user manual

27A8907 (Rev. 1)

ULX User Guide Supplement:

INTER-GROUP AVAILABILITY: ULX X1 944-952MHZ

The following table describes Frequency and Channel availablility in each of 10 Groups.

Channel

Group 1 2 3 4 5 6 7 8 9 10

X1, J1 and M1 bands fully

available

X1, J1 and

G3 bands

fully available

X1, M1 and

G3 bands fully

available

Full X1 spectrum, Robust, 7 channels Full X1 spectrum, Max. 9 channels

1 944.200 944.300 944.225 944.200 944.200 944.125 944.225 944.125 944.175 944.350

2 945.250 945.200 944.975 945.050 945.650 945.575 945.675 945.175 945.225 945.400

3 945.925 945.850 946.125 946.300 946.725 946.650 946.750 945.850 945.900 946.075

4 947.300 946.825 946.800 947.100 948.275 948.200 948.300 947.225 947.275 947.450

5 948.275 948.175 947.775 948.150 949.525 949.450 949.550 948.200 948.250 948.425

6 948.950 949.025 949.100 948.775 950.500 950.425 950.525 948.875 948.925 949.100

7 950.125 950.200 949.875 949.725 951.850 951.775 951.875 950.050 950.100 950.275

8 951.025 950.825 951.025 950.975 950.950 951.000 951.175

9 951.675 951.700 951.700 951.625 951.600 951.650 951.825

RF CARRIER FREQUENCY RANGE

470.000 to 952.000 MHz (available frequencies depend on the applicable regulations in the country where the system

is used). Refer to the frequency supplement supplied with the system.

ACCESSORIES

Furnished with ULXP4: UA820X 1/2 Wave Antenna (944-952Mhz)

Furnished with ULXS4: UA400 1/4 Wave Antenna (774-952Mhz)

COMPLIANCE INFORMATION

Type accepted under FCC Part 74, FCC ID DD4ULX2A. Type accepted under FCC Part 74, FCC ID DD4ULX1A.
