ELECTRONIC ORGANIZER

EL-6850

EL-6890

EL-6890S

OPERATION MANUAL

CONTENTS

Using the Organizer for the First Time ........................................ 1

When Abnormal Conditions Cause a Malfunction ....................... 1

Auto Power Off Function ............................................................. 1

Backlight ..................................................................................... 1

Adjusting the LCD Contrast ........................................................ 2

Turning the Key Touch Tone On and Off ...................................... 2

Freeing Up Memory .................................................................... 2

Part Names ...................................................................................... 3

Display Symbols .............................................................................. 4

Entering Characters .......................................................................... 4

Notes for the Built-in Calendar and the Time .................................... 5

Clock Mode ...................................................................................... 5

Note For Storing the Listings ............................................................ 8

Telephone/E-mail Mode .................................................................... 9

WWW Mode ................................................................................... 11

Calendar Mode ............................................................................... 12

Schedule Mode .............................................................................. 13

Memo Mode ................................................................................... 15

Anniversary Mode .......................................................................... 16

Recalling the Listings ..................................................................... 17

Editing the Listings ......................................................................... 19

Deleting the Listings ....................................................................... 19

Secret Function .............................................................................. 20

Calculator Mode ............................................................................. 22

Currency/Unit Conversion Mode .................................................... 23

Miscellaneous Functions ................................................................ 25

Using the Option Function .............................................................. 29

Battery Replacement ...................................................................... 32

Specifications ................................................................................. 35

NOTICE

• SHARP strongly recommends that separate permanent written records be kept of all important data. Data may be lost or

altered in virtually any electronic memory product under certain circumstances. Therefore, SHARP assumes no responsibility

for data lost or otherwise rendered unusable whether as a result of improper use, repairs, defects, battery replacement, use

after the specified battery life has expired, or any other cause.

• SHARP assumes no responsibility, directly or indirectly, for financial losses or claims from third persons resulting from the

use of this product and any of its functions, such as stolen credit card numbers, the loss of or alteration of stored data, etc.

• This Organizer is not designed to visit Web sites or transfer/receive e-mails by using the URL or E-mail addresses you will

store.

• The information provided in this manual is subject to change without notice.

CAUTIONS

• Do not carry the Organizer in the back pocket of slacks or trousers.

• Do not drop the Organizer or apply excessive force to it.

• Do not subject the Organizer to extreme temperatures.

• Since this product is not waterproof, do not use it or store it where fluids can splash onto it. Raindrops, water spray, juice,

coffee, steam, perspiration, etc. will also cause malfunction.

• Clean only with a soft, dry cloth.

• Use only a SHARP approved service facility.

NOTES

• Unless otherwise specified, the text material applies to ALL 3 models.

• Some of the models described in this manual may not be available in some countries.

• All company and/or product names are trademarks and/or registered trademarks of their respective manufactures.

Using the Organizer for the First Time

Be sure to perform the following operations before using the

Organizer for the first time.

1. Press the RESET switch while holding ON . Release the

RESET switch and then release ON .

“CLEAR ALL DATA OK (Y/N) ?” is displayed.

• Under certain conditions the message may appear as

“Data has been impaired ! Press [Y] to CLEAR ALL

memory”. Proceed to the next step in either case.

2. Press Y.

3. The Organizer is now initialized. Proceed to set the date

and time of the clock. (Refer to page 7.)

Press the RESET switch with a ball-point pen or similar

object. Do not use an object with a breakable or sharp tip.

When Abnormal Conditions Cause a Malfunction

If the Organizer is subjected to strong, extraneous electrical

noises or shocks during use, an abnormal condition may

occur in which no keys (including ON ) will respond. If this

happens, press the RESET switch.

Noises or shocks may erase some or all of the Organizer’s

memory.

Auto Power Off Function

When none of the keys have been pressed for approximately

7 minutes, the Organizer automatically turns the power off to

save the batteries. (The actual time may vary depending upon

the condition of use.) Press ON to resume operation.

Backlight

The Organizer provides a built-in Backlight, which allows you

to view the display and use the Organizer even in low-light

conditions. Pressing once illuminates the display for as

long as you continue to use the Organizer, until you have not

typed any key for the interval you set. (See the following

section, “Setting up the Backlight”.)

• To turn the Backlight off, press again.

• The Backlight may remain on for less than the set interval

or it may not function if the battery level is very low.

• The Backlight does not function during data transfer.

★Do not use the Backlight unnecessarily.

• Since the Backlight drains power from the operating

batteries, excessive use of the Backlight will

significantly reduce the life of your batteries.

• Do not continue using the Organizer after it has

automatically turned itself off while the backlight was

being used. Even if it can be turned on again, the clock

time will be incorrect and other functions may not work

properly until the batteries are replaced.

Setting up the Backlight

You can change the interval after which the Backlight turns

off automatically.

1. Press 2nd MENU

2. Press or to change

interval (15 – 60 seconds).

3. Press ENTER .

Adjusting the LCD Contrast

1. Press 2nd

2. Press or to darken or

lighten the display as

required.

3. Press C•CE after adjusting the contrast.

Turning the Key Touch Tone On and Off

The key touch tone is turned on and off by pressing 2nd .

Freeing Up Memory

When you turn the power on, the following message may be

displayed, asking you to free up memory by deleting

unnecessary space.

Press Y to delete it. Freeing

up memory requires not more

than one minute.

Press N when you wish to

start the operation soon. (Refer to page 28.)

CAPS

B/L SETUP

TURN OFF AFTER

15 30 45 60

SECONDS

LCD CONTRAST

–DARK

–LIGHT

CAPS

DO YOU WANT TO

FREE UP

MEMORY ?

(Yes/No)

CAPS

Part Names

OPTION key

MENU key

Mode keys

Computer link

Cursor movement keys

Power ON key

Power OFF key

RESET switch

Search keys

: Indicates the & key.

: Indicates the numeric 7 key.

: Indicates the MENU key.

: Indicates the alphabetic Q key.

To access the symbols above the number key (*1) and “ ,”

and “ ”, press the desired key after pressing 2nd .

*1 … &, , (, $, /, ∧ , !, @, #, )

* Numbers and letters and space between them for entering

are shown as unboxed numbers and letters.

In this manual the keys are represented by symbols,

for example:

→ &

→ 7

→ 2nd MENU

→ Q

Display Symbols

:A “beep” will sound when a key is pressed.

:The schedule alarm will sound.

CAPS

:Capital (uppercase) letters will be entered. To enter

small (lowercase) letters, turn “CAPS” off by

pressing CAPS .

EDIT

:The listing on the display can be edited.

2nd

:Indicates that 2nd has been pressed. The function

or character shown in yellow (or green) above the

keypad can be used next.

:More information exists above the current display.

(Press .)

:More information exists below the current display.

(Press .)

:Secret function is in effect. (Secret listings cannot be

recalled without a password.)

:Indicates that the recalled listing is secret.

BATT

:Indicates that the operating battery level is low.

• In this manual, only the symbols necessary for

explanation will be shown.

Entering Characters

1.Moving the Cursor

The cursor ( _ or ) can be moved by pressing (or holding

down) , , , or .

2.Entering Characters

(1) Entering Letters and Numbers

After initializing the Organizer, the default setting for entering

letters will be capital (uppercase) letters. To enter small

(lowercase) letters, turn “CAPS” off by pressing

CAPS

• To enter “ ’ ” or “ : ”, press , or : after pressing 2nd .

(2) Entering graphic symbols and special characters

Press SMBL to display the symbol entry mode, allowing a

total of 90 symbols and characters to be selected. To select

the symbol display containing the desired symbol/special

character, press

or PREV , then press the number

corresponding to it.

• The first display is determined by your previous choice.

The 5 most recently used symbols/special characters are

stored and displayed on this display.

Press SMBL to exit the symbol entry mode.

3.Making Corrections

(1) Inserting characters

Press INS to change the cursor from “■” (replace) to “ ”

(insert).

Press INS again to change the cursor from “ ” to “■”.

(2) Deleting characters

Press DEL or BS to delete the character.

•DEL and BS will not operate in some cases such as

when inputting time during the schedule entry or when

using the calculator. In these cases, press the C•CE key

and reenter.

• Press C•CE to clear all characters on the current display.

Notes for the Built-in Calendar and the Time

• Calendar, Schedule, and Clock modes allow you to enter

the desired date and time between Jan. 1, 1901 and Dec.

31, 2099.

• If an attempt is made to store an invalid time or date, you

cannot move the cursor to date entering, or cannot store

time and date by pressing ENTER . Enter the correct

value and press ENTER again.

CAPS

NEW YORK [H]

MON JAN 1 01

0:00

Day of the week/

Month/Day/Year

Time

LONDON [W]

MON JAN 1 01

) 5:00

CAPS

Time

Day of the week/

Month/Day/Year

Home city indication World city indication

Clock Mode

The Organizer has both Home and World clocks. The display

switches between Home and World clock each time CLOCK

is pressed.

Home clock World clock

“(+ 5:00)” indicates the time difference from the Home city.

1.Setting the Home Clock

(1) Setting and changing the Home city

Set your local city as the Home city by selecting its zone

number.

Zone City Zone City

number number

0 10 MOSCOW

1 AUCKLAND 11 CAIRO

2 NOUMEA 12 PARIS

3 SYDNEY 13 LONDON

3.3 ADELAIDE 14

4 TOKYO 15

5 HONG KONG 16 RIO DE JANEIRO

6 BANGKOK 17 CARACAS

6.3 YANGON 18 NEW YORK

7 DHAKA 19 CHICAGO

7.3 NEW DELHI 20 DENVER

8 KARACHI 21 LOS ANGELES

8.3 KABUL 22 ANCHORAGE

9 DUBAI 23 HONOLULU

9.3 TEHRAN 24 MIDWAY

Zone numbers are based on the distance of the zones from

the international date line (zone number zero). For example,

there is a 13-hour difference between the date line and

London (London is 13 hours behind), so the zone number for

London is 13. Honolulu is 23 hours behind the date line, so

its zone number is 23.

The names and zone numbers of 27 cities are stored in the

Organizer's memory. (Refer to this page.)

1. Press CLOCK once or twice to display the Home clock.

• The initial Home city after initialization of the Organizer is

New York.

2. Press 2nd EDIT to enter the edit mode.

• “18” on the display indicates the time zone.

3. Press

or PREV to display the desired city which

correspond to your local zone from the cities stored in the

Organizer.

4. Press ENTER to set the Home city.

• Some city names are abbreviated on the display as

follows:

HONG KONG → HONGKONG, NEW DELHI → DELHI,

RIO DE JANEIRO → RIO, LOS ANGELES → L.A.,

ANCHORAGE → ANC.

• Zone numbers 0, 14, and 15 have no city name display.

(2) Setting the Clock

Set the date and time to February 8, 2001, 10:05

PM.

1. Press CLOCK once or twice to display the Home clock.

2. Press 2nd EDIT .

• The cursor will flash.

3. Enter the hour and minutes.

1005

PM (For the 24-hour clock, press

2205

(Enter 2 digits each for both hour and minutes.)

4. Enter the month, day, and year.

02082001

Use to skip entering a number that needs no change.

5. Press ENTER . The clock starts from 0 seconds.

• The time can be displayed using either the 12-hour AM/

PM system or the 24-hour system (default). To change the

time system, refer to page 27, “Selecting the Time

System”. AM or PM is displayed for the 12-hour clock. For

this example, set the 12 hour clock.

(Note: 12:00PM: noon, 12:00AM: midnight)

NEW YORK 18

MON JAN 1 01

0:03

CAPS

2.Using the World Clock

(1) Changing the city for the World clock

1. Press CLOCK once or twice to display the World clock.

2. Press 2nd EDIT to enter the edit mode.

3. Press NEXT or PREV to display the city which

corresponds to the desired zone.

4. Press ENTER .

• The date and time need to be changed in the edit mode of

the Home clock.

3.Registering a City Name not Found in the List

If you want to set the city for the World clock to Rome, for

example (Rome belongs to the zone number 12, but is not

included in the city list):

1. Press CLOCK once or twice to display the World clock.

2. Press 2nd EDIT to enter the edit mode.

3. Press

(or PREV ) to set the zone number to 12.

(Initially the city is Paris.)

4. Enter the city name (up to 8

characters).

ROME (Press

DEL

to delete unnecessary

character(s), if necessary.)

ROME 12

FRI FEB 9 ©01

4:05A

CAPS

(2) World clock

1. Press CLOCK once or twice to display the World clock.

2. Press 2nd EDIT , then 2nd

ENTER

Setting DST in the World clock automatically sets the time

one hour ahead.

• When DST is set for one World city, it is used for all cities

displayed in the World clock.

(3) Clearing DST

To clear DST, follow the steps 1 to 4 for Home clock, or

follow the steps 1 and 2 for World clock.

A “ ” disappears.

Note For Storing the Listings

If the memory is full, “MEMORY FULL” will be displayed

briefly and the listing cannot be stored. Delete unnecessary

data and free up memory to make enough space to store new

listings. (Refer to pages 26, 28.)

5. Press ENTER to store the new name.

• To register a city name for the Home clock, first display

the Home clock then 2nd EDIT followed by to

move the cursor to the city name line.

• Only one changed city name can be stored in each of the

Home and World clocks.

• Each changed name is stored until you change the zone

number next time.

4.Setting Daylight Saving Time/Summer Time

If DST (daylight saving time/summer time) is used, the local

time is advanced one hour during the summer.

• DST can be set independently in either the Home or the

World clock. For example, if DST is set for the Home

clock, it does not have to be set for the World clock.

(1) Home clock

1. Press CLOCK once or twice to display the Home clock.

2. Press 2nd EDIT to enter the edit mode.

3. Enter the correct daylight saving time/summer time.

4. Press 2nd ENTER to set the time as DST.

A “ ” appears on the display and DST is now set.

Telephone/E-mail Mode

Telephone/E-mail listings can be accessed by pressing either

of TEL or E-MAIL , while both keys recall the same stored

listings respectively in each order on the display.

TEL recalls and displays the listing in the following order:

NAME → NUMBER → ADDRESS → E-MAIL, while E-MAIL

does in the following order: NAME → E-MAIL → NUMBER

→ ADDRESS.

Further, Telephone/E-mail listings are divided into 2 files

(TEL/MAIL1, TEL/MAIL2). You can switch them for

convenience by using one for business and one for personal.

The files are cycled each time you press TEL or E-MAIL .

↔

TEL/MAIL 1

NAME ?

( TEL MODE )

CAPS

TEL/MAIL 2

NAME ?

( TEL MODE )

CAPS

TEL/MAIL 1

NAME ?

(E–MAIL MODE)

CAPS

TEL/MAIL 2

NAME ?

(E–MAIL MODE)

CAPS

TEL

E-MAIL

135

the same stored listing

135

the same stored listing

In Telephone/E-mail mode, a listing consists of 4 entries:

name, number, postal address, and E-mail address. The

maximum number of characters that can be entered for each

listing is 512 in all.

Number entry

Address entry

→

E-mail address entry

→

NUMBER ?

CAPS

ADDRESS ?

CAPS

E–MAIL ?

CAPS

Name entry

TEL/MAIL 1

NAME ?

( TEL MODE )

CAPS

←

1.Designating the File Names

You can change each file name up to 10 characters long as

follows:

1. Press 2nd MENU

2. Enter the new name for TEL/

MAIL1, then press ENTER .

CAPS

FILE NAME

1: [TEL/MAIL 1]

2: [TEL/MAIL 2]

3: [ URL ]

Space

edwards@abcd.e

fg.com–

6. Press ENTER , then enter

the E-mail address. For

example,

edwards@abcd.efg.com

7. Press ENTER .

“STORED !” will be displayed briefly, then the listing will

be displayed.

• To skip entering the number, address, or E-mail address,

press ENTER when “NUMBER ?”, “ADDRESS ?”, or “E-

MAIL ?” is displayed. However, the name entry can not be

skipped.

• Regardless of the entry order, listings in the Telephone/E-

mail mode are stored internally according to the first

character of the person’s name in the following order:

201–265–5600

CAPS

F 265–1234–

Edwards Bob–

Supervisor

Sales dept.

ABCD co.

15 North St.–

• You can skip changing an each file name by pressing

ENTER .

• To cancel entering the filenames, press C•CE twice.

3. Perform the same procedure as step 2 for TEL/MAIL2 and

URL.

4. Press TEL , E-MAIL , or WWW to check the new file

name(s).

2.Storing Telephone Listings

1. Press TEL to display the TEL/MAIL1 entry prompt.

2. Enter the name. For example,

Edwards Bob

3. Press ENTER .

The number entry prompt is displayed.

4. Enter the phone number.

For example,

201-265-5600

F 265-1234

5. Press ENTER , then enter the address. For example,

Supervisor

Sales dept.

ABCD co.

15 North St.

WWW Mode

WWW mode is used exclusively for storing URL (Uniform

Resource Locator) and its remark which reminds you of the

URL contents. In this mode, a WWW listing consists of 3

entries: name, URL, and remark.

1.Storing WWW Listings

1. Press WWW to display the

name entry prompt.

2. Enter the name. For example,

SHARP ELECTRONICS CO.

3. Press ENTER .

The URL entry prompt

including “www.” is

displayed.

• You can edit “www.” if necessary.

4. Enter the URL. For example,

sharp-usa.com

URL

NAME ?

CAPS

www.sharp–usa.

com–

URL ?

CAPS

www.–

5. Press ENTER .

The REMARK entry prompt is displayed.

6. Enter the Remark. For

example,

ELECTRONICS

7. Press ENTER .

“STORED !” will be

displayed briefly, then the

listing will be displayed.

• The maximum number of characters (including “www.”)

that can be entered for each listing is 512 in all.

SHARP ELECTRON

ICS CO.

www.sharp–usa.

com

CAPS

ELECTRONICS–

CAPS

Calendar Mode

Calendar mode is selected by pressing SCHEDULE once or

twice. Each time you press this key, the display switches

between Calendar and Schedule modes.

1.Controling the Monthly Calendar Display

The Organizer has a 4-line display and 4 weeks of a month

can be displayed. Use the following keys to control the

display status.

:display the following (or previous) month.

•Hold down either of these keys for rapid

recall.

:move the cursor or scroll the calendar up

(or down) one week.

1. Press SCHEDULE once or

twice to display the Calendar

mode.

•“ ” indicates the first week of the month is hidden

above. To display the first week, press until the cursor

scrolls into the previous screen.

2. Press

( PREV ) to display the calendar for the

next (previous) month.

• In the year display, a “ ’ ” is attached to the years 1901 to

1999, while no mark is attached to the years 2000 to

2099.

2.Returning the Calendar to the Current Date

Press 2nd SCHEDULE in Calendar mode.

• The current monthly calendar will be displayed, and the

current date will flash.

CAPS

THU FEB 8 '01

TIME ?

CAPS

↔

Calendar mode Schedule mode

Schedule Mode

Schedule mode is selected by pressing SCHEDULE once or

twice. Each time you press this key, the display switches

between Schedule mode and Calendar mode.

A schedule listing consists of 3 entries: date, time, and detail.

The maximum number of characters for each detail is 512. In

the date entry, 4 digits can be entered for the year and 2

digits each for the month, day, hour, and minute.

1.Storing Schedule Listings

There are 3 ways to entering the desired date:

(1) Entering the desired date in Calendar mode

(2) Entering the desired date with NEXT (or PREV )

(3) Entering the desired date directly

After the date has been entered, actual entry of time and

detail is the same for all 3 ways.

(1) Entering the desired date in Calendar mode

Enter the following data.

“Lunch with Tom” from 11:30 AM to 1:00 PM on

February 24, 2001.

1. Press 2nd SCHEDULE in Calendar mode to display the

calendar for the current date (February 8, 2001).

2. Press , , , or to move the cursor to February

24, 2001.

3. Press SCHEDULE to

change to the Schedule

mode. Time entry prompt is

displayed.

• Multiple listings can be scheduled on the same date.

4. Enter the starting and ending time.

1130

(For the 24-hour clock, press 1130 13 .)

“DESCRIPTION ?” is displayed.

• “:00” will be entered automatically.

• You can enter schedule details without the ending time.

Press ENTER (or ) after entering the starting time to

display “DESCRIPTION ?” prompt.

• You can also enter schedule details without specified time,

except details starting with a number. Skip entering time

and start to enter letters for the details as described in

step 5.

• The hour and minute should each consist of 2 digits.

SAT FEB 24 '01

TIME ?

CAPS

SAT FEB 24 '01

11:30A~ 1:00P

Lunch with Tom

–

• The time can be set using either the 12-hour or 24-hour

format. When you move the cursor to the next entering,

the time is displayed in the format selected in the Time

System of the MENU functions.

• If an attempt is made to store an invalid time, you cannot

move the cursor to the next entering. Enter the correct

time and follow the next procedure.

5. Enter the schedule detail.

Lunch with Tom

6. Press ENTER to store the listing.

7. Now, press SCHEDULE to

check if the listing is stored

in memory.

• Notice the tag ( ) next to “February 24”. It indicates a

schedule item for that date:

Schedule item beginning in the morning

Anniversary item

Schedule item beginning after the noon

(2) Entering the desired date with

(or PREV )

This way is convenient for entering a nearby date. Press

(or PREV ) and change the display day by day until

the desired date appears.

Enter a schedule listing on February 11, 2001.

1. Press SCHEDULE once or twice to display the Schedule

mode screen.

2. Press 2nd SCHEDULE to display time entry prompt for

the current date (February 8, 2001).

3. Press

repeatedly until time entry prompt for

February 11, 2001 appears. Enter the time and detail

following the procedure for “(1) Entering the desired date

in Calendar mode” (from step 4) on page 13.

(3) Entering the desired date directly

When the date is not close to the currently displayed date,

this way is more convenient than the above 2 ways.

Enter a schedule listing on November 26, 2001.

1. Press SCHEDULE C•CE

to display the date entry

prompt.

MM/DD/YYYY

MONTH :02

DAY :08

YEAR :2001

CAPS

2. Enter the date.

11262001

3. Press ENTER . Time entry prompt (or Calendar) for

November 26, 2001 is displayed. Enter the time and detail

following the procedure for “(1) Entering the desired date

in Calendar mode” from step 4 (or from step 3) on page

13.

• If an attempt is made to store an invalid date, you cannot

move to the time entry prompt. Enter the correct date and

follow the next procedure.

2.Schedule Alarm

Schedule alarm sounds for approximately 20 seconds when

the time set for a schedule listing is reached. The alarm

sounds when a “ ” is on the display.

Press 2nd to turn the “ ” on and off.

• When the “ ” is turned on, alarms will sound for all

schedule listings with that starting time. You cannot

classify or declassify each listing.

• Press C•CE to turn the alarm off.

Memo Mode

Memo mode is selected by pressing

MEMO/ANN

once or

twice.

The maximum number of characters for each memo is 512.

1.Storing Memo Listings

1. Press

MEMO/ANN

once

or twice to display the

Memo entry prompt.

2. Enter the data.

3. Press ENTER .

MEMO

CAPS

TITLE ?

Anniversary Mode

Anniversary mode is selected by pressing

MEMO/ANN

once

or twice. Each time you press this key, the display switches

between Memo and Anniversary modes.

In Anniversary mode, you can store anniversaries, such as

birthdays, so that you can recall these important dates easily.

Once a date is stored as an anniversary, the date will be an

anniversary for every year from 1901 to 2099.

The maximum number of characters for each label is 512.

Anniversaries are marked with a tag ( ) in the center right of

the date in the monthly calendar.

1.Storing Anniversary Listings

1. Press

MEMO/ANN

once or

twice to display the

Anniversary entry prompt.

2. Enter the date and press

ENTER (or ) to enter the

label. For example,

0212

ENTER

FEB 12

–ANN–

Nancy's Birthd

ay–

FEB 12

–ANN–

DESCRIPTION ?

FEB 12

–ANN–

Nancy's Birthd

M/D=– /

–ANN–

M=MONTH D=DAY

CAPS

• If an attempt is made to store an invalid date, you cannot

move to the label entry prompt. Enter the correct date and

follow the next procedure.

3. Enter the label of the

anniversary. For example,

Nancy’s Birthday

4. Press ENTER to store in

memory.

Recalling the Listings

1.Notes for Recalling the Listings

• Perform searching the listings in each mode other than

Clock, Calculator, or Conversion mode.

• When the symbol “ ” or “ ” is displayed, more

information exists. Pressing or scrolls up or down

one line.

• When there are no more (or relevant) listings to be

recalled or to be searched, “NOT FOUND !” is displayed

briefly and the display returns to the entry prompt.

2.Sequential Search

Recalls listings in order in each mode.

Press NEXT (or PREV ) to recall listings in forward (or

reverse) order. Hold down either of these keys for rapid

recall.

Schedule listings

• When nothing has been entered for that day, only the time

entry prompt is displayed.

• Press 2nd SCHEDULE in Schedule mode to recall

today’s schedule listings. Then press NEXT repeatedly to

check if the other listings are scheduled for today.

• Press 2nd NEXT (or 2nd PREV ) in Schedule mode

repeatedly to recall listings skipping empty dates. Press

C•CE C•CE , then press 2nd NEXT (or 2nd

PREV ) to display the first (or last) listing in chronologi-

cal order. After the last (or first) listing in chronological

order has been found, “NOT FOUND !” is displayed briefly.

3.Direct Search

Recalls listings by the first character(s) of the name (or the

contents) in Telephone/E-mail, WWW, Schedule, or Memo

mode.

1. Enter the first character(s) of the desired name in each

mode.

2. Press NEXT (or PREV ).

• The search in Schedule mode begins from the currently

displayed date in forward (or reverse) order.

• If the desired listing in Telephone/E-mail or WWW mode is

not in memory, the subsequent listing in sequential order

will be displayed.

• Each time NEXT (or PREV ) is pressed, sequential

search will be performed.

4.Keyword Search

Recalls listings by a word contained in the desired listing in

Telephone/E-mail, WWW, Schedule, or Memo mode.

Recall listings containing the word “ABCD co.”

in the TEL/MAIL1 file.

1. Press TEL to display the TEL/MAIL1 file.

2. Enter the keyword.

ABCD CO.

• The keyword can be entered in either capital (uppercase)

or small (lowercase) letters.

The listings will be recalled regardless of whether the

keyword is entered in capital (uppercase) or small

(lowercase) letters.

3. Press 2nd NEXT .

• Each time 2nd NEXT are

pressed, subsequent listings

containing the word “ABCD

co.” will be displayed.

5.Date Search

Recalls listings by the date in Calendar, Schedule, or

Anniversary mode.

Calendar or Schedule listings

Recall the calendar for December 25, 2001.

1. Press SCHEDULE .

2. Press C•CE to display the

date entry prompt. To make

a correction, move the

cursor with or , or

press C•CE to clear the displayed date.

3. Enter the month, day, and year.

12252001

• To enter a single-digit month or day, enter zero and the

digit.

4. Press ENTER .

The specified calendar or schedule will be displayed.

Anniversary listings

In the Anniversary entry prompt, enter the date and then

press NEXT (or PREV ).

MM/DD/YYYY

MONTH :02

DAY :08

YEAR :2001

CAPS

Edwards Bob

201–265–5600

F 265–1234

Supervisor

CAPS

Editing the Listings

1.Editing Listings

1. Recall the listing to be edited.

2. Press 2nd EDIT to enter the edit mode. The cursor

flashes.

3. Edit the listing.

4. Press ENTER .

2.Creating a New Listing

Pressing 2nd ENTER in step 4 above creates a new listing

without deleting the previously stored listing.

This operation is useful when you enter a new listing whose

contents are the same as or similar to the previously stored

listing.

Deleting the Listings

1.Deleting One Listing

1. Recall the listing to be deleted.

2. Press DEL . “DELETE ? Y/N” will appear.

3. Press Y to delete the currently displayed listing.

• To cancel the deletion operation, press

2.Deleting All of the Listings in Each Mode

Refer to “4. Deleting the Data” on page 26.

Deleting all of the listings for an entire month

1. Press SCHEDULE once or twice to recall the calendar for

the desired month.

2. Press DEL . “DELETE ? Y/N” will appear.

3. Press Y to delete all of the schedule listings for the

currently displayed month.

• To cancel the deletion operation, press

• Although all of the schedule listings for the month are

deleted, anniversaries are still retained.

Secret Function

The Secret function allows you to protect confidential listings

with a password, so that no unauthorized person can recall

them.

1.Registering a Password

Up to 7 characters can be registered for the password.

If you forget the password, it will be necessary to

clear the password and all secret listings from the

memory (see page 27). As a safeguard, make a

written record of the password.

1. Press 2nd SECRET .

• If “ALLOW ACCESS TO

SECRET DATA” is displayed

instead, a password is

already registered.

To delete and change the password, refer to page 22.

2. Enter the password. For example,

1234567

ENTER

“PASSWORD [1234567] IS NOW SET” is displayed.

SET PASSWORD

[– ]

CAPS

ALLOW ACCESS

TO SECRET DATA

[– ]

CAPS

3. Press C•CE to display the entry prompt.

A “ S” indicates the Secret function is in effect.

2.Turning the Secret Function On and Off

When the Secret function is on, a “ S” is displayed. When

the Secret function is off, the “ S” is cleared even after the

password is registered.

(1) Turning the Secret function off

1. Press 2nd

SECRET

2. Enter the password and

press ENTER .

(Enter “1234567” in this case.)

“SECRET DATA ACCESSIBLE !” is displayed briefly. The

Secret function is now off and secret listings can be recalled.

The display changes into the entry prompt without the “ S”.

• If the incorrect password is entered, “INCORRECT

PASSWORD !” will be displayed briefly and the display

changes into the entry prompt.

• Even after the Secret function is turned off, the Secret

function will automatically be turned on after manual or

auto power off.

(2) Turning the Secret function on

1. Press 2nd SECRET .

2. Press 1 to select “1: HIDE

SECRET”.

“SECRET DATA IS HIDDEN !” is displayed briefly. The

secret function is now on and secret listings cannot be

recalled. The display changes into the entry prompt with

the “ S”.

3.Designating Listings as Secret

Only one password can be registered, but many secret

listings can be entered.

A “ ” next to a listing indicates it is secret. Secret listings

cannot be recalled unless the Secret function is off.

(1) Storing listings as secret

Press 2nd MARK to display the “ ” during the entry

procedure and store the listing.

(2) Designating stored listings as secret

Designate the listing for “Edwards Bob” as

secret.

2:DELETE THE

PASSWORD

1:HIDE SECRET

CAPS

Edwards Bob

201–265–5600

F 265–1234

Supervisor

CAPS

Edwards Bob

201–265–5600

F 265–1234

Supervisor

EDIT

CAPS

1. Recall the listing.

2. Press 2nd EDIT .

3. Press 2nd MARK .

The “ ” is displayed.

4. Press ENTER .

The listing for “Edwards Bob” is now designated as secret.

4.Changing Secret Listings to Non-Secret

1. Turn the Secret function off. (Refer to page 20.)

2. Recall the desired secret listing.

3. Press 2nd EDIT .

4. Press 2nd MARK . A “ ” is cleared.

5. Press ENTER .

The secret listing is now changed to non-secret.

5.Recalling (and Editing) Secret Listings

Perform recalling (or editing) secret listings in each mode.

To recall (and edit) secret listings, the Secret function must

first be off.

▲

(1) Recalling only the secret listings

1. Turn the Secret function off. (Refer to page 20.)

2. Press the desired mode key (other than that for Calendar,

Calculator, or Conversion mode) to display the entry

prompt.

3. Press 2nd MARK . The “ ” is displayed.

4. Press 2nd NEXT (or 2nd PREV ).

The secret listings only are sequentially recalled.

• If no secret listing is found, “NOT FOUND !” is displayed

briefly and the display returns to the entry prompt.

6.Deleting and Changing the Password

1. Turn the Secret function off.

(Refer to page 20.)

2. Press 2nd SECRET .

3. Press 2 to select “2 : DELETE THE PASSWORD”.

4. Enter the old password to be deleted and press ENTER .

“PASSWORD IS DELETED !” is displayed briefly and the

display changes into the entry prompt.

5. To register a new password, follow the procedure

described in “1. Registering a Password” on page 20.

2:DELETE THE

PASSWORD

1:HIDE SECRET

CAPS

↔

Calculator Mode

Press CALC/CONV once or twice to select Calculator mode.

Each time you press CALC/CONV , the display switches

between Calculator and Conversion modes.

The Organizer can calculate numbers up to 12 digits long.

1.Calculation

Before performing a calculation, press C•CE C•CE and

CM to clear the display and memory.

When +, –, , , M+, or M– is pressed, the

respective symbol, “+”, “–”, “×”, “ ”, “M+”, or “M–” is

displayed. When

or % is pressed, the symbol “=” is

displayed. (In the examples, these symbols are not

described.)

2.Errors

When the integer part of a calculation result or any integer in

the memory exceeds 12 digits, or other invalid operations are

attempted, an error will occur. (“–E–” will appear.) Press

C•CE to clear the error.

CALC

CAPS

CONVERSION

[1] $ £

CAPS

Example Operation Display

(–24+2) 4=–5.5 – 24 + 2 4 = *1 –5.5

34+57=91 34 + 57 =91.

45+57=102 45 =102.

68×25=1700 68 25 =1700.

68×40=2720 40 =2720.

200×10%=20 200 10 %20.

9 36=25(%) 9 36 %25.

200+(200×10%)=220

200 + 10 %220.

500–(500×20%)=400

500 – 20 %400.

46=(43)2=4096 4 = = =4096.

1/8=0.125 8 =0.125

25 ×5=125 CM 25 5 M+–M– 125.

–)84 3= 28 84 3 M––M– 28.

+)68 +17= 85 68 +17 M+–M– 85.

182 RM –M– 182.

25–9=4 25 – 9 = 4.

–E–

123456789098×145 123456789098 145

17.9012344192

=17901234419210 C•CE 17.9012344192

(17.9012344192×10

=17901234419200)

*1 – (minus) can only be used when entering a negative

number as the first number. Use +/– for following

negative numbers during calculation.

5 × (–10)=–50

5 10 +/–

No. Currency/Unit Conversion

AB Rate

1$ £ 0

2$ 0

3DM 0

4 inch cm 2.54

5 oz g 28.35

6°F°C (°F-32) × 5/9

Currency/Unit Conversion Mode

Each time you press CALC/CONV , the display switches

between Calculator and Conversion modes.

Currency conversion, such as from $ to £ and from $ to ,

can be performed. Unit conversions, such as from

centimeters to inches, are also possible. The following

currencies and units in the Organizer are factory installed.

CONVERSION

198

1.8

[1] $ £

CAPS

CONVERSION

356.4

1.8

[1] $ £

CAPS

CONVERSION

[1] $ £

CAPS

CONVERSION

1.8

[1] $ £

CAPS

• The rates in the above table show the value of B when A

equals 1. Conversion from B to A (for example, from £ to

$) is also possible.

• Currencies No. 1 to No. 3 can be changed. Set the correct

rate before using the conversion function. Units and rates

for items No. 4 to No. 6 cannot be changed.

• The Organizer can calculate numbers up to 12 digits long.

1.Setting a Rate

Set the following rate: $1 = £1.8

1. Press CALC/CONV once or

twice to select Currency/Unit

conversion mode.

2. Press NEXT (or PREV ) to select the currency or unit

that the rate is to be set for.

3. Enter the rate.

2nd EDIT

1.8

ENTER

• The rate can be entered up to 10 digits long.

2.Converting Currency/Unit

To convert unit A to unit B, press .

To convert unit B to unit A, press .

Convert $198 to £.

1. Press NEXT (or PREV ) to select the unit. (In this

example, select No. 1: $1 = £1.8.)

2. Enter the value to be

converted.

198

3. Press to convert it.

The symbol, “→”, changes to

“” and the conversion result

is displayed.

• After setting each rate, you can perform a consecutive

conversion such as from £ to $, and then from $ to .

After having finished the conversion No. 1 (from £ to $),

and when you press NEXT to select the conversion No.

2 (from $ to ), the conversion result to $ remains on

the display. Pressing once converts the result from $

to .

Convert 25°C to °F.

CONVERSION

77.

[6]

F C

CAPS

˚˚

1. Press NEXT (or PREV ) to select the unit. (In this

example, select No. 6. For No. 6, the rate is not displayed.)

2. Enter the value to be converted.

3. Press to convert it.

• The conversion result may have a slight calculation error

as a result of rounding off the number. Use the conversion

result for reference.

3.Changing the Unit Name

Only items No. 1 to No. 3 can be changed. While changing

the unit name, you can also set the rate at a time.

1. Select the currency or unit to be changed and press 2nd

EDIT .

The cursor will flash on the rate field.

2. Enter the rate.

3. Press to move the cursor to the unit name field.

4. Press and to move the cursor to the adequate

position and enter the new unit name.

5. Press ENTER after the new names and rate have been

entered.

Miscellaneous Functions

By pressing 2nd MENU , you can perform the following

operations:

.... 1. Setting the Daily Alarm

.... 2. Checking the Memory

Storage

.... 3. Adjusting the LCD

Contrast

.... 4. Deleting the Data

.... 5. Changing the File Names

.... 6. Setting Up the Backlight

.... 7. Selecting the Time

System

.... 8. Freeing Up Memory

1:SET ALARM

2:MEMORY CHECK

3:LCD CONTRAST

CAPS

1:DELETE DATA

2:FILE NAME

3:B/L SETUP

CAPS

1:TIME SYSTEM

2:FREE UP MEM.

CAPS

↓↑

NEXT PREV

↓↑

NEXT PREV

• Even after you have designated an each file name for TEL/

MAIL1, TEL/MAIL2, or URL, “T/M1”, “T/M2”, or “URL”

does not change according to the names you stored.

(Refer to page 9.)

3. Press NEXT again to display the number of listings

stored in Memo, Schedule and Anniversary files.

4. Press C•CE to return to the display on which you were

before pressing MENU .

• When the amount of memory used is reaching almost F

(FULL), delete unnecessary data and free up memory to

make enough space to store new listings.

• Since the same memory is used for Telephone, Schedule,

Anniversary, and Memo modes, the number of listings

that can be stored in each of these modes will vary

depending on the situation of the other modes.

3.Adjusting the LCD Contrast

See page 2 for operation.

4.Deleting the Data

(1) Deleting all of the data in each mode

If all of the entire data for Telephone/E-mail, WWW, Schedule,

Anniversary, or Memo mode is unnecessary, you can delete

all of the data in each mode individually.

0:00 OFF

[O] to ON/OFF

DAILY ALARM

1.Setting the Daily Alarm

When the time clock reaches the alarm time, it beeps for

approximately 1 minute. Press C•CE to turn the alarm off.

1. Press 2nd MENU 1 to

display the daily alarm

screen.

2. Enter the time.

3. Press O to turn on the alarm.

You can turn the daily alarm on and off each time you

press O.

4. Press ENTER .

2.Checking the Memory Storage

1. Press 2nd MENU 2.

The amount of memory in

use is displayed graphically.

2. Press NEXT .

The number of listings

stored in TEL/MAIL1, TEL/

MAIL2 and URL (WWW)

files is displayed.

MEMORY CHECK

EMPTY FULL

E ––––––– F

T/M 1:30

T/M 2:9

URL :8

E ––––––– F

Delete all listings in the TEL/MAIL1 file.

1. Press 2nd MENU NEXT 1.

2. Press 1 to select TEL/MAIL1.

“DELETE ? Y/N” is displayed.

• After performing the step 1, press the followings keys in

other modes:

TEL/MAIL2: 2

WWW (URL): 3

Schedule: NEXT 1 1

Anniversary: NEXT 1 2

Memo: NEXT 2

• When the Secret function is on, “SECRET ON MODE” is

displayed and the file cannot be deleted. In this case, turn

the Secret function off (page 20) and repeat the above

procedure.

• Even after you have designated the file name, the message

does not change accordingly.

3. Press Y.

• To cancel the deletion operation, press N.

• All listings in the TEL/MAIL1 file (including secret listings)

will be deleted.

(2) Deleting the password and secret listings

The password and all secret listings can be deleted at the

same time.

1. Press 2nd MENU NEXT 1.

2. Press NEXT

“ALL SECRET DATA DELETE ? Y/N” is displayed.

3. Press Y.

• To cancel the deletion operation, press

• “DELETED !” is displayed briefly and the password and all

secret listings are deleted.

5.Changing the File Names

See page 9, “Designating the File Names” for operation.

6.Setting Up the Backlight

See page 2 for operation.

7.Selecting the Time System

The time system can be switched between 12-hour and

24-hour format.

1. Press 2nd MENU NEXT

NEXT 1.

2. Press or to select

“12” (12-hour) or “24” (24-hour).

3. Press ENTER .

TIME SYSTEM

12 24

CAPS

DO YOU WANT TO

FREE UP

MEMORY ?

(Yes/No)

CAPS

8.Freeing Up Memory

Deleting or modifying data during operation can produce

unnecessary space in the memory of the Organizer.

Execute the deletion operation of the unnecessary space by

freeing up memory, when the Organizer displays “MEMORY

FULL”.

1. Press 2nd MENU NEXT NEXT .

2. Press 2 to start freeing up memory.

• “WORKING...” is displayed indicating that the memory is

being freed up now.

• The following situations may display the message shown

below.

– When the power is turned on.

– When you performed the

operation, “4. Deleting the

Data” on page 26.

(It is recommended to press Y to free up memory.)

• The indication “Replace the OPERATING batteries !”

shown at the time of freeing up memory means that the

operating batteries are almost exhausted. Replace them

with new ones then try again to free up memory.

• The backlight function does not work while the memory is

being freed up.

• The Backlight is nullified during data transfer. (When the

Backlight is turned on, it is automatically turned off at the

beginning of data transfer.)

• When the Organizers are not in the same mode before

transferring data by entry or mode, “DATA ERROR !” is

displayed and no data transfer is allowed.

However, directories in the TEL (or E-MAIL) and WWW

mode are excluded from this rule. For example, data in the

TEL/MAIL1 directory can be transferred to the WWW

directory.

• When the communication cable is disconnected during

data transfer, “I/O DEVICE ERROR !” is displayed. Press

C•CE

to clear the error, check that the Organizers are

connected correctly, and then start the steps again.

• The indication “Replace the OPERATING batteries !”

shown when

2nd

OPTION

are pressed means that the

operating batteries are almost exhausted. Replace them

with new ones then try again to transfer data.

• When “MEMORY FULL” is displayed and data transfer is

aborted, delete unnecessary data on the receiving

Organizer, then start the steps from the beginning.

Using the Option Function

You can share the specific data, the data in the specific mode,

or the whole data (for the purpose of making a backup copy

or restoring the data) by transferring it to/from another

EL-6850/6890/6890S.

• Backup data transfer is only possible between identical

models.

• Communicating with another EL-6850/6890/6890S

requires the optional cable “CE-260L”.

1. Cautions and Special Notes for Data Transfer

• Turn off the secret function before transferring data by

mode. If the secret function is turned on, data cannot be

transferred by mode.

• After data transfer, the data on the transfering Organizer is

preserved.

• Alarm setting is ignored. The alarm will not sound during

data transfer.

• The Auto power off function is disabled in all the transfer

modes.

• The indication “WORKING...” shown on the side of the

receiving Organizer at the beginning or end of the data

transmission means that the memory has begun to be

freed up automatically.

2.Transferring Data between Organizers

The single data entry or entire data in a mode (TEL, E-MAIL,

WWW, SCHEDULE, MEMO, ANN) can be transferred between

Organizers.

• Turn both of the Organizers off first before connecting

them with the optional cable. (CE-260L)

ASD

COMPUTER LINK

2nd

ASD

COMPUTER LINK

• When an error occurs, “I/O DEVICE ERROR!” is displayed

on the receiving or transferring Organizer, or on both

ones.

1. Press the desired mode key, or recall a listing to be

transferred on the transferring Organizer.

• To transfer all the data by mode, press the mode key to

display the entry prompt. To transfer the data by entry,

recall the desired listing.

2. Press 2nd

OPTION

both the Organizers.

The following menus are

displayed.

3. Press 2 on the receiving

Organizer to select RECV

(RECEIVE).

4. Press 1 on the transferring Organizer to select SEND.

SEND

BACKUP

RECV

RESTORE

VERIFY

UNIT TO UNIT

CAPS

RECEIVING

UNIT TO UNIT

MODE

CAPS

Transferring data between Telephone/E-mail mode and

WWW mode

Transferring data is possible between Telephone/E-mail mode

and WWW mode. When TEL (or E-mail) data is transferred to

WWW data, the E-mail (or postal) address is displayed

followed by the postal (or E-mail) address on the receiving

Organizer. The E-mail (or postal) address returned to the

transferring Organizer is relocated to its original field.

3. Transferring Data to Make Backup

All data in the Organizer can be transferred to another

EL-6850/6890/6890S.

1. Press

2nd

OPTION

on both the Organizers.

2. Press

on the receiving

Organizer to select

RESTORE.

3. Press

on the transferring

Organizer to select BACKUP.

A confirmation message is

displayed.

RECEIVING

UNIT TO UNIT

BACKUP

MODE

CAPS

SEND OK ? Y/N

UNIT TO UNIT

BACKUP

CAPS

5. Data transfer is started.

• To interrupt data transfer, press

Messages are displayed on the respective Organizers

while data is being transferred.

Transferring Organizer Receiving Organizer

When these messages are no longer displayed, the data

transfer is completed.

To verify the listing after it has been transferred, select

(VERIFY) on the receiving Organizer in step 3.

The following message is

displayed.

If any discrepancies are found, “VERIFY ERROR !” is

displayed.

–VERIFYING–

UNIT TO UNIT

CAPS

–RECEIVING–

UNIT TO UNIT

CAPS

–SENDING–

UNIT TO UNIT

CAPS

Battery Replacement

Batteries used

Type Model Quantity Use

Lithium battery CR2032 2 Unit operation

Lithium battery CR2032 1 Memory backup

• Do not remove both the operating and memory

backup batteries at the same time. Doing so will clear

the memory of its contents.

• Be sure to write down any important information

stored in memory before replacing the batteries.

1.Precautions

Since improper use of the batteries may cause leakage or

explosion, strictly observe the following instructions.

• Insert the battery with its positive side (+) correctly

positioned.

• Never throw batteries into a fire because they might

explode.

• Keep batteries out of reach of children.

4. Press Y to the confirma-

tion on the transferring

Organizer.

Backup data transfer is

started. Messages are

displayed on the respective

Organizers while the data is

being transferred. When these messages are no longer

displayed, the backup data transfer is completed.

Make sure you really want to delete all the data in the

receiving Organizer before executing the “Restore”

function. Once you start the restoration process, all the

data in the receiving Organizer will be deleted, even if you

cancel the restoration process.

–SENDING–

UNIT TO UNIT

CAPS

–RECEIVING–

UNIT TO UNIT

CAPS

• When batteries become weak, remove them from the

Organizer immediately to avoid battery leakage and

corrosion inside the Organizer.

Because the batteries in the Organizer were installed at the

factory, they may become depleted before the specified

expiration time is reached.

2.Operating Batteries Replacement

(1) Battery replacement time

When “

BATT

” is displayed, immediately replace the

batteries with new ones. If the battery level is very low, the

alarms or the key touch tone may not sound, or similarly the

Backlight may remain on for less than the set interval or it

may not function. Continued use of the Organizer with

consumed batteries can alter or clear the memory contents.

Memory contents may be lost if the batteries are improperly

replaced or if the following instructions are disregarded.

(2) Replacing the batteries

• Make sure the power is turned off before replacing the

batteries.

• Do not press ON until the battery replacement

procedure is completed.

1. Press OFF to turn the power off.

2. Loosen the screw (counter clockwise) and

remove the battery holder cover on the

back of the unit.

3. Remove the used batteries using a ball-

point pen or similar object.

• Do not use a mechanical pencil or sharp

pointed object.

4. Install two new batteries with the positive sides (+) facing

up.

5. Replace the holder cover and secure it with the screw.

6. The power will be turned on 2 to 3 seconds after ON is

pressed. If the power does not come on, press the RESET

switch.

7. Set the clock to the correct time.

3.Memory Backup Battery Replacement

(1) Battery replacement frequency

• Replace the battery every 5 years.

MEMORY BACKUP BATTERY

INSTALLATION DATE

MONTH

• YEAR •

When you start to use the Organizer, write down the date on

the label of the Organizer, so that you know when to replace

the battery the next time. For example,

(2) Precautions when replacing the memory backup bat-

tery

• If the memory backup battery is replaced when the

operating batteries are depleted, memory contents will be

lost. Make sure the operating batteries are not depleted. If

the operating batteries are depleted, first replace these

before replacing the memory backup battery.

(3) Replacing the battery

1. Press OFF to turn the power off.

2. Loosen the screw (counter clockwise) and

remove the battery holder cover on the

back of the unit.

02 2001

3. Remove the memory backup battery seal.

4. Remove the used battery using a ball-

point pen or similar object.

• Do not use a mechanical pencil or sharp

pointed object.

5. Install a new battery with the positive side (+) facing up.

6. Replace the seal and the holder cover and secure the

cover with the screw.

7. The power will be turned on 2 to 3 seconds after ON is

pressed. If the power does not come on, press the RESET

switch. If nothing appears on the display again, replace

the operating batteries.

WWW mode: Entry and recall of names, URL, and remarks

Calendar mode: From Jan., 1901 to Dec., 2099, Schedule

mark function distinguishing between morning,

afternoon, and anniversary

Schedule mode: Entry and recall of schedule (year, month,

day, hour and minute), schedule alarm

Anniversary mode: Entry and recall of month, day, and labels

of anniversaries

Memo mode: Entry and recall of memo listings

Calculator mode: 12 digits (with calculation status symbol)

Addition, subtraction, multiplication, division, percentage,

square root, memory calculation, etc.

Currency/Unit conversion mode: 10 digits, 6 kinds of

currencies and units

Power consumption: 0.1 W

Operating temperature: 0°C – 40°C (32°F – 104°F)

Power supply: Operating battery: 6V (DC)

(Lithium battery CR2032×2)

Memory backup battery: 3V (DC)

(Lithium battery CR2032×1)

Specifications

Models: EL-6850, EL-6890, EL-6890S

Product name: Electronic Organizer

Display: 14 columns × 4 lines

Memory capacity: EL-6850 129680 bytes

EL-6890 260752 bytes

EL-6890S 260752 bytes

Clock mode:

Accuracy: ±30 seconds/month (at 25°C/77°F)

Display: Year, month, day, day of the week, hour,

minute, AM/PM, city name, time zone

Clock system: 12-hour/24-hour format (switchable)

World clock function, daylight saving

time/summer time display function,

daily alarm function

Telephone/E-Mail mode: Entry and recall of names,

numbers, postal addresses, and E-mail addresses

Battery life:

Operating batteries (at 25°C/77°F)

• Approx. 1200 hours; When data is continuously

displayed without Backlight.

• Approx. 300 hours; When data is continuously displayed

with Backlight for 2 minutes per hourly use.

• Approx. 270 hours; When data is searched for 5 minutes

and displayed for 55 minutes per hourly use and

Backlight is on for 2 minutes per hourly use.

• Approx. 1.5 years; When turned off and the clock is

running.

Memory backup battery

• Approx. 5 years (if operating batteries are replaced

promptly when exhausted)

• Approx. 1 year (if operating batteries are exhausted or

not installed)

Weight: Approx. 120 g (0.27 lb.) (Including batteries)

Dimensions:

Open: 139.0 mm (W) × 174.7 mm (D) × 9.5 mm (H)

5-15/32" (W) × 6-7/8" (D) × 3/8" (H)

Closed: 139.0 mm (W) × 89.5 mm (D) × 13.7 mm (H)

5-15/32" (W) × 3-17/32" (D) × 17/32" (H)

Accessories: 3 lithium batteries (installed), operation manual

In Europe:

This equipment complies with the requirements of Directive 89/336/EEC

as amended by 93/68/EEC.

Dieses Gerät entspricht den Anforderungen der EG-Richtlinie 89/336/

EWG mit Änderung 93/68/EWG.

Ce matériel répond aux exigences contenues dans la directive 89/336/

CEE modifiée par la directive 93/68/CEE.

Dit apparaat voldoet aan de eisen van de richtlijn 89/336/EEG, gewijzigd

door 93/68/EEG.

Dette udstyr overholder kravene i direktiv nr. 89/336/EEC med tillæg nr.

93/68/EEC.

Quest’apparecchio è conforme ai requisiti della direttiva 89/336/EEC

come emendata dalla direttiva 93/68/EEC.

Η εγκατάσταση αυτή ανταποκρίνεται στις απαιτήσεις των οδηγιών

της Ευρωπαïκής Ενωσης 89/336/ΕΟΚ, !πως ο κανονισµ!ς αυτ!ς

συµπληρώθηκε απ! την οδηγία 93/68/ΕΟΚ.

Este equipamento obedece às exigências da directiva 89/336/CEE na sua

versão corrigida pela directiva 93/68/CEE.

Este aparato satisface las exigencias de la Directiva 89/336/CEE

modificada por medio de la 93/68/CEE.

Denna utrustning uppfyller kraven enligt riktlinjen 89/336/EEC så som

kompletteras av 93/68/EEC.

Dette produktet oppfyller betingelsene i direktivet 89/336/EEC i endringen

93/68/EEC.

Tämä laite täyttää direktiivin 89/336/EEC vaatimukset, jota on muutettu

direktiivillä 93/68/EEC.

In Canada:

This Class B digital apparatus complies with Canadian ICES-003.

In U.S.A:

Declaration of Conformity

Electronic Organizer : EL-6850/EL-6890/EL-6890S

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Responsible Party:

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430

TEL: 1-800-BE-SHARP

Tested To Comply With FCC Standards

FOR HOME OR OFFICE USE

WARNING – FCC Regulations state that any unauthorized changes or

modifications to this equipment not expressly approved by the

manufacturer could void the user’s authority to operate this equipment.

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference

to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

–Reorient or relocate the receiving antenna.

–Increase the separation between the equipment and receiver.

–Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

–Consult the dealer or an experienced radio/TV technician for help.

Note: A shielded interface cable is required to ensure compliance with

FCC regulations for Class B certification.

SHARP CORPORATION

PRINTED IN CHINA

01CTO (TINSE0481EHZZ)

Sharp Electronic Organizer El 6890 Users Manual Operation

Sharp-El-6890S-Owners-Manual-645724 sharp-el-6890s-owners-manual-645724

Electronic Organizer El-6850 org_man_el6890s

El-6850 to the manual b3bbc4c8-5af0-4ba6-b1bf-bc3dd795e567

Navigation menu

Versions of this User Manual:

Views

Navigation
