CAUTION: PUBLIC SAFETY RESTRICTIONS
Avoid the following groups, channels, and frequency ranges as specifi ed for each listed metro region.
NOTE: This information is known to be accurate at the time of printing but is subject to change. Check the Shure website for the latest public safety
frequency and channel information: http://www.shure.com/ProAudio/TechLibrary/WirelessFrequencyFinder/index.htm
MX690, MX890, SLX
User Guide Supplement:
G4 Public Safety Restrictions
Metro Region Groups, Showing Channels to Avoid Frequency (Mhz) to
Avoid
TV
Channels to Avoid
G1 G2 G3 G4 G5 G6
Boston, MA 1-3, 6-8 1-3, 7-8 1-5, 7-8 6-7, 10-12 1-8 6-8, 10-12 470-476, 482-488 14, 16
Chicago, IL, North Western Indiana 1-5 1-6 1-6 1-7 6-9 6-9 470-476, 476-482 14, 15
Cleveland, OH 1-5 1-6 1-6 1-7 6-9 6-9 470-476, 476-482 14, 15
Dallas-Fort Worth, TX 6-8 7-8 7-8 8-9 1-5 10-12 482-488 16
Detroit, MI 4-8 4-8 6-8 1-5, 8-9 1-5, 9 9-12 476-482, 482-488 15, 16
Houston, TX 9-12 9-12 9-12 10-12 10-12 1-5 488-494 17
Los Angeles, CA 1-3, 6-8 1-3, 7-8 1-5, 7-8 6-7, 10-12 1-8 6-8, 10-12 470-476, 482-488,
506-512 14, 16, 20
Miami, FL 1-3 1-3 1-5 6-7 6-8 6-8 470-476 14
New York, NY, Northeastern New Jersey 1-8 1-8 1-8 1-9 1-9 6-12 470-476, 476-482,
482-488 14, 15, 16
Philadelphia, PA Unaffected 500-506, 506-512 19, 20
Pittsburgh, PA 1-3 1-3 1-5 6-7 6-8 6-8 470-476, 494-500 14, 18
San Francisco, Oakland, CA 6-12 7-12 7-12 8-12 1-5, 10-12 1-5, 10-12 482-488, 488-494 16, 17
Washington, D.C., Maryland, Virginia 9-12 9-12 10-12 10-12 1-5 488-494, 494-500 17,18
INTER-GROUP AVAILABILITY: G4 470-494MHz
The following table describes compatible Frequencies and Channels available within each group.
Channel
Group 1 2 3 4 5 6
full G4
spectrum
full G4
spectrum
Full range, 5
frequencies in TV 14
Full range,
5 frequencies in TV 15
Full range,
5 frequencies in TV 16
Full range,
5 frequencies in TV 17
1471.150 470.125 470.275 476.275 482.275 488.275
2473.275 472.250 471.375 477.375 483.375 489.375
3474.825 473.800 472.775 478.775 484.775 490.775
4477.100 476.075 474.575 480.575 486.575 492.575
5479.800 478.775 475.750 481.750 487.750 493.750
6482.775 481.750 480.475 471.725 471.250 471.175
7483.875 482.850 484.550 473.325 474.100 473.950
8487.075 486.050 487.150 483.275 475.575 475.150
9489.625 488.600 489.100 487.500 480.675 481.475
10 491.000 489.975 490.225 489.725 489.475 483.475
11 492.625 491.600 491.725 491.225 491.725 484.725
12 493.825 492.800 492.950 492.350 493.550 486.700
ACCESSORIES
Furnished: UA400B 1/4 Wave Antenna (470-752Mhz)
Optional: UA820G 1/2 Wave Antenna (470-530Mhz)
Compliance Information
Type accepted under FCC Part 74, FCC ID DD4SLX1G4. Type accepted under FCC Part 74, FCC ID DD4SLX2G4.
Type accepted under FCC Part 74, FCC ID DD4MX690G4. Type accepted under FCC Part 74, FCC ID DD4MX890G4.
