Shuaixian Electronic Equipment SX-928 BLUETOOTH SPEAKER User Manual
Shenzhen Shuaixian Electronic Equipment Co., Ltd. BLUETOOTH SPEAKER
User Manual
65
Reconnection Aux-In Mode
87
Product Specifications
-Switch on the unit by sliding the Power On Switch.
-The blue LED will blink and you will hear a beep signaling the unit
has reconnected to last paired device.
-To use Aux-In mode, plug in the supplied 3.5 mm cable to the
Planet Audio and plug the other end to the device.
- The Planet Audio will automatically switch to Aux-In.
Phone Calls
-Accepting incoming calls is done by pressing the MFB button
once while ringing.
- To end the phone call, press the MFB once to end the call and
resume the music (if playing).
-Profiles Supported: A2DP, HFP, HSP
-Radio Power: this EUT is lower than 94dBuV/m
-Range: 10 m
-Battery: Li-Ion, 3.7 V, 1200 mAh
- Max Current Input: 500 mA
-Continuous Play Time: ı 4 Hrs
43
First Time Power On & Pairing Pairing a Device
-Slide the On/Kīswitch to the On position.
-After 9 sec, blue and red LED will flash alternatively.
-On your device make sure it is set to discover new devices.
-Pair: “Planet Audio”
-If prompted to enter a passcode, enter “0000”.
-Once the device is paired, the blue LED will flash every 5 sec.
-Turn on the Planet Audio, then after 9 sec, the blue and red LED will
flash alternatively.
-On your device make sure it is set to discover new devices.
-Pair with: “Planet Audio”
-If prompted to enter a passcode, enter “0000”.
-Once the device is paired, the blue LED will flash every 5 sec.
-Planet Audio will store up to 4 devices.
-Repeat the process if the unit times out.
21
Contents
-Speaker
-USB Charging Cable
-3.5 mm Audio Cable
- User Manual
Description
LED Indicator On/Off Switch
Left Speaker Right Speaker
Rear
Front
Previous/Volume- MFB Next/Volume+
3.5mm Aux-In Charging Port
FCC Certification Requirements
Caution: Any changes or modifications in construction of this device which are not
expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
