user manual supplement
MX690, MX890 SLX User Guide Supplement:
G5 Public Safety Restrictions
Metro Region Groups, Showing Channels to Avoid Frequency (Mhz) to Avoid TV
Channels to Avoid
G1 G2 G3 G4 G5 G6
Boston, MA
Unaffected
470-476, 482-488 14, 16
Chicago, IL , North Western Indiana 470-476, 476-482 14, 15
Cleveland, OH 470-476, 476-482 14, 15
Dallas-Fort Worth, TX 482-488 16
Detroit, MI 476-482, 482-488 15, 16
Houston, TX 488-494 17
Los Angeles, CA 7-10 7-10 9-10 8-10 1-5 12 470-476, 482-488,
506-512 14, 16, 20
Miami, FL
Unaffected
470-476 14
New York, NY, Northeastern New Jersey 470-476, 476-482,
482-488 14, 15, 16
Philadelphia, PA, New Jersey 4-10 4-10 6-10 1-5, 8-10 1-5, 9-10 9-12 500-506, 506-512 19, 20
Pittsburgh, PA 1-3 1-3 1-5 6-7 6-8 6-8 470-476, 494-500 14, 18
San Francisco, Oakland, CA Unaffected 482-488, 488-494 16, 17
Washington, D.C., Maryland, Virginia 1-3 1-3 1-5 6-7 6-8 6-8 488-494, 494-500 17,18
INTER-GROUP AVAILABILITY: SLX: G5 494-518 MHz
The following table describes compatible Frequencies and Channels available within each group.
Channel
Group 1 2 3 4 5 6
Full G5
Spectrum
Full G5
Spectrum
Full range, 5 frequencies in
TV 18
Full range, 5 frequencies in TV 19 Full range, 5 frequencies in
TV 20
Full range, 5 frequencies in TV 21
1495.150 494.125 494.275 500.275 506.275 512.275
2496.975 495.950 495.375 501.375 507.375 513.375
3499.275 498.250 496.775 502.775 508.775 514.775
4501.875 500.850 498.575 504.575 510.575 516.575
5503.800 502.775 499.750 505.750 511.750 517.750
6505.175 504.150 502.325 496.400 494.125 495.175
7507.450 506.425 504.475 498.700 495.250 497.075
8509.150 508.125 505.750 507.475 497.300 499.700
9510.300 509.275 508.550 509.750 501.150 501.675
10 511.875 510.850 510.800 511.650 502.575 503.050
11 514.000 512.975 515.200 513.100 515.650 505.525
12 517.150 516.125 516.500 517.075 516.900 510.625
SLX RECEIVER ACCESSORIES
Furnished: UA400B 1/4 Wave Antenna (470-752Mhz)
Optional: UA820G 1/2 Wave Antenna (470-530Mhz)
COMPLIANCE INFORMATION
Certied under FCC Part 74, FCC ID DD4SLX2G5. Certied under FCC Part 74, FCC ID DD4SLX1G5.
Certied under FCC Part 74, FCC ID DD4MX690G5. Certied under FCC Part 74, FCC ID DD4MX890G5.
Changes or modications not expressly approved by Shure Incorporated could void your authority to operate the equipment.
©2008 Shure Incorporated Printed in USA
27A11833 (Rev. 2)
CAUTION: PUBLIC SAFETY RESTRICTIONS
Avoid the following groups, channels, and frequency ranges as specied for each listed metro region.
NOTE: This information is known to be accurate at the time of printing but is subject to change.
Check the Shure website for the latest public safety frequency and channel information:
http://www.shure.com/ProAudio/TechLibrary/WirelessFrequencyFinder/index.htm
