Shen Zhen RDM Tag Master RDM880 RFID MODULE User Manual
Shen Zhen RDM Tag Master Co., Ltd. RFID MODULE
USERS MANUAL
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
RDM880 SERIAL MODULE:
OEM & ODM ISO14443A/B, ISO15693, ISO11784/11785 MODULE
DEVELOPMENT KIT
1 RS232 or SPI OPERATIONS
The OEM & ODM ISO14443-A-B, ISO15693, ISO11784 /11785 MODULE can operate with a
terminal such as computer or other controller, which can supply RS232 or SPI interface.
1.1 Electrical Interface
Basically, this communication protocol does not need to be bound with any electrical interface
characteristic. Typically the following types of physical link could be used:
• RS232 (Point to point only)
• CMOS-Logic Level (Point to point only)
• SPI (Slave only)
1.2 Data Format
The data format (Start Bit, Data Bits, parity, Stop Bit) is software configurable, and can be set to
match the special requirement of data transmission between two communication devices. The
general data format is defined as:
Parameter Description
Baud Rate Selective: 9600, 19200, 38400, 57600, 1152000
(It can be changed by command Send from the Host)
Data Bits Fixed: 8 bits
Start Bit Fixed: 1 Bits
Stop Bit Selective: 1 bit.
Parity None
The following is the default setting (RS232):
Baud Rate Data Bits Start Bit Stop Bit Parity
9600 8 1 1 None
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
2 Link Layer
The communication protocol is a packet-oriented protocol - all the data exchanged between two
communication devices will be based on packet format. The protocol is designed for multi-drop
mode and where point-to-point mode could be treated as a special case of multi-drop mode.
The data packet starts with the control character ‘STX’ and ends with ‘ETX’, which follows the 8-bit
BCC checksum. Besides the checksum is used for error checking, character (byte) time-out and
packet (command) time-out are used to re-synchronous the communication.
2.1 Packet Format
There are two types of data packets. Command Message is the packet Send from the Host to the
reader device. The Reply Message is the packet Send from the reader to the Host.
Packet format for Command Message (Host to Reader)
STX STATION ID DATA LENGTH CMD DATA[0..N] BCC ETX
Packet format for Reply Message (Reader to Host)
STX STATION ID DATA LENGTH STATUS DATA[0..N] BCC ETX
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
3 Available Commands
Name Description
SYSTEM COMMANDS
SetAddress Program the Device Address to the reader
SetBaudrate Set the reader’s communication baud rate
SetSerlNum Set the reader’s Serial Number
GetSerNum Get the reader’s Serial Number
SetUserInfo Set the Usr Information
GetUserInfo Get the User Information
GetVerNum Get the reader’s firmware version number.
SetPort Control status of the I/O ports.
SetLED Turn On/Off the LEDs
SetBuzzer Turn On/Off the Buzzer
Control-workmode Control the reader to stay in active state or idle state
ISO14443-A-B COMMANDS
REQA ISO14443A REQUEST
Anticoll ISO14443A Anti-collision
Select ISO14443A Select
Halt ISO14443A Halt
Request_B ISO14443B REQB command
Attrib_B ISO14443B ATTRIB command
RDM_Rst_ Typeb Integrate the request and attrib command
RDM__Typeb_Trans
fer_Command ISO14443-4 transparent command Type B Card
MF_Read The Read command integrates the low level commands (request, anti-
collision, select, authentication, read) to achieve the reading operation
with a one-step single command.
MF_Write The Write command integrates the low level commands (request, anti-
collision, select, authentication, write) to achieve the writing operation
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
with a one-step single command.
MF_InitVal The Initialization command integrates the low level commands (request,
anti-collision, select, authentication) to achieve the value block
initialization with a one-step single command.
MF_Decrement The Decrement command integrates the low level commands (request,
anti-collision, select, authentication) to achieve the Decrement with a
one-step single command.
MF_HLIncrement The Increment command integrates the low level commands (request,
anti-collision, select, authentication) to achieve the Increment with a
one-step single command.
MF_GetSnr The GetSnr command integrates the low level commands
(request,anticoll,select) to achieve the select card with a one-step single
command,and output the card’s Snr
ISO15693 COMMANDS
RDM_Inventory ISO15693 Inventory Command
RDM_Read ISO15693 Read Command
RDM_Write ISO15693 Write Command
RDM_Lockblock ISO15693 Lock_Block Command
RDM_StayQuiet ISO15693 Stay_Quiet Command
RDM_Select ISO15693_Select Command
RDM_Resetready ISO15693_Reset_To_Ready Command
RDM_Write_Afi ISO15693_Write_AFI Command
RDM_Lock_Afi ISO15693_Lock_AFI Command
RDM_Write_Dsfid ISO15693_Write_DSFID Command
RDM_Lock_Dsfid ISO15693_Lock_DSFID Command
RDM_Get_Information ISO15693_Get_System_Information Command
RDM_Get_Multiple_Block_Security ISO15693_Get_Multiple_Block_Security Command
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
RDM_15693_Transfer_Command Using this command may transparent ISO15693
command to The Card that it meet the ISO15693 protocol
CAUTION: Changes or Modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
3.1 Sequence Example
3.1.1 SetBaudrate ( 0x81 )
Data Field
DATA[0] Communication speed
0x00 – 9600 bps
0x01 – 19200 bps
0x02 – 38400 bps
0x03 – 57600 bps
0x04 – 115200 bps
Response:
STATUS: 0x00 - OK
Data Field
DATA[0] Return the new communication speed Code.
0x00 – 9600 bps
0x01 – 19200 bps
0x02 – 38400 bps
0x03 – 57600 bps
0x04 – 115200 bps
Description
Set the reader’s baud rate for host communication. The baud rate will be stored in the reader’s
EEPROM and used as the new default baud rate.The new baud rate will not take effect until the
reader is reset.
EXAMPLE:
Send Data： AA 02 02 81 01 80 BB
Response Data：： AA 02 02 00 01 01 BB (19200,N,8,1)
3.1.2 CMD_MF_Request (0x25)
Data Field
DATA[0]: Request mode
0x00 – Request Idle
0x01 – Request All
DATA[1]: 00 don’t need to execute the halt command
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
01 need to execute the halt command
Response:
Data Field
STATUS: 0x00 – OK
DATA[0-3]: Card Serial Number
Description:
The High Level Value Increment Command integrates the low level commands (Request, AntiColl1,
Select) and get the SNR of selected card.
EXAMPLE:
Send Data： aa 02 03 25 26 00 02 bb
Response Data：AA 02 06 00 00 16 0F F4 7F 96 BB
3.2 ISO15693 Commands Example
3.2.1 RDM_Inventory (0x10)
Data Field
DATA[0]: Flags
Bit0: Sub_carrier_flag
Bit1: Date_rate_flag
Bit2: Inventory_flag
Bit3: Protocol Extension_flag
Bit4: Afi_flag
Bit5: nb_slots_flag
Bit6: Option_flag
Bit7: RFU
DATA[1]: Afi
DATA[2]: Masklengh
DATA[3..10]: Maskvalue
Response:
STATUS: 0x00 - OK
Data[0] : The card’s number that exist in the reading area
Data[1..n] : UID
Description:
Run the anticollison loop. through this command you can get the UID of all the VICC in the readable
zone.(usually it may get 3 to 6 card’s snr,it base on the strength of the RF power)
Example:
Send Data： aa 00 04 10 06 00 00 12 bb
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
When only one card in the reading area： AA 00 0B 00 01 00 01 4A 80 E9 11 00 00 07 3E BB
Two card in the reading area： AA 00 15 00 02 00 01 4A 80 E9 11 00 00 07 E0 00 00
3B 80 E9 11 00 00 07 87 BB
Three card in the reading area： AA 00 1F 00 03 00 01 4A 80 E9 11 00 00 07 E0 00 00
3B 80 E9 11 00 00 07 E0 00 00 3F 80 E9 11 00 00 07 2C BB
Four card： AA 00 29 00 04 00 01 4A 80 E9 11 00 00 07 E0 00 00
3B 80 E9 11 00 00 07 E0 00 00 3E 80 E9 11 00 00 07 E0 00 00 3F 80 E9 11 00 00 07 BC BB
Have no card in the reading area： AA 00 02 01 83 80 BB
RDM TAG MASTER CO.,LTD
中国 ·深圳市南山区高新区科技南十二路方大大厦 201 室 TEL： +86-755- 61313350
Fangda Building201,Keji 12th Rood south, High-Tech Industrial Park, Nanshan Shenzhen, China
Http://www.datarfid.com E-mail：support@datarfid.com FAX：+86-755- 61313357
4 RDM880 Type Description
RDM880 X---- X
Contactless Interface option
A: ISO14443-TYPEA
B: ISO14443-TYPEA+B
C: ISO15693
D: ISO14443-TYPEA+TYPEB
E: ISO14443-TYPEA+TYPEB+IS015693
F: ISO11784/ISO11785
Communication Interface Option
T = TTL
S = RS232
P = SPI
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
Information in this document is subject to change without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without
the express written permission of RDM Tag Master Co.,Ltd.
