ShenZhen Shenboya Electronic Technology F6 Bluetooth Speaker User Manual
ShenZhen Shenboya Electronic Technology Co., Ltd Bluetooth Speaker
User Manual
1
Bluetooth Speaker User Manual
-----------------------------------------------
Thank you for purchasing our bluetooth speaker. Please read this manual carefully
and keep it for future reference.
Features of the speaker:
1. Support wireless control through Bluetooth device
2. Support TWS: True wireless stereo
3. Support plug and play for TF card
4. 3.5mm line-in jack for wired devices
5. Built in rechargeable battery supports up to 10 hours playback (medium volume)
6. Two 6W speakers deliver deep and rich sound
7. Built-in Microphone for phone calls
8. Support MP3, WAV, APE, FLAC, WMA format of audio file TF card
9. Support FM radio
2
Operating Instructions:
1. Charging
With the speaker turned off, connect the Micro-USB connector of the charging
cable to the DC5V input socket at the rear side of the speaker, and plug the USB
connector of the charging cable to an external USB power supply socket with a
minimum supply current of 1A. The external USB power supply can be the USB
socket in your computer/laptop, the USB adaptor of most cellphone USB chargers
with DC5V output, or the 5V USB port of a power socket etc.
When charging, the power indicator will be red.
2. On/Off
The On/Off slide button is at the rear side of the speaker. Slide to the on or off
position to turn the speaker on or off
3. Bluetooth
Paring – 1. Turn on speaker to enter Bluetooth mode directly. Then turn on your
Bluetooth device (such as a mobile phone, laptop, PDA etc), search for Bluetooth
equipment “F6”, and then pair up with the speaker. There will be a sound from the
speaker when Bluetooth connection is established
Bluetooth phone call - When paired to your phone, press the button to
answer incoming calls, and press the button again can end the call; Press
button and hold for 5 seconds can refuse the incoming calls; Press the
button twice can call back to the last incoming call number.
3
Note: Please talk close to the microphone when making phone calls.
TWS Operation: Put the two F6 speakers together, and turn on speakers to enter
Bluetooth mode, then choose one of them to press button and hold for 2
seconds, the two speakers will start automatically pair and enter TWS mode, the
one which you chose to press will work as left channel.
Volume adjustment – When playing music and when making a phone call under
Bluetooth mode, the volume can be adjusted by pressing the /
button. The volume can also be controlled from your Bluetooth device (cellphone,
laptop, PDA etc.)
Track selection – When playing music in Bluetooth mode, a short press of
/
buttons will jump to the previous track or next track. Track selection can
also be done from your Bluetooth device.
4. AUX / Line in:
Insert the audio cable into the 3.5mm jack of speaker and connect the other side to
your laptop / mobile phone / mp3 / mp4 / CD player etc to play music file from
AUX/Line in.
5. TF Card:
The speaker supports plug and play for Micro SD card. Just plug in your TF
Card into the speaker’s Card slot and the speaker will play the music files
automatically.
6. FM radio
Put the slide button on FM mode, then press button and hold, speaker will
start automatically searching FM channels and save channels. After finished
search, press / buttons can adjust channels, the volume can be
4
adjusted by pressing the / buttons.
7. Reset - If the speaker is not working normally, please turn on or powered on the
speaker then speaker will reset.
Note:
1 If speaker is in lower power, machine will play warning tone for three times and
then turn to sleep mode, please charge it then can work normally again
2. Due to the 2.4G radio interference, if the speaker can not paired or play music
well, please turn on the speaker again or reconnected the Bluetooth device again.
8. Technical data
Power
Built-in 4000mA Li battery
External USB 5V supply
Working voltage : 3.2V-4.2V
Charging voltage: 5V 1000mA
Technical
Frequency 100HZ-18KHZ
SNR ≥85db
Sensitivity Rate 80db
THD ≤0.3%
Speaker Φ52mm 4Ω 20 core
RMS 6W*2
Music format MP3, WMA, WAV, APE, FLAC
Speaker size φ205*57mm
Weight 621g
5
Trouble shooting:
1. Can’t turn the speaker on:
Check if the battery is in low. Recharge and then try to turn on again
2. Can’t charge the speaker:
Check the power supply is working and that the output of the power supply to the
charge cable is 5V and > 1A.
Check that the charge cable and connectors of the cable are not damaged.
3. No sound:
Check the speaker is paired with the right Bluetooth device. If not, disconnect
the Bluetooth connection and pair again to the right device.
Check the music format in the TF card.
Warning:
1. Do not use the product in high temperature; Always keep the product away from fire. For the
sake of your safety, never throw the product into fire, which may cause explosion and personal
injury.
2. Do not use the product close to high-voltage wire or electronic apparatus. Please take proper
safety measures when using the product in terrible weather conditions.
3. Do not use near water or any high-humidity environment, which may cause destructive
damage to the product
4. The product is not designed for use in or near any strong magnetic field, which may cause
destructive damage to the product
6
FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
FCC ID: 2ABCD-F6
