MX-2610N/MX-3110N/MX-3610N
QUICK START GUIDE
PRINTED IN FRANCE
TINSE4901GHZZ
DIGITAL FULL COLOUR MULTIFUNCTIONAL SYSTEM
MX-2610N/MX-3110N/MX-3610N
Keep this manual close at hand for reference whenever needed.
QUICK START GUIDE
2
For the users of the fax function
Important safety instructions
• If any of your telephone equipment is not operating properly, you should immediately remove it from your telephone line, as it may cause harm to the telephone network.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the socket is specifically designed for wet locations.
• Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
• Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.
• Do not use a telephone to report a gas leak in the vicinity of the leak.
• Do not install or use the machine near water, or when you are wet. Take care not to spill any liquids on the machine.
• Save these instructions.
title_1 L
27
The following trademarks and registered trademarks are used in conjunction with the machine
and its peripheral devices and accessories.
• Microsoft®, Windows®, Windows® 2000, Windows® XP, Windows Server® 2003, Windows
Vista®, Windows Server® 2008, Windows® 7 and Internet Explorer® are registered trademarks
or trademarks of Microsoft Corporation in the U.S.A. and other countries.
• PostScript is a registered trademark of Adobe Systems Incorporated.
• Adobe and Flash are registered trademarks or trademarks of Adobe Systems Incorporated in
the United States and other countries.
• Adobe, the Adobe logo, Acrobat, the Adobe PDF logo, and Reader are registered trademarks
or trademarks of Adobe Systems Incorporated in the United States and other countries.
• Macintosh, Mac OS, AppleTalk, EtherTalk and LaserWriter are trademarks of Apple Inc.,
registered in the U.S. and other countries.
• Netscape Navigator is a trademark of Netscape Communications Corporation.
• Mozilla® and Firefox® are registered trademarks or trademarks of the Mozilla Foundation in
the U.S.A. and other countries.
• PCL is a registered trademark of the Hewlett-Packard Company.
• IBM, PC/AT, and PowerPC are trademarks of International Business Machines Corporation.
• Sharpdesk is a trademark of Sharp Corporation.
• Sharp OSA is a trademark of Sharp Corporation.
• RealVNC is a trademark of RealVNC Limited.
• All other trademarks and copyrights are the property of their respective owners.
Candid and Taffy are trademarks of Monotype Imaging, Inc. registered in the United States
Patent and Trademark Ofce and may be registered in certain jurisdictions. CG Omega, CG
Times, Garamond Antiqua, Garamond Halbfett, Garamond Kursiv, Garamond and Halbfett
Kursiv are trademarks of Monotype Imaging, Inc. and may be registered in certain jurisdictions.
Albertus, Arial, Coronet, Gill Sans, Joanna and Times New Roman are trademarks of The
Monotype Corporation registered in the United States Patent and Trademark Ofce and may
be registered in certain jurisdictions. Avant Garde, ITC Bookman, Lubalin Graph, Mona Lisa,
Zapf Chancery and Zapf Dingbats are trademarks of International Typeface Corporation
registered in the United States Patent and Trademark Ofce and may be registered in certain
jurisdictions. Clarendon, Eurostile, Helvetica, Optima, Palatino, Stempel Garamond, Times
and Univers are trademarks of Heidelberger Druckmaschinen AG, which may be registered
in certain jurisdictions, exclusively licenced through Linotype Library GmbH, a wholly owned
subsidiary of Heidelberger Druckmaschinen AG. Apple Chancery, Chicago, Geneva, Monaco
and New York are trademarks of Apple Inc. and may be registered in certain jurisdictions.
HGGothicB, HGMinchoL, HGPGothicB and HGPMinchoL are trademarks of Ricoh Company,
Ltd. and may be registered in some jurisdictions. Wingdings is a registered trademark of
Microsoft Corporation in the United States and other countries. Marigold and Oxford are
trademarks of Arthur Baker and may be registered in some jurisdictions. Antique Olive is
a trademark of Marcel Olive and may be registered in certain jurisdictions. Hoeer Text is
a trademark of Johnathan Hoeer and may be registered in some jurisdictions. ITC is a
trademark of International Typeface Corporation registered in the United States Patent and
Trademark Ofce and may be registered in certain jurisdictions. Agfa is a trademark of the
Agfa-Gevaert Group and may be registered in certain jurisdictions. Intellifont, MicroType and
UFST are trademarks of Monotype Imaging, Inc. registered in the United States Patent and
Trademark Ofce and may be registered in certain jurisdictions. Macintosh and TrueType
are trademarks of Apple Inc. registered in the United States Patent and Trademark Ofce
and other countries. PostScript is a trademark of Adobe Systems Incorporated and may be
registered in some jurisdictions. HP, PCL, FontSmart and LaserJet are trademarks of Hewlett-
Packard Company and may be registered in some jurisdictions. The Type 1 processor resident
in Monotype Imaging’s UFST product is under licence from Electronics For Imaging, Inc. All
other trademarks are the property of their respective owners.
SHARP ELECTRONICS (Europe) GmbH
Sonninstraße 3, D-20097 Hamburg
TRADEMARK ACKNOWLEDGMENTS
26
Information on Disposal for Users (private households)
In the European Union
Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin! Used electrical and electronic equipment must be treated separately and
in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. Following the implementation by
member states, private households within the EU states may return their used electrical and electronic equipment to designated collection facilities free of charge*.
In some countries* your local retailer may also take back your old product free of charge if you purchase a similar new one.
*) Please contact your local authority for further details. If your used electrical or electronic equipment has batteries or accumulators, please dispose of these separately beforehand according to local
requirements. By disposing of this product correctly you will help ensure that the waste undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment
and human health which could otherwise arise due to inappropriate waste handling.
In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal. For Switzerland: Used electrical or electronic
equipment can be returned free of charge to the dealer, even if you don’t purchase a new product. Further collection facilities are listed on the homepage of www.
swico.ch or www.sens.ch.
Information on Disposal for Business Users
In the European Union
If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs
arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities. For Spain: Please contact the established collection system or your
local authority for take-back of your used products.
In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.
Attention: Your product is marked
with this symbol. It means that
used electrical and electronic
products should not be mixed with
general household waste. There
is a separate collection system for
these products.
INFORMATION ON DISPOSAL
3
Caution!
For complete electrical disconnection, pull out the main plug.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Shielded interface cables must be used with this equipment to maintain compliance with EMC regulations.
The equipment should be installed near an accessible socket outlet for easy disconnection.
4
FAX interface cable and Line cable
These special accessories must be used with the device.
To reduce the risk of re, use only UL-Listed No.26 AWG or larger telecommunication line cord.
Notice for users in the UK
MAINS PLUG WIRING INSTRUCTIONS
The mains lead of this equipment is already tted with a mains plug which is either a non-rewireable (moulded) or a rewireable type. Should the fuse need to be replaced, a BSI or ASTA approved
fuse to BS1362 marked or and of the same rating as the one removed from the plug must be used.
Always ret the fuse cover after replacing the fuse on the moulded plug. Never use the plug without the fuse cover tted.
In the unlikely event of the socket outlet in your home not being compatible with the plug supplied either cut-off the moulded plug (if this type is tted) or remove by undoing the screws if a rewireable
plug is tted and t an appropriate type observing the wiring code below.
DANGER: The fuse should be removed from the cut-off plug and the plug destroyed immediately and disposed of in a safe manner. Under no circumstances should the cut-off plug be inserted
elsewhere into a 13A socket outlet as a serious electric shock may occur.
To t an appropriate plug to the mains lead, follow the instructions below:
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
GREEN-AND-YELLOW: Earth
BLUE: Neutral
BROWN: Live
As the colours of the wires in this mains lead may not correspond with coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked with the letter E, or by the safety earth symbol , or coloured green or
greenand-yellow.
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red.
If you have any doubt, consult a qualied electrician.
WARNING: THIS APPARATUS MUST BE EARTHED.
EMC (this machine and peripheral devices)
Warning:
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
This machine contains the software having modules developed by Independent JPEG Group.
This product includes Adobe® Flash® technology of Adobe Systems Incorporated.
Copyright© 1995-2007 Adobe Macromedia Software LLC. All rights reserved.
25
Forwarding all transmitted and received data to the administrator (document administration function)
This function is used to forward all data transmitted and received by the machine to a specied destination (Scan to E-mail address, Scan to FTP destination, Scan to Network
Folder destination, or Scan to Desktop destination).
This function can be used by the administrator of the machine to archive all transmitted and received data.
To congure the document administration settings, click [Application Settings] and then [Document Administration Function] in the [Settings mode] (Administrator-level access
privileges are required.)
• The format, exposure, and resolution settings of transmitted and received data remain in effect when the data is forwarded.
• When forwarding is enabled for data sent in fax mode,
• The [Direct TX] key does not appear in the touch panel.
• Quick online transmission and dialling using the speaker cannot be used.
Settings mode password
The administrator password is required to change the machine’s settings mode.
Settings mode can be changed from either the operation panel or using a computer
web browser. After setting up the machine, refer to [Settings mode] in the Operation
Guide (PC) to set a new password.
The same passwords are used for logging in from the operation panel and from a web browser. If
the administrator changes a password, that password will be effective when logging in from both the
operational panel and a web browser.
Account Password
User users users
Administrator admin admin
System Administrator sysadmin sysadmin
Please take care not to forget newly set administrator passwords.
Password for logging in from a computer
There are three accounts that can log in from a web browser: “Administrator”,
“System Administrator” and “User”. The factory default passwords for each account
are shown on the below. Logging in as an “Administrator” or “System Administrator”
will allow you to manage all the settings available via web browser.
(Cut along the dotted line and keep in a safe place.)
TO THE ADMINISTRATOR OF THE MACHINE
24
OTHERS
Noise emission values
Sound power level LWAd
MX-2610N MX-3110N MX-3610N
Printing mode
(continuous printing) 7.3 B 7.6 B 7.5 B
Standby mode - - -
Sound pressure level LpA (actual measurement)
MX-2610N MX-3110N MX-3610N
Printing mode
(continuous printing) 56 dB 58 dB 57 dB
Standby mode - - -
Noise emission values as measured according to ISO7779 are listed to the right.
Emission density (measured according to RALUZ122: Edition Jun.2006)
Measured chemicals Condition of copier Colour mode Diffusion speed
Ozone
When copier is in operation
Colour 3.0 mg/h or less
Black and white 1.5 mg/h or less
Dust Colour 4.0 mg/h or less
Black and white
Styrene Colour
-
Black and white
Benzene Colour
Black and white
TVOC
Colour 18 mg/h or less
Black and white 10 mg/h or less
When on standby - 2.0 mg/h or less
Emission of noise and chemicals
5
SOFTWARE LICENCE
The SOFTWARE LICENCE will appear when you install the software from the CD-ROM. By using all or any portion of the software on the CD-ROM or in the machine, you are
agreeing to be bound by the terms of the SOFTWARE LICENCE.
The explanations in this manual are based on American English and the North American version of the software.
Software for other countries and regions may vary slightly from the North American version.
• The explanations in this manual assume that you have a working knowledge of your Windows or Macintosh computer.
• For information on your operating system, please refer to your operating system manual or the online Help function.
• The explanations of screens and procedures in this manual are primarily for Windows Vista® in Windows® environments. The screens may vary depending on the version of the operating system.
• Considerable care has been taken in preparing this manual. If you have any comments or concerns about the manual, please contact your dealer or nearest authorised service representative.
• This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect or other problem is discovered, please contact your dealer or nearest authorised service representative.
• Aside from instances provided for by law, SHARP is not responsible for failures occurring during the use of the product or its options, or failures due to incorrect operation of the product and its options, or other failures, or for any damage
that occurs due to use of the product.
Products that have earned the ENERGY STAR® are designed to
protect the environment through superior energy efciency.
Warranty
While every effort has been made to make this document as accurate and helpful
as possible, SHARP Corporation makes no warranty of any kind with regard to its
content. All information included herein is subject to change without notice. SHARP is
not responsible for any loss or damages, direct or indirect, arising from or related to
the use of this operation manual.
© Copyright SHARP Corporation 2010. All rights reserved. Reproduction, adaptation
or translation without prior written permission is prohibited, except as allowed under
copyright laws.
MATERIAL SAFETY DATA SHEET
The MSDS (Material Safety Data Sheet) can be viewed at the following URL address: http://www.sharp-world.com/corporate/info/index.html
Contents
6
OPERATION MANUALS AND HOW TO USE THEM ————————— 7
CAUTIONS ——————————————————————————— 8
Symbols in this manual ——————————————————————— 8
Power notes ———————————————————————————— 8
Installation notes —————————————————————————— 9
About consumables ————————————————————————— 10
Handling precautions ———————————————————————— 10
NAMES OF PARTS AND COMPONENTS,
TURNING ON THE POWER ——————————————————— 12
HOME SCREEN ———————————————————————— 13
For operating the touch panel and functions the icon.
OVERVIEW OF COPY OPERATION ——————————————— 14
OVERVIEW OF OTHER OPERATIONS —————————————— 16
For functions other than copy.
MAINTENANCE ———————————————————————— 17
SPECIFICATIONS ——————————————————————— 18
SUPPLIES —————————————————————————— 23
OTHERS ——————————————————————————— 24
TO THE ADMINISTRATOR OF THE MACHINE —————————— 25
INFORMATION ON DISPOSAL ————————————————— 26
TRADEMARK ACKNOWLEDGMENTS —————————————— 27
23
SUPPLIES
Standard supplies for this product that can be replaced by the user include paper,
toner cartridges, and staple cartridges for the nisher.
Be sure to use only SHARP-specied products for the toner cartridges, nisher staple
cartridge, and transparency lm.
The supply of spare parts for repair of the machine is guaranteed for at least 7 years following the termination of production. Spare parts are those parts of the machine which
may break down within the scope of the ordinary use of the product, whereas those parts which normally exceed the life of the product are not to be considered as spare parts.
Consumables too, are available for 7 years following the termination of production.
Proper storage
1. Store the supplies in a location that is:
• clean and dry,
• at a stable temperature,
• not exposed to direct sunlight.
2. Store paper in the wrapper and lying at.
3. Paper stored in packages standing up or out of the wrapper may curl or become
damp, resulting in paper misfeeds.
GENUINE SUPPLIES
For best copying results, be sure to use only Sharp Genuine
Supplies which are designed, engineered, and tested to maximize
the life and performance of Sharp products. Look for the Genuine
Supplies label on the toner package.
Storage of supplies
Supply of spare parts and consumables
Storing toner cartridges
Store a new toner cartridge box horizontally with the top side up. Do not store a toner
cartridge standing on end. If stored standing on end, the toner may not distribute
well even after shaking the cartridge vigorously, and will remain inside the cartridge
without owing out.
Staple cartridge
The nisher and saddle nisher require the following staple cartridge:
MX-SCX1 (for nisher and saddle nisher)
Approx. 5000 per cartridge x 3 cartridges
AR-SC3 (for saddle stitch of saddle nisher)
Approx. 2000 per cartridge x 3 cartridges
22
SPECIFICATIONS
Network Scanner Specications
Type Colour scanner
Scan resolution (main × vertical)
100 × 100 dpi, 150 × 150 dpi, 200 × 200 dpi, 300 × 300 dpi,
400 × 400 dpi, 600 × 600 dpi (push scan)
50 to 9,600 dpi *1 (pull scan)
Scan speed
(A4 (8-1/2" × 11"))
B/W: 50 sheets/minute (one-sided)
Colour: 50 sheets/minute (one-sided)
- When in standard mode using Sharp standard paper (A4 (8-1/2" × 11") size
with 6% coverage) and the auto colour detector is turned off. The speed
varies depending on the data volume of the original.
Interface 10BASE-T/100BASE-TX/1000BASE-T,
USB 2.0 (during USB memory scanning)
Compatible protocols TCP/IP (IPv4/IPv6)
Compatible OS *2
Pull scan (TWAIN) Windows 2000, Windows XP, Windows 2000 Server,
Windows Server 2003, Windows Vista, Windows Server
2008, Windows 7
Output format
(B/W)
TIFF, PDF, PDF/A, encrypted PDF, XPS *3
Compression method: decompression, G3 (MH), G4 (MMR)
(Grey scale/colour)
TIFF, JPEG, PDF, PDF/A, encrypted PDF, high compression PDF, XPS *3
Compression method: JPEG (high, mid, and low compression, Emphasis black
letter)
Driver TWAIN compliant
*1: You must decrease the scan size when increasing the resolution.
*2: There are cases when a connection cannot be established. Please contact your local dealer for more information.
*3: XPS (XML Paper Specication)
7
OPERATION MANUALS AND HOW TO USE THEM
3 Download the [Operation Guide (PC)]
Click [Download Operation Guide] on the
displayed page. Next, select the desired
language from the “Language to download”
list, and then click the [Download] button.
4 Double-click on the downloaded file to
display the Operation Guide (PC).
2 Insert the machine’s IP address into
the address bar of your web browser
to access the machine.
http://machine’s IP address/
User verication may be required
depending on the machine’s settings.
Please check with the machine’s
administrator to obtain the account
information necessary for verication.
1 Confirm the machine’s IP address
First, press the [Settings] key on the operation
panel and then touch [List Print (User)] when it
appears on the touch panel.
Next, touch the [Print] key in the [All Custom
Setting List], and conrm the IP address in the
printed list.
Quick Start Guide (this document)
Features important safety notes, names of parts and
components, information about the power-on procedure,
operation overviews, information for people who manage
the machine, and information about other aspects of this
machine.
Read this section before using the machine for the rst time.
Downloading the Operation Guide (PC)
You can download the [Operation Guide (PC)] by following the procedures below while the machine is connected to the network.
Operation Guide (PC)
Can be downloaded from the machine to a computer and
viewed. Refer to this document to learn more about printer
mode and settings mode, and to learn about the details of
each type of mode.
Operation Guide (Built-in)
Can be viewed by touching the operation guide icon on the
machine’s touch panel. When you are using this machine,
use this document to see an overview of a particular mode or
when you are having trouble operating the machine.
Software Setup Guide (CD-PDF)
Explains how to install the various drivers needed when using
this machine as a printer, network scanner, or fax machine.
Refer to this document when using this machine from a
computer. The Software Setup Guide can be found on the
“Software CD-ROM”.
Software Setup Guide
DIGITAL FULL COLOUR MULTIFUNCTIONAL SYSTEM
SETUP IN A WINDOWS ENVIRONMENT
TROUBLESHOOTING
SETUP IN A MACINTOSH ENVIRONMENT
BEFORE INSTALLING THE SOFTWARE
SETUP IN A WINDOWS ENVIRONMENT
TROUBLESHOOTING
SETUP IN A MACINTOSH ENVIRONMENT
BEFORE INSTALLING THE SOFTWARE
Operation Guide Index
Common operations
By mode
Home screen
Copier
Eco Maintenance
Troubleshooting
Appendix
Facsimile Image send
Preview screen
Text entry
How to set the
original and
paper
Document
filing
Others
To close Operation Guiude, tap [close] key or press Home button.
DIGITAL FULL COLOUR MULTIFUNCTIONAL SYSTEM
MX-2610N/MX-3110N/MX-3610N
Keep this manual close at hand for reference whenever needed.
QUICK START GUIDE
8
When moving the machine, switch off the main power and remove the power plug from the outlet
before moving.
The cord may be damaged, creating a risk of re or electrical shock.
CAUTION
When removing the power plug from the outlet, do not pull on the cord.
Pulling on the cord may cause damage such as wire exposure and breakage, and may result in re or
electrical shock.
If you will not use the machine for a long time, be sure to remove the power plug from the outlet for
safety.
Power notes
WARNING
Be sure to connect the power cord only to a power outlet that meets the specied voltage and current
requirements. Also make certain the outlet is properly grounded. Do not use an extension cord or
adapter to connect other devices to the power outlet used by the machine. Using an improper power
supply may cause re or electrical shock.
* For the power supply requirements, see the name plate in the lower left corner of the left side of the
machine.
Do not damage or modify the power cord.
Placing heavy objects on the power cord, pulling it, or forcibly bending it
will damage the cord, resulting in re or electrical shock.
Do not insert or remove the power plug with wet hands.
This may cause electrical shock.
Meaning of the symbols
CAUTION!
HOT
PINCH POINT
KEEP CLEAR
PROHIBITED
ACTIONS
DO NOT
DISASSEMBLE
MANDATORY
ACTIONS
Symbols in this manual
To ensure safe use of the machine, this manual uses various safety symbols. The
safety symbols are classied as explained below. Be sure you understand the
meaning of the symbols when reading the manual.
WARNING
Indicates a risk of death or serious injury.
CAUTION
Indicates a risk of human injury or property damage.
CAUTIONS
21
Type Built-in type
Continuous print speed Same as continuous copy speed
Resolution Data processing: 600 × 600 dpi, 1,200 × 1,200 dpi
Print: 600 × 600 dpi, equivalent to 9,600 dpi × 600 dpi, 1,200 × 1,200 dpi
Page description language Standard: PCL6 emulation, PS3 emulation *1
Compatible protocols TCP/IP, IPv4/IPv6, IPX/SPX, NetBEUI, IPP, EtherTalk *1
Compatible OS
Windows 2000, Windows XP, Windows 2000 Server, Windows Server 2003,
Windows Vista, Windows Server 2008, Windows 7
Macintosh (Mac OS 9.0 ~ 9.2.2, OS X 10.2.8, 10.3.9, 10.4 ~ 10.4.11, 10.5 ~
10.5.8, 10.6 ~ 10.6.2)*1
Network Printer Specications
Internal fonts (options) 80 fonts for PCL, 136 fonts for PS3 emulation
Memory Machine system memory and hard disk
Interface 10BASE-T/100BASE-TX/1000BASE-T, USB 1.1, USB 2.0 (high speed mode)
*1: When equipped with a PS extension kit (MX-PK11).
Fax Specications
Transmission time
Approx. 2 seconds *1 (A4 (8-1/2" × 11") Sharp standard paper, normal
characters, Super G3 (JBIG))
Approx. 6 seconds (G3 ECM)
Memory 1 GB
Notes
Touch dial memory Max. of 2,000 entries (Including group dialling for fax,
scanner, and Internet fax)
Entries per group Max. of 500 entries
Mass transmissions Max. of 500 recipients
*1 Complies with the 33.6 kbps transmission method for Super G3 facsimiles standardized by the International
Telecommunications Union (ITU-T). This is the speed for when sending an A4 (8-1/2" × 11") size piece of paper of
around 700 characters at standard image quality (8 × 3.85 chars/mm) in Hi-speed mode (33.6 kbps). This is the
transmission speed for image information only and does not include time for transmission control. The actual time
needed for a transmission depends on the content of the text, type of receiving fax machine, and telephone line
conditions.
Name Facsimile expansion kit (MX-FX11)
Useable lines General phone lines (PSTN), private branch exchange (PBX)
Scanning line density
Normal characters: 8 dot/mm × 3.85 chars/mm
Small characters: 8 dot/mm × 7.7 line/mm
Fine characters: 8 dot/mm × 15.4 line/mm
High-denition: 16 dot/mm × 15.4 line/mm
Connection speed Super G3: 33.6 kbps, G3: 14.4 kbps
Coding method MH, MR, MMR, JBIG
Connection mode Super G3 / G3
Original paper sizes for transmission A3 (11" × 17") to A5 (5-1/2" × 8-1/2") (Paper with a max. length of
1,000 mm* can be transmitted (one-sided and B/W only).)
Registered paper size A3 (11" × 17") to A5 (5-1/2" × 8-1/2")
20
Punch module (for saddle nisher)
Name Punch module for saddle nisher
MX-PNX5A, MX-PNX5B, MX-PNX5C, MX-PNX5D
Paper size for punch module A3 (11" × 17") to A4 (7-1/4" × 10-1/2"R)
Holes
MX-PNX5A 2 holes
MX-PNX5B 3 holes
MX-PNX5C 4 holes
MX-PNX5D 4 holes (wide)
Required power supply Supplied from saddle nisher
Dimensions 122 mm (W) × 604 mm (D) × 248 mm (H)
(4-27/32" (W) × 24-5/32" (D) × 9-59/64" (H))
Weight Approx. 3.5 kg (7.7 lbs.)
SPECIFICATIONS
Punch module (for nisher)
Name Punch module for nisher
MX-PN11A, MX-PN11B, MX-PN11C, MX-PN11D
Paper size for punch module A3 (11" × 17") to A4 (7-1/4" × 10-1/2"R)
Holes
MX-PN11A 2 holes
MX-PN11B 3 holes
MX-PN11C 4 holes
MX-PN11D 4 holes (wide)
Required power supply Supplied from nisher
Dimensions 98 mm (W) × 477 mm (D) × 137 mm (H)
(3-55/64" (W) × 18-50/64" (D) × 5-26/64" (H))
Weight Approx. 3 kg (7 lbs.)
Saddle Finisher
Name Finisher (MX-FN10)
Paper sizes Depends on feeder specications
Useable paper Paper weight 55 g/m2 (15 lbs.) to 256 g/m2 (68 lbs.)
No. of trays 1
Tray capacity (80g/m2 (21 lbs.))
Non-stapled A3 wide (12" × 18") / A3 (11" × 17") /
B4 (8-1/2" × 14") / A5R (5-1/2" × 8-1/2"R): 500 sheets
A4 (8-1/2" × 11") / A4R (8-1/2" × 11"R) / B5
B5R (7-1/4" × 10-1/2"R): 1,000 sheets
Staple function A3 (11" × 17") / B4 (8-1/2" × 14"): 50 units or 500 sheets
A4 (8-1/2" × 11") / A4R (8-1/2" × 11"R) / B5 / B5R :
50 units or 1,000 sheets
- Offset output is not available for A3 wide (12" × 18") /
A5R (5-1/2" × 8-1/2"R).
Required power supply Supplied from this machine
Weight Approx. 40 kg (88 lbs.)
Dimensions
When output paper tray is stored
497 mm (W) × 631 mm (D) × 988 mm (H)
(19-9/16" (W) × 24-27/32" (D) × 38-57/64" (H))
When output paper tray is extended
656 mm (W) × 631 mm (D) × 988 mm (H)
(25-53/64" (W) × 24-27/32" (D) × 38-57/64" (H))
Max. no. of stapled sheets Max. no. of 50 sheets (A4 (8-1/2" × 11"), A4R (8-1/2" × 11"R), B5, B5R)
Max. no. of 25 sheets (A3 (11" × 17"), B4 (8-1/2" × 14"))
Staple position 1 bottom, 1 top, 2 middle
Staple method (for saddle stitch) Centred fold with stapling in 2 centre places
Saddle stitch fold position Centred fold
Saddle usable sizes A3 (11" × 17") / B4 (8-1/2 × 14") / A4R (8-1/2" × 11"R)
Saddle usable paper weight 60 g/m2 (16 lbs.) to 209 g/m2 (56 lbs.)
9
Do not install the machine on an unstable or slanted surface. Install the machine on a surface that can
withstand the weight of the machine.
Risk of injury due to the machine falling or toppling.
If peripheral devices are to be installed, do not install on an uneven oor, slanted surface, or otherwise
unstable surface. Danger of slippage, falling, and toppling. Install the product on a at, stable surface that can
withstand the weight of the product.
Do not install in a location with moisture or dust.
Risk of re and electrical shock.
If dust enters the machine, dirty output and machine failure may result.
Locations that are excessively hot, cold, humid, or dry
(near heaters, humidiers, air conditioners, etc.)
The paper will become damp and condensation may form
inside the machine, causing misfeeds and dirty output.
SPECIFICATIONS (page 18)
If the location has an ultrasonic humidier, use pure water
for humidiers in the humidier. If tap water is used, minerals
and other impurities will be emitted, causing impurities to
collect on the inside of the machine and create dirty output.
When the machine is installed, the adjusters (5) must be lowered to the
oor to secure the machine (prevent it from moving).
Rotate the adjusters in the locking direction until they are in rm contact
with the oor.
If you nd it necessary to reposition the machine due to
rearrangement of your ofce layout or other reason, retract the
adjusters from the oor, turn off the power, and then move the
machine.
(After moving the machine, lower the adjusters again to secure the
machine.)
Locations exposed to direct sunlight
Plastic parts may become deformed and dirty output may result.
Lock
Release
Installation notes
CAUTION
Locations with ammonia gas
Installing the machine next to a diazo copy machine may cause
dirty output.
Do not install the machine in a location with poor air
circulation.
A small amount of ozone is created inside the machine during
printing. The amount of ozone created is not sufcient to be
harmful; however, an unpleasant odor may be noticed during
large copy runs, and thus the machine should be installed in a
room with a ventilation fan or windows that provide sufcient air
circulation. (The odor may occasionally cause headaches.)
* Install the machine so that people are not directly exposed to
exhaust from the machine. If installed near a window, ensure
that the machine is not exposed to direct sunlight.
Near a wall
Be sure to allow the required space around the machine for
servicing and proper ventilation. (The machine should be no
closer than the distances indicated below from walls. The
indicated distances are for the case when a saddle nisher and
large capacity paper tray are not installed.) 30 cm
30 cm
45 cm
Locations subject to vibration.
Vibration may cause failure.
CAUTION
The machine includes a built-in hard drive. Do not subject the machine to shock or vibration. In particular, never
move the machine while the power is on.
• The machine should be installed near an accessible power outlet for easy connection.
• Connect the machine to a power outlet which is not used for other electric appliances. If a lighting xture is
connected to the same outlet, the light may icker.
10
CAUTIONS
Do not throw a toner cartridge into a fire.
Toner may y and cause burns.
About consumables
CAUTION
Store a toner cartridge out of the reach of children.
Do not place a container of water or other liquid, or a metal
object that might fall inside, on the machine.
If the liquid spills or the object falls into the machine, re or electrical
shock may result.
Do not remove the machine casing.
High-voltage parts inside the machine may cause electrical shock.
Do not make any modifications to this machine.
Doing so may result in personal injury or damage to the machine.
Do not use a flammable spray to clean the machine.
If gas from the spray comes in contact with hot electrical components or the fusing unit inside
the machine, fire or electrical shock may result.
Handling precautions
WARNING
If you notice smoke, a strange odor, or other abnormality, do not
use the machine.
If used in this condition, re or electrical shock may result.
Immediately switch off the main power and remove the power plug from
the power outlet.
Contact your dealer or nearest authorised service representative.
If a thunder storm begins, switch off the main power and remove the power plug from the outlet
to prevent electrical shock and re due to lightning.
If a piece of metal or water enters the machine, switch off the main power and remove the
power plug from the power outlet.
Contact your dealer or nearest authorised service representative. Using the machine in this condition
may result in electrical shock or re.
19
Automatic document feeder (Standard equipment)
Name Reversing Single Pass Feeder (RSPF)
Document feeder types Reversing Single Pass Feeder (RSPF)
Original paper sizes A3 (11" × 17") to A5 (5-1/2" × 8-1/2")
Original paper types
Paper weight Thin paper 35 g/m2 (9 lbs.) to 49 g/m2 (13 lbs.)
Plain paper 50 g/m2 (13 lbs.) to 129 g/m2 (34 lbs.)
Two-sided 50 g/m2 (13 lbs.) to 105 g/m2 (28 lbs.)
Paper storage capacity 100 sheets (80 g/m2 (21 lbs.))
(or maximum stack height of 13 mm (33/64"))
Scan speed (copy)
B/W: 50 one-sided sheets/minute (A4 (8-1/2" × 11") horizontal)
(600 × 400 dpi)
Colour: 36 one-sided sheets/minute (A4 (8-1/2" × 11") horizontal)
(600 × 600 dpi)
Tray
Name Tray 1
(MX-DE12)
Tray 2
(MX-DE13)
Tray 3
(MX-DE14)
Large capacity tray
(MX-LC11)
Paper sizes A3 (11" × 17") to A5R (5-1/2" × 8-1/2"R) A4 (8-1/2" × 11"), B5
Useable paper 60 g/m2 (16 lbs.) to 209 g/m2 (56 lbs.) 60 g/m2 (16 lbs.) to
105 g/m2 (28 lbs.)
Paper capacity 500 sheets 1,000 (500 × 2) 1,500 (500 × 3) 3,500
Dimensions
MX-DE12/13/14
583 mm (W) × 577 mm (D) × 382 mm (H)
(22-61/64" (W) × 22-46/64" (D) × 15-3/64" (H))
MX-LC11
376 mm (W) × 523 mm (D) × 575 mm (H)
(14-53/64" (W) × 20-19/32" (D) × 22-41/64" (H))
Weight
MX-DE12: Approx. 21 kg (46 lbs.)
MX-DE13: Approx. 24 kg (53 lbs.)
MX-DE14: Approx. 29 kg (64 lbs.)
MX-LC11: Approx. 30 kg (66 lbs.)
Finisher
Name Finisher (MX-FN17)
Paper sizes Depends on feeder specications
Useable paper Paper weight 55 g/m2 (15 lbs.) to 256 g/m2 (68 lbs.)
No. of trays 1
Tray capacity (80g/m2 (21 lbs.))
Non-stapled A3 wide (12" × 18") / A3 (11" × 17") /
B4 (8-1/2" × 14"): 250 sheets
A4 (8-1/2" × 11") / A4R (8-1/2" × 11"R) / B5
B5R (7-1/4" × 10-1/2"R) / A5R (5-1/2" × 8-1/2"R):
500 sheets
Staple function A3 (11" × 17") / B4 (8-1/2" × 14"): 30 units or 250 sheets
A4 (8-1/2" × 11") / A4R (8-1/2" × 11"R) / B5
30 units or 500 sheets
- Offset output is not available for A3 wide (12" × 18") /
B5R (7-1/4" × 10-1/2"R) / A5R (5-1/2" × 8-1/2"R).
Max. no. of stapled sheets Max. no. of 50 sheets (A4 (8-1/2" × 11"), A4R (8-1/2" × 11"R), B5)
Max. no. of 30 sheets (A3 (11" × 17"), B4 (8-1/2" × 14"))
Staple position 1 bottom, 1 top, 2 middle
Required power supply Supplied from this machine
Weight Approx. 15 kg (33 lbs.)
Dimensions
When output paper tray is stored
428 mm (W) × 593 mm (D) × 198mm (H)
(16-55/64" (W) × 23-22/64" (D) × 7-51/64" (H))
When output paper tray is extended
612 mm (W) × 593 mm (D) × 198 mm (H)
(24-6/64" (W) × 23-22/64" (D) × 7-51/64" (H))
18
Basic Specications / Copier specications
Name MX-2610N/MX-3110N/MX-3610N
Type Desktop
Colour Full colour
Copier system Laser electrostatic copier
Scanning
resolution
Scan (B/W): 600 × 600 dpi, 600 × 400 dpi, 600 × 300 dpi
Scan (full colour): 600 × 600 dpi
Print: 600 × 600 dpi, equivalent to 9,600 dpi × 600 dpi
Gradation Scan: equivalent to 256 levels / Print: equivalent to 256 levels
Original paper
sizes Max. A3 (11" x 17”) for sheets and bound documents
Copy sizes
A3 wide (12" × 18") to A5R, 5-1/2" × 8-1/2"R, Transparency lm, Heavy paper, Envelopes
Tray 1-4: A3, B4, A4, A4R, B5, B5R, A5R, 11" × 17", 8-1/2" × 14", 8-1/2" × 13-1/2", 8-1/2" × 13-2/5",
8-1/2" × 13", 8-1/2" × 11", 8-1/2" × 11"R, 7-1/4 × 10-1/2"R, 5-1/2" × 8-1/2"R
Multi-bypass tray: A3 wide (12" × 18") to A5R, 5-1/2" × 8-1/2"R, Transparency lm, Heavy paper,
Envelopes
Lost margin (leading edge): 4 mm (11/64") ± 1 mm (± 3/64")
Lost margin: (trailing edge): 2 mm (6/64") - 5 mm (- 13/64")
Leading edge / trailing edge: total 8 mm (21/64") or less
Near edge / far edge: total 4 mm (11/64") ± 2 mm (± 6/64") or less
Warm-up time 20 seconds or less
- This may vary depending on the ambient conditions.
First-copy time
MX-2610N MX-3110N MX-3610N
Full colour: 8.1 seconds 7.9 seconds 6.8 seconds
B/W: 5.9 seconds 5.8 seconds 5.2 seconds
- This may vary depending on the state of the machine.
Continuous
copying speeds*
(when shifter is
not in operation)
MX-2610N
A4, 8-1/2" × 11" B5, 7-1/4" × 10-1/2" 26 copies/min.
A4R, 8-1/2" × 11"R B5R, 7-1/4" × 10-1/2"R 19 copies/min.
B4, 8-1/2" × 14" 16 copies/min.
A3, 11" × 17" 14 copies/min.
* Continuous speed for same original source. Output may be
temporarily interrupted to stabilize image quality.
MX-3110N
31 copies/min.
20 copies/min.
17 copies/min.
15 copies/min.
MX-3610N
36 copies/min.
23 copies/min.
20 copies/min.
17 copies/min.
Copy ratios
Same size: 1:1 ± 0.8 % Enlarge: 115 %, 122 %, 141 %, 200 %, 400 %
Reduce: 25 %, 50 %, 70 %, 81 %, 86 %
Zoom range: 25 to 400 % (25 - 200 % using RSPF) in 1 % increments, total
376 increments. Can calculate zoom rate when mm is specied.
Paper feed / capacity 500 sheets in one tray plus 100-sheet multi-bypass tray
- Using 80 g/m2 (21 lbs.) weight paper
Max. paper feed / max. capacity
5,600 sheets in 4 trays (500 × 4) plus 100-sheet multi-bypass tray plus 3,500
sheets in large capacity tray
- Using 80 g/m2 (21 lbs.) weight paper
Continuous copy Max. 999 copies
Memory
Standard: 2 GB HDD: 160 GB SD card 4 GB PCL accelerator 1 GB
- 1 GB = One billion bytes when referring to hard drive capacity. Actual format
capacity is less.
Ambient
environment
Operating
environment 10 °C (54 °F) to 35 °C (91 °F) (20 % to 85 % RH) 590 - 1,013 hpa
Standard
environment 20 °C (68 °F) to 25 °C (77 °F) (65 ± 5 % RH)
Required power supply
Local voltage ± 10 % (For the power supply requirements, see the name plate
in the lower corner of the left side of the machine.)
Power consumption Max. 1.44 kW (including options such as the desk)
Dimensions
MX-2610N/MX-3110N
583 mm (W) × 658 mm (D) × 834 mm (H)
(22-61/64" (W) × 25-29/32" (D) × 32-27/32" (H))
MX-3610N
608 mm (W) × 680 mm (D) × 834 mm (H)
(24-5/16" (W) × 26-25/32" (D) × 32-27/32" (H))
Weight MX-2610N/MX-3110N MX-3610N
Approx. 75 kg (165 lbs.) Approx. 78 kg (171 lbs.)
Overall
dimensions
With multi-bypass
tray extended
MX-2610N/MX-3110N
850 mm (W) × 658 mm (D) (33-15/32" (W) × 25-29/32" (D))
MX-3610N
876 mm (W) × 680 mm (D) (34-31/64" (W) × 26-25/32" (D))
With right side exit
tray extended
MX-2610N/MX-3110N
963 mm (W) × 658 mm (D) (37-59/64" (W) × 25-29/32" (D))
MX-3610N
1,015 mm (W) × 680 mm (D) (39-31/32" (W) × 26-25/32" (D))
SPECIFICATIONS
11
Do not look directly at the light source.
Doing so may damage your eyes.
Do not block the ventilation ports on the machine. Do not install the machine in a location that
will block the ventilation ports.
Blocking the ventilation ports will cause heat to build up in the machine, creating a risk of re.
CAUTION
The fusing unit and paper exit area are hot. When removing a
misfeed, do not touch the fusing unit and paper exit area. Take care
not to burn yourself.
When loading paper, removing a misfeed, performing
maintenance, closing the front and side covers, and
inserting and removing trays, take care that your ngers
are not pinched.
The machine includes the document ling function, which stores document image data on the machine's hard drive. Stored documents can be called up and printed or transmitted as needed. If a hard drive failure occurs, it will no longer be
possible to call up the stored document data. To prevent the loss of important documents in the unlikely event of a hard drive failure, keep the originals of important documents or store the original data elsewhere.
With the exception of instances provided for by law, Sharp Corporation bears no responsibility for any damages or loss due to the loss of stored document data.
Laser information
Wave length 790 nm ± 10 nm
Pulse times Normal paper mode (P/S = 104 mm/s) = (5.15 µs ± 0.03 ns) / 7 mm
Heavy paper mode (P/S = 70 mm/s) = (3.83 µs ± 0.03 ns) / 7 mm
Output power Max 0.405 mW
Caution
Use of controls or adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
This Digital Equipment is CLASS 1 LASER PRODUCT (IEC 60825-1 Edition
2-2007)
“BATTERY DISPOSAL”
THIS PRODUCT CONTAINS A LITHIUM PRIMARY MEMORY BACK-UP
BATTERY THAT MUST BE DISPOSED OF PROPERLY.
PLEASE CONTACT YOUR LOCAL SHARP DEALER OR AUTHORIZED
SERVICE REPRESENTATIVE FOR ASSISTANCE IN DISPOSING OF THIS
BATTERY.
12
NAMES OF PARTS AND COMPONENTS, TURNING ON THE POWER
This machine has a main power switch, found at the
bottom left after the front cover is opened, and a power
button ( ), located on the operation panel.
CAUTION
• When turning off the power, make sure that the indicators on the
operation panel turn off as well.
• If the machine suddenly turns off, such as in the event of a power failure,
turn the machine on again, and then turn off the machine following the
correct procedure for turning off the machine.
Switching off the main power switch or removing the power cord from the
outlet while any of the indicators are lit or blinking may damage the hard
drive and cause data to be lost.
• Switch off both the power button ( ) and the main power switch and
unplug the power cord if you suspect a machine failure, if there is a bad
thunderstorm nearby, or when you are moving the machine.
• When using the fax or Internet fax function, always keep the main power switch in
the “ ” position.
• In some states of the machine, pressing the power button ( ) to restart will not
make the settings take effect. In this case, use the main power switch to switch
the power off and then on.
Turning on the power
• Switch the main power switch to the “ ” position.
The main power indicator will light in orange. The
power button ( ) does not function while the main
power indicator is lit in orange.
• After the main power indicator lights in green, press
the power button ( ).
Turning off the power
(1) Press the power button ( ) to turn off the power.
(2) Switch the main power switch to the “ ” position.
Restarting the machine
In order for some settings to take effect, the machine
must be restarted. If a message in the touch panel
prompts you to restart the machine, press the power
button ( ) to turn off the power and then press the
key again to turn the power back on.
Main power indicator
Output tray (Centre tray)
Keyboard*
Automatic
document feeder
Operation
panel
Right tray
Paper pass unit*
Bypass tray
Front cover
Tray 5
(when a large capacity tray is installed)*
Tray 1
Tray 2
(when a paper feed tray is installed)*
Tray 3
(when a paper feed tray is installed)*
Tray 4
(when a paper feed tray is installed)*
Saddle Finisher*
Main power switch
Power button
Finisher*
* Optional
17
• Do not dispose of used toner cartridges. Place them in a plastic bag and keep them. The technician will collect the used toner cartridges when performing maintenance.
• To view the approximate amount of toner remaining, continually touch the [Home Screen] key during printing or when the machine is idle. The percentage of toner remaining will
appear in the display while the key is touched.
• When the percentage falls to “25-0%”, obtain a new toner cartridge and keep it ready for replacement.
• Depending on your conditions of use, the colour may become faint or the image blurred.
MAINTENANCE
When toner runs low, the colour and the message “Prepare a new toner cartridge.” appears.
Prepare a new toner cartridge for the indicated colour.
When toner runs out, the colour and the message “Replace the toner cartridge.” appears.
Replace the toner cartridge for the indicated colour.
Example: Replacing the yellow toner cartridge
When a paper misfeed occurs, the message “A misfeed has occurred.” will appear in the touch
panel and printing and scanning will stop.
In this event, touch the [Check how to remove misfeeds.] key in the touch panel.
When the key is touched, instructions for removing the misfeed will appear. Follow the
instructions. When the misfeed is cleared, the message will automatically clear.
Old toner cartridge
Shake 5 or 6 times Gently insert straight
into the machine
until it locks
CloseOpen
New toner cartridge
1 2 3 4 5
• Do not throw toner cartridges into a re. Toner may
y and cause burns.
• Store toner cartridges out of the reach of small
children.
• Always store toner cartridges on their sides. If toner
cartridges are stored on end, the toner may harden
and become unusable.
• Please use SHARP-recommended toner cartridges.
If toner cartridges other than SHARP-recommended
toner cartridges are used, the machine may not
attain full quality and performance and there is a risk
of damage to the machine.
• The fusing unit and the output unit are hot.
• Take care not to touch the fusing unit when
removing a misfeed.
• There is a risk of burning.
Replacing a toner cartridge
Removing misfeeds
Caution
Caution
Gently pull straight
out with both
hands
16
Transmission
Storing
For functions other than copy.
OVERVIEW OF OTHER OPERATIONS
E-mail
Fax
Tap
Tap
HDD le
retrieve
Tap
Step 1Step 5
Step 3
Scan Start
Select a
function
Place the
original
Step 4
Conrmation
Step 2
Scan and store the le
Select the folder
Place the original in the automatic
document feeder
Insert all the way
Do not pass this line
Align the edges
Upward
Adjust to
original size
Align to corner
Lift open
Downward
Placing a thick book
Conrmation
Face up/down
Orientation
Missing pages
Folded pages
Select the address
Place the original on the document
glass
13
Double-tap
Lightly strike the touch panel two times.
Used to change the preview display mode, or
enlarge the preview image.
Flick Flick (quickly swipe with the nger) to scroll
the preview image.
Tap Touch and then quickly release the nger.
Used to select keys, tabs, checkboxes, etc.
Long-touch Touch a key and keep the nger on the key for
a short time.
Slide Slide the nger on the scroll bar to move up or
down through a long list.
Drag Drag (slide the nger in the desired direction)
to rotate or delete original pages displayed as
a preview.
OPERATING THE TOUCH PANEL
In addition to the conventional "single tap" operation, you can also operate the touch panel using long touches, icks, and slides.
HOME SCREEN
Operation Guide
Refer to the Operation Guide when you have
questions about operating the machine.
E-mail The scanned original is attached to an e-mail and sent.
Fax The scanned original is sent using the telephon line.
Image send The scanned original is sent to the specied destination.
Job status
System settings
FTP/Desktop
The scanned file is sent to a specified
directory of an FTP server or to a specified
folder on a computer connected to the
network.
Network folder
The scanned original is sent to the specied
shared folder on a computer connected to the
Windows network.
Displays the status of the current job.
PC scan
A TWAIN-compliant application on a computer
connected to the network is used to scan a
document or image.
Allows various settings to be adjusted
according to how the machine will be used or
its current state of use.
The home screen is the rst screen to be displayed. Touch an icon to display the
corresponding screen. When the button is pressed on the operation panel, this home
screen is displayed.
* The actual screen displayed may vary depending on the model or how the machine
has been customized.
Up to 10 icons are always displayed.
Fixed area
Up to 12 icons are displayed.
Icons that are not displayed can be displayed
by scrolling horizontally.
Scroll area
HDD le retrieve
Copy
The scanned original is printed.
The scanned original is saved.
Saved data can be edited and used again for another
operation.
14
OVERVIEW OF COPY OPERATION
Step 1Select a function Step 2Place the original
Select the Copy icon.
Tap
Select the automatic document feeder or the document glass according to the type of original.
Tap
Print 1 set of copies
Place the original on the document glass
Lift open
Placing a thick book
Align to corner
Place image-side down
Insert all the way Do not pass this line
Align the edges
Place the original in the automatic document feeder
Adjust to original size
Place
image-side
up
15
Print
Scan the original
Enter the number of prints and start printing.
Tap
Scan another original
Step 3Scan Step 4Conrming while viewing the preview
Tap
Step 5Start
Tap
Conrm the results of the scan and any edits or settings.
Drag
Conrmation Face up/down, orientation,
missing pages, folded pages
Output settings Editing
Page editing, deleting, etc.
Document ling
The scanned original and the settings are saved on the
hard disk and can be used again.
