Congratulations on
purchasing your Shure
Performance Gear Wireless
system. Shure professional
audio products deliver
legendary sound quality,
stage-proven durability and
hassle-free setup for worry-free
performance.
Performance Gear Wireless
systems are available in a
variety of configurations for
handheld, guitar, headset, and
presentation applications.
Startup
channel
ready
audio
Internal Diver
Busy Indicator
When selecting channels,
a flashing dash indicates
interference from television
broadcasts, electronic devices
or other wireless systems.
CHANNEL
6
MUTE
channel
mute
channelreadyaudio
Internal Antenna Diversity
channel
mute
channel
mute
Accessing Gain Switch
channel
mute
Testing Audio
Talk or sing into the
microphone or play
instrument.
0dB For instrument or quiet to normal vocal performance (default).
–10dB Use if audio is distorted due to high vocal or instrument levels.
mic Use for headworn or lavalier microphones (PG1 only).
CHANNEL D"MIC
channel
ready
audio
Internal Diver
ENGLISH
Changing Channels
Press and hold the channel
button until the display starts
flashing.
Internal Anten
channel
ready
audio
While the display is flashing,
press the channel button.
The channel is active once
the display stops flashing.
channel
mute
Receiver and transmitter
channels should match.
Multiple gain settings are available on the PG1 and PG2 transmitters.
To change gain settings, see below.
Follow these simple steps to check for interference and to
set your receiver and transmitter to the same channel .
If you haven’t installed the
battery, do it now and leave the
cover off.
Turn ON the handheld or
bodypack transmitter by
pressing the power button.
The channel display should
illuminate.
The ready LED on the receiver
should be illuminated.
Replace battery cover.
Check to see that the
transmitter and the receiver
display the same channel .
channelready
audio
Internal Diversity Antenna Syste
channel
mute
Internal Anten
channel
ready
audio
©2006, Shure Incorporated
27EN8865 (Rev. 3)
Printed in U.S.A.
The audio LED on the
receiver should flicker green
or amber, if red, adjust the
Gain Switch .
If this occurs, change the
channel.
Lock system controls to prevent accidental muting.
To lock controls: Turn transmitter off. Remove Battery Cover. Press
and hold Channel Button. Press and release Power/Mute button.
Power/Mute LED will flash red and green.
To unlock controls: Press and hold Power/Mute button down until
Power/Mute LED flashes red and green.
Locking and Unlocking Transmitter Controls
It turns off after ten seconds to
conserve battery.
Wearing the Bodypack Transmitter
Clip the transmitter to belt or
guitar strap as shown.
Make sure the antenna is
unobstructed.
Changing Battery
Expected life for a 9 volt alkaline battery is approximately 8 hours.When the
Power/Mute LED glows red, the battery should be replaced immediately.
System Components
audio ready channel
Diversity Antenna System
PG4
audio ready channel
audio ready channel
PG1
Bodypack
Transmitter
PG2 Handheld
Transmitter
PG4 Wireless
Receiver
PG88 Dual Wireless Receiver
PS20
Power Supply
PG185
Lavalier Mic
Features
PG30
Headworn Mic
Turn OFF the microphone
or bodypack.
If left on, it will create a false
busy indicator.
Plug in the power supply.
There is no power switch.
The channel display should
illuminate.
If you see the Busy
Indicator (a flashing dash)
change the channel.
Press and hold down the
channel button until the
display begins flashing.
Wait for the channel display
to stop flashing.
Issue LED Status Solution
No sound or
faint sound
Transmitter Power/
Mute LED on,
receiver LEDs on
• Perform transmitter setup.
• Verify all sound system connections.
• Adjust transmitter gain.
Receiver Channel
Display off
• Make sure AC adapter is securely
plugged into electrical outlet and into
POWER connector on rear panel of
receiver.
• Make sure AC electrical outlet works
and is supplying proper voltage.
Transmitter LED
glowing
or flashing red
• Replace transmitter battery.
Transmitter LED off • Turn transmitter on.
• Make sure the +/– indicators on
battery match transmitter terminals.
• Insert fresh battery.
Distortion or unwanted noise bursts • Remove nearby sources of RF
interference (CD players, computers,
cell phones, digital effects, in-ear
monitor systems, etc.)
• Select a new channel for both receiver
and transmitter.
• Reduce transmitter gain.
• Replace transmitter battery.
• If using multiple systems, change the
channel of one of the active systems.
Sound level different from cabled
guitar or microphone, or when
using different guitars
• Adjust transmitter gain as necessary.
Cannot turn
transmitter on
Transmitter LED
flashing red
• Replace transmitter battery.
Troubleshooting
Regulatory Information
Replacement Parts
Technical Specifications
Audio Input Level –10 dBV maximum at “mic” gain position
+10 dBV maximum at 0dB gain position
+20 dBV maximum at –10dB gain position
Gain Adjustment Range 30 dB
Input Impedance 1mΩ
RF Transmitter Output 10 mW typical (dependent on applicable country regulations)
Dimensions 110 mm H x 64 mm W x 21 mm D (4.3 x 2.5 x 0.8 in.)
Weight 75 grams (2.6 oz.) without battery
Housing Molded ABS
Power Requirements One 9V alkaline or rechargeable battery
Battery Life >8 hours (alkaline)
Working Range 75m (250 ft.) Note: actual range depends on RF signal absorption, reflection,
and interference.
Audio Channel Response Minimum: 45 Hz.
Maximum: 15 kHz (overall system channel depends on
microphone element).
Total Harmonic Distortion 0.5%, typical
Ref. +/– 33 kHz deviation, 1 kHz tone
Dynamic Range >100 dB A-weighted, typical
Operating Temperature
Range
–18°C (0°F) to +57°C (+135°F)
Note: battery characteristics may limit this range
Transmitter Audio Polarity Positive pressure on microphone diaphragm (or positive voltage to tip of
WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3
of low impedance output) and the tip of the high impedance 1/4-inch output.
Audio Input Level +2 dBV maximum at –10dB position
–8 dBV maximum at 0dB position
Gain Adjustment Range 10dB
RF Transmitter Output 10 mW typical (dependent on applicable country regulations)
Dimensions 223.52 L x 53.34 Dia. (8.8 in. x 2.10 in.)
Weight 218 grams (7.7 oz.) without battery
Housing Molded ABS handle and battery cup
Power Requirements One 9V alkaline or rechargeable battery
Battery Life >8 hours (alkaline)
Output Impedance XLR connector: 200 Ω 1/4 inch connector: 1kΩ
Audio Output Level Ref.
+/– 33 kHz deviation with
1 kHz tone
XLR connector (into 100K Ω load): –19 dBV, typical
1/4 inch connector (into 100K Ω load): –5 dBV, typical
Sensitivity –105 dBm for 12 dB SINAD, typical
Image Rejection >50 dB, typical
Dimensions 188 mm L x 103 mm W x 40 mm D (7.4 in. x 4.0 in. x 1.5 in.)
Dimensions - PG88 388 mm L x 116 mm W x 40 mm D (15.3 in. x 4 in. x 1.5 in.)
Weight 241 grams (8.5 oz)
Weight - PG88 429 grams (15.1 oz)
Housing Molded ABS
Power Requirements 12–18 Vdc at 160 mA (PG4), 320mA (PG88), supplied by external
power supply
System
PG1 Bodypack Transmitter
PG2 Handheld Transmitter
Regulatory Information for North America, Europe, and Australia
PG1 & PG2 Transmitters: Certified to FCC Part 74 (FCC ID: “DD4PG1” and “DD4PG2”).
Certified by IC in Canada under RSS-123 and RSS-102 (“IC: 616A-PG1” and “IC: 616A-
PG2”). Meets the essential requirements of the European R&TTE Directive 99/5/EC (ETSI EN
300-422 Parts 1 & 2, EN 301 489 Parts 1 & 9) and are eligible to carry the CE marking.
PG4 and PG88 Receiver: Authorized under Declaration of Conformity (DoC) provision of
FCC Part 15. Certified under Industry Canada to RSS-123 (“IC: 616A-PG4”). This class B
digital apparatus complies with Canadian ICES-003. Meets the essential requirements of the
European R&TTE Directive 99/5/ EC (EN 301 489 Parts 1 & 9, EN 300 422 Parts 1 & 2) and
is eligible to carry the CE marking. Conforms to Australian EMC requirements and is eligible
for C-Tick marking.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio channel energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
PS20 Series Power Supplies: Conform to Safety Standard IEC 60065.
PS20E and PS20UK are eligible to bear CE marking.
N108
Z540
0978
Technical Specifications cont’d
PG4 and PG88 Receiver
SHURE Incorporated http://www.shure.com
United States, Canada, Latin America, Caribbean:
5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A.
Phone: 847-600-2000 U.S. Fax: 847-600-1212 Int’l Fax: 847-600-6446
Europe, Middle East, Africa:
Shure Europe GmbH, Phone: 49-7131-72140 Fax: 49-7131-721414
Asia, Pacific:
Shure Asia Limited, Phone: 852-2893-4290 Fax: 852-2893-4055
Changes or modifications not expressly approved by Shure Incorporated for compliance
could void the user’s authority to operate the equipment. Operation of this device is subject
to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired
operation of the device.
Caution
!
System Components
All Systems
PG4 or PG88 Receiver
Internal Diversity Antenna System
One 9 volt battery AC Power supply User guide
Vocalist System
Microphone Head PG2 handheld transmitter Microphone clip
Instrument System
PG1 bodypack
transmitter
4-pin mini connector (TA4F) to
1/4” connector cable
Lavalier and Headworn System
PG1 bodypack
transmitter
Microphone (choice of PG185, PG30)
Patents
Patent numbers 6,597,301 and 6,296,565
All Systems Microphone Stand Adapter (PGX2) WA371
System-Specific AC Adapter (120 VAC, 60 Hz) PS20
AC Adapter (220 VAC, 50 Hz), Argentina PS20AR
AC Adapter (230 VAC, 50/60 Hz, Europlug) PS20E
AC Adapter (230 VAC, 50/60 Hz, UK) PS20UK
AC Adapter (100 VAC, 50/60 Hz) PS20J
AC Adapter (220 VAC, 50 Hz, China) PS20CHN
AC Adapter (230 VAC, 50 Hz,, Australia) PS20AZ
AC Adapter (220 VAC, 60 Hz, Korea PS20K
PG58 Head with Grille RPW108
Belt Clip 44A8035
Optional Universal Rack Tray URT
4-pin mini connector (TA4F) to 1/4”
connector cable
WA302
A ministerial license may be required to operate this equipment in certain areas. Consult
your national authority for possible requirements.
This radio equipment is intended for use in musical professional entertainment and similar
applications.
LED Status
TRANSMITTER
LED COLOR STATUS
Green Ready
Amber Mute on
Red Battery low
Flashing Red on startup Battery is dead
Flashing Green and Red Controls locked
Flashing Amber and Red Mute on, battery low
RECEIVER
AUDIO LED COLOR INDICATES
Green Normal signal strength
Amber Strong signal
Red Peak signal
READY DISPLAY COLOR INDICATES
Green System is ready
To set up multiple systems, repeat the previous steps for each transmitter and
receiver pair. Once transmitters have been set, leave them on. Be sure to set
each transmitter and receiver pair to a different channel. For information about
frequencies and compatibility, refer to channel guide.
Multiple System Setup
©2007 Shure Incorporated Printed in USA
27A8898 (Rev. 1)
PG Wireless User Guide Supplement:
X1
INTER-GROUP AVAILABILITY: PG Wireless X1 944-952MHz
The following table describes Frequency and Channel availablility.
Channel
Group 1
1 944.600 Compatible
Frequencies
2 946.275
3 947.475
4 949.800
5 944.300 Compatible
Frequencies
6 945.975
7 947.175
8 949.500
9 951.825 Alternate
Frequencies
10 951.525
COMPLIANCE INFORMATION
Type accepted under FCC Part 74, FCC ID DD4PG2A. Type accepted under FCC Part 74, FCC ID DD4PG1A.

Navigation menu
