The operating manual of the ck-002 thermostat
The invention adopts the latest microcontroller control technology, and its
application is electric heating equipment or driver control.The temperature controller will
start and stop the controlled object (valve, floor heating, heating wall, electric heater, etc.)
automatically according to the preset temperature.
number
Name
operating instructions
1
set temperature
Displays the current set temperature
2
indoor
temperature
Displays the actual indoor temperature
3
Week
Show what day it is today
4
time
Dynamic Display Current Time
5
Mode button
Short press to switch to manual and automatic mode, automatic
mode is 24 degrees
6
power button
Short press to switch on and OFF. The shutdown state shows the
current indoor temperature and OFF. Long press the power supply
to shut OFF completely
7
Heating logo
When this icon is displayed, it is in a heated state; if it is not
displayed, it is not heated
8
mode identifier
Display this icon in manual mode, not displayed in automatic mode
9
Wifi logo
When this icon is displayed, it is a normal wifi connection; if it is not
displayed, it is not connected
10
Child Lock
The icon is locked when it is displayed, but not displayed when it is
not locked
11
Add button
Adjust the temperature and adjust in the setting mode
12
Minus buttons
Adjust temperature, adjust in the setting mode, minute, week, long
press to switch children lock and unlock
13
Set the key
Press the setting button to enter the setting time, week, and long
press the button to enter wifi pairing
14
Internal sensor
The sensor that detects indoor temperature
15
reset button
Press this button to shut down and restart the machine to restore
the factory Settings
16
The power entry
Ac port
17
The power
export
Load side exit interface
18
external sensors
External sensor interface
Pairing mode: long press the setting button when the device is on, the wifi icon
flashes and stops flashing for about 60 seconds.The pairing is successful, the wifi icon on
the server is always on, and the clock will update the network time.
Manual mode: when the indoor temperature is 3 degrees below the set temperature,
turn on the heating immediately, and the heating icon is displayed.To set the temperature
value (manually set the temperature value), stop heating and the heating icon is not
displayed.
Automatic mode: when the indoor temperature is below 21 degrees, turn on the
heating immediately, and the heating icon is displayed.When the temperature is set (from
Monday to Sunday, 6 times per day), stop heating and the heating icon is not
displayed.The default 24 degrees。
Alarm mode: when the local plate temperature is above the temperature limit, stop
heating. The default is 55 degrees.
Backlight function: backlight, power-on highlights;Turn off low.When the backlight
is turned off and turned off, press other keys/receive WIFI data and the backlight will be
turned on for 10 seconds.
Heating function: when the indoor temperature is 3 degrees below the set
temperature, start heating; when it is higher than the set temperature, stop heating.
Automatic upload function: upload all data to APP without any action for 10
seconds.So the APP updates the temperature every 10 seconds.
Features and functions:
1. After connecting with the WiFi router in your home, you can set the thermostat
working mode (remote control system) on the mobile terminal through the APP.Set
the temperature controller working mode through the touch screen;
2. The thermostat working mode can be set through the touch screen;
3. Time display and temperature display;
4. Automatic adjustment of room temperature;
5. Memory function of power failure
6. A white backlit square LCD screen.
7. Multiple time modes: 5+2/6+1/7 days, 6 stages per day.
8. Free choice of manual or automatic modes for different purposes.
9. Keyboard locking function to prevent child abuse.
Technical parameters:
1. Operating voltage: ac110-240v, 50/60 HZ
2. Maximum switch current: 16A
3. The internal sensor: NTCB = 3380 10 k @ 25 ℃, the sensor measurement range: 0
to 40 ℃, accuracy: + / 0.1 ℃
4.External sensors: NTCB = 3380 = 10 k @ 25 ℃length 3 meters, measuring range:
0-99 ℃, accuracy: + / - 1 ℃, set range: 5-90 ℃(factory setting: overtemperature
protection 50 ℃)
5. A 3-meter external sensor cable is provided
Note:
1. Please read the instruction before use
2. The thermostat can only be used for the purposes specified by the
company.Unauthorized modification and use of parts not sold or recommended by the
company may cause the system to fail or even fail.
3. Avoid using this thermostat in the atmosphere containing carbon dioxide, hydrogen
sulfide or other corrosive gases; otherwise, the relay will be electrocuted.
4. After the whole machine is installed, connect the relevant leads, and the power can be
sent to run under the condition that there is no error.
5. Do not grill the sensor probe with a lighter.
6. Do not apply the maximum rated voltage and current on the relay output contact.
