©2008 Shure Incorporated Printed in USA
27A8897 (Rev. 2)
PGX Wireless User Guide Supplement:
X1
INTER-GROUP AVAILABILITY: PGX X1 944-952MHz
The following table describes compatible Frequency and Channel availablility in each group.
Channel
Group 0 1 2 3 4 5 6 7 8 9
Full range, Robust, 5 channels Full range, Max frequencies, 5 channels
1 944.275 944.125 944.375 944.475 944.325 944.350 944.125 944.225 944.400 944.175
2 946.300 946.150 946.400 946.500 945.900 945.525 945.300 945.400 945.575 945.300
3 947.500 947.350 947.600 947.700 948.500 947.175 946.950 947.050 947.225 946.725
4 950.100 949.950 950.200 950.300 949.700 949.275 949.050 949.150 949.325 948.825
5 951.675 951.525 951.775 951.875 951.725 950.700 950.475 950.575 950.750 950.475
6 951.825 951.600 951.700 951.875 951.650
COMPLIANCE INFORMATION
Certied under FCC Part 74, FCC ID DD4PGX2A. Certied under FCC Part 74, FCC ID DD4PGX1A.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modications not expressly approved by Shure Incorporated could void your authority to operate the equipment.
