Users Manual
P20U Series Quick Guide【English】
55o
To place the machine on the desk and to carry it, do the following:
Place the P20U on a at surface such as a table.
Pull the stand upwards to an angle of 55°.
To carry or move your P20U fully extend the angle to 180°.
E Placing on the desk
E Product Overview
E Cleaning the screen
Follow these guidelines for cleaning the outside and handling the screen of the computer:
Turn o the system and disconnect all cables.
Use a cleaning cloth which is soft, lint-free and a little damp to gently wipe the screen
surface. Do not spray liquid directly on the screen.
Follow the steps ~ below to connect the AC adapter to the power jack (DC-IN).
Press the Power button to turn on the system.
E Powering on the system
01 LCD display (Multi-touch)
02 Webcam status LED
03 Webcam
04 4G external antenna x 2 (optional)
05 Power button
06 Kensington® Lock Hole
07 Microphone
08 SD card reader
09 USB 2.0 ports
The product’s colour and specications may vary from the actually shipping product.
A. Begin Installation
For safety reasons, please ensure that the power
cord is disconnected before opening the case.
Latch Latch
B. HDD or SSD Installation
2.
Tear o the adhesive tape of the serial ATA and power
cable.
1.
Replace the back cover and refasten the screws.
E. Complete
1.
Unscrew four screws of the back cover.
2.
Complete.
4.
Carefully push down the memory module until it snaps into
the locking mechanism.
100 x 100mm
10 Clear CMOS button
11 Microphone jack
12 Headphone / Line-out jack
13 HDMI port
14 USB 3.1 Gen 1 ports
15 LAN (RJ45) port
16 Power jack (DC-IN)
17 Cash drawer (RJ11) port (optional)
18 COM 1 and COM 2 ports
19 Hard disk drive LED
20 Power LED
21 MSR with/without transaction support (optional)
22 COM 3 and COM 4 ports (optional)
23 Line collection box
24 NFC (optional)
25 Mono speaker
26 Stand / Handle
27 D-Sub (VGA) port
1.
Locate the SO-DIMM slot on the mainboard.
3.
Gently insert the
module into the slot
in a 45-degree angle.
SO-DIMM slot
C. Memory Module Installation
2.
Align the notch of the
memory module with the
one of the memory slot.
45-degree
angle
3.
Connect the Serial ATA and power cable to the HDD or SSD.
Slide the rack into the chassis and refasten the screws.
Serial ATA and power cable
Use DDR4
SO-DIMM only!
53R-P20U03-H001
Unscrew
This mainboard does only support 1.2 V DDR4
SO-DIMM memory modules.
D. Component Installation
2.
Install the M.2 device into the M.2 slot and secure with the
screw.
1.
Place an HDD or SSD in the rack and secure with the four
screws from the sides. Ax the EMI shielding gasket with
the adhesive tape, as shown.
Read the following precautions before setting up a Shuttle P20U.
CAUTION Do not walk on the power cord or allow anything to rest on it. Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
• This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
E Safety Information
5. Repeat the above steps to install an additional memory
module, if required.
Notch
Cutout
06
05
08
09
10
07
14 15 09 16 17
02 0103
23
26
18
22
11 1312
19 20
1.
As shown, unfasten the screw rst.
E Follow the steps ~ to remove the line collection box cover
180o
DC-IN
Power
button
Place the cable/cord/wire inside the box and stow
the extra cable lengths before closing the cover.
04
21
MSR without
transaction support
or
24 25
27
Pull the cover outward.
Pull it upward.
Pull it upward. EMI shielding
gasket
Screw
Adhesive tape
Screw
M.2 2242/2260/2280 M key slot
Back cover
Serial ATA and power cable
2.
Pull the back cover upward and remove it.
MSR with
transaction support
!
!
04
JP11: USB2 \ USB3
jumper for standby voltage
Pin1-2 = +5V
(Default)
3 2 1
Daughter board (CM008)
Pin2-3 = +5VS
(Standby)
COM4 (optional) COM3 (optional)
COM1
COM2
JP13: COM port quantity jumper
Pin1-2 = COM port x 2
(Default)
3 2 1
COM port x 4
Pin2-3 = COM port x 3
The touch of your nger replaces the input devices and is all
you need to operate the P20U.
How to use the Touch Panel
E VESA mounting it to the wall
Note : The P20U can be mounted to a wall using a VESA compatible
100 x 100 mm wall/arm bracket.
If you are mounting your P20U to the wall, remove the cover on the back
of the P20U rst. Unscrew four screws of the stand mount and remove the
stand. The VESA standard lets users mount it on to walls easily. Please refer
to the user guide of the wall/arm mount kit you bought separately to install it.
