOR PROGRAMS" in the operation manual
for the saddle stitch finisher, and "DISABLING OF STAPLER"
in the key operator's guide.)
■
■■
■Are pages of different width mixed together in the
print job?
Punching is not possible when pages of different width are
mixed together in a print job.
■
■■
■Does the print job include page sizes that cannot be
punched?
Punching is not possible if the print job includes page sizes that
cannot be punched.
■
■■
■Is the paper tray that is selected in the printer driver
set to a paper size or paper type that cannot be used
for punching?
On the machine, set the paper tray to be used for punch
printing to a paper size and paper type that can be used for
punching.
6TROUBLESHOOTING
54
CONTENTS INDEX
Print quality is not satisfactory (part 1)
Check the paper being used
■
■■
■Non-standard paper used?
Check that the paper conforms to the specifications. Refer to
"LOADING PAPER" in the operation manual for copier.
■
■■
■Are you using paper with a high moisture content?
Use paper that is in good condition, with a low moisture
content and no curling.
■
■■
■Is the paper loaded with the wrong side up?
Some types of paper have a front and a back side. If the
paper is loaded so that printing takes place on the back side,
toner will not adhere well to the paper and poor print quality
will result.
■
■■
■Are you printing on paper that has an uneven
surface?
It may not be possible to print correctly on paper with seams
such as the back of an envelope.
6TROUBLESHOOTING
55
CONTENTS INDEX
Print quality is not satisfactory (part 2)
The printed image is coarse
■
■■
■Have the printer driver settings been specified to
suit both paper and the print job?
The printing resolution can be set to 1200 dpi, 600 dpi, or 300
dpi. When 600 dpi or 300 dpi is selected, "SMOOTHING" can
also be selected to improve the image quality.
Windows: Change the resolution settings in the "Advanced"
tab of the printer driver setup screen.
Macintosh: Change the resolution settings in the "Advanced"
menu in the Print window. (In Mac OS X v10.1 to
10.1.5, change the resolution settings in the
"Advanced" tab of the "Printer Features" menu.)
The printed image is distorted
■
■■
■Is the paper loaded correctly?
If a document is physically damaged when it is output or the
image is skewed on the paper, discard the damaged sheet,
reinsert the paper and print again. Insert the paper so that
there is no visible space between the paper and the paper
guides.
☞See the operation manual for copier for more details on
inserting paper.
Part of the printed image is missing
■
■■
■Did you set sufficient margins in the paper settings
of your application?
Printing is not possible at the edges of the paper. The print
margins are 5/32" (4 mm) at the top and bottom of the paper
and 1/8" (3 mm) at the sides of the paper. When configuring the
paper settings in the software application, be sure to establish
margins that are at least as large as the print margins.
■
■■
■Does the paper size set for the print image match the
size of paper loaded in the machine?
Make sure that the paper size setting matches the size of
paper loaded in the machine. When "Auto Select" is selected
for the paper source in the print settings, the print method will
vary depending on the settings of the key operator programs.
☞Windows: When "Paper Selection" is set to "Auto Select"
☞Macintosh: When "Paper Feed" is set to "Auto Select"
■
■■
■Are the print orientation settings correct?
Make sure that the correct paper orientation is selected for
the print image in the application's paper settings and in the
print settings.
If the paper is loaded in the machine in a different orientation
from the print image, the image is normally automatically
rotated to match the paper; however, if this function has been
disabled in the key operator programs, the paper orientation
must be set in the application. (See "ROTATED PRINT" in
the key operator's guide.)
●A slower printing speed may result when 1200 dpi or
"SMOOTHING" is selected.
●
For the available resolution settings, see "Printer specifications".
Note
6TROUBLESHOOTING
56
CONTENTS INDEX
If a notice page is printed (part 1)
If you find that a notice page has been printed at the end of a print job, the print data received from the computer has not been
printed as specified. Fix the problem as explained below and then try printing again.
Notice Page regarding memory full on IMC board
●When the Staple function is not selected:
Disable the ROPM function by removing the checkmark from
"ROPM" in the "Configuration" tab of the printer driver setup
screen. (See "CONFIGURING THE PRINTER DRIVER" in the
software setup guide for network printer.) If you need to use the
ROPM function, lower the resolution setting in the printer driver
or install more memory.
●When the Staple function is selected:
Lower the resolution setting or increase the "MEMORY FOR
PRINTER" setting in the key operator programs. If this does not
resolve the problem, install more memory.
When data loss error has occurred:
•Set the page protection function or enable the ROPM function.
To enable the ROPM function, select the "ROPM" checkbox in
the "Configuration" tab of the printer driver setup screen. (See
"CONFIGURING THE PRINTER DRIVER" in the software
setup guide for network printer.)
☞PAGE PROTECTION
****************************************************
Notice Page
****************************************************
The IMC memory full error had occurred,
a normal output was not able to be executed.
Please refer to the operation manual for
the solution method.
The IMC memory is used to store print data when the
ROPM function is used. This memory is also used to
store original image data in the copy mode. The
percentage of IMC memory allocated to the printer
function can be adjusted using a key operator program.
See "MEMORY FOR PRINTER" in the key operator's
guide. The memory can be extended by adding
commercially available memory modules. For details,
contact your SHARP dealer.
****************************************************
Notice Page
****************************************************
The data loss error had occurred, a normal
output was not able to be executed.
Please refer to the operation manual for
the solution method.
Note
6TROUBLESHOOTING
57
CONTENTS INDEX
If a notice page is printed (part 2)
Notice Page regarding memory full on the printer
board
●If the ROPM function has been disabled, enable it.
●Clear download fonts or form overlay data in the printer driver
settings.
●Add memory to the printer board. For information on
additional memory, contact your SHARP dealer.
●Check the memory setting in the "Configuration" tab in the
printer driver settings.
Disabling notice page printing
Notice page printing can be disabled using a key operator
program (see "PROHIBIT NOTICE PAGE PRINTING" in the
key operator's guide).
****************************************************
Notice Page
****************************************************
The memory full error had occurred, a normal
output was not able to be executed.
Please refer to the operation manual for
the solution method.
6TROUBLESHOOTING
58
CONTENTS INDEX
Removing the software
In the event that you need to remove the printer driver or utilities, follow these steps:
Windows
1Click the "start" button, and then click "Control
Panel".
On Windows 95/98/Me/NT 4.0/2000, click the "Start"
button, select "Settings", and then click "Control Panel".
2Click "Add or Remove Programs".
On Windows 95/98/Me/NT 4.0/2000, double-click the
"Add/Remove Programs" icon.
3Select the driver or utility that you wish to
remove from the list, and click the appropriate
button to remove it.
For more information, refer to your operating manual or
to the help files for your operating system.
4Restart your computer.
Macintosh (Mac OS 8.6 to 9.x)
1Insert the "Software" CD-ROM into your
CD-ROM drive.
2Double-click the CD-ROM icon ( ) on the
desktop and double-click the "Mac OS" folder.
3Double-click the "Installer" icon ( ).
4Select "Remove" from the Install menu and then
click the "Remove" button.
There is no remove tool for Mac OS X. The PPD file for
Mac OS X has been copied to the following folder in the
startup disk:
[Library] - [Printers] - [PPDs] - [Contents] - [Resources] -
[En.lproj] folder
Note
When reinstalling the software, install it correctly as explained in software setup guide for network printer.
Note
7WEB PAGE IN THE MACHINE
59
CONTENTS INDEX
About the Web page (part 1)
When the machine is connected to a network, you can access the machine's settings from your computer using a Web browser. The
settings will appear in a Web page in your browser, and you can configure the machine's E-mail server settings in the Web page to
have the machine receive e-mail and automatically print out attached files, as well as automatically send e-mail to the administrator
of the machine and/or the dealer which provides information on machine use (print count, copy count, etc.) and error conditions
(paper misfeed, out of paper, out of toner, etc.).
To use these functions, the machine must be able to connect to the Internet and the recipient of the messages must have a Web
browser (Microsoft Internet Explorer 5.5 or later, or an equivalent Web browser) and an SMTP-compatible e-mail software program.
Accessing the Web page
Use the following procedure to access the Web page.
1Open the Web browser on your computer.
Supported browsers:
Internet Explorer 5.5 or later (Windows)/
5.1 or later (Macintosh)
Netscape Navigator 6.0 or later
2In the "Address" field of your Web browser,
enter the IP address of the machine as a URL.
Enter the IP address previously
configured in the machine.
To check the machine's IP
address, print "NIC PAGE" as
explained in "Printing the printer
setting and font lists".
When the connection is completed, the following Web
page will appear in your Web browser.
☞About the Web page
7WEB PAGE IN THE MACHINE
60
CONTENTS INDEX
About the Web page (part 2)
When you access the Web page in the machine, the following page will appear in your browser.
A menu frame appears on the left side of the page. When you click an item in the menu, a screen appears in the right frame that
allows you to establish settings for that item.
For detailed explanations of the procedures for establishing settings, click [Help] in the menu frame.
Submit Print Job setup
A file in a computer can be printed out.
☞Directly printing a file in a computer
Information setup
Configure machine identification information for the status &
alert E-mail function.
☞Information setup
Password setup
Establish administrator's and user's passwords. The
administrator of this software can set passwords (for
administrator and user) to authorize access to the Web page for
the security of the settings on the page. If such a security
measure is not required, the Password Setting procedure can be
skipped. This will leave Web access settings open to all users.
☞
Protecting information programmed in the web page ("Passwords")
Status Message setup
Configure parameters required for sending status messages,
such as destination addresses and time schedules.
☞Status message setup
Alerts Message setup
Configure parameters required for sending alert messages,
such as destination addresses and types of event for which
messages are sent.
☞Alerts message setup
Services Setup
Configure information concerning the e-mail system.
☞SMTP setup
2
4
3
1
5
6
1
2
3
4
5
6
7WEB PAGE IN THE MACHINE
61
CONTENTS INDEX
E-mail print function (part 1)
An e-mail account can be set up for the machine. When this is done, the machine will periodically check the e-mail server for e-mail
and automatically print out any file attachments it receives. This provides a means for printing a file from a computer that does not
have the printer driver installed, as the user can simply send the file to the machine as an e-mail attachment.
Setting up the E-mail print function
To use the e-mail print function, the machine must have an
e-mail account.
1In the link menu, click [Direct Print].
The "Direct Print Setup" screen
will appear.
2Configure the required e-mail settings.
For more information, click [Help] in the menu frame.
3Click [Submit] to store the entered data.
7WEB PAGE IN THE MACHINE
62
CONTENTS INDEX
E-mail print function (part 2)
Using the E-mail print function
To use the e-mail print function, attach the file that you wish to print to an e-mail message and send the e-mail to the machine's
e-mail address.
The machine can print the following file types:
PCLXL, PCL5e, PS, PDF, and TIFF, with file extensions pcl, ps, pdf, tiff, and tif
Control commands can be entered in the message of the e-mail to specify the number of copies and print format. Commands are
entered in the format "command name = value".
The following control commands are available:
Function Command name Value Entry example
Copies COPIES 1-999 COPIES=2
Staple JOBSTAPLE STAPLENO, STAPLELEFT JOBSTAPLE=STAPLENO
Two-sided print DUPLEX OFF, TOP, LEFT DUPLEX=LEFT
Account number ACCOUNTNUMBER 5-digit number
ACCOUNTNUMBER=11111
File type LANGUAGE AUTO, PCL, PCLXL, POSTSCRIPT, PDF, TIFF LANGUAGE=TIFF
Paper PAPER Name of available paper (LETTER, etc.) PAPER=A4
●Enter the commands in Plain Text format. If entered in Rich Text format (HTML), the commands will have no effect.
●To receive a list of the control commands, enter the command "Config" in the e-mail message.
●If an e-mail is sent with nothing entered in the message, printing will take place according to the "DEFAULT SETTINGS" in the
condition settings menu of printer mode in the machine.
●To print PS files and PDF files, the PS3 expansion kit must be installed.
●Encrypted PDF files cannot be printed.
●Only enter a "File type" when you are specifying a page-description language. Normally there is no need to enter a file type.
Note
7WEB PAGE IN THE MACHINE
63
CONTENTS INDEX
Directly printing a file in a computer
A file that can be accessed by your computer can be directly printed without using the printer driver by specifying the file's address.
Any file that can be accessed by your computer can be printed by this method, including not only files in your computer but files in
other computers connected to the same network.
To directly print a file by this method, click "Submit Print Job" in the menu frame of the Web page.
1In the link menu, click [Submit Print Job].
The "Submit Print Job" screen
will appear.
2Select the print format in "Job Detail".
For more information, click [Help] in the menu frame.
3Enter the address of the file in "Enter Filename".
You can also click [Browse] to look for the file.
For more information, click [Help] in the menu frame.
4Click [Print].
Printing begins.
7WEB PAGE IN THE MACHINE
64
CONTENTS INDEX
E-mail status and e-mail alert settings
(part 1)
These functions send information on machine use (print count, copy count, etc.) and error conditions (paper misfeed, out of paper,
out of toner, etc.) via e-mail to the administrator of the machine or the dealer.
Information setup
Machine identification information for the status & alert E-mail
function is configured in the "Information Setup" screen. The
entered information will be included in status & alert E-mail
messages.
1In the link menu, click [Information].
The "Information Setup" screen
will appear.
2Enter the machine information.
For more information, click [Help] in the menu frame.
3Click [Submit] to store the entered information.
SMTP setup
The Status & Alert E-mail function uses SMTP (Simple Mail
Transport Protocol) to send e-mail. The following procedure is
used to set up the e-mail environment. This must be done by
the system administrator or other person familiar with the
network.
1In the link menu, click [Services].
The "Services Setup" screen will appear.
2Click [SMTP].
3Enter the information required to set up the
e-mail environment.
For more information, click [Help] in the menu frame.
4Click [Submit] to store the entered information.
7WEB PAGE IN THE MACHINE
65
CONTENTS INDEX
E-mail status and e-mail alert settings
(part 2)
Status message setup
Use the status message function to send the current counter information, such as copy count, print count, and total output count, on
a basis of the specified schedule. The destinations can be set for administrators and dealers respectively.
To set up the status message, follow these steps:
1In the link menu, click [Status Message].
The "Status Message Setup" screen will appear.
2Enter the required information, including the
destination addresses and time schedule.
For more information, click [Help] in the menu frame.
3Click [Submit] to store the entered information.
When the E-mail Status settings are completed, printer count
information will be sent periodically by e-mail to the specified
e-mail addresses.
If you quit the browser before clicking [Submit], the
settings will be canceled. To send printer information
immediately to the specified e-mail addresses, click
[Send Now].
Note
7WEB PAGE IN THE MACHINE
66
CONTENTS INDEX
E-mail status and e-mail alert settings
(part 3)
Alerts message setup
Use the alert message function to send alert information, such as empty toner and trouble including paper misfeeds, to specified
destinations when such problems occur. The destinations can be set for administrators and dealers respectively.
To set up the alert message, follow the procedure shown below.
1In the link menu, click [Alerts Message].
The "Alerts Message Setup" screen will appear.
2Enter the destination addresses.
For more information, click [Help] in the menu frame.
3Click [Submit] to store the entered information.
If these parameters are set, event information for the printer will
be transmitted to the specified addresses via E-mail each time
a specified event occurs. The meaning of each event item is
shown below.
Paper Jam: A paper misfeed occurs.
Toner Low: Toner is low.
No Toner: Toner must be added.
Paper Out: Paper must be loaded.
Service Required: The self-diagnostic function has found a
problem.
PM Required: Maintenance is required.
If you quit the browser before clicking [Submit], the
settings will be canceled.
Note
7WEB PAGE IN THE MACHINE
67
CONTENTS INDEX
Protecting information programmed in the web page ("Passwords")
Passwords can be set to restrict Web page access and protect settings. Note that it is not necessary to set passwords; the network
scanner function can also be used without passwords.
A password can be set for the administrator and passwords can be set for each user. If you use a user password to access the Web
page, you will be able to establish, edit, and delete destinations in the Scanner Destination Management menu; however, you will
not be able to establish settings in the Setup menu.
In the factory default setting, both password functions are disabled. To set a User and/or Admin password, the administrator needs
to follow the steps below:
1In the link menu, click [Passwords].
The Password Setup screen will appear.
2Enter the passwords and click the check box of
[Enable Password Protection of this Web Site].
For more information, click [Help]
in the menu frame.
3Click [Submit] to store the entered passwords.
Once the passwords have been established, you will be prompted for user name and password every time you open the Web page
of this system. The user names will always be "user" for user level and "admin" for administrator level.
●If you enable the password protection without entering User or Administrator passwords, the passwords which were previously
entered will be automatically set. The factory default passwords are "Sharp" for both Admin and User.
●If passwords have already been established, enter the Admin password in the [Admin Password] field. When setting the
passwords for the first time, enter "Sharp" in this field.
Note
8SPECIFICATIONS
68
CONTENTS INDEX
Printer specifications
*11200 dpi cannot be selected when using the PCL5e printer driver.
300 dpi can only be selected when using the PCL6 or PCL5e printer driver.
*2The factory default setting for memory used for the printer function is 16 MB. The proportion of IMC memory allocated to the
printer function can be changed in the key operator programs. See "MEMORY FOR PRINTER" in the "Key operator's guide".
*3Available only if the PS3 expansion kit is installed.
Printing speed AR-M236/AR-M237: 23 pages/min. at 600 dpi, 13.5 pages/min. at 1200 dpi*1
AR-M276/AR-M277: 27 pages/min. at 600 dpi, 13.5 pages/min. at 1200 dpi*1
Resolution*11200 dpi/600 dpi/300 dpi selectable
Memory
Standard memory: 64 MB
Additional memory slot: 1 slot (a 128 MB or 256 MB of additional memory module (144-pin SDRAM
SODIMM) can be installed)
IMC Memory
Standard memory: 32 MB*2
Additional memory slots: 2 slots (maximum of 1024 MB of additional memory modules (168-pin
SDRAM DIMM) can be installed)
Emulation PCL5e, PCL6, PS3 (PostScript 3)*3
Installed fonts PCL6 compatible: 80 outline fonts and 1 bitmap font
PostScript 3 compatible*3: 136 outline fonts
Interface
IEEE 1284-compliant parallel interface
USB 2.0 (Full-Speed/Low-Speed) interface
10/100BASE-TX network interface
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There
may be some deviations from these values in individual units.
Note
9INDEX
69
CONTENTS
Index (part 1)
Numerics
"2-Up Pamphlet" ................................ 13
A
About the Web page .......................... 59
Accessing the Web page ................... 59
ADVANCED PRINTING (WINDOWS) 20
Alerts message setup ........................ 66
Auditing mode
Macintosh ....................................... 35
Windows ........................................... 9
"Auto Select" ........................................ 7
B
Basic printing
Macintosh ....................................... 31
Windows ........................................... 6
"Border".............................................. 14
[BYPASS TRAY] key
Macintosh ....................................... 33
Windows ........................................... 7
C
Canceling a print job .......................... 37
"Carbon Copy" ................................... 25
Carbon copy print............................... 24
Check the connections....................... 48
Check the machine ............................ 50
Check the paper being used .............. 54
Check Your Computer ....................... 49
Checking the printer driver..................51
[CLEAR] key .......................................37
condition settings ................................38
Configuring the printer condition settings
...38
D
DATA indicator......................................6
"Default Job ID" ..................................21
DEFAULT SETTINGS ........................41
[DETAIL] key.......................................36
Directly printing a file in a computer....63
"Document Style"................................12
E
E-mail print function ............................61
F
"Finishing"...........................................18
"Fit To Page".......................................15
Font lists .............................................46
G
Giving priority to a print job .................36
H
"Help" button.......................................11
Hold After Print ...................................20
Hold Before Print ................................ 20
How to configure the settings .............38
How to print a print hold job................ 22
How to use the online manual ..............3
I
"Image Orientation" ............................16
IMC memory .......................................56
Information setup................................ 64
Introduction........................................... 2
J
"Job Control".......................................21
Job control function ............................ 35
N
NIC PAGE ..........................................46
Notice page ........................................ 56
"Notify Job End"..................................21
"N-Up Printing" ...................................14
O
ON LINE indicator.................................6
Opening the printer driver................... 10
OPERATION AT THE MACHINE ....... 36
"Order"................................................14
"Output" ................................................7
9INDEX
70
CONTENTS
Index (part 2)
P
Pamphlet style ................................... 13
"Paper Selection" ................................. 7
"Paper Source" .................................... 8
"Paper Type"........................................ 8
Part of the printed image is missing... 55
Passwords ......................................... 67
PCL SETTINGS ................................. 44
"PIN" .................................................. 21
PIN (5-digit ID number) ...................... 20
Points to note about the Print Hold function
.23
PostScript SETTINGS........................ 45
Print hold function .............................. 20
[PRINT] key.......................................... 6
Printer Administration Utility............... 27
Printer condition settings.................... 41
Printer driver settings ......................... 11
Printer Status Monitor ........................ 27
PRINTER UTILITIES ......................... 27
Printing a watermark .......................... 17
Printing does not take place............... 48
PRINTING FROM MACINTOSH........ 31
PRINTING FROM WINDOWS ............. 6
Printing is slow ................................... 52
[PRIORITY] key ................................. 36
Proof Print .......................................... 20
Punch................................................. 19
R
Removing the software .......................58
"Retention"..........................................21
"ROPM" ..............................................56
"Rotate 180 degrees"..........................16
S
Settings...............................................11
SMTP setup ........................................64
Stapling is not possible .......................52
Stapling printed pages ........................18
Status message setup ........................65
[STOP/DELETE] key ..........................37
[Submit Print Job] ...............................63
T
Text To Black......................................26
The printed image is coarse ...............55
The printed image is distorted ............55
"Tiled Pamphlet" .................................13
Troubleshooting ..................................47
Two-sided printing is not possible.......52
V
Vector To Black ..................................26
W
"Watermark"........................................17
WEB PAGE IN THE MACHINE ..........59

Navigation menu
