Shen Zhen MTC LG8864 Wifi Module User Manual

User Manual

TWFP-M601D is a high-gain and low power consumption wifi mudule . You can use

it on IEEE802.11a/b/g/n/ac wireless Local Area Networks and USB 2.0 Wi-Fi Dongle.It

fully complies with IEEE 802.11a/b/g/n and IEEE 802.11ac feature rich wireless

connectivity at high standards,delivers reliable,cost-effective,throughput from an

extended distance.

◆ Complies with IEEE 802.11g; 802.11b; 802.11n standard for 2.4GHz Wireless

LAN. 802.11a/n/ac standard for 5GHz Wireless LAN.

◆ Supports Ad-Hoc/Infrastructure modes

(This device supports Ad-Hoc mode, however Ad-Hoc is only possible in the

channels 2.412-2.462GHz and 2.422-2.452GHz and 5.15G-5.25G and

5.725-5.850G GHz as this is fixed in the firmware of the module,

it can not operate outside the certified channels as indicated

in this FCC certification filing.)

◆ Works with all existing network infrastructure.

◆ Supports Wi-Fi Protected Setup (WPS) configuration function

◆ Capable of up to 128-Bit WEP Encryption.

◆ Freedom to roam while staying connected.

◆ 22-Mbps Packet Binary Convolution Coding (PBCC)

(according to the IEEE Std 802.11b high-rate specification ).

◆ UP to 78 Mbps High-Speed Transfer Rate in 802.11ac mode of operation.

◆ Supports Windows 2000, XP32/64,Vista32/64,Linux

◆ Low power consumption.

◆ Easy to install and configure.

Product Features

Product Description

Ｈｉｇｈ　ｐｏｗｅｒ　ｒａｄａｒｓ　ａｒｅ　ａｌｌｏｃａｔｅｄ　ａｓ　ｐｒｉｍａｒｙ　ｕｓｅｒｓ　ｏｆ　ｔｈｅ　

２．４１２－２．４６２ＧＨｚ，　ａｎｄ　２．４２２－２．４５２ＧＨｚ，　５．１５－５．２５　

ＧＨｚ　ａｎｄ　５．７２５－５．８５０Ｇ　ＧＨｚ　ｂａｎｄｓ．　Ｔｈｅｓｅ　ｒａｄａｒ　ｓｔａｔｉｏｎｓ　ｃａｎ　ｃａｕｓｅ　

The HDMI port for debugging only.

Operating temperature:0 - 40 deg C

◆
