ShenZhen Bang Ao Technology BD-9588 2.4G Wireless Mouse User Manual

ShenZhen Bang Ao Technology Co., Ltd. 2.4G Wireless Mouse

User manual

REV：A0 BD-9588 USER MANUAL Page 1 /5
Model： BD-9588
Specification： 2.4G Wireless Mouse
Describe： 3D Optical Mouse
Approved ：Checked：Made：
USE MANUAL
FCC ID：2ASKMBD-9588
REV：A0 BD-9588 USER MANUAL Page 2 /5
Product Appearance and key function definition
Product Features
1、Adopt 2.4G bidirectional transmit technology，34 channels，super anti-interference;
2、Adopt high resolution, accurate position;
3、Super ability for replacement, use up freewheeling;
4、Strong dormancy power-saving design and can achieve economize electricity at level 3 .When it under deep
sleep mode the electric current will less than 100uA;
LED light will out of work and that access super save electricity mode within 10 min ,when it no use ,and it
can fall into deep sleep mode automatic;
(now the mouse almost no longer power consumption, press any key immediate wake up. )
5、Ensure you of working 360 degrees freely and say goodbye to wire;
6、No need code intelligence connection technology;
7、Ergonomic design for appearance，close to palm，use freely and can not tire.
8、The baking finish and flame plating technology of appearance are very fashion，Wear-resisting prevent
slippery.
9、Nano receiver, built-in mouse, very convenient;
10、Power on-off design, turn off the mouse power, it can prolong batteries life when no use;
11、Working voltage： 1.5V（AA）
12、Main size: 98*54*27mm
Middle Button and
Scroll Wheel Ri
g
ht Button
Left Button DPI Key
BD-9588
Receiver
REV：A0 BD-9588 USER MANUAL Page 3 /5
System Compatibility
1．Suitable Model: IBM PC/AT Compatible, Power Macintosh
2．Operation Systems: Windows 2000/XP/Vista/WIN7/MAC
3．Interface: USB
Technical Parameters
Mouse:
1． Rating working voltage 1.5V
2． Rating working current 10mA
3． Maximum acceleration 3 0 i p s
4． Resolution 800-1200-1600DPI
5． Wireless working channels 34 auto frequencies
6． Working frequency 2.402-2.480GHz
7． Working distance >10meters
Receiver:
1． Rating working voltage 5V
2． Rating working current 30mA
Pull out the receive and the battery installation steps
1． Open the mouse at the bottom of the battery cover.
2． Take out the 1 AA alkaline battery from the package.
3． Put the batteries into the battery cell according to the right pole . (Please don’t install in the opposite pole , or it will harm）
4． Pull the battery cover into the mouse and take out receive.
Receiver
Open the battery
cover according to
arrows
Power switch
REV：A0 BD-9588 USER MANUAL Page 4 /5
Install the receiver and connect the Parameters
1． Pull out the receiver from the bottom of the mouse . As picture three shows:
2． Pull "ON" to the mouse power switch .As picture four shows. After computer automatic identification and mouse can use.
DPI switch function
1． DPI default is 1200DPI
2． DPI key can switch between 800-1200-1600 DPI.
Nano Receiver
DPI indicator place
REV：A0 BD-9588 USER MANUAL Page 5 /5
Attention
1．It can prolong the batteries life if you use the mouse on the white surface.
2. Auto-sleeping and power-saving function, it will be auto-sleeping without operation within a long time, press any key or
scroll wheel to activate it.
3. Optical may not normal use in smooth desktop , glass , reflective , dark black and 3D mouse pad .。
4. Please turn off the power if you‘re in traveling or you’ll not use it for a long time.
5. When mouse work on metallic surface, the best way is to place a mouse pad under mouse or lay the receiver horizontally to
achieve the optimal receiving effect.
6. No need to connect data again when replace battery (built-in memory function.)
.
Technical Instructions
Adopt 2.4G Hz wireless high frequency technology, satisfying Europe R&TTE Directive1999/5/EC requirement, its
radiation will not harmful for men’s body (much less than mobile radiation), wireless emission will occur electromagnetic
signal, please be caution to use when in the using heart pacemaker or related to body assistant instrument surroundings
Disclaimer
We made every effort to ensure that the information and procedure in this guide is accurate and complete, no liability
can be accepted for any errors or omissions and reserves the right to make any changes without further notices to any products
herein.
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoid
theuser’sauthoritytooperatetheequipment.Thisequipmenthasbeentestedandfoundtocomply
withthelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsare
designedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnotinstalledandused
inaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbe
determinedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐ Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe receiveris
connected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
