Introduction Quick Start Setup Connections Basic

Operation

Useful

Features Appendix

OPERATION MANUAL

DATA PROJECTOR

MODEL

PG-D4010X

ii

IMPORTANT

• For your assistance in reporting the loss

or theft of your Projector, please record

the Model and Serial Number located on

the bottom of the projector and retain this

information.

• Before recycling the packag ing, please

ensure that you have checked the con-

tents of the carton thoroughly against the

list of “Supplied accessories” on page 11.

Model No.:

Serial No.:

iii

SPECIAL NOTE FOR USERS IN THE U.K.

The mains lead of this product is fi tted with a non-rewireable (moulded) plug incorporating

a 10A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse

marked or and of the same rating as above, which is also indicated on the pin face

of the plug, must be used.

Always refi t the fuse cover after replacing the fuse. Never use the plug without the fuse

cover fi tted.

In the unlikely event of the socket outlet in your home not being compatible with the plug

supplied, cut off the mains plug and fi t an appropriate type.

DANGER:

The fuse from the cut-off plug should be removed and the cut-off plug destroyed immedi-

ately and disposed of in a safe manner.

Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket

outlet, as a serious electric shock may occur.

To fi t an appropriate plug to the mains lead, follow the instructions below:

WARNING:

THIS APPARATUS MUST BE EARTHED.

IMPORTANT:

The wires in this mains lead are coloured in accordance with the following code:

Green-and-yellow : Earth

Blue : Neutral

Brown : Live

As the colours of the wires in the mains lead of this apparatus may not correspond with

the coloured markings identifying the terminals in your plug proceed as follows:

x The wire which is coloured green-and-yellow must be connected to the terminal in the

plug which is marked by the letter E or by the safety earth symbol or coloured green

or green-and-yellow.

x The wire which is coloured blue must be connected to the terminal which is marked

with the letter N or coloured black.

x The wire which is coloured brown must be connected to the terminal which is marked

with the letter L or coloured red.

IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.

iv

The supplied CD-ROM contains operation instructions in English, German, French,

Spanish, Italian, Dutch, Swedish, Portuguese, Chinese and Korean. Carefully read through

the operation instructions before operating the projector.

Die mitgelieferte CD-ROM enthält Bedienungsanleitungen in Englisch, Deutsch, Französisch,

Spanisch, Italienisch, Niederländisch, Schwedisch, Portugiesisch, Chinesisch und Koreanisch.

Bitte lesen Sie die Bedienungsanleitung vor der Verwendung des Projektors sorgfältig durch.

Le CD-ROM fourni contient les instructions de fonctionnement en anglais, allemand,

français, espagnol, italien, néerlandais, suédois, portugais, chinois et coréen. Veuillez lire

attentivement ces instructions avant de faire fonctionner le projecteur.

El CD-ROM suministrado contiene instrucciones de operación en inglés, alemán, francés,

español, italiano, holandés, sueco, portugués, chino y coreano. Lea cuidadosamente las

instrucciones de operación antes de utilizar el proyector.

Il CD-ROM in dotazione contiene istruzioni per l'uso in inglese, tedesco, francese, spagnolo,

italiano, olandese, svedese, portoghese, cinese e coreano. Leggere attentamente le istruzioni

per l'uso prima di usare il proiettore.

De meegeleverde CD-ROM bevat handleidingen in het Engels, Duits, Frans, Spaans,

Italiaans, Nederlands, Zweeds, Portugees, Chinees en Koreaans. Lees de handleiding

zorgvuldig door voor u de projector in gebruik neemt.

Den medföljande CD-ROM-skivan innehåller bruksanvisningar på engelska, tyska, franska,

spanska, italienska, holländska, svenska, portugisiska, kinesiska och koreanska. Läs noga

igenom bruksanvisningen innan projektorn tas i bruk.

O CD-ROM fornecido contém instruções de operação em Inglês, Alemão, Francês,

Espanhol, Italiano, Holandês, Sueco, Português, Chinês e Coreano. Leia cuidadosamente

todas as instruções de operação antes de operar o projetor.

1

Introduction

Before using the projector, please read this operation manual carefully.

Introduction ENGLISH

There are two important reasons for prompt warranty registration of your new

SHARP Projec tor, using the REGISTRATION CARD packed with the projector.

1. WARRANTY

This is to assure that you immediately receive the full benefi t of the parts,

service and labor warranty applicable to your purchase.

2. CONSUMER PRODUCT SAFETY ACT

To ensure that you will promptly receive any safety notifi cation of inspection,

modifi cation, or recall that SHARP may be required to give under the 1972

Consumer Product Safety Act, PLEASE READ CAREFULLY THE IMPORTANT

“LIMITED WARRANTY” CLAUSE. U.S.A. ONLY

WARNING: High brightness light source. Do not stare into the beam of light, or view

directly. Be especially careful that children do not stare directly into the

beam of light.

WARNING: To reduce the risk of fi re or electric shock, do not

expose this product to rain or mois ture.

The lightning fl ash with arrowhead sym-

bol, within an equilateral triangle, is in-

tended to alert the user to the presence

of uninsulated “dangerous voltage”

within the product's enclosure that may

be of suffi cient magnitude to constitute

a risk or electric shock to persons.

The exclamation point within a triangle

is intended to alert the user to the pres-

ence of important operating and main-

tenance (servicing) instructions in the

literature accompanying the product.

See bottom of projector.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER.

NO USER-SERVICEABLE PARTS EXCEPT LAMP UNIT.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT REMOVE SCREWS

EXCEPT SPECIFIED USER

SERVICE SCREW.

WARNING: FCC Regulations state that any unauthorized changes or modifi cations

to this equipment not expressly approved by the manufacturer could

void the user's authority to operate this equip ment. U.S.A. ONLY

2

INFORMATION

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the operation manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to correct the interference at

his own expense. U.S.A. ONLY

The enclosed computer cable must be used with the device. The cable is

provided to ensure that the device complies with FCC Class A verifi cation.

U.S.A. ONLY

WARNING:

This is a Class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate

measures.

PRODUCT DISPOSAL

This product utilizes tin-lead solder, and lamp containing a small

amount of mercury. Disposal of these materials may be regulated due

to environmental considerations. For disposal or recycling information,

please contact your local authorities, the Electronics Industries Alliance:

www.eiae.org, the lamp recycling organization www.lamprecycle.org, or

Sharp at 1-800-BE-SHARP. U.S.A. ONLY

Caution Concerning Lamp Replacement

See “Replacing the Lamp” on page 55.

This SHARP projector uses a DLP® chip. This very sophisticated panel contains 786,432

pixels (micromirrors). As with any high technology electronic equipment such as large screen

TVs, video systems and video cameras, there are certain acceptable tolerances that the

equipment must conform to.

This unit has some inactive pixels within acceptable tolerances which may result in inactive dots

on the picture screen. This will not affect the picture quality or the life expectancy of the unit.

Authorized representative responsible for the European Union Community Market

SHARP ELECTRONICS (Europe) GmbH

Sonninstraße 3, D-20097 Hamburg E.U. ONLY

3

Introduction

How to Read this Operation Manual

The specifi cations are slightly different, depending on the model. However, you can connect

and operate all models in the same manner.

In this operation manual, the illustration and the screen display are simplifi ed for explanation, and

may differ slightly from the actual display.

38

Using the Menu Screen

Adjustment buttons

(P/R/O/Q)

ENTER button

RETURN button

Press RETURN to return

to the previous screen

when the menu is

displayed.

•

MENU/HELP button

Adjustment buttons (P/R/O/Q)

MENU/HELP button

ENTER button

RETURN button

Menu Selections (Adjustments)

Example: Adjusting “Bright”.

This operation can also be performed by using the buttons on the projector.•

1

Press MENU/HELP.

The “Picture” menu screen for the selected

input mode is displayed.

2

Press Q or O and select

“Picture” to adjust.

•

1

2

Example: “Picture” screen menu for

COMPUTER (RGB) input

Menu item

Picture Mode

Contrast 0

0

0

Bright

Standard

SEL./ADJ. ENTER END

0

0

Red

Blue

CLR Temp

BrilliantColor

TM

C.M.S. Setting

C.M.S.

Eco+Quiet

0

1

On

On

DNR Off

Reset

Picture SCR PRJ Net. Help

Buttons used in

this operation

On-screen

display

Button used in

this step

Info

.........Indicates safeguards for using the projector.

Note

....... Indicates additional information for setting up and operating the

projector.

For Future Reference

Maintenance

P. 52

Troubleshooting

PP. 59 and 60

Index

P. 64

■

•

4

Contents

Preparing

Introduction

How to Read this Operation Manual ......3

Contents .................................................4

IMPORTANT SAFEGUARDS ..................6

How to Access the PDF Operation

Manuals..............................................10

Accessories ..........................................11

Part Names and Functions ...................12

Projector................................................. 12

Rear View ............................................... 13

Inserting the Batteries ............................. 15

Usable Range ......................................... 15

Quick Start

Quick Start ...........................................16

Setup and Projection .............................. 16

Setup

Setting up the Projector .......................18

Setting up the Projector .......................... 18

Standard Setup (Front Projection) ........... 18

Ceiling-mount Setup ............................... 18

Projection (PRJ) Mode ............................ 19

Screen Size and Projection Distance ...... 20

Connections

Connecting the Projector to

Other Equipment ................................21

Controlling the Projector by

a Computer ........................................24

Connecting the Power Cord .................25

Useful Features

Operating with the Remote Control......32

Displaying and Setting the

Break Timer ......................................... 32

Displaying the Pointer ............................. 32

Using the Spot Function ......................... 32

Switching the Eco+Quiet Mode .............. 32

Auto Sync (Auto Sync Adjustment) ......... 33

Freezing a Moving Image ........................ 33

Selecting the Picture Mode ..................... 33

Displaying an Enlarged Portion of

an Image ............................................. 33

Using the Remote Control as the

Wireless Computer Mouse ................... 34

Menu Items ...........................................35

Using the Menu Screen ........................38

Menu Selections (Adjustments) ............... 38

Picture Adjustment (“Picture” Menu) ....40

Selecting the Picture Mode ..................... 40

Adjusting the Image ................................ 41

Adjusting the Color Temperature ............. 41

Adjusting the Colors ............................... 41

Progressive............................................. 42

Reducing Image Noise (DNR) ................. 42

Eco+Quiet .............................................. 42

Adjusting the Projected Image

(“SCR - ADJ” Menu) ...........................43

Setting the Resize Mode ......................... 43

Adjusting the Image Position .................. 43

Keystone Correction ............................... 43

Setting the Overscan .............................. 43

Setting the On-screen Display ................ 44

Closed Caption ...................................... 44

Selecting the Background Image ............ 44

Reversing/Inverting Projected Images ..... 44

Selecting the On-screen Display

Language ............................................ 44

Adjusting the Projector Function

(“PRJ - ADJ” Menu) ...........................45

Auto Sync (Auto Sync Adjustment) ......... 45

Auto Power Off Function ........................ 45

Auto Restart Function ............................. 45

STANDBY Mode ..................................... 45

Setting the Confi rmation Sound

(System Sound) ................................... 45

Audio Output Type Setting ...................... 46

Speaker Setting ...................................... 46

Audio Input ............................................. 46

Selecting the Transmission Speed

(RS-232C) ........................................... 46

Fan Mode Setting ................................... 46

System Lock Function ............................ 46

Checking the Lamp Life Status ............... 47

Keylock Function .................................... 48

Using

Basic Operation

Turning the Projector On/Off ................26

Turning the Projector On ......................... 26

Turning the Power Off (Putting the

Projector into Standby Mode) .............. 26

Image Projection ..................................27

Adjusting the Projected Image ................ 27

Correcting Trapezoidal Distortion ............ 28

Switching the Input Mode ....................... 29

Adjusting the Volume .............................. 29

Displaying the Black Screen and

Turning Off the Sound Temporarily ....... 29

Resize Mode .......................................... 30

5

Introduction

Setting up the Projector Network

Environment (“Network” Menu)..........49

Setting a Password ................................ 49

DHCP Client Setting ............................... 50

TCP/IP Setting ........................................ 50

Confi rming the Projector Information ....... 50

Troubleshooting with the

“Help” Menu .......................................51

Utilizing the “Help” Menu Functions ........ 51

Appendix

Maintenance .........................................52

Maintenance Indicators ........................53

Regarding the Lamp .............................55

Lamp...................................................... 55

Caution Concerning the Lamp ................ 55

Replacing the Lamp ............................... 55

Removing and Installing the

Lamp Unit ............................................ 56

Resetting the Lamp Timer ...................... 57

Computer Compatibility Chart .............58

Troubleshooting ....................................59

For SHARP Assistance .........................61

Specifi cations .......................................62

Dimensions ...........................................63

Index .....................................................64

Reference

6

IMPORTANT SAFEGUARDS

CAUTION: Please read all of these instructions before you operate this

product and save these instructions for later use.

Electrical energy can perform many useful functions. This product has been engineered

and manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN

POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the

safeguards incorporated in this product, observe the following basic rules for its

installation, use and servicing.

1. Read Instructions

All the safety and operating instructions

should be read before the product is

operated.

2. Retain Instructions

The safety and operating instructions

should be retained for future reference.

3. Heed Warnings

All warnings on the product and in the

operating instructions should be adhered to.

4. Follow Instructions

All operating and use instructions should

be followed.

5. Cleaning

Unplug this product from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol

cleaners. Use a damp cloth for cleaning.

6. Attachments

Do not use attachments not recommended by the

product manufacturer as they may cause hazards.

7. Water and Moisture

Do not use this product near water–for

example, near a bath tub, wash bowl, kitchen

sink, or laundry tub; in a wet basement; or

near a swimming pool; and the like.

8. Accessories

Do not place this product on an unstable

cart, stand, tripod, bracket, or table. The

product may fall, causing serious injury to a

child or adult, and serious damage to the

product. Use only with a cart, stand, tripod,

bracket, or table recommended by the

manufacturer, or sold with the product. Any

mounting of the product should follow the

manufacturer's instructions, and should use a

mounting accessory recom mended by the

manufacturer.

9. Transportation

A product and cart

combination should be

moved with care. Quick

stops, excessive force, and

uneven surfaces may

cause the product and cart

combination to overturn.

10. Ventilation

Slots and openings in the cabinet are provided

for ventilation to ensure reliable operation of

the product and to protect it from overheating,

and these openings must not be blocked or

covered. The open ings should never be

blocked by placing the product on a bed, sofa,

rug, or other similar surface. This prod uct

should not be placed in a built-in installation

such as a book case or rack unless proper

ventilation is provided or the manufacturer's

instruc tions have been adhered to.

11. Power Sources

This product should be operated only from

the type of power source indicated on the

marking label. If you are not sure of the

type of power supply to your home, consult

your product dealer or local power

company. For products intended to operate

from battery power, or other sources, refer

to the operating instructions.

12. Grounding or Polarization

This product is provided with one of the

following types of plugs. If the plug should

fail to fi t into the power outlet, please contact

your electrician.

Do not defeat the safety purpose of the plug.

a. Two-wire type (mains) plug.

b. Three-wire grounding type (mains) plug

with a grounding terminal.

This plug will only fi t into a grounding

type power outlet.

13. Power-Cord Protection

Power-supply cords should be routed so

that they are not likely to be walked on or

pinched by items placed upon or against

them, paying particular attention to cords

at plugs, convenience receptacles, and the

point where they exit from the product.

14. Lightning

For added protection for this product during

a lightning storm, or when it is left

unattended and unused for long periods of

time, unplug it from the wall outlet and

disconnect the cable system. This will

pre vent damage to the product due to

lightning and power-line surges.

7

Introduction

15. Overloading

Do not overload wall outlets, extension cords,

or integral convenience receptacles as this

can result in a risk of fi re or electric shock.

16. Object and Liquid Entry

Never push objects of any kind into this

product through openings as they may touch

dangerous voltage points or short-out parts

that could result in a fi re or electric shock.

Never spill liquid of any kind on the product.

17. Servicing

Do not attempt to service this product

yourself as opening or removing covers

may expose you to dan ger ous voltage or

other hazards. Refer all servicing to

qualifi ed service personnel.

18. Damage Requiring Service

Unplug this product from the wall outlet

and refer servicing to qualifi ed service

personnel under the following conditions:

a. When the power-supply cord or plug is

damaged.

b. If liquid has been spilled, or objects

have fallen into the product.

c. If the product has been exposed to rain

or water.

d. If the product does not operate normally

by following the operating instructions.

Adjust only those con trols that are

covered by the operating instructions,

as an improper adjustment of other

controls may result in damage and will

often require extensive work by a

qualifi ed technician to restore the

product to normal operation.

e. If the product has been dropped or

damaged in any way.

f. When the product exhibits a distinct

change in performance, this indicates a

need for service.

19. Replacement Parts

When replacement parts are required, be

sure the service technician has used

replace ment parts specifi ed by the

manufacturer or have the same

characteristics as the original part.

Unauthorized substitutions may result in

fi re, electric shock, or other hazards.

20. Safety Check

Upon completion of any service or repairs

to this product, ask the service technician

to per form safety checks to determine that

the product is in proper operating

condition.

21. Wall or Ceiling Mounting

This product should be mounted to a wall

or ceiling only as recommended by the

manufacturer.

22. Heat

This product should be situated away from

heat sources such as radiators, heat

registers, stoves, or other products

(including amplifi ers) that produce heat.

DLP® and the DLP logo are registered trademarks of Texas Instruments and

BrilliantColorTM is a trademark of Texas Instruments.

Microsoft® and Windows® are registered trademarks of Microsoft Corporation in the

United States and/or other countries.

PC/AT is a registered trademark of International Business Machines Corporation in the

United States.

Adobe® Reader® is a trademark of Adobe Systems Incorporated.

Macintosh® is a registered trademark of Apple Computer, Inc. in the United States and/or

other countries.

PJLink is a registered trademark or an application trademark in Japan, the United States

and/or other countries/regions.

All other company or product names are trademarks or registered trademarks of their

respective companies.

Some IC chips in this product include confi dential and/or trade secret property belonging

to Texas Instruments. Therefore you may not copy, modify, adapt, translate, distribute,

reverse engineer, reverse assemble or discompile the contents thereof.

•

•

•

•

•

•

•

•

8

Observe the following safeguards when setting up your

projector.

Caution concerning the lamp unit

Potential hazard of glass

particles if lamp ruptures.

In case of lamp rupture,

contact your nearest Sharp

Authorized Projector

Dealer or Service Center

for replacement.

See “Regarding the Lamp”

on page 55.

Caution concerning the setup of the

projector

For minimal servicing and to maintain high

image quality, SHARP recommends that

this projector be installed in an area free

from humidity, dust and cigarette smoke.

When the projector is subjected to these

environments, the vents and lens must be

cleaned more often. As long as the

projector is regularly cleaned, use in these

environments will not reduce the overall

operation life of the unit. Internal cleaning

should only be performed by a Sharp

Authorized Projector Dealer or Service

Center.

Do not set up the projector in places

exposed to direct sunlight or bright light.

Position the screen so that it is not in direct

sunlight or room light. Light falling directly

on the screen washes out the colors,

making viewing diffi cult. Close the curtains

and dim the lights when setting up the

screen in a sunny or bright room.

Caution regarding placing of the projector

Place the projector on a level site within the

adjustment range (9 degrees) of the

adjustment foot.

After the projector is purchased, a faint

smell from the vent may appear when the

power is fi rst turned on. This is normal and

is not a malfunction. It will disappear after

the projector is used for a while.

■

■

■

■

■

When using the projector in high-

altitude areas such as mountains (at

altitudes of approximately 1,500

meters (4,900 feet) or more)

When you use the projector in high-altitude

areas with thin air, set “Fan Mode” to

“High”. Neglecting this can affect the

longevity of the optical system.

Warning about placing the projector in

a high position

When placing the projector in a high

position, make certain it is carefully secure

to avoid personal injury caused by the

projector falling down.

Do not subject the projector to hard

impact and/or vibration.

Protect the lens so as not to hit or damage

the surface of the lens.

Rest your eyes occasionally.

Continuously watching the screen for long

hours will cause eye strain. Take regular

breaks to rest your eyes.

Avoid locations with extremes of

temperature.

The operating temperature of the projector

is from 41°F to 95°F (+5°C to +35°C).

The storage temperature of the projector is

from –4°F to 140°F (–20°C to +60°C).

Do not block the exhaust and intake

vents.

Allow at least 11 13/16 inches (30 cm) of

space between the exhaust vent and the

nearest wall or obstruction.

Ensure that the intake vent and the exhaust

vent are not obstructed.

If the cooling fan becomes obstructed, a

protection circuit will automatically put the

projector into standby mode to prevent

overheat damage. This does not indicate a

malfunction. (See pages 53 and 54.)

Remove the projector power cord from the

wall outlet and wait at least 10 minutes.

Place the projector where the intake and

exhaust vents are not blocked, plug the

power cord back in and turn on the

projector. This will return the projector to

the normal operating condition.

■

■

■

■

■

■

■

■

■

9

Introduction

Caution regarding usage of the projector

If you are not to use the projector for a long

time or before moving the projector, make

certain you unplug the power cord from the

wall outlet, and disconnect any other

cables connected to it.

Do not carry the projector by holding the

lens.

When storing the projector, ensure that you

close the lens shutter.

Do not expose the projector to direct

sunlight or place next to heat sources.

Doing so may affect the cabinet color or

cause deformation of the plastic cover.

Other connected equipment

When connecting a computer or other

audio-visual equipment to the projector,

make the connections AFTER unplugging

the power cord of the projector from the

AC outlet and turning off the equipment to

be connected.

Please read the operation manuals of the

projector and the equipment to be

connected for instructions on how to make

the connections.

■

■

■

■

■

■

Using the projector in other countries

The power supply voltage and the shape of

the plug may vary depending on the region

or country you are using the projector in.

When using the projector overseas, make

sure you use an appropriate power cord for

the country you are in.

Temperature monitor function

If the temperature inside the projector

increases, due to blockage of the air vents,

or the setting location, the temperature

warning indicator will blink. And if the

temperature keeps on rising, “ ” will

illuminate in the lower left corner of the

picture with the temperature warning

indicator blinking. If this state continues,

the lamp will turn off, the cooling fan will

run and then the projector will enter

standby mode. Refer to “Maintenance

Indicators” on pages 53 and 54 for details.

Info

The cooling fan regulates the internal

temperature, and its performance is automatically

controlled. The sound of the fan may change

during projector operation due to changes in the

fan speed. This does not indicate malfunction.

■

■

•

Closed Caption uses Bitstream Vera fonts

Copyright (c) 2003 by Bitstream, Inc. All Rights Reserved. Bitstream Vera is a trademark of Bitstream, Inc.

Permission is hereby granted, free of charge, to any person obtaining a copy of the fonts accompanying this

license (“Fonts”) and associated documentation fi les (the “Font Software”), to reproduce and distribute the

Font Software, including without limitation the rights to use, copy, merge, publish, distribute, and/or sell

copies of the Font Software, and to permit persons to whom the Font Software is furnished to do so, subject

to the following conditions:

The above copyright and trademark notices and this permission notice shall be included in all copies of one

or more of the Font Software typefaces.

The Font Software may be modifi ed, altered, or added to, and in particular the designs of glyphs or

characters in the Fonts may be modifi ed and additional glyphs or characters may be added to the Fonts,

only if the fonts are renamed to names not containing either the words “Bitstream” or the word “Vera”.

This License becomes null and void to the extent applicable to Fonts or Font Software that has been

modifi ed and is distributed under the “Bitstream Vera” names.

The Font Software may be sold as part of a larger software package but no copy of one or more of the Font

Software typefaces may be sold by itself.

THE FONT SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR

IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A

PARTICULAR PURPOSE AND NONINFRINGEMENT OF COPYRIGHT, PATENT, TRADEMARK, OR OTHER

RIGHT. IN NO EVENT SHALL BITSTREAM OR THE GNOME FOUNDATION BE LIABLE FOR ANY CLAIM,

DAMAGES OR OTHER LIABILITY, INCLUDING ANY GENERAL, SPECIAL, INDIRECT, INCIDENTAL, OR

CONSEQUENTIAL DAMAGES, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING

FROM, OUT OF THE USE OR INABILITY TO USE THE FONT SOFTWARE OR FROM OTHER DEALINGS IN

THE FONT SOFTWARE.

Except as contained in this notice, the names of Gnome, the Gnome Foundation, and Bitstream Inc., shall

not be used in advertising or otherwise to promote the sale, use or other dealings in this Font Software

without prior written authorization from the Gnome Foundation or Bitstream Inc., respectively. For further

information, contact: fonts at gnome dot org.

10

How to Access the PDF Operation Manuals

PDF operation manuals in several languages are included in the CD-ROM. To

utilize these manuals, you need to install Adobe® Reader® on your computer

(Windows® or Macintosh®).

Please download Adobe® Reader® from the Internet (http://www.adobe.com).

Accessing the PDF Manuals

For Windows®:

 Insert the CD-ROM in the CD-ROM drive.

 Double click the “My Computer” icon.

 Double click the “CD-ROM” drive.

When you want to view the operation

manual

1) Double click the “MANUALS” folder.

2) Double click the language (name of the

folder) that you want to view.

3) Double click the pdf fi le to access the

projector manuals.

When you want to view the SETUP

MANUAL

1) Double click the “SETUP” folder.

2) Double click the language (name of the

folder) that you want to view.

3) Double click the pdf fi le to access the

SETUP MANUAL.

For Macintosh®:

 Insert the CD-ROM in the CD-ROM drive.

 Double click the “CD-ROM” icon.

When you want to view the operation

manual

1) Double click the “MANUALS” folder.

2) Double click the language (name of the

folder) that you want to view.

3) Double click the pdf fi le to access the

projector manuals.

When you want to view the SETUP

MANUAL

1) Double click the “SETUP” folder.

2) Double click the language (name of the

folder) that you want to view.

3) Double click the pdf fi le to access the

SETUP MANUAL.

If the desired pdf fi le cannot be opened by double clicking the mouse, start Adobe® Reader® fi r s t ,

then specify the desired fi le using the “File”, “Open” menu.

•

Note

SETUP MANUAL

Refer to the “SETUP MANUAL” contained on the supplied CD-ROM for details.

Connecting Pin Assignments ······················································· 2

RS-232C Specifi cations and Commands ·····································4

Setting up the Projector Network Environment ···························· 9

Controlling the Projector via LAN ··············································· 15

Setting up the Projector Using RS-232C or Telnet ·····················20

Resetting the Lamp Timer of the Projector via LAN···················· 30

Troubleshooting ·········································································· 32

11

Introduction

Accessories

Supplied accessories

Remote control

<RRMCGA662WJSA>

Two R-6 batteries

(“AA” size, UM/SUM-3,

HP-7 or similar)

Power cord*

RGB cable

(10' (3.0 m))

<QCNWGA086WJPZ>

For U.S. and

Canada, etc.

(6' (1.8 m))

<QACCDA007WJPZ>

For Europe,

except U.K.

(6' (1.8 m))

<QACCVA011WJPZ>

For U.K. and

Singapore

(6' (1.8 m))

<QACCBA036WJPZ>

For Australia, New

Zealand and Oceania

(6' (1.8 m))

<QACCLA018WJPZ>

(1) (2) (3) (4)

* Use the power cord that corresponds to the wall outlet in your country.

Operation manual (this manual <TINS-D946WJZZ> and CD-ROM <UDSKAA112WJZZ>)

•

Codes in “< >” are Replacement parts codes.•

Note

Optional accessories

■ Lamp unit

■ Ceiling-mount adaptor

■ Ceiling-mount unit

■ Remote receiver

■ 3 RCA to mini D-sub 15 pin cable (10 n (3.0 m))

AN-D400LP

AN-60KT

AN-XRCM30 (for U.S.A. only)

AN-TK201 <for AN-60KT>

AN-TK202 <for AN-60KT>

AN-EP101B <for AN-XRCM30>

(for U.S.A. only)

AN-MR2

AN-C3CP2

Some of the optional accessories may not be available depending on the region. Please check with

your nearest Sharp Authorized Projector Dealer or Service Center.

•

Note

12

Part Names and Functions

Numbers in Z refer to the main pages in this operation manual where the

topic is explained.

Projector

33

38, 51

26, 53

26, 53

38

26 29

38

29

53

38

32

28

Top View

STANDBY/ON

button

For turning the

power on and

putting the

projector into

standby mode.

Lamp

indicator

Temperature

warning

indicator

Adjustment buttons

(P/R/O/Q)

For selecting menu items.

VOL (Volume)

buttons (–O/Q+)

For adjusting the

speaker sound

level.

ENTER button

For setting items selected

or adjusted on the menu.

MENU/HELP button

For displaying

adjustment and

setting screens, and

help screen.

INPUT buttons (P/R)

For switching input mode.

KEYSTONE button

For entering the Keystone

Correction mode.

ECO+QUIET

button

For lowering the

noise of the cooling

fan and extending

the lamp life.

Power

indicator

RETURN button

For returning to the

previous menu screen

during menu operations.

AUTO SYNC

button

For automatically

adjusting images

when connected

to a computer.

Focus ring

For adjusting

the focus.

Remote control

sensor

HEIGHT

ADJUST lever

Intake vent

Zoom ring

For enlarging/

reducing the picture.

Front View

Adjustment foot

Lens shutter Adjustment foot

27

52

27

27

29

15

52

27

27

Exhaust vent

13

Introduction

Numbers in Z refer to the main pages in this operation manual where the

topic is explained.

Rear View

Using the Kensington Lock

This projector has a Kensington Security Standard connector for use with a Kensington

MicroSaver Security System. Refer to the information that came with the system for

instructions on how to use it to secure the projector.

•

Carrying handle

Remote control

sensor

46

34

22

22

21

22

23

23

23

23

23

25

46

21

22

15

25

Terminals

AUDIO 2 input terminal

S-VIDEO input terminal

Terminal for connecting video

equipment with an

S-video terminal.

VIDEO input terminal

Terminal for connecting

video equipment.

Kensington Security

Standard connector

AC socket

Connect the

supplied power cord.

AUDIO OUT

terminal

Audio output terminal of equipment

connected to the audio input terminal.

AUDIO 1 input

terminal

DVI-I input

terminal

Terminal for DVI

digital, computer

RGB and

component signals.

LAN terminal

Terminal for controlling the

projector using a computer

via network.

RS-232C terminal

Terminal for controlling the

projector using a computer.

COMPUTER/COMPONENT input

terminal

Terminal for computer RGB and

component signals.

USB terminal

Terminal

connecting with

the USB terminal

on the computer

for using the

supplied remote

control as the

computer mouse.

MONITOR OUT terminal

(Output terminal for computer

RGB, component and DVI analog

signals. Shared for COMPUTER/

COMPONENT and DVI-I)

Terminal for connecting a monitor.

Speaker

Speaker

Security bar

Using the Carrying Handle

When transporting the projector, carry it by the carrying handle on the

side.

Always close the lens shutter to prevent damage to the lens when

transporting the projector.

Do not lift or carry the projector by the lens as this may damage the

lens.

•

•

14

Part Names and Functions (Continued)

29

32

33

34

38

32

32

26

34

28

33

32

26

33

29

32

34

38

38

51

30

38

29

33

34

STANDBY button

For putting the projector into

the standby mode.

BREAK TIMER button

For displaying the

break time.

COMPUTER, DVI,

S-VIDEO, VIDEO buttons

For switching to the

respective input modes.

PAGE UP/PAGE

DOWN buttons

Same as the [Page Down] and

[Page Up] keys on a computer

keyboard, when with the USB

connection (using a USB cable

or the optional remote receiver).

POINTER button

For displaying the

pointer.

MOUSE/Adjustment

buttons (P/R/O/Q)

For moving the

computer cursor when with the USB

connection (using a USB cable or the

optional remote receiver).

For selecting and adjusting menu

items.

•

•

L-CLICK/EFFECT

button

For the Left click

when with the USB connection

(using a USB cable or the optional

remote receiver).

For changing the pointer or spot

area.

•

•

KEYSTONE button

For entering the

Keystone Correction mode.

AUTO SYNC button

For automatically

adjusting images when

connected to a computer.

ECO+QUIET button

For lowering the noise

of the cooling fan and

extending the lamp life.

AV MUTE button

For temporarily

displaying a black

screen and turning off

the sound.

FREEZE button

For freezing images.

VOL +/– (Volume)

buttons

For adjusting the

speaker sound level.

ON button

For turning the power

on.

SPOT button

For displaying the

spotlight.

R-CLICK/RETURN

button

For the Right click when

with the USB connection

(using a USB cable or

the optional remote

receiver).

For returning to the

previous menu screen

during menu

operations.

•

•

ENTER button

For setting items

selected or adjusted

on the menu.

MENU/HELP button

For displaying

adjustment and setting

screens, and help

screen.

PICTURE MODE

button

For selecting the

appropriate picture.

RESIZE button

For switching the

picture size (NORMAL,

STRETCH, etc.).

MAGNIFY buttons

For enlarging/reducing

part of the image.

15

Introduction

Inserting the Batteries

1 Pull down the tab on the cover and remove the

cover towards the direction of the arrow.

2 Insert the batteries.

Insert the batteries making sure the polarities correctly match

the m and n marks inside the battery compartment.

3 Insert the lower tab of the cover into the opening,

and lower the cover until it clicks in place.

Incorrect use of the batteries may cause them to leak or explode.

Please follow the precautions below

Caution

Danger of explosion if battery is incorrectly replaced.

Replace only with alkaline or manganese batteries.

Insert the batteries making sure the polarities correctly match the m and n marks inside the battery

compartment.

Batteries of different types have different properties, therefore do not mix batteries of different types.

Do not mix new and old batteries.

This may shorten the life of new batteries or may cause old batteries to leak.

Remove the batteries from the remote control once they have run out, as leaving them in can cause them to leak.

Battery fl uid from leaked batteries is harmful to skin, therefore ensure you wipe them fi rst and then

remove them using a cloth.

The batteries included with this projector may run down in a short period, depending on how they are kept.

Be sure to replace them as soon as possible with new batteries.

Remove the batteries from the remote control if you will not be using the remote control for a long time.

Comply with the rules (ordinance) of each local government when disposing of worn-out batteries.

•

•

•

•

•

•

•

•

•

1

2

3

Usable Range

The remote control can be used to control the

projector within the ranges shown in the

illustration.

Another remote control sensor is located

on the rear of the projector.

The signal from the remote control can be

refl ected off a screen for easy operation.

However, the effective distance of the signal

may differ depending on the screen material.

•

•

Note

When using the remote control

Ensure that you do not drop it or expose it to

moisture or high temperature.

The remote control may malfunction under a

fl uorescent lamp. In this case, move the

projector away from the fl uorescent lamp.

•

•

Remote control sensor

Remote control signal

transmitters

Remote control

23n (7 m)

30°

30°

Remote control sensor

Remote control signal

transmitters

Remote control

23n (7 m)

30°

30°

16

Quick Start

This section shows the basic operation (projector connecting with the computer). For details,

see the page described below for each step.

Setup and Projection

In this section, connection of the projector and the computer is explained using one example.

INPUT buttons

6

STANDBY button

8

KEYSTONE button

5

STANDBY/ON

button

3

8

5KEYSTONE button

Focus ring

4

HEIGHT

ADJUST lever

4

3ON button

6COMPUTER button

5Adjustment buttons

(P/R/O/Q)

5Adjustment buttons

(P/R/O/Q)

Zoom ring

4

1. Place the projector facing a wall or a screen _P. 18

When connecting equipment other than a computer, see pages

22 and 23.

2. Connect the projector to the computer and plug the power

cord into the AC socket of the projector

_PP. 21, 24, 25

On the projector On the remote control

3. Open the lens shutter fully and then turn the projector on

_P. 2 6

17

Quick Start

1 Adjusting the focus.

2

Adjusting the height.

3 Adjusting the picture size.

4. Adjust the projected image

BP. 2 7

Correcting trapezoidal distortion using Keystone Correction.

On the projector

On the remote control

Shrinks

upper side. Shrinks

lower side.

5. Correct trapezoidal distortion

BP. 2 8

Select the “COMPUTER” using INPUT on the projector or COMPUTER on the remote

control.

On the

projector

On the remote

control INPUT list

INPUT

COMPUTER

DVI-D Computer

D

DVI-D Video

D

On-screen display (RGB)

RGB

1024 × 768

COMPUTER

When you press INPUT on the projector, the INPUT list appears.

Press / to switch the INPUT mode.

•

6. Select the INPUT mode

BP. 2 9

7. Turn the computer on

Press STANDBY/ON on the projector or STANDBY on the remote control, and then press

the button again while the confi rmation message is displayed to put the projector into

standby mode.

On-screen display

On the

projector

On the remote

control

8. Turn the power off

BP. 2 6

18

Setting up the Projector

Setting up the Projector

For optimal image quality, position the projector perpendicular to the screen with the projector's

feet fl at and level. Doing so will eliminate the need for Keystone correction and provide the best

image quality. (See page 28.)

Standard Setup (Front Projection)

Place the projector at the required distance from the screen

according to the desired picture size. (See page 20.)

Example of standard setup

Side View

Screen

Lens center

H

L

Refer to page 20 for additional information concerning “Screen Size and Projection Distance”.•

Note

■

Ceiling-mount Setup

It is recommended that you use the

optional Sharp ceiling-mount adaptor and

unit for this installation. Before mounting

the projector, contact your nearest Sharp

Authorized Projector Dealer or Service

Center to obtain the recommended ceiling-

mount adaptor and unit (sold separately).

■

19

Setup

Projection (PRJ) Mode

The projector can use any of the 4 projection modes shown in the diagram below. Select the

mode most appropriate for the projection setting in use. (You can set the PRJ mode in “SCR-

ADJ” menu. See page 44.)

Table mounted, front projection

[Menu item ➞ “Front”]

Table mounted, rear projection

(with a translucent screen)

[Menu item ➞ “Rear”]

■

■

Ceiling mounted, front projection

[Menu item ➞“Ceiling + Front”]

Ceiling mounted, rear projection

(with a translucent screen)

[Menu item ➞“Ceiling + Rear”]

■

■

Indication of the Projection Image Size and Projection Distance

Example: 4:3 Signal Input (Normal Mode)

500"

200"

100"

80"

40"

49'0

"

(14.9 m)

19'7

"–

22'7

"

(6.0 m – 6.9 m)

9'10

"–

11'4

"

(3.0 m – 3.4 m)

7'10

"–

9'1

"

(2.4 m – 2.8 m)

3'11

"–

4'6

"

(1.2 m – 1.4 m)

400"×300"

160"

×

120"

80"

×

60"

64"

×

48"

32"

×

24"

Picture Size

Projection

Distance

20

Setting up the Projector (Continued)

Screen Size and Projection Distance

4:3 Signal Input (Normal Mode)

Picture (Screen) size Projection distance [L]

Distance from the lens center

to the bottom of the image [H]

Diag. [Ȥ] Width Height

Minimum [L1]

Maximum [L2]

500" (1270 cm) 1016 cm (400")762 cm (300")

14.9 m (49' 0")

— 11 cm (4 15/32

"

)

400" (1016 cm) 813 cm (320") 610 cm (240")

12.0 m (39' 3") 13.8 m (45' 3")

9 cm (3 37/64

"

)

300" (762 cm) 610 cm (240") 457 cm (180")

9.0 m (29' 5")

10.3 m (33' 11")

7 cm (2 11/16

"

)

250" (635 cm) 508 cm (200") 381 cm (150")

7.5 m (24' 6") 8.6 m (28' 3")

6 cm (2 15/64

"

)

200" (508 cm) 406 cm (160") 305 cm (120")

6.0 m (19' 7") 6.9 m (22' 7")

5 cm (1 51/64

"

)

150" (381 cm) 305 cm (120") 229 cm (90")

4.5 m (14' 9") 5.2 m (17' 0")

3 cm (1 11/32

"

)

120" (305 cm) 244 cm (96") 183 cm (72")

3.6 m (11' 9")

4.1 m (13' 7")

3 cm (1 5/64

"

)

100" (254 cm) 203 cm (80") 152 cm (60")

3.0 m (9' 10") 3.4 m (11' 4")

2 cm (57/64

"

)

80" (203 cm) 163 cm (64") 122 cm (48")

2.4 m (7' 10") 2.8 m (9' 1")

2 cm (23/32

"

)

70" (178 cm) 142 cm (56") 107 cm (42")

2.1 m (6' 10") 2.4 m (7' 11")

2 cm (5/8

"

)

60" (152 cm) 122 cm (48") 91 cm (36")

1.8 m (5' 11") 2.1 m (6' 9")

1 cm (17/32

"

)

40" (102 cm) 81 cm (32") 61 cm (24")

1.2 m (3' 11") 1.4 m (4' 6")

1 cm (23/64

"

)

F: Picture size (diag.) (in/cm)

L: Projection distance (m/ft)

L1: Minimum projection distance (m/ft)

L2: Maximum projection distance (m/ft)

H: Distance from the lens center to the bottom of the image (cm/in)

The formula for picture size and projection distance

[m/cm]

L1 (m) = 0.02989F

L2 (m) = 0.03446F

H (cm) = 0.02273F

[Feet/inches]

L1 (ft) = 0.02989F / 0.3048

L2 (ft) = 0.03446F / 0.3048

H (in) = 0.02273F / 2.54

16:9 Signal Input (Stretch Mode)

Picture (Screen) size Projection distance [L]

Distance from the lens center

to the bottom of the image [H]

Adjustable range of

image position [S]

Diag. [Ȥ] Width Height

Minimum [L1]

Maximum [L2]

400" (1016 cm) 886 cm (349")498 cm (196")

13.0 m (42' 9")

15.0 m (49' 3")

93 cm (36 37/64")

±83 cm (±32 11/16")

300" (762 cm) 664 cm (261") 374 cm (147")

9.8 m (32' 1")

11.3 m (36' 11")

70 cm (27 7/16")

±62 cm (±24 33/64")

250" (635 cm) 553 cm (218") 311 cm (123")

8.1 m (26' 8")

9.4 m (30' 9")

58 cm (22 55/64")

±52 cm (±20 27/64")

200" (508 cm) 443 cm (174") 249 cm (98")

6.5 m (21' 4") 7.5 m (24' 8")

46 cm (18 19/64")

±42 cm (±16 11/32")

15 0 " (381 cm) 332 cm (131") 187 cm (74")

4.9 m (16' 0") 5.6 m (18' 6")

35 cm (13 23/32")

±31 cm (±12 1/4")

12 0" (305 cm) 266 cm (105") 149 cm (59")

3.9 m (12' 10") 4.5 m (14' 9")

28 cm (10 31/32")

±25 cm (±9 13/16")

100 " (254 cm) 221 cm (87") 125 cm (49")

3.3 m (10' 8") 3.8 m (12' 4")

23 cm (9 9/64")

±21 cm (±8 11/64")

80" (203 cm) 177 cm (70") 100 cm (39")

2.6 m (8' 7") 3.0 m (9' 10")

19 cm (7 5/16")

±17 cm (±6 17/32")

60" (152 cm) 133 cm (52") 75 cm (29")

2.0 m (6' 5") 2.3 m (7' 5")

14 cm (5 31/64")

±12 cm (±4 29/32")

40" (102 cm) 89 cm (35") 50 cm (20")

1.3 m (4' 3") 1.5 m (4' 11")

9 cm (3 21/32")

±8 cm (±3 17/64")

F: Picture size (diag.) (in/cm)

L: Projection distance (m/ft)

L1: Minimum projection distance (m/ft)

L2: Maximum projection distance (m/ft)

H: Distance from the lens center to the bottom of the image (cm/in)

S: Adjustable range of image position (cm/in) See page 43.

The formula for picture size and projection distance

[m/cm]

L1 (m) = 0.03256F

L2 (m) = 0.03754F

H (cm) = 0.23231F

S (cm) = ±0.20754F

[Feet/inches]

L1 (ft) = 0.03256F / 0.3048

L2 (ft) = 0.03754F / 0.3048

H (in) = 0.23231F / 2.54

S (in) = ±0.20754F / 2.54

Refer to page 18 concerning “Projection distance [L]” and “Distance from the lens center to the

bottom of the image [H]”.

Allow a margin of error in the values in the diagrams above.

•

•

Note

21

Connections

Connecting the Projector to Other Equipment

Before connecting, ensure that the power cord of the projector is unplugged from the AC outlet

and turn off the equipment to be connected. After making all connections, turn on the projector

and then the other pieces of equipment. When connecting a computer, ensure that it is the last

equipment to be turned on after all the connections are made.

IMPORTANT:

Ensure that the appropriate input mode has been selected on the projector before

you turn on the connected equipment.

For more details of connection and cables, refer to the operation manual of the connecting equipment.

You may need other cables or connectors not listed below.

Terminals on the Projector

Equipment

Terminal on

connected equipment

Cable Terminal on the

projector

Computer RGB

output

terminal

RGB cable (supplied) COMPUTER/

COMPONENT

RGB

output

terminal

mini D-sub 15 pin to DVI cable

(commercially available)

DVI-I

DVI digital

output

terminal

DVI Digital cable (commercially available)

When you connect external equipment to the projector using a DVI digital cable, the image will look

different from its original appearance. In this case, switch to the Plug-and-Play data. (See page 37.)

See page 58 “Computer Compatibility Chart” for a list of computer signals compatible with the

projector. Use with computer signals other than those listed may cause some of the functions to not

work.

A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest

Macintosh Dealer.

Depending on the computer you are using, an image may not be projected unless the

computer's external output port is switched on (e.g. Press “Fn” and “F5” keys

simultaneously when using a SHARP notebook computer). Refer to the specifi c instructions in

your computer's operation manual to enable your computer's external output port.

•

•

•

•

Note

•

•

22

Connecting the Projector to Other Equipment (Continued)

Equipment

Terminal on

connected equipment

Cable Terminal on the

projector

Video equipment HDMI output

terminal

HDMI to DVI cable

(commercially available)

DVI-I

DVI digital

output

terminal

DVI Digital cable (commercially available)

Component

video output

terminal

3 RCA to mini D-sub 15 pin cable

(optional, AN-C3CP2)

COMPUTER/

COMPONENT

S-video

output

terminal

S-video cable (commercially available) S-VIDEO

Video output

terminal

Video cable (commercially available) VIDEO

Camera/Video game

Component

video

output

terminal

Cables for a camera or a video game/3 RCA to

mini D-sub 15 pin cable (optional, AN-C3CP2)

RCA adaptor plug

(commercially available)

COMPUTER/

COMPONENT

S-video

output

terminal

Cables for a camera or a video game S-VIDEO

Video

output

terminal

Cables for a camera or a video game VIDEO

While the projector is connected to video equipment that has an HDMI output terminal, only the video

signal can be input to the projector. (Connect the AUDIO input terminal for audio input.)

Depending on specifi cations of video equipment or the DVIÙHDMI digital cable, the signal

transmission may not work property. (The HDMI specifi cation does not support all connections to

video equipment that has HDMI digital output terminal using a DVIÙHDMI digital cable.)

For details on compatibility for connection, see support information on DVI connection provided by

the video equipment manufacturer.

When you connect external equipment to the projector using a DVI digital cable, the image will look

different from its original appearance. In this case, switch to the Plug-and-Play data. (See page 37.)

When you connect video equipment with a 21-pin RGB output (Euro-scart) to the projector, use a

commercially available cable that fi ts in the projector terminal you want to connect.

The projector does not support RGBC signals via the Euro-scart.

•

•

•

•

•

•

Note

23

Connections

Equipment

Terminal on

connected equipment

Cable Terminal on the

projector

Audio equipment ø3.5 mm

audio output

terminal

ø3.5 mm stereo or mono audio cable

(commercially available or available

as Sharp service part QCNWGA038WJPZ)

AUDIO 1

RCA audio

output

terminal

RCA audio cable (commercially available)

AUDIO 2

Audio

output

terminal

Cables for a camera or a video game

Monitor RGB

input

terminal

RGB cable (supplied or commercially

available)

MONITOR OUT

Amplifi er

ø3.5 mm

audio input

terminal

ø3.5 mm stereo or mono audio cable

(commercially available or available

as Sharp service part QCNWGA038WJPZ)

AUDIO OUT

RCA audio

input

terminal

ø3.5 mm stereo minijack to RCA audio cable

(commercially available)

When using the ø3.5 mm mono audio cable, the volume level will be half of when using the ø3.5 mm

stereo audio cable.

You can select “Audio 1” or “Audio 2” for “Audio Input” in the “PRJ-ADJ” menu. (See page 46.)

RGB signals and Component signals can be output to the monitor.

•

•

•

Note

24

Controlling the Projector by a Computer

When the RS-232C terminal on the projector is connected to a computer with an RS-232C serial

control cable (cross type, commercially available), the computer can be used to control the

projector and check the status of the projector. Refer to the “SETUP MANUAL” contained on the

supplied CD-ROM for “RS-232C Specifi cations and Commands”.

When connecting to a computer using an RS-232C serial control cable

RS-232C serial control cable (cross type, commercially available)

Computer

To RS-232C terminal

To RS-232C terminal

The RS-232C function may not operate if your computer terminal is not correctly set up. Refer to the

operation manual of the computer for details.

Refer to pages 2 to 8 of the “SETUP MANUAL” contained on the supplied CD-ROM for “Connecting

Pin Assignments” and “RS-232C Specifi cations and Commands”.

•

•

Note

Info

Do not connect the RS-232C cable to a port other than the RS-232C terminal on the computer. This

may damage your computer or projector.

Do not connect or disconnect an RS-232C serial control cable to or from the computer while it is on.

This may damage your computer.

•

•

25

Connections

When connecting to the LAN terminal using a LAN cable

TX/RX LED (yellow)

Illuminates when transmitting/receiving data.

LINK LED (green)

Illuminates when linked.

* To ensure safety, do not connect the LAN terminal

with any cables that may cause excessive voltage

such as a telephone line.

Hub

or

Computer

LAN cable (Category 5 type,

commercially available)

To LAN terminal

When connecting to a hub, use a straight-through Category 5 (CAT.5) type cable (commercially

available).

When connecting to a computer, use a cross-over Category 5 (CAT.5) type cable (commercially

available).

•

•

Note

Connecting the Power Cord

Plug the supplied power cord into the

AC socket on the rear of the projector.

Then plug into AC outlet.

AC socket

To AC outlet

Power cord

(supplied)

AC socket

To AC outlet

Power cord

(supplied)

26

Turning the Projector On/Off

Turning the Projector On

Note that the connections to external

equipment and power outlet should be

done before performing the operations

written below. (See pages 21 to 25.)

Open the lens shutter fully and press

STANDBY/ON on the projector or ON

on the remote control.

The power indicator illuminates green.

After the lamp indicator illuminates, the projector

is ready to start operation.

About the Lamp Indicator

The lamp indicator illuminates to indicate the

status of the lamp.

Green: The lamp is on.

Blinking in green: The lamp is warming up.

Red: The lamp is shut down

abnormally or the lamp should be

replaced.

When switching on the projector, a slight

fl ickering of the image may be experienced

within the fi rst minute after the lamp has been

illuminated. This is normal operation as the

lamp's control circuitry is stabilising the lamp

output characteristics. It should not be

regarded as faulty operation.

If the projector is put into standby mode and

immediately turned on again, the lamp may

take some time to start projection.

When System Lock is set, the keycode input

box appears. To cancel the keycode setting,

input the keycode that you have already set.

See page 46 for details.

•

•

•

•

Note

Turning the Power Off (Putting

the Projector into Standby Mode)

Press STANDBY/ON on the projector

or STANDBY on the remote control,

then press that button again while the

confi rmation message is displayed, to

put the projector into standby mode.

The projector cannot be turned on while cooling.

•

•

•

Info

When “Auto Restart” is set to “On”:

If the power cord is unplugged from the outlet

or the breaker switch is turned off when the

projector is on, then the projector

automatically turns on when the power cord

is plugged into the AC outlet or the breaker

switch is turned on. (See page 45.)

English is the factory default language. If you

want to change the on-screen display to

another language, change the language

according to the procedure on page 44.

•

•

STANDBY/ON button

Lamp indicator

Power indicator

STANDBY

button

ON button

On-screen display (confi rmation message)

Info

Direct Power Off function:

You can unplug the power cord from the AC

outlet even if the cooling fan is still running.

•

27

Basic

Operation

Image Projection

Adjusting the Projected Image

1 Adjusting the Focus

You can adjust the focus with the focus

ring on the projector.

Rotate the focus ring to adjust the

focus while watching the projected

image.

2 Adjusting the Height

The height of the projector can be

adjusted using the adjustment feet.

When the screen is above the projector,

the projection image can be made higher

by adjusting the projector.

1 Lift the projector to adjust its

height while lifting the HEIGHT

ADJUST lever.

2 Remove your hands from the

HEIGHT ADJUST lever of the

projector after its height has

been fi nely adjusted.

The angle of projection is adjustable up to

9 degrees from the surface on which the

projector is placed.

When adjusting the height of the projector,

trapezoidal distortion occurs. Follow the

procedures in Keystone Correction to correct

the distortion. (See pages 28 and 43.)

•

Note

3 Adjusting the Picture Size

You can adjust the picture size using the

zoom ring on the projector.

Rotate the zoom ring to enlarge or

shrink the picture size.

•

Focus ring

Zoom ring

Focus ring

Zoom ring

HEIGHT ADJUST

lever

HEIGHT ADJUST

lever

1

2

Make small

adjustments.

Make small

adjustments.

Info

Do not apply too much pressure on the

projector when the front adjustment feet

come out.

When lowering the projector, be careful not to

get your fi ngers caught in the area between

the adjustment feet and the projector.

Hold the projector fi rmly while lifting or carrying.

Do not hold by the lens area.

•

•

•

•

28

Image Projection (Continued)

Correcting Trapezoidal

Distortion

When the image is projected either from

the top or from the bottom towards the

screen at an angle, the image becomes

distorted trapezoidally. The function for

correcting trapezoidal distortion is called

Keystone Correction.

The Keystone Correction can be adjusted up

to an angle of approximately ±40 degrees and

the screen can also be set up to an angle of

approximately ±40 degrees (when the resize

mode is set to “NORMAL” (see page 30)).

•

Note

1 Press KEYSTONE to enter the

Keystone Correction mode.

You can also display the on-screen display

of the Keystone Correction mode with

KEYSTONE on the projector.

2 Press P/Q or O/R to adjust the

Keystone Correction.

You can also adjust the Keystone

Correction using the adjustment buttons

on the projector.

To return to the default setting, press

RETURN while the on-screen display of the

Keystone Correction mode is on the screen.

•

Note

3 Press KEYSTONE.

The on-screen display of the Keystone

Correction mode will disappear.

You can also use KEYSTONE on the

projector.

•

•

•

•

1

2

3

KEYSTONE button

Adjustment buttons

(P/R/O/Q)

RETURN button

On-screen display

(Keystone Correction mode)

0KEYSTONE

ADJUST END

Shrinks upper side.

(Move the slide bar in the + direction.)

Shrinks lower side.

(Move the slide bar in the - direction.)

Info

While adjusting the image using Keystone

Correction, straight lines and the edges of the

image may appear jagged.

•

29

Basic

Operation

Switching the Input Mode

Select the appropriate input mode for the

connected equipment.

Press COMPUTER,DVI,S-VIDEO or

VIDEO on the remote control to select

the input mode.

When you press INPUT on the projector or DVI

on the remote control, the INPUT list appears.

Press P/R to switch the INPUT mode.

Adjusting the Volume

Press VOL +/– on the remote control

or –O/Q+ on the projector to adjust

the volume.

Pressing VOL–/–O will lower the volume.

Pressing VOL+/Q+ will raise the volume.

When the projector is connected to external

equipment, the volume level of the external

equipment changes in accordance with the

volume level of the projector. Set the projector's

volume to the lowest level when turning the

projector on/off or when changing the input signal.

When you do not want to output the sound

from the projector's speaker while the

projector is connected to external equipment,

set “Speaker” in “PRJ-ADJ” menu to “Off”.

(See page 46.)

•

•

•

•

Note

Displaying the Black Screen

and Turning Off the Sound

Temporarily

Press AV MUTE on the remote control

or close the lens shutter to temporarily

display a black screen and turn off the

sound.

Pressing AV MUTE again will turn the

projected image back on.

When you close the lens shutter, the projector will

be AV MUTE mode and then the projector will be

turned off automatically after about 30 minutes.

•

•

Note

•VOL +/– (Volume)

buttons

COMPUTER, DVI,

S-VIDEO, VIDEO

buttons

AV MUTE button

VOL +/– (Volume)

buttons

COMPUTER, DVI,

S-VIDEO, VIDEO

buttons

AV MUTE button

On-screen displayOn-screen display

On-screen displayOn-screen display

30

Image Projection (Continued)

Resize Mode

This function allows you to modify or customize the resize mode to enhance the input

image. Depending on the input signal, you can choose a desired image.

Press RESIZE.

See page 43 for setting on menu screen.

COMPUTER

Main resolution NORMAL FULL DOT BY DOT BORDER STRETCH

4:3 aspect ratio

SVGA (800 × 600)

1024 × 768 —

800 × 600

768 × 576 1024 × 576

XGA (1024 × 768) —

SXGA (1152 × 864) 1152 × 864

UXGA (1600 × 1200) 1600 × 1200

Other aspect ratios

SXGA (1280 × 1024) 968 × 768

1024 × 768

1280 × 1024 720 × 576

1280 × 720 1024 × 576 1280 × 720 — —

1360 × 768 1024 × 578 1360 × 768 — —

1366 × 768 1024 × 576 1366 × 768 — —

1280 × 768 1024 × 614 1280 × 768 960 × 576 1024 × 576

1280 × 800 1024 × 640 1280 × 800 922 × 576

Input signal For 4:3 screen For 16:9 screen

Computer Image type NORMAL FULL DOT BY DOT BORDER STRETCH

Resolution

lower than

XGA

4:3 aspect ratio

—

*2 *1 *1

XGA

—

*2

Resolution

higher than

XGA

SXGA (1280 × 1024)

5:4 aspect ratio

1280 × 720

16:9 aspect ratio

*1

—

*2

—

*2

1360 × 768

1366 × 768

1280 × 768

16:10 aspect ratio

*1 *1 *1

1280 × 800

: Cutout area on which images cannot be projected

: Area where the signals are off screen

*1 The Image Shift function can be used for these images.

*2 Same as NORMAL mode

•RESIZE

button

RESIZE

button

31

Basic

Operation

VIDEO/DTV

Input signal For 4:3 screen For 16:9 screen

Video/DTV Image type NORMAL AREA ZOOM V-STRETCH BORDER STRETCH

480I, 480P,

576I, 576P,

NTSC, PAL,

SECAM

4:3 aspect ratio

*1 *1

Squeeze

*1 *1

Letter box

*1 *1

720P, 1035I,

1080I, 1080P 16:9 aspect ratio

*1

—

*2

—

*2

540P

16:9 aspect ratio

(4:3 aspect ratio in 16:9)

*1

: Cutout area on which images cannot be projected

: Area on which the image is not included in the original signals

*1 The Image Shift function can be used for these images.

*2 Same as NORMAL mode.

About Copyrights

When using the RESIZE function to select an image size with a different aspect ratio to a TV

program or video image, the image will look different from its original appearance. Keep this

in mind while choosing an image size.

The use of the Resize or Keystone Correction function to compress or stretch the image for

commercial purposes/public displays in a café, hotel, etc. may be an infringement of

copyright protected by law for copyright holders. Please use caution.

•

•

32

Operating with the Remote Control

POINTER button

ECO+QUIET button

Adjustment buttons

(P/R/O/Q)

BREAK TIMER button

SPOT button

AUTO SYNC button

FREEZE button

PICTURE MODE button

MAGNIFY buttons

EFFECT button

Displaying and Setting the

Break Timer

1 Press BREAK TIMER.

The timer starts to count down from 5

minutes.

On-screen display

2 Press P/R/O/Q to adjust the

length of the break time.

Increases with P or Q

5 minutes ➞ 6 minutes ➞ 60 minutes

Shortens with O or R

4 minutes ➞ 3 minutes ➞1 minute

The break time can be set in units of one

minute (up to 60 minutes).

Canceling the break timer display function

Press BREAK TIMER.

Break Timer does not function while the

projector is operating the “Auto Sync”,

“FREEZE” or “AV MUTE” functions.

•

Note

•

•

•

•

1

2

Displaying the Pointer

1 Press POINTER and press P/R/

O/Qon the remote control to

move the pointer.

Press EFFECT to change the pointer icon

(5 types).

Star Finger1 Finger2 Heart Underline

2 Press POINTER again.

The pointer will disappear.

Using the Spot Function

1 Press SPOT and press P/R/O/Q

on the remote control to move

the spot area.

Press EFFECT to change the spot area

size (3 types).

1/9 1/25 1/8

2 Press SPOT again.

The spot area will disappear.

Switching the Eco+Quiet

Mode

Press ECO+QUIET to switch the

Eco+Quiet mode between on and off.

When the Eco+Quiet Mode is set to “ON”, the

sound of the cooling fan will turn down, the power

consumption will decrease, and the lamp life will

extend.

Refer to “Eco+Quiet” on page 42 for details.•

Note

•

•

•

•

•

1

2

1

2

33

Useful

Features

Auto Sync

(Auto Sync Adjustment)

Auto Sync function works when detecting

input signal after the projector turns on.

Press AUTO SYNC to manually adjust

with Auto Sync function.

When the optimum image cannot be achieved

with Auto Sync adjustment, use the help

menu for manual adjustments. (See page 51.)

•

Note

Freezing a Moving Image

1 Press FREEZE.

The projected image is frozen.

2 Press FREEZE again to return to

the moving image from the

currently connected device.

Selecting the Picture Mode

You can select the appropriate picture

mode for the projected image, such as

movie or video game.

Press PICTURE MODE.

When pressing PICTURE MODE, the picture

mode changes in the following order:

STANDARD PRESENTATION MOVIE GAME sRGB

*

See page 40 for details on the picture mode.•

Note

* “sRGB” is displayed only when RGB signal is input.

•

•

1

2

Displaying an Enlarged

Portion of an Image

Graphs, tables and other portions of

projected images can be enlarged. This

is helpful when providing more detailed

explanations.

1 Press MAGNIFY on the

remote control.

Enlarges the image.

Pressing or MAGNIFY enlarges

or reduces the projected image.

×1×2×3×4

Press

.

Press

.

You can change the location of the

enlarged image using P,R,O and Q.

•

Note

2 Press RETURN on the remote

control to cancel the operation.

The magnifi cation then returns to u1.

The selectable magnifi cations differ

depending on the input signal.

In the following cases, the image will

return to the normal size (u1).

- When switching the INPUT mode.

- When RETURN has been pressed.

- When the input signal is changed.

- When the input signal resolution and

refresh rate (vertical frequency)

change.

- When the Resize mode is changed.

- When the Picture mode is changed.

- When the Progressive mode is

changed.

•

•

Note

•

•

•

1

2

34

Using the Remote Control as the Wireless Computer Mouse

When connecting the projector and the computer with a USB cable, you can use the

remote control as the computer mouse.

If the computer is placed too far away from the projector to be connected via the USB

cable, the remote receiver (optional, AN-MR2) makes it possible to operate the

projector with the remote control. For details, see the operation manual of the

receiver.

Connecting with a USB cable

or

R

emote receiver

(optional, AN-MR2)

To USB terminal

USB cable

(commercially available or available as

Sharp service part QCNWGA014WJPZ)

To USB terminal

Computer

The mouse pointer can be

operated in the following way

after it is connected.

When moving the cursor

Press MOUSE/Adjustment buttons (P/R/O/Q).

When left-clicking

Press L-CLICK.

When right-clicking

Press R-CLICK.

When your computer supports only a

one-click mouse (such as Macintosh)

Press L-CLICK or R-CLICK.

L-CLICK and R-CLICK have common function.

When using [Page Up] or [Page Down]

■

■

■

■

■

MOUSE/Adjustment

buttons (//?/_)

R-CLICK button

L-CLICK button

PAGE UP/

PAGE DOWN button

s

MOUSE/Adjustment

buttons (//?/_)

R-CLICK button

L-CLICK button

PAGE UP/

PAGE DOWN button

s

Same as the [Page Up] and [Page Down] keys on a computer keyboard.

Press PAGE UP or PAGE DOWN.

This function only works with the Microsoft® Windows® OS and Mac OS®. However, this function

does not work with the following operation systems that do not support USB.

Versions earlier than Windows® 95

Versions earlier than Windows® NT4.0

Versions earlier than Mac OS® 8.5

You cannot use this function when displaying the menu screen.

Confi rm that the computer recognizes the USB connection.

•

•

•

•

•

•

Note

Operating with the Remote Control (Continued)

35

Useful

Features

Menu Items

The following shows the items that can be set in the projector.

“Picture” menu

Main menu Sub menu


Page 40 Page 40

Page 41

Page 41

Page 41

Page 41

Page 41

Page 42

Page 42

+30-30

Contrast

+30-30

+30-30

+30-30

1-1

20

+30-30

+30-30

+30-30

Tint

Color

Sharp

Bright

Progressive

Eco+Quiet

Reset

2D Progressive

3D Progressive

Film Mode

CLR Temp

BrilliantColor™

C.M.S. Setting [On/Off]

C.M.S.

Standard

Presentation

Movie

Game

sRGB*1

Picture Mode

*2

*2

*2

Red

Blue

*2

Page 42

DNR Off

Level 1

Level 2

On

Off

C.M.S.-Hue

C.M.S.-Saturation

C.M.S.-Value

Page 41

Page 41

Page 41

Reset

+30-30

R

+30-30

+30-30

+30-30

+30-30

+30-30

C

G

B

Y

M

Reset

Main menu Sub menu


Page 40 Page 40

Page 41

Page 41

Page 41

Page 41

Page 41

Page 42

Page 42

+30-30

Contrast

+30-30

+30-30

+30-30

1-1

20

+30-30

+30-30

+30-30

Tint

Color

Sharp

Bright

Progressive

Eco+Quiet

Reset

2D Progressive

3D Progressive

Film Mode

CLR Temp

BrilliantColor™

C.M.S. Setting [On/Off]

C.M.S.

Standard

Presentation

Movie

Game

sRGB*1

Picture Mode

*2

*2

*2

Red

Blue

*2

Page 42

DNR Off

Level 1

Level 2

On

Off

C.M.S.-Hue

C.M.S.-Saturation

C.M.S.-Value

Page 41

Page 41

Page 41

Reset

+30-30

R

+30-30

+30-30

+30-30

+30-30

+30-30

C

G

B

Y

M

Reset

Picture Mode

Contrast 0

0

0

0

Bright

Color

Tint

0Sharp

Standard

SEL./ADJ. ENTER END

0

0

Red

Blue

Picture SCR PRJ Net. Help

PAGE 1

Picture Mode

CLR Temp

BrilliantColorTM

C.M.S. Setting

C.M.S.

Standard

SEL./ADJ. ENTER END

Progressive

Eco+Quiet

0

1

On

3D Progressive

On

DNR Off

Reset

Picture SCR PRJ Net. Help

PAGE 2

“C.M.S.”

SEL./ADJ.

Return

ENTER

END

C. M. S. - Hu e

0

0

0

0

C. M. S. - Saturation

C. M. S. - Value

0

0

R

Y

G

C

B

M

C. M. S.

Reset

Reset

*1 Items when inputting RGB signal through

COMPUTER or DVI.

*2 Items when inputting component signal through

COMPUTER or DVI, or when selecting S-VIDEO or

VIDEO.

36

“Screen adjustment (SCR-ADJ)” menu

SEL./ADJ. ENTER END

Resize

Image Shift 0

0

Keystone

Overscan

OSD Display

Closed Caption

Background

PRJ Mode

Language

Front

English

Logo

On

Off

On

Border

Pict. SCR-ADJ PRJ Net. Help

“Projector adjustment (PRJ-ADJ)” menu

SEL./ADJ. ENTER END

Auto Power Off

System Sound

System Lock

h

On

On

Auto Restart On

STANDBY Mode Standard

0 min0Lamp Timer(Life) 100%

Auto Sync On

Pict. SCR PRJ-ADJ Net. Help

Speaker On

Audio Input Audio 1

RS-232C 9600bps

Fan Mode Normal

Disable

Audio Out VAO

Main menu Sub menu

SCR - ADJ

Page 43

Language

Image Shift

Resize

Page 43

Page 43

Page 43

Page 44

Page 44

Page 44

Page 44

Keystone

OSD Display [On/Off]

Page 44

Closed Caption

Page 43

Overscan [On/Off]

Background

PRJ Mode

Logo

Blue

None

Off

CC1

CC2

Front

Ceiling + Front

Rear

Ceiling + Rear

+80-80

+96-96

Normal

Full

Dot By Dot

Area Zoom

V-Stretch

Border

Stretch

English

Deutsch

Español

Nederlands

Français

Italiano

Svenska

Português

polski

Magyar

Türkçe

Main menu Sub menu

SCR - ADJ

Page 43

Language

Image Shift

Resize

Page 43

Page 43

Page 43

Page 44

Page 44

Page 44

Page 44

Keystone

OSD Display [On/Off]

Page 44

Closed Caption

Page 43

Overscan [On/Off]

Background

PRJ Mode

Logo

Blue

None

Off

CC1

CC2

Front

Ceiling + Front

Rear

Ceiling + Rear

+80-80

+96-96

Normal

Full

Dot By Dot

Area Zoom

V-Stretch

Border

Stretch

English

Deutsch

Español

Nederlands

Français

Italiano

Svenska

Português

polski

Magyar

Türkçe

Main menu Sub menu

PRJ - ADJ

Page 45

STANDBY Mode

System Sound [On/Off]

Speaker [On/Off]

System Lock

[Enable/Disable]

Lamp Timer(Life)

Page 45

Auto Restart [On/Off]

Page 45

Auto Power Off [On/Off]

Page 45

Page 45

Audio Out

Page 46

Page 46

Page 46

Page 47

Fan Mode

Page 46

Normal

High

RS-232C

Page 46

9600bps

38400bps

115200bps

Audio Input

Page 46

Audio 1

Audio 2

FAO

VAO

Standard

Eco

Auto Sync [On/Off]

Page 45

Main menu Sub menu

PRJ - ADJ

Page 45

STANDBY Mode

System Sound [On/Off]

Speaker [On/Off]

System Lock

[Enable/Disable]

Lamp Timer(Life)

Page 45

Auto Restart [On/Off]

Page 45

Auto Power Off [On/Off]

Page 45

Page 45

Audio Out

Page 46

Page 46

Page 46

Page 47

Fan Mode

Page 46

Normal

High

RS-232C

Page 46

9600bps

38400bps

115200bps

Audio Input

Page 46

Audio 1

Audio 2

FAO

VAO

Standard

Eco

Auto Sync [On/Off]

Page 45

Menu Items (Continued)

37

Useful

Features

“Network” menu

SEL./ADJ. ENTER END

Pict. SCR PRJ Network Help

Password Disable

DHCP Client Off

TCP/IP

MAC Address

Projector

XX : XX : XX : XX : XX : XX

XX-XXXX

“Help” menu

SEL ENTER END

There is no picture or audio

Vertical stripes or flickering image appear

Data image is not centered

Color is faded or poor

Picture is dark

The image is distorted

It is difficult to hear audio

Reset all adjustments to default settings

SEL.

Pict. SCR PRJ Net. Help

Main menu

Network

Page 49

Password [Enable/Disable]

DHCP Client

[On/Off]

TCP/IP

MAC Address

Projector

Page 49

Page 50

Page 50

Page 50

Page 50

Main menu

Network

Page 49

Password [Enable/Disable]

DHCP Client

[On/Off]

TCP/IP

MAC Address

Projector

Page 49

Page 50

Page 50

Page 50

Page 50

The items you can set with the

“Help” menu

“Help” menu n Page 51

Vertical stripes or fl ickering image appear

Auto Sync/Clock/Phase

Data image is not centered

COMPUTER or DVI-Analog input

Auto Sync/H-Pos/V-Pos/Resolution

DVI-D input

Switch to Plug-and-Play data

* Switch to Plug-and-Play data in the following

cases.

DVI-D Computer input

Standard : Aspect ratio 4:3 or 5:4 signals

such as 1024x768

Enhanced1 : Wide-screen signals such as

1280x800 are prioritized.

Enhanced2 : Wide-screen signals such as

1366x768 are prioritized.

DVI-D Video input

Standard : Normal

Enhanced : Select this item when no

image is projected in

“Standard” mode.

Color is faded or poor

COMPUTER or DVI input

Signal type: Auto/RGB/Component

S-VIDEO or VIDEO input

Video System: Auto/PAL/SECAM/

NTSC3.58/NTSC4.43/

PAL-M/PAL-N/PAL-60

DVD-D input

Dynamic range: Auto/Standard/Enhanced

* The selectable items vary depending on the input

signal and the selected input mode.

It is diffi cult to hear audio

Balance/Treble/Bass

•

•

•

•

38

Using the Menu Screen

Adjustment buttons

(P/R/O/Q)

ENTER button

RETURN button

Press RETURN to return

to the previous screen

when the menu is

displayed.

•

MENU/HELP button

Adjustment buttons (P/R/O/Q)

MENU/HELP button

ENTER button

RETURN button

Menu Selections (Adjustments)

Example: Adjusting “Bright”.

This operation can also be performed by using the buttons on the projector.•

1 Press MENU/HELP.

The “Picture” menu screen for the selected

input mode is displayed.

2 Press Q or O and select

“Picture” to adjust.

•

1

2

Example: “Picture” screen menu for

COMPUTER (RGB) input

Menu item

Picture Mode

Contrast 0

0

0

Bright

Standard

SEL./ADJ. ENTER END

0

0

Red

Blue

CLR Temp

BrilliantColorTM

C.M.S. Setting

C.M.S.

Eco+Quiet

0

1

On

On

DNR Off

Reset

Picture SCR PRJ Net. Help

39

Useful

Features

3 Press P or R and select “Bright”

to adjust.

The selected item is highlighted.

To adjust the projected

image while watching it

Press ENTER.

The selected item (e.g. “Bright”) is

displayed by itself at the bottom of the

screen.

When pressing P or R, the following item

(“Red” after “Bright”) will be displayed.

Press ENTER again to return to the

previous screen.

•

Note

4 Press O or Q to adjust the item

selected.

The adjustment is stored.

5 Press MENU/HELP.

The menu screen will disappear.

•

•

•

•

•

3

0Bright


SEL./ADJ. Rtn. Menu END

Picture Mode Standard

SEL./ADJ. Single ADJ END

Resize

Image Shift 0

0

Keystone

Border

Picture Mode

Contrast 0

0

Standard

SEL./ADJ. END

0

0

Red

Blue

CLR Temp

BrilliantColorTM

C.M.S. Setting

C.M.S.

Eco+Quiet

0

1

On

On

Reset

Bright 0

DNR Off

Picture SCR PRJ Net. Help

Pict. SCR-ADJ PRJ Net. Help

Items to be adjusted

The item displayed by itself

Press ENTER.

0Bright


SEL./ADJ. Rtn. Menu END

Picture Mode Standard

SEL./ADJ. Single ADJ END

Resize

Image Shift 0

0

Keystone

Border

Picture Mode

Contrast 0

0

Standard

SEL./ADJ. END

0

0

Red

Blue

CLR Temp

BrilliantColorTM

C.M.S. Setting

C.M.S.

Eco+Quiet

0

1

On

On

Reset

Bright 0

DNR Off

Picture SCR PRJ Net. Help

Pict. SCR-ADJ PRJ Net. Help

Items to be adjusted

The item displayed by itself

Press ENTER.

4

Picture Mode

Contrast 0

0

Standard

SEL./ADJ. Single ADJ END

0

0

Red

Blue

CLR Temp

BrilliantColorTM

C.M.S. Setting

C.M.S.

Eco+Quiet

0

1

On

On

Reset

15Bright

DNR Off

Picture SCR PRJ Net. Help

Picture Mode

Contrast 0

0

Standard

SEL./ADJ. Single ADJ END

0

0

Red

Blue

CLR Temp

BrilliantColorTM

C.M.S. Setting

C.M.S.

Eco+Quiet

0

1

On

On

Reset

15Bright

DNR Off

Picture SCR PRJ Net. Help

5

Menu buttons do not function while the projector is operating the “Auto Sync”, “Break Timer”,

“FREEZE”, or “AV MUTE” functions.

•

Note

40

Picture Adjustment (“Picture” Menu)

Menu operation n Page 38

QPAGE1 QPAGE2

Picture Mode

Contrast 0

0

0

0

Bright

Color

Tint

0Sharp

Standard

SEL./ADJ. ENTER END

0

0

Red

Blue

Picture SCR PRJ Net. Help

1

2

Picture Mode

CLR Temp

BrilliantColor

TM

C.M.S. Setting

C.M.S.

Standard

SEL./ADJ. ENTER END

Progressive

Eco+Quiet

0

1

On

3D Progressive

On

DNR Off

Reset

Picture SCR PRJ Net. Help

7

6

5

4

2

3

1Selecting the Picture Mode

Selectable

items Description The default settings of each item when selecting Picture Mode

CLR Temp BrilliantColorTM Eco+Quiet

Standard For standard image 0 1 Off

Presentation Brightens portions of image for

more enhanced presentations.

02Off

Movie Gives natural tint to the

projected image.

–1 0 On

Game Gives sharpness to the

projected image.

01Off

*sRGB For high fi delity reproduction of

images from a computer.

––Off

“sRGB” is displayed only when RGB signal is input.

You can set or adjust each item in the “Picture” menu to your preference. Any changes you make are

retained in memory.

You can also press PICTURE MODE on the remote control to select the picture mode. (See page 33.)

*sRGB is an international standard of color reproduction regulated by the IEC (International

Electrotechnical Commission). As the fi xed color area has been decided by the IEC, the images are

displayed in a natural tint based on an original image, when “sRGB” is selected.

For additional information about the sRGB function, visit “http://www.srgb.com/”.

You cannot set the items, “Red”, “Blue”, “CLR Temp”, “BrilliantColorTM”, when “sRGB” is selected.

•

•

Note

Info

When “sRGB” is selected, the projected image may become dark, but this does not indicate a

malfunction.

•

•

•

41

Useful

Features

Menu operation n Page 38

2 Adjusting the Image

Adjustment

items O button Q button

Contrast For less

contrast. For more

contrast.

Bright For less

brightness. For more

brightness.

Color*1For less color

intensity. For more color

intensity.

Tint*1For making skin

tones purplish. For making skin

tones greenish.

Sharp*1For less

sharpness. For more

sharpness.

Red*2For weaker red. For stronger

red.

Blue*2For weaker

blue. For stronger

blue.

BrilliantColor™*

2

*

3

For making the

effect weaker. For making the

effect stronger.

*1 Not displayed in the RGB input mode.

*2 Not adjustable/selectable when selecting “sRGB”.

*3 BrilliantColor™ uses Texas Instruments'

BrilliantColor™ technology. As the BrilliantColor™

level is increased, the image becomes brighter

while the color reproduction is kept at a high level.

“Red”, “Blue”, “BrilliantColorTM” and “CLR

Temp” cannot be set when “sRGB” is

selected.

To reset all adjustment items, select “Reset”

and press ENTER.

•

•

Note



Adjusting the Color

Temperature

Selectable

items Description

–1

0

1

For lower color temperature for

warmer, reddish incandescent-like

images.

For higher color temperature for

cooler, bluish, fl uorescent-like images.

Values on “CLR Temp” are only for general

standard purposes.

•

Note

4 Adjusting the Colors

This function adjusts each of the six main

colors that comprise the color wheel, altering

their “Hue”, “Saturation”, or “Value”.

Selectable items Description

C.M.S.-Hue Sets the hue of the main colors.

C.M.S.-Saturation Sets the saturation of the main

colors

C.M.S.-Value Sets the brightness of the main

colors.

Reset The adjustments of “Hue”,

“Saturation” and “Value” of all

colors are reset to the default

setting.

Adjusting “Hue”, “Saturation”, or “Value”.

1Select “On” for “C.M.S. Setting” in the “Picture”

menu and then press ENTER.

2 Select “C.M.S.” in the “Picture” menu and then

press ENTER.

3 Press P or R to select either “Hue”, “Saturation”, or

“Value” and then press ENTER.

4 Select the color to be adjusted with P or R and

adjust it with O or Q.

Example of adjusting the “Hue”

Main colors O button Q button

R (Red)

Closer to magenta

Closer to yellow

Y (Yellow) Closer to red Closer to green

G (Green) Closer to yellow Closer to cyan

C (Cyan) Closer to green Closer to blue

B (Blue) Closer to cyan

Closer to magenta

M (Magenta) Closer to blue Closer to red

When “Saturation” is selected, the selected

color becomes

O: lighter. Q: thicker.

When “Value” is selected, the selected color

becomes

O: darker. Q: brighter.

To reset the adjustment values of each color to

the default settings, select “Reset” and press

ENTER.

•

•

•

42

5 Progressive

Selectable

items Description

2D

Progressive

Useful to display fast-moving images

such as sports.

3D

Progressive

Useful to display relatively slow-

moving images such as drama and

documentary more clearly.

Film Mode Reproduces the image of fi lm source*

clearly. Displays the optimized image

of fi lm transformed with three-two pull

down (NTSC and PAL60Hz) or two-

two pull down (PAL50Hz and SECAM)

enhancement to progressive mode

images.

* The fi lm source is a digital video recording with the

original encoded as is at 24 frames/second. The

projector can convert this fi lm source to

progressive video at 60 frames/second with NTSC

and PAL60Hz or at 50 frames/second with

PAL50Hz and SECAM to play back a high-

defi nition image.

In NTSC or PAL60Hz, even if the 3D

Progressive mode has been set, the three-two

pull down enhancement will be enabled

automatically when the fi lm source has been

entered.

When the image is blurred or noisy, switch to

the optimal mode.

•

•

Note

Info

This function is available for 480I and 576I

signals using COMPUTER/COMPONENT or

DVI input.

This function is available for all signals with

S-VIDEO and VIDEO input.

•

•

Picture Adjustment (“Picture” Menu)

(Continued)

Menu operation n Page 38

6

Reducing Image Noise (DNR)

Video digital noise reduction (DNR) provides

high quality images with minimal dot crawl

and cross color noise.

Selectable

items Description

Off The DNR function is not activated.

Level 1 Sets the DNR level for viewing a

clearer picture.

Level 2

Set “DNR” to “Off” in the following cases:

When the image is blurry.

When the contours and colors of moving

images drag.

When TV broadcasts with weak signals are

projected.

•

•

•

Note

7 Eco+Quiet

Selectable

items Brightness and Power consumption

On Approx. 75%

Off 100%

When “Eco+Quiet” is set to “On”, the fan

sound and power consumption are lower than

they are when “Off” is selected. (Projection

brightness decreases as shown in the chart.)

•

Note

43

Useful

Features

Adjusting the Projected Image (“SCR - ADJ” Menu)

Menu operation n Page 38

SEL./ADJ. ENTER END

Resize

Image Shift 0

0

Keystone

OSD Display

Closed Caption

Overscan

Background

PRJ Mode

Language

Front

English

On

Off

Logo

On

Border

Pict. SCR-ADJ PRJ Net. Help



















1

Setting the Resize Mode

For details of the Resize mode, see pages

30 and 31.

You can also press RESIZE on the remote

control to set the resize mode. (See page 30.)

•

•

Note

2 Adjusting the Image

Position

You can move the projected image vertically.

Q buttonO button

This function only works in some RESIZE

modes. (See pages 30 and 31.)

•

Note

3 Keystone Correction

When the image is projected either from the top

or from the bottom towards the screen at an

angle, the image becomes distorted trapezoidally.

The function for correcting trapezoidal distortion

is called Keystone Correction.

Select “Keystone” on the “SCR-ADJ”

menu and adjust with the slide bar.

See page 28 for details of Keystone Correction.

O buttonQ button

The Keystone Correction can be adjusted up

to an angle of approximately ±40 degrees

(when “Resize” is set to “Normal”).

You can also press KEYSTONE on the

remote control or on the projector to adjust

Keystone Correction.

•

•

Note

4 Setting the Overscan

This function allows you to set the overscan area

(display area).

Selectable

items Description

On The input area is displayed without the

screen edges.

Off The whole input area is displayed.

You can set “Overscan” for the following input

signals (Computer, DVI-D Video and DVI-

Analog).

—480P, 540P, 576P, 720P, 1035I and

1080I/1080P

If noise appears at the screen edges when

“Off” is selected, set the function to “On”.

Also see “About Copyrights” on page 31.

•

•

•

Note

44

5

Setting the On-screen

Display

Selectable

items Description

On All on-screen displays are displayed.

Off INPUT/VOLUME/AV MUTE/FREEZE/

AUTO SYNC/RESIZE/PICTURE

MODE/ECO+QUIET/MAGNIFY/ “An

invalid button has been pressed.” are

not displayed.

6 Closed Caption

<For Americas only>

Info

This function is available for NTSC3.58 and 480I

signals.

This function does not work when the resize

mode is set to “Border”.

This function is available in the following cases

only:

Resize mode Keystone Correction

Normal

Area Zoom

V-Stretch

-40 − +40

Stretch -12 − +12

•

•

•

“Closed Caption” is a system which allows

conversations, narration, and sound effects in TV

programs (Limited regions) and home videos to

be viewed as captions on the screen.

Not all programs and videos will offer closed

captioning. Please look for the symbol to

ensure that captions will be shown.

Two channels are available: CC1 and CC2.

The Closed Caption letters of this projector are

displayed in black and white.

Selectable

items Description

Off —

CC1 Closed Caption mode for CH1 data

CC2 Closed Caption mode for CH2 data

•

•

•

•

Closed Caption may malfunction (white blocks,

strange characters, etc.) if signal conditions are

poor or if there are problems at the broadcast

source. This does not necessarily indicate a

problem with the projector.

If any button is pressed to call up the on-

screen display while viewing a Closed Caption

broadcast, the closed captions will disappear.

•

•

Note

7 Selecting the Background


Selectable items Description

Logo Sharp logo screen

Blue Blue screen

None —

8 Reversing/Inverting

Projected Images

Selectable items Description

Front Normal image (Projected from

the front of the screen)

Ceiling + Front Inverted image (Projected from

the front of the screen with an

inverted projector)

Rear Reversed image (Projected from

the rear of the screen or with a

mirror)

Ceiling + Rear Reversed and inverted image

(Projected with a mirror)

See page 19 for details of Projection (PRJ) Mode.

9

Selecting the On-screen

Display Language

The projector can switch the on-screen

display language among 17 languages.

English

Deutsch

Español

Nederlands

Français

Italiano

Svenska

Português

polski

Magyar

Türkçe

Adjusting the Projected Image (“SCR - ADJ” Menu)

(Continued)

Menu operation n Page 38

45

Useful

Features

Adjusting the Projector Function (“PRJ - ADJ” Menu)

Menu operation n Page 38

SEL./ADJ. ENTER END

Auto Power Off

System Sound

System Lock

h

On

On

Auto Restart On

STANDBY Mode Standard

0 min0Lamp Timer(Life) 100%

Speaker On

Audio Out VAO

Audio Input Audio 1

RS-232C 9600bps

Fan Mode Normal

Disable

Auto Sync On

Pict. SCR PRJ-ADJ Net. Help

1

2

3

4

5

7

6

8

9

0

1 Auto Sync (Auto Sync

Adjustment)

Selectable

items Description

On Auto Sync adjustment will occur when

the projector is turned on or when the

input signals are switched, when

connected to a computer.

Off Auto Sync adjustment is not

automatically performed.

Auto Sync adjustment is also performed by

pressing AUTO SYNC on the remote control.

The Auto Sync adjustment may take some

time to complete, depending on the image of

the computer connected to the projector.

When the optimum image cannot be achieved

with Auto Sync adjustment, use manual

adjustments. (See page 51.)

•

•

•

Note

2

Auto Power Off Function

Selectable

items Description

On When no input signal is detected for

more than 15 minutes, the projector will

automatically enter standby mode.

Off The Auto Power Off function will be

disabled.

When the Auto Power Off function is set to

“On”, 5 minutes before the projector enters

standby mode, the message “Enter STANDBY

mode in X min.” will appear on the screen to

indicate the remaining minutes.

•

Note

3 Auto Restart Function

Selectable

items Description

On

If the power cord is unplugged from the

outlet or the breaker switch is turned off

when the projector is on, then the

projector automatically turns on when

the power cord is plugged into the AC

outlet or the breaker switch is turned on.

Off The projector does not turn on

automatically when the power cord is

plugged into the AC outlet or the

breaker switch is turned on.

4STANDBY Mode

When set to “Eco”, power consumption is

reduced in standby mode.

Selectable

items Description

Eco The monitor output and Network

functions are switched off in standby

mode.

Standard The monitor output and Network

functions are activated even if the

projector is in standby mode.

5

Setting the Confi rmation

Sound (System Sound)

Selectable

items Description

On A confi rmation sound is made when

the projector turns on/off.

Off No confi rmation sound is made.

46

6

Audio Output Type Setting

This function determines whether the audio

level output from the AUDIO output (MONITOR

output) terminal is fi xed or variable by linking

with VOLUME.

Selectable

items Description

FAO

(Fixed Audio

Output)

Audio output that does not vary in

strength with the volume level of the

source projector.

VAO

(Variable

Audio

Output)

Audio output that varies in strength

with the volume level of the source

projector.

Info

When “Audio Out” has been set to “VAO”, fi rst

make sure to lower the volume of the

projector before turning the power on or off

and when switching the input.

•

7 Speaker Setting

Selectable

items Description

On The audio signal is output from the

internal speaker.

Off The audio signal is not output from the

internal speaker.

8Audio Input

This function allows you to select an

appropriate combination of audio input

terminals for each input mode.

Selectable

items Description

Audio 1 The AUDIO 1 input terminal is used as

an audio input terminal.

Audio 2 The AUDIO 2 input terminal is used as

an audio input terminal.

9

Selecting the Transmission

Speed (RS-

232C)

Make sure that both the projector and

computer are set for the same baud rate.

Selectable

items Description

9600bps

38400bps

11520 0bps

Transmission speed is slow.

Transmission speed is rapid.

0Fan Mode Setting

This function changes the fan rotation speed.

Selectable

items Description

Normal Suitable for normal environments.

High Select this when using the projector at

altitudes of approximately 1,500 meters

(4,900 feet) or more.

When “Fan Mode” is set to “High”, the fan rotation

speeds up, and the fan noise becomes louder.

System Lock Function

This function prevents unauthorized use of the

projector. Once this function is activated,

users must enter the correct keycode each

time the projector is turned on. We suggest

you record the keycode in a safe place

where only authorized users have access.

Info

If you lose or forget your keycode, contact

your nearest Sharp Authorized Projector

Dealer or Service Center (see page 61). Even

if the product warranty is valid, the keycode

reset will incur a charge.

•

a

Setting/Changing the keycode

1 Select “System Lock”, then press

ENTER or Q.

2

Select “Next”, then press ENTER.

The screen for entering the keycode

appears.

•

1

2

Adjusting the Projector Function (“PRJ - ADJ” Menu)

(Continued)

Menu operation n Page 38

47

Useful

Features

3

Press the 4 buttons on the remote

control or on the projector to enter

the preset keycode in “Old Code”.

When setting the keycode for the fi rst time,

press R on the projector for four times.

Setting the System Lock

PRJ - ADJ

Old Code

New Code

Reconfirm

––––

––––

––––

If you input a wrong keycode, the cursor

returns to the fi rst point of the “Old Code”.

The preset keycode is 4 R buttons on

the projector. When you press the R

button four times, the keycord input

screen disappears.

•

•

Note

4 Press the 4 buttons on the remote

control or on the projector to enter

the new keycode in “New Code”.

You cannot use the following buttons

for keycode: STANDBY/ON, ON,

STANDBY, ENTER, L-CLICK, R-

CLICK/RETURN and MENU/HELP

System lock function recognizes

each button on the remote control

or on the projector as an individual

button, even if they share the same

button name. If you used the buttons

on the projector in setting your

keycode, the keycode cannot be

canceled with the remote control.

•

•

Note

Setting the System Lock

PRJ - ADJ

Old Code

New Code

Reconfirm

****

––––

––––

5Enter the same keycode in “Re-

confi rm”.

•

3

4

5

To cancel the keycode that you have

already set

Press R on the projector for four times in

steps 4 and 5 above.

When the System Lock is set

When System Lock is set, the keycode input

screen appears after the power is turned on.

When it appears, enter the right keycode to

start projection.

Input screen for keycode

System Lock ––––

•

•

Note

12

Checking the Lamp

Life Status

You can confi rm the cumulative lamp usage

time and the remaining lamp life (percentage).

Lamp usage condition Remaining lamp life

“Life” 100% 5%

Operated exclusively with

“Eco +Quiet” set to

“On”

Approx.

3,000

hours

Approx.

150 hours

Operated exclusively with

“Eco +Quiet” set to “Off”

Approx.

2,000

hours

Approx.

100 hours

It is recommended that the lamp be changed

when the remaining lamp life becomes 5%.

The lamp life may vary depending on the

usage condition.

•

•

Note

Menu operation n Page 38

48

Keylock Function

Locking the Operation

Buttons on the Projector

Use this function to lock the operation buttons

on the projector.

Locking the Operation Buttons

Hold down ENTER on the projector for about

5 seconds while the projector is being turned

on.

On-screen display

The keylock function does not affect the

operation with the remote control buttons.

You cannot use the keylock function while the

projector is warming up.

Taking the Keylock off

Hold down ENTER on the projector for about

5 seconds.

On-screen display

When the projector is in standby mode, you can

release the keylock by holding down ENTER

and STANDBY/ON on the projector

simultaneously for about 5 seconds.

Info

Keylock cannot be set while the projector is:

displaying the “Menu” screens, in standby

mode, warming up, changing input signals,

operating “Auto Sync” function, in “FREEZE”

mode or on the “System Lock” screen during

warming up.

•

■

•

•

■

•

Adjusting the Projector Function (“PRJ - ADJ” Menu)

(Continued)

49

Useful

Features

Setting up the Projector Network Environment (“Network” Menu)

Menu operation n Page 38

SEL./ADJ. ENTER END

Pict. SCR PRJ Network Help

Password Disable

DHCP Client Off

TCP/IP

MAC Address

Projector

XX : XX : XX : XX : XX : XX

XX-XXXX

4

2

3

1

1 Setting a Password

If you do not want others to change the setting

for the “Network” menu, set a password.

a

Setting a Password

1 Select “Password”, then press

ENTER or Q.

The screen for entering the password

appears.

Setting the Password

Old Password

New Password

Reconfirm

–

––––

–––

––––

Network

2

Press P or R to set the fi rst digit

in “New Password”, then press Q.

3 Enter the remaining 3 digits, then

press ENTER.

To return to the previous digit, press O.

4 Enter the same password in

“Reconfi rm”, then press ENTER.

The status for “Password” changes to

“Enable”.

Once the password is set, you must enter the

password to change the “Network” menu

settings.

•

Note

a

Changing the Password

1 Select “Password”, then press

ENTER or Q.

The screen for entering the password

appears.

•

•

•

•

1

2

3

4

1

2 Enter the password in “Old

Password” using P,R,Q and O,

then press ENTER.

3 Enter the password in “New

Password” using P,R,Q and O,

then press ENTER.

4 Enter the same password again

in “Reconfi rm” using P,R,Q and

O, then press ENTER.

If you do not need the password protection

for the “Network” menu settings anymore,

press ENTER without entering the new

password in steps 3 and 4.

To cancel the password settings, press

RETURN.

•

•

Note

If you forget the password

If you forget the password, perform the

following procedure to delete it, then set a

new password.

On the projector, press  

.

If ENTER is held down for more than 5

seconds, the operation buttons on the

projector will be locked. (See page 48.)

You cannot use the buttons on the

remote control to delete the password.

•

•

Note

2

3

4

50

2 DHCP Client Setting

Connect the LAN cable before turning the

projector on. If not, the DHCP Client function

does not work.

Selectable items Description

On Obtains confi guration

parameters for TCP/IP network

automatically.

Off Sets the TCP/IP manually.

Select “On” for “DHCP Client”. “Obtaining IP

Address...” appears, then the menu screen

appears. Confi rm the parameters of IP

Address, Subnet Mask and Gateway on the

TCP/IP screen.

If the DHCP server is not available, “Could not

obtain IP Address.” appears.

In this case, set the TCP/IP manually. (See the

item 3.)

3 TCP/IP Setting

Set the TCP/IP manually.

1 Select “Off” for “DHCP Client”,

then press ENTER.

2 Select “TCP/IP”, then press

ENTER.

3 Enter “IP Address” using P,R,Q

and O, then press ENTER.

Setting the TCP/IP

Subnet Mask

IP Address

Gateway

1

55 .2

92 .

000 .

1

55 .2

68 .

000 .

1

55 .2

50 .

000 .

0

000

02

000

Network

4 Enter “Subnet Mask” using P,R,

Q and O, then press ENTER.

5 Enter “Gateway” using P,R,Q

and O, then press ENTER.

1

2

3

4

5

Selectable items Description

IP Address Factory default setting:

192.168.150.002

Enter an IP address

appropriate for the network.

Subnet Mask Factory default setting:

255.255.255.000

Set the subnet mask to the

same as that of the computer

and equipment on the

network.

Gateway Factory default setting:

000. 000. 000. 000

* When not in use, set to “000.

000. 000. 000”.

Confi rm the existing network's segment (IP

address group) to avoid setting an IP address

that duplicates the IP addresses of other

network equipment or computers. If

“192.168.150.002” is not used in a network

with an IP address of “192.168.150.XXX”, you

don't have to change the projector IP address.

For details about each setting, consult your

network administrator.

•

•

Note

4 Confi rming the

Projector Information

You can confi rm the MAC address and

projector name.

Selectable items Description

MAC Address The MAC address of the

projector is displayed.

Projector The projector name is

displayed.

For information on how to change the

projector name, see “SETUP MANUAL”

contained in the supplied CD-ROM.

•

Note

Setting up the Projector Network Environment (“Network” Menu)

(Continued)

Menu operation n Page 38

51

Useful

Features

Utilizing the “Help” Menu

Functions

Example: When image fl ickering appears

Operation to solve image fl ickering when

projecting the computer RGB signal.

1 Press MENU/HELP.

2 Press O or Q to select “Help”,

then press ENTER.

3 Press P or R to select “Vertical

stripes or fl ickering image

appears” on Help menu, then

press ENTER.

If there is no change after performing "Auto Sync"

adjustments, adjust the following items.

Initiate “Auto Sync” Adjustments.

Vertical stripes or flickering image appear

Adjust vertical noise

Adjust horizontal noise

Reset the 2 items above

Return

Signal Info 1024 768

H 48.3 kHz / V 59.9 Hz

SEL. ENTER END

There is no picture or audio

Vertical stripes or flickering image appear

Data image is not centered

Color is faded or poor

Picture is dark

The image is distorted

It is difficult to hear audio

SEL. ENTER END

Vertical stripes or flickering image appear

Pict. SCR PRJ Net. Help

Help

Reset all adjustments to default settings

Press ENTER.

Adjustment buttons

(P/R/O/Q)

ENTER button

MENU/HELP

button

Adjustment buttons

(P/R/O/Q)

ENTER button

MENU/HELP

button

1

2

3

4

Select “Initiate “Auto Sync”

Adjustments”, then press ENTER.

5 If the image is not improved,

select “Adjust horizontal noise”,

then press ENTER.

6 Press O or Q to adjust.

0Phase

SEL./ADJ. Rtn. Menu END

Help

You can adjust the items with check marks (✔).

The items in the “Help” menu change,

depending on the input signal or setting that

you have selected.

If the problem is not solved, refer to

“Troubleshooting” (see pages 59 and 60).

When selecting “sRGB” in “Picture Mode”, the

item “Color is faded or poor” is not displayed.

This means you cannot change input signal

types.

•

•

•

•

Note

4

5

6

Troubleshooting with the “Help” Menu

This function advises you to solve the problems during usage.

52

Maintenance

Cleaning the projector

Ensure that you have unplugged the power

cord before cleaning the projector.

The cabinet as well as the operation panel is

made of plastic. Avoid using benzene or

thinner, as these can damage the fi nish on

the cabinet.

Do not use volatile agents such as

insecticides on the projector.

Do not attach rubber or plastic items to the

projector for long periods.

The effects of some of the agents in the

plastic may cause damage to the quality or

fi nish of the projector.

Wipe off dirt gently with a soft fl annel cloth.

When the dirt is hard to remove, soak a cloth

in a mild detergent diluted with water, wring

the cloth well and then wipe the projector.

Strong cleaning detergents may discolor,

warp or damage the coating on the projector.

Make sure to test on a small, inconspicuous

area on the projector before use.

Mild detergent

Mild detergent diluted

with water

Thinner

Wax

■

■

■

■

■

Cleaning the lens

Use a commercially available blower or lens

cleaning paper (for glasses and camera

lenses) for cleaning the lens. Do not use any

liquid type cleaning agents, as they may

wear off the coating fi lm on the surface of the

lens.

As the surface of the lens can easily get

damaged, be careful not to scrape or hit the

lens.

Cleaning the exhaust and intake vents

Use a vacuum cleaner to clean dust from the

exhaust vent and the intake vent.

Info

If you want to clean the air vents during

projector operation, ensure you press

STANDBY/ON on the projector or

STANDBY on the remote control and put the

projector into standby mode. After the

cooling fan has stopped, clean the vents.

•

■

■

■

53

Appendix

Maintenance Indicators

The warning lights (power indicator, lamp indicator and temperature warning indicator) on the

projector indicate problems inside the projector.

If a problem occurs, either the temperature warning indicator or the lamp indicator will

illuminate red, and the projector will enter standby mode. After the projector has entered

standby mode, follow the procedures given below.

Top View

Lamp indicator

Temperature warning

indicator

Power indicator

About the temperature warning indicator

If the temperature inside the projector increases, due to blockage of the air vents, or the setting

location, the temperature warning indicator will blink. And if the temperature keeps on rising,

“” will illuminate in the lower left corner of the picture with the temperature warning

indicator blinking. If this state continues, the lamp will turn off, the cooling fan will run and then

the projector will enter standby mode. When you fi nd the temperature warning indicator

blinking, be sure to perform the measures described on page 54.

About the lamp indicator

When the remaining lamp life becomes 5% or less, (yellow) and “Change The Lamp” will

be displayed on the screen. When the percentage becomes 0%, it will change to (red), the

lamp will automatically turn off and then the projector will automatically enter standby mode.

At this time, the lamp indicator will illuminate in red.

If you try to turn on the projector a fourth time without replacing the lamp, the

projector will not turn on.

■

■

Indicators on the Projector

Power indicator Red on Normal (Standby)

Green on Normal (Power on)

Red blinks Abnormal (See page 54.)

Green blinks Normal (Cooling)

Green and orange

blink alternately The lens shutter is closed. (See page 29.)

Lamp indicator Green on Normal

Green blinks The lamp is warming up.

Red on The lamp is shut down abnormally or requires to be

changed. (See page 54.)

Temperature

warning indicator Off Normal

Red on/Red blinks The internal temperature is abnormally high. (See page 54.)

■

■

54

Maintenance Indicators (Continued)

Maintenance indicator Problem Cause Possible Solution

Normal Abnormal

Temperature

warning

indicator

Off Red blinks

(On)/

Red on

(Standby)

The internal

temperature is

abnormally high.

Temperatures

around the projector

are high.

Blocked air intake

•

•

Use the projector in an

area with a temperature of

lower than 95°F (+35ºC).

Relocate the projector to

an area with proper

ventilation. (See page 8.)

•

•

Cooling fan

breakdown

Internal circuit failure

Clogged air intake

•

•

•

Take the projector to your

nearest Sharp Authorized

Projector Dealer or Service

Center (see page 61) for

repair.

•

Lamp

indicator

Green on

(Green

blinks

when the

lamp is

warming

up.)

Red on The lamp does

not illuminate.

The lamp is shut

down abnormally.

• Disconnect the power cord

from the AC outlet, and

then connect it again.

•

Time to change

the lamp.

Remaining lamp life

becomes 5% or less.

• Carefully replace the lamp.

(See page 55.)

Take the projector to your

nearest Sharp Authorized

Projector Dealer or Service

Center (see page 61) for

repair.

Please exercise care when

replacing the lamp.

Securely install the cover.

•

•

•

•

Red on

(Standby)

The lamp does

not illuminate.

Burnt-out lamp

Lamp circuit failure

•

•

Power

indicator

Green on/

Red on

Green

blinks

(Cooling)

Red blinks The power

indicator blinks in

red when the

projector is on.

The lamp unit cover

is open.

• If the power indicator blinks

in red even when the lamp

unit cover are securely

installed, contact your

nearest Sharp Authorized

Projector Dealer or Service

Center (see page 61) for

advice.

•

Info

If the temperature warning indicator illuminates, and the projector enters standby mode, follow the

possible solutions above and then wait until the projector has cooled down completely before

plugging in the power cord and turning the power back on. (At least 10 minutes.)

If the power is turned off for a brief moment due to power outage or some other cause while using

the projector, and the power supply recovers immediately after that, the lamp indicator will illuminate

in red and the lamp may not be lit. In this case, unplug the power cord from the AC outlet, replace

the power cord in the AC outlet and then turn the power on again.

The cooling fan keeps the internal temperature of the projector constant and this function is

controlled automatically. The sound of the cooling fan may change during operation because the fan

speed may change and this is not a malfunction.

•

•

•

55

Appendix

Regarding the Lamp

Lamp

It is recommended that the lamp (sold separately) be replaced when the remaining lamp life becomes

5% or less, or when you notice a signifi cant deterioration in the picture and color quality. The lamp life

(percentage) can be checked with the on-screen display. (See page 47.)

Purchase a replacement lamp of type AN-D400LP from your place of purchase, nearest Sharp

Authorized Projector Dealer or Service Center.

IMPORTANT NOTE TO U.S. CUSTOMERS:

The lamp included with this projector is backed by a 90-day parts and labor limited

warranty. All service of this projector under warranty, including lamp replacement,

must be obtained through a Sharp Authorized Projector Dealer or Service Center.

For the name of the nearest Sharp Authorized Projector Dealer or Service Center,

please call toll-free: 1-888-GO-SHARP (1-888-467-4277).

Hg LAMP CONTAINS MERCURY For State Lamp Disposal

Information

www.lamprecycle.org or 1-800-BE-SHARP U.S.A ONLY

Caution Concerning the Lamp

This projector utilizes a pressurized mercury lamp. A loud sound may indicate lamp failure. Lamp failure

can be attributed to numerous sources such as: excessive shock, improper cooling, surface scratches

or deterioration of the lamp due to a lapse of usage time.

The period of time up to failure largely varies depending on the individual lamp and/or the condition and

the frequency of use. It is important to note that failure can often result in the bulb cracking.

When the lamp replacement indicator and on-screen display icon are illuminated, it is recommended

that the lamp be replaced with a new one immediately, even if the lamp appears to be operating

normally.

Should the lamp break, there is also a possibility that glass particles may spread inside of the projector.

In such a case, it is recommended you contact your nearest Sharp Authorized Projector Dealer or

Service Center to assure safe operation.

Should the lamp break, the glass particles may spread inside the lamp cage or gas contained in the

lamp may be vented into the room from the exhaust vent. Because the gas in this lamp includes

mercury, ventilate the room well if the lamp breaks and avoid all exposure to the released gas. In case of

exposure to the gas, consult a doctor as soon as possible.

Replacing the Lamp

Caution

Do not remove the lamp unit from the projector right after use. The lamp will be very hot and may cause

burns or injury.

Wait at least one hour after the power cord is disconnected to allow the surface of the lamp unit to fully

cool before removing the lamp unit.

Carefully change the lamp by following the instructions described in this section. * If you

wish, you may have the lamp replaced at your nearest Sharp Authorized Projector Dealer or

Service Center.

* If the new lamp does not light after replacement, take your projector to the nearest Sharp Authorized Projector

Dealer or Service Center for repair.

■

■

■

■

■

■

•

•

■

56

Regarding the Lamp (Continued)

Removing and Installing the

Lamp Unit

Warning!

Do not remove the lamp unit from the

projector right after use. The lamp and parts

around the lamp will be very hot and may

cause burns or injury.

•

Info

Do not touch the glass surface of the lamp

unit or the inside of the projector.

To avoid injury to yourself and damage to the

lamp, make sure you carefully follow the

steps below.

Do not loosen other screws except for the

lamp unit cover and lamp unit.

•

•

•

1 Press STANDBY/ON on the

projector or STANDBY on the

remote control to put the

projector into standby mode.

2 Disconnect the power cord.

Unplug the power cord from the AC

socket.

Leave the lamp until it has fully cooled

down (about 1 hour).

3 Remove the lamp unit cover.

Close the lens shutter. Loosen the user

service screw (1) that secures the lamp

unit cover. Remove the lamp unit cover

(2).

•

•

•

Lamp unit

AN-D400LP

Optional

accessory

Lamp unit

AN-D400LP

Optional

accessory

1

STANDBY/ON button

AC socket

STANDBY/ON button

AC socket

2

3

User service screw

(for lamp unit cover)

1

2

User service screw

(for lamp unit cover)

1

2

57

Appendix

4 Remove the lamp unit.

Loosen the securing screws from the lamp

unit. Hold the lamp unit and pull it in the

direction of the arrow. At this time, keep

the lamp unit horizontal and do not tilt it.

5 Insert the new lamp unit.

Press the lamp unit fi rmly into the lamp unit

compartment. Fasten the securing screws.

6 Replace the lamp unit cover.

Align the tab on the lamp unit cover

(1) and place it while pressing the cover

(2) to close it. Then tighten the user

service screw (3) to secure the lamp unit

cover.

Info

If the lamp unit and lamp unit cover

are not correctly installed, the power

will not turn on, even if the power

cord is connected to the projector.

•

Resetting the Lamp Timer

Reset the lamp timer after replacing the lamp.

Info

Make sure to reset the lamp timer only when

replacing the lamp. If you reset the lamp timer

and continue to use the same lamp, this may

cause the lamp to become damaged or

explode.

•

1 Connect the power cord and

open the lens shutter fully.

Plug the power cord into the AC socket of

the projector.

2 Reset the lamp timer.

While simultaneously holding down

MENU/HELP, ENTER and R on the

projector, press STANDBY/ON on the

projector.

“LAMP 0000H” is displayed, indicating

that the lamp timer is reset.

•

•

•

•

•

•

4

Securing screwsSecuring screws

5

6

AC socketAC socket

1

ENTER button

MENU/HELP

button

R button

STANDBY/ON

button

ENTER button

MENU/HELP

button

R button

STANDBY/ON

button

2

58

Computer Compatibility Chart

Computer

• Multiple signal support

Horizontal Frequency: 15-110 kHz,

Vertical Frequency: 45-85 Hz,

Pixel Clock: 12-170 MHz

Sync signal: Compatible with TTL level

• Compatible with sync on green signal

PC/MAC Mode Resolution Horizontal frequency

[kHz]

Vertical

frequency[Hz]

Analog

Support

Digital

Support Display

PC

VGA

640 × 400

27.0 60 ✔

Upscale

31.5 70 ✔

37.9 85 ✔

720 × 400

27.0 60 ✔

31.5 70 ✔✔

37.9 85 ✔

640 × 480

26.2 50 ✔

31.5 60 ✔✔

34.7 70 ✔

37.9 72 ✔✔

37.5 75 ✔✔

43.3 85 ✔

SVGA 800 × 600

31.3 50 ✔

35.2 56 ✔✔

37.9 60 ✔✔

46.6 70 ✔

48.1 72 ✔✔

46.9 75 ✔✔

53.7 85 ✔

XGA 1024 × 768

40.3 50 ✔

TRUE

48.4 60 ✔✔

56.5 70 ✔✔

60.0 75 ✔✔

68.7 85 ✔

WXGA

1280 × 720 45.0 60 ✔✔

Intelligent

Compression

1280 × 768 47.8 60 ✔ ✔

*

1280 × 800 49.7 60 ✔ ✔

*

62.8 75 ✔

1360 × 768 47.7 60 ✔ ✔

*

1366 × 768 47.8 60 ✔ ✔

*

WXGA+ 1440 × 900 55.9 60 ✔

SXGA

1152 × 864

55.0 60 ✔✔

66.2 70 ✔

67.5 75 ✔✔

1280 × 960 60.0 60 ✔✔

75.0 75 ✔

1280 × 1024 64.0 60 ✔✔

80.0 75 ✔✔

SXGA+ 1400 × 1050 64.0 60 ✔✔

65.3 60 ✔✔

WSXGA+ 1680 × 1050 65.3 60 ✔

UXGA 1600 × 1200 75.0 60 ✔

MAC 13” VGA 640 × 480 34.9 67 ✔Upscale

MAC 16” SVGA 832 × 624 49.7 75 ✔

MAC 19” XGA 1024 × 768 60.2 75 ✔TRUE

MAC 21” SXGA 1152 × 870 68.7 75 ✔Intelligent

Compression

*Switch to Plug-and-Play data. (See page 37.)

Optimum image quality will be achieved by matching your computer's output resolution to the

resolution that corresponds to “TRUE” in the “Display” column shown above.

When “Screen resolution” of the computer is different from the resolution displayed on the projected

image, follow the procedures shown below.

– Refer to “Select the resolution” for “Data image is not centered” on the Help menu and select the

same resolution as the resolution in “Screen resolution” of the computer.

–

Depending on the computer you are using, the output signal may not be faithful to the “Screen resolution”

adjustment. Check the settings of the computer's signal output. If the settings cannot be changed, it is

recommended that the resolution be set to the one that corresponds to “TRUE” in the “Display” column.

•

•

Note

DTV

Signal Horizontal

Frequency (kHz)

Vertical

Frequency (Hz)

Analog

Support

Digital

Support Signal Horizontal

Frequency (kHz)

Vertical

Frequency (Hz)

Analog

Support

Digital

Support

480I15.7 60 ✔720P 45.0 60 ✔✔

480P 31.5 60 ✔✔

1035I33.8 60 ✔

540P 33.8 60 ✔1080I28.1 50 ✔✔

576I15.6 50 ✔1080I33.8 60 ✔✔

576P 31.3 50 ✔✔

1080P 56.3 50 ✔✔

720P 37.5 50 ✔✔

1080P 67.5 60 ✔✔

59

Appendix

Troubleshooting

Problem Check Page

No picture and no sound

or projector does not

start.

Projector power cord is not plugged into the wall outlet.• 25

Power to the external connected devices is off.• –

The lens shutter is closed.•26, 29

The selected input mode is wrong.•29

Cables are incorrectly connected to the projector.• 21–25

Remote control battery has run out.•15

External output has not been set when connecting notebook computer.

•21

The lamp unit cover is not installed correctly.• 56, 57

If the connected DVI digital equipment is turned on before the “DVI-D”

input mode is selected on the projector, the image may not be projected

properly or may not be displayed at all. Ensure that the appropriate input

mode has been selected on the projector before you turn on the

connected equipment.

•21

Sound is heard but no

picture appears

(or picture is dark).

Cables are incorrectly connected to the projector.• 21–25

“Bright” is set to minimum position.• 41

Depending on the computer you are using, an image may not be

projected unless the signal output setting of the computer is switched

to the external output. Refer to the computer's operation manual for

how to switch its signal output settings.

• –

Color is faded or poor.

Image adjustments are incorrectly set.

Make adjustments of “Color” and “Tint” in “Picture Mode” and lower the

“BrilliantColorTM” value.

•

•41

(Video Input only)

Video input system is incorrectly set.•51

Picture is blurred;

noise appears.

Adjust the focus.• 27

The projection distance exceeds the focus range.•20

There is fog on the lens. If the projector is carried from a cold room into a

warm room, or if it is suddenly heated, condensation may form on the surface

of the lens and the image will become blurred. Set up the projector at least

one hour before it is to be used. If condensation should form, remove the

power cord from the wall outlet and wait for it to clear.

• –

(Computer Input only)

Perform Synchronization Adjustments (“Clock” and “Phase”

Adjustment)

Noise may appear depending on the computer.

•

•

51

–

Picture appears but no

sound is heard.

Cables are incorrectly connected to the projector.• 21–25

Volume is set to minimum.

When the projector is connected to an external device and the volume

is set to minimum, the sound is not output even if you turn up the

volume of the external device.

•

•29

“Speaker” is set to “Off”.•46

Data image is not

centered.

Select “Data image is not centered” in the “Help” menu and make the

necessary adjustments.

•51

Depending on the computer you are using, the output resolution signal

may be different from the one you have set. For details, refer to the

operation manual of the computer.

• –

60

Problem Check Page

An unusual sound is

occasionally heard from

the cabinet.

If the picture is normal, the sound is due to cabinet shrinkage caused

by room temperature changes. This will not affect operation or

performance.

• –

Maintenance indicator on

the projector illuminates

or blinks in red.

See “Maintenance Indicators”.• 53

The projector cannot

be turned on or put into

the standby mode

using STANDBY/ON on

the projector.

The keylock is set.

If the keylock is set to “ON”, all the buttons are locked.

•

•48

Picture is green on

COMPUTER

(Component)/

DVI (Component).

Change the input signal type setting.

When you cannot select an input signal type, select “Color is faded or

poor” in the “Help” menu, after selecting an item other than “sRGB” in

“Picture Mode”, and then select an input signal type.

•

•51

40, 51

Picture is pink

(no green) on

COMPUTER (RGB)/

DVI (RGB).

Picture is too bright and

whitish.

Image adjustments are incorrectly set.•41

The cooling fan becomes

noisy.

When temperature inside the projector increases, the cooling fan runs

faster.

•

8, 9

52, 53, 5

4

The lamp does not light

up even after the

projector turns on.

The lamp indicator is illuminating in red.

Replace the lamp.

The lens shutter is closed.

•

•

53, 56, 57

The lamp suddenly turns

off during projection.

The image sometimes

fl i c k e r s .

Cables are incorrectly connected to the projector or the connected

equipment works improperly.

Select “Vertical stripes or fl ickering image appear” in the “Help” menu

and make the necessary adjustments.

If this happens frequently, replace the lamp.

•

•

•

21–25

51

56

The lamp needs much

time to turn on.

The lamp will eventually need to be changed.

While the remaining lamp life draws to a close, replace the lamp.

•56

Picture is dark.

The remote control

cannot be used.

Operate the remote control while pointing it at the projector's remote

control sensor.

The remote control may be too far away from the projector.

If direct sunlight or a strong fl uorescent lamp is shining on the

projector's remote control sensor, place the projector where it will not

be affected by strong light.

•

•

•15

The batteries may be depleted or inserted incorrectly. Make sure the

batteries are inserted correctly or insert new ones.

•15

This unit is equipped with a microprocessor. Its performance could be adversely affected by incorrect

operation or interference. If this should happen, unplug the Unit and plug it in again after more than 5

minutes.

Troubleshooting (Continued)

61

Appendix

U.S.A. Sharp Electronics Corporation

1-888-GO-SHARP (1-888-467-4277)

lcdsupport@sharpsec.com

http://www.sharpusa.com

Canada Sharp Electronics of Canada Ltd.

(905) 568-7140

http://www.sharp.ca

Mexico Sharp Electronics Corporation

Mexico Branch

(525) 716-9000

http://www.sharp.com.mx

Latin America Sharp Electronics Corp. Latin

American Group

(305) 264-2277

www.servicio@sharpsec.com

http://www.siempresharp.com

Germany Sharp Electronics (Europe) GMBH

01805-234675

http://www.sharp.de

U.K. Sharp Electronics (U.K.) Ltd.

08705 274277

http://www.sharp.co.uk/customersupport

Italy Sharp Electronics (Italy) S.P.A.

(39) 02-89595-1

http://www.sharp.it

France Sharp Electronics France

01 49 90 35 40

hotlineced@sef.sharp-eu.com

http://www.sharp.fr

Spain Sharp Electronica Espana, S.A.

93 5819700

sharplcd@sees.sharp-eu.com

http://www.sharp.es

Switzerland Sharp Electronics (Schweiz) AG

0041 1 846 63 11

cattaneo@sez.sharp-eu.com

http://www.sharp.ch

Sweden Sharp Electronics ( Nordic ) AB

(46) 8 6343600

vision.support@sen.sharp-eu.com

http://www.sharp.se

Austria Sharp Electronics (Europe) GMBH

Branch Offi ce Austria

0043 1 727 19 123

pogats@sea.sharp-eu.com

http://www.sharp.at

Benelux SHARP Electronics Benelux BV

0900-SHARPCE (0900-7427723)

Nederland

9900-0159 Belgium

http://www.sharp.nl

http://www.sharp.be

http://www.sharp.lu

Australia Sharp Corporation of Australia Pty.

Ltd.

1300-135-022

http://www.sharp.net.au

New Zealand Sharp Corporation of New Zealand

Phone: (09) 573-0111

Fax: (09) 573-0112

http://www.sharp.net.nz

Singapore Sharp-Roxy Sales (S) Pte. Ltd.

65-226-6556

ckng@srs.global.sharp.co.jp

http://www.sharp.com.sg

Hong Kong Sharp-Roxy (HK) Ltd.

(852) 2410-2623

dcmktg@srh.global.sharp.co.jp

http://www.sharp.com.hk

Taiwan Sharp Corporation (Taiwan)

0800-025111

http://www.sharp-scot.com.tw

Malaysia Sharp-Roxy Sales & Service Co.

(60) 3-5125678

U.A.E. Sharp Middle East Fze

971-4-81-5311

helpdesk@smef.global.sharp.co.jp

Thailand Sharp Thebnakorn Co. Ltd.

02-236-0170

svc@stcl.global.sharp.co.jp

http://www.sharp-th.com

Korea Sharp Electronics Incorporated of

Korea

(82) 2-3660-2002

lcd@sharp-korea.co.kr

http://www.sharpkorea.co.kr

India Sharp Business Systems (India)

Limited

(91) 11- 6431313

service@sharp-oa.com

For SHARP Assistance

If you encounter any problems during setup or operation of this projector, fi rst

refer to the “Troubleshooting” section on pages 59 and 60. If this operation

manual does not answer your question, please contact the SHARP Service

departments listed below.

62

Specifi cations

Model PG-D4010X

Display devices 0.7" DLP® Chip

Resolution XGA (1024 × 768)

Lens F number F 2.5 – 2.7

Zoom Manual, ×1.15 (f = 21.0 – 24.2 mm)

Focus Manual

Input terminals DVI-I (Compatible with HDCP) ×1

Computer/Component

(mini D-sub 15 pin)

×1

S-Video (mini DIN 4 pin) ×1

Video (RCA) ×1

Audio (ø3.5 mm stereo minijack) ×1

Audio (RCA) ×1 (L/R)

Output

terminals

Computer/Component

(mini D-sub 15 pin)

×1

Audio (ø3.5 mm stereo minijack) ×1 (variable audio output)

Control and

communication

terminals

LAN (RJ-45) ×1

USB (Type B) ×1

RS-232C (mini D-sub 9 pin) ×1

Speakers 5W × 2 (Stereo)

Projection lamp 330 W

Rated voltage AC 100 – 240 V

Rated frequency 50/60 Hz

Input current 4.5 A

Power consumption (Standby*) 429 W (10.2 W) with AC 100 V

408 W (10.8 W) with AC 240 V

Operation temperature 41ºF to 95ºF (+5ºC to +35ºC)

Cabinet Plastic

Dimensions (main body only) [W × H × D] 15 3/4" × 3 15/16" × 13 13/64"

(400 × 100 × 335 mm)

Weight (approx.) 12.8 lbs. (5.8 kg)

*STANDBY Mode: Standard

As a part of policy of continuous improvement, SHARP reserves the right to make design and

specifi cation changes for product improvement without prior notice. The performance specifi cation

fi gures indicated are nominal values of production units. There may be some deviations from these

values in individual units.

63

Appendix

Dimensions

Units: inches (mm)

M4 M4

M4 M4

1/4 (6)13 13/64 (335)3 15/16 (100)

143/64

(42.2)

417/32 (115)

323/64

(85)

417/32

(115)

15 3/4(400)

1/8(3)

11/2

(38)

333/64

(89)

649/64 (171.5)

15/64 (5.75) 113/16

(45.75)

45/8

(116.25)

261/64

(75)

75/64

(179.75)

64

Accessories ······························································· 11

AC socket ··································································25

Adjustment buttons ··················································· 38

Adjustment foot ·························································27

AREA ZOOM ·····························································31

Aspect ratio ·······························································30

Audio Input ································································ 46

Audio Out ··································································46

AUDIO 1, 2 terminal ··················································· 23

AUDIO OUT terminal ·················································23

Auto Power Off ··························································45

Auto Restart ······························································45

Auto Sync (Auto Sync adjustment) ········· 33, 37, 45, 51

AUTO SYNC button···················································33

AV MUTE button ························································ 29

Background ······························································· 44

Batteries ····································································15

Blue ···········································································41

BORDER ······························································30, 31

BREAK TIMER button ···············································32

Bright ········································································· 41

BrilliantColorTM ··························································41

Carrying handle ·························································13

Closed Caption ·························································· 44

CLR Temp (Color Temperature) ································· 41

C.M.S. ·······································································41

Color ·········································································· 41

COMPUTER button ··················································· 29

COMPUTER/COMPONENT input terminal ········21, 22

Contrast ·····································································41

DHCP Client ······························································ 50

DNR ··········································································· 42

DOT BY DOT ····························································· 30

DVI button ·································································29

DVI-I input terminal ··············································21, 22

Eco+Quiet···························································· 32, 42

ECO+QUIET button ···················································32

ENTER button ···························································· 38

Exhaust vent ························································ 12, 52

Fan Mode ··································································46

Focus ring ··································································27

FREEZE button ·························································· 33

FULL ·········································································· 30

HEIGHT ADJUST lever ··············································27

Help ···········································································51

H-Pos ··································································37, 51

Image shift ·································································43

INPUT modes ···························································· 29

Intake vent ···························································12, 52

Kensington Security Standard connector ················· 13

Keycode ···································································46

Keylock ····································································· 48

KEYSTONE button ··················································· 28

Keystone Correction ············································ 28, 43

Lamp ·········································································55

Lamp indicator ··························································53

Lamp Timer (Life) ·······················································47

Lamp unit ··································································56

Language (on-screen display language) ···················44

LAN terminal ······························································ 25

L-CLICK/EFFECT button ····································· 32, 34

Lens shutter ························································· 26, 29

MAC Address ····························································50

MAGNIFY buttons ·····················································33

MENU/HELP button ············································ 38, 51

MONITOR OUT terminal ············································23

MOUSE/Adjustment buttons ······························· 34, 38

Network ····································································· 49

NORMAL ·····························································30, 31

ON button ·································································· 26

Optional accessories ·················································11

OSD Display ·····························································44

Overscan ···································································43

PAGE DOWN button ··················································34

PAGE UP button ························································ 34

Password ··································································· 49

PDF············································································ 10

Picture Adjustment ···················································40

Picture Mode ······················································· 33, 40

PICTURE MODE button ············································33

POINTER button ························································ 32

Power cord ································································ 25

Power indicator ·························································53

PRJ - ADJ ·································································· 45

PRJ Mode ···························································· 19, 44

Progressive ································································ 42

R-CLICK/RETURN button ··································· 34, 38

Red ············································································ 41
