ShenZhen RuiMaiDe S002P Apple Watch Charger User Manual S002
ShenZhen RuiMaiDe(RMD) Technology Co., LTD Apple Watch Charger S002
User Manual
Thank you for purchasing the 2-in-1 Wireless Charger.
Please read the manual carefully before using the product.
Product Outline
Instructions
Place both your phone and Apple Watch on the wireless
charger. Make sure they are well located in the charging
area of the wireless charger.
1. USB Cable Connection
2. Charging
3. LED Indicator
3.1. Qi Wireless Charger
When the phone is charging, the LED Indicator on Qi
wireless charger will light up to show charging status:
User Maunal
2-in-1
Wireless Charger
Connect Type-C USB cable
to the main body and plug
it into the power adapter. 1) Standby Mode - light is on with green color
LED Indicator
Power Bank Switch (click
once - ON, click twice - OFF)
Apple Watch
Charging Stand
Qi Wireless Charging Dock
Anti-slip Pads
Type-C Charging Port
2) Charging Mode - light will flash for 5 times and
turn off
3) Fully Charged - iOS: without LED light;
Android OS: light is on with green color
?
10 0% C ha rg ed
Android OS
10 0% C ha rg ed
iOS
Product Contents
1 x 2-in-1 Wireless Charger
1 x Apple Watch Charger
1 x Power Adapter
1 x USB Cable
1 x User Manual
Applicable Devices
1. Qi Wireless Charger Compatible Devices:
1.1 10W Fast Charging Mode for:
Samsung S9 / S9 Plus / Note 8 / S8 / S8 Plus / S7 / S7
Edge / S6 Edge Plus / Note 5
1.2 7.5W Fast Charging Mode for:
iPhone X / 8 / 8 Plus
1.3 5W Mode for All Qi-enabled Phones:
a: Samsung S6 / S6 Edge
b: Nokia Lumia 920 / 1020 / 928 / 1520 / 820 / 822
/ 930 / 950
c: Moto Droid Maxx / Droid Mini / Droid Turbo
d: Google Nexus 4 / 5 / 6 / 7
e: LG Optimus Vu2 / G2 / G3 / LG G6 / LG V30
f: Nexus 4 / Nexus 5 / Nexus 6 / LTE 2 / D1
Product Specifications
Qi: 1 LED shows the charging status
Apple Watch Power Bank: 3 LEDs indicate
30%, 60%, 100% of the power
Model S002
Material ABS+PC, Silicone
Wireless charging for Apple Watch 5W
Output Interface Type-C
Output 1 Wireless charging for mobiles
5W / 7.5W / 10W
Output 2
Input QC 3.0 18W
Cable Length 1m
Capacity 850mAh
Plug Standard US (JP/CN), EU, UK
LED Indicator
Dimension Qi Wireless Charger: 170 x 84 x 13.8mm
Apple Watch Charger: 39.5 x 39.5 x 41mm
not work normally.
2. Please do not place any metal or magnetic object between
your phone and charger, otherwise the charger will not
work.
3. Equip your device with a Qi receiver if it is not Qi-enabled
out of the box.
4. Only after the Apple Watch is fully charged can the power
bank begin to charge.
2. Apple Watch Charger Compatible Devices:
Apple Watch Series 1 / 2 / 3 / 4 / 1st generation in 38mm,
40mm, 42mm and 44mm.
Attention:
1. Please make sure that the power adapter used meets the
requirement. If the power is insufficient, the product may
4. Apple Watch Power Bank
The Apple Watch charger can be detached and used
alone as a power bank.
Three LED indicators on the Apple Watch Charger indicate
30%, 60%, 100% of the battery respectively.
100%60%30%
3.2. Apple Watch Charger
4) Foreign Object or Error Warning - light is on with
red color
Note: It refers to the battery of Apple Watch Power Bank,
but not the Apple Watch Charger.
Any Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interfe-
rence that may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment .
This equipment should be installed and operated with minimum
distance 20cm between the radiator& your body.
This transmitter must not be co-located or operating in conjun-
ction with any other antenna or transmitter.
FCC Caution:
