Item No. 206061
TRUE NIGHT VISION BINOCULARS
User Manual
Thank you for purchasing the Sharper Image True Night Vision Binoculars.
Please read this guide carefully and keep it for future reference.
- 1 -
PACKAGE CONTENTS
ABOUT THE BINOCULAR
1 23
1. POWER: Long press for power on
and off.
2. IR: Press IR for 3 levels of
brightness (0->1->2->3) when
using the binoculars at night.
3. ZOOM: Press Zoom to zoom in at
multiple levels. The maximum
zoom is 2X. Once reaching 2X,
keep pressing Zoom to go
back to 1X.
- 2 -
QUICK START
Install batteries
1. Open the covers.
2. Put in 4 AA Alkaline batteries
in each compartment in the
directions of + and –.
3. Close the battery compartments.
Turn on the Binocular:
1. For day use, first cover the
lens with the lid. For night use,
take off the lid.
(Note: Uncovering the lid during
the day time will NOT damage
the lens, but it will affect
the image quality.)
2. Long press the Power button
to turn on the binocular. Once
the power is on, look into the
LCD screen inside for preview.
3. Adjust the focus by turning
the focus wheel at the front
bottom. See below arrow for
“focus wheel”.
4. For night use, turn on the IR by
pressing the IR button.
Increase the brightness by
pressing the button repeatedly.
It has 3 levels of brightness
(0->1->2->3)
5. Long press the Power button to
shut down the binocular.
ABOUT THE BINOCULAR (CONT.)
4. PROTECTION LID: Long press for
power on and off.
5. VIEW AREA
6. STRAP HOOK
7. FOCUS WHEEL
8. BATTERY COMPARTMENT
9. TRIPOD HOLDER
5
6
7
9
88
4
- 3 -
QUICK START (CONT.)
TROUBLE SHOOTING
SPECIFICATIONS
DISPLAY INFORMATION
Use Digital Zoom
Press Zoom to zoom in at multiple levels up to 2X. Once reaching 2X, keep pressing to go back to 1X.
Binocular Power Off
If the binocular fails to activate, check
for defective, missing or improperly-
installed batteries. Replace or install
batteries correctly. Please make sure
to use Alkaline batteries.
Poor Image
• If you wear glasses, please keep them on while using the binocular.
• If at day, make sure the protection lid is on. If at night, make sure the protection lid is off.
• Adjust the focus by slowing turning the Focus Wheel at the front bottom of the binocular.
Make sure it is focused.
Viewfinder EVF mode
Aspect ratio 4:3
Aperture F1.4 with adjustable aperture Day and Night dual mode
Operation Preview
Visual distance 60M (66 yards) at Night, 400M (440 yards) at Day
Zoom Up to 2X
Object lens Focus Manually adjust
Visual angle 10° degrees
- 4 -
WARRANTY / CUSTOMER SERVICE
Sharper Image branded items purchased from SharperImage.com include a 1-year limited
replacement warranty. If you require any assistance with your True Night Vision Binoculars,
please call 1 (877) 210-3449.
The SHARPER IMAGE® name and logo are registered trademarks.
©Sharper Image. All Rights Reserved.
Luminance IR LED / total 1W
Power Supply Alkaline AA battery x 8
Power consumption 1.5W with IR LED fully on
Size 18.5cm X 14.5cm X 5.5cm (approx..)/7.28” X 5.70” X 2.16” (ap-
prox..)
Net Weight 603g (approx.)/ 1.33lbs (approx.)
Color Black
SPECIFICATIONS (CONT.)
